HyQuest Solutions DH59 User manual

DH59
User Manual
04-2023 – 01-01-000

© 2023 HyQuest Solutions 2
Table of Contents
Disclaimer 3I
II Scope of Delivery 4
III Safety Instructions 5
Part I Introduction 6
Part II Operation 7
2.1 Example ............................................................................................................................................................... 7
2.2 Diagram .............................................................................................................................................................. 9
Part III Repair 10
Part IV Technical Data 11
Part V Obligations of the Operator and Disposal 12
5.1 Obligations of the Operator ....................................................................................................................... 12
5.2 Dismantling / Disposal ................................................................................................................................ 12

Copyright Notice: No parts of this work may be
reproduced in any form or by any means without the
written permission of the publisher. HyQuest
Solutions waives copyright for users to print out
parts of the documentation in hard copy for their
own use only.
Trademark Notice: HyQuest Solutions (HS) and
KISTERS products and services referred to in this
document are trademarks or registered trademarks
of HyQuest Solutions or KISTERS AG. Other product
names used may or may not be the trademarks of
their respective owners.
© 2020 HyQuest Solutions, a KISTERS Group
Company. Any rights not expressly granted herein
are reserved.
The information provided in this manual was deemed
accurate as of the publication date. However, updates
to this information may have occurred.
This manual does not include all of the details of
design, production, or variation of the equipment
nor does it cover every possible situation which may
arise during installation, operation or maintenance.
HyQuest Solutions shall not be liable for any
incidental, indirect, special or consequential damages
whatsoever arising out of or related to this
documentation and the information contained in it,
even if HyQuest Solutions has been advised of the
possibility of such damages.
Any errors found in any HyQuest Solutions product
should be reported to HyQuest Solutions where
every effort will be made to quickly resolve the
problem.
This document is public.
3© 2023 HyQuest Solutions
I Disclaimer

© 2023 HyQuest Solutions 4
II Scope of Delivery
§ Sampler with three nozzles: 3.2, 4.8 and 6.3 mm diameter
§ Sampler bottle: 0.5 litres, nylon, screw cap for DH48, DH59 and D49 units (additional bottles available as spare parts)
§ Carry case
© 2023 HyQuest Solutions 4

§ Read the user manual including all operating instructions prior to installing, connecting and powering up the HyQuest
Solutions DH59. The manual provides information on how to operate the product. The manual is intended to be used
by qualified personnel, i.e. personnel that have been adequately trained, are sufficiently familiar with installation,
mounting, wiring, powering up and operation of the product.
§ Keep the user manual on hand for later reference!
§ If you encounter problems understanding the information in the manual (or part thereof), please consult the
manufacturer or its appointed reseller for further support.
§ HyQuest Solutions DH59 is intended to be used in hydrometeorological or environmental monitoring applications.
§ Before starting to work, you have to check the functioning and integrity of the system.
§ Check for visible defects on the DH59, this may or may not include any or all of the following mounting facilities,
connectors and connections, mechanical parts, internal or external communication devices, power supplies or
power supply lines, etc.
§ If defects are found that jeopardize the operational safety, work must be stopped. This is true for defects found
before starting to work as well as for defects found while working.
§ Do not use the HyQuest Solutions DH59 in areas where there is a danger of explosion.
§ The present user manual specifies environmental/climatic operating conditions as well as mechanical and electrical
conditions. Installation, wiring, powering up and operating the HyQuest Solutions DH59 must strictly comply with
these specifications.
§ Perform maintenance only when tools or machinery are not in operation.
§ If guards are removed to perform maintenance, replace them immediately after servicing.
§ Never make any electrical or mechanical diagnostics, inspections or repairs under any circumstances. Return the
product to the manufacturer’s named repair centre. You can find information on how to return items for repair in the
relevant section of the HyQuest Solutions website.
§ Disposal instructions: After taking the HyQuest Solutions DH59 out of service, it must be disposed of in
compliance with local waste and environmental regulations. The HyQuest Solutions DH59 is never to be disposed in
household waste!
§ Inputs and outputs of the device are protected against electric discharges and surges (so-called ESD). Do not
touch any part of the electronic components! If you need to touch any part, please discharge yourself, i.e. by touching
grounded metal parts.
III Safety Instructions
© 2023 HyQuest Solutions 5

© 2023 HyQuest Solutions 6
Introduction
1Introduction
Thank you for choosing our product. We hope you will enjoy using the device.
HyQuest Solutions manufactures, sells, installs and operates quality instrumentation, data loggers and communication
technology. Products are designed with passion for environmental monitoring and with a deep understanding of the
quality, accuracy and robustness needed to fulfil the requirements of measurement practitioners in the field.
The present User Manual will help you understand, install and deploy the device. If, however, you feel that a particular
information is missing, incomplete or confusing, please do not hesitate to contact us for further support!
DH59 is an easy-to-use medium-weight suspended sediment sampler.

© 2023 HyQuest Solutions 7
Operation
2Operation
Round bottles are used for sample containers. Pressure from a spring tensioned operating rod holds and seals the bottle
against a rubber gasket within the casting. The contact between the sample bottle and the gasket should be air tight and
should be tested by blocking off the air exhaust tube with a finger and blowing into the nozzle each time a bottle is fitted
to the sampler.
The axis of the sample container is inclined at an angle to the vertical which permits sampling to within 90mm of the
stream bed. With the instrument oriented into the direction of flow (nozzle horizontal and pointed upstream) a
continuous stream filament is discharged into the sample bottle during the period of submergence. The air displaced by
the sample is ejected through the air escape passage projecting from the instrument alongside the head and oriented to
discharge downstream.
A fixed static head differential between the intake and air exhaust facilitates sampling in low stream velocities and slack
waters.
Three nozzles, 1/8", 3/16" and 1/4" diameter, are supplied with each sampler.
One is chosen for each sampling cross section according to the velocity and depth to be sampled.
A clean bottle should be used for each separate sediment sample.
At least one suspended sediment sample is taken at each stream vertical selected in the cross section. In a sampling
operation, the intake nozzle is oriented upstream, directly into the current while the sediment sampler is lowered into the
stream.
Submerged obstructions directly upstream or adjacent to the sampler should be avoided to preclude interference with
the stream filament approaching the intake nozzle.
The sampler should be lowered at a uniform rate from the water surface to the bottom of the stream, instantly reversed,
and then raised again to the water surface at a uniform but not necessarily an equal rate. Each filled sample bottle when
removed from the instrument should be capped immediately and appropriately marked.
The sampler continues to take its sample in flowing water throughout the time of submergence, even after the bottle is
completely filled. If the bottle becomes entirely full, the sample may not be representative and should be discarded.
Although the capacity of the sample container is about 470ml, the tilt of the bottle is such that any sample containing
more than 440ml of a water sediment mixture may be in error.
In order to provide sufficient sample of a laboratory analysis, the length of time the instrument remains submerged
should be adequate to produce a sample volume greater than 375ml but not to exceed 440ml. It is generally preferable
to save an initial sample smaller than 375ml but larger than
300ml than to discard the sample on the spot and re-sample into the same bottle. Moreover, if the initial sample volume
is considerably less than
300ml, the stream vertical may be integrated a second time, or even a third time, each being additive to the same sample
bottle. A minimum sample of 350ml is suggested.
Sample Size
The volume of sample collected throughout any stream vertical is dependent primarily upon the mean stream velocity in
the vertical, the size of the intake nozzle, and the time of submergence of the instrument. The operator must regulate the
size of the sample accumulated by establishing the appropriate time period over which the sample is to be taken. Thus the
volume of the sample may be increased or decreased by varying correspondingly the sampling time. The attached graph
shows the relation between stream velocity and filling time to produce samples 395ml in volume for three different
nozzle sizes. The filling time in seconds represents the total time of submergence of the instrument and includes the time
involved in traversing the stream vertical in both the downward and upward direction.
2.1 Example
(Refer Diagram 1 )
Mean Velocity 1.2 metres/sec.
Nozzle 1/4"
Filling Time 10 seconds
9

© 2023 HyQuest Solutions 8
Operation
If the sampler is lowered from the water surface to the stream bed at a uniform rate in 5 seconds, it should be raised at a
uniform rate so as to break the water surface at the expiration of the next 5 seconds. The time of traversing the stream
vertical need not be the same in both directions of travel. However, the rate at which the sampler moves vertically must
remain uniform in each direction of travel. Thus, in the above example, the stream vertical could have been traversed at a
uniform rate downward in 4 seconds and the sampler raised at a uniform rate upward to clear the water surface in 6
seconds, the total 1 submergence period still being 10 seconds.
Sample Notations
Adequate information and data to identify the sample and to satisfy the purposes of the investigation should be recorded
at the time of sampling. The following items are suggested:
§ Name of Gauging Station
§ Location of the cross section
§ Location of vertical
§ Stream depth covered by the sample
§ Stage of the stream
§ Date
§ Time of day
§ Identification of personnel
§ Sampling time
§ Water temperature
§ Coordination with sample groups
§ Serial number of sample
Before the bottle are reused they should be washed clean inside and outside to avoid contamination of future samples.

© 2023 HyQuest Solutions 9
Operation
2.2 Diagram

© 2023 HyQuest Solutions 10
Repair
3Repair
HyQuest Solutions precision instruments and data loggers are produced in quality-controlled processes. All HyQuest
Solutions production and assembly sites in Australia, New Zealand and Europe are ISO 90001 certified. All equipment is
factory tested and/or factory calibrated before it is shipped to the client. This ensures that HyQuest Solutions products
perform to their fullest capacity when delivered.
Despite HyQuest Solutions most rigorous quality assurance (QA), malfunction may occur within or outside of the warranty
period. In rare cases, a product may not be delivered in accordance with your order.
In such cases HyQuest Solutions’ return and repair policy applies. For you as a customer, this means the following:
1. Contact HyQuest Solutions using the Repair Request Form made available online:
https://cdn.hyquestsolutions.eu/fileadmin/Services/Downloads/HS-RepairRequestForm_EU.pdf
In response you will receive a reference number that must be referenced on all further correspondence and on the
freight documents accompanying your return shipment.
2. Please provide as much information and/or clear instructions within the return paperwork. This will assist our test
engineers with their diagnosis.
3. Please do not ship the goods prior to obtaining the reference number. HyQuest Solutions will not reject any
equipment that arrives without reference number; however, it may take us longer to process.
Custom requirements for items sent to HyQuest Solutions for warranty or non-warranty repairs: Check with your
national customs/tax authorities for details, processes and paperwork regarding tax exempt return of products. Typically,
special custom tariff codes are available (such as HS Code = 9802.00) that verify the item is being returned for repair and
has no commercial value. Please note that the customs invoice / dispatch documents should also clearly state: “Goods
being returned to manufacturer for repair – No Commercial value”. It is mandatory to have any returned goods
accompanied by a commercial invoice on headed paper. HyQuest Solutions reserves the right to charge the customer for
time spent rectifying incorrect customs documents.
Note: Please ensure that your goods are packed carefully and securely. Damage that occurs during transit is not covered
by our warranty and may be chargeable.

© 2023 HyQuest Solutions 11
Technical Data
4Technical Data
Type
Suspended sampler using a winch, depth integrating
Material
Epoxy-coated cast, marine bronze body
Net Weight
10 kg (22 lb)
Length
380 mm
Packing Details
16 kg, 0.01 m3

© 2023 HyQuest Solutions 12
Obligations of the Operator and Disposal
5Obligations of the Operator and Disposal
This chapter contains the following subsections:
§ Obligations of the Operator
§ Dismantling / Disposal
5.1 Obligations of the Operator
European Union
In the Single European Market it is the responsibility of the operator to ensure that the following legal regulations are
observed and complied with: national implementation of the framework directive (89/391/EEC) and the associated
individual directives, in particular 2009/104/EC, on minimum safety and health requirements for the use of work
equipment by employees at work.
Worldwide
Regulations: If and where required, operating licences must be obtained by the operator. In addition, national or regional
environmental protection requirements must be complied with, regardless of local legal provisions regarding the
following topics:
§ Occupational safety
§ Product disposal
Connections: Local regulations for electrical installation and connections must be observed.
5.2 Dismantling / Disposal
When disposing of the units and their accessories, the applicable local regulations regarding environment, disposal and
occupational safety must be observed.
Before dismantling
§ Electrical Devices:
§ Switch off the units.
§ Disconnect electrical appliances from the power supply, regardless of whether the appliances are connected to the
mains or to another power source.
§ Mechanical devices:
§ Fix all loose components. Prevent the device from moving independently or unintentionally.
§ Loosen mechanical fastenings: Please note that appliances can be heavy and that loosening the fastenings may
cause them to become mechanically unstable.
Disposal
Operators of old appliances must recycle them separately from unsorted municipal waste. This applies in particular to
electrical waste and old electronic equipment.
Electrical waste and electronic equipment must not be disposed of as household waste!
Instead, these old appliances must be collected separately and disposed of via the local collection and return systems.
Integrated or provided batteries and accumulators must be separated from the appliances and disposed of at the
12
12

© 2023 HyQuest Solutions 13
Obligations of the Operator and Disposal
designated collection point. At the end of its service life, the lithium-ion battery must be disposed of according to legal
provisions.
EU WEEE Directive
As players in the environmental market, KISTERS AG and HyQuest Solutions are committed to supporting efforts to avoid
and recycle waste. Please consider:
§ Avoidance before recycling!
§ Recycling before disposal!
This symbol indicates that the scrapping of the unit must be carried out in accordance with Directive 2012/19/EU.
Please observe the local implementation of the directive and any accompanying or supplementary laws and regulations.

Contact Data
© 2023 HyQuest Solutions
Europe
Australia
New Zealand
Latin America
North America | Hydrological Services America LLC
(KISTERS Group)
| HyQuest Solutions (KISTERS LATAM)
| HyQuest Solutions NZ Ltd
| HyQuest Solutions Pty Ltd
| HyQuest Solutions (KISTERS AG) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
[phone]
[e-mail]
www.hyquestsolutionsamerica.com
[phone]
[e-mail]
www.hyquestsolutions.es
[phone]
[e-mail]
www.hyquestsolutions.com.au
[phone]
[e-mail]
www.hyquestsolutions.com.au
[phone]
[e-mail]
www.hyquestsolutions.eu

www.hyquestsolutions.com
© 2023 HyQuest Solutions
04/04/2023
