Hussmann RGSSFP Instruction Manual

22
1 of 22
RGSSFP
Technical Data Sheet
Rev A
S
p
ecialt
y
Products
RGSSFP
These merchandisers are manufactured to meet ANSI/National Sanitation
Foundation Standard #7 requirements.
We reserve the right to change or revise specifications and
p
roduct design in connection with any feature of our
p
roducts. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
CUL Listed
UL Sanitation
REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75F and 55% R.H.
Discharge Air (F) 28
Discharge Air (F) 30 (Rear Storage Only)
Evaporator (F) 18
Evaporator Air (F) 20 (Rear Storage Only)
N
ote: Not recommended to control temp by regulating
coil temp allow t-stat to cycle and control temp.
Front
B
tu/hr/
ft
*
Parallel 650
Conventional 748
Refrigerated Dome
Parallel 200
Conventional 230
Rear Storage
Parallel 175
Conventional 201
*For all refrigeration equipment other than Hussmann,
use conventional Btu values.
DEFROST DATA
Frequency Hrs 6
OFFTIME
Temp Term °F 54
Failsafe Minutes 40
ELECTRIC or GAS Not Recommended
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 ½*
Merchandiser Liquid Line (in.) 3/8*
Merchandiser Suction Line (in.) 5/8*
Estimated Charge (lb)***
4ft 1.2
5ft 1.5
6ft 1.8
*Dependent on case length and refrigerant type.
*** This is an average for all refrigerants types. Actual
refrigerant charge may vary by approximately half a
p
ound. GLYCOL REQUIREMENTS
GPM PSI
NA NA

22
2 of 22
RGSSFP
Technical Data Sheet
Rev A
S
p
ecialt
y
Products
RGSSFP
350 RGSSFP Self Contained ►4' W3500001
6' W3500002
8' W3500003
12' W3500005
Self Contained ►6' W3500006
8' W3500007
5' W3500008
Self Contained ►6' W3500009
351 RGSSFP-Combos 4' W3510001
6' W3510002
Self Contained ►6' W3510006
8' W3510003
12' W3510005
4' DRY/2 HOTWELLS/ 4' REF 8' W3510007
8' DRY/6 SOUP SELLS 8' W3510008
RGSSFP-REM-8 Hot/Cold 8' W3510010
