Icemobile Charm II User manual

Contents
FCC ID：C89CHARMII
1 SECURITY MEASURES...................................1
1.1 S AFETY P RECAUTIONS ................................................1
1.2
U SE OF THE ENVIRONMENT ...........................................1
1.3
F AIR U SE ...................................................................1
1.4
A CCESSORIES AND BATTERIES ......................................1
1.5
D ATA B ACKUP ............................................................2
2 GETTING USED...............................................2
2.1 H OW TO SWITCH TO MOBILE PHONE ...............................2
2.2
H OW TO CHARGE THE BATTERY .....................................2
2.3
H OW TO INSTALL & REMOVE THE SIM CARD ...................2
6 USER PROFILES.............................................2
10 SETTINGS .....................................................3
10.1 F ILE MANAGER ..........................................................3
10.2
D UAL SIM SETTINGS .................................................4
10.3
P HONE SETTINGS ......................................................4
10.4
N ETWORK SETTINGS ..................................................4
10.5
S ECURITY SETTINGS ..................................................4
1

10.6
C ONNECTIVITY ..........................................................4
10.7
R ESTORE FACTORY SETTINGS .....................................5
9 EXTRAS...........................................................5
9.1 C ALENDAR .................................................................5
9.2
A LARM .......................................................................5
9.3
C ALCULATOR ..............................................................6
9.4
S TOPWATCH ...............................................................6
9.5
E BOOK READER ..........................................................6
9.6
T ASKS .......................................................................6
9.7
W ORLD CLOCK ............................................................7
11 SERVICES .....................................................7
11.1 I NTERNET SERVICE ....................................................7
11.2
SIM TOOLKIT ............................................................8
5 PHONEBOOK ..................................................8
5.1 C ONTACTS L IST ..........................................................8
5.2
O PTIONS MENU ...........................................................9
7 MESSAGES .....................................................9
7.1 W RITE MESSAGES .......................................................9
2

7.2
I NBOX ......................................................................10
7.3
D RAFTS ...................................................................10
7.4
O UTBOX ...................................................................10
7.5
S ENT MESSAGES .......................................................10
7.6
SMS SETTINGS .........................................................10
4 CALL CENTER...............................................11
4.1 C ALL LOGS ...............................................................11
4.1.1 Missed calls：................................................................. 11
4.1.2 Dialed calls： .................................................................. 11
4.1.3 Received calls： ............................................................. 11
4.1.4 Delete call logs： ............................................................ 11
4.2 C ALL SETTINGS .........................................................11
4.2.1 SIM call settings： .......................................................... 11
4.2.2 Advanced setting:............................................................ 12
13 MULTIMEDIA ...............................................12
13.1 C AMERA .................................................................12
13.2
I MAGE VIEWER ........................................................13
13.3
V IDEO RECORDER ...................................................13
13.4
V IDEO PLAYER ........................................................13
13.5
A UDIO PLAYER ........................................................14
3

13.6
S OUND RECORDER ..................................................15
3 MAKE & RECEIVE CALLS ...............................2
3.1 MAKE A CALL .............................................................15
3.2
M AKE AN EMERGENCY CALL ........................................16
3.3
I NTERNATIONAL CALLS ...............................................16
3.4
A NSWER THE CALL ....................................................17
3.5
ADJUST THE VOLUME .................................................17
3.6
T ALK HANDS - FREE ....................................................17
3.7
C ALL WAITING ...........................................................17
3.8
C ALL OPTIONS ..........................................................17
13.7
FM RADIO ..............................................................15
14 MAINTENANCE AND HELP .........................17
14.1 M AINTENANCE AND REPAIR .......................................17
14.2
M AINTENANCE OF THE BATTERY ................................18
14.3
HELP ......................................................................19
4

1 Security measures
1.1 Safety Precautions
 When mobile Phone use is prohibited or the use may cause
interference or danger, please do not turn on it, and turn off the
automatic startup function.
 Please read and follow the simple rules to prevent dangerous
and illegal use.
1.2 Use of the environment
 When you take a plane the phone should be turned off,
wireless devices may cause interference in aircraft.
 In the hospital should be powered off, the phone may make
some medical equipment (such as pacemakers, hearing aids, etc.)
have an impact.
 At gas stations, oil depots, chemical plants, where blasting
operations or near flammable materials and chemicals areas, do not
use the phone.
 Do not use mobile phones while driving, before using, you should
stop your car.
1.3 Fair Use
 Just use your phone in the normal position.
 When you connect it to other devices, please read the
instructions for detailed and safety actions, do not connect
incompatible products.
 Only qualified personnel can install and repair the phone.
1.4 Accessories and batteries
 Use only the specified batteries and accessories.
 The use of any unauthorized accessories may affect the
phone's performance, even lead to physical danger or in violation of
5

state on the relevant provisions of communication terminal
products.
1.5 Data Backup
 Please note that back up all important data, so as to avoid
loss.
2 Getting used
2.1 How to switch to mobile phone
 Power off or on state, long press key switch machine startup or
shutdown.
2.2 How to charge the battery
 The charging interface will be inserted into one end of the
mobile phone charger, the other end is inserted into a household
power socket.
 When charging the battery level indicator on the screen icon
was dynamic display, until the battery is full up.
 After charging, disconnect the power, then unplug the charger,
so that the charger no-load.
2.3 How to install & remove the SIM card
The machine supports two SIM cards. Please tell the SIM card
inserted into the mobile phone in the mobile phone on the screen,
make sure the phone is turned off and no charging.
6 User profiles
The phone provides a few profiles: general, silent, meeting,
outdoor . Select it , click left keys and you can choose to activate,
customize or reset the mode. Select “activate”and you activate the
associated function. Select “reset”and you restore the profile to
default mode. Select “customize” and you set associated function
below:
6

Ring type：Able to set ring type.
Ringtong：Able to set ringtone of ringtong.
Ringtone volume: Able to set ringtone of incoming call size.
message：Able to set ringtone of message.
Message volume: Able to set ringtone of message size.
Keypad: Able to set the sound of keypad to be “silent”, “click”,
“tone”.
Keypad volume: Able to set ringtone of keypad size.
Cower open: Set the tone when the phone is being powered on.
Cower close: Set the tone when the phone is being shut down.
System alert：Set the system alert on or off.
9 Settings
9.1 File manager
Used for a variety of documents and data storage management.
The phone memory card can be used for capacity expansion.
Select the memory card (memory card is inserted), the following
options:
Open: Go to the next level of the folder list interface
Format: to format the current memory.
Details: You can view the memory space information.
View different folders, select "Options" as follows operations:
Open: Open the folder, and view the folder content.
New Folder: Create a new folder.
Rename: change the name of the folder.
Delete: delete the folder
7

9.2 SIM settings
Able to choose SIM open or “flight mode”.
9.3 Phone settings
 Time and date：Set the time, date and local city and its format.
 Language：Set the language the phone displays.
 Pref.input method ： Set fuzzy tone, hand to set the pace,
handwritten font size, and font color handwritten.
 Display: Set the "wallpaper" and "show date and time".
 Dedicated key：Set the standby interface navigation key function.
 Misc.setting：Set the LCD backlight brightness .
9.4 Network settings
Setting to choose the network by hands or automatically.
9.5 Security settings
 SIM security：This function can open or close the password lock.
PIN number need to be input to power on the phone after it being
locked. Remarks: SIM card would be locked after 3 times mistaking
the PIN number, and then PUK number is necessary to unlock it.
 Phone security：Open this function, when boot you need to input
password, the default password is 1234.
Auto keypad lock: Setting the waiting time of auto keypad lock.
The keypad will be locked automatically after the set time has
passed in the standby interface without any operation.
9.6 Connectivity
Bluetooth
1. Power: Setting the power of Bluetooth.
8

2. Visibility: Setting the visibility of Bluetooth. When it’s off, other
phones can’t search this phone though it has opened Bluetooth.
3. My device: Searching the devices which has turned on Bluetooth
nearby.
4. Search audio device: Searching Bluetooth earphone nearby.
5. My name: The name shows on other phones when Bluetooth is
on and the phone is searched.
6. Advanced: Setting the audio path and the position of storage and
check the Bluetooth address.
9.7 Restore factory settings
This function will be used for some settings which need
restore the default Settings. Choose the item and input factory
password for confirmation (factory password is 0000), the related
parameters will return to factory Settings.
8 Extras
8.1 Calendar
 In the main interface of calendar,press left or right key of
navigation keys to switch switch year and month.
 Press the "options" to enter menu, Can jump to date, go to
today, go to weekly view operation.
8.2 Alarm
you can set 5 alarm clocks, which support ring when shutdown.
 Enter the alarm function, choose a clock, and press left key to
enter editing interface.
 Press up or down of navigation key to choose seting items,
Press left or right of navigation keys，or use a digital keyboard to
modify, and press the right key to save the settings.
9

8.3 Calculator
Calculator can execute addition, subtraction, multiplication, division,
and four fundamental operations of arithmetic.
 Press numeric keys to input the numbers. and the navigation
key input, +, -, x.
 Right function keys can delete datas.
 "OK" key caculate results.
8.4 Stopwatch
This machine is used for the user to provide a stopwatch.
Stopwatch includes typical stopwatch and nway stopwatch, Can
choose according to the actual situation.
8.5 Ebook reader
Ebooks whose formats are txt can be read. Note: Txt files should
be stored under T card’s Ebook menu or in the phone.
When entering the reader, the files stored in the phone or T
card are list in the interface. The options “open Ebook”, “global
settings”, “book informations”, “delete”, “delete all files”, “sort
by”, “help” are able to be operated. Among them, “global
settings”has functions to set font size, scroll type, scroll speed and
the storage position.
When reading, press the left function key to enter the menu. “Full
screen on”, “find”, “jump to”, “add bookmark”, “go to bookmark”,
“delete bookmark”, “auto scroll on”, “close”.
8.6 Tasks
Tasks can be established.
 When adding new tasks, press the “up”and “down”key to
choose the the object to set. Press the navigation keys or the
number keys to modify and the right function key to save the
10

settings.
 Task list interface has options as “view”, “add”, “edit”,
“delete”, “delete overdue”, “delete all”, “jump to date”, “view
uncompleted”, “send vCalendar”, “save as file”.
8.7 World clock
You can view the world of time through the navigation key. Press
the left button to enter it, you can set the daylight saving time
switch.
10 Services
10.1 Internet service
The internetwork is the application platform which wireless
communication combine with with Internet ,it can make you get
plentiful Internet information resources and electronic commerce
application by phone.
Note:
1. Your Internet service provider may not support the certain
functions, in order to guarantee the normal operation of the browser
line, please confirm your SIM card has support the Internet service.
2.when you browse the web,it will costs related flow fee, the
expenses please enquiry local operators.
1、Homepage
The choice will be directly connected to home page which you set
in advance or the default.
2、Bookmark
Choosing a bookmark can visit the website which was set by the
bookmark. You can reserve the commonly used web site in the
favorites. Specific operation is as follows:
Add new bookmark: choose to add new bookmark, preserve after
11

enter a new bookmark address and name.
3、Search or input URL
Input the words to search or the website address to browse.
4、Setting
Able to set the homepage of the browser, configuration files, data
account, browser setting, favorite, security.
10.2 SIM toolkit
This function card toolkit for SIM, provide some service operators for
subscribers to use, please consult the local operators.
5 Phonebook
This feature can view and manage the telephone number
information in the machine and in the SIM card.
5.1 Contacts List
 Press the right function key in the standby screen to access
Contacts.

Contacts list is displayed by default for all phonebook
records in mobile phone and SIM card.，you can press "options" to
enter the menu, then select "Contacts Settings -> preferred storage
location" to re-set the display of the phone book..

In the list interface you can do the following:
- Select "Add Contact" you can add a SIM card or phone
number;
- Press the navigation key to check the records;
- Press the number keys by the first letter to find telephone
numbers;
- Press dial keys will call the current number ;
- Press the left function key to access the Options menu,
and
12

perform the corresponding function through the menu;
- Press the OK key to view the current record for more
information.
5.2 Options menu
In the Contacts Options menu you can do the following:

View: check the detail of the current contact number.

Send text message: Sending messages to the current number.

Call: Dial the current number.
 Edit: Edit the detail of the current number.

Delete: delete the current number.

Copy: Copy the current number.
 Phonebook settings: Able to take operations below:
1、Preferred storage: Choose the preferred position of storage.
2、Extra number: fixed dial may be set
3、Memory status: Memory status of SIM card and the phone can
be checked.
7 Messages
7.1 Write messages
Enter the interface of the message editing , input the
message content, and press the left function key to access the
options menu;
Select "Options" to enter the menu where you can select
"Send, insert commonly used statement, insert contact information,
insert emoticons, save messages" and other options
Select "Send" or press the OK key to enter the number
inputing interface:
- Input number: input the recipient number directly;
- Add from Phonebook: enter the phonebook to select recipients.
13

 Enter the recipient number and then press the OK button to send
text messages.
7.2 Inbox
 Inbox storage and manage the received messages.
Enter the selected Inbox, press the navigation key to select text,and
press the OK key to read its contents.
According to Options view can be reply, call, sender, forward,
delete, delete all, save to phonebook etc.
7.3 Drafts
 When edit a sms which saved as a draft message can be for
viewing and management, operation in this feature , please refer to
the Inbox.
7.4 Outbox
 Outbox storage and manage the messages being sent and failed
being sent. Please refer to the Inbox.
7.5 Sent messages
 Sent messages storage and manage the messages sent and
stored. Please refer to the Inbox.
7.6 SMS settings
SIM
- SMSC address：setting the number of the SMS center
- Validity period: setting SMS validity period
- Message type: setting the type of SMS
- Delivery report: setting the switch of SMS report
- Reply path: setting the switch of reply path
- Voice Mail server: Each SIM card can be set two voice mail
number in the settings, press the “1”key for a longtime to make
available to listen to dial voice mail number voice messages. This
14

function should be supported by the network operator.
 Memory status: The memory status of SIM card and the
phone are visible.
 Save sent message: setting the switch of the storage of
sent messages.
 Preferred storage: setting the preferred position of the
storage of SMS.
4 Call center
4.1 Call logs
This function records related call records. You can see related
calling records options.
4.1.1
Missed calls ：
This function records the number or name recently missed. Press
“ok”key to see the options from the list. The options that can be
chosen are “view”, “call”, “send text message”, “save to
phonebook”, “add to blacklist”, “delete”.
4.1.2
Dialed calls ：
This function records the number or name recently called. for
Operattions please reference Missed calls.
4.1.3
Received calls ：
This function records the number or name recently received. for
Operattions please reference Missed calls.
4.1.4
Delete call logs ：
Each module can remove or delete all.
4.2 Call settings
4.2.1 SIM call settings ：
Call waiting: Set the status to be activated, deactivated, query
status. Note: This function depends on the network operator.
15

Please ask the local network operator for more detail.
Call divert: The options are “Divert all voice calls”, “Divert if
unreachable”, “Divert if no answer”, “Divert if busy”, “Divert
all data calls”, “Cancel all diverts”. Note: This function depends
on the network operator. Please ask the local network operator for
more detail.
Call barring: The options are “All voice calls”, “International
voice calls”, “International voice calls except to home”, “All voice
calls”, “Voice calls when roaming”, “Cancel all”, “Change
barring password”. Note: This function depends on the network
operator. Please ask the local network operator for more detail.
Line switching: Able to switch line 1 or line 2.
4.2.2
Advanced setting :
Auto radial: Able to open or close the function of auto radial.
When it’s on, the phone shall redial automatically after you failed
dialing.
Call time reminder: The call time will display when calling if it’s
on.
Answer mode: Able to set answer the call by pressing any key.
12 Multimedia
12.1 Camera
 Enter photographed point interface. Press Up and down key to
adjust the focal length. click "OK" key to complete photograph.
 Press left function key to enter in the options menu, you can
undertake associated Settings:
 Switch to video recorder: Switch to video recorder.
 Photos: Enter the image viewer view.
 Camera settings: Set some parameters of the camera.
16

 Image settings: Set the picture size and quality.
 White balance: Auto, daylight, tungsten, fluorescent, cloudy,
incandescent.
 Scene mode: Able to set “auto”or “night”.
 Restore default: All the parameters are restored to factory
parameters.
12.2 Image viewer
In [image viewer] interface, press the [option] can undertake the
following function:
 View: Able to view the selected image.
 Image information: Review images for details.
 Browse style: Able to choose list style or matrix style.
 Send: Send the image by the means of Bluetooth or MMS.
 Rename: Change the name of the selected pictures.
 Delete: Delete the selected pictures.
12.3 Video recorder
 Enter photographed point interface.Press Up and down key to
adjust the focal length. Click "OK" button to start shooting.
 Press left function key to enter in the options menu, you can
undertake associated Settings:
 Switch to camera:
Switch to the camera.
 Camcorder settings: Set the parameters of the cameras.
 Video settings: Set the video quality.
12.4 Video player
Access to the video interface list, press up and down navigation
keys to select the video, press the left button can carry out the
following operations：
 Play：The selected video playback
17

 Send：Via multimedia message or Bluetooth transmission
 Rename：The selected video rename
 Delete：Delete the selected video
Select the play into the video playing interface, can carry out the
following operations：
 OK key：Play /
Pause
 navigation up key：Full screen
 navigation down key：Stop the current broadcast
 navigation left, right：Fast forward or rewind
 *key：Decrease volume
 #key：Increase volume
 Options keys：Set whether automatic repeat
12.5 Audio player
Into the music play interface, can undertake the following operation：
 OK key：Play /
Pause
 navigation up key：Looping settings
 navigation down key：The playing order set
 navigation left, right：Short press switch songs, long press to
fast-forward, rewind.
 *key：Decrease volume
 #key：Increase volume
 left function keys：Access list，The list of songs by up and
down navigation keys to move the cursor，According to the options
you can perform the following operations
1、Play：The currently selected songs。
2 、 Details: You can view the selected songs specific
information。
3、Refresh list：The song list refresh。
4、Settings：The list auto gen, repeat, shuffle, background
18

play set。
12.6 Sound recorder
In this feature, press the left function key to select a new record to
start recording, recording success can operate according to the
options.
12.7 FM radio
The phone has FM Radio function for listening broadcast, but
the function is available only with the earphone inserting.
Enter the radio interface, enter into next channel with pressing
the left key and the right key for entering into the previous one, and
up key for smart search, and down key for radio ON/OFF, there are
below options when press left soft key:
Channel List: For compiling channel name and rate.
Manual Input: For inputting rate manually .
Auto Search: For searching channels automatically and
saving the searched channels into Channel List.
Settings: For setting radio conceirned parameters.
Record: Recording the current broadcast.
File list:List of recordings.
3. Make & receive calls
3.1 make a call
Enter the phone number in the standby screen, Press the dial
key call.
When to input,press the right function key to delete the
number.
During the call press the end key to end the call.
You can also choose from a number of direct contacts to
allocate;
19

Press the right function key in the standby screen enter the
phone number screen, and press the navigation key to select to
dial the number.
Press dial key to call the selected number.
Directly in the call log can also call:
In the idle screen press the dial button to enter the call log.
Press the navigation up and down keys to select the number
to dial.
Pressing the dial keys will make the call.
3.2 Make an emergency call
Within the GSM system, you can make an emergency call.
When making an emergency call, please do not arbitrarily terminate
the call. Phone without a SIM card can still make emergency calls.
Enter the emergency number.
Press dial keys to make an emergency call.
Note: As with any mobile phone,
due to the network coverage
reasons or wireless signal transmission case，may not support the
characteristics of the mobile phones，Some networks do not even
support the 112 emergency call service.
Thus, for particularly
critical communications (eg medical emergencies), should not rely
solely on mobile phones. Please check with your local network
operator and reconciliation.
3.3 International calls
In the idle screen press "+" key then in turn enter the country
code, area code and telephone number.
Press dial key to make international calls.
Note: International dialing code of some networks is not "+"
sign, please be discretion.
20
