IBM Flex System x240 M5 Product Guide
Lenovo Product Guide
The IBM® Flex System™ x240 M5 Compute Node is a high-performance server that offers new security,
efficiency, and reliability features to handle business-critical workloads. The blade server is based on the
Intel Xeon E5-2600 v3 processors. It features up to 18 cores and uses new IBM TruDDR4 Memory, which
runs at speeds up to 2133 MHz.
Suggested uses: Database, virtualization, enterprise applications, collaboration and email, streaming
media, web, HPC, and cloud applications.
Figure 1 shows the IBM Flex System x240 M5 Compute Node.
Figure 1. The IBM Flex System x240 M5 Compute Node
Did you know?
The x240 M5 Compute Node uses IBM TruDDR4 Memory DIMM technology, which offers higher clock
speeds, faster data transfer rates, and runs at a lower voltage (1.2V). With DDR4 technology, memory
DIMMs can now operate at speeds up to 2133 MHz, which provides lower latency times and enhanced
computing power. The TruDDR4 Memory portfolio includes RDIMMs with advanced error correction for
reliability, performance, and maximum memory capacity. In addition, TruDDR4 Memory supports memory
performance that exceeds industry standards.
The x240 M5 Compute Node integrates leadership security and reliability. System x Trusted Platform
Assurance, an exclusive set of System x features and practices, establishes a foolproof security
foundation for your workloads. Enterprise-class data protection is provided with optional self-encrypting
drives and simple, centralized key management through IBM Security Key Lifecycle Management.
Diagnostic tools facilitate reduced downtime and costs.

IBM Flex System x240 M5 Product Guide 2
Key features
The IBM Flex System x240 M5 Compute Node is a high-availability, scalable compute node that is
optimized to support the next-generation microprocessor technology. It is ideally suited for medium and
large businesses. This section describes the key features of the server.
Scalability and performance
The x240 M5 offers the following features to boost performance, improve scalability, and reduce costs:
Improves productivity by offering superior system performance with up to 18-core processors, up to

45 MB of L3 cache, and up to 9.6 GT/s QPI interconnect links.
Supports up to two processors, 36 cores, and 72 threads, which maximizes the concurrent execution

of multi-threaded applications.
Intelligent and adaptive system performance with energy efficient Intel Turbo Boost Technology

allows CPU cores to run at maximum speeds during peak workloads by temporarily going beyond
processor thermal design power (TDP).
Intel Hyper-Threading Technology boosts performance for multithreaded applications by enabling

simultaneous multithreading within each processor core, up to two threads per core.
Intel Virtualization Technology integrates hardware-level virtualization hooks that allow operating

system vendors to better use the hardware for virtualization workloads.
Intel Advanced Vector Extensions 2.0 (AVX 2.0) enable acceleration of enterprise-class workloads,

such as databases and enterprise resource planning.
Up to 2133 MHz memory speeds with two DIMMs per channel that are running at 2133 MHz to help

maximize system performance.
Up to 1.5 TB of memory capacity with 64 GB load-reduced DIMMs, or LRDIMMs (support for 64 GB

LRDIMMs is planned for a later date).
Optional support for high-performance PCIe-attached NVMe Flash Storage solid-state drives (SSDs)

can significantly improve I/O performance.
Supports the Storage Expansion Node, which provides another 12 hot-swap, 2.5-inch drive bays for

local storage.
Up to 16 virtual I/O ports per compute node with available 10 Gb Virtual Fabric Adapters, which offers

the choice of Ethernet, Fibre Channel, iSCSI, or Fibre Channel over Ethernet (FCoE) connectivity.
The x240 M5 offers PCI Express 3.0 I/O expansion capabilities that improve the theoretical maximum

bandwidth by 60% (8 GT/s per link), compared with the previous generation of PCI Express 2.0.
With Intel Integrated I/O Technology, the PCI Express 3.0 controller is integrated into the Intel Xeon

processor E5 family. This integration helps to dramatically reduce I/O latency and increase overall
system performance.
Support for high-bandwidth I/O adapters, up to two in each x240 M5 Compute Node.

Support for 10 Gb Ethernet, 16 Gb Fibre Channel, and FDR InfiniBand.

Supports the PCIe Expansion Node for support for up to six more I/O adapters.

High-speed USB 3.0 port for connectivity to external devices.


IBM Flex System x240 M5 Product Guide 3
Availability and serviceability
The x240 M5 provides the following features to simplify serviceability and increase system up-time:
Chipkill, memory mirroring, and memory rank sparing for redundancy if there is a non-correctable

memory failure.
Tool-less cover removal provides easy access to upgrades and serviceable parts, such as CPU,

memory, and adapter cards.
Hot-swap drives support integrated RAID 1 redundancy for data protection and greater system

up-time.
A light path diagnostics panel and individual light path LEDs to quickly lead the technician to failed (or

failing) components. This feature simplifies servicing, speeds up problem resolution, and helps
improve system availability.
Predictive Failure Analysis (PFA), which detects when system components (such as processors,

memory, and hard disk drives) operate outside of standard thresholds and generates pro-active alerts
in advance of possible failure, which increases uptime.
Solid-state drives (SSDs), which offer significantly better reliability than traditional mechanical HDDs

for greater uptime.
Built-in Integrated Management Module II (IMM2) continuously monitors system parameters, triggers

alerts, and performs recovering actions if there is a failure to minimize downtime.
Built-in diagnostics that uses Dynamic Systems Analysis (DSA) Preboot speeds up troubleshooting

tasks to reduce service time.
Three-year customer replaceable unit and on-site limited warranty; next business day 9x5. Optional

service upgrades are available.
Manageability and security
The following powerful systems management features simplify the local and remote management of the
x240 M5:
The x240 M5 includes an IMM2 to monitor server availability and perform remote management.

Integrated industry-standard Unified Extensible Firmware Interface (UEFI) enables improved setup,

configuration, and updates, and simplifies error handling.
Integrated Trusted Platform Module (TPM) 1.2 support enables advanced cryptographic functionality,

such as digital signatures and remote attestation.
System x Trusted Platform Assurance, an exclusive set of System x security features and practices,

establishes a foolproof security foundation for workloads by delivering firmware that is securely built,
tested, digitally signed, and verified before execution.
The server offers enterprise-class data protection with optional self-encrypting drives and simple,

centralized key management through IBM Security Key Lifecycle Management.
Industry-standard AES NI support for faster, stronger encryption.

Integrates with the IBM® Flex System™ Manager for proactive systems management. It offers

comprehensive systems management for the entire IBM Flex System platform that helps to increase
up-time, reduce costs, and improve productivity through advanced server management capabilities.
IBM Fabric Manager simplifies deployment of infrastructure connections by managing network and

storage address assignments.

IBM Flex System x240 M5 Product Guide 4
Intel Execute Disable Bit functionality can help prevent certain classes of malicious buffer overflow

attacks when combined with a supporting operating system.
Intel Trusted Execution Technology provides enhanced security through hardware-based resistance

to malicious software attacks, which allows an application to run in its own isolated space that is
protected from all other software that is running on a system.
Energy efficiency
The x240 M5 offers the following energy-efficiency features to save energy, reduce operational costs,
increase energy availability, and contribute to the green environment:
Component-sharing design of the IBM Flex System chassis provides ultimate power and cooling

savings.
The Intel Xeon processor E5-2600 v3 product family offers significantly better performance over the

E5-2600 v2 family while fitting into the same thermal design power (TDP) limits.
Intel Intelligent Power Capability powers individual processor elements on and off as needed, which

reduces power draw.
Low-voltage Intel Xeon processors draw less energy to satisfy demands of power and thermally

constrained data centers and telecommunication environments.
Low-voltage 1.2 V DDR4 memory DIMMs use up to 20% less energy compared to 1.35 V DDR3

DIMMs.
Solid state drives (SSDs) use as much as 80% less power than traditional spinning 2.5-inch HDDs.

The x240 M5 uses hexagonal ventilation holes, which are a part of IBM Calibrated Vectored Cooling™

technology. Hexagonal holes can be grouped more densely than round holes, which provides more
efficient airflow through the system.

IBM Flex System x240 M5 Product Guide 5
Locations of key components and connectors
Figure 2 shows the front of the server.
Figure 2. Front view of the IBM Flex System x240 M5 Compute Node
Figure 3 shows the locations of key components inside the server.
Figure 3. Inside view of the IBM Flex System x240 M5 Compute Node

IBM Flex System x240 M5 Product Guide 6
Standard specifications
The following table lists the standard specifications.
Table 1. Standard specifications (part 1)
Components Specification
Models 9532-x2x, 9532-x4x, 9532-x6x
Form factor Standard-width compute node.
Chassis support IBM Flex System Enterprise Chassis.
Processor Up to two Intel Xeon processor E5-2600 v3 product family CPUs with 18 cores (2.3 GHz), 16
cores (2.3 GHz), 14 cores (up to 2.6 GHz), 12 cores (up to 2.6 GHz) or 10 cores (up to 2.6
GHz), 8 cores (up to 3.2 GHz), 6 cores (up to 3.4 GHz), or up to 4 cores (up to 3.5 GHz). Two
QPI links up to 9.6 GTps each. Up to 2133 MHz memory speed. Up to 45 MB L3 cache.
Chipset Intel C612
Memory Up to 24 DIMM sockets (12 DIMMs per processor). RDIMMs and LRDIMMs are supported.
Memory types cannot be intermixed. Memory speed up to 2133 MHz. Four memory channels
per processor (3 DIMMs per channel).
Memory
maximums
With LRDIMMs: Up to 1.5 TB with 24x 64 GB LRDIMMs and two processors
With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors
Memory
protection
ECC, optional memory mirroring and memory rank sparing.
Disk drive bays Two 2.5-inch hot-swap SAS/SATA drive bays that support SAS, SATA, and SSDs. Optional
support for 2.5-inch NVMe Enterprise PCIe SSDs. Optional support for up to four 1.8-inch SSDs
in place of the two 2.5-inch bays. Up to 12 more 2.5-inch drive bays with the optional Storage
Expansion Node.
Maximum
internal storage
With two 2.5-inch hot-swap drives: Up to 3.2 TB that uses 1.6 TB 2.5-inch SATA SSDs or up to
2.4 TB that uses 1.2 TB SAS HDDs. An intermix of SAS HDDs or SATA HDDs or SSDs is
supported.
With two 2.5-inch NVMe SSDs: Up to 4 TB that uses 2 TB NVMe 2.5-inch G3HS Enterprise
Value PCIe SSDs.
With four 1.8-inch SSDs: Up to 3.2 TB that uses 800 GB 1.8-inch SSDs.
More storage is available with an attached Flex System Storage Expansion Node.
RAID support RAID 0 and 1 with integrated LSI SAS3004 controller. Optional RAID 5 support with ServeRAID
M1200 RAID 5 Enablement Kit and 1.8-inch SSDs
Network
interfaces
x2x models: None standard; optional 1 Gb or 10 GbE adapters.
x4x models: Two 10 GbE ports with EN4172 2-port 10Gb Ethernet Adapter.
x6x models: Two 10 GbE ports with CN4052 2-port 10Gb Virtual Fabric Adapter.
PCI Expansion
slots
Two I/O connectors for adapters. PCI Express 3.0 x16 interface. Includes an Expansion
Connector (PCIe 3.0 x16) to connect an expansion node, such as the PCIe Expansion Node.
PCIe Expansion Node supports two full-height PCIe adapters, two low-profile PCIe adapters,
and two Flex System I/O adapters.
Ports Front: One USB 3.0 port and one console breakout cable port that provides local KVM and serial
ports (cable standard with chassis; more cables optional).
Internal: Optional SD Media Adapter provides two SD Media slots for VMware vSphere
hypervisor support (RAID 1 pair).

IBM Flex System x240 M5 Product Guide 7
Table 1. Standard specifications (part 2)
Components Specification
Systems
management
UEFI, IBM Integrated Management Module 2 (IMM2) with Renesas SH7758 controller,
Predictive Failure Analysis, light path diagnostics panel, automatic server restart, remote
presence. Support for IBM Flex System Manager™, IBM Systems Director and Active Energy
Manager, IBM Tools Center.
Security
features
Power-on password, administrator's password, Trusted Platform Module 1.2.
Video Matrox G200eR2 video core with 16 MB video memory integrated into the IMM2. Maximum
resolution is 1600x1200 at 75 Hz with 16 M colors.
Limited
warranty
Three-year customer-replaceable unit and on-site limited warranty with 9x5/NBD.
Operating
systems
supported
Microsoft Windows Server 2012 and 2012 R2, Red Hat Enterprise Linux 6 and 7, SUSE Linux
Enterprise Server 11, VMware vSphere 5.1 and 5.5. For more information, see "Supported
operating systems."
Service and
support
Optional service upgrades are available through IBM ServicePacs®: 4-hour or 2-hour response
time, 8-hour fix time, 1-year or 2-year warranty extension, remote technical support for IBM
hardware and selected IBM and original equipment manufacturer (OEM) software.
Dimensions Width: 215 mm (8.5 inches), height 51 mm (2.0 inches), depth 493 mm (19.4 inches).
Weight Maximum configuration: 7.1 kg (15.6 lb).
The x240 M5 servers are shipped with the following items:
Statement of Limited Warranty

Important Notices

Documentation CD that contains the Installation and User's Guide


IBM Flex System x240 M5 Product Guide 8
Standard models
Table 2 lists the standard models.
Table 2. Standard models (Part 1)
Model Intel Xeon Processor
(2 maximum)* Memory Disk adapter Disk bays† (used/max) Disks 10 GbE‡ I/O
slots
(used /
max)
Models with no Ethernet adapter standard
9532-A2x 1x E5-2609 v3 6C 1.9GHz
15MB 1600MHz 85W
1x 16 GB
(1600 MHz)
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-B2x 1x E5-2620 v3 6C 2.4GHz
15MB 1866MHz 85W
1x 16 GB
(1866 MHz)
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-C2x 1x E5-2630 v3 8C 2.4GHz
20MB 1866MHz 85W
1x 16 GB
(1866 MHz)
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-D2x 1x E5-2640 v3 8C 2.6GHz
20MB 1866MHz 90W
1x 16 GB
(1866 MHz)
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-F2x 1x E5-2650L v3 12C 1.8GHz
30MB 2133MHz 65W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-G2x 1x E5-2650 v3 10C 2.3GHz
25MB 2133MHz 105W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-H2x 1x E5-2660 v3 10C 2.6GHz
25MB 2133MHz 105W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-J2x 1x E5-2670 v3 12C 2.3GHz
30MB 2133MHz 120W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-L2x 1x E5-2680 v3 12C 2.5GHz
30MB 2133MHz 120W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-M2x 1x E5-2690 v3 12C 2.6GHz
30MB 2133MHz 135W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-N2x 1x E5-2697 v3 14C 2.6GHz
35MB 2133MHz 145W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
9532-Q2x 1x E5-2698 v3 16C 2.3GHz
40MB 2133MHz 135W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open Open 0 / 2
Models with EN4172 2-port 10Gb Ethernet Adapter standard
9532-B4x 1x E5-2620 v3 6C 2.4GHz
15MB 1866MHz 85W
1x 16 GB
(1866 MHz)
LSI SAS3004 2.5” hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-D4x 1x E5-2640 v3 8C 2.6GHz
20MB 1866MHz 90W
1x 16 GB
(1866 MHz)
LSI SAS3004 2.5” hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-H4x 1x E5-2660 v3 10C 2.6GHz
25MB 2133MHz 105W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-J4x 1x E5-2670 v3 12C 2.3GHz
30MB 2133MHz 120W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-L4x 1x E5-2680 v3 12C 2.5GHz
30MB 2133MHz 120W
1x 16 GB
2133 MHz
LSI SAS3004 2.5” hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
* Processor detail: Processor quantity, model, cores, core speed, L3 cache, memory speed, power TDP rating.
† The two 2.5-inch drive bays can be replaced with four 1.8-inch SSD bays.

IBM Flex System x240 M5 Product Guide 9
Table 2. Standard models (Part 2)
Model Intel Xeon Processor
(2 maximum)* Memory (max
786 GB)
Disk
adapter Disk bays† Disks 10 GbE‡ I/O
slots
Models with CN4052 2-port 10Gb Virtual Fabric Adapter standard
9532-B6x 1x E5-2620 v3 6C 2.4GHz
15MB 1866MHz 85W
1x 16 GB
(1866 MHz)
LSI SAS3004 2.5-inch hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-D6x 1x E5-2640 v3 8C 2.6GHz
20MB 1866MHz 90W
1x 16 GB
(1866 MHz)
LSI SAS3004 2.5-inch hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-H6x 1x E5-2660 v3 10C 2.6GHz
25MB 2133MHz 105W
1x 16 GB
2133 MHz
LSI SAS3004 2.5-inch hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-J6x 1x E5-2670 v3 12C 2.3GHz
30MB 2133MHz 120W
1x 16 GB
2133 MHz
LSI SAS3004 2.5-inch hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
9532-L6x 1x E5-2680 v3 12C 2.5GHz
30MB 2133MHz 120W
1x 16 GB
2133 MHz
LSI SAS3004 2.5-inch hot-swap (0 / 2) Open 2x 10 Gb 1 / 2
* Processor detail: Processor quantity, model, cores, core speed, L3 cache, memory speed, power TDP rating.
† The two 2.5-inch drive bays can be replaced with four 1.8-inch SSD bays.

IBM Flex System x240 M5 Product Guide 10
Chassis support
The x240 M5 is supported in the IBM Flex System Enterprise Chassis.
Up to 14 x240 M5 Compute Nodes can be installed in the chassis; however, the actual number that can
be installed in a chassis depends on the following factors:
TDP power rating for the processors that are installed in the x240 M5

Number of power supplies that are installed in the chassis

Capacity of the installed power supplies (2100 W or 2500 W)

Chassis power redundancy policy that is used (N+1 or N+N)

The following table provides guidelines about what number of x240 M5 Compute Nodes can be installed.
For more information, use the Power Configurator, which is found at the following website:
http://ibm.com/systems/bladecenter/resources/powerconfig.html
The following color coding was used In the table:
Green = No restriction on the number of x240 M5 Compute Nodes that can be installed

Yellow = Some bays must be left empty in the chassis

Table 3. Maximum number of x240 M5 Compute Nodes that can be installed based on installed power
supplies and power redundancy policy used
2100 W power supplies installed 2500 W power supplies installed
x240 M5
TDP
rating
N+1, N=5
6 power
supplies
N+1, N=4
5 power
supplies
N+1, N=3
5 power
supplies
N+N, N=3
6 power
supplies
N+1, N=5
6 power
supplies
N+1, N=4
5 power
supplies
N+1, N=3
4 power
supplies
N+N, N=3
6 power
supplies
70 W 14 14 12 13 14 14 14 14
80 W 14 14 12 12 14 14 14 14
85 W 14 14 12 12 14 14 14 14
105 W 14 14 11 11 14 14 13 14
120 W 14 14 10 11 14 14 13 14
130 W 14 13 10 10 14 14 12 13
135 W 14 13 10 10 14 14 12 13
145 W 14 13 9 10 14 14 12 13

IBM Flex System x240 M5 Product Guide 11
Processor options
The x240 M5 supports the processor options that are listed in the following table. The server supports one
or two processors. The table also shows which server models have each processor standard, if any.
Table 4. Processor options
Part
number Feature code* Intel Xeon processor description Models where used
00JX063 A5T1 / A5SJ Intel Xeon E5-2603 v3 6C 1.6GHz 15MB 1600MHz 85W -
00KJ052 AS35 / AS3F Intel Xeon E5-2608L v3 6C 2.0GHz 15MB 1866MHz 52W -
00JX062 A5T2 / A5SK Intel Xeon E5-2609 v3 6C 1.9GHz 15MB 1600MHz 85W A2x
00KJ051 AS34 / AS3E Intel Xeon E5-2618L v3 8C 2.3GHz 20MB 1866MHz 75W -
00JX060 A5T3 / A5SL Intel Xeon E5-2620 v3 6C 2.4GHz 15MB 1866MHz 85W B2x, B4x, B6x
00KJ048 AS31 / AS3B Intel Xeon E5-2623 v3 4C 3.0GHz 10MB 1866MHz 105W -
00KJ050 AS33 / AS3D Intel Xeon E5-2628L v3 10C 2.0GHz 25MB 1866MHz 75W -
00JX059 A5T5 / A5SN Intel Xeon E5-2630 v3 8C 2.4GHz 20MB 1866MHz 85W C2x
00JX061 A5T4 / A5SM Intel Xeon E5-2630L v3 8C 1.8GHz 20MB 1866MHz 55W -
00JX066 A5T6 / A5SP Intel Xeon E5-2637 v3 4C 3.5GHz 15MB 2133MHz 135W -
00JX058 A5T7 / A5SQ Intel Xeon E5-2640 v3 8C 2.6GHz 20MB 1866MHz 90W D2x, D4x, D6x
00JX065 A5T8 / A5SR Intel Xeon E5-2643 v3 6C 3.4GHz 20MB 2133MHz 135W -
00KJ049 AS32 / AS3C Intel Xeon E5-2648L v3 12C 1.8GHz 30MB 2133MHz 75W -
00JX056 A5TA / A5ST Intel Xeon E5-2650 v3 10C 2.3GHz 25MB 2133MHz 105W G2x
00JX057 A5T9 / A5SS Intel Xeon E5-2650L v3 12C 1.8GHz 30MB 2133MHz 65W F2x
00KJ044 AS2X / AS37 Intel Xeon E5-2658 v3 12C 2.2GHz 30MB 2133MHz 105W -
00JX055 A5TB / A5SU Intel Xeon E5-2660 v3 10C 2.6GHz 25MB 2133MHz 105W H2x, H4x, H6x
00JX064 A5TC / A5SV Intel Xeon E5-2667 v3 8C 3.2GHz 20MB 2133MHz 135W -
00JX054 A5TD / A5SW Intel Xeon E5-2670 v3 12C 2.3GHz 30MB 2133MHz 120W J2x, J4x, J6x
00JX053 A5TE / A5SX Intel Xeon E5-2680 v3 12C 2.5GHz 30MB 2133MHz 120W L2x, L4x, L6x
00KJ047 AS30 / AS3A Intel Xeon E5-2683 v3 14C 2.0GHz 35MB 2133MHz 120W -
00KJ046 AS2Z / AS39 Intel Xeon E5-2685 v3 12C 2.6GHz 30MB 2133MHz 120W -
00JX052 A5TF / A5SY Intel Xeon E5-2690 v3 12C 2.6GHz 30MB 2133MHz 135W M2x
00JX051 A5TG / A5SZ Intel Xeon E5-2695 v3 14C 2.3GHz 35MB 2133MHz 120W -
00JX050 A5TH / A5T0 Intel Xeon E5-2697 v3 14C 2.6GHz 35MB 2133MHz 145W N2x
00KJ045 AS2Y / AS38 Intel Xeon E5-2698 v3 16C 2.3GHz 40MB 2133MHz 135W Q2x
00KJ043 AS2W / AS36 Intel Xeon E5-2699 v3 18C 2.3GHz 45MB 2133MHz 145W -
* The first feature code is for processor 1 and second feature code is for processor 2.

IBM Flex System x240 M5 Product Guide 12
Memory options
TruDDR4 Memory uses the highest quality components that are sourced from Tier 1 DRAM suppliers and
only memory that meets the strict requirements of IBM is selected. It is compatibility tested and tuned on
every IBM System x server to maximize performance and reliability. TruDDR4 Memory has a unique
signature that is programmed into the DIMM that enables IBM System x servers to verify whether the
memory that is installed is qualified or supported by IBM. Because TruDDR4 Memory is authenticated,
certain extended memory performance features can be enabled to extend performance over industry
standards. From a service and support standpoint, IBM memory automatically assumes the IBM system
warranty and IBM provides service and support worldwide.
The following table lists the supported memory options.
Table 5. Memory options for the x240 M5
Part
number Feature code Description Models where used
Registered DIMMs (RDIMMs)
46W0784 A5B6 4GB TruDDR4 Memory (1Rx8, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM -
46W0788 A5B5 8GB TruDDR4 Memory (1Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM -
46W0792 A5B8 8GB TruDDR4 Memory (2Rx8, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM -
95Y4821 ASD9 16GB TruDDR4 Memory (2Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM All models
Load-reduced DIMMs (LRDIMMs)
46W0800 A5B9 32GB TruDDR4 Memory (4Rx4, 1.2V) PC417000 CL15 2133MHz LP LRDIMM -
95Y4812 A5UK 64GB TruDDR4 Memory (4Rx4,1.2V) PC4-17000 CL15 2133MHz LP LRDIMM -
The server supports up to 12 TruDDR Memory DIMMs when one processor is installed and up to 24
DIMMs when two processors are installed. Each processor has four memory channels, and there are
three DIMMs per memory channel (3 DPC). RDIMMs and LRDIMMs are supported, but the mixing of
these different types is not supported. UDIMMs are not supported. DIMMs can be installed individually;
however, install them in sets of four (one for each of the four memory channels) for performance reasons.
The following rules apply when the memory configuration is selected:
Mixing of different types of DIMMs (RDIMM and LRDIMM) in the same server is not supported.

The maximum number of supported ranks per channel is eight.

The maximum quantity of DIMMs that can be installed in the server depends on the number of CPUs,

DIMM rank and operating voltage, as shown in the "Maximum quantity" row in the following table. The
shaded cells indicate that the DIMM type supports the maximum number of DIMMs (24 for the x240
M5).

IBM Flex System x240 M5 Product Guide 13
All DIMMs in all CPU memory channels operate at the same speed, which is determined as the

lowest value of the following factors:
Memory speed that is supported by the specific CPU.

Lowest maximum operating speed for the selected memory configuration that depends on rated

speed, as shown in the "Maximum operating speed" section in the following table. The shaded
cells indicate that the speed indicated is the maximum that the DIMM allows.
The following table shows the maximum memory speeds that are achievable based on the installed
DIMMs and the number of DIMMs per channel. The table also shows the maximum memory capacity at
any speed that is supported by the DIMM and maximum memory capacity at rated DIMM speed. In the
table, cells that are highlighted in gray indicate when the specific combination of DIMM voltage and
number of DIMMs per channel still allows the DIMMs to operate at the rated speed.
Table 6. Maximum memory speeds
Specification RDIMMs LRDIMMs
Rank Single rank Dual rank Quad rank
Part numbers 46W0784 (4 GB)
46W0788 (8 GB)
46W0792 (8 GB)
95Y4821 (16 GB)
46W0800 (32 GB)
95Y4812 (64 GB)†
Rated speed 2133 MHz 2133 MHz 2133 MHz
Rated voltage 1.2 V 1.2 V 1.2 V
Operating voltage 1.2 V 1.2 V 1.2 V
Maximum quantity* 24 24 24
Largest DIMM 8 GB 16 GB 64 GB
Max memory capacity 192 GB 384 GB 1.5 TB
Max memory at rated
speed
128 GB 256 GB 1.0 TB
Maximum operating speed (MHz)
One DIMM per channel 2133 MHz 2133 MHz 2133 MHz
Two DIMMs per channel 2133 MHz 2133 MHz 2133 MHz
Three DIMMs per channel 1600 MHz 1600 MHz 1866 MHz
* The maximum quantity that is supported is shown for two processors that are installed. When one processor is
installed, the maximum quantity that is supported is half of that shown.
† 64 GB LRDIMM planned for 4Q/2014
The following memory protection technologies are supported:
ECC

Memory mirroring

Memory sparing

If memory mirroring is used, DIMMs must be installed in pairs (minimum of one pair per CPU), and both
DIMMs in a pair must be identical in type and size.
If memory rank sparing is used, a minimum of one quad-rank DIMM or two single-rank or dual-rank
DIMMs must be installed per populated channel (the DIMMs do not need to be identical). In rank sparing
mode, one rank of a DIMM in each populated channel is reserved as spare memory. The size of a rank
varies depending on the DIMMs that are installed.

IBM Flex System x240 M5 Product Guide 14
Internal storage
The x240 M5 server has two 2.5-inch hot-swap drive bays that are accessible from the front of the blade
server (see Figure 2). These bays connect to the integrated LSI SAS3004 12 Gbps SAS/SATA
RAID-on-Chip (ROC) controller.
The integrated LSI SAS3004 ROC has the following features:
Four-port LSI SAS3004 controller with 12 Gbps throughput per port

PCIe x4 Gen 2 host interface

Two SAS ports routed internally to the two hot-swap drive bays

Supports RAID-0, RAID-1 and RAID-1E

The two 2.5-inch front-accessible drive bays can be replaced with four 1.8-inch drive bays, two 1.8-inch
bays replacing each 2.5-inch bay, by using the ServeRAID M1200 RAID 5 Enablement Kit, 00JX141. This
kit contains a replacement backplane to connect the four 1.8-inch SSDs. The kit also includes ServeRAID
M1200 Zero Cache/RAID 5 Upgrade (Feature on Demand license), which adds RAID 5 support. The part
number for this upgrade is listed in the table.
The two standard 2.5-inch SAS/SATA drive bays can also be replaced with new PCIe NVMe
(Non-Volatile Memory Express) drives that are directly connected to the PCIe bus of the second
processor. Such connectivity, when combined with SSD drives, ensures the lowest possible latency while
still using a standard drive form factor.
Support for NVMe drives requires a replacement drive backplane for the two 2.5-inch drives plus the
second processor must also be installed in the server. The kit containing the backplane, NVMe Enterprise
PCIe SSD Enablement Kit for IBM Flex System x240 M5, is listed in the following table.
Table 7. Internal storage upgrades
Part
number Feature
code Name and description Maximum supported
00JX141 A5SF ServeRAID M1200 RAID 5 Enablement Kit for IBM Flex System x240 M5 1
00JX177 A5SH NVMe Enterprise PCIe SSD Enablement Kit for IBM Flex System x240 M5 1
Supported drives are listed in the "Internal drive options" section.

IBM Flex System x240 M5 Product Guide 15
Internal drive options
The 2.5-inch drive bays support SAS or SATA HDDs or SATA SSDs. The following table lists the
supported 2.5-inch drive options.
Table 8. 2.5-inch drive options for internal disk storage (Part 1)
Part number Feature
code Description Maximum supported
10K SAS hard disk drives
00AJ096 A4TL IBM 300GB 10K 6Gbps SAS 2.5-inch G3HS HDD 2
00AJ091 A4TM IBM 600GB 10K 6Gbps SAS 2.5-inch G3HS HDD 2
00AJ071 A4TN IBM 900GB 10K 6Gbps SAS 2.5-inch G3HS HDD 2
00AJ146 A4TP IBM 1.2TB 10K 6Gbps SAS 2.5-inch G3HS HDD 2
15K SAS hard disk drives
00AJ111 A4TQ IBM 146GB 15K 6Gbps SAS 2.5-inch G3HS HDD 2
00AJ081 A4TR IBM 300GB 15K 6Gbps SAS 2.5-inch G3HS HDD 2
00AJ126 A4TS IBM 600GB 15K 6Gbps SAS 2.5-inch G3HS HDD 2
10K and 15K self-encyrpting disk drives (SED HDDs)
00AJ106 A4TY IBM 300GB 10K 6Gbps SAS 2.5-inch G3HS SED 2
00AJ101 A4TZ IBM 600GB 10K 6Gbps SAS 2.5-inch G3HS SED 2
00AJ076 A4U0 IBM 900GB 10K 6Gbps SAS 2.5-inch G3HS SED 2
00AJ151 A4U1 IBM 1.2TB 10K 6Gbps SAS 2.5-inch G3HS SED 2
00AJ116 A4U2 IBM 146GB 15K 6Gbps SAS 2.5-inch G3HS SED 2
NL SAS
00AJ121 A4TT IBM 500GB 7.2K 6Gbps NL SAS 2.5-inch G3HS HDD 2
00AJ086 A4TU IBM 1TB 7.2K 6Gbps NL SAS 2.5-inch G3HS HDD 2
NL SATA
00AJ131 A4TV IBM 250GB 7.2K 6Gbps NL SATA 2.5-inch G3HS HDD 2
00AJ136 A4TW IBM 500GB 7.2K 6Gbps NL SATA 2.5-inch G3HS HDD 2
00AJ141 A4TX IBM 1TB 7.2K 6Gbps NL SATA 2.5-inch G3HS HDD 2

IBM Flex System x240 M5 Product Guide 16
Table 8. 2.5-inch drive options for internal disk storage (Part 2)
Part number Feature
code Description Maximum supported
6 Gb solid-state drives - Enterprise
00AJ207 A4UA IBM 200GB SAS 2.5-inch MLC G3HS Enterprise SSD 2
00AJ212 A4UB IBM 400GB SAS 2.5-inch MLC G3HS Enterprise SSD 2
00AJ217 A4UC IBM 800GB SAS 2.5-inch MLC G3HS Enterprise SSD 2
00AJ222 A4UD IBM 1.6TB SAS 2.5-inch MLC G3HS Enterprise SSD 2
00AJ156 A4U3 S3700 200GB SATA 2.5-inch MLC G3HS Enterprise SSD 2
00AJ161 A4U4 S3700 400GB SATA 2.5-inch MLC G3HS Enterprise SSD 2
00AJ166 A4U5 S3700 800GB SATA 2.5-inch MLC G3HS Enterprise SSD 2
6 Gb solid-state drives - Enterprise Value
00AJ395 A577 IBM 120GB SATA 2.5-inch MLC G3HS Enterprise Value SSD 2
00AJ400 A578 IBM 240GB SATA 2.5-inch MLC G3HS Enterprise Value SSD 2
00AJ405 A579 IBM 480GB SATA 2.5-inch MLC G3HS Enterprise Value SSD 2
00AJ410 A57A IBM 800GB SATA 2.5-inch MLC G3HS Enterprise Value SSD 2
PCIe NVMe solid-state drives
90Y3227 A5RW P3600 400GB NVMe 2.5-inch G3HS Enterprise Value PCIe SSD 2
90Y3230 A5RX P3600 800GB NVMe 2.5-inch G3HS Enterprise Value PCIe SSD 2
90Y3233 A5RY P3600 1.6TB NVMe 2.5-inch G3HS Enterprise Value PCIe SSD 2
90Y3236 A5RZ P3600 2.0TB NVMe 2.5-inch G3HS Enterprise Value PCIe SSD 2

IBM Flex System x240 M5 Product Guide 17
The supported 1.8-inch SSDs are listed in the following table. The use of 1.8-inch requires the
ServeRAID M1200 RAID 5 Enablement Kit, 00JX141.
Table 9. Supported 1.8-inch SSDs
Part number Feature
code Description Maximum supported
Enterprise SSDs
41Y8366 A4FS S3700 200GB SATA 1.8-inch MLC Enterprise SSD 4
41Y8371 A4FT S3700 400GB SATA 1.8-inch MLC Enterprise SSD 4
Enterprise Value SSDs
00AJ040 A4KV S3500 80GB SATA 1.8-inch MLC Enterprise Value SSD 4
00AJ045 A4KW S3500 240GB SATA 1.8-inch MLC Enterprise Value SSD 4
00AJ050 A4KX S3500 400GB SATA 1.8-inch MLC Enterprise Value SSD 4
00AJ455 A58U S3500 800GB SATA 1.8-inch MLC Enterprise Value SSD 4
00AJ335 A56V IBM 120GB SATA 1.8-inch MLC Enterprise Value SSD 4
00AJ340 A56W IBM 240GB SATA 1.8-inch MLC Enterprise Value SSD 4
00AJ345 A56X IBM 480GB SATA 1.8-inch MLC Enterprise Value SSD 4
00AJ350 A56Y IBM 800GB SATA 1.8-inch MLC Enterprise Value SSD 4

IBM Flex System x240 M5 Product Guide 18
IBM Flex System Storage Expansion Node
The x240 M5 supports the attachment of the IBM Flex System Storage Expansion Node. The IBM Flex
System Storage Expansion Node provides the ability to attach another 12 hot-swap 2.5-inch HDDs or
SSDs locally to the attached compute node. The Storage Expansion Node provides storage capacity for
Network Attach Storage (NAS) workloads, which provides flexible storage to match capacity,
performance, and reliability needs.
The following figure shows the IBM Flex System Storage Expansion Node attached to a compute node.
Figure 4. IBM Flex System Storage Expansion Node (right) attached to a compute node (left)
The ordering information for the Storage Expansion Node is shown in the following table.
Table 10. Ordering part number and feature code
Part number Feature code Description Maximum
supported
68Y8588 A3JF IBM Flex System Storage Expansion Node 1
The Storage Expansion Node has the following features:
Connects directly to supported compute nodes via a PCIe 3.0 interface to the compute node's

expansion connector (see Figure 3).
Supports 12 hot-swap 2.5-inch drive, accessible via a sliding tray.

Supports 6 Gbps SAS and SATA drives, both HDDs and SSDs.

Based on an LSI SAS2208 6 Gbps RAID on Chip (ROC) controller.

Supports RAID 0, 1, 5, 10, and 50 as standard. JBOD also supported. Optional RAID 6 and 60 with a

Features on Demand upgrade.
Optional 512 MB or 1 GB cache with cache-to-flash super capacitor offload.

Note: The use of the Storage Expansion Node requires that the x240 M5 Compute Node have both
processors installed.
For more information, see the IBM Redbooks Product Guide on the IBM Flex System Storage Expansion
Node, which is available at this website:
http://www.redbooks.ibm.com/abstracts/tips0914.html?Open

IBM Flex System x240 M5 Product Guide 19
Internal tape drives
The server does not support an internal tape drive. However, it can be attached to external tape drives by
using Fibre Channel connectivity.
Optical drives
The server does not support an internal optical drive option. However, you can connect an external USB
optical drive, such as the IBM and Lenovo part number 73P4515 or 73P4516, or use the remote media
feature of the IMMv2 and the Chassis Management Module.
Note: The USB port on the compute nodes supplies up to 0.5 A at 5 V. For devices that require more
power, another power source is required.
EN4172 2-port 10Gb Ethernet Adapter
Some models of the x240 M5 (those with a model of the form 9532-x4x) include the IBM Flex System
EN4172 2-port 10Gb Ethernet Adapter installed in slot 1. Table 2 lists the models with this adapter
standard. These models require that a compatible Ethernet switch be installed in I/O module bays 1 and 2
of the chassis.
The EN4172 2-port 10Gb Ethernet Adapter includes the following features:
Two-port 10 Gb Ethernet adapter

Single ASIC controller that uses the QLogic BCM57840 ASIC

PCI Express 3.0 x8 host interface

B and 10 Gb auto-negotiation)

Full line-rate performance

Supports vNIC - Switch Independent Mode

For more information about this adapter, see the IBM Redbooks Product Guide, available from:
http://www.redbooks.ibm.com/abstracts/tips1087.html?Open
CN4052 2-port 10Gb Virtual Fabric Adapter
Some models of the x240 M5 (those with a model of the form 9532-x6x) include the IBM Flex System
CN4052 2-port 10Gb Virtual Fabric Adapter installed in slot 1. Table 2 lists the models with this adapter
standard. These models require that a compatible Ethernet switch be installed in I/O module bays 1 and 2
of the chassis.
The CN4052 2-port 10Gb Virtual Fabric Adapter includes the following features:
Two-port 10 Gb Ethernet adapter.

Optional support for FCoE and iSCSI via an Features on Demand license upgrade.

Single ASIC controller that uses the Emulex XE104 design.

PCIe Express 3.0 x8 host interface (8 GT/s).

Connection to 1 Gb or 10 Gb data center infrastructure (1 Gb and 10 Gb auto-negotiation) .

Full line-rate performance.

Supports NIC virtualization (vNIC) up to four virtual ports per physical port. Supports IBM Fabric

Mode, Switch Independent Mode, and Unified Fabric Port Mode.
For more information about this adapter, see the IBM Redbooks Product Guide, available from:
http://www.redbooks.ibm.com/abstracts/tips1164.html?Open

IBM Flex System x240 M5 Product Guide 20
I/O expansion options
The x240 M5 has two I/O expansion connectors for attaching I/O adapter cards. There is a third
expansion connector that is designed to connect an expansion node, such as the PCIe Expansion Node.
The I/O expansion connectors are a high-density, 216-pin PCIe connector. Installing I/O adapter cards
allows the server to connect with switch modules in the IBM Flex System Enterprise Chassis. Each slot
has a PCI Express 3.0 x16 host interface and both slots support the same form-factor adapters.
The following figure shows the location of the I/O expansion connectors.
Figure 5. Location of the I/O adapter slots in the IBM Flex System x240 M5 Compute Node
All I/O adapters are the same shape and can be used in any available slot.. A compatible switch or
pass-through module must be installed in the corresponding I/O bays in the chassis, as indicated in the
following table. Installing two switches means that all ports of the adapter are enabled, which improves
performance and network availability.
Table 11. Adapter to I/O bay correspondence
I/O adapter slot in the server Port on the adapter Corresponding I/O module bay in the chassis
Port 1 Module bay 1
Port 2 Module bay 2
Port 3 (for 4-port cards) Module bay 1
Slot 1
Port 4 (for 4-port cards) Module bay 2
Port 1 Module bay 3
Port 2 Module bay 4
Port 3 (for 4-port cards) Module bay 3
Slot 2
Port 4 (for 4-port cards) Module bay 4
