IBASE Technology IB811F Series User manual

IB811F Series
Intel®Pentium®/ Celeron®/
Atom™ x7 / x5 SoC
3.5”Disk-Size SBC
User’s Manual
Version 2.0
(Sep. 2019)

ii
IB811F Series User’s Manual
Copyright
©2017 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval
system, translated into any language or transmitted in any form or by any
means, electronic, mechanical, photocopying, or otherwise, without the prior
written consent of IBASE Technology, Inc. (hereinafter referred to as
“IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the
products described in this document without prior notice. Every effort has
been made to ensure the information in the document is correct; however,
IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising
from misapplication or inability to use the product or the information
contained herein, nor for any infringements of rights of third parties, which
may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for
identification purposes only and may be trademarks and/or registered
trademarks of their respective owners.

IB811F Series User’s Manual
iii
Compliance
This product has passed CE tests for environmental specifications and limits.
This product is in accordance with the directives of the European Union (EU).
In a domestic environment, this product may cause radio interference in
which case users may be required to take adequate measures.
This product has been tested and found to comply with the limits for a Class
B device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household
waste, in accordance with the EU directive of for waste
electrical and electronic equipment (WEEE - 2012/19/EU).
Instead, it should be disposed of by returning it to a
municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS
restrictions and prohibits use of the following substances in
concentrations exceeding 0.1% by weight (1000 ppm)
except for cadmium, limited to 0.01% by weight (100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
IB811F Series User’s Manual
Important Safety Information
Carefully read the precautions before using the board.
Environmental conditions:
•Use this product in environments with ambient temperatures between
0˚C and 60˚C, or -40 and 85 ˚C.
•Do not leave this product in an environment where the storage
temperature may be below -40°C or above 110°C. To prevent from
damages, the product must be used in a controlled environment.
Care for your IBASE products:
•Before cleaning the PCB, unplug all cables and remove the battery.
•Clean the PCB with a circuit board cleaner or degreaser, or use cotton
swabs and alcohol.
•Vacuum the dust with a computer vacuum cleaner to prevent the fan
from being clogged.
WARNING
Attention during use:
•Do not use this product near water.
•Do not spill water or any other liquids on this product.
•Do not place heavy objects on the top of this product.
Anti-static precautions
•Wear an anti-static wrist strap to avoid electrostatic discharge.
•Place the PCB on an anti-static kit or mat.
•Hold the edges of PCB when handling.
•Touch the edges of non-metallic components of the product instead of
the surface of the PCB.
•Ground yourself by touching a grounded conductor or a grounded bit of
metal frequently to discharge any static.
CAUTION
Danger of explosion if the internal lithium-ion battery is replaced by an
incorrect type. Replace only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions or recycle them at a local recycling facility or
battery collection point.

IB811F Series User’s Manual
v
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of
shipment cannot be ascertained, the product serial numbers can be
used to determine the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are
not manufactured by IBASE, such as CPU, CPU cooler, memory,
storage devices, power adapter, panel and touchscreen.
＊PRODUCTS, HOWEVER, THAT FAIL DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL
BE TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL
BE BILLED FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest
information about the product.
2. If you need any further assistance from your distributor or sales
representative, prepare the following information of your product and
elaborate upon the problem.
•Product model name
•Product serial number
•Detailed description of the problem
•The error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software in use (such as OS and application software, including the
version numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the
form and contact your distributor or sales representative.

vi
IB811F Series User’s Manual
Table of Contents
Compliance.....................................................................................iii
Important Safety Information........................................................iv
Warranty Policy...............................................................................v
Technical Support & Services .......................................................v
Chapter 1 General Information.............................................1
1.1 Introduction .........................................................................................2
1.2 Features..............................................................................................2
1.3 Packing List.........................................................................................3
1.4 Optional Accessories...........................................................................3
1.5 Specifications......................................................................................4
1.6 Block Diagram.....................................................................................7
1.7 Overview.............................................................................................8
1.8 Dimensions .......................................................................................10
Chapter 2 HardwareConfiguration........................................11
2.1 Essential Installations Before You Begin............................................12
2.1.1 Installing the Memory...........................................................12
2.2 Setting the Jumpers...........................................................................13
2.3 Jumper & Connector Locations..........................................................14
2.4 Jumpers Quick Reference.................................................................15
2.4.1 LVDS Panel Brightness Selection (JP1)..............................15
2.4.2 LVDS Panel Power Selection (JP2).....................................16
2.4.3 eDP Panel Power Selection (JP3).......................................16
2.4.4 eDP / LVDS Panel Selection (JP4)......................................17
2.4.5 ATX / AT Power Selection (JP5)..........................................17
2.4.6 CMOS Data Clearance (JP6) ..............................................18
2.4.7 ME Register Clearance (JP7)..............................................18
2.5 Connectors Quick Reference.............................................................19
2.5.1 eDP Connector (CN1) .........................................................20
2.5.2 SATA III Connector (CN2, CN3)..........................................21
2.5.3 LAN Ports (CN4) .................................................................21
2.5.4 USB 3.0 Ports (CN5, CN6)..................................................21
2.5.5 Console COM1 (RJ50) RS-232/422/485 Port (CN7)............22

IB811F Series User’s Manual
vii
2.5.6 DisplayPort (CN8)................................................................23
2.5.7 HDMI Port (CN9) .................................................................23
2.5.8 LCD Backlight Connector (J2)..............................................23
2.5.9 LVDS Connector (J1, J3).....................................................24
2.5.10 Audio Connector (J4)...........................................................25
2.5.11 DDR3L SO-DIMM Slot (J5, J8)............................................25
2.5.12 USB 2.0 Connector (J6).......................................................26
2.5.13 Amplifier Connector (J7)......................................................26
2.5.14 SATA HDD Power Connector (J10) .....................................27
2.5.15 Mini PCIe / mSATA Slot (J11)..............................................27
2.5.16 COM2 / COM3 / COM4 RS-232 Port (J16, J17, J12)...........28
2.5.17 M.2 (B key) 3042 Slot (J14) .................................................28
2.5.18 Front Panel Connector (J13)................................................29
2.5.19 Digital I/O Connector (J18)...................................................30
2.5.20 DC Power Input Connector (J19).........................................30
Chapter 3 Drivers Installation.............................................31
3.1 Introduction........................................................................................32
3.2 Intel®Chipset Software Installation Utility...........................................33
3.3 VGA Driver Installation.......................................................................35
3.4 HD Audio Driver Installation...............................................................37
3.5 Intel®Trusted Execution Engine Drivers.............................................39
3.6 Intel®Serial IO Drivers.......................................................................41
3.7 LAN Driver Installation .......................................................................43
Chapter 4 BIOS Setup..........................................................45
4.1 Introduction........................................................................................46
4.2 BIOS Setup........................................................................................46
4.3 Main Settings.....................................................................................48
4.4 Advanced Settings.............................................................................49
4.4.3 LVDS (eDP/DP) Configuration..............................................52
4.4.4 Fintek Super IO Configuration...............................................53
4.4.5 Fintek Super IO Hardware Monitor........................................55
4.4.6 M.2 Setup.............................................................................56
4.4.7 CPU Configuration................................................................57
4.4.8 AMI Graphic Output Protocol Policy......................................58
4.4.9 Network Stack Configuration.................................................59
4.4.10 CSM Configuration ...............................................................60
4.4.11 USB Configuration................................................................61

viii
IB811F Series User’s Manual
4.5 Chipset Settings................................................................................62
4.6 Security Settings ...............................................................................67
4.7 Boot Settings.....................................................................................71
4.8 Save & Exit Settings..........................................................................72
Appendix........................................................................................73
A. I/O Port Address Map........................................................................74
B. Interrupt Request Lines (IRQ)............................................................77
C. Watchdog Timer Configuration..........................................................79

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Block Diagram
•Specifications
•Board Overview
•Board Dimensions

2
IB811F Series User’s Manual
1.1 Introduction
IB811F is a 3.5” disk-size single board computer based on the platform of
Intel®Atom™x7/x5, Pentium®or Celeron®. It features both DisplayPort and
HDMI at coastline, and on-board headers for eDP / 24-bit dual channel LVDS
interfaces for video display. It is able to be operated at the ambient operating
temperature ranging from 0 ~ 60 °C, and even from -40 ~ 85 °C for models of
wide temperature.
Photo of IB811F-420
1.2 Features
•3.5” disk-size SBC with Intel®Atom™x7-E3950 / x5 E3940/ x5-E3930/
Pentium®N4200E / Celeron®N3350E
•2 x DDR3L-1600/1866 SO-DIMM slots, expandable up to 16GB
•1 x HDMI, 1 x DisplayPort, eDP / 24 bit dual channel LVDS
•2 x GbE LAN, 4 x USB 3.0, 2 x USB 2.0, 4 x COM, 2 x SATA III, 1 x Mini
PCIe slot (full-size), 1 x M.2 (B-key)
•Configurable watchdog timer and digital I/O, mSATA, EuP/ErP
•Wide temperature supported by IB811F-I50 and IB811F-I40 and
IB811F-I30

General Information
IB811F Series User’s Manual
3
1
1.3 Packing List
Your IB811F package should include the items listed below. If any of the
items below is missing, contact the distributor or dealer from whom you
purchased the product.
•IB811F SBC x 1
•Disk x 1
(including chipset drivers and flash memory utility)
•This User’s Manual x 1
1.4 Optional Accessories
IBASE provides optional accessories as follows. Please contact us or your
dealer if you need any.
•Cable Kit (IB76A)
(including:
SATA cable (SATA-53) x 1
Power cable (PW87) x 1
COM ports cable (PK1H) x 1
USB cable (USB29) x 1
•Heatsink for IB811F-I50/IB811F-I40/IB811F-I30 (HSIB811-A)
•Heatsink for IB811F-420 / IB811F-335 (HSIB811-B)
•Audio cable (Audio-18)
•COM1 RJ50 cable (PK105)

4
IB811F Series User’s Manual
1.5 Specifications
Product
Name
•IB811F-I50
•IB811F-I40
•IB811F-I30
•IB811F-420
•IB811F-335
Form Factor
3.5” disk-size SBC
System
Operating
System
•Windows 10 Enterprise (64-bit)
•Windows 10 IoT Core (64-bit)
•Linux Ubuntu
CPU Type
•Intel® Atom™ QC x7 / E3950
(IB811F-I50)
•Intel® Atom™ DC x5 / E3940
(IB811F-I40)
•Intel® Atom™ DC x5 / E3930
(IB811F-I30)
•Intel® Pentium®
QC N4200E
(IB811F-420)
•Intel® Celeron®
DC N3350E
(IB811F-335)
CPU Speed
1.6~2.0GHz
1.6~1.8GHz
1.3~1.8GHz
1.1~2.5GHz
1.1~ 2.4GHz
Cache
2 MB
Chipset
Integrated
Memory
2 x DDR3L-1600/1866 SO-DIMM, expandable up to 16
GB (Non-ECC)
Storage
1 x mSATA SSD
Graphics
Intel®SoC integrated Gen. 9
Network
2 x Intel®I210IT PCIe Gigabit
Ethernet
2 x Intel®I211AT PCIe
Gigabit Ethernet
TPM2.0
Infineon SLB9670XQ
Infineon SLB9670VQ
Super I/O
Fintek F81964
Audio Codec
& Controller
Intel®SoC built-in HD audio controller
Realtek ALC283QHD codec with speaker amplifier
Power
Requirement
9~36V DC-In (jumper-selectable ATX / AT power mode)
Watchdog
Timer
Yes (256 segments, 0, 1, 2…255 sec / min)
BIOS
AMI BIOS
H/W Monitor
Yes

General Information
IB811F Series User’s Manual
5
1
Smart
Control
•EuP/ErP
•Power failure detection by a jumper connector
•LVDS brightness control
Dimensions
102.22 x 147.01 mm (4.02” x 5.8”)
RoHS
Yes
Certification
CE, FCC Class B, LVD
I/O Ports
Display
•1 x HDMI (1.4b), 3840 x 2160 at 30 Hz
•1 x DisplayPort (1.2), 4096 x 2160 at 60 Hz
•1 x eDP / 24-bit dual channel LVDS
eDP: 4096 x 2160 at 60 Hz
LVDS: 1920 x 1200 at 60 Hz
LAN
2 x RJ45 GbE LAN
USB
•4 x USB 3.0: I/O coastline connectors
•2 x USB 2.0: via an on-board pin headers
Serial
4 x COM ports:
•COM1: RS-232/422/485 (I/O coastline RJ50
connector, jumper-less selection)
•COM2, COM3, COM4: RS-232 only (via on-board
box-headers)
SATA
2 x SATA III
Audio
On-board audio connector for Line-In, Line-Out, and
Mic-In
Digital IO
4-In & 4-Out
Expansion
Slots
•1 x Mini PCIe slot (full-size) with USB and mSATA
•1 x M.2 (B key) 3042 Slot with PCIe (x1), USB and
SATA

6
IB811F Series User’s Manual
Product
Name
•IB811F-I50
•IB811F-I40
•IB811F-I30
•IB811F-420
•IB811F-335
Environment
Temperature
•Operation: -40 ~ 85 °C
(-40 ~ 185 °F)
•Storage: -40 ~ 110 °C
(-40 ~ 230 °F)
•Operation: 0 ~ 60 °C
(32 ~ 140 °F)
•Storage: -40 ~ 110 °
C (-40 ~ 230 °F)
Relative
Humidity
0 ~ 90 %, non-condensing at 60 °C
All specifications are subject to change without prior notice.

General Information
IB811F Series User’s Manual
7
1
1.6 Block Diagram

8
IB811F Series User’s Manual
1.7 Overview
Top View
Bottom View
Photo of IB811F-420
＊The photos above are for reference only. Some minor components may
differ.

General Information
IB811F Series User’s Manual
9
1
I/O View
No.
Name
No.
Name
1
COM1 (RJ50) Port
4
LAN Port
2
DisplayPort
5
USB 3.0 Port
3
HDMI Port

10
IB811F Series User’s Manual
1.8 Dimensions
0
0
05
5
13.45
13.30
41.78
97.23
102.22
18.4 37.39 58.92 70.36 85.92 111.04 128.26 142.01 147.01
16.34

11
Chapter 2
Hardware Configuration
This section provides information on jumper settings and
connectors on the IB811F in order to set up a workable system.
On top of that, you will also need to install crucial pieces such as
the CPU and the memory before using the product. The topics
covered are:
•Essential installations before you begin:
CPU and the memory
•Jumper and connector locations
•Jumper settings and information of connectors

12
IB811F Series User’s Manual
2.1 Essential Installations Before You Begin
Follow the instructions below to install the memory.
2.1.1 Installing the Memory
To install the modules, locate the memory slot on the board and perform the
following steps:
1. Align the key of the memory module with that on the memory slot and
insert the module slantwise.
2. Gently push the module in an upright position until the clips of the slot
close to hold the module in place when the module touches the bottom
of the slot.
To remove the module, press the clips outwards with both hands, and the
module will pop-up.
