IBASE Technology SI-32-N Series User manual

SI-32-N User Manual
SI-32-N Series
User Manual

ii
SI-32-N User Manual
Revision
Release Date
V0.1
2014/09/01

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
iii
IBASE Technology Inc.
Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
No part of thismanual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by anymeans, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE ”).
Products and corporate namesmentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of thismanual are correct and
up to date. However, themanufacturermakes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

iv
SI-32-N User Manual
Table of Contents
Setting up your system......................................................................................................v
Care during use .................................................................................................................vi
Acknowledgments............................................................................................................vii
CHAPTER 1 INTRODUCTION .................................................................................... 1
1.1 General Description......................................................................................................1
1.2 System Specifications..................................................................................................2
1.2.2 Dimensions ................................................................................................................3
1.2.3 I/O View.......................................................................................................................4
1.3 Exploded View of the SI-32-N Assembly.....................................................................5
1.3.1 Parts Description.......................................................................................................5
1.4 Packing List ..................................................................................................................6
1.4.1 Optional Items............................................................................................................6
1.5 HARDWARE INSTALLATION........................................................................................7
1.5.1 Installing the optional Wireless Module...................................................................7
1.5.2 Installing Storage.......................................................................................................9
CHAPTER 2 MOTHERBOARD INTRODUCTION .........................................................11
2.1 Introduction.................................................................................................................11
2.2 Installations.................................................................................................................13
2.2.1 Installing the Memory..............................................................................................13
2.3 Setting the Jumpers ...................................................................................................14
2.4 Connectors on IB939..................................................................................................15
CHAPTER 3 BIOS SETUP .........................................................................................19
CHAPTER 4 DRIVERS INSTALLATION .......................................................................33
4.1 VGADrivers Installation.............................................................................................33
4.2 Audio Driver Installation ............................................................................................37
4.3 LAN Drivers Installation.............................................................................................38
Appendix...............................................................................................................40
Mounting SI-32-N to the Wall ...........................................................................................40
Wall Mounting Requirements ..........................................................................................41
Selecting the Location .....................................................................................................41
Mounting SI-32-N to the Wall ...........................................................................................41
SI-32-N Mounting Bracket Solution.................................................................................42

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
v
IBASE Technology Inc.
Safety Information
Your SI-32-N is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions
Setting up your system
Read and follow all instructions in the documentation before you operate your
system.
Do not use this product near water.
Set up the system on a stable surface. Do not secure the system on any unstable
plane.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
This system should be operated from the type of power indicated on themarking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
Use this product in environments with ambient temperatures between 0˚C and
45˚C.
If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20°C (-4°F) OR ABOVE 80°C
(176°F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.

vi
SI-32-N User Manual
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.
The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by themanufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
vii
IBASE Technology Inc.
Acknowledgments
AMI is a registered trademark of AMI Software International, Inc.
AMD and ATI are registered trademarks of AMD Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
FINTEK is a registered trademark of FINTEK Electronics Corporation.
REALTEK is a registered trademark of REALTEK Electronics Corporation.
All other product names or trademarks are properties of their respective
owners.

1
SI-32-N User Manual
CHAPTER 1 INTRODUCTION
1.1 General Description
The “Signature Book™” SI-32-N is a professional fanless digital signage system
powered by the AMD Embedded high performance R-Series Quad-Core R-452L
(1.6/2.4GHz) APU. Clients can have flexible video wall display configuration support
from AMD Eyefinity function. The slim-design player comes with a chassis that
provides passive cooling for better system reliability and quiet operation.
SI-32-N

2
SI-32-N User Manual
1.2 System Specifications
1.2.1 Hardware Specifications
Model Name
SI-32-N
System Mainboard
IB939-45
CPU
AMDR-452L Quad-Core (1.6/2.4GHz)APU
Memory
2 x DDR3 1600MHz SO-DIMM Memory, Max. 8GB
I/O Interface
1 x Hybrid-DVI (VGA/DVI/HDMI with audio)
1 x Dual-link DVI-I
3 x USB 3.0 ports
2 x RJ45 for LAN
1 x RJ45 for RS232
2 x Microjack audio connectors for Line-in/Line-out
Power LED/HDD LED & power on/off button
1 xATX 4-pin Power jack connector
Storage
1 x open frame SSD
1 x mSATA
Expansion Slots
1 x mSATA/mPCIe(x1) Full size
1 x mPCIe(x1) Half size
For WIFI, Bluetooth, 3G or TV Tuner options
Power Supply
+ 12V~24V DC-in
Construction
Aluminum + SGCC
Mounting
Slim design with wall mounting holes
Dimensions
218 mm(W) x 140 mm(D) x 35mm(H)
Operating
Temperature
0°C~ 45°C (32°F~113°F)
Storage
Temperature
-20°~ 80°C (-4°F~176°F)
Relative Humidity
5~90% @ 45°C, (non-condensing)
Vibration
SSD: 5 grms / 5~500Hz / random operation
HDD: 0.25 grms / 5~500Hz / random operation
RoHS
Available
Certification
CE, FCC, UL, CCC
‧ This specification is subject to change without prior notice.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
3
IBASE Technology Inc.
1.2.2 Dimensions

4
SI-32-N User Manual
1.2.3 I/O View
Item
Connector
Item
Connector
1
ATX 4pin Power Jack
5
2 x RJ45 for Gigabit LAN
2
Power On/off button
6
2 x DVI-I
3
COM port
7
Line-in / Line-out
4
3 x USB 3.0 ports (Vertical type)

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
5
IBASE Technology Inc.
1.3 Exploded View of the SI-32-N Assembly
1.3.1 Parts Description
Part No.
Description
Part No.
Description
1
IB939 main board
2
SI-32-N Heat sink
3
SI-32-N Base
4
SI-32-N rear bracket
5
SI-32-N wall mount bracket
6
SI-32-N SSD bracket
7
mSATA
8
N/A
9
Battery
10
SI-32-N battery bracket

6
SI-32-N User Manual
1.4 Packing List
Item No.
Description
Qty
1
Driver CD
1
2
Power adaptor
1
3
Power Cord
1
1.4.1 Optional Items
WiFi Solution
Description
QCOM WiFi module
Wireless; PCI-E Mini Card 802.11B/G/N
[AW-NE238H] (A008WLAWNE238H000P)
External Antenna-2pcs
WiFi Antenna (A055RFA02C2M20800P)
Internal cable-2pcs
Internal Antenna, 100mm [BTC130-1-70B-200-1]
RoHS (A055RFA0000020000P)
3G Solution
Description
ZU 202
Wireless; 3.75G UMTS/HSPA [ZU202] RoHS
(A008WIRELESS00520P)
ZU 200
Wireless; 3.75G UMTS/HSPA & GPS Module
[ZU200] RoHS (A008WIRELESS00510P)
Cable
Cable; Antenna-2 30CM P 2pcs
(C501ANT0200300000P)
Antenna
Antenna; 3G, P, 2pcs (A055ANT0921Q2P000P)
COM Port Cable
Description
EXT-311
Cable; EXT-311 2-HD 10C 150CM; DSUB-9F =>
RJ45-10M RoHS (C501EXT3110A12000P)
EXT-312
Cable; EXT-312 2-HD 10C 150CM; DSUB-9M =>
RJ45-10M RoHS (C501EXT3120A12000P)

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
7
IBASE Technology Inc.
1.5 HARDWARE INSTALLATION
1.5.1 Installing the optional Wireless Module
1. Remove the 13 screws on the sides that are used to secure the cover to the
chassis. Once all the screws are removed, from the side, push the cover forward to
remove it.

8
SI-32-N User Manual
2. Push the WIFI module into the slot. Screwtwo screws to secure themodule into the
slot.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
9
IBASE Technology Inc.
1.5.2 Installing Storage
1. Remove the 13 screws on the sides that are used to secure the cover to the
chassis. Once all the screws are removed, from the side, push the cover forward to
remove it.

10
SI-32-N User Manual
2. First, put the thermal pad and push the module into the slot. Screw two screws to
secure the module into the slot.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
11
IBASE Technology Inc.
CHAPTER 2 MOTHERBOARD INTRODUCTION
2.1 Introduction
The IB939 is a custom sized SBC with dimensions of 210mm x 105 mm. It
supports theAMD® eTrinity processor with 2.4GHz speed with 4MB of L2 cache.
With theAMD® eTrinity integrated memory controller, the board’s two DDRIII
(1600MHz) SODIMM accept up to 8GB of system memory.
IB939 Mainboard
CPU
Model
AMD® 32nm QC APU
R-452L (1.6/2.4 GHz) 2MBx2
Speed
R-452L (1.6/2.4 GHz)
Cache
2MBx2
Socket
837mm*2; 827-BGA
TDP
R-452L (19W)
Chipset
Model
AMD A70M; 7.4W
FCBGA-656 Package (24.5 x 24.5 mm)
BIOS
Model
AMI BIOS, support ACPI Function
Memory
Configuration
2 X 2GB (4GB)
Max. Support
AMD® integrated memory controller
DDRIII 1600 MHz Dual Channel
-SO-DIMM x 2 (w/o ECC), Max. 8GB
Edge I/O
Display
AMD® QC APU Fusion IGX (480 Core @ 650 MHz)
Dual Link DVI-I (Connector #1)
Dual-Link DVI (DP3 + DP4)
VGA (DP0 via iTE6512 Display Port to CRT
converter)
Hybrid DVI-I (Connector #2)
HDMI (DP2)
VGA (DP1 via A70M FCH integrated CRT
translator)
LAN / PHY
2 x RJ45 for Gigabit LAN
Audio
2 x Microjack Audio connectors for Line-in / Line-out
USB
3 x USB 3.0 ports
SATA / eSATA
Same as SI-38
1 x SATA 3.0 2.5” open frame SSD.
1 x SATA 3.0 header

12
SI-32-N User Manual
LPC I / O
NCT6106
COM1 (RS232) (RJ45 same as original IB938)
Monitor (2 thermal inputs, 2 voltage monitor inputs
COM 2/3 with pin-9 with power for 2 ports (500 mA each
port)
Expansion slot
1x mPCIe(x1) 26.8 mm
1x mPCIe(x1) 51 mm (mPCIe & mSATA)
Digital IO
4 in & 4 out
Internal I/O
Audio
Header for speaker out (w/ amplifier)
USB
2x 10-pin header for two USB 2.0 Do Not Populate For Si
System
Serial ATA
1x 10-pin header; Do Not Populate For Si System
Expansion Slot
1 x mPCIe(x1) 26.8 mm; 1 x mPCIe(x1) 51 mm (mPCIe &
mSATA)
Add-On Features
Watchdog, H/W monitoring, iSMART, LAN Wakeup
Dimensions
PCB
Dimensions
-105mm x 205mm
Power
Power
-12~24V DC in(+-10%)
