Hyundai power products HNHP2500SP-195i User manual

1
HIGH PRESSURE WASHER ELECTRIC
HNHP2500SP-195i

2
Warning: Do not use appliance without reading the instruction sheet
1. SAFETY INSTRUCTIONS

Use this unit as described in this manual. Any
mishandling and any use contrary to
instructions for use shall in no case be the
responsibility of the manufacturer.

Failure to observe the safety and operating
instructions may result in a risk of electric
shock, fire and / or personal injury.

If you are giving this unit to another person,
please also provide this manual.

Do not use attachments other than those
recommended by the manufacturer; they can
damage the unit and / or cause injury.

This machine should not be used by children.
Children should be supervised to ensure that
they do not play with the appliance.
This machine can be used by people with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the machine
in a safe way and understand the hazards
involved.

3
Children shall not play with the appliance.

If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.

Before any connection, check:

The appliance, power cable and accessories are
not damaged. In this case, do not use the
appliance and take it to your dealer for
inspection and repair.
 The voltage indicated on the rating plate of
the appliance corresponds to that of your
electrical installation.
 Do not disassemble the device yourself. Any
disassembly, repair or inspection should be
carried out exclusively by a qualified person.

Do not touch the plug with wet hands. Do not
allow the plug to fall into the water.

Do not walk on the power cord, do not exert
excessive pressure, or pull on the cord to avoid
damage.

WARNING: This machine is intended for
use with a cleaning agent supplied or

4
recommended by the manufacturer. Use of
other cleaning or chemical agents may affect
the safety of the machine.
 WARNING: High pressure jets can be dangerous
if misused. The jets should not be directed to
people, electrical equipment or the machine
itself.
 WARNING: Do not use the machine near people
unless they wear protective clothing.

Do not direct the jet against yourself or
others to clean clothes or footwear.

WARNING: Risk of explosion. Do not spray
flammable liquids.
 WARNING: High pressure cleaners should not
be used by children or untrained persons.
 WARNING: Pipes, fittings and connectors are
important for the safety of the machine. Only
use hoses, fittings and connectors
recommended by the manufacturer.

WARNING: To ensure the safety of the machine,
use only the original manufacturer's parts or
approved by the manufacturer.
 WARNING: Water that has flowed through the

5
flow shutters is considered to be unsafe.
 WARNING: The machine must be disconnected
from the power supply during cleaning or
maintenance and when replacing parts or
converting the machine to other functions by
removing the power source plug.
 WARNING: Do not operate the machine if the
power cord or any important parts are damaged,
such as safety devices, high pressure hoses or the
trigger gun.

WARNING: If an extension cord is used, the
plug and cable must be watertight.

WARNING Inadequate extension cords can
be dangerous. If an extension cord is used, it
shall be suitable for outdoor use, and the
connection has to be kept dry and off the
ground. It is recommended that this is
accomplished by means of a cord reel which
keeps the socket at least 60 mm above the
ground.
 WARNING: Make sure there are no exhaust
emissions near the air intakes.
 Children, animals and persons not
participating in the use of the machine must

6
remain at a minimum distance of 10 meters
from the sprayer.

The high pressure hose must remain
connected to the compressor as long as the
system is under pressure.

Do not use corrosive or flammable liquids in the
machine.

The appliance must be connected to a water
supply using a new set of hoses; the old pipe set
must not be reused.

Make sure that there are no exhaust emissions
near the air inlets.

When using the machine, wear protective
equipment including safety goggles, safety
shoes, safety gloves, safety helmet with visor
and double-insulated hearing protection.

In order to move the unit easily, bend the lance.
Make sure the unit is turned off and unplugged
before transporting the unit.
 The connection to the power supply must be made
by a qualified electrician in accordance with
IEC60364-1. It is recommended that the power
supply of this machine includes a residual current

7
device that interrupts power if the earth leakage
exceeds 30 mA for 30 ms or a device that will
homologate the earth circuit.
 Before assembling, dismantling, repairing,
transporting, servicing and storing, please
check if the appliance is disconnected from the
power supply.

Handle the unit with care, do not drop it.
 Do not use the machine in extreme weather
conditions, when it is very cold. Do not use the
machine with ice water.

Use the tool in a stable and plane location.
 The inlet hose can be connected to the water
mains with a maximum pressure of 10 bars.
 The appliance must not be connected to
potable water supply.

CAUTION: In order to avoid danger due to
untimely resetting of the thermal cut-out, this
device must not be powered by an external
switch, such as a timer, or connected to a
circuit that is regularly switched on energized
and de-energized by the electricity supplier.

When transporting the machine, take note of its

8
weight. Do not overestimate your efforts and
get help if necessary.

The machine must be transported from
one point to another and disconnected.
Always use the handle to push the machine.
 Use the handle to lift the machine.
 Improper transport of the machine may result
accidents and injuries.
 During use, transportation, assembly,
dismantling when out of service, testing or
foreseeable breakdowns, the tool must keep
always stand up.

Do not use the tool where dangerous
situations or accidents may occur. Do not use
it indoor, in places where are exhausted
gases, etc.

In case of accidents or breakdowns, stop to
use the tool, switch off it and unplug it. Check
the conditions of the tool and bring it to a
service agent for inspection and reparation if
necessary.

When opening the trigger gun, pay attention

9
to the kickback force. The power of the gun can
cause a kickback and can produce a loss of
control of the gun and create accidents and
injuries. Hold the gun firmly, and with both
hands if possible.
 WARNING Always switch off the mains
disconnecting switch when leaving the machine
unattended.

Means for disconnection must be
incorporated in the fixed wiring in accordance
with the wiring rules.

10
Intended Use
Your PRESSURE CLEANER can perform a myriad of tasks in the house and in the garden. It
effectively cleans a wide variety of surfaces.
Your PRESSURE CLEANER is designed to operate from a cold water supply. It operates
efficiently with water whose temperature is between 5 and 60 degrees.
Your PRESSURE CLEANER has been designed for outdoor use only on materials such as stone,
wood and plastics. Please check, before use, whether materials can be cleaned with your sprayer;
the manufacturer cannot be held responsible for any damage resulting from improper use.
The main applications of this product are household cleaning tasks such as:
Voices, motorcycles, bicycles;
Patios, grates, garden walls, pathways, garages and facades of houses;
To remove algae and mosses from roofs, brick walls and gutters;
For cleaning of gardening tools and machinery, furniture and grills;
For hygiene and maintenance of kennels, stables, etc. And their surroundings;
It is especially useful for cleaning muddy sidings.
The sprayer alone is capable of performing most of the garden cleaning tasks or on buildings. The
detergent is useful for cleaning vehicles and other painted surfaces.
Symbol
WARNING! The jet should not be directed to persons, animals,
live devices or the device itself.
This machine is not suitable for connection to potable
water supply.
Guaranteed sound power level
Read the instruction manual

11
2. YOUR PRODUCT
a. Description
1. Hose unwinding handle
2. High-pressure hose
3. Carry handle
4. Gun
5. Lance
6. on / off switch
7. Nozzle
8. Water supply connection

12
b. Electrical circuit
c. Technical specifications
Model
HNHP2500SP-195i
Voltage
230 V˜ 50Hz
Assigned pressure
13 MPa
Maximum pressure
19.5 MPa (Maximum allowable pressure)
Max. inlet water pressure
0,4 MPa
Assigned speed
7,0 l/min
Maximum flow
8,75 l/min
Power
2500 W
Vibration
Max.
Rear handle: 4,271 m/s2
Front handle: 1,154 m/s2
K=1,5 m/s2
Sound emission
Lpa: 80,9 dB(A) K = 3 dB
Lwa: 93,7 dB K = 3 dB
Net weight
22 kg
Maximum temperature of the water
5 ~ 50 °C
Regarding the methods used for the measurement of noise emissions in the air, the
requirements of the standard EN 60335-2-79 have been applied.

13
3. INSTALLATION AND CONNECTIONS
Connecting pipes
Note: The inlet filter must always be installed to filter out sand, limestone and other
impurities as these may damage the valves of the pump.
-Install the high-pressure hose to the trigger gun and screw it in place (5, 7).
-Connect the machine to the water supply (2, 3 a n d 4). The minimum length
recommended for the water supply pipe is 10 meters (but not exceeding 25 meters) with
a diameter of 12.5 mm to avoid counter-pressures and the risk of potential damage
to your device. Make sure that it can withstand the water and a maximum pressure of
10 bar (0.1 Mpa). If you want to connect your device to other water sources, make
sure that the maximum water input pressure is 10 bar (0.1 Mpa).
-Connect and screw the high pressure hose to the water outlet (6) of the machine.
-Plug the tool to the electrical supply (8).
Install the lance on the gun
-Install the lance on the gun and screw it in place.
Adjusting the nozzle
-High pressure
Trigger must be released; water must not come out of nozzle.
Turn the nozzle counter clockwise. Press the trigger, the
water comes out at high pressure.
-Low pressure
Trigger must be released; water must not come out of nozzle.
Turn the nozzle clockwise. Press the trigger, the water comes
out at low pressure.

14
4. USE
a. Before starting the machine
NOTE: Never operate the sprayer without first opening the water supply!
Never open the lid of the sprayer while it’s running. Do not use the sprayer in
dangerous environments and in places where explosive substances are stored.
Do not put water in materials containing asbestos and other materials that can be
dangerous to health
Do not use liquids containing organic solvents, oil-based acids or solvent, paint or
oil having highly flammable, explosive and toxic vapors. Compounds like acetone,
acids and solvents are corrosive and may damage the device.
Open the tap, but do not start the machine immediately.
Press the gun trigger until the air has been expelled from the sprayer and water begins to
flow. Once the water begins to flow to the nozzle, release the trigger. The sprayer is now
running. Now you can turn the unit on.
b. Start/Stop
Turn the power switch to ON.
Press and hold down the gun trigger to start working.
Release the trigger to momentarily stop working and then re-press it to start again.
Keeps a suitable distance according to room being treated.
To work further on, unroll the hose using the unwinder handle.
If you need to stop using the device for more than 2 minutes, please turn it off.
At the end of the operation, release the trigger.
Turn off the machine by turning the power switch OFF and unplug the power outlet. Press
the gun trigger to release pressure.
NOTE: The trigger gun features a locking device. When this locking device is
activated, the trigger gun cannot be operated.
c. Use with detergent
Open the cap and pour the detergent into the container (the bottle is located to the rear of
the machine).
Note: make sure that the machine is switched off before you fill the detergent.
NOTE: detergents can be purchased in gardening stores and on the web.
The use of detergent may help reducing the working time and contribute removing stubborn
dirt. Some detergents are specially designed to be used with high-pressure cleaners for
specific cleaning operations. The viscosity of these detergents is close to that of water. If you
use detergents having a higher viscosity, for instance a dishwashing liquid, the detergent
injection system may clog and you will not be able to spray the detergent.
Detergents can clean a surface only if they are applied long enough on the surface so that
their chemical agents may degrade dirt and grime. They are most effective if they are applied

15
at low pressure.
The combination of the action of the chemical agents and rinsing with high pressure is very
effective in removing dirt. On vertical surfaces, apply the detergent starting from the bottom
moving upwards. This will prevent the detergent flowing downwards and forming trails.
Similarly, you need to rinse the surface from the bottom upwards.
To remove particularly stubborn dirt, using a brush in a combination with a detergent and a
high-pressure rinse may be necessary.
The next cleaning procedure will help you to better organize your cleaning and obtain optimal
results in minimum time:
A. Before starting, prepare the surface to be cleaned; remove furniture from the working
area and ensure windows and doors are properly closed. Protect or remove any
hazardous materials and any object that may be damaged.
B. Then spray the surface to be cleaned with the high-pressure water jet to remove dirt on
the surface. Before you press the trigger adjust the nozzle for a cone jet and slowly
adjust the shape of the jet until you get the desired result. Thus, you avoid spraying the
surface with a jet that could be too powerful and could cause damage.
C. Start the final rinse from the bottom of the surface moving upwards. Make sure rinsing
the surface so that not even the slightest trace of detergent remains.
5. CARE AND MAINTENANCE
The machine must be switched off and unplugged before any cleaning, maintenance and
replacement of parts. Perform maintenance on this machine regularly according to these
instructions to keep it in good working condition and extend its life.
Always check the high-pressure hose and connectors regularly to ensure there aren't any
damage or issues, as these are essential elements for the machine. Do not use them if they
are damaged.
After each use, perform the following actions:
- Check the cap to verify that it's not blocked by dirt. If necessary, clean the tip and then
rinse it with cold water.
- Remove the water inlet screen and make sure it is not obstructed. If it is dirty, wipe and
rinse it. When you remove the filter, always put it back in place after cleaning.
- Wash the hoses, connectors and accessories.
- Clean each time the detergent sprayer and sprays.
- Verify that the air vents are not blocked. Clean the vents if they are dirty.
Other maintenance services:
- Grease regularly the fittings so that the joints do not dry up.
-
Bring your machine one or twice a year to a qualified technical service for a general
inspection of your device.
NOTE: If repairs need to be made, they should only be performed by personnel
belonging to an approved technical center or qualified technicians.
6. STORAGE
Proceed to its cleaning and remove the hoses and accessories before storage. Check that
there isn't any water in the pipes.
Store the machine, hoses and accessories together in a safe and dry, protected from
moisture and frost.
The machine should be stored in order to be out of the reach of children.
You can install the accessories (multiple jet, turbo nozzle and jet cleaner) behind the machine.

16
7. DISPOSAL
Electrical products should not be disposed of with household products. According to
the European Directive 2012/19/EU for electrical and electronic equipment waste
and its implementation in national law, used electrical products should be collected
separately and disposed of at collection points provided for this purpose. Consult
with your local authorities or your dealer for advice on recycling.
8. TROUBLESHOOTING
This troubleshooting guide can help you solving a problem that occurred on the machine.
If you can't solve the problem, please contact directly the customer service.
Problems
Causes
Possible solutions
The machine does not
start
The machine is not plugged in
Connect the machine to a
suitable outlet
Defective plug
Change the plug or have
your electrical installation
inspected
The fuse is blown
Change the fuse with a
similar one
Defective extension cable
Use the machine without the
extension cable and change
the defective cable
Fluctuations of
pressure
The pump sucks the air
Check that hoses and fittings
are waterproof.
Dirty, worn or jammed
valves
Contact your service center
The water supply is not enough
Increase the water pressure,
check for blockage of the
hose and / or change the
large hose.
Worn out pump seals
The machine stops. The fuse
is blown
The machine stops
The fuse is blown
Replace the fuse.
Mains voltage incorrect
Disconnect the other
machines.
Check that the mains voltage
corresponds to the
specification on the
nameplate
Thermal sensor activated
Let the machine cool down
for 5 minutes
Jet is partially blocked
Clean the jet with a needle
and spray some water toward
the rear through the jet

17
The fuse is blown
Too small fuse
Replace with a higher fuse.
Increase the amperage
Try without the extension
cable
Pulsation of the
machine
Air in the inlet hose /
pump
Let the machine operate with
the open trigger until the
working pressure
resumes regularly.
Inadequate supply
Increase the water pressure,
check for blockage of the
hose or change the large
hose
Jet is partially blocked
Clean the jet with a needle
and spray some water toward
the rear through the jet
Blocked water filter
Clean the filter
Hose bending
Straighten the hose.
The machine starts
and stops
automatically
Leaky shotgun and/or
trigger
Contact your nearest service
center
The machine starts,
but the water does not
come out
No water supply
Connect the water inlet.
Blocked water filter
Clean the filter
Blocked jet
Clean the jet with a needle
and spray some water toward
the rear through the jet

18
9. EC DECLARATION OF CONFORMITY
Declaration of conformity
BUILDER SAS
ZI, 32, rue Aristide Bergès-31270 CUGNAUX France
Declares that the machine designated below
HIGH PRESSURE WASHER ELECTRIC
HNHP2500SP-195i
Serial number: 20200814945-20200815304
20200807485-20200807844
20201000381-20201000740
Is in conformity with the provisions of the Machinery Directive 2006/42/EC and to
the national regulations transposing it.
Also complies with the provisions of the following European Directives:
EMC Directive 2014/30/EU
Directive ROHS (EU)2015/863 amending 2011/65/EU
Directive 2000/14/EC + 2005/88/EC
Also complies with European and national standards and the following technical
provisions:
EN60335-1:2012+A11:2014+A13:2017+A1:2019+A14:2019+A2:2019;
EN60335-2-79:2012
EN 55014-1:2017
EN 55014-2:2015;
EN IEC61000-3-2:2019;
EN61000-3-3:2013
Cugnaux on 08/07/2020
Philippe MARIE / CEO

10. WARRANTY
WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
19

11. PRODUCT FAILURE
WHAT TO DO IF MY MACHINE BREAKS DOWN?
If you bought your product in a store:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
Go to the store with the complete machine and with the receipt or invoice.
If you bought your product on a website:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
c) Create a SWAP-Europe service ticket on the site: https://services.swap-europe.com When making the
request on SWAP-Europe, you must attach the invoice and the photo of the nameplate (serial number).
d) Contact the repair station to make sure it is available before dropping o󰀨 the machine.
Go to the repair station with the complete machine packed, accompanied by the purchase invoice and the
station support sheet downloadable after the service request is completed on the SWAP-Europe site
For machines with engine failure from manufacturers BRIGGS & STRATTON, HONDA and RATO, please
refer to the following instructions.
Repairs will be done by approved engine manufacturers of these manufacturers, see their site:
• http://www.briggsandstratton.com/eu/fr
• http://www.honda-engines-eu.com/fr/service-network-page;jsessionid=5EE8456CF39CD572AA2AEEDFD
290CDAE
• https://www.rato-europe.com/it/service-network
Please keep your original packaging to allow for after-sales service returns or pack your machine
with a similar cardboard box of the same dimensions.
For any question concerning our after-sales service you can make a request on our website https://
services.swap-europe.com
Our hotline remains available at [phone].
20
