IBM TotalStorage SAN16B-2
Installation, Service, and User’s Guide
Service information: 2005 /B16, 16B
GC26-7753-00
Read Before Using
This product contains software that is licensed under written license agreements. Your use of such software is subject to
the license agreements under which they are provided.


IBM TotalStorage SAN16B-2
Installation, Service, and User’s Guide
Service information: 2005 /B16, 16B
GC26-7753-00


Note:
Before using this information and the product it supports, read the information in “Notices” on page 43.
First Edition (August 2005)
The following paragraph does not apply to any country (or region) where such provisions are inconsistent with local
law.
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE. Some states (or regions) do
not allow disclaimer of express or implied warranties in certain transactions; therefore, this statement may not apply
to you.
Order publications through your IBM representative or the IBM branch office serving your locality.
©Copyright International Business Machines Corporation 2005. All rights reserved.
US Government Users Restricted Rights –Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Figures ............................v
Tables ............................ vii
Safety and environmental notices .................ix
Safety notices and labels .....................ix
Danger notices ........................ix
Labels ...........................xi
Caution notices ........................xi
Attention notices ....................... xii
Laser safety .......................... xii
Usage restrictions ....................... xii
Rack safety .......................... xiii
Rack installation ....................... xiii
Rack relocation (19″rack).................... xiv
Environmental notices ......................xv
Product recycling and disposal ..................xv
Battery return program ..................... xvi
Cable warning ........................ xvi
About this document ..................... xvii
Who should read this document .................. xvii
Product documents ....................... xvii
Brocade documents ....................... xvii
IBM and Brocade product matrix ................. xvii
Getting help ......................... xviii
How to send your comments ................... xviii
Chapter 1. Introducing the SAN16B-2 switch .............1
Features and functions of the SAN16B-2 switch .............1
Supported connectivity ......................2
Switch characteristics .......................2
Port side of the SAN16B-2 switch .................2
Non-port side of the SAN16B-2 switch................3
Supported (optional) features ....................3
Additional Port Activation.....................3
Full Fabric Activation ......................3
Fabric Watch .........................3
Advanced Security .......................4
Performance Bundle (Performance Monitoring and ISL Trunking) ......4
Chapter 2. Installing and configuring the SAN16B-2 ..........7
Items included with the switch ....................7
Installation and safety considerations .................8
Facility requirements ......................8
Electrical requirements .....................9
Environmental requirements and considerations ............9
Installing astand-alone SAN16B-2 ..................9
Installing aSAN16B-2 into an EIA cabinet ...............10
Time required ........................10
Items required ........................10
Installation instructions .....................10
Cabling and configuring the SAN16B-2 ................16
©Copyright IBM Corp. 2005 iii

Recommendations for cable management ..............16
Items required for installation...................16
Configuring the SAN16B-2 ...................16
Verifying the configuration ....................20
Backing up the configuration ...................20
Chapter 3. Operating the SAN16B-2 ................21
Powering the SAN16B-2 on and off .................21
Interpreting LED activity .....................21
LED location.........................21
LED patterns and recommended actions ..............22
POST and boot specifications ...................25
POST ...........................25
Boot ............................25
Interpreting POST results .....................26
Chapter 4. Monitoring and maintaining the SANB16-2 .........27
Management features of the SANB16-2................27
Maintaining the SANB16-2 ....................27
Diagnostic tests .......................27
Installing, removing, and testing SFPs ................28
Installing an SFP .......................29
Removing SFP modules ....................32
Appendix A. Product specifications ................37
Data transmission ranges .....................37
Fibre Channel port specifications ..................37
Serial port specifications .....................37
Power supply specifications ....................38
Weight and physical dimensions ..................39
Memory specifications ......................39
System general specifications ...................39
Appendix B. Power cord information ................41
Types of plugs .........................42
Notices ...........................43
Trademarks ..........................45
Electronic emission notices ....................45
Federal Communications Commission (FCC) Class AStatement .....45
Industry Canada Class AEmission Compliance Statement ........45
Avis de conformité àla réglementation d’Industrie Canada ........46
European Union (EU) Electromagnetic Compatibility Directive.......46
Germany Electromagnetic Compatibility Directive ...........46
People’s Republic of China Class AElectronic Emission Statement ....47
Japan VCCI Class AITE Electronic Emission Statement.........47
Korea Class AElectronic Emission Statement ............47
Glossary ...........................49
Index ............................63
iv SAN16B-2 Installation, Service, and User’s Guide

Figures
1. Port side of the SANB16-2 switch .........................3
2. Trunking groups ...............................5
3. Rack assembly ...............................11
4. Separating the inner and outer rails.........................12
5. Mounting the moving portion of the slide and mounting brackets to the switch ........13
6. Mounting the fixed portion of the rail and the locking ears to the rack ...........14
7. Inserting slides into the rack rails .........................15
8. SAN16B-2 port side details ...........................17
9. LEDs on the port side of the SAN16B-2 ......................22
10. SFP plastic tab variety .............................28
11. SFP wire bale variety .............................28
12. Removing the protective cap from aplastic tab type SFP ................29
13. Removing the protective cap from awire bale type SFP ................29
14. Installing aplastic tab type SFP .........................30
15. Installing awire bale type SFP..........................30
16. Locking wire bale SFP in place .........................31
17. Removing the caps from fiber-optic cables .....................31
18. Inserting afiber-optic cable into an SFP module ...................32
19. Fiber-optic cable lever and latches ........................32
20. Removing afiber-optic cable ..........................33
21. Unlocking the SFP module latch, plastic tab type ...................33
22. Removing an SFP module, plastic tab type .....................34
23. Unlocking the SFP module latch, wire bale type ...................35
24. Types of plugs................................43
©Copyright IBM Corp. 2005 v

vi SAN16B-2 Installation, Service, and User’s Guide

Tables
1. Brocade and IBM product and model number matrix ................. xviii
2. Facility requirements ..............................8
3. Environmental requirements ...........................9
4. Parts supplied with the rack-mount kit .......................11
5. Example of changing an IP address ........................18
6. System LED patterns during normal operation ....................23
7. Port LED patterns during normal operation .....................24
8. Ethernet LED patterns .............................25
9. Management options for the switch ........................27
10. Laser data transmission ranges .........................37
11. SAN16B-2 power supply specifications.......................38
12. Switch specifications .............................39
13. Memory specifications .............................39
14. General specifications .............................39
15. Power cord information ............................41
©Copyright IBM Corp. 2005 vii

viii SAN16B-2 Installation, Service, and User’s Guide

Safety and environmental notices
This section contains information about:
v“Safety notices and labels”
v“Laser safety” on page xii
v“Rack safety” on page xiii
v“Environmental notices” on page xv
Safety notices and labels
When using this product, observe the danger, caution, and attention notices
contained in this guide. The notices are accompanied by symbols that represent the
severity of the safety condition. The danger and caution notices are listed in
numerical order based on their IDs, which are displayed in parentheses, for
example (D004), at the end of each notice. Use this ID to locate the translation of
these danger and caution notices in the IBM eServer Safety Notices (G229–9054)
publication, which is on the CD-ROM that accompanies this product. See the
following examples of danger and caution notices for the location of the ID number.
The following sections define each type of safety notice and provide examples.
The following notices and statements are used in IBM
® documents. They are listed
below in order of increasing severity of potential hazards. Follow the links for more
detailed descriptions and examples of the danger, caution, and attention notices in
the sections that follow.
vNote: These notices provide important tips, guidance, or advice.
v“Attention notices” on page xii: These notices indicate potential damage to
programs, devices, or data.
v“Caution notices” on page xi: These statements indicate situations that can be
potentially hazardous to you.
v“Danger notices”: These statements indicate situations that can be potentially
lethal or extremely hazardous to you. Safety labels are also attached directly to
products to warn of these situations.
vIn addition to these notices, “Labels” on page xi may be attached to the product
to warn of potential hazards.
Danger notices
Adanger notice calls attention to asituation that is potentially lethal or extremely
hazardous to people. Alightning bolt symbol accompanies adanger notice to
represent adangerous electrical condition. Asample danger notice follows.
DANGER
An electrical outlet that is not correctly wired could place
hazardous voltage on metal parts of the system or the devices
that attach to the system. It is the responsibility of the customer
to ensure that the outlet is correctly wired and grounded to
prevent an electrical shock. (D004)
©Copyright IBM Corp. 2005 ix

Acomprehensive danger notice provides instructions on how to avoid shock
hazards when servicing equipment. Unless instructed otherwise, follow the
procedures in the following danger notice.
DANGER
Electrical voltage and current from power, telephone, and
communication cables are hazardous.
To avoid ashock hazard:
vDo not connect or disconnect any cables or perform
installation, maintenance, or reconfiguration of this product
during an electrical storm.
vConnect all power cords to aproperly wired and grounded
electrical outlet. Ensure outlet supplies proper voltage and
phase rotation according to the system rating plate.
vConnect any equipment that will be attached to this product to
properly wired outlets.
vWhen possible, use one hand only to connect or disconnect
signal cables.
vNever turn on any equipment when there is evidence of fire,
water, or structural damage.
vDisconnect the attached power cords, telecommunications
systems, networks, and modems before you open the device
covers, unless instructed otherwise in the installation and
configuration procedures.
vConnect and disconnect cables as described below when
installing, moving, or opening covers on this product or
attached devices.
To Disconnect:
1. Turn everything OFF (unless instructed otherwise).
2. Remove power cords from the outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
To Connect:
1. Turn everything OFF (unless instructed otherwise).
2. Attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
(D005)
xSAN16B-2 Installation, Service, and User’s Guide

Labels
As an added precaution, safety labels are often installed directly on products or
product components to warn of potential hazards.
The actual product safety labels may differ from these sample safety labels:
DANGER
Hazardous voltage, current, or energy levels are present
inside any component that has this label attached.
(L001)
Do not service, there are no serviceable parts.
DANGER
Multiple power cords (L003)
To remove all power to the device, disconnect all power cords.
Caution notices
Acaution notice calls attention to asituation that is potentially hazardous to people
because of some existing condition. Acaution notice can be accompanied by
different symbols, as in the examples below:
If the symbol is... It means....
Ahazardous electrical condition with less severity than
electrical danger.
Agenerally hazardous condition not represented by other
safety symbols.
Ahazardous condition due to the use of alaser in the
product. Laser symbols are always accompanied by the
classification of the laser as defined by the U. S.
Department of Health and Human Services (for example,
Class I, Class II, and so forth).
Sample caution notices:
CAUTION:
This product is equipped with a3–wire (two conductors and
ground) power cable and plug. Use this power cable with aproperly
grounded electrical outlet to avoid electrical shock. (C018)
CAUTION:
Data processing environments can contain equipment transmitting
on system links with laser modules that operate at greater than
Class 1power levels. For this reason, never look into the end of an
optical fiber cable or open receptacle. (C027)
Safety and environmental notices xi

Attention notices
An attention notice indicates the possibility of damage to aprogram, device, or
system, or to data. An exclamation point symbol may accompany an attention
notice, but is not required. Asample attention notice follows:
Attention: Do not bend afibre cable to aradius less than 5cm (2 in.);
you can damage the cable. Tie wraps are not recommended for optical
cables because they can be easily overtightened, causing damage to the
cable.
Laser safety
This equipment contains Class 1laser products, and complies with FDA radiation
Performance Standards, 21 CFR Subchapter Jand the international laser safety
standard IEC 825-2.
CAUTION:
Data processing environments can contain equipment transmitting on
system links with laser modules that operate at greater than Class 1
power levels. For this reason, never look into the end of an optical fiber
cable or open receptacle. (C027)
Attention: In the United States, use only SFP or GBIC optical transceivers that
comply with the FDA radiation performance standards, 21 CFR Subchapter J.
Internationally, use only SFP or GBIC optical transceivers that comply with IEC
standard 825–1. Optical products that do not comply with these standards may
product light that is hazardous to the eyes.
Usage restrictions
The optical ports of the modules must be terminated with an optical connector or
with adust plug.
xii SAN16B-2 Installation, Service, and User’s Guide

Rack safety
Rack installation
DANGER
v
Always lower the leveling pads on the rack cabinet.
vAlways install stabilizer brackets on the rack cabinet.
vTo avoid hazardous conditions due to uneven mechanical
loading, always install the heaviest devices in the bottom of
the rack cabinet. Always install servers and optional devices
starting from the bottom of the rack cabinets.
vRack-mounted devices are not to be used as ashelf or work
space. Do not place any object on top of rack-mounted
devices.
vEach rack cabinet might have more than one power cord. Be
sure to disconnect all power cords in the rack cabinet before
servicing any device in the rack cabinet.
vConnect all devices installed in arack cabinet to power
devices installed in the same rack cabinet. Do not plug a
power cord from adevice installed in one rack cabinet into a
power device installed in adifferent rack cabinet.
CAUTION:
vDo not install aunit in arack where the internal rack ambient
temperatures will exceed the manufacturer’s recommended
ambient temperature for all your rack-mounted devices.
vDo not install aunit in arack where the air flow is compromised.
Ensure that air flow is not blocked or reduced on any side, front,
or back of aunit used for air flow through the unit.
vConsideration should be given to the connection of the
equipment to the supply circuit so that overloading of the
circuits does not compromise the supply wiring or overcurrent
protection.
vTo provide the correct power connection to arack, refer to the
rating labels located on the equipment in the rack to determine
the total power requirement of the supply circuit.
v(For sliding drawers.) Do not pull out or install any drawer or
feature if the rack stabilizer brackets are not attached to the rack.
Do not pull out more than one drawer at atime. The rack may
become unstable if you pull out more than one drawer at atime.
v(For fixed drawers.) This drawer is afixed drawer and should not
be moved for servicing unless specified by manufacturer.
Attempting to move the drawer partially or completely out of the
rack may cause the rack to become unstable or cause the drawer
to fall out of the rack.
(R001)
Safety and environmental notices xiii

Rack relocation (19″rack)
CAUTION:
Removing components from the upper positions in the rack cabinet improves
rack stability during relocation. Follow these general guidelines whenever you
relocate apopulated rack cabinet within aroom or building:
vReduce the weight of the rack cabinet by removing equipment starting at
the top of the rack cabinet. When possible, restore the rack cabinet to the
configuration of the rack cabinet as you received it. If this configuration is
not known, you must do the following:
–Remove all devices in the 32U position and above.
–Ensure that the heaviest devices are installed in the bottom of the rack
cabinet.
–Ensure that there are no empty U-levels between devices installed in the
rack cabinet below the 32U level.
–If the rack cabinet you are relocating is part of asuite of rack cabinets,
detach the rack cabinet from the suite.
–Inspect the route that you plan to take when moving the rack to
eliminate potential hazards.
–Verify that the route that you choose can support the weight of the
loaded rack cabinet. Refer to the documentation that came with your
rack cabinet for the weight of aloaded rack cabinet.
–Verify that all door openings are at least 760 x2030 mm (30 x80 in.).
–Ensure that all devices, shelves, drawers, doors, and cables are secure.
–Ensure that the four leveling pads are raised to their highest position.
–Ensure that there is no stabilizer bracket installed on the rack cabinet
during movement.
–Do not use aramp inclined at more than ten degrees.
–Once the rack cabinet is in the new location, do the following:
-Lower the four leveling pads.
-Install stabilizer brackets on the rack cabinet.
-If you removed any devices from the rack cabinet, repopulate the rack
cabinet from the lowest position to the highest position.
–If along distance relocation is required, restore the rack cabinet to the
configuration of the rack cabinet as you received it. Pack the rack
cabinet in the original packaging material, or equivalent. Also, lower the
leveling pads to raise the casters off of the pallet and bolt the rack
cabinet to the pallet.
(R002)
xiv SAN16B-2 Installation, Service, and User’s Guide

Environmental notices
Use the environmental statements and warning in this section to guide you when
using this product and in properly disposing of the product and its components.
Product recycling and disposal
This unit must be recycled or discarded according to applicable local and national
regulations. IBM encourages owners of information technology (IT) equipment to
responsibly recycle their equipment when it is no longer needed. IBM offers a
variety of product return programs and services in several countries to assist
equipment owners in recycling their IT products. Information on IBM product
recycling offerings can be found on IBM’s Internet site at
http://www.ibm.com/ibm/environment/products/prp.shtml
Note: This mark applies only to countries within the European Union (EU) and
Norway.
Appliances are labeled in accordance with European Directive 2002/96/EC
concerning waste electrical and electronic equipment (WEEE). The Directive
determines the framework for the return and recycling of used appliances as
applicable throughout the European Union. This label is applied to various products
to indicate that the product is not to be thrown away, but rather reclaimed upon end
of life per this Directive.
In accordance with the European WEEE Directive, electrical and electronic
equipment (EEE) is to be collected separately and to be reused, recycled, or
recovered at end of life. Users of EEE with the WEEE marking per Annex IV of the
WEEE Directive, as shown above, must not dispose of end of life EEE as unsorted
municipal waste, but use the collection framework available to customers for the
return, recycling and recovery of WEEE. Customer participation is important to
minimize any potential effects of EEE on the environment and human health due to
the potential presence of hazardous substances in EEE. For proper collection and
treatment, contact your local IBM representative.
Safety and environmental notices xv

Battery return program
This product may contain sealed lead acid, nickel cadmium, nickel metal hydride,
lithium, or lithium ion battery. Consult your user manual or service manual for
specific battery information. The battery must be recycled or disposed of properly.
Recycling facilities may not be available in your area. For information on disposal of
batteries outside the United States, go to
http://www.ibm.com/ibm/environment/products/batteryrecycle.shtml or contact your
local waste disposal facility.
In the United States, IBM has established areturn process for reuse, recycling, or
proper disposal of used IBM sealed lead acid, nickel cadmium, nickel metal hydride,
and other battery packs from IBM equipment. For information on proper disposal of
these batteries, contact IBM at 1-800-426-4333. Please have the IBM part number
listed on the battery available prior to your call.
For Taiwan:
Cable warning
WARNING: Handling the cord on this product or cords associated
with accessories sold with this product, will expose you to lead, a
chemical known to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands after handling.
xvi SAN16B-2 Installation, Service, and User’s Guide

About this document
This document describes how to install, service, and use the IBM TotalStorage
®
SAN16B-2 SAN Switch (2005 Models B16 and 16B). Throughout this document, the
product is referred to as the SAN16B-2 ,or simply the switch to apply to both
models. If information applies to only one model, the model will be specified as the
B16 or the 16B.
The sections that follow provide information about:
v“Who should read this document”
v“Product documents”
v“Brocade documents”
v“Getting help” on page xviii
v“How to send your comments” on page xviii
Who should read this document
This document is intended for clients who are responsible for installing, servicing,
and using the SAN16B-2 SAN switches.
Product documents
The following documents contain information related to this product:
vIBM TotalStorage SAN16B-2 Installation, Service, and User’s Guide,GC26-7753
(this document)
vIBM eServer Safety Notices,G229–9054
vIBM TotalStorage SAN b-type 2005 Statement of Limited Warranty,GC26–7654
Brocade documents
IBM b-type switches use software licensed from Brocade Communications Systems,
Inc. You can find information related to the software that supports the director in the
following documents on the CD-ROM supplied with this product:
Brocade Fabric OS
vBrocade Fabric OS Administrator’s Guide
vBrocade Fabric OS Command Reference Manual
vBrocade Fabric OS MIB Reference Manual
vBrocade Fabric OS System Error Message Reference Manual
Brocade Fabric OS optional features
vBrocade Fabric Watch Administrator’s Guide
vBrocade Secure Fabric OS User’s Guide
vBrocade Web Tools Administrator’s Guide
IBM and Brocade product matrix
When you use any of the Brocade documents, you will notice that the model
numbers reflect the original Brocade switches. Table 1on page xviii provides a
product matrix for you to use to correlate the Brocade model numbers to the IBM
product names and machine types and model numbers. Note that anumber of
©Copyright IBM Corp. 2005 xvii

these products are no longer marketed by IBM or Brocade.
Table 1. Brocade and IBM product and model number matrix
Brocade product
name
IBM TotalStorage product
name
IBM product and model
number
SilkWorm AP7420 SAN16B-R multiprotocol router 2109 Model A16
SilkWorm 200E SAN16B-2 2005 Models B16 and 16B
SilkWorm 3250 SAN Switch H08 2005 Model H08
SilkWorm 3800 SAN Switch F16 2109 Model F16
SilkWorm 3850 SAN Switch H16 2005 Model H16
SilkWorm 3900 SAN Switch F32 2109 Model F32
SilkWorm 4100 SAN32B-2 2005 Models B32 and 32B
SilkWorm 12000 SAN Switch M12 2109 Model M12
SilkWorm 24000 SAN Switch M14 2109 Model M14
SilkWorm 48000 SAN256B Director 2109 Model M48
Getting help
For the latest version of your product documentation, visit the web at
http://www.elink.ibmlink.ibm.com/public/applications/publications/cgibin/pbi.cgi.
For more information about IBM SAN products, see the following Web site:
http://www.ibm.com/servers/storage/san/
For support information for this product and other SAN products, see the following
Web site:
http://www.ibm.com/servers/storage/support/san
For detailed information about the Fibre Channel standards, see the Fibre Channel
Industry Association (FCIA) Web site at:
www.fibrechannel.org/
Visit www.ibm.com/contact for the contact information for your country or region.
You can also contact IBM within the United States at 1-800-IBMSERV
(1-800-426-7378). For support outside the United States, you can find the service
number at:
http://www.ibm.com/planetwide/.
How to send your comments
Your feedback is important in helping us provide the most accurate and high-quality
information. If you have comments or suggestions for improving this document,
send us your comments by e-mail to [email protected] or use the Readers’
Comments form at the back of this publication. Be sure to include the following:
vExact publication title
vForm number (for example, GC26-1234-02)
vPage numbers to which you are referring
If the Reader Comment Form in the back of this manual is missing, you can direct
your mail to:
xviii SAN16B-2 Installation, Service, and User’s Guide
