Hyundai Robex 380LC-9 User manual

Robex 380LC-9
CRAWLER EXCAVATOR
SERVICE MANUAL

TABLE OF CONTENT
FOREWORD 8
1. Structure 8
2. How To Read The Service Manual 9
3. Conversion Table 10
SECTION 1 GENERAL 16
Group 1 Safety 17
Group 2 Specifications 26
1. Major Component 26
2. Specifications 27
3. Working Range 28
4. Weight 31
5. Lifting Capacities 32
6. Bucket Selection Guide 34
7. Undercarriage 36
8. Specifications For Major Components 38
9. Recommended Oils 41
SECTION 2 STRUCTURE AND FUNCTION 42
Group 1 Pump Device 43
1. Structure 43
2. Function 49
Group 2 Main Control Valve 62
1. Structure (1/4) 62
2. Function 66
Group 3 Swing Device 88
1. Structure 88
2. Function 91
Group 4 Travel Device 100
1. Construction (type 1) 100
2. Function 104
2. Specification 114
3. Principle Of Driving 115
4. Reduction Gear 126
Group 5 Rcv Lever 127
1. Structure 127
2. Functions 130
Group 6 Rcv Pedal 134
1. Structure 134
2. Function 136
SECTION 3 HYDRAULIC SYSTEM 140
Group 1 Hydraulic Circuit 141
Find manuals at https://best-manuals.com

Group 2 Main Circuit 142
1. Suction And Delivery Circuit 142
2. Return Circuit 143
3. Drain Circuit 144
Group 3 Pilot Circuit 145
1. Suction, Delivery And Return Circuit 146
2. Safety Solenoid Valve (safety Lever) 147
3. Boom Priority System 148
4. Travel Speed Control System 149
5. Main Relief Pressure Change Circuit 150
6. Swing Parking Brake Release 151
7. Swing Priority System 152
Group 4 Single Operation 153
1. Boom Up Operation 153
2. Boom Down Operation 154
3. Arm In Operation 155
4. Arm Out Operation 156
5. Bucket In Operation 157
6. Bucket Out Operation 158
7. Swing Operation 159
8. Travel Forward And Reverse Operation 161
Group 5 Combined Operation 163
1. Outline 163
2. Combined Swing And Boom Up Operation 164
3. Combined Swing And Arm Operation 165
4. Combined Swing And Bucket Operation 166
5. Combined Swing And Travel Operation 167
6. Combined Boom And Travel Operation 168
7. Combined Arm And Travel Operation 169
8. Combined Bucket And Travel Operation 170
9. Combined Boom Up And Bucket Operation 171
SECTION 4 ELECTRICAL SYSTEM 172
Group 1 Component Location 173
1. Location 1 173
2. Location 2 174
GROUP 2 ELECTRICAL CIRCUIT 175
ELECTRICAL CIRCUIT (1/2) 175
ELECTRICAL CIRCUIT (2/2) 176
Memorandum 177
1. Power Circuit 178
2. Starting Circuit 180
3. Charging Circuit 182
4. Head And Work Light Circuit 184
Find manuals at https://best-manuals.com

5. Beacon Lamp And Cab Light Circuit 186
6. Wiper And Washer Circuit 188
Group 3 Electrical Component Specification 193
Group 4 Connectors 201
1. Connector Destination 201
2. Connection Table For Connectors 205
SECTION 5 MECHATRONICS SYSTEM 224
Group 1 Outline 225
Group 2 Mode Selection System 227
1. Power Mode Selection System 227
2. Work Mode Selection System 228
3. User Mode Selection System 229
Group 3 Automatic Deceleration System 230
1. When Auto Idle Pilot Lamp On 2. When Auto Idle Pilot Lamp Off 230
Group 4 Power Boost System 231
Group 5 Travel Speed Control System 232
Group 6 Automatic Warming Up System 233
Group 7 Engine Overheat Prevention System 234
Group 8 Variable Power Control System 235
Group 9 Attachment Flow Control System 236
Group 10 Anti-restart System 237
1. Anti-restart Function 237
Group 11 Self-diagnostic System 238
3. Machine Error Codes Table 239
4. Engine Fault Code 242
Group 12 Engine Control System 251
1. Mcu And Engine Ecm (electronic Control Module) 2. Mcu Assembly 251
Group 13 Eppr Valve 252
1. Pump Eppr Valve 252
2. Boom Priority Eppr Valve 255
Group 14 Monitoring System 257
1. Outline 257
2. Cluster 257
3. Cluster Connector 259
Group 15 Fuel Warmer System 280
1. Specification 280
2. Operation 280
3. Electric Circuit 280
SECTION 6 TROUBLESHOOTING 281
Group 1 Before Troubleshooting 282
1. Introduction 282
2. Diagnosing Procedure 283
Find manuals at https://best-manuals.com

Group 2 Hydraulic And Mechanical System 285
1. Introduction 285
2. Drive System 286
3. Hydraulic System 288
4. Swing System 290
5. Travel System 294
6. Attachment System 299
Group 3 Electrical System 305
1. When Starting Switch Is Turned On, Monitor Panel Display Does Not Appear
305
3. Battery Charging Warning Lamp Lights Up(starting Switch : On) 307
4. When Coolant Overheat Warning Lamp Lights Up (engine Is Started) 308
5. When Air Cleaner Warning Lamp Lights Up (engine Is Started) 309
6. When Engine Oil Pressure Warning Lamp Lights Up (engine Is Started) 310
7. When Hydraulic Oil Temperature Warning Lamp Lights Up (engine Is Started)
311
8. When Coolant Temperature Gauge Does Not Operate (hcespn 304, Fmi 3 Or 4)
312
9. When Fuel Gauge Does Not Operate(hcespn 301, Fmi 3 Or 4) 313
10. When Safety Solenoid Does Not Operate 314
11. When Travel Speed 1, 2 Does Not Operate (hcespn 167, Fmi 5 Or 6) 315
12. When Engine Does Not Start ( Lights Up Condition) 316
13. When Starting Switch On Does Not Operate 317
14. When Starting Switch Is Turned On, Wiper Motor Does Not Operate 318
15. When Starting Switch Is Turned On, Head Lamp Does Not Lights Up 319
16. When Starting Switch Is Turned On, Work Lamp Does Not Lights Up 320
Group 4 Mechatronics Systegroup System 321
1. All Actuators Speed Are Slow 321
2. Engine Stall 323
3. Malfunction Of Cluster Or Mode Selection System 325
4. Malfunction Of Accel Dial 326
5. Auto Decel System Does Not Work 328
6. Malfunction Of Pump 1 Pressure Sensor 330
7. Malfunction Of Pump 2 Pressure Sensor 332
8. Malfunction Of Pump 3 Pressure Sensor 334
9. Malfunction Of Negative 1 Pressure Sensor 336
10. Malfunction Of Negative 2 Pressure Sensor 338
11. Malfunction Of Swing Pressure Sensor 340
12. Malfunction Of Arm In/out & Bucket In Pressure Sensor 342
13. Malfunction Of Boom Up Pressure Sensor 344
14. Malfunction Of Power Max 346
15. Malfunction Of Boom Priority Eppr Valve 348
SECTION 7 MAINTENANCE STANDARD 349
Find manuals at https://best-manuals.com

Group 1 Operational Performance Test 350
1. Purpose 350
2. Terminology 351
3. Operation For Performance Tests 352
Group 2 Major Component 370
1. Main Pump 370
2. Main Control Valve 371
3. Swing Device 372
4. Travel Motor 373
5. Rcv Lever 377
6. Rcv Pedal 378
7. Turning Joint 379
8. Cylinder 380
Group 3 Track And Work Equipment 381
1. Track 381
1. Work Equipment 386
SECTION 8 DISASSEMBLY AND ASSEMBLY 387
Group 1 Precautions 388
1. Removal Work 388
2. Install Work 389
3. Completing Work 390
Group 2 Tightening Torque 391
1. Major Components 391
2. Torque Chart 392
Group 3 Pump Device 394
1. Removal And Install 394
2. Main Pump (1/2) 396
3. Regulator 407
Group 4 Main Control Valve 418
1. Removal And Install 418
2. Structure (1/4) 419
3. Disassembly And Assembly 423
Group 5 Swing Device 438
1. Removal And Install Of Motor 438
2. Swing Motor 439
3. Reduction Gear 450
Group 6 Travel Device 458
2. Travel Motor (type 1) 459
3. Travel Reduction Gear (type 1) 462
4. Disassembling 464
5. Assembling 474
2. Specification 491
2. Disassembling 493
Find manuals at https://best-manuals.com

3. Disassembling Reduction Gear 509
4. Assembling Reduction Gear 514
Group 7 Rcv Lever 526
1. Removal And Install 526
2. Disassembly And Assembly 527
Group 8 Turning Joint 540
1. Removal And Install 540
2. Disassembly And Assembly 541
Group 9 Boom, Arm And Bucket Cylinder 545
1. Removal And Install 545
2. Disassembly And Assembly 551
Group 10 Undercarriage 562
1. Track Link 562
2. Carrier Roller 563
3. Track Roller 564
4. Idler And Recoil Spring 565
Group 11 Work Equipment 574
1. Structure 574
2. Removal And Install 575
SECTION 9 COMPONENT MOUNTING TORQUE 578
Group 1 Introduction Guide 579
Group 2 Engine System 580
Group 3 Electric System 582
Group 4 Hydraulic System 584
Group 5 Undercarriage 587
Group 6 Structure 588
Group 7 Work Equipment 592
Find manuals at https://best-manuals.com

0-1
FOREWORD
FOREWORD
1. STRUCTURE
1. STRUCTURE
This service manual has been prepared as an aid to improve the quality of repairs by giving the
serviceman an accurate understanding of the product and by showing him the correct way to
perform repairs and make judgements. Make sure you understand the contents of this manual and
use it to full effect at every opportunity.
This service manual mainly contains the necessary technical information for operations performed in
a service workshop.
For ease of understanding, the manual is divided into the following sections.
SECTION 1 GENERAL
SECTION 1 GENERAL
This section explains the safety hints and gives the specification of the machine and major
components.
SECTION 2 STRUCTURE AND FUNCTION
SECTION 2 STRUCTURE AND FUNCTION
This section explains the structure and function of each component. It serves not only to give an
understanding of the structure, but also serves as reference material for troubleshooting.
SECTION 3 HYDRAULIC SYSTEM
SECTION 3 HYDRAULIC SYSTEM
This section explains the hydraulic circuit, single and combined operation.
SECTION 4 ELECTRICAL SYSTEM
SECTION 4 ELECTRICAL SYSTEM
This section explains the electrical circuit, monitoring system and each component. It serves not
only to give an understanding electrical system, but also serves as reference material for trouble
shooting.
SECTION 5 MECHATRONICS SYSTEM
SECTION 5 MECHATRONICS SYSTEM
This section explains the computer aided power optimization system and each component.
SECTION 6 TROUBLESHOOTING
SECTION 6 TROUBLESHOOTING
This section explains the troubleshooting charts correlating
problems
problems to
causes
causes.
SECTION 7 MAINTENANCE STANDARD
SECTION 7 MAINTENANCE STANDARD
This section gives the judgement standards when inspecting disassembled parts.
SECTION 8 DISASSEMBLY AND ASSEMBLY
SECTION 8 DISASSEMBLY AND ASSEMBLY
This section explains the order to be followed when removing, installing, disassembling or
assembling each component, as well as precautions to be taken for these operations.
SECTION 9 COMPONENT MOUNTING TORQUE
SECTION 9 COMPONENT MOUNTING TORQUE
This section shows bolt specifications and standard torque values needed when mounting
components to the machine.
The specifications contained in this shop manual are subject to change at any time and without any
advance notice. Contact your HYUNDAI distributor for the latest information.
Find manuals at https://best-manuals.com

0-2
Revised edition mark
Revised edition mark(①②③…)
When a manual is revised, an edition mark is
recorded on the bottom outside corner of the
pages.
Revisions
Revisions
Revised pages are shown at the list of revised
pages on the between the contents page and
section 1 page.
Symbols
Symbols
So that the shop manual can be of ample
practical use, important places for safety and
quality are marked with the following symbols.
2. HOW TO READ THE SERVICE MANUAL
2. HOW TO READ THE SERVICE MANUAL
Distribution and updating
Distribution and updating
Any additions, amendments or other changes will
be sent to HYUNDAI distributors.
Get the most up-to-date information before you
start any work.
Filing method
Filing method
See the page number on the bottom of the
page.
File the pages in correct order.
Following examples shows how to read the
page number.
Example 1
2 - 3
Item number(2. Structure and
Function)
Consecutive page number for
each item.
Additional pages : Additional pages are
indicated by a hyphen(-) and number after the
page number. File as in the example.
1.
2.
3.
Symbol Item Remarks
Special safety precautions are
necessary when performing the
work.
Extra special safety precautions
are necessary when performing
the work because it is under
internal pressure.
Special technical precautions or
other precautions for preserving
standards are necessary when
performing the work.
Safety
Caution
※
10 - 4
10 - 4 - 1
10 - 4 - 2
10 - 5
Added pages
Find manuals at https://best-manuals.com

0-3
3. CONVERSION TABLE
3. CONVERSION TABLE
Method of using the Conversion Table
The Conversion Table in this section is provided to enable simple conversion of figures. For details of
the method of using the Conversion Table, see the example given below.
Example
Example
Method of using the Conversion Table to convert from millimeters to inches
Method of using the Conversion Table to convert from millimeters to inches
Convert 55
mm into inches.
Locate the number 50
in the vertical column at the left side, take this as ⓐ , then draw a
horizontal line from
ⓐ .
Locate the number 5
in the row across the top, take this as ⓑ , then draw a perpendicular line
down from
ⓑ .
Take the point where the two lines cross as
ⓒ . This point ⓒ gives the value when converting
from millimeters to inches. Therefore, 55
mm = 2.165 inches.
Convert 550
mm into inches.
The number 550 does not appear in the table, so divide by 10(Move the decimal point one place
to the left) to convert it to 55
mm .
Carry out the same procedure as above to convert 55mm to 2.165 inches.
The original value(550
mm ) was divided by 10, so multiply 2.165 inches by 10(Move the decimal
point one place to the right) to return to the original value.
This gives 550
mm = 21.65 inches.
1.
1.
2.
(1)
(2)
(3)
(1)
(2)
(3)
Millimeters to inches
Millimeters to inches 1
mm = 0.03937 in
ⓑ
ⓐ
0 1 2 3 4 5 6 7 8 9
0 0.039 0.079 0.118 0.157 0.197 0.236 0.276 0.315 0.354
10 0.394 0.433 0.472 0.512 0.551 0.591 0.630 0.669 0.709 0.748
20 0.787 0.827 0.866 0.906 0.945 0.984 1.024 1.063 1.102 1.142
30 1.181 1.220 1.260 1.299 1.339 1.378 1.417 1.457 1.496 1.536
40 1.575 1.614 1.654 1.693 1.732 1.772 1.811 1.850 1.890 1.929
50 1.969 2.008 2.047 2.087 2.126 2.165 2.205 2.244 2.283 2.323
60 2.362 2.402 2.441 2.480 2.520 2.559 2.598 2.638 2.677 2.717
70 2.756 2.795 2.835 2.874 2.913 2.953 2.992 3.032 3.071 3.110
80 3.150 3.189 3.228 3.268 3.307 3.346 3.386 3.425 3.465 3.504
90 3.543 3.583 3.622 3.661 3.701 3.740 3.780 3.819 3.858 3.898
ⓒ
Find manuals at https://best-manuals.com

0-4
Millimeters to inches
Millimeters to inches 1
mm = 0.03937 in
0 1 2 3 4 5 6 7 8 9
0 0.039 0.079 0.118 0.157 0.197 0.236 0.276 0.315 0.354
10 0.394 0.433 0.472 0.512 0.551 0.591 0.630 0.669 0.709 0.748
20 0.787 0.827 0.866 0.906 0.945 0.984 1.024 1.063 1.102 1.142
30 1.181 1.220 1.260 1.299 1.339 1.378 1.417 1.457 1.496 1.536
40 1.575 1.614 1.654 1.693 1.732 1.772 1.811 1.850 1.890 1.929
50 1.969 2.008 2.047 2.087 2.126 2.165 2.205 2.244 2.283 2.323
60 2.362 2.402 2.441 2.480 2.520 2.559 2.598 2.638 2.677 2.717
70 2.756 2.795 2.835 2.874 2.913 2.953 2.992 3.032 3.071 3.110
80 3.150 3.189 3.228 3.268 3.307 3.346 3.386 3.425 3.465 3.504
90 3.543 3.583 3.622 3.661 3.701 3.740 3.780 3.819 3.858 3.898
Kilogram to Pound
Kilogram to Pound 1
kg = 2.2046 lb
0 1 2 3 4 5 6 7 8 9
0 2.20 4.41 6.61 8.82 11.02 13.23 15.43 17.64 19.84
10 22.05 24.25 26.46 28.66 30.86 33.07 35.27 37.48 39.68 41.89
20 44.09 46.30 48.50 50.71 51.91 55.12 57.32 59.5. 61.73 63.93
30 66.14 68.34 70.55 72.75 74.96 77.16 79.37 81.57 83.78 85.98
40 88.18 90.39 92.59 94.80 97.00 99.21 101.41 103.62 105.82 108.03
50 110.23 112.44 114.64 116.85 119.05 121.25 123.46 125.66 127.87 130.07
60 132.28 134.48 136.69 138.89 141.10 143.30 145.51 147.71 149.91 152.12
70 154.32 156.53 158.73 160.94 163.14 165.35 167.55 169.76 171.96 174.17
80 176.37 178.57 180.78 182.98 185.19 187.39 189.60 191.80 194.01 196.21
90 198.42 200.62 202.83 205.03 207.24 209.44 211.64 213.85 216.05 218.26

0-5
Liter to U.S. Gallon
Liter to U.S. Gallon 1ℓ= 0.2642 U.S.Gal
0 1 2 3 4 5 6 7 8 9
0 0.264 0.528 0.793 1.057 1.321 1.585 1.849 2.113 2.378
10 2.642 2.906 3.170 3.434 3.698 3.963 4.227 4.491 4.755 5.019
20 5.283 5.548 5.812 6.6076 6.340 6.604 6.869 7.133 7.397 7.661
30 7.925 8.189 8.454 8.718 8.982 9.246 9.510 9.774 10.039 10.303
40 10.567 10.831 11.095 11.359 11.624 11.888 12.152 12.416 12.680 12.944
50 13.209 13.473 13.737 14.001 14.265 14.529 14.795 15.058 15.322 15.586
60 15.850 16.115 16.379 16.643 16.907 17.171 17.435 17.700 17.964 18.228
70 18.492 18.756 19.020 19.285 19.549 19.813 20.077 20.341 20.605 20.870
80 21.134 21.398 21.662 21.926 22.190 22.455 22.719 22.983 23.247 23.511
90 23.775 24.040 24.304 24.568 24.832 25.096 25.631 25.625 25.889 26.153
Liter to U.K. Gallon
Liter to U.K. Gallon 1ℓ= 0.21997 U.K.Gal
0 1 2 3 4 5 6 7 8 9
0 0.220 0.440 0.660 0.880 1.100 1.320 1.540 1.760 1.980
10 2.200 2.420 2.640 2.860 3.080 3.300 3.520 3.740 3.950 4.179
20 4.399 4.619 4.839 5.059 5.279 5.499 5.719 5.939 6.159 6.379
30 6.599 6.819 7.039 7.259 7.479 7.969 7.919 8.139 8.359 8.579
40 8.799 9.019 9.239 9.459 9.679 9.899 10.119 10.339 10.559 10.778
50 10.998 11.281 11.438 11.658 11.878 12.098 12.318 12.528 12.758 12.978
60 13.198 13.418 13.638 13.858 14.078 14.298 14.518 14.738 14.958 15.178
70 15.398 15.618 15.838 16.058 16.278 16.498 16.718 16.938 17.158 17.378
80 17.598 17.818 18.037 18.257 18.477 18.697 18.917 19.137 19.357 19.577
90 19.797 20.017 20.237 20.457 20.677 20.897 21.117 21.337 21.557 21.777

0-6
kgf
kgf
·m to
to
lbf
lbf
·ft
ft
1 kgf·m = 7.233 lbf·ft
0 1 2 3 4 5 6 7 8 9
7.2 14.5 21.7 28.9 36.2 43.4 50.6 57.9 65.1
10 72.3 79.6 86.8 94.0 101.3 108.5 115.7 123.0 130.2 137.4
20 144.7 151.9 159.1 166.4 173.6 180.8 188.1 195.3 202.5 209.8
30 217.0 224.2 231.5 238.7 245.9 253.2 260.4 267.6 274.9 282.1
40 289.3 396.6 303.8 311.0 318.3 325.5 332.7 340.0 347.2 354.4
50 361.7 368.9 376.1 383.4 390.6 397.8 405.1 412.3 419.5 426.8
60 434.0 441.2 448.5 455.7 462.9 470.2 477.4 484.6 491.8 499.1
70 506.3 513.5 520.8 528.0 535.2 542.5 549.7 556.9 564.2 571.4
80 578.6 585.9 593.1 600.3 607.6 614.8 622.0 629.3 636.5 643.7
90 651.0 658.2 665.4 672.7 679.9 687.1 694.4 701.6 708.8 716.1
100 723.3 730.5 737.8 745.0 752.2 759.5 766.7 773.9 781.2 788.4
110 795.6 802.9 810.1 817.3 824.6 831.8 839.0 846.3 853.5 860.7
120 868.0 875.2 882.4 889.7 896.9 904.1 911.4 918.6 925.8 933.1
130 940.3 947.5 954.8 962.0 969.2 976.5 983.7 990.9 998.2 10005.4
140 1012.6 1019.9 1027.1 1034.3 1041.5 1048.8 1056.0 1063.2 1070.5 1077.7
150 1084.9 1092.2 1099.4 1106.6 1113.9 1121.1 1128.3 1135.6 1142.8 1150.0
160 1157.3 1164.5 1171.7 1179.0 1186.2 1193.4 1200.7 1207.9 1215.1 1222.4
170 1129.6 1236.8 1244.1 1251.3 1258.5 1265.8 1273.0 1280.1 1287.5 1294.7
180 1301.9 1309.2 1316.4 1323.6 1330.9 1338.1 1345.3 1352.6 1359.8 1367.0
190 1374.3 1381.5 1388.7 1396.0 1403.2 1410.4 1417.7 1424.9 1432.1 1439.4

0-7
kgf/cm
kgf/cm
2
to
to
lbf/in
lbf/in
2
1 kgf / cm2 = 14.2233 lbf / in
2
0 1 2 3 4 5 6 7 8 9
14.2 28.4 42.7 56.9 71.1 85.3 99.6 113.8 128.0
10 142.2 156.5 170.7 184.9 199.1 213.4 227.6 241.8 256.0 270.2
20 284.5 298.7 312.9 327.1 341.4 355.6 369.8 384.0 398.3 412.5
30 426.7 440.9 455.1 469.4 483.6 497.8 512.0 526.3 540.5 554.7
40 568.9 583.2 597.4 611.6 625.8 640.1 654.3 668.5 682.7 696.9
50 711.2 725.4 739.6 753.8 768.1 782.3 796.5 810.7 825.0 839.2
60 853.4 867.6 881.8 896.1 910.3 924.5 938.7 953.0 967.2 981.4
70 995.6 1010 1024 1038 1053 1067 1081 1095 1109 1124
80 1138 1152 1166 1181 1195 1209 1223 1237 1252 1266
90 1280 1294 1309 1323 1337 1351 1365 1380 1394 1408
100 1422 1437 1451 1465 1479 1493 1508 1522 1536 1550
110 1565 1579 1593 1607 1621 1636 1650 1664 1678 1693
120 1707 1721 1735 1749 1764 1778 1792 1806 1821 1835
130 1849 2863 1877 1892 1906 1920 1934 1949 1963 1977
140 1991 2005 2020 2034 2048 2062 2077 2091 2105 2119
150 2134 2148 2162 2176 2190 2205 2219 2233 2247 2262
160 2276 2290 2304 2318 2333 2347 2361 2375 2389 2404
170 2418 2432 2446 2460 2475 2489 2503 2518 2532 2546
180 2560 2574 2589 5603 2617 2631 2646 2660 2674 2688
200 2845 2859 2873 2887 2901 2916 2930 2944 2958 2973
210 2987 3001 3015 3030 3044 3058 3072 3086 3101 3115
220 3129 3143 3158 3172 3186 3200 3214 3229 3243 3257
230 3271 3286 3300 3314 3328 3343 3357 3371 3385 3399
240 3414 3428 3442 3456 3470 3485 3499 3513 3527 3542

0-8
TEMPERATURE
TEMPERATURE
Fahrenheit-Centigrade Conversion.
A simple way to convert a fahrenheit temperature reading into a centigrade temperature reading or vice verse
is to enter the accompanying table in the center or boldface column of figures.
These figures refer to the temperature in either Fahrenheit or Centigrade degrees.
If it is desired to convert from Fahrenheit to Centigrade degrees, consider the center column as a table of
Fahrenheit temperatures and read the corresponding Centigrade temperature in the column at the left.
If it is desired to convert from Centigrade to Fahrenheit degrees, consider the center column as a table of
Centigrade values, and read the corresponding Fahrenheit temperature on the right.
˚ C ˚ F ˚ C ˚ F ˚ C ˚ F ˚ C ˚ F
-40.4 -40 -40.0 -11.7 11 51.8 7.8 46 114.8 27.2 81 117.8
-37.2 -35 -31.0 -11.1 12 53.6 8.3 47 116.6 27.8 82 179.6
-34.4 -30 -22.0 -10.6 13 55.4 8.9 48 118.4 28.3 83 181.4
-31.7 -25 -13.0 -10.0 14 57.2 9.4 49 120.2 28.9 84 183.2
-28.9 -20 -4.0 -9.4 15 59.0 10.0 50 122.0 29.4 85 185.0
-28.3 -19 -2.2 -8.9 16 60.8 10.6 51 123.8 30.0 86 186.8
-27.8 -18 -0.4 -8.3 17 62.6 11.1 52 125.6 30.6 87 188.6
-27.2 -17 1.4 -7.8 18 64.4 11.7 53 127.4 31.1 88 190.4
-26.7 -16 3.2 -6.7 20 68.0 12.8 55 131.0 32.2 90 194.0
-26.1 -15 5.0 -6.7 20 68.0 12.8 55 131.0 32.2 90 194.0
-25.6 -14 6.8 -6.1 21 69.8 13.3 56 132.8 32.8 91 195.8
-25.0 -13 8.6 -5.6 22 71.6 13.9 57 134.6 33.3 92 197.6
-24.4 -12 10.4 -5.0 23 73.4 14.4 58 136.4 33.9 93 199.4
-23.9 -11 12.2 -4.4 24 75.2 15.0 59 138.2 34.4 94 201.2
-23.3 -10 14.0 -3.9 25 77.0 15.6 60 140.0 35.0 95 203.0
-22.8 -9 15.8 -3.3 26 78.8 16.1 61 141.8 35.6 96 204.8
-22.2 -8 17.6 -2.8 27 80.6 16.7 62 143.6 36.1 97 206.6
-21.7 -7 19.4 -2.2 28 82.4 17.2 63 145.4 36.7 98 208.4
-21.1 -6 21.2 -1.7 29 84.2 17.8 64 147.2 37.2 99 210.2
-20.6 -5 23.0 -1.1 35 95.0 21.1 70 158.0 51.7 125 257.0
-20.0 -4 24.8 -0.6 31 87.8 18.9 66 150.8 40.6 105 221.0
-19.4 -3 26.6 0 32 89.6 19.4 67 152.6 43.3 110 230.0
-18.9 -2 28.4 0.6 33 91.4 20.0 68 154.4 46.1 115 239.0
-18.3 -1 30.2 1.1 34 93.2 20.6 69 156.2 48.9 120 248.0
-17.8 0 32.0 1.7 35 95.0 21.1 70 158.0 51.7 125 257.0
-17.2 1 33.8 2.2 36 96.8 21.7 71 159.8 54.4 130 266.0
-16.7 2 35.6 2.8 37 98.6 22.2 72 161.6 57.2 135 275.0
-16.1 3 37.4 3.3 38 100.4 22.8 73 163.4 60.0 140 284.0
-15.6 4 39.2 3.9 39 102.2 23.3 74 165.2 62.7 145 293.0
-15.0 5 41.0 4.4 40 104.0 23.9 75 167.0 65.6 150 302.0
-14.4 6 42.8 5.0 41 105.8 24.4 76 168.8 68.3 155 311.0
-13.9 7 44.6 5.6 42 107.6 25.0 77 170.6 71.1 160 320.0
-13.3 8 46.4 6.1 43 109.4 25.6 78 172.4 73.9 165 329.0
-12.8 9 48.2 6.7 44 111.2 26.1 79 174.2 76.7 170 338.0
-12.2 10 50.0 7.2 45 113.0 26.7 80 176.0 79.4 172 347.0

SECTION 1 GENERAL
SECTION 1 GENERAL
Group 1 Safety Hints -------------------------------------------------------------------------------------------------------- 1-1
Group 2 Specifications ----------------------------------------------------------------------------------------------------- 1-10

FOLLOW SAFE PROCEDURE
FOLLOW SAFE PROCEDURE
Unsafe work practices are dangerous.
Understand service procedure before doing
work; Do not attempt shortcuts.
WEAR PROTECTIVE CLOTHING
WEAR PROTECTIVE CLOTHING
Wear close fitting clothing and safety equipment
appropriate to the job.
WARN OTHERS OF SERVICE WORK
WARN OTHERS OF SERVICE WORK
Unexpected machine movement can cause
serious injury.
Before performing any work on the excavator,
attach a
「
Do Not Operate
Do Not Operate 」 tag on the right
side control lever.
USE HANDHOLDS AND STEPS
USE HANDHOLDS AND STEPS
Falling is one of the major causes of personal
injury.
When you get on and off the machine, always
maintain a three point contact with the steps
and handrails and face the machine. Do not
use any controls as handholds.
Never jump on or off the machine. Never mount
or dismount a moving machine.
Be careful of slippery conditions on platforms,
steps, and handrails when leaving the machine.
SECTION 1 GENERAL
SECTION 1 GENERAL
GROUP 1 SAFETY
GROUP 1 SAFETY
1-1
13031GE01
13031GE02
13031GE03

PREPARE FOR EMERGENCIES
PREPARE FOR EMERGENCIES
Be prepared if a fire starts.
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctors,
ambulance service, hospital, and fire
department near your telephone.
PROTECT AGAINST FLYING DEBRIS
PROTECT AGAINST FLYING DEBRIS
Guard against injury from flying pieces of metal
or debris; Wear goggles or safety glasses.
PROTECT AGAINST NOISE
PROTECT AGAINST NOISE
Prolonged exposure to loud noise can cause
impairment or loss of hearing.
Wear a suitable hearing protective device such
as earmuffs or earplugs to protect against
objectionable or uncomfortable loud noises.
AVOID POWER LINES
AVOID POWER LINES
Serious injury or death can result from contact
with electric lines.
Never move any part of the machine or load
closer to electric line than 3m(10ft) plus twice
the line insulator length.
1-2
13031GE04
13031GE05
13031GE06
13031GE07

KEEP RIDERS OFF EXCAVATOR
KEEP RIDERS OFF EXCAVATOR
Only allow the operator on the excavator. Keep
riders off.
Riders on excavator are subject to injury such
as being struck by foreign objects and being
thrown off the excavator. Riders also obstruct
the operator's view resulting in the excavator
being operated in an unsafe manner.
MOVE AND OPERATE MACHINE SAFELY
MOVE AND OPERATE MACHINE SAFELY
Bystanders can be run over. Know the location
of bystanders before moving, swinging, or
operating the machine.
Always keep the travel alarm in working
condition. It warns people when the excavator
starts to move.
Use a signal person when moving, swinging, or
operating the machine in congested areas.
Coordinate hand signals before starting the
excavator.
OPERATE ONLY FORM OPERATOR'S SEAT
OPERATE ONLY FORM OPERATOR'S SEAT
Avoid possible injury machine damage. Do not
start engine by shorting across starter
terminals.
NEVER start engine while standing on ground.
Start engine only from operator's seat.
PARK MACHINE SAFELY
PARK MACHINE SAFELY
Before working on the machine:
· Park machine on a level surface.
· Lower bucket to the ground.
· Turn auto idle switch off.
· Run engine at 1/2 speed without load for 2 minutes.
· Turn key switch to OFF to stop engine. Remove key
from switch.
· Move pilot control shutoff lever to locked position.
· Allow engine to cool.
1-3
13031GE08
13031GE09
13031GE26

SUPPORT MACHINE PROPERLY
SUPPORT MACHINE PROPERLY
Always lower the attachment or implement to
the ground before you work on the machine. If
you must work on a lifted machine or
attachment, securely support the machine or
attachment.
Do not support the machine on cinder blocks,
hollow tiles, or props that may crumble under
continuous load.
Do not work under a machine that is supported
solely by a jack. Follow recommended
procedures in this manual.
SERVICE COOLING SYSTEM SAFELY
SERVICE COOLING SYSTEM SAFELY
Explosive release of fluids from pressurized
cooling system can cause serious burns.
Shut off engine. Only remove filler cap when
cool enough to touch with bare hands.
HANDLE FLUIDS SAFELY-AVOID FIRES
HANDLE FLUIDS SAFELY-AVOID FIRES
Handle fuel with care; It is highly flammable.
Do not refuel the machine while smoking or
when near open flame or sparks. Always stop
engine before refueling machine.
Fill fuel tank outdoors.
Store flammable fluids away from fire hazards.
Do not incinerate or puncture pressurized
containers.
Make sure machine is clean of trash,
grease, and debris.
Do not store oily rags; They can ignite and
burn spontaneously.
1-4
13031GE10
13031GE11
13031GE12
13031GE13
