IBASE Technology SI-06 Series User manual

SI-06 Series
User Manual

Revision
Release Date
V0.1
2013/04/11
V0.2
2014/09/23

3
Copyright © 2013 IBASE Technology INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE”).
Products and corporate namesmentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, themanufacturermakes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

4
Table of Contents
Setting up your system ........................................................................................................5
Care during use....................................................................................................................6
Acknowledgments ...............................................................................................................7
Table: Terms and Abbreviation............................................................................................7
Accessories............................................................................................................. 8
Components ........................................................................................................... 8
I/O View...............................................................................................................................8
System Specification..............................................................................................10
Mechanical Specification .......................................................................................11
SI-06 Mounting Bracket Solution.......................................................................................12
SI-06 VESA Mounting Solution...........................................................................................13
Exploded View of the SI-06 Assembly...............................................................................14
Parts Description................................................................................................................14
Installation............................................................................................................14
Installing the memory........................................................................................................15
Jumper Locations on IB901................................................................................................16
Connector Locations on IB901...........................................................................................17
BIOS Setup ............................................................................................................20
Drivers Installation ................................................................................................35
Appendix...............................................................................................................39

5
Safety Information
Your SI-06 is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions.
Setting up your system
Read and follow all instructions in the documentation before you operate your
system.
Do not use this product near water.
Set up the system on a stable surface. Do not secure the system on any unstable
plane.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
This system should be operated from the type ofpower indicated on themarking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
Use this product in environments with ambient temperatures between 0˚C and
45˚C.
If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENTWHERE
THESTORAGE TEMPERATURE MAY GO BELOW -20°C (-4°F) OR ABOVE
80°C (176°F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.

6
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.
The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by themanufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY

7
Acknowledgments
AMI is a registered trademark ofAMI Software International, Inc.
Intel are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
FINTEK is a registered trademark of FINTEK Electronics Corporation.
REALTEK is a registered trademark of REALTEK Electronics Corporation.
All other product names or trademarks are properties of their respective owners.
Table: Terms and Abbreviation

8
Accessories
Components
I/O View
Refer to the diagram below to identify the components on this side of the system.

9
Power Button
The power switch allows powering ON and OFF the system.
HDD
The hard disk LED blinks when data is being written into or read from the hard
disk.
Power
The power bottom LED illuminated when system been power on.
DVI-I Port
The DVI-I interface is to transmitting uncompressed digital data.
LAN 1
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection
to a local network.
USB1/2
The USB (Universal Serial Bus 2.0) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral acting
as additional plug-in sites or hubs.
COM 1
Communication or serial port is compatible with RJ 45 interface without RI (ring
indicator) signal.
AUDIO
The stereo audio jack (3.5mm) is used to connect the system’s audio out signal to
amplified speakers or headphones.
DC-IN 12 V
The supplied power adapter convertsAC power to DC power for use with this
jack. Power supplied through this jack supplies power to the system. To prevent
damage to the system, always use the supplied power adapter.

10
System Specifications
‧ This specification is subject to change without prior notice.

11
Mechanical Specification

12
SI-06 Mounting Bracket Solution
SI-06 mounting bracket (IBASE) part number: SC2SIMK1---0A1100P
Install SI-06 to the mounting bracket using 4 screws, as shown in the picture.

13
SI-06 VESA Mounting Solution
You can install SI-06 on plastic (LCD monitor), wood, drywall surface over studs, or
a solid concrete or metal plane directly. Ensure the installer uses at least four M3
length 6mm screws to secure the system on wall. Six M3 length 6mm screws are
recommended to secure the system on wall.

14
Exploded View of the SI-06 Assembly
Parts Description
Part No.
Description
Part No.
Description
1
Top cover
2
Main chassis
3
Rear panel
4
SI-06 MB
5
HDD holder
6
2.5”HDD
7
Brackets
Installation

15
Installing the memory
The IB901 board supports two DDR3 memory socket for a maximum total memory of
16GB in DDR3 SO-DIMMmemory type. Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and perform the
following steps:
1. Hold the DDR3 module so that the key of the DDR3 module aligns with that on
the memory slot. Insert the module into the socket at a slight angle
(approximately 30 degrees). Note that the socket and module are both keyed,
which means that the module can be installed only in one direction.
2. To seat the memory module into the socket, apply firm and even pressure to
each end of the module until you feel it slip down into the socket.
3. With the module properly seated in the socket, rotate the module downward.
Continue pressing downward until the clips at each end lock into position.
4. To remove the DDR3 module, press the clips with both hands.

16
Setting the Jumpers
The following lists the connectors on IB901 and their respective functions.
Jumper Locations on IB901

17
J3: Clear CMOS Contents
J3
Setting
Function
Pin 1-2
Short/Closed
Normal
Pin 2-3
Short/Closed
Clear CMOS
Connector Locations on IB901
Top Side
Bottom Side

18
SW1: Power Switch
CN1: 3G SIM Card Slot
CN2: SATA 2.5” HDD/SSD Connector
CN4: Gigabit LAN Connector (Realtek RTL8111E)
This RJ45 LAN connector features LAN wakeup.
CN5: COM Serial Port
CN5
Pin #
Signal Name
1
DSR, Data set ready
2
GND, ground
3
GND, ground
4
TXD, Transmit data
5
RXD, Receive data
6
DCD, Data carrier detect
7
DTR, Data terminal ready
8
CTS, Clear to send
9
RTS, Request to send
10
RI, Ring indicator
CN6: USB2.0 Connector
CN7: Audio Connector (Headphone out)

19
CN8: DVI-I Connector
CRT via DVI-I connector
Signal Name
Pin #
Pin #
Signal Name
DATA 2-
1
16
HOT POWER
DATA 2+
2
17
DATA 0-
Shield 2/4
3
18
DATA 0+
DATA 4-
4
19
SHIELD 0/5
DATA 4+
5
20
DATA 5-
DDC CLOCK
6
21
DATA 5+
DDC DATA
7
22
SHIELD CLK
VSYNC
8
23
CLOCK-
DATA 1-
9
24
CLOCK +
DATA 1+
10
C1
Red.
SHIELD 1/3
11
C2
Green
DATA 3-
12
C3
Blue
DATA 3+
13
C4
HSYNC
DDC POWER
14
C5
Ground
AGROUND 1
15
C6
Ground
J2: SPI Flash (Factory use only)
J4: DDR3 SO-DIMM Socket
J6: Mini PCIE Connector
Supports mSATA and 3G SIM card
J7: SATA PWR Connector
J9: +12V DC-IN Connector

20
BIOS Setup
BIOS Introduction
The BIOS (Basic Input/Output System) installed in your computer system’s ROM
supports Intel processors. The BIOS provides critical low-level support for a standard
device such as disk drives, serial ports and parallel ports. It also password protection
as well as special support for detailed fine-tuning of the chipset controlling the entire
system.
BIOS Setup
The BIOS provides a Setup utility program for specifying the system configurations
and settings. The BIOS ROM of the system stores the Setup utility. When you turn on
the computer, the BIOS is immediately activated. Pressing the <Del> key immediately
allows you to enter the Setup utility. If you are a little bit late pressing the <Del> key,
POST (Power On Self Test) will continue with its test routines, thus preventing you
from invoking the Setup. If you still wish to enter Setup, restart the system by pressing
the ”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys.
You can also restart by turning the system Off and back On again. The following
message will appear on the screen:
Press <DEL> to Enter Setup
In general, you press the arrow keys to highlight items, <Enter> to select, the <PgUp>
and <PgDn> keys to change entries, <F1> for help and <Esc> to quit.
When you enter the Setup utility, the Main Menu screen will appear on the screen.
The Main Menu allows you to select from various setup functions and exit choices.
Warning:
It is strongly recommended that you avoid making any changes to the
chipset defaults. These defaults have been carefully chosen by both
AMI and your system manufacturer to provide the absolute maximum
performance and reliability. Changing the defaults could cause the
system to become unstable and crash in some cases.
System Date
Set the Date. Use Tab to switch between Data elements.
System Time
Set the Time. Use Tab to switch between Data elements.
