Iai Sp-20000c-usb User manual

10051E-1404

Spark Series

SP-20000M-USB

SP-20000C-USB

20 MP CMOS Digital Progressive Scan

Monochrome and Color Camera

Document Version: Ver.1.4

SP-20000-USB_Ver.1.4_May2015

User Manual

SP-20000M-USB / SP-20000C-USB

- 2 -

Notice

The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan and

may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its

product and assumes no responsibility for any errors which may appear or for damages resulting from the

use of the information contained herein. JAI Ltd., Japan reserves the right to make changes without

notice.

Company and product names mentioned in this manual are trademarks or registered trademarks of their

respective owners.

Warranty

For information about the warranty, please contact your factory representative.

Certifications

CE compliance

As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC

(Electromagnetic compatibility), JAI Ltd., Japan declares that SP-20000M-USB and SP-20000C-USB

comply with the following provisions applying to its standards.

EN 61000-6-3 (Generic emission standard part 1)

EN 61000-6-2 (Generic immunity standard part 1)

FCC

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-Consult the dealer or an experienced radio/TV technician for help.

Warning

Changes or modifications to this unit not expressly approved by the party

responsible for FCC compliance could void the user’s authority to operate the

equipment.

SP-20000M-USB

Supplement

The following statement is related to the regulation on “ Measures for the Administration

of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “.

The table shows contained Hazardous Substances in this camera.

mark shows that the environment-friendly use period of contained Hazardous

Substances is 15 years.

嶷勣廣吭並㍻

嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕

功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇



云恢瞳ゞ嗤蕎



嗤

墾麗嵎賜圷殆兆各式根楚燕〃泌和



桟隠聞喘豚㍉

窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌

亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半

賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。

方忖仝15々葎豚㍉15定。

SP-20000C-USB

Supplement

The following statement is related to the regulation on “ Measures for the Administration

of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “.

The table shows contained Hazardous Substances in this camera.

mark shows that the environment-friendly use period of contained Hazardous

Substances is 15 years.

嶷勣廣吭並㍻

嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕

功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇



云恢瞳ゞ嗤蕎



嗤

墾麗嵎賜圷殆兆各式根楚燕〃泌和



桟隠聞喘豚㍉

窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌

亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半

賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。

方忖仝15々葎豚㍉15定。

SP-20000M-USB / SP-20000C-USB

- 3 -

-Contents -

Introduction.....................................................................................- 6 -

1. General....................................................................................- 7 -

2. Camera composition....................................................................- 7 -

3. Key features ...............................................................................- 8 -

4. Parts locations and their functions ...................................................- 9 -

4.1 Parts locations and their functions........................................................................- 9 -

4.2 Rear Panel.................................................................................................. - 10 -

5. Input and output.......................................................................... - 11 -

5.1 USB 3.0 Interface specifications ....................................................................... - 11 -

5.2 Connectors and pin assignment ........................................................................ - 11 -

5.2.1 Digital Video Output (USB3.0 Micro B connector).............................................. - 11 -

5.2.2 12-Pin connector..................................................................................... - 11 -

5.2.2.1 Figure............................................................................................. - 11 -

5.2.2.2 Pin configuration ............................................................................... - 12 -

5.2.3 AUX Connector Hirose 10-Pin connector .................................................... - 12 -

5.3 Digital In and out inteface .............................................................................. - 13 -

5.3.1 Line Selector ......................................................................................... - 13 -

5.3.2 Line Source ........................................................................................... - 13 -

5.3.3 Line Mode ............................................................................................. - 14 -

5.3.4 Line Inverter.......................................................................................... - 14 -

5.3.5 Line Status ............................................................................................ - 14 -

5.3.6 Line Format........................................................................................... - 14 -

5.3.6 GPIO.................................................................................................... - 14 -

5.3.6.1 Basic block diagram ............................................................................ - 14 -

5.3.6.2 Input and output matrix table ............................................................... - 16 -

5.3.6.3 Associated GenICam Register information ................................................. - 17 -

5.4 Optical Interface ........................................................................................... - 18 -

5.4.1 Recommended External Input circuit diagram for customer ................................ - 18 -

5.4.2 Recommended External Output circuit diagram for customer .............................. - 18 -

5.4.3 Characteristics of optical interface ............................................................. - 19 -

5.5 Pulse Generator ........................................................................................... - 19 -

5.5.1 Clock Pre-scaler...................................................................................... - 19 -

5.5.2 Pulse Generator Selector........................................................................... - 20 -

5.5.3 Pulse Generator Length ............................................................................ - 20 -

5.5.4 Pulse Generator Start Point........................................................................ - 20 -

5.5.5 Pulse Generator End Point ......................................................................... - 20 -

5.5.6 Pulse Generator Repeat Count .................................................................... - 20 -

5.5.7 Pulse Generator Clear Activation ................................................................. - 21 -

5.5.8 Pulse Generator Clear Sync Mode................................................................. - 21 -

5.5.9 Pulse Generator Clear Source ..................................................................... - 22 -

5.5.10 Pulse Generator Inverter ......................................................................... - 23 -

5.5.11 Pulse Generator setting parameters ............................................................ - 23 -

6. Sensor layout, output format and timing ........................................ - 25 -

6.1 Sensor layout .............................................................................................. - 25 -

6.1.1 Monochrome sensor ................................................................................. - 25 -

6.1.2 Bayer sensor .......................................................................................... - 25 -

6.2 Camera output format (Tap Geometry) .............................................................. - 26 -

6.2.1 1X–1Y................................................................................................... - 26 -

6.2.2 Pixel Type............................................................................................. - 26 -

6.3 Output timing and output image ....................................................................... - 27 -

6.3.1 Horizontal timing .................................................................................... - 27 -

6.3.2 Vertical timing ....................................................................................... - 29 -

SP-20000M-USB / SP-20000C-USB

- 4 -

6.3.3 ROI (Region Of Interest) ............................................................................ - 31 -

6.3.4 Mirroring function ................................................................................... - 33 -

6.3.5 Multi ROI function ................................................................................... - 34 -

6.3.5.1 Multi ROI setting parameters................................................................. - 34 -

6.3.5.2 Associated GenICam register information ................................................. - 36 -

6.4 Digital output bit allocation ............................................................................ - 36 -

7. Operating modes ......................................................................- 37 -

7.1. Acquisition control (change the frame rate)........................................................ - 37 -

7.1.1 Acquisition Mode..................................................................................... - 37 -

7.1.1.1 Single Frame .................................................................................... - 37 -

7.1.1.2 Multi Frames .................................................................................... - 38 -

7.1.1.3 Continuous....................................................................................... - 39 -

7.1.2 Acquisition Start ..................................................................................... - 39 -

7.1.3 Acquisition Stop...................................................................................... - 39 -

7.1.4 Acquisition control .................................................................................. - 40 -

7.1.4.1 Upper limit of Frame Rate.................................................................... - 41 -

7.1.4.2 Calculation formula of Frame Rate (In Continuous Trigger operation) ................ - 42 -

7.2. Exposure control ......................................................................................... - 44 -

7.2.1 Exposure Mode ....................................................................................... - 44 -

7.2.2 ExposureTime ........................................................................................ - 45 -

7.2.3 Behavior if Trigger Overlap is set to Readout .................................................. - 46 -

7.2.3 ExposureAuto......................................................................................... - 46 -

7.3. Trigger operation ........................................................................................ - 47 -

7.3.1 Trigger Selector...................................................................................... - 48 -

7.3.2 Trigger Mode ......................................................................................... - 48 -

7.3.1 TriggerSource ........................................................................................ - 48 -

7.3.2 TriggerActivation .................................................................................... - 49 -

7.3.3 Triggeroverlap........................................................................................ - 49 -

7.4. Normal continuous operation (Timed Exposure Mode/Trigger Mode OFF)..................... - 49 -

7.5. Timed mode (EPS operation) .......................................................................... - 50 -

7.5.1 If Overlap setting is OFF............................................................................ - 50 -

7.5.2 If Overlap setting is Readout ...................................................................... - 54 -

7.5.3 GPIO TTL output timing if Trigger Overlap is OFF ............................................. - 57 -

7.5.6 GPIO TTL output timing if Trigger Overlap is Readout........................................ - 58 -

7.6 Trigger width mode (PWC) .............................................................................. - 60 -

7.6.1 If Overlap setting is OFF............................................................................ - 60 -

7.6.2 If Overlap setting is Readout ...................................................................... - 64 -

7.7 PIV (Particle Image Velocimetry) ...................................................................... - 67 -

7.8 Sequence ROI Trigger .................................................................................... - 73 -

7.8.1 Sequence ROI Trigger mode ....................................................................... - 73 -

7.8.2 Video Send Mode..................................................................................... - 73 -

7.8.3 Trigger Sequence .................................................................................... - 73 -

7.8.4 Command Sequence................................................................................. - 73 -

7.8.5 Typical minimum trigger interval of Sequence ROI Trigger .................................. - 74 -

7.8.6 Defaul Sequence Index Table...................................................................... - 75 -

7.8.7 Sequence ROI setting parameters ................................................................ - 75 -

7.9. Acqusition Transfer Start Trigger ..................................................................... - 80 -

7.10. Operation and function matrix....................................................................... - 83 -

8. Other functions ........................................................................- 84 -

8.1 Black level control........................................................................................ - 84 -

8.1.1 Black Level Selector................................................................................. - 84 -

8.1.2 Black Level............................................................................................ - 84 -

8.1.3 Auto black control ................................................................................... - 84 -

8.1.4 Associated GenICam register information....................................................... - 85 -

8.2 Gain control................................................................................................ - 85 -

8.2.1 Gain Selector ......................................................................................... - 86 -

SP-20000M-USB / SP-20000C-USB

- 5 -

8.2.2 Gain .................................................................................................... - 86 -

8.2.3 Gain Auto ............................................................................................. - 86 -

8.2.4 Balance White Auto ................................................................................. - 86 -

8.2.5 Associated GenICam register information ....................................................... - 87 -

8.3. LUT ......................................................................................................... - 88 -

8.3.1 LUT Mode.............................................................................................. - 88 -

8.3.2 LUT Index ............................................................................................. - 88 -

8.3.3 LUT Value ............................................................................................. - 88 -

8.3.4 Associated GenICam register information ....................................................... - 88 -

8.4 Gamma...................................................................................................... - 89 -

8.5 Shading Correction ....................................................................................... - 89 -

8.6 Blemish compensation ................................................................................... - 90 -

8.7 ALC .......................................................................................................... - 91 -

8.8 HDR function (Option) ................................................................................... - 93 -

9. Camera Control Settings .............................................................. - 95 -

9.1 Camera Control Tool ..................................................................................... - 95 -

9.2 Camera Default Settings ................................................................................. - 95 -

10. External appearance and dimensions .......................................... - 96 -

11. Specifications ........................................................................ - 97 -

11.1. Camera spectral response ............................................................................ - 97 -

11.2. Specification table ..................................................................................... - 98 -

Appendix .................................................................................... - 100 -

1. Precautions .................................................................................................. - 100 -

2. Typical Sensor Characteristics............................................................................ - 100 -

3. Caution when mounting a lens on the camera ........................................................ - 100 -

4. Caution when mounting the camera .................................................................... - 100 -

5. Exportation .................................................................................................. - 101 -

6. References ................................................................................................... - 101 -

Manual change history .................................................................... - 102 -

User's Record ............................................................................... - 103 -

SP-20000M-USB / SP-20000C-USB

- 6 -

Introduction

EMVA 1288

With regard to signal to noise ratio in this manual, specifications measured by EMVA 1288 are used

together with specifications by a traditional measurement method.

EMVA 1288 is a more complete measurement that considers multiple noise sources, including random

noise, pattern noise, and shading. Additionally, EMVA 1288 incorporates temporal variances in pixel

output by capturing 100 frames of data and computing the RMS variations over the captured frames.

Because of the comprehensive nature of the noise analysis and the additional consideration for RMS

variances over time, EMVA 1288 SNR measurements are inherently lower than the traditional SNR

measurements given by manufacturers. However, the comprehensive nature combined with rigid test

parameters, means that all manufacturers’ are measuring their products equally and EMVA 1288 tested

parameters can be compared among different manufacturers’ products.

In order to learn more about EMVA 1288, please visit http://www.emva.org

Interface

The SP-20000-USB employs a USB 3.0 interface and is in the process of being certified for compliance

with the USB3 Vision standard. USB3 Vision is a new standard interface for machine vision applications

being developed and managed by the AIA (Automated Imaging Association). USB3 Vision uses USB 3.0

ports that will soon be standard on most PCs (with Windows 7 service pack and Windows 8 native support

expected soon). Components from different manufacturers will easily communicate with each other.

USB3 Vision also supports the GenICamTM standard which is managed by the EMVA (European Machine

Vision Association). The purpose of the GenICam standard is to provide a common program interface for

various machine vision cameras. By using GenICam, cameras from different manufacturers can

seamlessly connect in one platform.

The maximum transfer speed of USB 3.0 is specified at 5.0 Gbps, however effective bandwidth is reduced

by a number of factors including pixel format conversions and the physical interface components used.

The USB3 Vision standard specifies a bandwidth of 2.8 Gbps or greater. Maximum cable length for passive

cables is five meters, but this can be made longer using active cables.

As for the USB connector, SP-20000-USB uses a Micro B connector which complies with USB3.0. This

connector has an additional 5-pin plug “stacked” on the side of a standard USB 2.0 Micro B connector.

However, USB 2.0 cannot be used with the SP-20000-USB.

Power supply

Although the USB 3.0 interface is capable of supporting both data and power, the power supplied through

the interface is not sufficient to operate the camera. A separate power supply unit must be connected to

the 12-pin connector.

Computer used for SP-20000-USB series

It is necessary to use a PC equippped with a USB 3.0 interface. It is also recommended to use a PC

equipped with slots of better than PC Express 2.0 x 8. Please note that the SP-20000-USB may not work

properly depending on the chipset used in the PC.

SP-20000M-USB / SP-20000C-USB

- 7 -

1. General

The SP-20000-USB cameras are members of JAI’s new “Spark Series.”They provide both high resolution

and a high frame rate with excellent image quality for machine vision applications. The SP-20000M-USB

is a monochrome progressive scan COMS camera and the SP-20000C-USB is the equivalent Bayer mosaic

progressive scan CMOS camera. Both are equipped with CMOS sensors offering a 35 mm full size image

format, a resolution of 20 million pixels, and a 4:3 aspect ratio. They provide 16 frames per second for

continuous scanning with 5120 x 3480 full pixel resolution for both monochrome and raw Bayer output.

8-bit, 10-bit and 12-bit outputs can be selected for both monochrome and raw Bayer formats. The new

cameras feature a USB3 Vision interface. A full pixel readout or partial scan readout mode can be

selected depending on applications.

The SP-20000-USB has various comprehensive functions needed for automated optical inspection

applications, such as solid state device inspection or material surface inspection. They incorporate video

processing functions such as a look-up table, flat field shading compensation and blemish compensation

in addition to fundamental functions such as trigger, exposure setting and video level control.

The latest version of this manual can be downloaded from: www.jai.com

The latest version of the JAI SDK for the SP-20000-USB can be downloaded from: www.jai.com

For camera revision history, please contact your local JAI distributor.

2. Camera composition

The standard camera composition is as follows.

Camera body 1

Sensor protection cap 1

Dear Customer (sheet) 1

The following optional accessories are available.

Tripod base

MP-42

Power supply unit

PD-12 series

SP-20000M-USB / SP-20000C-USB

- 8 -

3. Key features

New Spark Series, 35mm full size, CMOS 20-megapixel progressive scan camera with global shutter

Utilizes USB3 Vision interface

Aspect ratio 4:3, 5120(H) x 3840(V) - 20 million effective pixels

6.4 μm square pixels

S/N 53 dB for monochrome and 51 dB for color

8-bit, 10-bit or 12-bit output for monochrome and Bayer color

16 frames/second with full resolution in continuous operation

Supports ROI (Region Of Interest) modes for faster frame rate

0 dB to +24 dB gain control for both SP-20000-USB models

299 μs (1/3,344) to 8 seconds exposure control in 1 μs step

Auto exposure control

Timed and trigger width exposure control

PIV and sequential trigger modes for specific applications

ALC control with combined function of AGC and auto exposure

HDR (High Dynamic Range) function is available (Option)

Various pre-processing circuits are provided

Programmable LUT

Gamma correction from 0.45 to 1.0

Flat field correction

Bayer white balance with manual or one-push auto (SP-20000C-USB only)

Blemish compensation

New Hirose 10P connector for TTL IN and OUT and LVDS IN interface

F-mount for lens mount

Setup by Windows XP/Vista/7 via serial communication

SP-20000M-USB / SP-20000C-USB

- 9 -

4. Parts locations and their functions

4.1 Parts locations and their functions

Lens mount F-mount (Note *1)

AUX 10-pin connector AUX Connector for TTL IN/OUT and LVDS IN

LED Indication for power and trigger input

12-pin connector DC and trigger input

USB 3.0 connector Connector for interfacing USB 3.0

Mounting holes Holes for mounting tripod base or direct installation.

Depth 5 mm (Note*2)

*1) Note1: Rear protrusion on F-mount lens must be less than 14.0 mm.

*2) Note2: The part number for the tripod adapter plate (with 1/4"-20 thread) is MP-42 (option).

When the camera is mounted directly using mounting holes, the length of screws must be less

than 5mm. If they are longer than 5mm, they may not fasten securely due to the 5mm hole

depth.

Fig. 1 Locations

SP-20000M-USB / SP-20000C-USB

- 10 -

4.2Rear Panel

The rear panel mounted LED provides the following information:

Amber: Power connected –initiating

This light goes OFF after initiating.

Steady green: Camera is operating in Continuous mode

Flashing green: The camera is receiving external triggering

Note: The interval of flashing does not correspond with external

trigger duration.

Fig. 2 Rear panel

SP-20000M-USB / SP-20000C-USB

- 11 -

5. Input and output

5.1 USB 3.0 Interface specifications

The SP-20000-USB employs a USB 3.0 interface for video and data transfer. USB 3.0 is an upgraded

version of USB 2.0 widely used in the industry. Its transfer rate is 5 Gbps, which is 10 times faster than

the 480 Mbps rate of USB 2.0. USB 3.0 employs full-duplex system which executes both transmitting

and receiving at the same time. USB 3.0 has downward compatibility to USB 2.0 but in the SP-20000-USB,

USB 2.0 cannot be used because the performance is not guaranteed.

The connector used for USB 3.0 in the SP-20000-USB is a Micro B Type connector with a USB 3.0 form

factor.

5.2Connectors and pin assignment

5.2.1 Digital Video Output (USB3.0 Micro B connector)

Type: ZX3600-B-10P or equivalent

図3．USB3.0 Micro B Connector

Table 1. USB3.0 Pin Configuration

I/O

Name

Note

VBUS IN

Power(VBUS) +5V

I/O

USB2.0 Differential pair(D-)

I/O

USB2.0 Differential pair(D+)

OTG ID

USB OTG ID for identifying lines

GND

FX3 SSTXM

USB3.0 Signal Transmission line (-)

FX3 SSTXP

USB3.0 Signal Transmission line (+)

GND

FX3 SSRXP

USB3.0 Signal Receiving line (-)

FX3 SSRXM

USB3.0 Signal Receiving line (+)

Note1: Power is not supplied through the USB 3.0 interface. Requires an external power supply.

Note2: USB 2.0 interface is not supported.

5.2.2 12-Pin connector

5.2.2.1 Figure

Type: HR-10A-10R-12PB(72) Hirose male or equivalent.

Fig.3 12-pin connector

1 2 3 4 5 678910

SP-20000M-USB / SP-20000C-USB

- 12 -

5.2.2.2 Pin configuration

Table –2 12-pin configuration

Note 1) Factory default setting is Exposure Active and negative

Note 2) Factory default setting is trigger input.

5.2.3 AUX Connector Hirose 10-Pin connector

Type: HIROSE 10-Pin Connector 3260-10S3(55)

Fig. 4 Hirose 10p connector

Table-3 Pin configuration for Hirose 10P

I/O

Name

Note

TTL OUT2

Line8

TTL OUT3

Line9

TTL IN2

Line10

GND

LVDS IN1+

Line11

LVDS IN1-

GND

Pin no.

Signal

Remarks

GND

DC input

+12V ～+24V (note 3)

GND

OPTO IN-

Line 5

OPTO IN+

OPTO OUT -

Line 2

OPTO OUT+

TTL out 1

Line1 (note 1)

TTL In 1

Line4 (note 2)

DC input

+12V ～+24V (note 3)

GND

SP-20000M-USB / SP-20000C-USB

- 13 -

5.3Digital In and out inteface

In the SP-20000-USB, the software control tool can assign the necessary signals used in the system to

digital inputs and outputs.

5.3.1 Line Selector

In the Line Selector, the following input and output signals can be assigned.

Table –4 Line Selector

5.3.2 Line Source

Line source signal can be selected from the following table to connect it to the line item which is

selected in the line selector.

Table-5 Line Source

Line Selector item

Description

Line 1 TTL OUT 1

TTL output from #9 pin of DC In/Trigger HIROSE 12-Pin on the rear

Line 2 OPTO OUT 1

Optical output from #7 and 8 pins of DC In/Trigger HIROSE 12-Pin on the rear

Line 8 TTL OUT 2

TTL output from #1 pin “AUX” HIROSE 10-Pin on the rear

Line 10 TTL OUT 3 t

TTL output from #2 pin “AUX” HIROSE 10-Pin on the rear

NAND 0 In 1

First input at first NAND gate in GPIO

NAND 0 In 2

Second input at first NAND gate in GPIO

NAND 1 In 1

First input at second NAND gate in GPIO

NAND 1 in 2

Second input at second NAND gate in GPIO

Note: In the line source, input interfaces besides those mentioned above will be shown but

the line source setting is not available. The input interface can be configured in the trigger

source and the pulse generator source.

Line Source item

Description

Low

Connect Low Level signal to line item selected in Line Selector, Default setting

High

Connect High Level signal to line item selected in Line Selector

Acquisition Trigger Wait

Connect Acqusition Trigger Wait signal to line item selected in Line Selector

Acqusition Active

Connect Acqusition Active signal to line item selected in Line Selector

Frame Trigger Wait

Connect Frame Trigger Wait signal to line item selected in Line Selector

Frame Active

Connect Frame Active signal to line item selected in Line Selector

Exposure Active

Connect Exposure Active signal to line item selected in Line Selector

FVAL

Connect FVAL signal to line item selected in Line Selector

LVAL

Connect LVAL signal to line item selected in Line Selector

PulseGenerator0 Out

Connect Pulse Generator 0 signal to line item selected in Line Selector

PulseGenerator1 Out

Connect Pulse Generator 1 signal to line item selected in Line Selector

Line 4 –TTL IN 1

Connect TTL IN 1 signal to line item selected in Line Selector

Line 5 –OPTO IN 1

Connect OPTO IN 1 signal to line item selected in Line Selector

User output 0

Connect User output 0 signal to line item selected in Line Selector

User output 1

Connect User output 1 signal to line item selected in Line Selector

User output 2

Connect User output 2 signal to line item selected in Line Selector

User output 3

Connect User output 3 signal to line item selected in Line Selector

Nand0 Out

Connect NAND 0 signal to line item selected in Line Selector

Nand1 Out

Connect NAND 1 signal to line item selected in Line Selector

Line 10 TTL IN 2

Connect TTL IN 2 signal to Line 10

Line 11 LVDS IN

Connect LVDS IN signal to Line 11

Note: (1) The user output is the trigger signal generated by software in PC for the camera.

(2) As for LVAL, some line items cannot be connected. Refer to “5.3.6.2 GPIO matrix table”

SP-20000M-USB / SP-20000C-USB

- 14 -

5.3.3 Line Mode

Indicates the status of the item selected in Line Selector. (INPUT or OUTPUT)

5.3.4 Line Inverter

Inverts the signal polarity for the item selected in Line Selector. (False=Positive, True=Negative)

5.3.5 Line Status

Indicates the status of the selected signal (input or output) (True=High, False=Low)

5.3.6 Line Format

Indicates the interface category of input and output for the selected signal.

Category: No connect, TTL, LVDS and OPTO coupled

5.3.6 GPIO

GPIO is a general interface for input and output and controls the I/O for trigger signals and other valid

signals and pulse generators. By using this interface you can control an external light source, make a

delay function for an external trigger signal, or make a precise exposure setting together with a PWC

trigger.

5.3.6.1 Basic block diagram

The basic block diagram is as follows.

In the SP-20000-USB, the pixel clock is 40 MHz.

SP-20000M-USB / SP-20000C-USB

- 15 -

Soft Trigger

FVAL IN

Exposure Active

Acquisition Trigger Wait

Acquisition Active

Frame Trigger Wait

Frame Active

GPIO 4 (TTL IN 1)

GPIO 10 (TTL IN2)

GPIO 11 (LVDS IN)

Pixel Clock

Cross Point

Switch

12 bit Counter

INV

INV N

NAND

INV

Non INV

Pulse Generator

20 bit counter x 2

CLR

Sel Bit (5,0) Sel Bit (7)

Sel Bit (7)

Pulse Generator 0

Pulse Generator 1

Trigger 1 (Acquisition End)

GPIO 1 (TTL OUT 1)

GPIO 8 (TL OUT 2)

GPIO 9 (TTL OUT 3)

Sel Bit (7)

Ｃｌｏｃｋ　ＩＮ

Ｃｌｅａｒ　ＩＮ

Gate 1

Gate 2

User output 0

User output 1

User output 2

User output 3

GPIO 5 (OPTO IN 1)

Trigger 0 (Acquisition Start)

Trigger 2 (Frame Start)

GPIO 2 (OPT OUT 1)

Trigger 3 (Acquisition

Transfer Start)

Fig.5 GPIO interface

SP-20000M-USB / SP-20000C-USB

- 16 -

5.3.6.2 Input and output matrix table

The relationship between input and output is as follows.

Table - 6 GPIO matrix table

Selector (Cross

point switch output)

Source signal

(Cross point switch input)

Low              

High              

Soft Trigger              

Acqusition Trigger Wait              

Acqusition Active              

Exposure Active              

Frame Trigger Wait              

Frame Active              

FVAL              

LVAL              

Pulse Generator 0              

Pulse Generator 1              

Line 4 - TTL In1              

Line 5 - OPTO IN 1              

NAND 0 Out              

NAND 1 Out 1              

User Output 0              

User Output 1              

User Output 2              

User Output 3              

Line 10 - TTL IN 2              

Line 11 - LVDS IN              

Trigger

Source

Line Selector

Pulse

Generator

Selector

Frame Start

Line 1 - TTL OUT 1

Line 8 - TTL OUT 2

Line 2 OPTO OUT 1

Acquisition Start

Acquisition End

Pulse

Generator

Clear

Sour ce

Line Source

Line 9 - TTL OUT 3

NAND 1 In 1

NAND 1 In 2

NAND 2 In 1

NAND 2 In 2

Pulse Generator 0

Pulse Generator 1

Trigger

Selector

Acquisition Transfer Start

SP-20000M-USB / SP-20000C-USB

- 17 -

5.3.6.3 Associated GenICam Register information

GenICam

Name

Access

Values
