IBASE Technology CSB200-818 User manual

CSB200-818
Slim & Fanless SBC System
User’s Manual
Version 1.0a
(Feb. 2019)

ii
CSB200-818 User Manual
Copyright
©2019 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

CSB200-818 User Manual
iii
Compliance
This is a class B product. This product has passed CE tests for environmental
specifications and limits. This product is in accordance with the directives of the
Union European (EU). If users modify and/or install other devices in this equipment,
the CE conformity declaration may no longer apply.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS restrictions and
prohibits use of the following substances in concentrations exceeding
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by
weight (100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
CSB200-818 User Manual
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
•Lay the device horizontally on a stable and solid surface in case the device may
fall, causing serious damage.
•Leave plenty of space around the device and do not block the openings for
ventilation. NEVER DROP OR INSERT ANY OBJECTS OF ANY KIND INTO
THE VENTIILATION OPENINGS.
•Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the device for ventilation.
NEVER INSERT OBJECTS OF ANY KIND INTO THE VENTILATIN OPENINGS.
•Use this product in environments with ambient temperatures between -30˚C and
65˚C for SSD, and between -10˚C and 45˚C for HDD.
•DO NOT LEAVE THIS DEVICE IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -40˚C OR ABOVE 85˚C. This
could damage the device. The device must be used in a controlled environment.
Care for your IBASE products:
•Before cleaning the device, turn it off and unplug all cables such as power in case
a small amount of electrical current may still flow.
•Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
•Vacuum the dust with a computer vacuum cleaner to prevent the air vent or slots
from being clogged.
WARNING
Attention during use:
•Do not use this product near water.
•Do not spill water or any other liquids on your device.
•Do not place heavy objects on the top of the device.
•Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local
power company.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
Do not disassemble, repair or make any modification to the device. Disassembly,
modification, or any attempt at repair could generate hazards and cause damage to
the device, even bodily injury or property damage, and will void any warranty.

CSB200-818 User Manual
v
CAUTION
Danger of explosion if internal lithium-ion battery is replaced by an incorrect type.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, memory, HDD, power adapter, panel
and touchscreen.
＊PRODUCTS, HOWEVER, THAT FAILS DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any further assistance from your distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
•Product model name
•Product serial number
•Detailed description of the problem
•The error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi
CSB200-818 User Manual
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
WARNING ......................................................................................................iv
CAUTION ........................................................................................................v
Warranty Policy..............................................................................................v
Technical Support & Services ......................................................................v
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................2
1.3 Packing List ............................................................................................3
1.4 Optional Accessories ..............................................................................3
1.5 Specifications..........................................................................................4
1.6 Overview.................................................................................................6
1.7 Dimensions.............................................................................................7
Chapter 2 Hardware Configuration.........................................................8
2.1 Installation / Replacement.......................................................................9
2.1.1 Memory Installation / Replacement...........................................9
2.1.2 Mini PCIe Card Installation / Replacement..............................10
2.1.3 HDD/SSD Installation / Replacement......................................11
2.1.4 WiFi / 3G / 4G Antenna Installation.........................................11
2.1.5 Mounting Installation...............................................................12
2.2 Pinout for DC Power Input Connector...................................................12
2.3 Setting the Jumpers..............................................................................13
2.3.1 How to Set Jumpers ...............................................................13
2.4 Jumper & Connector Locations on Motherboard...................................14
2.5 Jumpers Quick Reference.....................................................................15
2.5.1 LVDS Panel Brightness Selection (JP1, JP4) .........................15
2.5.2 LVDS Panel Power Selection (JP2, JP3)................................15
2.5.3 LCD Panel Backlight VCC (JP5, JP6).....................................15
2.5.4 ATX / AT Power Selection (JP7).............................................16
2.5.5 Clearing CMOS Data (JP8).....................................................16
2.5.6 Clearing ME Register (JP9)....................................................16

CSB200-818 User Manual
vii
2.6 Connectors Quick Reference................................................................17
2.6.1 LCD Backlight Connector (J3, J6)...........................................17
2.6.2 LVDS Connector (CH1: J4, J5, CH2: J1, J2) ..........................18
2.6.3 Audio Connector (J7)..............................................................18
2.6.4 USB 2.0 Connector (J10)........................................................18
2.6.5 Amplifier Connector (J9).........................................................19
2.6.6 SATA HDD Power Connector (J12)........................................19
2.6.7 COM2 / COM3 / COM4 RS-232 Port (J18, J19, J14)..............19
2.6.8 Front Panel Connector (J16)...................................................19
2.6.9 Digital I/O Connector (J22) .....................................................20
2.6.10 DC Power Input (J21).............................................................20
2.6.11 COM1 RS-232/422/435 (CN10)..............................................20
Chapter 3 Driver Installation .................................................................21
3.1 Introduction...........................................................................................22
3.2 Intel®Chipset Software Installation Utility..............................................22
3.3 Intel®Graphics Driver Installation..........................................................24
3.4 HD Audio Driver Installation..................................................................25
3.5 Intel®Trusted Execution Engine Installation..........................................26
3.6 Intel®Serial I/O Drivers Installation .......................................................28
3.7 LAN Driver Installation ..........................................................................29
Chapter 4 BIOS Setup............................................................................31
4.1 Introduction...........................................................................................32
4.2 BIOS Setup...........................................................................................32
4.3 Main Settings........................................................................................33
4.4 Advanced Settings................................................................................34
4.4.1 ACPI Settings.........................................................................34
4.4.2 LFP (eDP) to LVDS Configuration ..........................................35
4.4.3 EFP (DP) to LVDS Configuration............................................36
4.4.4 Fintek Super IO Configuration ................................................37
4.4.5 Fintek Super I/O Hardware Monitor ........................................39
4.4.6 CPU Configuration..................................................................40
4.4.7 AMI Graphic Output Protocol Policy........................................41
4.4.8 Network Stack Configuration ..................................................42
4.4.9 CSM Configuration.................................................................43
4.4.10 USB Configuration..................................................................44
4.5 Chipset Settings....................................................................................45
4.5.1 North Bridge...........................................................................45
4.5.2 South Cluster Configuration....................................................46

viii
CSB200-818 User Manual
4.6 Security Settings...................................................................................50
4.7 Boot Settings.........................................................................................51
4.8 Save & Exit Settings..............................................................................52
Appendix ......................................................................................................53
A. I/O Port Address Map............................................................................54
B. Interrupt Request Lines (IRQ)...............................................................56
C. Watchdog Timer Configuration..............................................................57

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Specifications
•Overview
•Dimensions

2
CSB200-818 User Manual
1.1 Introduction
The CSB200-818 Is applicable to thin clients, smart industrial automation or
controller, and retail equipment. It is slim and fanless with an Intel®Atom™
E3930 / Pentium®N4200 / Celeron®N3350 processor. This system is built
with an easily removable HDD at the bottom and features rich peripheral ports
for data transmission or receiving. The power connector is a 3-pin terminal
block by default but a DC jack is available for option too.
1.2 Features
•Fanless system with IBASE IB818 3.5” disk-size SBC
•Onboard Intel®Atom™processors E3930 / Pentium®N4200 / Celeron®
N3350 Series
•Wide-range operating temperature from -30°C to 65°C
•12V DC power input
•Wall mount kit included

General Information
CSB200-818 User Manual
3
1
1.3 Packing List
Your product package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
purchased the product.
•CSB200-818 x 1
•Wall Mount Kit (2 brackets) x 1
•Screws for Wall Mount Kit x 4
•3-Pin Female Terminal Block x 1
(For power connector. If the optional DC Jack is used,
this terminal block will not be enclosed.)
•DVD Disk (including drivers) x 1
•Motherboard IB818 User’s Manual x 1
(You can download CSB200-818 User’s Manual from
our website.)
1.4 Optional Accessories
IBASE provide optional accessories as follows. Please contact us or your
dealer if you need any.
•Power Adapter
•Power Cord

4
CSB200-818 User Manual
1.5 Specifications
Product Name
CSB200-818
System
Motherboard
IB818F 3.5” disk-size SBC
Operating
System
•Windows 10 Enterprise (64-bit)
•Windows 10 IoT Core (64-bit)
•Linux Ubuntu
CPU
Intel®Atom™ DC Processor E3930 / Pentium®N4200 / Celeron®
N3350 Series
System Speed
Up to 2.5 GHz
Chipset
Integrated
Memory
1 x DDR3L-1866 SO-DIMM 4 GB, expandable to 8 GB
Graphics
Intel®SoC integrated Gen. 9
Super I/O
Fintek F81964D-I
Storage
1 x 2.5” HDD or SSD (removable from the bottom)
Audio Codec
Intel®SoC built-in HD audio controller
Realtek ALC283QHD codec with speaker amplifier
Network
Intel®I210IT / I211AT GbE LAN
Power Supply
60W power adaptor (Optional)
BIOS
AMI BIOS
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
Chassis
Aluminum & steel, black
Mounting
Desktop or wall mount (wall mount kit is included.)
Dimensions
(W x H x D)
172 x 53 x 111.6 mm (6.77” x 2.09” x 4.39”)
Net Weight
1.1 kg (2.43 lb)
Certificate
CE / LVD / FCC Class B
I/O Ports
DC Input
Terminal block for 12V DC-In (DC Jack type is optional.)
LAN
2 x RJ45 GbE LAN
USB
•4 x USB 3.0
•2 x USB 2.0
Serial
4 x COM ports:
•COM1 RS-232/422/485 port
•COM2, COM3, COM4 RS-232 ports

General Information
CSB200-818 User Manual
5
1
Display
1 x HDMI Port
Audio Jack
•1 x Microphone Input
•1 x Line-Out
SATA
2 x SATA III connector
Expansion
•1 x Mini PCIe slot (full-sized, with USB 2.0 and SATA)
•1 x Mini PCIe slot (half-sized, with USB 2.0)
Environment
Temperature
•Operating: (With air flow)
For N-Series CPU, with HDD: -10 ~ 45 °C (14 ~ 113 °F)
For E3930 CPU, with SSD: -30 ~ 65 °C (22 ~ 149 °F)
•Storage: -40~ 85 °C (-40 ~ 185 °F)
Relative
Humidity
5 ~ 90% at 45 °C (non-condensing)
Vibration
Protection
•Operating: 1.0 Grms / 5 ~ 500 Hz, random operation
•Non-operating: 2.0 Grms / 5 ~ 500Hz, ramdom operation
Shock
Protection
•Operating: 20 g / 11 ms
•Non-operating: 30 g / 11 ms
All specifications are subject to change without prior notice.

6
CSB200-818 User Manual
1.6 Overview
Front View
No.
Name
No.
Name
1
Power Button
5
USB 2.0 Ports
2
Reset Button
6
Audio Line-Out Jack
3
Power LED Indicator
7
Microphone Input Jack
4
HDD LED Indicator
8
Antenna Hole
Rear View
No.
Name
No.
Name
1
DC-In Power Connector
5
COM1 RS-232/422/485 Port
2
USB 3.0 Ports
6
COM2 ~ COM4 RS-232 Ports
3
GbE LAN Ports
7
Antenna Holes
4
HDMI Port
8

General Information
CSB200-818 User Manual
7
1
Oblique View
1.7 Dimensions
Unit: mm

8
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
•Installation / Replacement
•Information and locations of connectors

Hardware Configuration
CSB200-818 User Manual
9
2
2.1 Installation / Replacement
Before installations, you need to turn your device upside down and remove
the bottom chassis base by removing 6 screws as indicated below.
2.1.1 Memory Installation / Replacement
If you need to install or replace a memory module, you will have to remove the
interior plate carrying a small PCB with I/O module locating above the memory
slot as shown below. Follow the instructions to remove the plate.
1. Loosen the 3 screws to free up interior plate.
2. Take out the interior plate along with the small PCB and I/O module
carefully.
3. Align the key of your memory module with that on the memory slot and
insert the module slantwise.

10
CSB200-818 User Manual
4. Gently push the module in an upright position until the clips of the slot click
to hold the module in place when the module touches the bottom of the
slot.
.
To remove the module, press the clips outwards with your thumb and index
finger of both hands.
2.1.2 Mini PCIe Card Installation / Replacement
If you are using a model type of CSB200-818 that doesn’t include a mini-PCIe
card, follow the instructions below to install a mSATA card.
1. Loosen 6 screws to from the bottom chassis and remove it carefully.
2. Locate the half-size or full-size mini-PCIe slot.
3. Align the key of your mini PCIe card to the interface, and insert the card
slantwise.
4. Push the card down and fix it with the a screw..
5. Secure the bottom chassis back.

Hardware Configuration
CSB200-818 User Manual
11
2
2.1.3 HDD/SSD Installation / Replacement
1. Remove one screw as indicated below to remove the HDD/SSD plate.
2. Remove 4 screws to free the HDD/SSD from the plate.
3. Unplug all the SATA cables if a HDD/SSD is pre-installed.
4. Attach a new HDD/SSD and tighten these screws to fix the HDD/SSD.
Then connect the SATA cables.
5. Secure the plate along with the new HDD/SSD back to the system.
2.1.4 WiFi / 3G / 4G Antenna Installation
Thread the WiFi / 3G / 4G antenna extension cable through an antenna hole
of the front I/O cover and fasten the antenna as shown below. Then apply
adhesive to the edge of the hex nut behind the front I/O cover to prevent the
extension cable from falling if the cable becomes loose.
1. Thread and fasten the hex nut and the
washer. Then install the antenna.
2. Apply adhesive around here.
Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC).

12
CSB200-818 User Manual
2.1.5 Mounting Installation
Requirements
Before mounting the system, ensure that you have enough room for the power
adaptor and signal cable routing, and have good ventilation for the power
adaptor. The method of mounting must be able to support weight of the
product plus the weight of the suspending cables attached to the system. Use
the following methods for mounting your system:
Wall Mounting Installation
1. Attach the mounting kit (2 brackets) to the your product, and secure with
the supplied four screws as below.
2. Then prepare at least four screws (M3, 6 mm) to mount the device on
wall .
2.2 Pinout for DC Power Input Connector
•DC Power Input (terminal block)
Pin
Assigment
Pin
Assigment
1
GND
3
+12V
2
Chassis GND
1 3
