2. WIRING REQUIREMENTS
• The unit requires connection to a 230 AC 50Hz mains electricity supply.
• It is recommended that the unit is connected to the lighting circuit via a 5 amp fused spur and using Twin &Earth 2-Core
round flexible cable ofatleast 1mm gauge (waterproof cable should be used for outdoor installations).
• It is also advisable to install a singlepole wall switch to allow easy controlof thefloodlight [Fig. 1].
3. FIXING THE MIGHTYLITE PRO
WARNING: Isolate the power supplybefore installation.
The Mightylite can be fixed in position by EITHER:
Option 1: AttachingtheUbracket to the mounting surface and attaching the Mightylitetothe U bracket, or
Option 2: Clamping the pipe bracket to the U bracket around a pipe or pole, and then attaching the Mightylite.
3.1. OPTION 1: ATTACHING THE MIGHTYLITE PRO VIATHE U BRACKET
If attaching the Mightylite Pro direct to a wall using the U bracket:
• Select a mounting point which is strong enough to support the weight of the Mightylite.
• Attach the Mightylite Protothe U bracket using the two securing bolts provided [Fig.2].
• Position theunit against the mounting surface and mark the position for the U bracket, ensuringthe wires can easily
reach theunit.
• Use the Ubracket Fixing Holes [Fig.3] to mark the 4 drill holes required to secure the U bracket tothe wall (and mark the
cable outlet location if required).
• Detach the Mightylite Profromthe U bracket, drill the wall and screw U bracket onto thewall using appropriatefixings
which are able support the weight of the Mightylite Pro.
• Oncethe U bracket is securely attached to the wall, offer the Mightylite Pro up to the U bracket and secure using the
securing bolts,spring washers and washers provided [Fig.2].
• Loosen the 4 screws holding thefront of the connection box in place and remove.
• Feed the wire through the cable gland on the connection box gently tighteninggland nut up against the gland body
[Fig. 4] to ensure the wire(s) is secured in place and no water can get though intothe connection box.
• Wirethe MightylitePro as described in Section 4.
2
Fig. 2 Fig. 3 Fig. 4 Fig. 5
PIPE
Fixing Holes
Fixing to a pipe
MightyliteTo Mains
N In
EARTH
N Out
L OutL In
Fig.1
Fig. 6
3.2. OPTION 2: ATTACHING THE MIGHTYLITE VIATHE PIPE BRACKET
If attaching the Mightylite Pro to a pipeor post using the pipe bracket, first ensurethe pole is strong enough to support the
weight of the Mightylite then proceed as follows:
• Establish the correct position for the Mightylite Pro on the pipe ensuring thewires can easily reach the unit.
• Position thepipe bracket and U bracket around the pipe and secure using appropriate nuts bolts and washers (included),
as shown in [Fig.5].
• Offer the Mightylite Pro up to the U bracket and secure using the securing bolts, spring washers and washers
provided [Fig.2].
• Loosen the 4 screws holding thefront of the connection box in place, and remove.
• Feed the wire through the cable gland, gently tightening gland nut up against the gland body [Fig.4]to ensurethe
wire(s) is secured in place and no water can get though into the connection box.
• Wirethe MightylitePro as described in Section 4.
4. WIRING THE FLOODLIGHT
• Oncethe power cable has been fed through the cable gland, approximately 6mm of insulation should be stripped
from each of the cores of AC cableready to attach it to the terminal block in the front of the light fitting.
NOTE: Hylite Mightylite Pro are Class 1 fittings and therefore need to be Earthed
4.1 CONNECTING TO POWERSUPPLY
IMPORTANT: The Mightylite Pro has two dual channel drivers which control the 4 LED arrays within the Mightylite Pro. The four
BROWN(Live) wires in the Mightylite Pro terminal, each operate as the Live for each of theLED arrays, enablingthe arrays to
be wired to be switched on and off independently of each other (See Section 4.2 Wiring Options). The two BLUE (Neutral)
wires in the terminal operate as the Neutral for each of the drivers.
The unit is supplied with all4wires linked into 2 terminals which are, in turn, connected by a single BROWN wire. To wire the
unit so all4 LED arrays operate together from a single switch (Single Level wiring) proceed as follows:
• Connect the BROWN or RED (Live) wireto either terminal (marked “L”) holding 2 BROWN wires in the floodlight unit,
and linked together by a single BROWN wire [Fig.6].
• Connect the BLUE or BLACK (Neutral) wire to the terminal (marked “N”) holding the2 BLUE wires in the floodlight unit
[Fig.6].
• Connect the YELLOW/GREEN or BARE (Earth) wire to the terminal (marked “EARTH”) holding theYELLOW/GREEN
wire in the floodlight unit
4.2 WIRING OPTIONS
Live
Neutral
Earth
Fig.7 Wiring for Single LightingLevel
Note: One switch operates the Mightylite Pro which is always
at full power (100% light level) when switched on.
Note: Oneswitch operates two of theMightylitePro LED
arrays, and another controls the other two arrays, enabling the
unit to operate at 50% or 100% power dependent on
switching.
Fig.8 Wiring for Two Lighting Levels
L1 (LIVE)
L2 (LIVE)
NEUTRAL
EARTH
