Hyundai HYVI3014 User manual

1
WET / DRY VACUUM CLEANER
HYVI3014
Instruction Manual

HYUNDAI
2
IMPORTANT: DONT FORGET TO REGISTER YOUR EXTENDED
3 YEAR HYUNDAI WARRANTY WITHIN 30 DAYS OF PURCHASE.
https://www.hyundaipowerequipment/warranty
1. On/off switch
2. Electronic power socket
3. Motor housing
4. Water outlet
5. Hose lock knob
6. Water outow
7. Container
8. Container latch
9. Hose connection
10. Hose
11. Telescopic tube
12. Nozzle
13. Wheels

3
1
8
5
9
10/11
2
3
6
7
4
13
12
A

4
HYUNDAI
WET/DRY VACUUM CLEANER
HYVI3014
WARNING
Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric
shock, re and/or serious injury. Save all warnings and
instructions for future reference.
SAFETY WARNINGS
When using the machine, always observe the enclosed safety
warnings as well as the additional safety warnings.
The following symbols are used throughout this manual:
Denotes risk of personal injury or damage to the machine.
SAFETY INSTRUCTIONS FOR WET/DRY VACUUM
CLEANERS
• Use original accessories only.
• When picking up liquids, only use the accessories intended for
this purpose.
• Do not connect any electrical equipment to the electronic power
socket when using the machine to pick up liquids.
• Do not connect any electrical equipment to the electronic power
socket that exceeds the maximum power rating of 2,000 W.
• Do not use the machine to pick up burning or smouldering
debris, explosive or inflammable substances and liquids.
• Keep body parts away from the vacuum opening when the
machine is running.
ELECTRICAL SAFETY
Always check that the power supply corresponds to the
voltage on the rating plate.
DESCRIPTION (FIG. A)
Your wet/dry vacuum cleaner has been designed for picking up dry
dust and debris as well as liquids.
1. On/off switch
2. Electronic power socket
3. Motor housing
4. Water outlet
5. Hose lock knob
6. Water outow
7. Container
8. Container latch
9. Hose connection
10. Hose
11. Telescopic tube
12. Nozzle
13. Wheels
Package contents
The package contains the following parts:
Wet/dry vacuum cleaner
Hose
Telescopic tube
Nozzle
Crevice nozzle
Brush nozzle
Dustbag
Intake filter for liquids
Wheels (4x)
MOUNTING THE ACCESSORIES (FIG. A)
Before mounting an accessory, always unplug the
machine.
Mounting accessories for picking up dry material (g. A)
The dustbag must be used for picking up dry material.
• Remove the motor housing (3) from the container (7) by
releasing the container latches (8).
• Remove the intake filter by sliding it off the float.
• Place the dustbag in the container and slide it firmly over the
hose connection (9).
• Replace the motor housing and click the container latches firmly
shut.
• Connect the hose (10) to the hose connection (9).
NOTE: In order to ensure proper filtering when vacuuming dust
and dry material the intake filter needs removing and the
dustbag needs to be put in its place. The intake filter is only to
be used vacuuming liquids.
Mounting accessories for picking up liquids (g. A)
The intake lter must be used for picking up liquids.
• Remove the motor housing (3) from the container (7) by
releasing the container latches (8).
• Slide the intake filter over the float.
• Remove the dustbag from the container.
• Replace the motor housing and click the container latches firmly
shut.
• Connect the hose to the hose connection.
NOTE: Remove all dirt and debris from the tank. A intake filter
must be used to vacuum up wet debris. Unplug the power cord
from the wall outlet before removing the motor assembly from
the tank. Turn the motor over.
Remove the dust collection bag and install the intake filter.
Connecting the hose (g. A)
• Slide the hose lock knob (5) to the right, insert the end of the
hose into the hose connection and release the lock button.
• Place the telescopic tube (11) onto the other end of the hose.
• Place a nozzle onto the other end of the telescopic tube.
• Set the telescopic tube to the desired length by sliding the
release button into the direction of the arrow and sliding the tube
in or out.
• Switch on the machine.
Blower function
Connect the hose to the hose connection on the backside to switch
from blowing to blowing.
Always switch off the piston when changing function.

5
for a few seconds after the power tool has been switched off.
• Switch off the machine by setting the on/off switch to position ‘0’.
The electronic outlet is not suitable for use as a regular
outlet. Therefore never use the machine as a regular outlet
or as a replacement for an extension cord.
For liquids
Do not connect any electrical equipment to the electronic
power socket when using the machine to pick up liquids.
• Insert the mains plug into a mains outlet.
•Switch on the machine by setting the on/off switch (1) to position ‘I’.
• Switch off the machine by setting the on/off switch to position ‘0’.
The machine is equipped with an overow oat which ensures that
the suction power stops when the tank gets too full and a warning
signal sounds. Switch off the machine, empty the tank and switch on
the machine again.
CLEANING AND MAINTENANCE
The machine does not require any special maintenance.
Always remove the plug from themains outlet before
cleaning the machine or performing maintenance to the
machine.
• Allow the intake filter to dry thoroughly after each use.
• Empty the container each time after using the machine to pick
up liquids. Allow the container to dry thoroughly afterwards.
• Regularly clean the container using soap and water. Allow the
container to dry thoroughly afterwards.
• Regularly clean the motor housing using a non-fluffy cloth or
brush.
• Regularly clean the exhaust outlet using a non-fluffy cloth or
brush.
• Regularly replace the dustbag. Always replace the dustbag
when it is full.
• Regularly replace the intake filter.
TECHNICAL DATA HYVI3014
Mains voltage V 230
Mains frequency Hz 50
Power input W 1,400
Max. power rating power socket W 2,000
Container capacity l 30
LpA (sound pressure)* dB(A) 80
Weight (gross/net) kg 9.4/8.0
*Level of sound pressure in the workplace.
WARRANTY
Register your 3 year warranty within 30 days of purchase
at:
https://hyundaipowerequipment.co.uk/warranty
Full warranty term and conditions can be found on the
HYUNDAI website:
www.hyundaipowerequipment.co.uk
ENVIRONMENT
Disposal
Your product, accessories and packaging should be sorted for
environmental-friendly recycling.
Only for EC countries
Do not dispose of power tools into domestic waste. According to the
European Guideline 2002/96/EC for Waste Electrical and Electronic
Equipment and its implementation into national right, power tools
that are no longer usable must be collected separately and disposed
of in an environmentally friendly way.
Subject to change; specications can be changed without further
notice.
SWITCHING ON AND OFF (FIG. A)
Always check whether the correct accessories have been
mounted before switching on the machine.
For dry dust and debris
• Insert the mains plug into a mains outlet.
•Switch on the machine by setting the on/off switch (1) to position ‘I’.
• Switch off the machine by setting the on/off switch to position ‘0’.
For dust released by electric equipment
The machine has been equipped with an electronic outlet for
connection of your electrical equipment. The machine is switched on
automatically the moment you switch on the electrical tool.
Do not connect any electrical equipment to the electronic
power socket that exceeds the maximum power rating of
2,000 W.
• Set the on/off switch (1) to position ‘II’.
• Insert the mains plug into a mains outlet.
•Plug the electrical equipment into the electronic power socket (2).
• Connect the hose (10) to the dust extraction outlet on the
electrical equipment.
•Operate the electrical equipment as described in the instructions.
If the electrical equipment is switched on or off, the machine
automatically switches on or off. The machine is equipped with a
delay function which means that the machine continues to suck

6
GENPOWER LTD confirms that this HYUNDAI POWER PRODUCT conforms to the following CE Directives:
EN62233:2008
EN60335-1:2012+AC:14+A11:14
EN60335-2-82015
EC DECLARATION OF CONFORMITY
The undersigned, as authorised by: Genpower Ltd
Declares that the following equipment manufactured under license by Hyundai Korea
Conforms to the Directive:
EN62233:2008
EN60335-1:2012+AC:14+A11:14
EN60335-2-82015
Of the European Parliament and of the council on the approximation of the laws of the Member States relating to the noise
emission in the environment by equipment for use outdoors.
Equipment Category:
Product Name/Model:
Type:
Mains Voltage:
Power Tools
HYVI3014
Wet / Dry Vacuum Cleaner
1400W
Input Power: 230V
Capacity: 30L
The technical documentation is kept by: Roland Llewellin, Genpower Ltd,
Isaac Way, Pembroke Dock,
Pembrokeshire, SA72 4RW.
The conformity assessment procedure followed was in accordance with annex V or VI of the Directive.
Notified Body:
Certification No:
Measured Sound Power Level:
Guaranteed Sound Power Level:
Yongkang Jienuo Industry Trade Co, Ltd
Xialixi Industrial Zone, Yongkang City, Zhejiang Province, P.R. China
160400931HZH-001
80 dB (A)
80 dB (A)
A copy of this certificate has been submitted to the European Commission and to EU Member State United Kingdom.
Place of Declaration: Pembroke Dock, SA72 4RW
Date: Tuesday, 06 August 2019
Signed By: Roland Llewellin
Position in Company: Managing Director
Name and address of manufacturer or authorised representative:
Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW.

HYUNDAI

Imported for:
GENPOWER LTD
Isaac Way, London Road,
Pembroke Dock, UNITED KINGDOM, SA72 4RW
T: [phone] F: [phone]
E: [email protected]
www.hyundaipowerproducts.co.uk
Imported/Distributed by Genpower Ltd for The United Kingdom & Ireland Licensed by Hyundai Corporation, Korea
