HZ Sound Systems 9300 User manual

To see operational and troubleshooting information and videos,
go to www.hzsupport.com
Dated receipt required for warranty replacement.
FEATURES
• 1080p HD Video
• 180° Motion Sensor
• Audible Alarm
• Energy Saving LED
UNPACKING
Be sure to remove all contents from packaging and verify
all items are present before assembling this light xture.
is package includes the following items:
• Security Light
• Owner’s Manual
• HZconnect App Quick Start Guide
• Mounting Hardware
© 2019 HeathCo LLC 210284-01A
Connected LED Video
Security Motion Light
Model: 9300
HARDWARE INCLUDED
Note: Six mounting bracket screws are included. e installation will only require two. Discard the unused mounting
bracket screws after installation.
Plastic plug #6 Mounting Bracket #8 Mounting Bracket
Screw (x2) Screw (x2)
Mounting Bolt Mounting Bolt (Pre-Installed in Light Fixture)
FRONT
Mounting Bracket Mini Screwdriver

2 To see operational and troubleshooting information and videos,
go to www.hzsupport.com
210284-01
IMPORTANT SAFETY AND INSTALLATION INFORMATION
Before installing security light, read all instructions carefully and keep owner’s manual for future reference.
• WARNING: To prevent electric shock, ensure that the power is disconnected before installation.
• WARNING: Risk of re. Keep the lamp heads at least 2 in. from combustible materials.
• WARNING: Shock hazard.For eave mounting,the center of the junction box must be located at least 4 1/2" (11.5 cm)
from the outside edge of the eave.
• CAUTION: To avoid water damage and the risk of electrical shock, the motion sensor RESET button must be facing
the ground when the installation is complete.
• CAUTION: Keep the lamp heads 30° below horizontal to avoid water damage and electrical shock.
• CAUTION: Burn hazard. Allow the light xture to cool before touching.
• NOTICE: Do not connect this light xture to a dimmer switch or timer.
• is light xture requires 120-volts AC.
• is light xture must be properly grounded.
• Some electrical codes require installation by a qualied electrician.
• is xture is designed for outdoor installation and should be mounted to a wall or eaves.
• To achieve best results,this xture should be mounted 8 feet (2.4 meters) above the ground.Note: If xture is mounted
higher than 8 ft. (2.4 meters), aiming the sensor down will reduce coverage distance.
e motion sensor on this light xture detects “motion” by the movement of heat across the coverage area.e motion
sensor is more sensitive to the movement of heat moving across the coverage area and less sensitive to the movement
of heat directly towards it.
e video camera on this light xture has a 110° detection zone within the motion sensor’s detection area.e light and
the camera may not detect motion at the same time.
Note: Light xture and sensor should be mounted as shown above when installed (depending upon type of installation).
Least Sensitive Most Sensitive
Motion Motion
Sensor
Wall Mount Eave Mount
R
E
S
E
T
THISSIDE UP
R
E
S
E
T
THISSIDE UP
Video Motion
Detection Zone
Video Motion
Detection Zone
Motion Sensor
Detection Zone
Motion Sensor
Detection Zone

To see operational and troubleshooting information and videos, 3
go to www.hzsupport.com
210284-01
INSTALLATION
WARNING: Turn power o at circuit breaker or fuse.
Place tape over circuit breaker switch and verify power is
o at the xture.
is xture comes with an “Easy Install” mounting plate. It is pre-
assembled on the xture for shipping.
1. Unscrew the large mounting bolt connecting the light xture to
themounting plateandremove themountingplate (seeFigure1).
e mounting bolt is designed to stay in the light xture.
2. Install the mounting bracket with the stamped word “FRONT”
facing away from the junction box (see Figure 2).Use the mount-
ing bracket screws that best t the junction box.
3. Route the junction box wires through the hole in the mounting
plate (see Figure 3).
4. Place the mounting plate against the junction box (see Figure3).
• Wall Mounted – e “UP” arrow must point upward
• EaveMounted–e“UP”arrowmustpointtowardthebuilding
5. Insert the small mounting bolt through the mounting plate hole
located below the threaded hole.read the bolt into the center
holeof themountingbracket (seeFigure3).Tighten boltsecurely.
WIRING
Insert the junction box wires into the side of the terminal block and
aroundthegroundscrew(seeFigure4).Tightenterminalblockscrews
and ground screw to secure wires.
• White to “N (White)”
• Black to “L (Black)”
• Bare or green ground wire to GND (ground) screw.
FINAL ASSEMBLY
1. Double check that all wiring connections are securely connected.
2. Align the bottom edge of the light xture with the bottom edge
of the mounting plate.Tilt the light xture toward the mounting
plate, making sure the light xture is centered on the mounting
plate.
IMPORTANT: e two pins on the rear of the light xture must
insert into the terminal block for the light to work.
3. Tightenthemountingboltsecurelybeingcarefulnottoovertighten
(see Figure 5).
Figure 1
Figure 2
Figure 3
Figure 4
FRONT
FRONT
FRONT
N (White/
Blanc/Blanco)
GND
Terre
Tierra
UP/Haut/Arriba
L (Black/
Noir/Negro)
FRONT
N (White/
Blanc/Blanco)
GND
Terre
Tierra
UP/Haut/Arriba
L (Black/
Noir/Negro)
N (White/
Blanc/Blanco)
GND
Terre
Tierra
UP/Haut/Arriba
L (Black/
Noir/Negro)

4 To see operational and troubleshooting information and videos,
go to www.hzsupport.com
210284-01
IMPORTANT:
• If wall mounted, make sure the xture is mounted with the
sensor below the lamp heads.
• If eave mounted, mount the xture with sensor facing away
from the house wall.Rotate the sensor so the RESET button
(see Figure8) faces the ground.
4. Push the plastic plug rmly into the mounting bolt hole on the
light xture (see Figure 5).
5. Caulkaround mountingplate andmounting surfacewith silicone
weather sealant (see Figure 6).
TESTING AND ADJUSTMENTS
Figure 6
Figure 7
Figure 5
CAUTION:To avoid water damage and risk of electrical
shock, rotate the motion sensor so the RESET button faces
the ground when the installation is complete.
1. Turn on the circuit breaker and light switch.
Note: e motion sensor has a 1 minute warm up period before
it will detect motion.When rst turned on wait for the red LED
indicator to start blinking slowly (1 minute).
2. Go to the App StoreSM and search for the “HZconnect” app or
Google Play™ and search for “HeathZenith”and download the
HZconnect app . See the enclosed instruction sheet, “Con-
necting to your new HZconnect device”, for more details.
3. Once step 2 is complete, open the HZconnect app and log into
the account.
4. IMPORTANT: is light has two detection zones – the motion
sensing detection zone and the camera detection zone. Use the
live video from step 4 and the motion sensor to set up your light
and camera.
5. Click on the home screen icon
Home
> click on the light > click
“Light” icon > click “Light Setting” > click “Test”.
6. Click on the back arrow “<”in the upper left of the screen to view
a live video feed.
7. Walk through the coverage area noting where you are when the
lights turn on. Also, the LED indicator behind the motion sen-
sor lens will glow blue when motion is detected (see Figure 7).
Note: e blue LED will turn o 30 seconds after all motion has
stopped.
8. If needed, gently grasp the motion sensor and move it from side
to side or up and down to the best position to pick up motion
and to view the desired area using the camera.
9. If needed,gently grasp the lamp heads and move them from side
to side or up and down to adjust the light coverage area.
LED Indicator
Motion Sensor
and Camera
Motion
Detection
Zone
Camera Zone

To see operational and troubleshooting information and videos, 5
go to www.hzsupport.com
210284-01
10. When testing is complete, use the app to set the
controls for the light xture.
LED Indicator
• RED + Solid: Light is warming up – Stays in this mode
until the light is ready.
• RED + ashing (1 second ON / 1 second OFF): Light
is in wi- connection mode.
• BLUE + ashing: Light is connecting to the internet.
• BLUE + (2 Minutes ON): Light is connected to the
internet.
• BLUE: When motion is detected,the LED will be ON
until all motion has stopped for 30 seconds.
ForadditionalinformationconcerningthislightortheHZ-
connect app, visit www.heath-zenith.com/HZconnect.
IMPORTANT CONSIDERATIONS
AVOID AIMING THE SENSOR AT:
• Below are examples of objects that might produce heat
and may cause the motion sensor to trigger:
• Pools of Water • Air Conditioners
• Dryer Vents • Animals
• Heating Vents • Automobile Trac
If you suspect that a heat source of this type is triggering
the motion sensor, reduce the sensitivity.
• Areaswherepetsortracmaytriggerthemotionsensor.
• Nearby large,light-colored objects reecting light may
trigger the shut-o feature. Do not point other lights
at the motion sensor.
SEASONAL CHANGES:
e motion sensor works by sensing temperature changes
across its eld of view. e closer the surrounding tem-
perature is to a person’s body heat, the less sensitive the
sensor will appear.e greater the temperature dierence,
the more sensitive the sensor will appear.Use the sensitiv-
ity control in the app to adjust the setting as the outside
temperature changes for the dierent seasons. is is a
normal part of the light sensor’s operation.
Figure 8
R
E
S
E
T
DUALBRITE DURATION
“DualBrite” mode is a selectable feature within the app
that turns the light on at a reduced (accent) level at dusk.
When motion is detected, the light will increase to full
bright for the amount of the “Full Brite Setting” (1, 5, or
20 minutes) then returns to “DualBrite” mode.e light
will stay on at the reduced light level for the amount of
timeselected(O,3hr.,6hr.,dusk-to-dawn)andthenturn
o completely. Once the “DualBrite” timer runs out, the
lightwillturn ONonlywhenmotionis detected.Selecting
OFFdisables the“DualBrite”feature,howeverthe motion
sensing features will continue to work.
RESET BUTTON
islight can beresetto theoriginalfactory settingseither
by using the reset button on the bottom of the sensor or
throughtheHZconnectapp.Note: Afterresettingthelight,
it may take up to 5 minutes for the light to be removed
from the HZconnect app.
• Reset Button (see Figure 8) – Use a paper clip to press
the RESET button for 15 seconds to reset the light.
ForadditionalinformationconcerningthislightortheHZ-
connect app ,visit www.heath-zenith.com/HZconnect.

6 To see operational and troubleshooting information and videos,
go to www.hzsupport.com
210284-01
TROUBLESHOOTING GUIDE
SYMPTOM POSSIBLE CAUSE SOLUTION
e light will not come on. 1. Light switch is turned o.
2. Fuse is blown or circuit breaker is turned o.
3. Daylight turn-o (photocell) is in eect.
4. e circuit wiring is incorrect, if this is a new
installation.
5. e motion sensor is aimed in the wrong
direction.
6. e outside air temperature is close to the
same as a person’s body heat.
7. e light has been turned “OFF” using the
app.
1. Turn light switch on.
2. Replace fuse or turn circuit breaker on.
3. Recheck after dark.
4. Verify wiring is correct.
5. Re-aim the motion sensor to cover the
desired area.
6. Increase the sensitivity setting. See Seasonal
Changes on page 5 for more information.
7. Use the app to set the light to “AUTO”
mode.
e light comes on during
the day. 1. e motion sensor may be installed in a relatively dark location.
2. e “Full Brite Setting” in the app is set to
“TEST”.
1. e light xture is operating normally under
these circumstances.
2. Set the “Full Brite Setting” in the app to the
1, 5, or 20 minute setting.
e light comes on for no
apparent reason. 1. e motion sensor may be sensing small animals or automobile trac.
2. Sensitivity is set too high.
3. e “DualBrite Duration” in the app is in
the 3 hour, 6 hour, or dusk-to-dawn setting.
4. e outside temperature is much warmer or
cooler than a person’s body heat (summer or
winter).
5. e light xture is wired through a dimmer
or timer.
1. Decrease the sensitivity setting or reposition
the motion sensor.
2. Decrease the sensitivity setting.
3. e light xture is operating normally under
these circumstances.
4. Decrease the sensitivity setting. See Seasonal
Changes on page 5 for more information.
5. Do not use a dimmer or timer to control the
light xture. Replace the dimmer or timer
with a standard on/o wall switch.
e lights turn o too late
in Dusk-to-Dawn setting. e light xture may be installed in a relatively dark location. Relocate the light xture or use the 3 hour or 6 hour setting.
SPECIFICATIONS
Motion Sensing Range.........................Up to 70 ft. (21 m) [varies with surrounding temperature].
Motion Sensing Angle .........................Up to 180°
Camera Viewing Angle........................110°
Power Requirements.............................120 VAC, 60 Hz
Electrical load – LED...........................26 Watts
Oine Operating Modes.....................TEST and MOTION ACTIVATED
ON-Timer............................................1, 5, 20 minutes (Night Only)
Test Timer............................................5 Seconds (Day and Night)
Sensitivity.............................................“Low”, “Medium”, “High”
LED Lumens .......................................2000
LED color temperature ........................5000K

To see operational and troubleshooting information and videos, 7
go to www.hzsupport.com
210284-01
TROUBLESHOOTING GUIDE
SYMPTOM POSSIBLE CAUSE SOLUTION
e lights stay on
continuously. 1. e motion sensor may be picking up a heat source like an air vent, dryer vent, or brightly
painted, heat-reective surface.
2. e light has been turned “ON”using the
app.
3. e light xture is wired through a dimmer
or timer.
4. e light xture is on the same circuit as a
motor, transformer, or uorescent bulb.
1. Decrease the sensitivity setting or reposition
the motion sensor.
2. Use the app to set the light to “AUTO” or
“OFF” mode.
3. Do not use a dimmer or timer to control the
light xture. Replace the dimmer or timer
with a standard on/o wall switch.
4. Install the light xture on a circuit without
motors, transformers, or uorescent bulbs.
e lights ash on and o. 1. Heat or light from the lamp heads may be
turning the motion sensor on and o.
2. Heat is being reected from other objects
and may be turning the motion sensor on
and o.
3. e “Full Brite Setting” is in “TEST” mode
and warming up.
4. A utility company has installed a Smart
Meter device close to the light xture.
1. Reposition the lamp heads away from the
motion sensor.
2. Decrease the sensitivity setting or reposition
the motion sensor.
3. While in TEST mode, the light only stays on
for 5 seconds. Set the “Full Brite Setting” in
the app to the 1, 5, or 20 minute setting.
4. e Smart Meter device can create an
interference with motion sensing lights.
Relocate the light xture away from this type
of meter.
e lights ash once then
stay o in manual mode. e motion sensor is detecting light from the lamp heads. Reposition the lamp heads to keep the area below the motion sensor relatively dark.

8 To see operational and troubleshooting information and videos,
go to www.hzsupport.com
210284-01
ONE YEAR LIMITED WARRANTY
is is a “Limited Warranty”which gives you specic legal rights. You may also have other rights which vary from
state to state or province to province.
For a period of 1 year from the date of purchase,any malfunction caused by factory defective parts or workmanship
will be, at the sole option of HeathCo LLC, either repaired or replaced at no charge to you.
Not Covered - Repair service,adjustment and calibration due to misuse, abuse or negligence,light bulbs,batteries,
and other expendable items are not covered by this warranty. Unauthorized service or modication of the product
or of any furnished component will void this warranty in its entirety.is warranty does not include reimbursement
for inconvenience, installation, setup time, loss of use, unauthorized service, or return shipping charges. HeathCo
LLC reserves the right to discontinue products and to change specications at any time without incurring any
obligation to incorporate new features in products previously sold.
is warranty covers only HeathCo LLC assembled products and is not extended to other equipment and com-
ponents that a customer uses in conjunction with our products.
THISWARRANTYISEXPRESSLYINLIEUOFALLOTHERWARRANTIES,EXPRESSORIMPLIED,
INCLUDING ANY WARRANTY, REPRESENTATION OR CONDITION OF MERCHANT ABILITY
OR THAT THE PRODUCTS ARE FIT FOR ANY PARTICULAR PURPOSE OR USE,AND SPECIFI-
CALLY IN LIEU OF ALL SPECIAL,INDIRECT, INCIDENTAL,OR CONSEQUENTIAL DAMAGES.
REPAIR OR REPLACEMENT SHALL BE THE SOLE REMEDY OFTHE CUSTOMER ANDTHERE
SHALL BE NO LIABILITY ON THE PART OF HEATHCO LLC FOR ANY SPECIAL, INDIRECT,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO ANY
LOSS OF BUSINESS OR PROFITS, WHETHER OR NOT FORESEEABLE. Some states or provinces do
not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you.
Please keep your dated sales receipt, it is required for all warranty requests.
TECHNICAL SERVICE
Please call 1-800-858-8501 (English speaking only) for assistance before returning product to
store.
If you experience a problem, follow this guide. You may also want to visit our Web site at: www.hzsupport.com. If the
problem persists, call* for assistance at 1-800-858-8501 (English speaking only), 8:00 AM to 5:00 PM CST (M-F).
You may also write* to:
HeathCo LLC
P.O. Box 90045
Bowling Green, KY 42102-9045
ATTN: Technical Service
* If contacting Technical Service, please have the following information available: Model Number, Date of Purchase,
and Place of Purchase.
No Service Parts Available for this Product
Please keep your dated sales receipt, it is required for all warranty requests.

Para ver más información y vídeos sobre operación y resolución de problemas, 9
visite www.hzsupport.com
210284-01
© 2019 HeathCo LLC 210284-01 S
Se necesitael recibofechado parareemplazo bajogarantía.
CARACTERÍSTICAS
• Video de AD (HD) de 1080p
• Detector de movimiento de 180 °
• Alarma audible
• LED de ahorro de energía
DESEMPAQUE
Asegúrese de retirar todo el contenido del empaque y
vericar que todos los elementos estén incluidos antes de
ensamblar este aparato de luz. Este paquete incluye los
siguientes elementos:
• Luz de seguridad
• Manual del propietario
• Guía de inicio rápido de la aplicación HZconnect
• Ferretería de montaje
FERRETERÍA INCLUIDA
Nota: Se incluyen seis tornillos para el soporte de montaje. La instalación sólo requiere dos. Deseche los tornillos del
soporte de montaje no utilizados luego de la instalación.
Enchufe de Tornillo n°6 de soporte Tornillo n°8 de soporte
plástico de montaje (x2) de montaje (x2)
Tornillo de montaje Tornillo de montaje (Preinstalado en el aparato)
FRONT
Soporte de montaje Mini-destornillador
Luz LED de seguridad y
detectora de movimiento
con video conectada
Modelo: 9300

10 Para ver más información y vídeos sobre operación y resolución de problemas,
visite www.hzsupport.com
210284-01
R
E
S
E
T
THISSIDE UP
R
E
S
E
T
THISSIDE UP
INFORMACIÓN IMPORTANTE DE SEGURIDAD E INSTALACIÓN
Antes de instalar la luz de seguridad, lea todas las instrucciones con cuidado y guarde el manual del propietario para
futura referencia.
• ADVERTENCIA: Para evitar descargas eléctricas, asegúrese de que la alimentación esté desconectada antes de la ins-
talación.
• ADVERTENCIA: Riesgo de incendio. Mantenga las bombillas alejadas al menos 2 pulgadas (51mm) de materiales
combustibles.
• ADVERTENCIA: Peligro de descarga eléctrica. Para montaje en aleros,el centro de la caja de conexiones debe estar ubicado
al menos a 4 1/2 Pulg. (11,5 cm) desde el borde exterior del alero.
• PRECAUCIÓN: Para evitar daños causados por el agua y el riesgo de descarga eléctrica, el botón RESET del detector
de movimiento debe estar orientado hacia el suelo cuando se complete la instalación.
• PRECAUCIÓN: Mantenga los porta bombillas inclinados a 30° por debajo de la línea horizontal para evitar daños por
el agua o una descarga eléctrica.
• PRECAUCIÓN: Peligro de quemaduras. Deje que el aparato de luz se enfríe antes de tocarlo.
• AVISO: No conecte este aparato de luz a un interruptor reductor de luz ni a un temporizador.
• Este aparato de luz requiere 120 voltios CA.
• Este aparato de luz debe estar correctamente conectado a tierra.
• Algunas normativas eléctricas exigen que la instalación la realice un electricista calicado.
• Este aparato está diseñado para una instalación al aire libre y se lo debe montar en una pared o en aleros.
• Para lograr los mejores resultados, este aparato debe montarse a 8 pies (2,4 metros) por encima del suelo. Nota: Si el
aparato está instalado a más de 8 pies (2,4 m), si se apunta el detector hacia abajo se reducirá la distancia de cobertura.
El detector de movimiento de este aparato de luz detecta “movimiento” debido al movimiento del calor a través del
área de cobertura. El detector de movimiento es más sensible a la circulación del calor que se mueve a través del área de
cobertura y menos sensible a la circulación del calor que va directamente hacia él.
La cámara de video de esta lámpara tiene una zona de detección de 110 ° dentro del área de detección del detector de
movimiento. Es posible que la luz y la cámara no detecten movimiento al mismo tiempo.
Nota: La lámpara y el sensor debe montarse como se indica arriba, una vez instalado (según el tipo de instalación).
Lo menos sensible Lo más sensible
Detector
Movimiento Movimiento
Montaje en pared Montaje en alero
Zona de detección
de movimiento
con video
Zona de detección
de movimiento
con video
Zona de detección
del detector de
movimiento
Zona de detección
del detector de
movimiento
