Hyper HYPERDRIVE HDM1H User manual

HYPERDRIVE
Dual HDMI 10-in-1
Travel Dock
USER GUIDE

Safety Instructions 1
Copyright 1
Trademarks 1
Regulatory Compliance 2
FCC Conditions 2
CE 2
WEEE Information 2
Introduction 3
Package Contents 3
Product Compatibility 3
Product Overview 4
Specifications 6
Hyper Driverless Display Technology 7
Setup for Windows 7
Setup for Mac 9
Warranty 11
Safety Warnings 13
Technical Support 14
Table of Contents

1
Before attempting to connect, operate or adjust
this product, please save and read the User Guide
completely. The style of the product shown in this
User Guide may be dierent from the actual unit due
to various models.
Copyright
This document contains proprietary information protected
by copyright. All rights are reserved. No part of this guide
may be reproduced by any mechanical, electronic or
other means, in any form, without prior written permission
of the manufacturer.
Trademarks
Hyper, the ++Hyper logo, and HyperDrive are trademarks
or registered trademarks of Targus International LLC,
in the U.S. and in certain other countries. USB-C is a
registered trademark of USB Implementers. Windows
is a registered trademark or trademark of Microsoft
Corporation in the United States and/or other countries.
Mac, macOS, and iPad are trademarks of Apple Inc.,
registered in the U.S. and other countries. The terms
HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. Android,
Chromebook, and Chrome OS are trademarks of Google
LLC. All trademarks and registered trademarks are the
property of their respective owners or companies.
© 2023 Targus International LLC,1211 North Miller Street,
Anaheim, CA 92806 USA. All rights reserved.

2
Regulatory Compliance
FCC Conditions
This equipment has been tested and found to comply
with Part 15 Class B of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not
cause harmful interference. (2) This device must accept
any interference received and include interference that
may cause undesired operation.
CE
This equipment is in compliance with the requirements of
the following regulations: EN 55032/EN 55024: CLASS B
WEEE Information
For EU (European Union) member users: According to
the WEEE (Waste electrical and electronic equipment)
Directive, do not dispose of this product as household
waste or commercial waste. Waste electrical and electronic
equipment should be appropriately collected and recycled
as required by practices established for your country. For
information on recycling of this product, please contact your
local authorities, your household waste disposal service or
the shop where you purchased the product.
CAN ICES-003(B)/NMB-003(B)

Package Contents
• HyperDrive Dual HDMI 10-in-1 Travel Dock
• User Guide
Introduction
The HyperDrive Dual HDMI 10-in-1 Travel Dock is easy to
carry, and the Hub with multiport function to connect your
USB-C laptop to multiple devices. The Dock can be seamless
to connect 10 kinds of devices, with this USB-C multiport hub
you can connect HDMI display, 4K60Hz monitors, USB-C PD
to your laptop. The USB-C PD port can connect to a 100W
PD 3.0 adapter to provide PD passthrough charging to your
computer.
3
Product Compatibility
Windows® PC, Mac®, iPad®*, Chromebook™, Android™
Devices** and USB-C Devices that support DP Alt Mode,
Data, and Power Delivery
* For iPad, it’s only support single display.
** For Android device, please help to download driver at:
https://www.siliconmotion.com/downloads/index.html
Requirements
• This Dock device support multi devices.
• The host device’s USB-C port must support Power
Delivery, DisplayPort Alt Mode and USB-C 3.2
Gen 1 or 2 Data.
• This Dock is supported on Windows, Chrome OS
and macOS.

4
Product Overview(Left Side)
Item Description
1. 3.5mm Audio Port Connects to a headset
2. USB-C Port Connects to a USB-C device
3. USB-A Port x 2 Connects to a USB-A device
4. HDMI Port Connects to a HDMI monitor
5. HDMI Port Connects to a HDMI monitor
6. USB-C Host Port Connects to a Host Computer
4
6 7 8
1
2
3
4
5

Product Overview(Right Side)
Item Description
7. Ethernet Port Connects to Ethernet network
8. USB-C PD Port Connects to a Max 100W USB-C
PD Power Adaptor
9. SD Card Connects to a standard SD Card
10. Micro SD Card Connects to a standard Micro SD Card
5
7 8
9
10

6
Specifications
Interface USB-C
(Host)
USB 3.2 Gen1 5Gbps, PD
Passthrough 3.0 Max 100W
PD Passthrough charging requires
Host USB PD Support
Max 100W requires PD 3.0 support
3.5mm Audio 3.5mm audio device
USB-C
(Device)
USB 3.2 Gen1 5Gbps
USB-A
(Device) x 2
USB 3.2 Gen1 5Gbps
HDMI (Device) HDMI 2.0 4K60Hz display
HDMI (Device) HDMI 1.4 4K30Hz display
USB-C PD
Port
Connect to PD Adapter, Max
100W PD 3.0
SD Card
Reader
Connects to a standard SD card
Micro SD
Card Reader
Connects to a standard Micro
SD card
Dimension
& Weight
Length
Width
Height
125mm / 4.92inch
67mm / 2.64inch
18mm / 0.7inch
Weight 180g / 0.4lb

HYPER DRIVERLESS
DISPLAY TECHNOLOGY
SETUP FOR WINDOWS
1Connect the USB-C Display Hub to your Windows
computer.
2The computer will ask if you want to open a drive. Open
the drive, then select “Windows InstantView.exe.”.
3A permission screen should appear, asking if you want
to install the software. Select “Install.” You can choose to
“Always trust software from Silicon Motion, Inc.”
7

8
4A Hyper Plug & Play window will appear. Simply
hit connect and you will get to choose between
Extended Mode or Mirrored Mode.
Switch to Extended Display
Switch to Mirrored Display
Disconnects Monitor
Disconnects Monitor
EXTENDED MODE:
MIRRORED MODE:
