IBM @Server pSeries 630 6C4 Manual

Quick Setup Instructions
Completing Your
System Installation
If you encounter difficulties while setting
up your system, contact your service
representative for assistance.
If you have not completed all of the steps in the Quick Setup Instructions labeled
Read Me First, locate the Read Me First Quick Setup Instructions and complete
all of the steps. Then return to this instruction set. The Read Me First Quick Setup
Instructions booklet is located in Box 1 inside the large shipping box that contains
the system drawer.
You must provide the following items:
One flat-blade screwdriver
pSeries 630-6C4
Completing Your
System Installation
Read and understand the caution notices found in this booklet. For a
complete listing of all safety notices and other documentation related to
this product, visit the IBM pSeries and AIX Information Center at
http://publib16.boulder.ibm.com/pseries/index.htm.
To access the pSeries publications, click Hardware documentation.

Check inventory
1
The exclamation mark surrounded by a yellow triangle
denotes caution. A CAUTION notice indicates the presence
of a hazard that has the potential of causing moderate or
minor personal injury. Before doing a step that contains a
caution icon, read and understand the caution statement that
accompanies it.
2Read safety notices
2
2
AIX 5L for
POWER V 5.2
Documentation CD
(ca_ES)
5765-E62
Licensed Materials-Property of IBM.
Copyright IBM 1997, 2002
All Rights Reserved.
Recorded in the
United States of America
Note: U.S.Government users,
RESTRICTED RIGHTS-Use,
Duplication, or Disclosure
restricted by GSA ADP Schedule
Contract with IBM Corp.
See the AIX 5.2
Installation Guide
for Instructions on
the use of this CD.
COMPACTCOMPACT
DIGITALDATADIGITALDATA
LCD4-1148-00
TMTM
P/N 80P3920
LCD4-1137-03
Written in U.S.A.
Contains Licensed Material
Property of IBM.
Copyright IBM and others 2001, 2004
All Rights Reserved.
Note: U.S.Government users,
RESTRICTED RIGHTS-Use,
Duplication, or Disclosure
restricted by GSA ADP Schedule
Contract with IBM Corp.
Version 5.2.0.30
Standalone Diagnostics
Quick Setup Instructions
Completing Your
System Installation
If you encounter difficulties while setting
up your system unit, contact your service
representative for assistance.
The pSeries Model 6C4 and Model 6E4 Installation Guide
was shipped with your system. It is located with the other
documentation in box 2. Before you begin read all safety notices and
instructions found in this manual.
If you have not completed the procedure in the Read Me First brochure,
locate the Read Me First brochure and complete all of the steps and
return to this brochure. The Read Me First brochure is located in
box 1 of your system over pack.
Items that you provide:
One flat-blade screwdriver
pSeries 630-6C4
Completing Your
System Installation
“About Your Machine” document,
books, CD-ROMs and other media
Power cables
(1 standard, 2 optional)
9-pin to 25-pin serial
converter cables (2)
(optional)
RJ-48 to 9-pin
converter cable
Keyboard (optional)
If ordered, the keyboard might
not have shipped in this box.
Note: Review your inventory
closely. If any of the components
shown on this page are missing, or
you encounter any difficulties while
setting up your system, contact your
service representative for assistance.
Mouse (optional)
If ordered, the mouse might
not have shipped in this box.

If you have internal options, such as adapters, disk drives,
or memory upgrades that are not installed, install them now.
Are all of the internal options installed?
3
Check your display or console
4
If you are using an ASCII terminal with a keyboard as the console for
this system, go to “Step 8 Connect the Serial and Parallel Cables”.
If you are using a graphics display with a keyboard and mouse,
go to “Step 6 Connect the Keyboard and Mouse”.
If you are connecting to a Hardware Management Console (HMC),
go to “Step 5 Connecting to a Hardware Management Console”.
Are you connecting to a Hardware
Management Console (HMC)?
5
If your HMC is already installed, complete this step. If your HMC has not been previously installed, refer to
Hardware Management Console Installation and Operations Guide or visit the
After you complete the HMC installation procedure, return here and complete this step.
IBM pSeries and AIX
Information Center at http://publib16.boulder.ibm.com/pseries/index.htm. Click hardware documentation.
To connect your HMC to your system, connect the HMC serial cable to the HMC1 connector.
If this is the second HMC being connected to your system, connect the HMC serial connector
to the HMC2 connector. After connecting the HMC, go to “Step 18 Connect the Serial and
Parallel Devices.”
Your system drawer is equipped with two HMC connectors located on the back of the system.
The connectors are labeled HMC1 and HMC2.
HMC1 HMC2
Model 6C4 HMC
Ifyou need additionalinformation aboutinstalling internal options,
visitthe IBM pSeries and AIXInformation Center at
http://publib16.boulder.ibm.com/pseries/index.htm.Click hardw are documentat ion.

Connect the graphic display
6
A PCI 2D graphics adapter can be installed in any of the six PCI slots.
Some displays require an additional cable.
If you have an ASCII terminal, it is preferable to connect it to serial connector S1.
However, it can also be connected to serial connector S2 or S3.
Connect the graphics display cable to the back of the display and to the graphics adapter
connector. To locate installed adapters, consult the "About Your Machine" document.
Connect the keyboard and mouse
(when using a graphic display)
7
Rear View
Connect the keyboard and mouse to the connectors on the rear of the system, as shown.
If a wrist/palm rest was included with your keyboard and you want to attach
it, refer to the keyboard documentation for installation instructions.
Rear View
Serial
Connector
S1
PCI 2D
Graphics
Adapter

Connect the serial and parallel cables
8
Serial connector 1
(FS1 front)
Operator
panel
Rear of the
system
Rear of the
system
Rear of the
system
Serial port
number Location Examples of applicable usage
Serial connector 1
(S1 rear)
Serial connector 2
(S2)
Serial connector 3
(S3)
Service Agent, PDA system-management applications (for example, handheld
devices or mobile computers), service processor menus, ASCII terminal for AIX
console, and modems
Service Processor menus, Service Agent, PDA system management applications
(interface cable required), ASCII Terminal for AIX Console, and Modems
Service Processor menus, HACMP, ASCII Terminal for AIX Console, and Modems
HACMP, UPS (uninterruptible power supply), ASCII Terminal for AIX Console,
and Modems
Front View 1a
RR
Rear View
1 23 4
1Serial Connector 1
1a Serial Connector 1 (RJ-48 connector)
2 Serial Connector 2
3Serial Connector 3
4 Parallel Connector
Illustration Key
Note: Do not use serial connector S1 to run HACMP or to attach a UPS. If you are configuring your system
to run HACMP with a UPS attached, you must connect the HACMP cable to serial port S2 and the UPS
cable to serial port S3. Do not run a UPS connected to serial port S2. If you decide to disconnect HACMP,
you must reset the service processor using the service processor pinhole reset switch before running
another application. The service processor pinhole reset switch is located on the operator panel. Step 16
shows the location of the service processor reset switch.
Cabling to the serial ports:
This system is equipped with two serial connectors identified as serial connector 1. One is located
at the front of the system (FS1) and the other (S1) is located at the rear of the system.
Use an RJ-48 to 9-pin converter cable to access the front serial connector FS1.
When using FS1, the rear serial connector (S1) is deactivated.
Use a 9-pin serial cable when you activate the rear serial connector S1. If you are attaching to a 25-pin
device, use a 9-pin to 25-pin serial converter cable. The converter cable is a customer-purchased option.
If you have a remote ASCII terminal, connect it through an external modem to serial connector S1.
Connect a local ASCII terminal to serial connector S2 or serial connector S3.
You can connect additional serial devices to the two remaining serial ports (S2 and S3), which are
located at the rear of the system.
Cabling to the parallel port:
If you have a parallel device, such as a printer, connect it to the parallel connector.

Connect the adapter cables
Connect the first external SCSI device
9
10
If you are using any optional adapters (such as token ring or 8-port EIA-232), connect the
cables to the appropriate adapter connectors in the PCI slots of your system. To locate
installed adapters, consult the "About Your Machine" document.
Connect the SCSI cable to the SCSI connector.
Connect the other end of the SCSI cable to the SCSI device.
If this is the last device connected, connect the SCSI device terminator.
If this is not the last device connected, go to the step 11.
Note: The built-in SCSI interface is Ultra3 SCSI. When a cable is not attached
to the SCSI connector on the system, the SCSI bus is automatically terminated.
To set the SCSI device address, refer to the SCSI device documentation.
10.1
10.2
10.3
10.4
If you are not going to install any additional optional adapters, go to step 10.
If you are not going to install an external SCSI Device, go to step 11.
Rear View
1
3
4
2
1External SCSI Connector
2 SCSI Cable to SCSI Device
3SCSI Terminator
4SCSI Device
Illustration Key
Rear View

Connect any additional external
SCSI devices
11
11.1
11.2
11.3
11.5
11.6
11.7
11.4
Locate the last SCSI device cabled from the system.
Remove the SCSI terminator from the last cabled SCSI device.
Connect the new SCSI cable to the SCSI connector on the last SCSI device.
Connect the other end of the SCSI cable to the new SCSI device.
Repeat substeps 11.1, 11.2, and 11.3 for each additional SCSI device that you attach.
Connect the SCSI device terminator to the last SCSI device.
To set the SCSI device address, see the SCSI device documentation.
If you are not going to install any additional external SCSI devices, go to step 12.
1System Unit to First SCSI Device Cable
2 First External SCSI Device
3SCSI Cable to Last SCSI Device
4SCSI Terminator
5Last SCSI Device
Illustration Key
1
2
5
3
4
Rear View

Are you using the
rack-indicator light feature?
12
The rack-indicator light feature signals when a drawer installed in a rack has a
failure or you have issued a locate signal. If you are unsure whether you are using
the rack-indicator light feature, ask your system administrator.
If you are not connecting a rack-indicator light to your system, go to step 13.
Connect one end of the supplied cable to the rack-indicator light feature. Connect the
other end of the cable to the rear RJ-48 connector located on the back of the Model 6C4.
Are you using an Ethernet connection?
13
If you are unsure whether you are using an Ethernet connection, ask your
system administrator. If you are not using Ethernet or you have already connected
your Ethernet to an adapter, go to step 14.
To connect the Ethernet cable, connect the twisted-pair cable to one of two RJ-45 connectors
located on the rear of the system drawer. For RJ-45 connector locations, see the following
illustration.
Note: The twisted-pair connector is compatible with the IEEE 802.3 Ethernet
network 10/100 Base T link.
Rack Indicator Light
Rear View
Rear View
12.1

Connect the power cables to the receptacles
on the rear, and then connect the cables to
different power source outlets.
If your system is equipped with one power supply,
connect the power cable to the power receptacle.
A second power receptacle is present when a
second (redundant) power supply has been added
to the system drawer.
Note: If you are using dc to power your system,
you must have a dc power distribution source.
Shown with two power
supplies installed.
Rear View
Note: This system could be equipped with two power
supplies, each requiring a separate power cable.
CAUTION: This product is equipped with a three-wire power cable and
plug for the user’s safety. Use this power cable with a properly grounded
electrical outlet to avoid electrical shock.
Connect the power cable
14
14.1
14.2
15.1
15.2
15.3
Attach cables to the
cable management arm
15
Put the system into the service position. The rails lock in the fully extended position with a click.
Loosely wrap the hook-and-loop fastener strips around the external cables.
Note: To allow the cable to move, do not tightly wrap the hook-and-loop
fastener strip around the cables.
After you attach the cables to the cable management arm, go to the front
of the rack and move the system drawer in and out. Observe the
movement of the cable and cable management arm to verify that
the cable is not binding.
Hook-and-Loop
Fastener Strips

If you are using dc to power your system,
you must to have a dc power distribution source.
This system could be equipped with two power supplies,
each requiring a separate power cable.
Notes:
Connect your power cable to
the electrical power source
Your system is now set up
16
17
Connect the power cable(s) to the power source.
16.1
16.2
Before you press the power-on button on your operator panel,
observe the following:
The power LED is slowly blinking.
An OK prompt is visible in the operator panel display.
The following illustration shows the operator panel in standby
mode with the OK displayed in the operator panel.
If your system does not stop in standby mode, check all cables
for good connection. If you cannot find a problem, call your support center
for assistance.
1Power-On Button
2 Power LED
3Attention LED
4SCSI Port Activity
5Ethernet Port Activity
6Operator Panel Display
7 (FS1) Front Serial Connector (RJ-48)
8Service Processor Reset Switch (Pinhole)
9System Reset Button
Illustration Key
If an operating system has been preinstalled in your system, see the documentation
provided with your operating system.
If you plan to install the operating system now, see the installation instructions
provided with your operating system.
If you are installing an I/O drawer, follow the instructions that were provided with the I/O
drawer. When you have completed the I/O drawer installation, return to this booklet
and go to step 18.
Power
Distribution
Bus
2
9 8
7
61 3 4 5
R
OK

Start your system
Starting your system without an HMC attached
Starting your system with an HMC attached
18
Press the power-on button on the operator panel.
After you press the power-on button located on the operator panel,
observe the following:
1) The power LED begins to blink visibly faster.
2) The system cooling fans are activated and can be heard accelerating to
operating speed.
Note: There is approximately a 30-second transition period between the time that the
power-on button is pressed and the power LED remains on solid (no longer blinking).
3) The power LED stays on solid. Progress indicators, also referred to as checkpoints,
are visible on the operator panel display.
If you just completed installing, or are not going to install an I/O drawer, run system
verification. Go to “Step 19 “Run System Verification”.
If you are installing an I/O drawer, go to “Cabling the 7028 Model 6C4 to a 7311 Model D20
I/O Drawer”, located in the eServer pSeries 630 Model 6C4 and Model 6E4 Installation Guide,
order number SA38-0605.
18.1
18.2
After the required cables are installed and the power cables are connected, the HMC user interface
provides a power-on function to turn on the power to the system. The power-on button on the operator
panel can be pushed to initialize the system, but the preferred method is to use the HMC if you are starting
logical partitions. Progress indicators, also referred to as checkpoints, are visible on the operator panel
display as the system power is turned on. The power LED on the base system stops blinking and stays
on, indicating that the system power is on.
The base system and I/O subsystems are powered on through the system power control network
(SPCN). When power is applied, the power LEDs on the base system go from blinking to continuous,
and the power LEDs on the I/O subsystems come on and stay on. This situation indicates that power
levels are satisfactory in the subsystems.
21 3
R
E010
1Power-On Button
2 Power LED
3Operator Panel Display
Illustration Key

Run system verification
19
The system verification procedure checks the system for correct hardware operation. If you have a
problem with your system in the future, use this procedure to test the system hardware to help you
determine if you have a hardware problem.
To run the system verification procedure, go to the “Verifying the Hardware Operations”
chapter of the user’s guide for this system. The user’s guide can be accessed by visiting
the atIBM pSeries and AIX Information Center
http://publib16.boulder.ibm.com/pseries/index.htm. Click hardware documentation.
To access the “Verifying the Hardware Operations” chapter in the user’s guide, do the following:
Select Hardware documentation.
Select pSeries 630 Model 6C4 and 6E4.
Select User’s Guide.
Select the Verifying the Hardware Operations chapter, then follow the instructions for the
system configuration that most closely resembles your own.
© International Business Machines Corporation 2004. All rights reserved.
Note to U.S. Government Users -- Documentation related to restricted rights --
Use, duplication or disclosure is subject to restrictions set forth is GSA ADP Schedule Contract with IBM Corp.
