I-Tech NK-1e User manual

NK-1e / NK-1b
1U Keyboard Drawer
Options :
- Full Range Combo KVM
User Manual
i-Tech Company LLC
EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 04-01-2022

Contents
< Part. 1 > NK-1e / NK-1b
1.1 Package Content P.1
1.2 Structure Diagram & Dimension P.1
1.3 Installation P.3
1.4 Connection P.4
< Part. 2 > Specications
2.1 Keyboard / Mouse Specications P.5
2.2 Environmental Conditions P.8
< Part. 3 > KVM Integration
3.1 NK1e P.9

P. 1
2
1
3
5
Installation Slides
Membrane switch (KVM option)
104-key keyboard
Mouse interchangeable module kit
Carry handle to release the 2-pt lock
1
2
3
4
5
4
NK-1e or NK-1b unit X 1
- M6 screw, cage nut & cup washer X 8
■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Unpacking
Before Installation
The above package content varies with KVM options.
< Part 1 > NK-1e / NK-1b
< 1.1 > Package Content
< 1.2 > Structure Diagram
RK-1e / RK-1b
Package Content
Structure Diagram & Dimension

P. 2
NK-1e / b
< 1.2 > Dimension
Front View
Side View
UNIT : mm
1mm = 0.03937 inch
Top View
Model Product Dimension
(W x D x H)
Packing Dimension
(W x D x H) Net Weight Gross Weight
NK-1e / NK-1b 442 x 600 x 44 mm
17.4 x 23.6 x 1.73 inch
580 x 845 x 115 mm
22.8 x 33.3 x 4.5 inch
10.9 kg
24 lb
13.2 kg
29 lb
* All dimensions stated are subject to change if options are selected / integrated to base model part codes
Rear View
KB / MS
Power

P. 3
< 1.3 > Installation - How to install Installation Slides
■Insert the left and right rear mounting bracket into
the keyboard drawer.
Step 1
Step 2
■Measure the depth of the front and rear mounting rails.
■Align each rear mounting bracket to a suitable length.
■Fix the keyboard drawer into the rack.
Complete the installation
Step 3
M6 screw, cage nut & cup washer x 8 are provided.
Installation

P. 4
NK-1e / b
Caution : The keyboard drawer is hot-pluggable, but components of connected devices, such
as the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables
while servers and KVM are powered on may cause irreversible damage to the servers, KVM and
keyboard drawer. Before attempting to connect anything to the keyboard drawer, we suggest
turning o󰀨 the power to all devices. Apply power to connected devices again only after the
keyboard drawer is receiving power. The company is not responsible for damage caused in this way.
< 1.4 > Connection to USB Server
< 1.4 > Connection to external KVM
Keyboard Drawer
Keyboard Drawer
USB server
USB console KVM
Connection
attached 2-in-1
K/B cable
USB
attached 2-in-1
K/B cable

P. 5
Key force 55 ± 5g
Travelling distance 3 ± 0.3mm
Switch life > 10 million life cycle time
OS support Windows / Linux / Unix / Mac OS
G keyboard integrated with trackball
Gb
G keyboard integrated with touchpad
Ge
< Part 2 > Specications
< 2.1 > Standard Keyboard / Mouse Specications
Specications
Keyboard / Mouse Specications
Supporting layouts
America
United States
EMEA
United Kingdom Germany France Spain Italy
Asia
Japan Korea

P. 6
NK-1e / b
< 2.1 > MAC Keyboard / Mouse Options
MAC keyboard integrated with trackball
Mb
MAC keyboard integrated with touchpad
Me
How to Use "MAC" Keyboard
Keyboard Features
F1
Decrease display brightness
F9
Fast-forward
F2
Increase display brightness
F10
Mute sound
F3
Mission control
* Only works with OS X Lion
default Keyboard Shortcuts.
F11
Decrease volume
F4
Dashboard
F12
Increase volume
F7
Rewind Eject disc
F8
Play / Pause Command
Supporting layouts
America
United States

P. 7
< 2.1 > SUN Keyboard / Mouse Options
Audio / Display Keys * Please ask your supplier for full details
F9
Audio : Mute
Display : Degauss
F11
Audio : Decrease volume
Display : Decrease contrast
F12
Audio : Increase volume
Display : Increase contrast
Num LED in Green mode
Key pad behaves as a normal key
pad mode
Num Cap s Scro ll Comp oseNum Cap s Scro ll Comp ose
■Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help
■104 key notepad keyboard with full numerical pad and SUN function
■USB interface
■US layout only
S keyboard integrated with touchpad / trackball
Num LED in O󰀨 mode
Key pad behaves as a SUN Solar
system administration command mode
How to Use "S" Keyboard
S keyboard integrated with trackball
Sb
S keyboard integrated with touchpad
Se

P. 8
NK-1e / b
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage / Non-operating Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration (11ms duration)
Vibration 10~300Hz 0.5G RMS random vibration
< 2.2 > Environmental Conditions
Environmental Conditions

P. 9
Model Product Dimension
(W x D x H)
Packing Dimension
(W x D x H) Net Weight Gross Weight
NK1 with KVM 442 x 600 x 44 mm
17.4 x 23.6 x 1.73 inch
580 x 845 x 115 mm
22.8 x 33.3 x 4.5 inch
10.9 kg
24 lb
13.2 kg
29 lb
KVM Integration
RK1e
DB-15
Combo
KVM
Local Remote 8-port 16-port 32-port
1 0 1 -IP8 -IP16 -
1 1 0 -CE8 -CE8 -
1 0 0 -SS8 -S16 -
DB-15
Matrix
KVM
Local Remote 8-port 16-port 32-port
1 1 1 -M118 -M1116 -
1 1 2 -M218 -M2116 -
1 1 0 -M018 -M0116 -
1 2 0 -M028 -M0216 -
1 3 0 -M038 -M0316 -
DVI-D
KVM
Local Remote 12-port - -
1 0 0 -12De- -
2K
KVM
Local Remote 8-port - -
0 0 0 -K8e - -
< Part 3 > KVM Integration
< 3.1 > NK1e
Cat6
Combo
KVM
Local Remote 8-port 16-port 32-port
1 0 1 -CIP8 -CIP16 -CIP32
1 1 0 -CCE8 -CCE16 -CCE32
1 0 0 -C8 -C16 -C32
Cat6
Matrix
KVM
Local Remote 8-port 16-port 32-port
1 1 1 --MC1116 -MC1132
1 1 2 --MC2116 -MC3224
1 1 0 --MC0116 -MC0132
1 2 0 --MC0216 -MC0232
1 3 0 - -MC0316 -MC0332
