SI-60E User Manual
SI-60E
User Manual

2
Revision
Release Date
V1.0
2015/06/23
V1.1
2015/09/08
V1.2
2015/10/20
V1.3
2016/04/26
V1.4
2017/08/04

3
Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE ”).
Products and corporate names mentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, the manufacturer makes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

4
Table of Contents
Setting up your system........................................................................................................... 5
Care during use ....................................................................................................................... 6
Acknowledgments................................................................................................................... 7
CHAPTER 1 INTRODUCTION ................................................................................... 8
1.1 General Description .......................................................................................................... 8
1.2 System Specifications ...................................................................................................... 9
1.2.1 Hardware Specifications................................................................................................ 9
1.2.2 Dimensions ................................................................................................................... 10
1.2.3 I/O View...........................................................................................................................11
1.3 Exploded View of the SI-60E Assembly ........................................................................ 12
1.3.1 Parts Description.......................................................................................................... 13
1.4 Packing List...................................................................................................................... 14
1.4.1 Optional Items module................................................................................................. 14
1.5 HARDWARE INSTALLATION .......................................................................................... 15
1.5.1 Mounting Installation.................................................................................................... 15
1.5.2 Installing the storage.................................................................................................... 16
1.5.3 Installing the Rackmount........................................................................................... 167
CHAPTER 2 MOTHERBOARD INTRODUCTION ........................................................18
2.1 Introduction...................................................................................................................... 18
2.2 Installations...................................................................................................................... 20
2.2.1 Installing the Memory................................................................................................... 20
2.3 Setting the Jumpers........................................................................................................ 21
2.4 Connectors on MBD60E.................................................................................................. 23
CHAPTER 3 BIOS SETUP ........................................................................................29
3.1 BIOS Introduction............................................................................................................ 29
3.2 BIOS Setup....................................................................................................................... 29
CHAPTER 4 DRIVERS INSTALLATION ......................................................................53
4.1 Intel Chipset Software Installation Utility...................................................................... 53
4.2 AMD Radeon E8860 Graphics Driver............................................................................. 56
4.3 Realtek High Definition Audio Driver............................................................................. 60
4.4 Intel® I21x Gigabit Network Driver ................................................................................ 62
4.5 Intel® Management Engine(ME) Driver ......................................................................... 66
4.6 Intel® USB 3.0 eXtensible Host Controller Driver........................................................ 69
4.7 Realtek RTL8111G LAN Driver........................................................................................ 72
4.8 IDD100 Driver and Utility................................................................................................. 74
Appendix .............................................................................................................79
A. IBASE Display Matrix........................................................................................................ 79
B. IBASE Multiple-Display Matrix Technology Utility for Video Wall Display configuration
setting……………………………………………………………......................................…...82
C. IDD100 LED Indicator Description................................................................................. 103
D. I/O Port Address Map...................................................................................................... 104
E. Interrupt Request Lines (IRQ)........................................................................................ 105
F. Watchdog Timer Configuration...................................................................................... 106

5
Safety Information
Your SI-60E is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions
Setting up your system
•Read and follow all instructions in the documentation before you operate your
system.
•Do not use this product near water.
•Set up the system on a stable surface. Do not secure the system on any unstable
plane.
•Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
•Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
•This system should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
•Use this product in environments with ambient temperatures between 0˚C and
45˚C.
•If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
•DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20°C (-4°F) OR ABOVE 80°C
(176°F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.

6
Care during use
•Do not walk on the power cord or allow anything to rest on it.
•Do not spill water or any other liquids on your system.
•When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
•If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
➢The power cord or plug is damaged.
➢Liquid has been spilled into the system.
➢The system does not function properly even if you follow the operating
instructions.
➢The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY

7
Acknowledgments
•AMI is a registered trademark of AMI Software International, Inc.
•AMD and ATI are registered trademarks of AMD Corporation.
•Intel, Pentium, and Intel Core are registered trademarks or trademarks of
Intel Corporation.
•Microsoft Windows is a registered trademark of Microsoft Corporation.
•FINTEK is a registered trademark of FINTEK Electronics Corporation.
•REALTEK is a registered trademark of REALTEK Electronics Corporation.
•All other product names or trademarks are properties of their respective
owners.

8
•
CHAPTER 1 INTRODUCTION
1.1 General Description
The “Signature Book™” SI-60E is a professional digital signage system powered
by 4th Gen. Intel®CoreTM I Desktop Processors with AMD Radeon™ E8860 graphics.
The SI-60E integrates 12 HDMI ports with EDID emulation function and one DVI-I for
console use. Additionally, SI-60E has two quad-channel DDR3L-1600 sockets to
provide up to 32GB of memory. It also has dual Gigabit Ethernet, dual extended SSD
drive, Intel AMT for remote control and IBASE’s iSMART green technology for power
on/off scheduling and power resume functions. The ruggedized design player’s
chassis that provides passive cooling for better system reliability and quiet operation.
SI-60E overview

9
1.2 System Specifications
1.2.1 Hardware Specifications
Model Name
SI-60E
System Mainboard
MBD60E
CPU
4th Generation Intel® Core™ i7/i5/i3 and Pentium® QC/DC
processors; Up to 3.5GHz
Memory
4x DDR3 1600 MHz, Max. 32GB
I/O Interface
12x HDMI with EDID emulation function
1x DVI-I for console
4x USB 3.0 ports
2x RJ45 for Gigabit LAN
1x DSUB 9 pin for RS-232/422/485
3x Microjack audio connectors for Line-in / Line-out/MIC-in
Power LED for power on/off & HDD
1x power button
1x AC power inlet
Storage
1x mSATA
2x SATA 3.0 2.5” HDD Dock (support Raid 1)
Expansion Slots
Dual mPCI-E(x1) slots for WiFi, 3G/LTE, capture card and TV
tuner options
Construction
SGCC
Mounting
Standard system bracket
Dimensions
412mm(W) x 310mm(D) x 47mm(H)
16.22”(W) x 12.2”(D) x 1.85”(H)
Operating
Temperature
0°C~ 45°C (32°F~113°F)
Storage
Temperature
-20°C ~ 80°C (-4°F~176°F)
Relative Humidity
5~90% @ 45°C, (non-condensing)
Vibration
mSATA: 5 grms / 5~500Hz / random operation
RoHS
Available
Certification
CE, FCC, CCC, UL
‧ This specification is subject to change without prior notice.

10
1.2.2 Dimensions

11
1.2.3 I/O View
SI-60E front side
SI-60E rear side

12
1.3 Exploded View of the SI-60E Assembly

13
1.3.1 Parts Description
Part No.
Description
Part No.
Description
1
SI-60E_BASE
2
4028_fan
3
HDMI Board Module
4
Power module
5
SI-60E Main Board
6
SI-60E_HDD-TRAY
7
SI-60E_HDD-BRK
8
Screw F Type M3*0.5
9
SATA Cable
10
2.5" SATA HDD
11
M3 nut
12
M3 double screw bolt
13
SI-60E_top-cover_L
14
SI-60E_top-cover_r
15
Screw PW Type M3*0.5
16
M3 screw
17
Screw F Type M3*0.5 BK

14
1.4 Packing List
Description
Qty
Driver CD
1
Power cord
1
1.4.1 Optional Items module
WiFi Solution
Description
WiFi module
Wireless; PCI-E Mini Card 802.11B/G/N [AW-NE238H]
(A008WLAWNE238H000P)
External Antenna 2pcs
WiFi Antenna (A055RFA02C2M20800P)
Internal cable 1pcs
Internal Antenna 300mm [BTC130-1-70B-300] RoHS
(A055RFA0000020100P)
Internal cable 1pcs
Internal Antenna 200mm [BTC130-1-70B-200-1] RoHS
(A055RFA0000020000P)
Screw, 2pcs
Screw; A44-N NI 3.4 NYLOK M2*L3.8 P0.4mm [LHS]
RoHS (H02203A0442200N00P)
Bracket, -1set
MPCIE-EXT V-B2 Bracket (SC2MPCIEEXT0B2100P)
3G Solution
Description
3G
Wireless; 3.75G UMTS/HSPA [ZU202] RoHS
(A008WIRELESS00520P)
3G+GPS
Wireless; 3.75G UMTS/HSPA & GPS Module
[ZU200] RoHS (A008WIRELESS00510P)
WW-350U
Wireless; 3.75G UMTS/HSPA [NAVISYS WW-350U]
RoHS (A008WIRELESS00530P)
Cable
Cable; SMA IPX Cable For 3G 30CM [RF11030A]
RoHS (A012INTENAL010000P)
Antenna
3G [ANT0921Q2P] RoHS (A055ANT0921Q2P000P)

15
1.5 HARDWARE INSTALLATION
1.5.1 Mounting Installation
1. Please install SI-60E to its intended location using 4x M4*0.7*6L screws, as shown
in the picture.

16
1.5.2 Installing the storage
1. Remove the two screws on the HDD cover and draw the HDD out.
2. Install the HDD/SSD to the HDD bracket with 4 screws.

17
1.5.3 Installing the Rackmount
1. Please install SI-60E to its intended location using 12x M3 screws, as shown in the

18
CHAPTER 2 MOTHERBOARD INTRODUCTION
2.1 Introduction
MBD60E Jumpers and Connectors

19
MBD60E Board Dimensions

20
2.2 Installations
2.2.1 Installing the Memory
The MBD60E board supports four DDR3 memory modules for a maximum total of
32GB in DDR3 SODIMM memory type.
Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and perform the
following steps:
1.Hold the DDR3 module so that the key of the DDR3 module aligned with that on the
memory slot.
2.Gently push the DDR3 module in an upright position until the clips of the slot close
to hold the DDR3 module in place when the DDR3 module touches the bottom of
the slot.
3.To remove the DDR3 module, press the clips with both hands.
