IBM ThinkPad 770Z Manual

You can use the ThinkPad 770X User's Reference for the ThinkPad 770Z computer . This
supplement includes updated information for the User's Reference (part number 27L3407). Use this
information instead of the corresponding information in the User's Reference .
Single FDD support
Although the User's Reference states that several FDDs can be supported by the ThinkPad
computer, your computer can support only one FDD at a time. The FDD in the bay always takes
precedence over the external FDD. For example, in suspend mode, if you install an FDD in the bay
and attach an FDD externally, the computer recognizes the FDD in the bay after resuming.
This information also applies when you are using the docking station.
Software Selections CD
Although your User's Reference describes the ThinkPad Customization Center CD, and the Setup
Guide describes a ThinkPad Customization Center icon, your computer has a Software Selections
CD rather than the ThinkPad Customization Center CD, and there is no ThinkPad Customization
Center icon on the desktop. The Software Selections CD includes the preloaded software and
ThinkPad device drivers for Windows 98, Windows 95, and Windows NT. You can customize your
computer with this CD. To use the Software Selections CD, insert it into the CD-ROM or DVD
drive. The main menu appears. Follow the instructions on the screen. For more information, click
Help in the menu.
Part Number: 27L8686
ThinkPad 770Z
User's Reference and Setup Guide Supplement
 Copyright IBM Corp. 1998

Updated Diskette Factory
Because of the new function in the Software Selections CD, the Diskette Factory no longer supports
all device drivers. You can see the supported software listed in the Diskette Factory main window.
New diskette name
The diskette name in the description of the Personalization Editor in the User's Reference has
changed from Utility Diskette for DOS to Personalization Data Update Diskette .
The Recovery CD
The Recovery CD is a startable CD-ROM and is not shipped with a boot diskette. The description
about using the Recovery CD with the boot diskette in the User's Reference no longer applies.
Asset ID icon
The “Config” menu of Easy-Setup includes an Asset ID icon ( ), for a new radio-frequency ID
option that is supported in specified models. More details are provided in the option's user's guide.
Docking your computer to a docking station
– If you use a SelectaDock I or SelectaDock II docking station, connect the power cord to a
docking station and the AC Adapter to a SelectaBase 770 port replicator.
– If you use a SelectaDock III docking station, connect the power cord to the docking station.
Notice for using the external monitor
If you use the Both LCD and CRT Display function, the external monitor must support the same
resolution as that of your ThinkPad LCD.
If you are using an external monitor that does not support the maximum resolution of the ThinkPad
LCD (1024 X 768 for the XGA model, or 800 X 600 for the SVGA model), do not use Both LCD
and CRT Display.
Notice for using the Compact Smart Card
Some Compact Smart Cards are too thick to be inserted into the upper PC Card slot of your
computer. Insert the card into the lower slot.
Solving computer problems
Docking station problems
The following troubleshooting might apply to users who are using the docking station—SelectaDock
I, II, III, or the Port Replicator with Advanced EtherJet Feature—under the Windows 95
environment.

Note: In the following steps, src_cd is the drive letter of the DVD or CD-ROM drive and cc is the
respective country code.
The following table shows the country code that you will need in the instructions:
Country Code Country Code Country Code
Denmark DK Italy IT Spain SP
Finland FI Japan JP Sweden SW
France FR Netherlands NL United
States US
Germany GR Norway NO
Problem Action
PC Cards in the docking
station cannot be recognized
after you warm-dock your
computer to the docking
station.
PC Card modems, SCSI
cards, ATA cards, 3Com
Combo Cards, or CardBus
Cards in the docking station
don't work after the computer
resumes from the power
management mode.
1. Start Windows 95.
2. Insert the Software Selections CD into the CD-ROM drive.
3. At the DOS prompt, type:
COPY src_cd:\DATA\WIN95\cc\W95UPD\PCI.VXD C:\WINDOWS\SYSTEM
and press Enter.
You are prompted if it is okay to overwrite the file.
4. Type Y and press Enter.
The system reboots when you
insert the PC Card into the
docking station.
1. Start Windows 95.
2. Insert the Software Selections CD into the CD-ROM drive.
3. Click Start and move the cursor to Program; then click on
Windows Explorer.
4. Click the driver letter of the DVD or CD-ROM drive.
5. Double-click PCMCIA.REG under DATA\WIN95\cc\W95UPD
6. Click OK.

Audio problem
Battery pack problem
Protection notice requirement
This device is protected by U.S. patent numbers 4631603, 4577216, 4819098, 4907093, and other
intellectual property rights. The use of Macrovision's copy protection technology in the device must
be authorized by Macrovision and is intended for home and other limited pay-per-view use only,
unless otherwise authorized in writing by Macrovision. Reverse engineering or disassembly is
prohibited.
Sound synchronization restriction
For some MPEG1 or MPEG2 files, the sound might not synchronize with the movie.
Problem Action
( Windows 95 or Windows 98
users: ) Wave or MIDI sound does
not play correctly.
Make sure that the built-in audio device is configured correctly:
1. Click Start.
2. Move the cursor to Program; then click Control Panel.
3. Double-click System.
4. Click the Device Manager tab.
5. Click the + mark by Sound, video and game controller.
6. Make sure all the following devices are enabled and configured
correctly:
Crystal PnP audio System CODEC
Crystal PnP audio System Control Registers
Crystal SoundFusion PCI Audio Accelerator
Crystal SoundFusion Virtual MPU-401
Problem Action
The battery pack cannot be
charged. The battery pack might not be able to charged when it is hot. In that case, remove it from the computer and leave it at room temperature for
a while. After it cools down, reinstall it and recharge it. If it cannot be
charged, have it serviced.
