Hytorc LITHIUM Series User manual

LITHIUM SERIES® Electric Torque Tool
(BTM and BTM-DOC Models)
Operations Manual
333 Route 17 N.
Mahwah, NJ 07430
USA
800-FOR-HYTORC
(800-367-4986)
201-512-9500
hytorc.com
Firmware Version 1.26

This manual provides information for the standard LITHIUM SERIES® Electric Torque Tool.
Models: BTM-0250, BTM-0700, BTM-1000, BTM-2000, BTM-3000, BTM-0250-DOC, BTM-0750-DOC, BTM-1000-DOC, BTM-2000-DOC,
BTM-3000-DOC
Notice. The information contained in this document is subject to change without notice. HYTORC makes no warranty of any kind with regard to
this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. HYTORC shall not be liable
for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. It is
further recommended that the end-user or repair technician insure they have obtained and are familiar with the latest revision of the manual for the
equipment outlined in this document.
Restricted Rights Legend. Use and duplication of the information contained within this manual is limited to the purchaser, end user, or licensed
HYTORC representative. It is recommended that proper training for the equipment outlined in this manual be conducted by a HYTORC-authorized
training representative for any person who is operating or repairing the equipment outlined in this document. Modification of, or disclosure by any
other agency or representative is strictly forbidden.
Product Modifications. HYTORC DOES NOT ALLOW any of the products listed in this manual to be modified by any end user without exception.
Should an application require a modification to the tool, or any of the standard accessories please consult with your local HYTORC representative and
they will be able to obtain the assistance for any modification that may be required.
LITHIUM SERIES® is a registered trademark of HYTORC.
Copyright © 2020 HYTORC All Rights Reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except as
allowed under the copyright laws.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
ORIGINAL INSTRUCTIONS
ABOUT THIS DOCUMENT

Warranty. The LITHIUM SERIES® Tool has a one-year limited warranty. Every tool is tested before leaving the factory and is warranted to be free from
defects in workmanship and materials. HYTORC will repair or replace, without charge, any tool which, upon examination, proves to be defective in
workmanship or materials for one (1) year after the date of purchase. This warranty does not cover damage resulting from repairs made or attempted
by unauthorized repair facilities. The repair and replacement remedies described herein are exclusive. In no event shall HYTORC be liable for any
incidental, special, or consequential damages, including loss of profits. This warranty is exclusive and in lieu of all other warranties or conditions,
written or oral, expressed or implied for merchantability or fitness for particular use or purpose. This warranty gives you specific legal rights. You may
also have other rights that vary from state to state and province to province. In those states that do not allow the exclusion of implied warranties or
limitation of incidental or consequential damages, the above limitations or exclusions may not apply to you. If you have questions about the warranty,
contact our customer service center at 201-828-5270.
Printed in the USA. January 2020
Complies with standards publication BS EN 82079-1:2012
ABOUT THIS DOCUMENT (CONT’D.)

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual
TABLE OF CONTENTS
1. GENERAL SAFETY INFORMATION 
2. SERVICE 
3. TOOL DESCRIPTION 
4. CARE AND HANDLING 
5. CHARGE, TEST AND INSTALL BATTERY 
6. OPERATING THE CONTROL PANEL 
7. NAVIGATING THE MENUS 
8. SHORTCUTS 
9. BOLTING WITH CONVENTIONAL REACTION ARM 
10. BOLTING WITH THE HYTORC WASHER 
11. BOLTING WITH THE HYTORC NUT 
12. ADDENDUM FOR BTMDOC MODELS ONLY IMPORTANT 
CHANGELOG 

1
A. WORK AREA SAFETY
•Keep work area clean and well lit. Cluttered or dark areas invite accidents.
•Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust or fumes.
•Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
B. ELECTRICAL SAFETY
•Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
•Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
•Do not allow battery to get wet. Do not operate tool in rain, snow or high humidity. Do not splash or immerse
in liquids.
•Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
•When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of electric shock.
•If operating a power tool in a damp location is unavoidable, use a Ground Fault Circuit Interrupt (GFCI)
protected supply. Use of a GFCI reduces the risk of electric shock.
C. PERSONAL SAFETY
•Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a
power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
•Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce personal injuries.
•Prevent unintentional starting. Ensure the switch is in the o-position before connecting to power source
and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
•Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
•Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in
unexpected situations.
•Dress properly. Do not wear loose clothing or jewelry. Keep your hair and clothing away from moving parts.
Loose clothes, jewelry or long hair can be caught in moving parts.
•If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
•Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool
safety principles. A careless action can cause severe injury within a fraction of a second.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
WARNING! Read all safety warnings designated by the symbol and all instructions.
. GENERAL SAFETY INFORMATION

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual 2
E. BATTERY TOOL USE AND CARE
•Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery pack.
•Use power tools only with specifically designated battery packs. Use of any other battery packs may create a
risk of injury and fire.
•When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
•Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery
may cause irritation or burns.
•Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk of injury.
•Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above
130 °C may cause explosion.
•Follow all charging instructions and do not charge the battery pack or tool outside the temperature range
specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the
battery and increase the risk of fire.
F. SERVICE
•Have your power tool serviced by a qualified repair person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
•Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or
authorized service providers.
D. POWER TOOL USE AND CARE
•Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
•Do not use the power tool if the switch does not turn it on and o. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
•Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power
tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
•Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
•Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may aect the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
•Keep cutting tool sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
•Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account
the working conditions and the work to be performed. Use of the power tool for operations dierent from those
intended could result in a hazardous situation.
•Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the tool in unexpected situations.
(CONT’D.)

3
G. IMPORTANT TOOL CARE AND HANDLING
•Inspect all tool components as they are removed from the shipping container. If damage is found to any
component, contact the shipper immediately. Do not use the tool.
•Modifying a tool or tool accessory is dangerous and invalidates the warranty
•Inspect the tool before each use. Have any obviously worn or damaged parts replaced.
•When not in use, store the tool and tool accessories in the plastic storage case supplied with the tool. Do not
store the tool and batteries in an environment outside of the following temperature and humidity range:
-4°F (-20°C) to 122°F (50°C), 5% to 95% ambient relative humidity
H. IMPORTANT BATTERY PACK INSTRUCTIONS
•Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The battery pack
can explode in a fire. Toxic fumes and materials are created when Lithium-ion battery packs are burned.
•Do not charge or use the battery in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Inserting or removing the battery from the charger may ignite dust or fumes.
•Contents of opened battery cells may cause respiratory irritation. Provide fresh air. If symptoms persist,
seek medical attention.
WARNING
Never attempt to open the battery pack for any reason. If battery pack case is cracked or
damaged, do not insert into charger or tool. Do not crush, drop, or damage battery pack.
Do not use a battery pack or charger that has received a sharp blow, has been dropped
or has been run over or damaged in any way (i.e. pierced with a nail, hit with a hammer,
stepped on). Damaged battery packs should be returned to an authorized HYTORC service
center for recycling.
CAUTION
The US Department of Transportation Hazardous Materials Regulations (HMR) actually
prohibit transporting batteries in commerce or on airplanes, (i.e. packed in suitcases and
carry-on luggage). When transporting individual batteries, make sure that the battery
terminals are protected and well insulated from materials that could contact them and
cause a short circuit. For any other concerns in regarding the transportation of LI-ION
batteries, consult your Transportation Carrier.
WARNING
Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
(CONT’D.)

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual 4
I. IMPORTANT BATTERY CHARGER SAFETY INSTRUCTIONS
•Before using charger, read all instructions and cautionary markings on charger, battery pack and product
using battery pack
•DO NOT attempt to charge the battery pack with any chargers other than the one in this manual. The charger
and battery pack are specifically designed to work together.
•These chargers are not intended for any uses other than batteries supplied with LITHIUM SERIES Tools as
described in this manual. Any other uses may result in risk of fire, electric shock or electrocution.
•Do not expose charger to rain or snow
•To disconnect charger, firmly grasp plug and remove. Do not disconnect the charger by pulling on the cord.
•Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to
damage or stress
•Do not use an extension cord unless it is absolutely necessary
•An extension cord must have adequate wire size (AWG) for safety. In general the larger the wire size the greater
the capacity of the cable.
•Do not block any ventilation slots on charger power supply
•To clean the charger, first unplug from the power source, then wipe with a dry cloth
WARNING
Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
WARNING
Burn hazard. To reduce the risk of injury, charge only tool batteries. Other types of batteries
may burst causing personal injury and damage.
CAUTION
Under certain conditions, with the charger plugged into the power supply, the charger
can be shorted by foreign material. Foreign materials of a conductive nature such as, but
not limited to, steel wool, aluminum foil, or any buildup of metallic particles should be kept
away from charger cavities. Always unplug the charger from the power supply when there
is no battery pack in the cavity. Unplug charger before attempting to clean.
J. EMISSIONS
•The noise emission, measured in accordance with EN 62841-1 I.2, is as follows:
– A-weighted sound pressure level LpA does not exceed 70 dB(A)
– A-weighted sound power level LWA = 80.9 dB(A) and its uncertainty KWA = 3dB(A)
•Wear hearing protection when required by job conditions
•The vibration total value and its uncertainty measured in accordance with EN 62841-1 I.3 is as follows:
– The vibration total value does not exceed 2.5 m/s2
•The declared vibration total value has been measured in accordance with a standard test method and may
be used for comparing one tool with another
•The declared vibration total value may also be used in a preliminary assessment of exposure
•The vibration emission during actual use of the tool can dier from the declared total value depending on the
ways in which the tool is used
•Identify safety measures to protect the operator that are based on an estimation of exposure in the actual
conditions of use (taking account of all parts of the operating cycle such as the times when the tool is
switched o and when it is running idle in addition to the trigger time)
(CONT’D.)

5
FREE SERVICES*
FOLLOW US ONLINE
REPAIRS TOOL RENTALS
HELP
•User safety training upon receipt of merchandise
•Semi-Annual user safety training on request
•Annual safety seminar on appointment
•Loaner tools in event of product failure within 24 hours
•Torque/Tension consultation/seminar
•Half-Day, first-use supervision
•Annual product inspection on request
•Product demonstrations
*Above services are not subject to travel expense charges.
•All repairs are guaranteed for 6 months
•All repairs are subject to labor and part cost as outlined
in the oicial HYTORC price list
•All repairs will be tested and calibrated to ensure the
highest quality repairs
•All warranty repairs are free of all charges including
return-freight
•100% of all paid rentals will be applied as a discount
towards any new purchase in that calendar year
•User training for first-time rentals is free of all cost
•Rental tools are guaranteed to perform and are subject
to the free loaner tool policy of HYTORC
If you require any further assistance, please call your local HYTORC Representative or 1-800-FOR-HYTORC
(1-800-367-4986). Please visit us at HYTORC.com.
•12-Month no-questions-asked warranty
•5-Year tool housing warranty
•User training for first-time rentals
•Warranty repairs including return-freight
•Upgrades during the lifetime of the tool to enhance
safety, durability, and function
•Free calibration with new tool purchase
. SERVICE

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual 6
The LITHIUM SERIES® Electric Torque Tool provides the following:
•High-strength planetary gear drive powered by brushed DC electric motor.
•Two Speeds: Fast run-down, high powered torque.
•Electronic control and setup via push-button menu.
•Heads-Up LCD display.
•Ergonomic lightweight hand-held design with pistol-grip and trigger activation.
•Portable tool powered by rechargeable extended-life 36V lithium ion battery.
•Standard square-drive with dual-reaction spline.
•Integrated data acquisition and export capability.
PUSH-BUTTON CONTROL PANEL
. TOOL DESCRIPTION
Eyelet
Brushless DC Motor
Cooling Vents
Square Drive
Reaction Spline
Trigger
Pistol Grip Handle
Battery Lock Button
Battery Test Button
and Charge
36V Rechargable and
Interchangeable Battery
USB Port
Planetary Gear Box
Dual Speed Switch

7
ENVIRONMENTAL CONSIDERATIONS
INSPECT TOOLS & CALIBRATION
The LITHIUM SERIES Tool is a rugged industrial tool with an electric motor and electronic control. The following
environmental considerations will help maintain reliable tool operation. Pictured above, keep cooling vents clear (1), and
secure the tool per local practice (2) to protect from dropping.
•The tool should not be exposed to moisture. Do not operate in rain, snow or extreme humidity.
•The operating temperature of the tool is -4°F (-20°C) to 140°F (60°C).
•All Cooling Vents should be kept clear of dust, dirt and debris to allow internal fans to maintain airflow to keep the motor
and electronics within temperature limits, do not subject the tool to extreme dust environments that would clog the
vents or do not cover the vents with your hand.
•The tool and electronic components are not certified or approved for explosive environments or areas containing
combustible chemical materials.
•Inspect all components; if damaged report any sign of
damage to the shipper and do not use the tool.
•Inspect the tool before each use; repair or replace any
obviously worn or damaged parts.
•Maintenance must be performed by a qualified
technician.
•Modifying any of the components invalidates the
warranty.
•Check the calibration date on the tool. HYTORC
recommends tool recalibration annually.
•If more than a year has passed since last calibration,
contact HYTORC for recalibration.
•When not in use store all tool components in the plastic
storage case.
•Save all instructions and calibration reports in the
storage case.
1 2
. CARE AND HANDLING

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual 8
CHARGE THE BATTERY
•The LITHIUM SERIES® II Tool is supplied with the HYTORC Battery Charger (Model: A000791) and two long-life HYTORC
36-volt batteries (Model: P002036-1)
•Before charging a battery verify the local voltage supply to ensure capability with the charger; this will typically be 110
Volts or 220 Volts AC.
•Only operate the battery charger between 32°F (0°C) to 104º F (40º C) and with 10% to 90% ambient relative humidity
(no condensate)
•Connect the charging cradle to the power supply
•Connect the power cord to a grounded outlet
•If necessary connect the plug adapters to the local power outlet
•Insert the battery by sliding it into the charger and locking into place
•The 36-volt battery is fully charged in approximately 90 minutes
CHARGING/FAULT INDICATOR
•POWER INDICATOR green when charger is plugged into AC outlet
•CHARGING/FAULT INDICATOR is flashing green while battery is charging
•CHARGING/FAULT INDICATOR solid green when battery is fully charged
•CHARGING/FAULT INDICATOR is flashing red for battery fault not charging
BATTERY STORAGE
•Only store the battery and charger in the following environmental conditions:
•-4°F (-20°C) to 122°F (50°C) 5% to 95% ambient relative humidity
Charging Cable
Battery Pack
Charging Cradle Power Indicator Charging/Fault IndicatorLegend Power Supply
Power Supply Cord
. CHARGE, TEST & INSTALL BATTERY

9
BATTERY RECYCLING
Do not ship batteries if they can be disposed of or recycled locally. All defective, damaged or spent batteries should be
disposed of or recycled properly according to these guidelines.
•Dispose of Properly: Li-Ion battery packs should not be disposed of in the household (municipal) waste stream;
they must be taken to an authorized waste collection center or battery recycling center
•Protect the Environment: Drop o your old batteries at a local recycling center near you
TEST THE BATTERY
The Lithium-Ion battery has a long run life and will power
the tool at full speed until the battery is depleted, so there
is no gradual drop in power during use
•For continuous use, have one or more spare battery
packs charging while the tool is in use. When needed,
simply swap batteries from the charger to the tool.
•Batteries can be charged hundreds of times without
any noticeable loss in capacity
•Push the TEST button on the side of the battery and
the LED’s will provide an approximate indicator of
remaining battery life
1 LED ON < 25% Battery Charge Left
2 LEDs ON < 50% Battery Charge Left
3 LEDs ON < 75% Battery Charge Left
4 LEDs ON < 100% Battery Charge Left
INSTALL THE BATTERY
The battery easily slides onto the tool body and snaps
into place
•Press the release button on the battery and slide
battery pack o the charger
•Align the base of the tool with the rails in the
battery and slide the battery pack firmly into the
handle until you hear (or see) the lock snap in place
•To remove the battery pack from the tool, press the
release button on the battery and firmly pull the
battery pack out of the tool
NOTE: When not in use, remove the battery pack from
the tool
Battery Release
Button
(CONT’D.)

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual 10
PRIMARY CONTROL FEATURES
•Press Any Button to Power-On Tool (the tool automatically turns o after 5 minutes)
•A new tool shows the factory default settings
•A tool that has been used before displays the last settings used on the tool before it was powered o
•Left Button Increases the Torque Value
•Right Button Decreases the Torque Value
•Screen Features; Torque, Angle, Release, Direction, Battery Status, Fastener Type, Data Record Indicator
•Push and hold center button to cycle; TORQUE, ANGLE and RELEASE
•Hold 2 Left Buttons to display main and sub-menu options
. OPERATING THE CONTROL PANEL

11
TOGGLE TORQUE, ANGLE & RELEASE
The tool provides simple access to set Torque, Angle and Release by toggling the center button.
•Press and hold the center button for approximately 3 seconds and release it to access the Angle screen.
•Press and hold the center button for approximately 3 seconds and release it to access the Release screen.
•Press and hold the center button for approximately 3 seconds and release it to access the Torque screen.
•The torque setup screen is the home screen for operating the tool.
TORQUE
Push.
Hold for 3 seconds.
Release.
ANGLE
Push.
Hold for 3 seconds.
Release.
RELEASE
Push.
Hold for 3 seconds.
Release.
1 2 3
(CONT’D.)

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual 12
SET TORQUE
SET ANGLE
SET RELEASE
•Push the left button hto increase the Torque value. Push the right button ito decrease.
•Torque may be set to any value from the minimum to the maximum capability of the tool (or MAX
MIN Torque Limits set in the ADMIN menu).
•Torque can be displayed in lb-ft, N-m, kgf-m or %. (See output unit settings under the ADMIN
menu)
•The Torque rotational direction arrow and the rotating nut icon reflect the direction associated with
the specific fastener type. The fastener type may be set under the Operation – Fastener Type menu.
•Certain bolting specifications may require an Angle value in-addition to or instead of a Torque
value.
•The current Angle setting will be displayed in “TT + DDD” format. TT = number of turns and DDD =
angle. Value can be increased or decreased using arrow buttons from “0 + 0” to “99 + 359”.
•Push the left button hto increase the Angle value. Push the right button ito decrease.
•If an Angle value is set the tool will add the desired angle of rotation by applying additional torque
after the completed Torque operation, up to the maximum output of the tool.
•The Angle feature is actuated by holding the trigger after the tool has completed Torque operation.
•Angle is applied after a time delay set in the Angle Delay menu – typical ½ to 3 seconds.
•When the tool achieves the Torque value (and Angle, if set) the motor automatically stalls and the
gear box continues to exert force (and reaction force) essentially locking the tool onto the nut.
•Set a Release Angle to reverse the motor slightly thus taking the applied force o the gear box and
reaction point and releasing the tool from the nut without loosening the nut.
•The Release Angle setting may vary depending on the application and may need to be developed
iteratively by testing the value on the application; the objective is to set the minimum RELEASE
angle required to release the tool without applying a force that would turn or loosen the nut.
•Release Angle is typically set to less than 10 degrees (1-to-3 degrees for HYTORC Washer, or 3-to-7
degrees for reaction arms) so that nut is not loosened.
•The automatic release feature is actuated by continuing to hold the trigger after the tool
successfully completes Torque operations (and Angle if set).
•During operation the screen will show the release angle and direction, the tool motor will reverse
by the desired release angle and then stall again to allow the tool to be removed from the nut.
•The Release Angle is applied following application of Torque (and Angle, if set) and after an
additional time delay set in the Angle Delay menu – typical ½ to 3 seconds.
(CONT’D.)

13
LOOSEN MODE
From the Home Screen, press the middle button to alternate between Torque and Loosen mode. If no angle is set, the
maximum rated torque will be applied in the loosen direction.
Directional Switch
(CONT’D.)

LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual 14
SET LOOSEN ANGLE
The Loosen Angle feature allows the user to loosen by number of full turns (expressed as TT with a range of 0-99), and
degrees of angle (expressed as DDD with a range 0-359).
Press and hold the center button for approximately 3
seconds to enter a new Loosen Angle.
The current Loosen Angle setting will be displayed in “TT +
DDD” format. Where TT = number of turns and DDD = angle.
Value can be increased or decreased using arrow buttons
from “0 + 0” to “99 + 359”.
Press and hold the center button for approximately 3
seconds and release it to access the Loosen Release screen.
A release is required in some applications.
Push the left button hto increase the Release Angle value.
Push the right button ito decrease.
Press and hold the center button for approximately 3
seconds to return to the Loosen Mode screen.
(CONT’D.)

15
MAIN MENU AND SUBMENUS
MAIN MENU
The Main Menu provides Operations, Job Data, System, Admin and the Exit and
Power O options.
Press and hold the left and center buttons simultaneously for approximately
three seconds, to display the Main Menu.
•The green bar highlights the current position
•Press left button (i) to scroll down, right button (h) to scroll up
•Press the center button (g) to select and display a sub-menu
. NAVIGATING THE MENUS
