IBM BladeCenter HT 8740 User manual

BladeCenterHTType8740and8750
Problem Determination and Service Guide


BladeCenterHTType8740and8750
Problem Determination and Service Guide


Note
Before using this information and the product it supports, read the general information in Appendix B, “Notices,” on page 125,
and the IBM Safety Information and IBM Systems Environmental Notices and User Guide documents on the IBM
Documentation CD.
The most recent version of this document is available at http://www.ibm.com/systems/supportportal/.
Fifth Edition (October 2012)
© Copyright IBM Corporation 2012.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety ............................vii
Guidelines for trained service technicians ...............viii
Inspecting for unsafe conditions .................viii
Guidelines for servicing electrical equipment .............ix
Safety statements ........................ix
Chapter 1. Introduction ......................1
Related documentation ......................1
Notices and statements in this document................3
Deployment scenarios.......................3
Features and specifications.....................5
BladeCenter HT unit power, controls, and indicators............6
Supplying power to the BladeCenter HT unit .............6
Disconnecting power from the BladeCenter HT unit ..........11
BladeCenter HT components, controls, and LEDs ...........14
Chapter 2. Configuration information and guidelines..........21
Updating the firmware ......................21
Configuring the BladeCenter HT unit .................21
Configuring the management module................21
Configuring I/O modules ....................21
Configuring blade servers ....................22
BladeCenter networking guidelines .................22
Chapter 3. Parts listing .....................23
Front view ..........................24
Rear view ...........................26
AC power cords ........................28
Chapter 4. Removing and replacing BladeCenter HT components ....31
Installation guidelines ......................31
System reliability guidelines ...................32
Handling static-sensitive devices .................32
Returning a device or component .................33
Removing and replacing Tier 1 CRUs ................34
Removing a bezel .......................34
Installing a bezel .......................35
Removing a bezel filter .....................36
Installing a bezel filter .....................38
Removing a bezel collar ....................41
Installing a bezel collar .....................45
Removing a cable management tray ................49
Installing a cable management tray ................50
Removing a media tray .....................51
Installing a media tray .....................52
Removing a CompactFlash module ................53
Installing a CompactFlash module .................54
Removing a power module ...................55
Installing a power module ....................57
Removing a fan pack .....................58
Installing a fan pack ......................59
Removing a blade server ....................60
Installing a blade server ....................61
© Copyright IBM Corp. 2012 iii

Removing an I/O-module interposer ................62
Installing an I/O-module interposer.................63
Removing an I/O module ....................64
Installing an I/O module ....................65
Removing a high-speed I/O-module interposer tray ..........66
Installing a high-speed I/O-module interposer tray ...........67
Removing a high-speed I/O-module interposer card ..........68
Installing a high-speed I/O-module interposer card ...........69
Removing a high-speed I/O module ................71
Installing a high-speed I/O module.................72
Removing a management-module interposer .............73
Installing a management-module interposer .............74
Removing a management module .................75
Installing a management module .................76
Removing a network clock-module filler ...............77
Installing a network clock-module filler ...............78
Removing a multiplexer expansion module..............79
Installing a multiplexer expansion module ..............80
Removing an alarm panel module .................81
Installing an alarm panel module .................82
Removing a fan module ....................83
Installing a fan module .....................85
Removing a dc terminal cover ..................86
Installing a dc terminal cover ...................88
Removing the fan shuttle ....................89
Installing the fan shuttle ....................90
Removing and replacing FRUs ...................92
Removing a power box .....................92
Installing a power box .....................94
Removing the midplane.....................96
Installing the midplane .....................98
Chapter 5. Diagnostics .....................101
Diagnostic tools ........................101
Troubleshooting tables .....................102
Blade server problems ....................102
Fan-module problems .....................103
Fan pack problems ......................105
I/O module problems .....................105
Keyboard, mouse, or pointing-device problems............107
Management-module problems .................107
Media tray problems .....................108
Monitor or video problems ...................110
Power problems .......................111
Light path diagnostic LEDs ....................113
BladeCenter system LEDs ...................113
Module LEDs ........................115
Event log messages ......................117
Service data .........................118
Solving undetermined problems ..................118
Calling IBM for service .....................120
Appendix A. Getting help and technical assistance ..........121
Before you call ........................121
Using the documentation.....................122
Getting help and information from the World Wide Web .........122
iv BladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide

How to send Dynamic System Analysis data to IBM ...........122
Creating a personalized support web page ..............122
Software service and support ...................122
Hardware service and support ...................123
IBM Taiwan product service....................123
Appendix B. Notices ......................125
Trademarks..........................125
Important notes ........................126
Particulate contamination.....................127
Documentation format ......................127
Telecommunication regulatory statement ...............128
Electronic emission notices ....................128
Federal Communications Commission (FCC) statement ........128
Industry Canada Class A emission compliance statement ........128
Avis de conformité à la réglementation d'Industrie Canada .......128
Australia and New Zealand Class A statement ............129
European Union EMC Directive conformance statement ........129
Germany Class A statement ..................129
VCCI Class A statement ....................130
Japan Electronics and Information Technology Industries Association (JEITA)
statement ........................130
Korea Communications Commission (KCC) statement .........131
Russia Electromagnetic Interference (EMI) Class A statement ......131
People's Republic of China Class A electronic emission statement ....131
Taiwan Class A compliance statement ...............131
Index ............................133
Contents v

vi BladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide

Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d'installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
© Copyright IBM Corp. 2012 vii

Guidelines for trained service technicians
This section contains information for trained service technicians.
Inspecting for unsafe conditions
Use the information in this section to help you identify potential unsafe conditions in
an IBM product that you are working on. Each IBM product, as it was designed and
manufactured, has required safety items to protect users and service technicians
from injury. The information in this section addresses only those items. Use good
judgment to identify potential unsafe conditions that might be caused by non-IBM
alterations or attachment of non-IBM features or options that are not addressed in
this section. If you identify an unsafe condition, you must determine how serious the
hazard is and whether you must correct the problem before you work on the
product.
Consider the following conditions and the safety hazards that they present:
vElectrical hazards, especially primary power. Primary voltage on the frame can
cause serious or fatal electrical shock.
vExplosive hazards, such as a damaged CRT face or a bulging capacitor.
vMechanical hazards, such as loose or missing hardware.
To inspect the product for potential unsafe conditions, complete the following steps:
1. Make sure that the power is off and the power cords are disconnected.
2. Make sure that the exterior cover is not damaged, loose, or broken, and
observe any sharp edges.
3. Check the power cords:
vMake sure that the third-wire ground connector is in good condition. Use a
meter to measure third-wire ground continuity for 0.1 ohm or less between
the external ground pin and the frame ground.
vMake sure that the power cords are the correct type.
vMake sure that the insulation is not frayed or worn.
4. Remove any access covers.
5. Check for any obvious non-IBM alterations. Use good judgment as to the safety
of any non-IBM alterations.
6. Check inside the computer for any obvious unsafe conditions, such as metal
filings, contamination, water or other liquid, or signs of fire or smoke damage.
7. Check for worn, frayed, or pinched cables.
viii BladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide

8. Make sure that the power-supply cover fasteners (screws or rivets) have not
been removed or tampered with.
Guidelines for servicing electrical equipment
Observe the following guidelines when servicing electrical equipment:
vCheck the area for electrical hazards such as moist floors, nongrounded power
extension cords, and missing safety grounds.
vUse only approved tools and test equipment. Some hand tools have handles that
are covered with a soft material that does not provide insulation from live
electrical current.
vRegularly inspect and maintain your electrical hand tools for safe operational
condition. Do not use worn or broken tools or testers.
vDo not touch the reflective surface of a dental mirror to a live electrical circuit.
The surface is conductive and can cause personal injury or equipment damage if
it touches a live electrical circuit.
vSome rubber floor mats contain small conductive fibers to decrease electrostatic
discharge. Do not use this type of mat to protect yourself from electrical shock.
vDo not work alone under hazardous conditions or near equipment that has
hazardous voltages.
vLocate the emergency power-off (EPO) switch, disconnecting switch, circuit
breakers, or electrical outlet so that you can turn off the power quickly in the
event of an electrical accident.
vDisconnect all power before you perform a mechanical inspection, work near
power supplies, or remove or install main units.
vBefore you work on the equipment, disconnect all power cords. If you cannot
disconnect the power cords, have the customer power-off the wall box that
supplies power to the equipment and lock the wall box in the off position.
vNever assume that power has been disconnected from a circuit. Check it to
make sure that it has been disconnected.
vIf you have to work on equipment that has exposed electrical circuits, observe
the following precautions:
– Make sure that another person who is familiar with the power-off controls is
near you and is available to turn off the power if necessary.
– When you are working with powered-on electrical equipment, use only one
hand. Keep the other hand in your pocket or behind your back to avoid
creating a complete circuit that could cause an electrical shock.
– When using a tester, set the controls correctly and use the approved probe
leads and accessories for that tester.
– Stand on a suitable rubber mat to insulate you from grounds such as metal
floor strips and equipment frames.
vUse extreme care when measuring high voltages.
vTo ensure proper grounding of components such as power supplies, pumps,
fans, and motor generators, do not service these components outside of their
normal operating locations.
vIf an electrical accident occurs, use caution, turn off the power, and send another
person to get medical aid.
Safety statements
Important:
Safety ix

Each caution and danger statement in this document is labeled with a number. This
number is used to cross reference an English-language caution or danger
statement with translated versions of the caution or danger statement in the Safety
Information document.
For example, if a caution statement is labeled "Statement 1," translations for that
caution statement are in the Safety Information document under "Statement 1."
Be sure to read all caution and danger statements in this document before you
perform the procedures. Read any additional safety information that comes with the
server or optional device before you install the device.
xBladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide

Statement 2:
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
a module containing a lithium battery, replace it only with the same module
type made by the same manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.
Do not:
vThrow or immerse into water
vHeat to more than 100°C (212°F)
vRepair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3:
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
vDo not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
vUse of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.
DANGER
Some laser products contain an embedded Class 3A or Class 3B laser
diode. Note the following.
Laser radiation when open. Do not stare into the beam, do not view directly
with optical instruments, and avoid direct exposure to the beam.
Safety xi

Statement 8:
CAUTION:
Never remove the cover on a power supply or any part that has the following
label attached.
Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect a problem with one of these parts, contact
a service technician.
Statement 12:
CAUTION:
The following label indicates a hot surface nearby.
Statement 13:
DANGER
Overloading a branch circuit is potentially a fire hazard and a shock hazard
under certain conditions. To avoid these hazards, ensure that your system
electrical requirements do not exceed branch circuit protection
requirements. Refer to the information that is provided with your device for
electrical specifications.
xii BladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide

Statement 21:
CAUTION:
Hazardous energy is present when the blade is connected to the power
source. Always replace the blade cover before installing the blade.
Statement 29:
CAUTION:
This equipment is designed to permit the connection of the earthed conductor
of the dc supply circuit to the earthing conductor at the equipment. If this
connection is made, all of the following conditions must be met:
vThis equipment shall be connected directly to the dc supply system
earthing electrode conductor or to a bonding jumper from an earthing
terminal bar or bus to which the dc supply system earthing electrode
conductor is connected.
vThis equipment shall be located in the same immediate area (such as,
adjacent cabinets) as any other equipment that has a connection between
the earthed conductor of the same dc supply circuit and the earthing
conductor, and also the point of earthing of the dc system. The dc system
shall not be earthed elsewhere.
vThe dc supply source shall be located within the same premises as this
equipment.
vSwitching or disconnecting devices shall not be in the earthed circuit
conductor between the dc source and the point of connection of the
earthing electrode conductor.
Safety xiii

Statement 31:
DANGER
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid a shock hazard:
vDo not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical
storm.
vConnect all power cords to a properly wired and grounded power
source.
vConnect to properly wired power sources any equipment that will be
attached to this product.
vWhen possible, use one hand only to connect or disconnect signal
cables.
vNever turn on any equipment when there is evidence of fire, water, or
structural damage.
vDisconnect the attached ac power cords, dc power sources, network
connections, telecommunications systems, and serial cables before you
open the device covers, unless instructed otherwise in the installation
and configuration procedures.
vConnect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached
devices.
To Connect: To Disconnect:
1. Turn OFF all power sources and
equipment to be attached to this product.
2. Attach all cables to the devices.
3. Attach signal cables to the connectors.
4. Attach power cords to power sources.
For dc systems, ensure correct polarity of
-48VDC connections: RTN is (+) and
-48VDC is (-). Earth ground should use a
two-hole lug for safety.
5. Turn ON all the power sources.
1. Turn OFF all power sources and
equipment to be attached to this product.
vFor ac systems, remove all power
cords from the chassis power
receptables or interrupt power at the
ac power distribution unit.
vFor dc systems, disconnect dc power
sources at the breaker panel or by
turning off the power source, then
remove the dc cables.
2. Remove the signal cables from the
connectors.
3. Remove all cables from the devices.
xiv BladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide

Statement 32:
CAUTION:
To avoid personal injury, before lifting the unit, remove all the blades, power
supplies, and removable modules to reduce the weight.
Statement 33:
CAUTION:
This device does not provide a power control button. Removing power supply
modules or turning off the server blades does not turn off the electrical
current supplied to the device. The device also might have more than one
power cord. To remove all electrical current from the device, ensure that all
power cords are disconnected from the power source.
BladeCenter HT Type 8740:
BladeCenter HT Type 8750:
Safety xv

Statement 34:
CAUTION:
To reduce the risk of electric shock or energy hazards:
vThis equipment must be installed by trained service personnel in a
restricted-access location, as defined by the NEC and IEC 60950-1, First
Edition, The Standard for Safety of Information Technology Equipment.
vConnect the equipment to a properly grounded safety extra low voltage
(SELV) source. A SELV source is a secondary circuit that is designed so
that normal and single fault conditions do not cause the voltages to exceed
a safe level (60 V direct current).
vIncorporate a readily available approved and rated disconnect device in the
field wiring.
vSee the specifications in the product documentation for the required
circuit-breaker rating for branch circuit overcurrent protection.
vUse copper wire conductors only. See the specifications in the product
documentation for the required wire size.
vSee the specifications in the product documentation for the required torque
values for the wiring-terminal nuts.
xvi BladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide

Chapter 1. Introduction
This Problem Determination and Service Guide contains information to help you
solve problems that might occur in your IBM®BladeCenter®HT Type 8740 and
8750 unit. It describes the diagnostic tools that come with the BladeCenter HT unit,
error codes and suggested actions, and instructions for replacing failing
components.
Replaceable components are of three types:
vTier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged for
the installation.
vTier 2 customer replaceable unit: You can install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your computer.
vField replacement unit (FRU): FRUs must be installed only by trained service
technicians.
For information about the terms of the warranty and getting service and assistance,
see the Warranty and Support Information document on the IBM Documentation
CD.
Related documentation
In addition to this document, the following related documentation is provided in
Portable Document Format (PDF) on the BladeCenter Documentation CD that
comes with your BladeCenter HT unit:
vBladeCenter HT Installation and User’s Guide
This printed document contains instructions for setting up the BladeCenter HT
unit and general information about the BladeCenter HT unit, including information
about features, and how to configure the BladeCenter HT unit. It also contains
detailed instructions for installing, removing, and connecting optional devices that
the BladeCenter HT unit supports.
vBladeCenter HT 2-Post Rack Installation Instructions
This document is in Portable Document Format (PDF) on the IBM Documentation
CD. It contains instructions for installing the BladeCenter HT unit in a 2-post rack.
vBladeCenter HT 4-Post Rack Installation Instructions
This document is in Portable Document Format (PDF) on the IBM Documentation
CD. It contains instructions for installing the BladeCenter HT unit in a 4-post rack.
vIBM BladeCenter HT Advanced Management Module Interposer and Flex Cable
Assembly Installation Instructions
This document provides the installation instructions and warranty information for
an IBM BladeCenter HT Advanced Management Module Interposer and Flex
Cable Assembly.
vBladeCenter Advanced Management Module Installation Guide
This document contains instructions for installing the management module in the
BladeCenter HT unit and creating the initial configuration.
vBladeCenter Management Module User’s Guide
This document provides general information about the management module for
your BladeCenter HT unit, including information about features, how to configure
the management module, and how to get help.
© Copyright IBM Corp. 2012 1

vBladeCenter Management Module Command-Line Interface Reference Guide
This document explains how to use the management-module command-line
interface to directly access BladeCenter management functions as an alternative
to using the Web-based user interface. The command-line interface also provides
access to the text-console command prompt on each blade server through a
serial over LAN (SOL) connection.
vSafety Information
This document contains translated caution and danger statements. Each caution
and danger statement that appears in the documentation has a number that you
can use to locate the corresponding statement in your language in the Safety
Information document.
vWarranty and Support Information
This document contains information about the terms of the warranty and getting
service and assistance.
vIBM BladeCenter HT Redundant Media Tray Installation Instructions
This document provides the installation instructions and warranty information for
an IBM BladeCenter HT Redundant Media Tray.
vBladeCenter HT CompactFlash Module
This document provides the installation instructions and warranty information for
an IBM BladeCenter HT CompactFlash Module.
vIBM BladeCenter HT AC Power Supply Modules Installation Instructions
This document provides the installation instructions and warranty information for
an IBM BladeCenter HT AC Power Supply Module.
vIBM BladeCenter HT DC Power Supply Modules Installation Instructions
This document provides the installation instructions and warranty information for
an IBM BladeCenter HT dc Power Supply Module.
vIBM BladeCenter HT Interposer for Gb Switch/Bridge Bays and IBM BladeCenter
HT Interposer for Gb Switch/Bridge Bays with Interswitch Links (ISL) Installation
Instructions
This document provides the installation instructions and warranty information for
the IBM BladeCenter HT Interposer for Gb Switch/Bridge Bays and the IBM
BladeCenter HT Interposer for Gb Switch/Bridge Bays with Interswitch Links
(ISL).
vIBM BladeCenter HT Interposer for HS Switch Bay Installation Instructions
This document provides the installation instructions and warranty information for
an IBM BladeCenter HT Interposer for HS Switch Bay.
vIBM BladeCenter HT Bezel Installation Instructions
This document provides the installation instructions and warranty information for
the IBM BladeCenter HT Bezel option.
vIBM BladeCenter HT Bezel Filter 4-Pack Option
This document provides warranty information for the IBM BladeCenter HT Bezel
Filter 4-Pack Option.
Additional documentation might be included on the IBM BladeCenter Documentation
CD.
The BladeCenter HT unit might have features that are not described in the
documentation that comes with the BladeCenter HT unit. The documentation might
be updated occasionally to include information about those features, or technical
updates might be available to provide additional information that is not included in
2BladeCenter HT Type 8740 and 8750: Problem Determination and Service Guide
