IBASE Technology MB886 User manual

MB886
Socket LGA775 Pentium®4
Intel®945G Chipset
Industrial Motherboard
USER’S MANUAL
Version 1.1

Acknowledgments
Award is a registered trademark of Award Software International,
Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Pentium 4 are registered trademarks of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of their
respective owners.

MB886 User’s Manual iii
Table of Contents
Introduction.......................................................1
Checklist..............................................................................1
Product Description.............................................................2
Specifications......................................................................3
Board Dimensions...............................................................4
Installations.......................................................5
Installing the CPU...............................................................6
ATX Power Installation ......................................................7
Installing the Memory.........................................................7
Setting the Jumpers .............................................................8
Connectors on MB886 ......................................................11
Watchdog Timer Configuration........................................22
BIOS Setup.......................................................27
Drivers Installation......................................49
Intel 945G Chipset Software Installation Utility...............50
Intel 945G Chipset Graphics Driver..................................52
Realtek Codec Audio Driver Installation..........................53
Intel LAN Drivers Installation ..........................................54
Appendix...........................................................55
A. I/O Port Address Map...................................................55
B. Interrupt Request Lines (IRQ)......................................56

iv MB886 User’s Manual
This page is intentionally left blank.

INTRODUCTION
MB886 User’s Manual 1
Introduction
Checklist
Your MB886 Pentium®4 motherboard package should include the items
listed below:
•The MB886 motherboard
•This User’s manual
•1 Back I/O shield
•1 IDE cable
•1 Floppy cable
•1 SATA cable
•1 Serial-Port cable
•1 CD containing the following:
•Chipset Drivers
•Flash Memory Utility

INSTALLATIONS
2MB886 User’s Manual
Product Description
The MB886 LGA 775 Pentium®4 motherboard incorporates the Intel
945G chipset that can utilize a single LGA775 processor of up to
4.0GHz or higher and supports FSB frequency of 533/800/1066Mhz
(133MHz(533MT/s), 200MHz(800MT/s) and 266MHz(1066MT/s)
HCLK respectively. MB886 supports Intel® Core™2 Duo processors,
Pentium® D dual core CPU and Pentium® 4 single core CPU. It also
supports EMT64 processors.
MB886 has four DDR2 memory sockets to support DDR2 400/533/667
SDRAM DIMM modules of up to 4GB in capacity. The board is
designed with one Intel 82573L PCI Express Gigabit LAN single
controllers. Four Serial ATA connectors offer 3 Gb/s data throughput
speed - faster than the most advanced parallel ATA.
Expansion is provided by four PCI slots, two PCI Express x1 and one
PCI Express x16. Other advanced features include eight USB 2.0 ports,
IrDA interface, digital I/O, four serial ports, watchdog timer and audio
function. Dimensions of the board are 12” by 9.5” in an ATX form
factor.

INTRODUCTION
MB886 User’s Manual 3
Specifications
MB886
Socket LGA775 Pentium®4 ATX Motherboard w/ Intel®945G Chipset
Features Supports Intel® Core™2 Duo,Pentium®4 / Celeron®D processors
Up to 3.8GHz+, 533MHz/800MHz/1066MHz FSB
DDR2 DIMM x 4, max. 4GB
ICH7 10/100 and Intel PCI Express Gigabit Ethernet
Integrated Intel®945G VGA, CRT support
4 x SATA II, 8 x USB 2.0, 4 x COM, Watchdog timer, Digital I/O
4 x PCI, 1 x ISA, 2 x PCI Express (x1), 1 x PCI Express (x16) slots
System
CPU Socket LGA775 for Intel® Core™2 Duo, Pentium
®
4 / Celeron
®
D,
up to 3.8GHz+
System Memory DDRII DIMM x 4, max. 4GB, 533/667MHz
System Chipset Intel
®
945G + ICH7, 533MHz/800MHz/1066MHz FSB
BIOS Award 4Mbit
Watchdog Timer 256 levels
SSD NA
H/W Monitor Yes
Expansion Slot 4 PCI, 2 PCI Express (x1), 1 PCI Express (x16), 1 ISA
Graphics
VGA Controller Intel
®
945G integrated
VGA Memory Shared memory
Max. 224MB
LCD Interface N/A
Ethernet
Controller ICH7 integrated with 82562ET PHY 10/100 and Intel 82573L
PCI Express Gigabit LAN
Connector Two RJ-45 on board
Multi I/O
Chipset ICH7, Winbond 83627EHF, Fintek F81216
1x IDE (UDMA33/66/100), 1x FDD, 1x KB, 1x Mouse
4x RS-232, 4x SATA II (300MB/s)
USB 4 ports on board
Pin header for 4 ports (USB 2.0)
Audio Built-in audio + AC97 codec
Others IrDA, 4-in/4-out digital I/O
Mechanical and Environmental
Dimensions 305mm x 244mm (12“ x 9.6“)
Max. Power Requirement TBC
Operating Temperature 0°C~60°C (32°F~140°F)
Storage Temperature -20°C~80°C (-68°F~176°F)
Relative Humidity 10%~90% (non-condensing)
Remarks: MB886 supports Intel® Core™2 Duo processors, Pentium®
D dual core CPU and Pentium® 4 single core CPU. It also supports
EMT64 processors.

INSTALLATIONS
Board Dimensions
4MB886 User’s Manual

INSTALLATIONS
MB886 User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the MB886 in order to set up a workable system. The
topics covered are:
Installing the CPU........................................................................ 6
ATX Power Installation............................................................... 7
Installing the Memory.................................................................. 7
Setting the Jumpers...................................................................... 8
Connectors on MB886............................................................... 11
Watchdog Timer Configuration................................................. 22

INSTALLATIONS
Installing the CPU
The MB886 motherboard supports an LGA 775 processor socket for
Intel® Pentium® 4 processors.
The LGA 775 processor socket comes with a lever to secure the
processor. Refer to the pictures below, from left to right, on how to place
the processor into the CPU socket. Please note that the cover of the
LGA775 socket must always be installed during transport to avoid
damage to the socket.
6MB886 User’s Manual

INSTALLATIONS
MB886 User’s Manual 7
ATX Power Installation
The system power is provided to the motherboard with the ATX1 and
ATX_12V power connectors. ATX1 is a 24-pin power connector and
ATX_12V is a 8-pin 12V power connector.
The 24-pin power connector can to be connected to a standard 20-pin
ATX power connector in a standard ATX power supply (Min. 400watt).
Note: The power supply 5VSB voltage must be at least 2A.
Installing the Memory
The MB886 motherboard supports four DDR2 memory sockets for a
maximum total memory of 4GB in DDR memory type. It supports
DDR2 533/667.
Basically, the system memory interface has the following features:
Supports two 64-bit wide DDR data channels
Available bandwidth up to 5.3GB/s (DDR2 667) for single-channel
mode and 10.7GB/s (DDR2 667) in dual-channel mode.
Supports 256Mb, 512Mb, 1Gb DDR2 technologies.
Supports only x8, x16, DDR2 devices with four banks
Supports only unbuffered DIMMs
Supports opportunistic refresh
Up to 32 simultaneously open pages (four per row, four rows
maximum)

INSTALLATIONS
8MB886 User’s Manual
Setting the Jumpers
Jumpers are used on MB886 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on MB886 and their respective functions.
Jumper Locations on MB886..........................................................9
JP1, JP2, JP3: RS232/422/485 (COM2) Selection.......................10
JP4: IDE DMA Mode Setting.......................................................10
JP6: Clear CMOS Contents ..........................................................10

INSTALLATIONS
Jumper Locations on MB886
JP1, JP2, JP3: RS232/422/485 (COM2) Selection.............................. 10
JP4: IDE DMA Mode Setting.............................................................. 10
JP6: Clear CMOS Contents................................................................. 10
MB886 User’s Manual 9

INSTALLATIONS
JP1, JP2, JP3: RS232/422/485 (COM2) Selection
COM1 is fixed for RS-232 use only.
COM2 is selectable for RS232, RS-422 and RS-485. COM3 and COM4
are fixed for RS-232 use only. The following table describes the jumper
settings for COM2 selection.
COM2
Function RS-232 RS-422 RS-485
Jumper
Setting
(pin closed)
JP1:
1-2
JP2:
3-5 & 4-6
JP3:
3-5 & 4-6
JP1:
3-4
JP2:
1-3 & 2-4
JP3:
1-3 & 2-4
JP1:
5-6
JP2:
1-3 & 2-4
JP3:
1-3 & 2-4
JP4: IDE DMA Mode Setting
JP4 Setting Function
Pin 1-2
Short/Closed UDMA66 (default)
Pin 2-3
Short/Closed Forced UDMA33
JP6: Clear CMOS Contents
Use JP6, a 3-pin header, to clear the CMOS contents. Note that the
ATX-power connector should be disconnected from the motherboard
before clearing CMOS.
JP6 Setting Function
Pin 1-2
Short/Closed Normal
Pin 2-3
Short/Closed Clear CMOS
10 MB886 User’s Manual

INSTALLATIONS
MB886 User’s Manual 11
[
Connectors on MB886
The connectors on MB886 allows you to connect external devices such
as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on MB886 and their respective
functions.
ATX1: 24-pin ATX Power Connector ................................................ 13
ATX2: ATX 12V Power Connector.................................................... 13
MB886 Edge Connectors .................................................................... 13
CN1: PS/2 Keyboard and PS/2 Mouse Connectors............................. 14
CN2, J2, J7, J8: COM1/2/3/4 Serial Ports........................................... 14
CN3: Parallel Port Connector.............................................................. 15
CN4: VGA CRT Connector ................................................................ 15
CN5: Audio Connector........................................................................ 16
CN6: 10/100 RJ-45 and USB0/1 Connector........................................ 16
CN7: GbE RJ-45 and USB2/3 Connector ........................................... 16
CN11, CN10, CN9, CN8: SATA0/1/2/3 Connector ........................... 16
J1: Digital I/O Connector (4 in, 4 out)................................................. 17
J3: Audio Front Header....................................................................... 17
J5: USB4/USB5 Connector................................................................. 17
J6: USB6/USB7 Connector................................................................. 17
J9: Wake On LAN Connector ............................................................. 18
J10: System Function Connector......................................................... 18
J11: IrDA Connector ........................................................................... 20
FAN1: CPU Fan Power Connector .................................................... 20
FAN2, FAN3, FAN4: Fan Power Connectors..................................... 20
IDE1: Primary IDE Connectors........................................................... 21
PCIE_1: x16 PCI Express Slot............................................................ 21
PCIE_2, PCIE_3: x1 PCI Express Slots.............................................. 21
PCI1, PCI2, PCI3, PCI4: PCI Slots..................................................... 21
SL1: ISA Slot ...................................................................................... 21
CN12: CF Socket................................................................................. 21

INSTALLATIONS
Connector Locations on MB886
ATX1: 24-pin ATX Power Connector...................................................................................................................13
ATX2: ATX 12V Power Connector ......................................................................................................................13
MB886 Edge Connectors.......................................................................................................................................13
CN1: PS/2 Keyboard and PS/2 Mouse Connectors...............................................................................................14
CN2, J2, J7, J8: COM1/2/3/4 Serial Ports.............................................................................................................14
CN3: Parallel Port Connector ................................................................................................................................15
CN4: VGA CRT Connector...................................................................................................................................15
CN5: Audio Connector ..........................................................................................................................................16
CN6: 10/100 RJ-45 and USB0/1 Connector..........................................................................................................16
CN7: GbE RJ-45 and USB2/3 Connector..............................................................................................................16
CN11, CN10, CN9, CN8: SATA0/1/2/3 Connector..............................................................................................16
J3: Audio Front Header..........................................................................................................................................17
J5: USB4/USB5 Connector....................................................................................................................................17
J6: USB6/USB7 Connector....................................................................................................................................17
J9: Wake On LAN Connector................................................................................................................................18
J10: System Function Connector ...........................................................................................................................18
FAN1: CPU Fan Power Connector.......................................................................................................................20
FAN2, FAN3, FAN4: Fan Power Connectors.......................................................................................................20
IDE1: Primary IDE Connectors .............................................................................................................................21
PCIE_1: x16 PCI Express Slot...............................................................................................................................21
PCIE_2, PCIE_3: x1 PCI Express Slots ................................................................................................................21
PCI1, PCI2, PCI3, PCI4: PCI Slots........................................................................................................................21
SL1: ISA Slot.........................................................................................................................................................21
CN12: CF Socket...................................................................................................................................................21
12 MB886 User’s Manual

INSTALLATIONS
ATX1: 24-pin ATX Power Connector
Signal Name Pin # Pin # Signal Name
3.3V 13 1 3.3V
-12V 14 2 3.3V
Ground 15 3 Ground
PS-ON 16 4 +5V
Ground 17 5 Ground
Ground 18 6 +5V
Ground 19 7 Ground
-5V 20 8 Power good
+5V 21 9 5VSB
+5V 22 10 +12V
+5V 23 11 +12V
Ground 24 12 +3.3V
ATX2: ATX 12V Power Connector
Signal Name Pin # Pin # Signal Name
+12V 5 1 Ground
+12V 6 2 Ground
+12V 7 3 Ground
+12V 8 4 Ground
MB886 Edge Connectors
MB886 User’s Manual 13

INSTALLATIONS
CN1: PS/2 Keyboard and PS/2 Mouse Connectors
Keyboard
Signal Pin # Mouse Signal
Keyboard data 1 Mouse data
N.C. 2 N.C.
GND 3 GND
5V 4 5V
Keyboard clock 5 Mouse clock
N.C. 6 N.C.
Mouse (top)
Keyboard (bottom)
CN2, J2, J7, J8: COM1/2/3/4 Serial Ports
CN2 (COM1) is a DB-9 connector, while J2, J7 and J8 are a COM
pin-header connectors.
COM1 COM2
Signal Name Pin # Pin # Signal Name
DCD, Data carrier detect 1 6 DSR, Data set ready
RXD, Receive data 2 7 RTS, Request to send
TXD, Transmit data 3 8 CTS, Clear to send
DTR, Data terminal ready 4 9 RI, Ring indicator
GND, ground 5 10 Not Used
COM2 is jumper selectable for RS-232, RS-422 and RS-485.
Pin # Signal Name
RS-232 R2-422 RS-485
1 DCD TX- DATA-
2 RX TX+ DATA+
3 TX RX+ NC
4 DTR RX- NC
5 Ground Ground Ground
6 DSR RTS- NC
7 RTS RTS+ NC
8 CTS CTS+ NC
9 RI CTS- NC
10 NC NC NC
14 MB886 User’s Manual

INSTALLATIONS
CN3: Parallel Port Connector
CN3 is a DB-25 external connector situated on top of the VGA and serial
ports.
CN4 Parallel Port
Signal Name Pin # Pin # Signal Name
Line printer strobe 1 14 AutoFeed
PD0, parallel data 0 2 15 Error
PD1, parallel data 1 3 16 Initialize
PD2, parallel data 2 4 17 Select
PD3, parallel data 3 5 18 Ground
PD4, parallel data 4 6 19 Ground
PD5, parallel data 5 7 20 Ground
PD6, parallel data 6 8 21 Ground
PD7, parallel data 7 9 22 Ground
ACK, acknowledge 10 23 Ground
Busy 11 24 Ground
Paper empty 12 25 Ground
Select 13 N/A N/A
CN4: VGA CRT Connector
CN4 is a DB-15 VGA connector located beside the COM1 port. The
following table shows the pin-out assignments of this connector.
Signal Name Pin # Pin # Signal Name
Red 1 2 Green
Blue 3 4 N.C.
GND 5 6 GND
GND 7 8 GND
VCC 9 10 GND
N.C. 11 12 DDCDATA
HSYNC 13 14 VSYNC
DDCCLK 15
MB886 User’s Manual 15

INSTALLATIONS
CN5: Audio Connector
CN6: 10/100 RJ-45 and USB0/1 Connector
CN7: GbE RJ-45 and USB2/3 Connector
CN11, CN10, CN9, CN8: SATA0/1/2/3 Connector
Pin # Signal Name
1 Ground
2 TX+
3 TX-
4 Ground
5 RX-
6 RX+
7 Ground
16 MB886 User’s Manual
