IBM x3500 - System - 7977 User manual

IBM System x3500 Ty pe 7977
User’s Guide


IBM System x3500 Ty pe 7977
User’s Guide


Note: Before using this information and the product it supports, read the general information in “Notices,” on page 77 and the
Warranty and Support Information document on the IBM System xDocumentation CD.
Third Edition (October 2007)
©Copyright International Business Machines Corporation 2007. All rights reserved.
US Government Users Restricted Rights –Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety ............................v
Chapter 1. The System x3500 server ................1
Related documentation ......................1
Notices and statements in this document ................2
Features and specifications .....................3
What your server offers ......................4
Reliability, availability, and serviceability ................5
IBM Director ..........................6
The UpdateXpress program ....................7
Front view ...........................8
Rear view ...........................10
Server power features ......................11
Turning on the server .....................11
Turning off the server .....................11
Chapter 2. Installing optional devices................13
Server components .......................13
System-board internal connectors and switches ............14
System-board LEDs ......................15
System-board external connectors .................16
Light path diagnostics panel ...................16
Installation guidelines ......................21
System reliability guidelines ...................22
Working inside the server with the power on .............22
Handling static-sensitive devices .................22
Removing the bezel .......................23
Removing the left-side cover ....................24
Installing an adapter .......................24
Installing aDVD drive ......................27
Installing afull-high tape drive ...................28
Installing aUSB tape drive ....................29
Installing ahot-swap hard disk drive .................30
Installing an IBM Remote Supervisor Adapter II SlimLine .........31
Installing amemory module ....................33
Installing amicroprocessor ....................39
Installing redundant power and cooling ................42
Completing the installation.....................46
Connecting the cables .....................47
Updating the server configuration .................47
Chapter 3. Configuring the server .................49
Using the Configuration/Setup Utility program .............50
Starting the Configuration/Setup Utility program ............50
Configuration/Setup Utility menu choices ..............50
Passwords .........................54
Using the ServerGuide Setup and Installation CD ............55
ServerGuide features .....................56
Setup and configuration overview .................56
Typical operating system installation ................57
Installing your operating system without ServerGuide ..........57
Using the baseboard management controller ..............57
©Copyright IBM Corp. 2007 iii

Enabling and configuring SOL using the OSA SMBridge management utility
program .........................58
Installing the OSA SMBridge management utility program ........66
Using the baseboard management controller utility programs .......68
Using the Boot Menu program ...................69
Enabling the Broadcom Gigabit Ethernet Utility program..........69
Configuring the Broadcom Gigabit Ethernet controller...........70
Setting up the Remote Supervisor Adapter II SlimLine ..........70
Requirements ........................70
Cabling the Remote Supervisor Adapter II SlimLine ..........71
Installing the Remote Supervisor Adapter II SlimLine firmware ......71
Completing the setup .....................72
Using the Adaptec RAID Configuration Utility program ..........72
Starting the Adaptec RAID Configuration Utility program.........72
Adaptec RAID Configuration Utility menu choices ...........73
Creating aRAID array .....................73
Viewing the array configuration ..................73
Using ServeRAID Manager ....................73
Configuring the controller ....................74
Viewing the configuration ....................75
Updating IBM Director ......................75
Appendix. Notices .......................77
Trademarks ..........................77
Important notes.........................78
Product recycling and disposal ...................79
Battery return program ......................80
Electronic emission notices ....................81
Federal Communications Commission (FCC) statement .........81
Industry Canada Class Aemission compliance statement ........82
Avis de conformité àla réglementation d’Industrie Canada ........82
Australia and New Zealand Class Astatement ............82
United Kingdom telecommunications safety requirement.........82
European Union EMC Directive conformance statement .........82
Taiwanese Class Awarning statement ...............83
Chinese Class Awarning statement ................83
Japanese Voluntary Control Council for Interference (VCCI) statement ...83
Index ............................85
iv IBM System x3500 Type 7977: User’s Guide

Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat udit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
©Copyright IBM Corp. 2007 v

Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Important:
Each caution and danger statement in this document is labeled with anumber. This
number is used to cross reference an English-language caution or danger
statement with translated versions of the caution or danger statement in the IBM
Safety Information book.
For example, if acaution statement is labeled "Statement 1", translations for that
caution statement are in the Safety Information document under "Statement 1".
Be sure to read all caution and danger statements in this document before you
perform the procedures. Read any additional safety information that comes with the
server or optional device before you install the device.
vi IBM System x3500 Type 7977: User’s Guide

Statement 1:
DANGER
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid ashock hazard:
vDo not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical
storm.
vConnect all power cords to aproperly wired and grounded electrical
outlet.
vConnect to properly wired outlets any equipment that will be attached to
this product.
vWhen possible, use one hand only to connect or disconnect signal
cables.
vNever turn on any equipment when there is evidence of fire, water, or
structural damage.
vDisconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
vConnect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached
devices.
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
Safety vii

Statement 2:
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
amodule containing alithium battery, replace it only with the same module
type made by the same manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.
Do not:
vThrow or immerse into water
vHeat to more than 100°C (212°F)
vRepair or disassemble
Dispose of the battery as required by local ordinances or regulations.
viii IBM System x3500 Type 7977: User’s Guide
