I-View EPOC-131VAT User manual

1
Product Overview:
1. Extend: Terminal block Connector converter allows 10/100 Base-T Ethernet and PoE power to be transmitted
using 2-Wire cable.
2. Link: The LED indicates the cable link status. The LED will be on after 10 seconds when first connection is
success; Off: No connection.
3. Pwr: The LED indicates the power status. On: Power on; Off: No power.
4. Ethernet/PoE: RJ45 connector, attaches to POE IP Camera or Hub via Cat5, 5e, 6 or 7 patch cables.
5. Eth: The LED indicates the communication status. Flash: Communicate with Traffic; Off: No connection.
6. Power jack: Plug DC power adapter to for PoE source when PoE Hub cannot provide enough power source.
7. PoE: The LED indicates the PoE power status. On: PoE power is provided; Off: No PoE power.
Packing Checklist:
Check the package box the following items are included:
EPOC-131VAT & EOPC-131PST x 1 set
Menu x 1 Pc
Installation Steps:
IPcamera end
1. Connect the IP camera RJ45 connector to the 10/100BaseT Ethernet port of EPOC-131PST using a standard
Cat5/6 cable of maximum 100 m (328 feet) in length.
2. Connect one end of the long 2-Wire cable such as power core, Bell wire to the 2-Pin Terminal block connector of
EPOC-131PST.
Note: Each wire MUST connects same port of terminal block; such as Blue-wire (+) Blue-wire (+);
White-wire (-) Blue-wire (-) )
3. When the IP camera and EPOC-131PST cannot receive power through the 2-Wire cable, even though using the
POE+ Hub or plug DC56V power adapter for EPOC-131VAT. Plug the DC48V power adapter into the
EPOC-131PST will be needed at this end. Please refer to “Power Distance VS. Cable Impedance”table.
Switch Hub end
1. Connect the PoE switch Hub RJ45 connector to the 10/100BaseT Ethernet port of EPOC-131VAT using a
standard Cat5/6 cable of maximum 100 m (328 feet) in length.
2. Connect one end of the long UTP cable such as Cat.5, 5e, 6, or 7 cable to the RJ45 (No light) of EPOC-131VAT.
3. When the IP camera and EPOC-131PST cannot receive power through the Wire cable, please change the POE+
Hub or plug DC56V power adapter to EPOC-131VAT.
Ethernet/PoE Extender over 2-Wire Cable Installation Guide
V1.2
6
4
2
3
1
5
7
6
5
4
3
2
1
1

2
ProductApplication Diagram
The Ethernet over 2-Wire cable system supports virtually any type of 2-wire cable, including such as power core,
Telephone wire. And different wire types can be concatenated together, as needed.
To avoid the interference signal, we strongly recommend using the shield cable when there are more 8 pcs
EPOC-131VAT install at the same Hub site.
Point to Point Topology
The IP camera and EPOC-131PST cannot receive power through the 2-wire cable. Please do as below:
1. POE+ Hub or plug DC56V power adapter for EPOC-131VAT.
2. Plug the DC48V power adapter into the EPOC-131PST will be needed at this end. Please refer to “Power
Wattage VS. Cable Distance”table or visit www.i-view.com.tw
Power Wattage VS. Cable Distance
Plug DC48V/56V power adapter to EPOC-131PST when the EPOC-13TPST cannot receive power.

3
Data Rate VS. Cable distance
LED Function table
Name
Color
Status
Function
Pwr
Yellow
On
Power is on
Off
Power is off
Eth
Green
Flashing
Communication is OK with Traffic
Off
No communication
Link
Green
On
Connection is OK; (It take 10 sec. for LED on)
Off
No connection
PoE
Green
On
PoE is offering
Off
No PoE offer

4
Specification:
1.Distance and number of devices supported may be lower due to power supply capacity and wire voltage-drop. The bandwidth is
dynamically allocated (shared based on traffic), and decreases with wire distance.
Phone: [phone] Fax: [phone]
Mail: [e-mail]
ITEM \ MODEL
EPOC-131VAT
EPOC-131PST
EPOC-131PST-O
Ethernet
Connector
RJ-45
RJ-45
RJ-45
Connectivity
10/100/1000 Base-T auto-negotiation, auto MDI / MDX crossover
Wire type
Cat5 or better
Distance
Up to 328 feet (100m)
Cable Link
Connector
RJ-45
Type
Receiver (Hub Site)
Transmitter (Camera Site)
Wire type
Any 2-Wire cable
Distance
Up to 600 Meters (1980 feet)
Topology
Supports Star, Daisy-Chain, or any combination
Encryption
128-bit AES
Latency
3 ms
Bandwidth
Total network bandwidth 150 Mbps; with dynamic bandwidth allocation
Power
Power Source
PoE Hub; DC44～56V
PoE or DC48V
PoE or DC48V
Power Output
PoE (RJ-45 via 4 pairs)
25W PoE (RJ45); (50W Option)
Physical
Waterproof
None
None
IP 66
Dimensions (mm)
100 x 55 x 34
100 x 55 x 34
128 x 102 x 36
Weight
140g
140g
310g
LEDs
Status indicators
Cable link
Ethernet Power
Ethernet link/activity
Cable link
Ethernet Power
PoE Connection
Ethernet link/activity
Cable link
Ethernet Power
PoE Connection
Ethernet link/activity
Environment
Temperature
Operation: 0℃to 50℃/ 14℉to 122℉
Humidity
20% ~ 85% non-condensing
Power consumption
≤ 2W
Transient immunity
20µS x5 3,000A, 6,000V; ESD 20KV, 200pF
