Instruction manual
CO2Monitor
models -500P

www.iCeeO2.com 2 iCeeO2-500P_US_004English.docx
Getting Started
Hello there! Congratulations on your new iCeeO2product! Our products are
packaged and shipped with the utmost care. In the unlikely event that your item is
incorrect, incomplete, or unsatisfactory, please contact us and we will see to fix it
immediately. Feel free to contact us at www.iCeeO2.com; service@.iCeeO2.com
.
Package Contents
CO2 Monitoring Unit
Micro USB Cable for power
User Manual
AC adapter (optional)
Micro SD card (optional)
Features at a Glance
CO2Monitor; Tracer
Chart with variable time Zoom Levels
2-Channel Low Drift NDIR Sensor
Data Logger by SD card
Real-Time colock
3 color LEDs for Easy-Reading
Foolproof “Hold Home”function
Operating Instructions
Initial Setup : When first unboxing, plug in the unit to the included Micro USB (or one
of your own) to almost any cell phone charger or USB power source. If successfully
connected, 3 things will happen while booting up:
3 LEDs flash one by one
Chart display shows the current software version & “Warm Up”
Main display shows a countdown from 10
Once the countdown is complete, your product is ready to use. No initial setup or
calibration is needed.
1. Plug in USB Power Cable

www.iCeeO2.com 3 iCeeO2-500P_US_004English.docx
LCD Display
1. CO2/TEMP/RH Chart
2. Max Reading of Chart
3. Min Reading of Chart
4. Micro SD Card
5. Audible Alarm On/Off
6. Date and Time
7. Temperature Reading
8. RH Reading
9. Main Menu
10. CO2Reading
11. Zoom Level of Time(indicates
the chart’s span of time)
Trend Chart
The trend chart (1) displays the past readings for CO2and temperture and RH
parameters.
That can be toggled by using DOWN key: CO2, TEMP, RH. As show below:

www.iCeeO2.com 4 iCeeO2-500P_US_004English.docx
Trend Chart Zoom
Below is a table that show the available Zoom Levels for all parameters, as well as
the duration of each division for corresponding Zoom Levels:
Zoom Level
(Time Span) (11)
Time Per
Division
1MIN (minute)
5sec /div
1HR (hour)
5m/div
1Day (day)
2h/div
1WEEK(week)
0.5d/div
Using UP will toggle the available Zoom Levels for each parameters. Note that in
addition to the Zoom Levels for each paramete.
Max/Min
At the top right corner of the display, there are two numerical indicators: Max (2)and
Min (3). As the Zoom Level is changed, the Max and Min values will reflect the
maximum and minimum values on the chart of the selected CO2 parameter. At
startup, the unit will automatically display values for CO2.
Real Time
The real-time(6) display at the top right corner of LCD, user can adjust date and
time by enter TIME mode.

www.iCeeO2.com 5 iCeeO2-500P_US_004English.docx
SD Card For Logger
The device will record data logger by SD card while it existed. It’s can record Date,
Time, CO2, Tempereture, RH, user can check and download logger by SD card
reader.
Main Menu Functions
The Main Menu (9) functions can be toggled through by using MENU. If the main
menu is not brought up, the green bar will remain blank, leaving the UP / DOWN
buttons to toggle between parameters and Zoom Levels, respectively.
Pressing MENU once will bring up the main menu, with a flashing bar indicating the
current choice.
To select the function, press ENTER when the bar flashing over the current choice.
Note that after 1 minute if nothing is pressed, the Main Menu will disappear and the
device will revert to the normal state.
HOLD HOME
To revert to start up settings at any point, hold ENTER for 3 sec until an audible
beep. The device will revert to Home Setting, displaying “Back Home done.” Note
that this is not the same as Restore to factory settings.
Below is a table showing what main menu selection is made by pressing MENU
multiple times as well as their functions. Note that the device will display “Done,”
followed by the confirmed selection if selected correctly.

www.iCeeO2.com 6 iCeeO2-500P_US_004English.docx
Function
Directions
ALARM
When ALARM is set ON, an audible alarm will resound if the CO2level
exceeds varying levels (depending on border lever set) . Once ALARM is
selected (by pressing ENTER), use either UP or DOWN to toggle the
selection from ON to OFF or vice versa. Press ENTER one more time to
confirm. A regular bell icon will be displayed if alarm is on; a silenced
bell icon will appear on the screen if the alarm is set to be off.
TIME
This function allows the user to adjust the real-time, once TIME is
selected, use UP and DOWN to adjust the current date and time, Press
ENTER to comfirm.
LOG
This feature allows the user to see historical data recorded in the log at
any point that is displayable on the chart. First make sure the desired
Zoom Level is selected before enabling this function. Then once LOG is
enabled, use UP and DOWN toggle between the time divisions to see
all parameters’ measurements for each division. Press ENTER once more
to exit this mode.
CALI
Use this function to calibrate your device with outside atmospheric CO2
level ~ 400ppm. Select this mode, hold ENTER for 3 seconds until a beep
and the chart will read “Calibrating”, then place the device outside for
20min. To escape, press MENU. Make sure the device is far from a source
of CO2, not in direct sunlight, and not exposed to water.
ALTI
This feature provides an altitude correction to the CO2level for increased
accuracy. Select this feature, then use UP and DOWN to input the
current altitude (look it up if unknown) in meters. Press ENTER once
altitude is correct.
ºC/ºF
Use this feature to toggle between Celsius and Fahrenheit for the
temperature display. First use UP and DOWN, then ENTER when the
desired one is selected.
ADV
This function toggles between 3 things when selected: changing the
alarm and lights to suit levels For Low border, or For Hi border, or
Restore factory setting.
Restore factory setting will reset the device to factory settings and erase
all stored data in the chart. To use any of these modes, hold ENTER for 3
seconds until an audible beep.
(Return)
Exits the main menu. No options will be displayed on the green bar. A
different audible beep be heard in this option.

www.iCeeO2.com 7 iCeeO2-500P_US_004English.docx
Specifications
Typical test conditions, unless otherwise specified: Ambient Temp =23+/-3°C,
RH=50%-70%, Altitude=0~100 meter
Measurement
Spec
Operating Temperature
32°F to 122°F (0°C to 50°C)
Storage Temperature
-4°F to 140°F (-20°C to 60°C)
Operating & Storage RH
0-95%, non-condensing
CO2 Measurement
Accuracy at 0~3000ppm
±50ppm or ±5% of reading, whichever is greater
Accuracy over 3000ppm
±7%
Repeatability
20ppm at 400ppm (standard dev. of 10 readings in 1
minute)
Measurement Range
0-5000ppm
Display Resolution
1ppm (0-1000); 5ppm (1000-2000); 10ppm (>2000)
Temp Dependence
±0.2% of reading per °C or ±2ppm per °C,
whichever is greater, referenced to 25°C
Pressure Dependence
0.13% of reading per mmHg (corrected by user’s
altitude input)
Response Time
<2min for 63% of step change or <4.6min for 90%
step change
Warm-up Time
<30 sec
Temp Measurement
Operating Temperature
32°F to 122°F (0°C -50°C)
Display Resolution
0.1°F (0.1°C)
Accuracy
±1°F (±0.5°C)
Response Time
<20min (63%)
RH Measurement
Range
5-95%
Accuracy
±5%
Resolution
1% on Main Reading, 0.1% on Max Min Reading
Power Requirements
160mA Peak, 15mA average at 5.0V
Dimension
120*66*33mm (4.7*2.6*1.3inch)
Weight
103g ( 3.6oz) Device only, AC Adapter not included

www.iCeeO2.com 8 iCeeO2-500P_US_004English.docx
Rear View:
Disclaimers:
USB connection is for power supply only; no communication with PC. Unplugging the device may result in
loss of most recent logged data on the chart.
This device is not intended for workplace hazard CO2monitoring, nor intended as a definitive monitor for
human or animal health institutions, life sustenance, or any medical-related situation.
iCeeO2and the manufacturer assumes no responsibility for any damage or loss suffered by the user or any
third party arising through the use of this product or its malfunction.
iCeeO2reserve the right to change the spec without notice.
Note:
Recommend Battery capacity: larger or equal to 4000mAh (3000mAh still works, with reduced battery life)
Recommend battery size: smaller than 101x60x22mm / 4.0x2.4x0.87inch,larger battery still works, but not
easy to fit in.
* * * *
