ICC ICRESVPA1C User manual
8-Port Telephone Resi Module
with RJ31X Jack
Package includes:
A. 8-Port Telephone Module with
RJ31X Jack, 1 pc
B. Bracket, 1 pc
C. Locking Button, 4 pcs
D. Warning Label, 1 pc
E. Installation Instructions, 1 sheet
Features and Bene its:
Designed to support up to 4 incoming telephone lines with 8 outputs/extensions per line
Module is bridged as using only 2 incoming lines can get 16 outputs/extensions per line and using
only 1 incoming line can get 32 outputs/extensions
Includes an RJ31X jack connected to line 1 for a security system
Includes an expansion jack for more outputs/extensions by connecting to ICRESVPB1C 8-port
telephone resi module with expansion jacks
Fits all ICRESDC 14", 21", and 28" resi distribution center enclosures with the 4 locking buttons
Installation instructions #MSR-0411-3 included
ANSI/TIA-568-C and UL 1863 compliant
RESI MODULE, TELEPHONE, 8-PORT W/ RJ31X
PremiumProducts
ProvenPerformance
CompetitivePrices
CUSTOMER CARE / TECHNICAL SUPPORT * CSR@ICC.COM / 888-ASK-4-ICC (275-4422) * 2100 E. V lenci Dr, Suite D, Fullerton, CA 92831 * www.icc.com
PremiumProducts
ProvenPerformance
CompetitivePrices
RESI MODULE, TELEPHONE, 8-PORT W/ RJ31X
CUSTOMER CARE / TECHNICAL SUPPORT * CSR@ICC.COM / 888-ASK-4-ICC (275-4422) * 2100 E. V lenci Dr, Suite D, Fullerton, CA 92831 * www.icc.com
