IBASE Technology IBT400 Series User manual

IBT400 Series
User Manual
2008 November V1.0

2
Copyright © 2008 IBASE Technology INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE”).
Products and corporate names mentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, the manufacturer makes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

3
Table of Contents
Accessories ........................................................................................................... 6
Components.......................................................................................................... 7
Front View ................................................................................................................... 7
Rear View (AMI400-9) ..................................................................................................8
Rear View (AMI400-8) ................................................................................................ 10
Specification ........................................................................................................12
Mounting AMI400 to the Wall..............................................................................13
Wall mounting requirements ...................................................................................... 13
Selecting the location ................................................................................................. 14
Exploded view of the AMI400 assembly – AMI400-9 .............................................15
Parts description ........................................................................................................ 16
Exploded view of the AMI400 assembly – AMI400-8 .............................................17
Parts Description........................................................................................................ 18
Driver Installation ................................................................................................19
BIOS Setup ...........................................................................................................19

4
Safety Information
Your AMI400-8/9 is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions.
Setting up your system
•Read and follow all instructions in the documentation before you operate your
system.
•Do not use this product near water.
•Set up the system on a stable surface or secure on wall with the provided rail. Do
not secure the system on any unstable plane or without the rail.
•Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
•Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
•This system should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
•Use this product in environments with ambient temperatures between 0˚C and
45˚C.
•If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
Care during use
•Do not walk on the power cord or allow anything to rest on it.
•Do not spill water or any other liquids on your system.
•When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
•If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.

5
The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users

6
Accessories
a. Power Cord x 1 b. M/B Manual x 1
c. Driver CD x 1 d. Power Brick x 1
e. Mounting Rail Screw x 6 f. Mounting Rail x 2

7
Components
Front View
Refer to the diagram below to identify the components on this side of the system.
PWR
The power LED illuminated when system been power on.
HDD
The hard disk LED blinks when data is being written into or read from the hard
disk drive.
RES
The reset switch allows reset the system.
ON/OFF
The power switch allows powering ON and OFF the system.
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral acting
as additional plug-in sites or hubs.

8
Rear View (AMI400-9)
Refer to the diagram below to identify the components on this side of the system.
M/S
The PS/2 mouse port is use to connect PS/2 mouse.
K/B
The PS/2 keyboard port is use to connect PS/2 compatible devices such as
keyboard, MSR and scanner.
COM1
Communication or serial port one is compatible with RS-232 interface.
VGA
Video Graphic Array (VGA) port supports a VGA-compatible device such as a
monitor or projector. The system default display output port.
LAN
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection
to a local network.

9
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral acting
as additional plug-in sites or hubs.
1394
IEEE 1394 interface connector.
DVI
The Digital Visual Interface (DVI) port supports a high quality VGA-compatible
device such as a monitor or projector to allow viewing on a larger external
display.
SPDIF
Plug a standard SPDIF optical audio cable into this connector for digital audio
transfer.
BASS/REAR/SIDE/LINE IN/FRONT/MIC
Analog audio output connector. Please refer M/B manual to connect analog audio
signal out to get stereo or 5.1 channels signal.
PCI SLOT
There is one 33MHz/32bit standard PCI slot for half size PCI card expansion.
DC IN
The supplied power adapter convertsAC power to DC power for use with this
jack. Power supplied through this jack supplies power to the system. To prevent
damage to the system, always use the supplied power adapter.

10
Rear View (AMI400-8)
Refer to the diagram below to identify the components on this side of the system.
M/S
The PS/2 mouse port is use to connect PS/2 mouse.
K/B
The PS/2 keyboard port is use to connect PS/2 compatible devices such as
keyboard, MSR and scanner.
S-VIDEO
Super Video is a Y/C analog video signal output port that carries luma and
chroma signals to any display which support this interface such as projector, TV.
TV-OUT
Composite Video port (RCA connector) is format of an analog television (picture
only) signal to any display which supports this interface such as projector, TV.
COM1
Communication or serial port one is compatible with RS-232 interface.
VGA
Video Graphic Array (VGA) port supports a VGA-compatible device such as a
monitor or projector. The system default display output port.

11
LAN
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection
to a local network.
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral acting
as additional plug-in sites or hubs.
1394
IEEE 1394 interface connector.
SPDIF
Plug a standard SPDIF optical audio cable into this connector for digital audio
transfer.
LINE IN
The stereo headphone jack (3.5mm) is used to connect the audio signal into
system to record or bypass it to storage or LINE OUT.
LINE OUT
The stereo audio jack (3.5mm) is used to connect the system’s audio out signal to
amplified speakers or headphones.
MIC
The microphone jack is designed to connect the microphone used for video
conferencing, voice narrations, or simple audio recordings.
PCI SLOT
There is one 33MHz/32bit standard PCI slot for half size PCI card expansion.
DC IN
The supplied power adapter convertsAC power to DC power for use with this
jack. Power supplied through this jack supplies power to the system. To prevent
damage to the system, always use the supplied power adapter.

12
Specification
System Mainboard MI910E / MB899EF
Construction Aluminum
Chassis Color Silver
Storage 2.5” 80GB SATA HDD x 1
Mounting Desktop or wall mount
Dimensions 226(W) x 109(H) x 263.5(D)mm
(8.9” x 4.29” x 10.37”)
Power Supply 150W DC adapter
Operating
Temperature
0°C ~ 45°C (32°F ~ 113°F)
Storage
Temperature
-20°C ~ 80°C
Relative Humidity 5~95% @45°C (non-condensing)
Vibration HDD: 0.25g/5~500Hz random operation
RoHS Available
‧This specification is subject to change without prior notice.

13
Mounting AMI400 to the Wall
Using attached mounting rail, you can install AMI400 on wood, drywall surface over
studs, or a solid concrete or metal plane. Ensure the installer uses at least four M4
length 8mm screws to secure the system on wall. Six M4 length 8mm screws are
recommended to secure the system on wall.
Fasteners are not included with the unit, and must be supplied by the installer. The
types of fasteners required are dependent on the type of wall construction. Choose
fasteners that are rated either ”Medium Duty“ or ”Heavy Duty.“ To assure proper
fastener selection and installation, follow the fastener manufacturer’s
recommendations.
Wall mounting requirements
Note: Before mounting the system on wall, ensure that you are following all
applicable building and electric codes.
When mounting, ensure that you have enough room for power and signal cable
routing. And have good ventilation for power adapter. The method of mounting must

14
be able to support weight of the AMI400 plus the suspend weight of all the cables to
be attached to the system. Use the following methods for mounting your system:
Mounting to hollow walls
Method 1: Wood surface – A minimum wood thickness – 38mm (1.5in.) by
25.4 cm (10in.) – of high, construction – grade wood is recommended.
Note: This method provides the most reliable attachment of the unit with
little risk that the unit will come loose or require ongoing maintenance.
Method 2: Drywall walls - Drywall over wood studs is acceptable.
Mounting to a solid concrete or brick wall - Mounts on a flat smooth surface.
Selecting the location
Plan the mounting location thoroughly. Locations such as walkway areas, hallways,
and crowded areas are not recommended. Mount the unit to a flat, sturdy,
structurally sound column or wall surface.
The best mounting surface is a standard countertop, cabinet, table, or other
structure that is minimally the width and length of the unit. This recommendation
reduces the risk that someone may accidentally walk into and damage the device.
Local laws governing the safety of individuals might require this type of
consideration.

15
Exploded view of the AMI400 assembly – AMI400-9
2
3
4
5
6
8
9
10
18
19
22
23
24
25
26
20
11
17
1
13
12
7
21
16
15
14

16
Parts description
Part NO. Description Part NO. Description
1 HDD 2 HDD Cover
3 Top chassis 4 Heat pipe
5 ID392 DVI board 6 MI910E
7 CPU FAN bracket 8 PCI Bracket
9 Rear panel 10 MI910E I/O Shield
11 DC extension cable 12 SATA signal cable
13 SATA power cable 14 Screws for SB heat sink
15 Screws for SB heat sink 16 Southbridge heat sink
17 ATX power extension cable 18 ID737
19 I D450 20 Control panel cable
21 USB extension cable 22 PCI Expansion Card Bracket
23 IP115 24 Front panel
25 Bottom chassis 26 Mounting rail

17
Exploded view of the AMI400 assembly – AMI400-8
5
3
4
2
7
8
9
22
21
20
19
18
15
14
11
12
1
13
10
6
17
16

18
Parts Description
Part NO. Description Part NO. Description
1 HDD 2 HDD Cover
3 Top chassis 4 Heat pipe
5 MB899EF 6 CPU FAN bracket
7 PCI Bracket 8 Rear panel
9 MB899EF I/O Shield 10 DC extension cable
11 SATA signal cable 12 SATA power cable
13 ATX power extension cable 14 ID737
15 I D450 16 Control panel cable
17 USB extension cable 18 PCI Expansion Card Bracket
19 IP115 20 Front panel
21 Bottom chassis 22 Mounting rail

19
Driver Installation
Please refer correspond mainboard user manual to install the driver properly.
BIOS Setup
Please refer correspond mainboard user manual to configure BIOS setting.
