IBM eServer 240 xSeries Product information sheet

User’s Reference
xSeries 240
®

Note
Before using this information and the product it supports, be sure to read the general information in Appendix B,
“Product warranties and notices” on page 179.
First Edition (October 2000)
Copyright International Business Machines Corporation 2000. All rights reserved.
Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject to
restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

Contents
Safety information statements ............................ v
Lithium battery notice ................................. vii
Laser compliance statements ............................. viii
About this book ..................................... ix
How this book is organized ............................... ix
Notices used in this book ................................ x
Chapter 1. Introducing the IBM xSeries 240 ................... 1
Features and specifications ............................... 2
What your server offers ................................. 4
Reliability, availability, and serviceability features .................. 6
Controls and indicators ................................. 7
Operator information panel .............................. 10
Input/output connectors and expansion slots .................... 11
Power supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 2. Arranging your workspace ...................... 17
Comfort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Glare and lighting .................................... 17
Air circulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Electrical outlets and cable lengths ......................... 18
Chapter 3. Configuring your server ....................... 19
Configuration overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
The Configuration/Setup Utility program ....................... 20
Using the Configuration/Setup Utility main menu .................. 21
Configuring options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Resolving configuration conflicts ........................... 30
Using the SCSISelect utility program ........................ 32
Configuring the Ethernet controller .......................... 35
Failover for redundant Ethernet ............................ 35
Chapter 4. Installing options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Before you begin .................................... 41
Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Working inside the server with power on ...................... 44
Handling static-sensitive devices ........................... 44
System reliability considerations ........................... 45
Preparing to install options .............................. 46
Working with adapters ................................. 53
Installing a microprocessor kit ............................ 62
Installing memory-module kits ............................ 65
Installing internal drives ................................ 67
Installing a hot-swap power supply .......................... 79
Removing a hot-swap power supply ......................... 81
Replacing a hot-swap fan assembly ......................... 83
Completing the installation .............................. 85
Connecting external options .............................. 90
Copyright IBM Corp. 2000 iii

Chapter 5. System board and processor board ................ 99
System-board component locations ......................... 99
System-board jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Processor-board component locations ....................... 101
Processor-board jumper and switches ....................... 102
Changing jumper positions ............................. 103
Chapter 6. Solving problems . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Diagnostic tools overview .............................. 107
Diagnostic programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Power-on self-test (POST) messages ....................... 112
Power-on self test (POST) beep codes ...................... 122
Recovering BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Diagnostic error message tables .......................... 125
Ethernet controller messages ............................ 136
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Resolving configuration conflicts .......................... 151
Identifying problems using status LEDs ...................... 151
Replacing the battery ................................ 157
Chapter 7. Getting help, service, and information .............. 161
Service support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Before you call for service .............................. 163
Getting customer support and service ....................... 163
Purchasing additional services ........................... 166
Ordering publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Appendix A. Installing a server in a rack enclosure ............ 171
Appendix B. Product warranties and notices ................ 179
Warranty Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Electronic emission notices ............................. 191
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
iv IBM xSeries User's Reference

Safety information statements
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Před instalací tohoto produktu si přečtěte příručku bezpečnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d'installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Pred inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy.
Antes de instalar este producto lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Copyright IBM Corp. 2000 v

1
DANGER
Electrical current from power, telephone, and communication
cables is hazardous.
To avoid a shock hazard:
– Do not connect or disconnect any cables or perform
installation, maintenance, or reconfiguration of this product
during an electrical storm.
– Connect all power cords to a properly wired and grounded
electrical outlet.
– Connect to properly wired outlets any equipment that will be
attached to this product.
– When possible, use one hand only to connect or disconnect
signal cables.
– Never turn on any equipment when there is evidence of fire,
water, or structural damage.
– Disconnect the attached power cords, telecommunications
systems, networks, and modems before you open the
device covers, unless instructed otherwise in the installation
and configuration procedures.
– Connect and disconnect cables as described in the
following table when installing, moving, or opening covers
on this product or attached devices.
To Connect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
To Disconnect:
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
vi IBM xSeries User's Reference

Lithium battery notice
2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354
or an equivalent type battery recommended by the manufacturer. If
your system has a module containing a lithium battery, replace it only
with the same module type made by the same manufacturer. The
battery contains lithium and can explode if not properly used, handled,
or disposed of.
Do not:
–Throw or immerse into water
–Heat to more than 100°C (212°F)
–Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Safety information statements vii

Laser compliance statements
Some server models are equipped from the factory with a CD-ROM drive.
CD-ROM drives are also sold separately as options. The CD-ROM drive is a laser
product. The CD-ROM drive is certified in the U.S. to conform to the requirements
of the Department of Health and Human Services 21 Code of Federal Regulations
(DHHS 21 CFR) Subchapter J for Class 1 laser products. Elsewhere, the drive is
certified to conform to the requirements of the International Electrotechnical
Commission (IEC) 825 and CENELEC EN 60 825 for Class 1 laser products.
3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic
devices, or transmitters) are installed, note the following:
–Do not remove the covers. Removing the covers of the laser
product could result in exposure to hazardous laser radiation.
There are no serviceable parts inside the device.
–Use of controls or adjustments or performance of procedures other
than those specified herein might result in hazardous radiation
exposure.
DANGER
Some laser products contain an embedded Class 3A or Class 3B
laser diode. Note the following.
Laser radiation when open. Do not stare into the beam, do not
view directly with optical instruments, and avoid direct exposure
to the beam.
viii IBM xSeries User's Reference

About this book
This book provides instructions for installing and removing server options and
configuring and troubleshooting your server. It also provides information to help
you solve problems if they occur.
How this book is organized
Chapter 1, “Introducing the IBM xSeries 240,”describes the xSeries 240 server
and provides an overview of the server's features.
Chapter 2, “Arranging your workspace,”provides information on arranging your
equipment and workspace.
Chapter 3, “Configuring your server,”describes how to use the Configuration/Setup
Utility program to configure your server. This chapter also provides instructions for
using various utility programs.
Chapter 4, “Installing options,”contains instructions for installing and removing
options, such as memory, adapters, and internal drives. Instructions for connecting
external options are also included in this chapter.
Chapter 5, “System board and processor board,”contains information about the
system board and processor board component, switch, and jumper locations. This
chapter also provides the instructions needed to change the jumper settings.
Chapter 6, “Solving problems,”includes an overview of the diagnostic tools,
instructions for testing the server, lists of error messages, and troubleshooting
charts.
Chapter 7, “Getting help, service, and information,”provides the telephone number
and World Wide Web listings that you can use to obtain product updates, help, or
service.
Appendix A, “Installing a server in a rack enclosure,”contains information about
installing rack models of the xSeries 240.
Appendix B, “Product warranties and notices,”contains warranty and emission
notices. This chapter also contains trademarks and general-information notices.
An index follows the appendix.
Copyright IBM Corp. 2000 ix

Notices used in this book
This book contains information notices that relate to a specific topic. The Caution
and Danger notices also appear in the multilingual Safety Information book
provided on the IBM xSeries Documentation CD. Each notice is numbered for easy
reference to the corresponding notices in the multilingual book. The notice
definitions are as follows:
Notes
These notices provide important tips, guidance, or advice.
Attention
These notices indicate possible damage to programs, devices, or data. An
attention notice is placed just before the instruction or situation in which
damage could occur.
Caution
These notices indicate situations that can be potentially hazardous to you. A
caution notice is placed just before a description of a potentially hazardous
procedure step or situation.
Danger
These notices indicate situations that can be potentially lethal or extremely
hazardous to you. A danger notice is placed just before a description of a
potentially lethal or extremely hazardous procedure step or situation.
xIBM xSeries User's Reference

Chapter 1. Introducing the IBM xSeries 240
Your IBMxSeries 240 is a high-performance, symmetric multiprocessing
(SMP) server. It is ideally suited for networking environments that require superior
microprocessor performance, efficient memory management, flexibility, and large
amounts of reliable data storage.
Performance, ease of use, reliability, and expansion capabilities were key
considerations during the design of your server. These design features make it
possible for you to customize the system hardware to meet your needs today, while
providing flexible expansion capabilities for the future.
Your server comes with a three-year limited warranty and IBM Server Start Up
Support. You can obtain up-to-date information about your xSeries 240 server and
other IBM server products at http://www.ibm.com/eserver/xseries on the World Wide
Web.
Your server serial number and model number are located on labels on the rear of
the server and on the front under the trim bezel. Write these numbers in the
spaces provided in your Installation Guide. You will need these numbers when you
register your server with IBM. After you register your server, you can receive
information about updates, performance tips, and compatibility. To register your
server, go to http://www.ibm.com/pc/register on the World Wide Web.
4
CAUTION:
Use safe practices when lifting.
18 kg (37 lbs) 32 kg (70.5 lbs) 55 kg (121.2 lbs)
Copyright IBM Corp. 2000 1

Features and specifications
The following table summarizes the features of the xSeries 240 server.
Table 1. Server features
Microprocessor
IntelPentiumIII microprocessor
with MMXtechnology and SIMD
extensions
32 KB of level-1 cache
256 KB of level-2 cache (min.)
Expandable to two microprocessors
Memory
Standard: 128 MB (min), expandable
to 4 GB
133 MHz, registered, error correcting
code (ECC), synchronous dynamic
random access memory (SDRAM)
(complying with PC 133 SDRAM
Registered DIMM Specification,
Revision 1.0 or later). When installed
in systems using 100 MHz front-side
bus microprocessors, the memory
operates at 100 MHz.
Four dual inline memory-module
(DIMM) sockets
Diskette Drive
Standard: One 3.5-inch, 1.44 MB
Hard Disk Drives
Up to six hot-swappable hard disk
drives supported
CD-ROM Drive
Standard: 40X IDE
Keyboard and Auxiliary Device
(standard only on tower models)
Keyboard
Mouse
Expansion Bays
Six slim (1-inch) or three half-high
(1.6-inch) hot-swap drive bays
Three 5.25-inch non-hot-swap bays
(one contains the CD-ROM drive)
Expansion Slots
Up to five PCI adapters supported.
Three 64-bit hot-plug PCI slots
Two standard (non-hot-plug) 32-bit
PCI slots
Upgradable Microcode
BIOS, diagnostics, and Advanced
System Management Processor
upgrades (when available) can
update EEPROMs on the system
board
Security Features
Door and side cover lock (tower
model only)
Power-on and administrator
passwords
Selectable drive-startup
Keyboard password
System management security
–User log-in password
–Read-only or read/write access
–Dial back
Predictive Failure Analysis(PFA)
Alerts
Power supplies
Fans
Memory
Hard disk drives
Microprocessors
Voltage regulator modules (VRMs)
Integrated Functions
Two serial ports
Two universal serial bus (USB) ports
One parallel port
Mouse port
Keyboard port
Video port
Advanced System Management
Interconnect port
Two SCSI ports (one internal, one
external)
10BASE-T/100BASE-TX Ethernet port
(controller on system board)
Redundant Ethernet capability,
through the use of an optional
network interface card (NIC)
Advanced System Management
Processor on system board
Dedicated Advanced System
Management I/O port
Video controller (with 4MB video
memory) compatible with:
–Super video graphics array
(SVGA)
–Video graphics adapter (VGA)
Power Supply
Two 250 W (115–230 V ac)
–Standard - 500 W non-redundant,
250 W redundant
–Optional - Additional 250 W
power supply is available for
500 W redundancy
Automatic voltage range selection
Built-in overload and surge protection
Automatic restart after a loss of
power
Redundant Cooling
Three hot-swap fans
2IBM xSeries User's Reference

The following table provides the specifications for the xSeries 240 server.
Table 2. Server specifications
Size (Tower Model)
–Depth: 659.3 mm (26 in.)
–Height: 426.5 mm (16.8 in.)
–Width: 217.3 mm (8.6 in.)
Size (Rack Model)
–Depth: 629.3 mm (24.8 in.)
–Height: 217.3 mm (8.6 in.)
(5 U)
–Width: 426.6 mm (16.8 in.)
Weight (Tower Model)
Minimum configuration: 26.6 kg
(58.6 lb)
Maximum configuration: 37.5 kg
(82.7 lb)
Weight (Rack Model)
Minimum configuration: 25.3 kg
(55.8 lb)
Maximum configuration: 36.2 kg
(79.8 lb)
Heat Output
Approximate heat output in British
Thermal Units (Btu) per hour:
–Minimum configuration:
683 Btu (200 watts)
–Maximum configuration:
2048 Btu (600 watts)
Electrical Input
Sine-wave input (50 to 60 Hz) is
required
Input voltage:
–Low range:
- Minimum: 90 V ac
- Maximum: 137 V ac
–High range:
- Minimum: 180 V ac
- Maximum: 265 V ac
–Input kilovolt-amperes (kVA)
approximately:
- Minimum configuration as
shipped: 0.08 kVA
- Maximum configuration:
0.52 kVA
Power Available for Drives
Each hot-swap drive bay:
–+5 V dc line: 15 A
–+12 V dc line: 17.2 A
Acoustical Noise Emissions Values
Sound power, idling: 6.6 bel
maximum
Sound power, operating: 6.8 bel
maximum
Sound pressure, operating: 67 dBa
maximum
Environment
Air temperature:
–Server on: 10°to 35°C
(50°to 95°F)
Altitude: 0 to 914 m (3000 ft.)
–Server on: 10°to 32°C
(50°to 90°F)
Altitude: 914 m (3000 ft.) to
2133 m (7000 ft.)
–Server off: 10°to 43°C
(50°to 110°F)
Maximum Altitude: 2133 m
(7000 ft.)
Humidity:
–Server on: 8% to 80%
–Server off: 8% to 80%
Maximum altitude: 2133 m
(7000 ft)
Chapter 1. Introducing the IBM xSeries 240 3

What your server offers
The unique design of your IBM xSeries 240 takes advantage of advancements in
symmetric multiprocessing (SMP), data storage, and memory management. Your
server combines:
Impressive performance using an innovative approach to SMP
Your server supports up to two Pentium III microprocessors. Your server
comes with one microprocessor installed; you can install an additional
microprocessor to enhance performance and provide SMP capability.
Large data-storage and hot-swap capabilities
All models of the server support up to six hot-swap hard disk drives. This
hot-swap feature enables you to remove and replace hard disk drives without
turning off the server.
Hot-plug PCI adapter capabilities
Your server has three hot-plug slots for PCI adapters. This feature is
sometimes referred to as Active PCI. With operating system support, you can
replace failing hot-plug PCI adapters without turning off the server. If the
hot-add feature is supported by your operating system and the PCI adapter,
you can also add PCI adapters in these slots without turning off the server.
Redundant cooling and power capabilities
The redundant cooling and hot-swap capabilities of the fans in your server
allow continued operation if one of the fans fails. You can also replace a failing
fan without turning off the server.
The two 250-watt power supplies in your server provide redundant power for
many configurations of your server. If the average load on your server is less
than 250 watts and a problem occurs with one of the power supplies, the other
power supply can handle the load. For power loads above 250 watts, you can
install a third, optional power supply to provide a full 500 watts of power. The
NON REDUNDANT light emitting diode (LED) on the diagnostic LED panel is lit
when the power load is 250 watts or greater with two power supplies installed.
Large system memory
The memory bus in your server supports up to 4GB of system memory. The
memory controller provides error correcting code (ECC) support for up to four
industry-standard PC133, 3.3 V, 168-pin, 8-byte, registered,
synchronous-dynamic-random access memory (SDRAM) DIMMs (Intel
PC-Registered SDIMM Specifications, Revision 1.0 or later), synchronous, dual
inline memory modules.
4IBM xSeries User's Reference

System-management capabilities
Your server comes with an Advanced System Management Processor on the
system board. This processor, in conjunction with the systems-management
software provided with your server, allows you to manage the functions of the
server locally and remotely. The Advanced System Management Processor
also provides system monitoring, event recording, and dial-out alert capability.
Note: The Advanced System Management Processor is sometimes referred to
as the service processor.
Refer to the information provided with the systems-management software for
more information.
Integrated network environment support
Your server comes with an Ethernet controller on the system board. This
Ethernet controller has an interface for connecting to 10-Mbps or 100-Mbps
networks. The server automatically selects between 10BASE-T and
100BASE-TX. The controller provides full-duplex (FDX) capability, which allows
simultaneous transmission and reception of data on the Ethernet local area
network (LAN).
Redundant network-interface card
The addition of an optional, redundant network interface card (NIC) provides a
failover capability to a redundant Ethernet connection. If a problem occurs with
the primary Ethernet connection, all Ethernet traffic associated with this primary
connection is automatically switched to the redundant NIC. This switching
occurs without data loss and without user intervention.
IBM ServerGuide CDs
The ServerGuideCDs included with your server provide programs to help you
set up your server and install the network operating system (NOS). The
ServerGuide program detects the hardware options installed and provides the
correct configuration program and device drivers. For more information, see
the ServerGuide topic provided on the IBM xSeries Documentation CD.
Your server is designed to be cost-effective, powerful, and flexible. It uses
peripheral component interconnect (PCI) bus architecture to provide compatibility
with a wide range of existing hardware devices and software applications.
As always, your IBM server meets stringent worldwide certifications for power,
electromagnetic compatibility (EMC), and safety.
Chapter 1. Introducing the IBM xSeries 240 5

Reliability, availability, and serviceability features
Three of the most important features in server design are reliability, availability, and
serviceability (RAS). These factors help to ensure the integrity of the data stored
on your server; that your server is available when you want to use it; and that
should a failure occur, you can easily diagnose and repair the failure with minimal
inconvenience.
The following is an abbreviated list of the RAS features that your server supports.
Menu-driven setup, system configuration, RAID configuration, and diagnostic
programs
Power-on self-test (POST)
Integrated Advanced System Management Processor
Predictive failure alerts
System auto-configuring from configuration menu
Remote system problem-determination support
Power and temperature monitoring
Fault-resilient startup
Hot-swap drive bays
Support for hot-plug PCI adapters
Error codes and messages
System error logging
Upgradable BIOS, diagnostics, and Advanced System Management Processor
code
Automatic restart after a power failure
Parity checking on the SCSI and PCI buses
Error checking and correcting (ECC) memory
Redundant hot-swap power supply option
Redundant hot-swap cooling
Redundant Ethernet capabilities (with optional adapter)
Vital Product Data (VPD) on processor complex, system board, power
backplane, SCSI backplane, and each power supply.
Operator information and diagnostic LED panels
Customer support center 24 hours per day 7 days a week1
Remote Connect
Light Path Diagnostics
1Service availability will vary by country. Response time will vary depending on the number and nature of incoming calls.
6IBM xSeries User's Reference

Controls and indicators
The most commonly used controls and indicators on the front of the server appear
in the following illustrations.
Tower model
Rack model
Chapter 1. Introducing the IBM xSeries 240 7

1 Operator Information Panel: The lights on this panel provide status
information for your server. See “Operator information panel”on page 10 for
more information.
2 Diskette-Eject Button: Press this button to eject a diskette from the drive.
3 Diskette Drive In-Use Light: When this light is on, the diskette drive is being
accessed.
4 CD-ROM Eject/Load Button: Press this button to eject or retract the
CD-ROM tray so that you can insert or remove a CD.
5 Hard Disk Status Light: Each of the hot-swap drive bays has a Hard Disk
Status light. When this amber light is on continuously, the drive has failed.
When the light flashes slowly (one flash per second), the drive is being rebuilt.
When the light flashes rapidly (three flashes per second), the controller is
identifying the drive.
6 Hard Disk Activity Light: Each of the hot-swap drive bays has a Hard Disk
Activity light. When this green light is flashing, the drive is being accessed.
7 Cover Release Lever: Use this lever to release the left-side cover on the
tower model or the top cover on the rack model.
8 Reset Button: Press this button to reset the server and run the power-on
self-test (POST).
9 Power Control Button: Press this button to manually turn the server on or
off. (See “Turning on the server”on page 9 and “Turning off the server”on
page 9 for more information.)
1 CD-ROM Drive In-Use Light: When this light is on, the CD-ROM drive is
being accessed.
11 CD-ROM Manual Tray-Release Opening: Insert a straightened paper clip in
the opening to release the CD-ROM tray when using the CD-ROM eject
button is not successful.
8IBM xSeries User's Reference

Turning on the server
Use the following instructions to turn on the server.
You can turn on the server by pressing the Power Control button on the front of
the server.
Note: If you have just plugged the power cord of your server into an electrical
outlet, wait approximately 20 seconds before pressing the Power
Control button.
If the server is turned on and a power failure occurs, the server will start
automatically when power is restored.
The Advanced System Management Processor can also turn on the server.
Turning off the server
Use the following instructions to turn off the server.
5
CAUTION:
The power control button on the device and the power switch on the
power supply do not turn off the electrical current supplied to the
device. The device also might have more than one power cord. To
remove all electrical current from the device, ensure that all power
cords are disconnected from the power source.
1
2
You can turn off the server by pressing the Power Control button on the front of
the server. Pressing the Power Control button starts an orderly shutdown of
the operating system, if this feature is supported by your operating system, and
places the server in standby mode.
Note: After turning off the server, wait at least 5 seconds before pressing the
Power Control button to power the server on again.
You can press and hold the Power Control button for more than 4 seconds to
cause an immediate shutdown of the server and place the server in standby
mode. This feature can be used if the operating system halts.
You can disconnect the server power cords from the electrical outlets to shut
off all power to the server.
Note: Wait about 15 seconds after disconnecting the power cords for your
system to stop running. Watch for the System Power light on the
operator information panel to stop blinking.
Chapter 1. Introducing the IBM xSeries 240 9

Operator information panel
The operator information panel on the front of the server contains status lights.
100
MB LINK
OK TX
RX
OK 1 2
1 System Power Light: When this green light is on, system power is present
in the server. When this light flashes, the server is in standby mode (the
system power supply is turned off and ac current is present). When this light
is off, either a power supply, ac power, or a light has failed.
Attention: If this light is off, it does not mean there is no electrical current
present in the server. The light might be burned out. To remove all electrical
current from the server, you must unplug the server power cords from the
electrical outlets.
2 System POST Complete Light: This green light is on when the power-on
self-test (POST) completes without any errors.
3 SCSI Hard Disk Drive Activity Light: This green light is on when there is
activity on a hard disk drive.
4 Processor 1 Activity Light: This green light is on when there is
microprocessor 1 activity.
5 Processor 2 Activity Light: This green light is on when there is
microprocessor 2 activity.
6 Information Light: This amber light is on when the information log contains
information about certain conditions in your server that might affect
performance. For example, the light will be on if your server does not have
redundant power. A light on the diagnostic LED panel will also be on. (For
more information, see “Identifying problems using status LEDs”on page 151.)
7 System Error Light: This amber light is on when a system error occurs. A
light on the diagnostic LED panel will also be on to further isolate the error.
(For more information, see “Identifying problems using status LEDs”on
page 151.)
8 Ethernet Transmit/Receive Activity Light: When this green light is on,
there is transmit or receive activity to or from the server.
9 Ethernet Link Status Light: When this green light is on, there is an active
connection on the Ethernet port.
1 Ethernet Speed 100 Mbps Light: When this green light is on, the Ethernet
speed is 100 Mbps. When the light is off, the Ethernet speed is 10 Mbps.
10 IBM xSeries User's Reference
