Husqvarna CTH164T/96051003200 Setup guide

ILLUSTRATED PARTS LIST
MFG. ID NO. 96051003200
CUSTOMER CATALOG NO. CTH164T
PRODUCT NO. 960 51 00-32
532 44 61-68 Rev. 14
47
47

2
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
6
2
1
3
11
4
10
5
9
8
7
wheel_art_1-tex
WHEELS AND TIRES
KEY PART
NO. NO. DESCRIPTION
1 532 05 91-92 Cap Valve Tire
2 532 06 51-39 Stem Valve
3 532 13 83-36 Rim Front
4 532 05 99-04 Tube Front (Service Item Only)
5 532 10 62-22 Tire Front 15 x 6.0-6
6 532 12 49-57 Fitting Grease (Front Wheel Only)
7 532 12 49-59 Bearing Flange (Front Wheel Only)
8 532 17 50-39 Cap Axle Blk 1 50 x 1 00
9 532 42 05-31 Tire R.TS 18 x 9.5-8.C.Ser.
10 532 12 49-26 Tube Rear (Service Item Only)
11 532 13 83-37 Rim Asm 8" Rear
- - 532 14 43-34 Sealant, Tire (10 oz. Tube)
TRACTOR - MODEL NO. CTH164T (96051003200), PRODUCT NO. 960 51 00-32
DECALS
27
27
KEY PART
NO. NO. DESCRIPTION
1 532 44 55-03 Decal Warning Sym. CE
2 532 19 68-41 Decal Warning Eng. Sym.
3 532 17 83-02 Decal Operator Cruise Symbol
4 532 43 88-95 Decal Replacement
5 532 44 02-47 Decal, Lower Dash
6 532 18 04-32 Decal 100 DBA
7 581 62 73-01 Decal Hood
8 532 44 61-59 Decal Side Panel
9 532 40 11-46 Decal Bypass
11 532 18 21-66 Decal Mower Cut Finger Symbol
14 532 15 97-36 Decal Chassis Hot Muffler
21 532 44 11-89 Decal Belt Schematic
22 532 44 51-02 Decal, Battery
23 532 44 46-19 Decal, Bypass
24 532 44 54-93 Decal, Info/Warning
- - 532 44 14-09 Pad, Footrest Pad LH
- - 532 44 14-10 Pad, Footrest Pad RH
- - 532 44 49-27 Manual Operator's (Euro)
KEY PART
NO. NO. DESCRIPTION
7
14
21
7
6
5
1
3
99
14 4
11
2
11
8
23
24 22

3
M
FUSE
STARTER
SOLENOID
BATTERY
REVERSE SWITCH (NOT IN REVERSE)
SEAT SWITCH (NOT OCCUPIED)
FULL BAG
IGNITION
UNIT
HOUR
METER
CHASSIS HARNESS
CONNECTOR (C1)
(MATING SIDE)
DASH HARNESS
CONNECTOR (C1)
(MATING SIDE)
FUEL
LINE
FUEL SHUT-OFF
SOLENOID
(IF SO EQUIPPED)
C1
S
M
B
G
L
2
3
1
6
A2
A1
M
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
(OPTIONAL)
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE RE-INSTALLED TO
PROPERLY SECURE YOUR
WIRING.
SCH19
IGNITION SWITCH
CIRCUITPOSITION
OFF
B+A1
RUN/OVERRIDE
B+S+A1START
M+G+A1
B+A1RUN
“MAKE”
L+A2
PTO SWITCH
(DISENGAGED)
BLACK
BLACK /WHITE
BLUE
BLUE BLACK
GREEN
BLACK
YELLOW
BLK/WHT
BLACK
BLK/WHT
DER
WHITE
WHITE
GRAY
GRAY
BLACK
YELLOW
POWER OUTLET
(OPTIONAL)
12V
BLACK
BLUE
BLACK
BROWN
HEADLIGHTS
LIGHT SWITCH
ORANGE
CLUTCH/BRAKE
(PEDAL UP)
WHITE
GREEN
GREEN
BLUE RED
BAG PRESENT SWITCH
(BAG ATTACHED)
SHORTING CONNECTOR
BAG FULL SWITCH
(NOT FULL)
9
BUZZER
BLACK
BLACK
BLACK
BLUE BLACK
5
6
C1
4
C1
BROWN
8
C1
DER RED
1
2
3
654
98
123
456
89
ELECTRIC CLUTCH
BLACKRED
REGULATOR STATOR
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
CHARGING SYSTEM OUTPUT
9-16AMPDC@3600 RPM
TRACTOR - MODEL NO. CTH164T (96051003200), PRODUCT NO. 960 51 00-32
SCHEMATIC
38
38

4
30
33
34
22
79 21
26
40
71
16
TC09S
28
55
With Service Minder Option
4646
43
27
99
25
108
83
107
2
102
105
29
TRACTOR - MODEL NO. CTH164T (96051003200), PRODUCT NO. 960 51 00-32
ELECTRICAL
32
32

5
TRACTOR - MODEL NO. CTH164T (96051003200), PRODUCT NO. 960 51 00-32
ELECTRICAL
32
32
KEY PART
NO. NO. DESCRIPTION
1 532 43 71-57 Battery
2 532 44 09-23 Screw Hex Hd Cap M6 x 1.12MM
16 532 17 61-38 Switch Interlock Push-In
21 532 40 02-52 Harness Socket Light w/4152J
22 532 00 41-52 Bulb Light
25 532 43 71-62 Cable Starter
26 532 17 51-58 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 43 71-63 Cable, Ground
29 532 40 15-45 Switch, Seat
30 532 19 33-50 Switch, Ign
33 532 41 19-35 Key/Chain
34 532 11 07-12 Switch Light/Reset
40 532 42 95-33 Harness Ign. Dash/Lift
43 532 19 25-07 Solenoid
46 532 40 17-63 Gauge Serviceminder Hrmtr
50 532 17 46-51 Switch PTO
55 817 06 05-12 Screw Thdrol 5/16-18 x 3/4 TYTT
71 532 44 08-20 Harness Ignition (Chassis)
79 532 17 52-42 Socket Asm. Bulb
83 532 43 67-74 Nut Square M6 x 1.8.5 x 11MM
99 817 72 04-08 Screw 1/4-20 x 1/2
102 532 44 12-62 Tex ROS Tuff Torq.
105 532 40 75-68 Switch Reverse
107 532 18 03-79 Switch Tall Bagger
108 532 42 10-62 Switch Snapmount
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
