IBM eServer 330 xSeries User manual

Welcome. . .
Thank you for buying an
IBM xSeries server.
This server
contains information for setting
up and configuring your server.
For detailed information
about your server, view the
on the
You can also find the most
current information about your
server on the IBM Web site at:
http://www.ibm.com/pc/support
Installation Guide
User's Reference
Documentation CD.
Go to the Server Support
flow chart
Cable the server
and options
Start the server
Install options:
• Drives
• Microprocessors
• Adapters
• Memory
Did the server
start correctly?
Yes
No
Use ServerGuide™
to setup and
configure hardware
Did configuration
complete?
Use
ServerGuide to
install operating
system?
Use ServerGuide to
install applications,
such as IBM systems
management software
and IBM ServeRAID
programs
System is ready to use.
Go to the Server Support
flow chart to register
and profile your server.
Go to the Web for Instructions,
http://www.ibm.com/pc/support
No
Yes
Yes
No
Installation Guide
Install the server in
the rack, if required
xSeries 330
Type 8674
®

Server Support
After you register and profile, you will be able to:
•Diagnose problems using the IBM Online Assistant
•Participate in the IBM discussion forum
•Receive e-mail notifications of technical updates
related to your profiled products
Register at:
Profile at: http://www.ibm.com/pc/register http://www.ibm.com/pc/support
Register and profile your server
Yes
No
No
Phone an
IBM HelpCenter
Use the troubleshooting
information provided with
your server to determine
the cause of the problem
and the action to take.
Flash the latest levels of BIOS,
service processor, diagnostics,
and RAID code.
You can download this code at:
http://www.ibm.com/pc/support
No
No
Yes
Yes
Yes
Check all cables for loose connections
and verify that all optional devices you
installed are on the ServerProven list.
You can view the ServerProven list at:
®
http://www.ibm.com/pc/compat
Server working
properly?
Problem
solved?
Problem
solved?
Problem
solved?
You can view the HelpCenter phone
numbers in the Support Phone List at:
http://www.ibm.com/pc/support

IBM
IBM® xSeries 330
Installation Guide
SC06-P455-80

Before using this information and the product it supports, be sure to read the general information in
Appendix 1, “Product warranty and notices,” on page 45.
Note:
First Edition (August 2001)
© Copyright International Business Machines Corporation 2001. All rights reserved.
US Government Users Restricted Rights –Use, duplication or disclosure restricted by GSA ADP Schedule Contract with
IBM Corp.

© Copyright IBM Corp. 2001 iii
Contents
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Chapter 1.Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features and specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Notices and statements used in this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Before you begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Handling static-sensitive devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Major components of the xSeries 330 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2.Installing options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Removing the cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Working with adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Adapter considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing an adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Working with memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Memory considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing memory modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Working with hard disk drives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Hard disk drive considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing a hard disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Working with microprocessors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing the cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Working with cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cabling the RS-485 ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting the servers with a C2T chain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cable management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 3.Server power, controls, and indicators. . . . . . . . . . . . . . . . . . . . . . . . 21
Turning on the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Turning off the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Server controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Chapter 4.Configuring your server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Starting the utility programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using the Configuration/Setup Utility program . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using the SCSISelect Utility program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using the PXE Boot Agent Utility program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Using the ServerGuide CDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Using the System Updates and Applications CD . . . . . . . . . . . . . . . . . . . . . . . . . 27
Updating and configuring the ASM processor . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 5.Solving problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Diagnostic tools overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
POST beep code descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
POST error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
ServerGuide startup problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Troubleshooting charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Getting information, help, and service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Getting information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Getting help and service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Purchasing additional services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

iv IBM®xSeries 330: Installation Guide
Chapter 1.Product warranty and notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Warranty information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Warranty period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
IBM Statement of Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Edition notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Processing date data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Electronic emission notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Power cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

© Copyright IBM Corp. 2001 v
Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d'installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Pred instalacítohoto produktu si prectete prírucku bezpecnostních instrukcí.

vi IBM®xSeries 330: Installation Guide
Antes de instalar este producto lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Statement 1
DANGER
To connect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
To disconnect:
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
Electrical current from power, telephone, and communication cables is
hazardous. To avoid a shock hazard:
• Do not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical
storm.
• Connect all power cords to a properly wired and grounded electrical
outlet.
• Connect to properly wired outlets any equipment that will be attached
to this product.
• When possible, use one hand only to connect or disconnect signal
cables.
• Never turn on any equipment when there is evidence of fire, water, or
structural damage.
• Disconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
• Connect and disconnect cables as described in the following table
when installing, moving, or opening covers on this product or
attached devices.

vii
Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
a module containing a lithium battery, replace it only with the same module type
made by the same manufacturer. The battery contains lithium and can explode
if not properly used, handled, or disposed of.
Do not:
•Throw or immerse into water.
•Heat to more than 100 C (212 F)
•Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
•Do not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
•Use of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.

viii IBM®xSeries 330: Installation Guide
DANGER
Statement 4
CAUTION:
Use safe practices when lifting.
Statement 5
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current
from the device, ensure that all power cords are disconnected from the power
source.
≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs)
Some laser products contain an embedded Class 3A or Class 3B laser
diode. Note the following. Laser radiation when open. Do not stare into
the beam, do not view directly with optical instruments, and avoid direct
exposure to the beam.
Class 1 Laser Product
Laser Klasse 1
Laser Klass 1
Luokan 1 Laserlaite
Appareil A Laser de Classe
1
`

ix
Statement 8
CAUTION:
Never remove the cover on a power supply or any part that has the following
label attached.
Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect a problem with one of these parts, contact a
service technician.
1
2

x IBM®xSeries 330: Installation Guide

© Copyright IBM Corp. 2001 1
Chapter 1. Introduction
Thank you for purchasing an IBM® xSeries 330. This Installation Guide
provides the information that is needed to:
•Set up and cable your server
•Start and configure your server
•Install your network operating system (NOS)
Packaged with the Installation Guide are software CDs that help you to configure
hardware, install device drivers, and install the network operating system.
Also included is an IBM xSeries Documentation CD, which provides detailed
information about your server.
If you have access to the World Wide Web, you can obtain up-to-date information
about your xSeries 330 server and other IBM server products at
http://www.ibm.com/eserver/xseries.
The machine type and serial number are located on the ID label located on the right
edge of the bezel on the server as shown in the following illustration. You will need
these numbers when you register your server with IBM.
Note: The illustrations in this document might differ slightly from your hardware.
Record your product information in this table.
Product name _________________________________________________
Machine type _________________________________________________
Model number _________________________________________________
Serial number _________________________________________________
ID label

2 IBM®xSeries 330: Installation Guide
Features and specifications
The following table provides a summary of the features and specifications for your
server.
Table 1. Features and Specifications.
Microprocessor:
•Intel®Pentium®III
microprocessor with MMX™
technology and SIMD
extensions
•133 MHz Front-Side Bus (FSB)
•512 KB Level-2 cache
•Supports up to two
microprocessors
Memory:
•Standard: 256 MB
•Maximum: 4 GB
•Type: 133 MHz, ECC, SDRAM,
registered DIMMs
•Slots: Four dual inline
Drives standard:
•Diskette: 1.44 MB
•CD-ROM: 24X IDE
Expansion bays:
Two 3.5-inch slim high bays for hard
disk drives
PCI expansion slots:
Two 33 MHz/64-bit
Power supply:
One 200 watt (115-230 V ac)
Video:
•S3 Savage4 PRO
Graphics/Video Accelerator
(integrated on system board)
•Compatible with SVGA
•8 MB SDRAM video memory
Size
•Height 43.69 mm (1.72 in.)
•Depth: 653.29 mm (25.72 in.)
•Width: 439.93 mm (17.32 in.)
•Weight: approximately 12.7 kg
(28 lb) when fully configured
Integrated functions:
•Advanced System Management
(ASM) processor with support for
IBM Remote Supervisor adapter
•One Ultra160 SCSI controller
•Two 10BASE-T/100BASE-TX
Intel Ethernet controllers with
Wake on LAN™(WOL) support
•Two Universal Serial Bus (USB)
ports
•Two RS-485 Advanced System
Management processor ports
(one In, one Out)
•One serial port
•Two cable chaining technology
(C2T) ports (one In, one Out)
Acoustical noise emissions:
•Sound power, idling: 6.1 bel
maximum
•Sound power, operating: 6.1 bel
maximum
•Sound pressure, idling: 47
decibels
•Sound pressure, operating: 47
decibels
Environment:
•Air temperature:
—Server on: 10°to 35°C (50.0°
to 95.0°F). Altitude: 0 to 914
m (2998.7 ft)
—Server on: 10°to 32°C (50.0°
to 89.6°F). Altitude: 914 m
(2998.7 ft.) to 2133 m (6998.0
ft)
—Server off: 10°to 43°C (50.0°
to 109.4°F). Maximum
altitude: 2133 m (6998.0 ft)
•Humidity:
—Server on: 8% to 80%
—Server off: 8% to 80%
Heat output:
Approximate heat output in British
thermal units (Btu) per hour
•Minimum configuration: 273 Btu
(80 watts)
•Maximum configuration: 751 Btu
(220 watts)
Electrical input:
•Sine-wave input (50-60 Hz)
required
•Input voltage low range:
—Minimum: 100 V ac
—Maximum: 127 V ac
•Input voltage high range:
—Minimum: 200 V ac
—Maximum: 240 V ac
•Input kilovolt-amperes (kVA)
approximately:
—Minimum: 0.08 kVA
—Maximum: 0.22 kVA

Chapter 1. Introduction 3
Notices and statements used in this book
This information product contains notices and statements that relate to a specific
topic. The Caution and Danger statements also appear in the multilingual safety
information provided with your product. Each safety statement is numbered for easy
reference to the corresponding statements in the safety information on the IBM
xSeries 330 Documentation CD.
The notice and statements definitions are as follows:
•Notes: These notices provide important tips, guidance, or advice.
•Important: These notices provide information or advice that might help you avoid
inconvenient or problem situations.
•Attention: These notices indicate possible damage to programs, devices, or
data. An attention statement is placed just before the instruction or situation in
which damage could occur.
•Caution: These statements indicate situations that can be potentially hazardous
to you. A caution statement is placed just before the description of a potentially
hazardous procedure step or situation.
•Danger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
Before you begin
Before you begin to install options in your server, read the following information:
•Become familiar with the information provided in “Safety”on page v and “Handling
static-sensitive devices”. These guidelines will help you work safely while
working with your server options.
•Make sure that you have an adequate number of properly grounded electrical
outlets for your server, monitor, and any other options that you intend to install.
•Back up all important data before you make changes to disk drives.
•For a list of supported options for the xSeries 330, refer to
http://www.ibm.com/pc/compat on the World Wide Web.
Handling static-sensitive devices
Attention: Static electricity can damage electronic devices and your system. To
avoid damage, keep static-sensitive devices in their static-protective package until
you are ready to install them.
To reduce the possibility of electrostatic discharge, observe the following precautions:
•Limit your movement. Movement can cause static electricity to build up around
you.
•Handle the device carefully, holding it by its edges or its frame
•Do not touch solder joints, pins, or exposed printed circuitry.
•Do not leave the device where others can handle and possibly damage the
device.

4 IBM®xSeries 330: Installation Guide
•While the device is still in its static-protective package, touch it to an unpainted
metal part of the system unit for at least two seconds. (This drains static electricity
from the package and from your body.)
•Remove the device from its package and install it directly into your system unit
without setting it down. If it is necessary to set the device down, place it in its
static-protective package. Do not place the device on your system unit cover or
on a metal table.
•Take additional care when handling devices during cold weather; heating reduces
indoor humidity and increases static electricity.
Major components of the xSeries 330
The following illustration shows the locations of major components in your server.
Microprocessor
Terminator card
Fans
Hard disk driv
e
filler panel
Hard disk drive
Memory module
Air baffle
Light Path
Diagnostics panel
Clear shield
Heatsink
Clip

© Copyright IBM Corp. 2001 5
Chapter 2. Installing options
This chapter provides basic information that is needed to install hardware options in
your server. For more detailed installation information, see the User’s Reference on
the IBM xSeries Documentation CD.
Removing the cover
Use the following procedure to remove the cover.
1. Review the safety precautions beginning on page v.
2. Turn off the server and peripheral devices and disconnect all external cables and
power cords.
3. Remove the two screws on the rear of the server.
4. Pull the cover-release lever back.
5. Slide the cover off the server.
Note: You might need to remove the clear plastic shield to reach some parts in the
server. For proper cooling and airflow, replace the clear plastic shield before
replacing the cover.
Attention: For proper cooling and airflow, replace the cover before turning on the
server. Operating the server for extended periods of time (over 30 minutes) with the
cover removed might damage server components.
Working with adapters
Your server comes with two peripheral component interconnect (PCI) adapter slots on
the system board with riser cards installed in them.
Attention: Your server comes with an integrated video controller on the system
board. When you install a video adapter in a PCI slot, the server BIOS automatically
disables the integrated video controller. This enables the video adapter in the PCI slot
to control the video functions for your monitor.
Cover-release
lever Screws

6 IBM®xSeries 330: Installation Guide
The following illustration shows the location of the 33 MHz PCI expansion slots on the
system board.
Adapter considerations
Before you install adapters, review the following:
•Locate the documentation that comes with the adapter and follow those
instructions in addition to the instructions in this chapter. If you need to change the
switch settings or jumper settings on your adapter, follow the instructions that
come with the adapter.
•You can install 32-bit or 64-bit full-length or half-length adapters in the expansion
slots. Full-length adapters are installed in slot 1; half-length adapters are installed
in either slot 1 or 2.
•Your server supports 5.0 V and universal PCI adapters; it does not support 3.3 V
only adapters.
•Your server uses a rotational interrupt technique to configure PCI adapters. You
can use this technique to install PCI adapters that currently do not support
sharing of PCI interrupts.
•PCI slots 1 and 2 and the integrated SCSI controller are on PCI bus B; the system
board and all other integrated devices are on PCI bus A.
Note: PCI bus A is bus 0; PCI bus B is bus 1.
•The system scans PCI slots 1 and 2 to assign system resources. By default, the
system starts (boots) devices in the following order: system IDE and SCSI
devices, then PCI devices.
Note: To change the startup order, start the Configuration/Setup Utility program,
and select Start Options from the main menu. Then, select the PCI SCSI
adapter boot option.
PCI slot 1
64 bit
33 MHz (J10)
PCI slot 2
64 bit
33 MHz (J23)

Chapter 2. Installing options 7
Installing an adapter
Complete the following steps to install an adapter:
Attention: When you handle static-sensitive devices, take precautions to avoid
damage from static electricity. For details on handling these devices, see “Handling
static-sensitive devices”on page 3.
1. Review the safety precautions beginning on page v.
2. Turn off the server and peripheral devices.
3. Remove all external cables from the server; then, remove the server cover. For
detailed instructions to remove the cover, see “Removing the cover”on page 5.
4. Remove the expansion slot clip that holds the expansion-slot cover in place by
sliding it upward and off the frame of the server.
5. Remove the expansion-slot cover.
6. See the documentation that comes with your adapter for any cabling instructions
for internal cables.
Notes:
a. Route internal adapter cables before you install the adapter.
b. If you are installing a ServeRAID adapter and want it to control the internal
hard disk drive, remove the cable from the SCSI connector (J4) on the system
board and attach it to the ServeRAID adapter.
7. Set any jumpers or switches as described by the adapter manufacturer.
Retention
latch Tab
Adapter
Expansion
slot cover
Expansion
slot clip
Expansion
slot

8 IBM®xSeries 330: Installation Guide
8. Install the adapter:
a. Open the adapter-retention latch by pushing the blue tab to release it. Then,
push the latch up to the full open position.
b. Carefully grasp the adapter by its top edge or upper corners, and align it with
the connector on the PCI riser card.
c. Press the adapter firmly into the riser-card connector.
Attention: When you install an adapter, be sure that the adapter is correctly
seated in the riser-card connector before you turn on the server. Improperly
seated adapters might cause damage to the system board, the riser card, or
the adapter.
d. Push down on the blue adapter-retention latch until it clicks into place,
securing the adapter.
e. Replace the expansion-slot clip by sliding it down until it latches into place
and holds the adapter securely.
9. Connect the internal cables to the adapter.
Attention: Route cables so that they do not block the flow of air from the fans.
10. If you have other options to install, install them now. Otherwise, continue with
“Installing the cover”on page 14.
Working with memory
Your xSeries 330 supports 128 MB, 256 MB, 512 MB, and 1 GB DIMMs. See the
ServerProven list at http://www.ibm.com/pc/compat for a list of memory modules for
use with your server.
SCSI connector
(J4)
Extra cable
length
ServeRAID
adapter
