Icom VS-3 User manual

–
Bluetooth®HEADSET
INSTRUCTIONS q
VS-3
Thank you for purchasing the VS-3 Bluetooth®h e a d -
s e t .
This headset is compatible with Bluetooth®opera-
tion, and includes a [PTT] switch.
Please read these instructions carefully and com-
pletely before using.
Name and the Passkey
• Name: ICOM-BT002
• Passkey: 0000 (four zeros)
The name is displayed on the paring list of other Bluetooth®
devices when a Device Search is made.
Panel description
Earphone jack (3.5 (d) mm: 1⁄8 inch)
Clip
[FWD]
[PLAY]
[RWD]
[RESET]
USB port for
charging
[PWR]
LED indicator
[VOL](–)
[VOL](+)
[PTT]
Microphone
Fully charge the headset before using, and when the LED
blinks every 3 seconds.
How to charge the VS-3
Make sure the headset power is OFF.q
• If it’s ON, hold down [PWR] for 3 seconds.
Open the USB port cover, and then connect the VS-3 tow
a USB power adapter, or a PC, with the supplied USB
cable.
• The charging temperature range: 0ç to +45ç
(32ƒ to +113ƒ)
• While charging, the LED lights red.
• When the charge is completed, the LED turns OFF.
Before using the headset
Features
The VS-3 Bluetooth
®
h e a d s e t enables you to hands-free op-
eration with a Bluetooth®unit installed transceiver or an An-
droid
®
device (third party).
Bluetooth® connection image:
VS-3
Bluetooth®mobile
device (third party)
UT-133
Bluetooth®
Bluetooth®unit
installed
Transceiver
Supplied accessories
• Earphone (SP-36)+Earpad
• USB cable for charging (OPC-2326)
• Instruction sheets q (this sheet) and w
Connecting the earphone plug
LR
For your
left ear
For your
right ear
Charging cautions
The charging time is approximately 3 hours.
If the LED does not turn OFF after 3 hours of charging,
disconnect the USB cable to stop charging.
Overcharge may degrade the battery performance or short-
en battery life. Also, it may cause a fire or explosion.
While charging, you cannot use the headset.
Precautions
RDANGER! NEVER operate the headset while driv-
ing a vehicle, except for a hands-free operation. Safe driving
requires your full attention—anything less may result in an
accident.
RDANGER! NEVER use the headset in an explosive
atmosphere. This may pose a re hazard or explosion.
RDANGER! NEVER incinerate the headset since the
lithium polymer battery gas may cause it to rupture, or may
cause an explosion.
RDANGER! NEVER put the headset in a microwave
oven or high-pressure cooker, or put on a electromagnetic
cooker. This may pose a re hazard or explosion.
RDANGER! NEVER use or leave the headset in ar-
eas with temperatures below –20°C (–4°F) or above +60°C
(+140°F). Extreme temperatures may damage the headset,
shorten the internal battery life, cause fluid to leak from the
battery, or cause the battery to rupture or catch fire.
RWARNING! NEVER use a non specified USB cable.
This may pose a re hazard or result in an electric shock.
RWARNING! NEVER make any changes or modifica-
tions to the headset. This may pose a re hazard or result in
an electric shock.
RWARNING! NEVER drop, impact or vibrate the
headset.
RWARNING! NEVER touch the headset with wet
hands to prevent electric shock.
RWARNING! NEVER let metal, wire or other objects
touch any internal part of the headset. This may result in an
electric shock or this could cause a fire or damage the head-
set.
RWARNING! NEVER keep charging the battery since
overcharge may cause overheating or battery may rupture.
CAUTION: NEVER use the headset nearby medical
equipment. Radio waves the headset may cause the interfer-
ence.
CAUTION: NEVER bend or slew around forcedly, hitch,
heat or remodel the USB cables and earphones.
This may result in an electric shock or this could cause a fire
or damage the headset.
CAUTION: NEVER hitch the cable when detaching the
cable from the headset.
CAUTION: NEVER use the headset if the USB port or
earphone jack is broken. Contact your Icom dealer or dis-
tributor for advice.
CAUTION: Immediately stop the headset operation if it
emits an abnormal odor, sound or smoke. Contact your Icom
dealer or distributor for advice.
DO NOT place the headset in excessively dusty environ-
ments or in direct sunlight.
DO NOT use harsh solvents such as benzine or alcohol to
clean this device, as they will damage the device’s surfaces.
If the device becomes dusty or dirty, wipe it clean with a soft,
dry cloth.
DO NOT charge the headset outside of the specified tem-
perature range, 0˚C to +45˚C (32°F to +113°F).
If the headset must be left unused for a long time, it must be
kept safely in a cool dry place with the temperature range
as below:
–20˚C to +60˚C: –4°F to +140°F (within a month)
–20˚C to +45˚C: –4°F to +113°F (within three months)
–20˚C to +25˚C: –4°F to +77°F (within a year)
After not using the headset for a long time, the internal bat-
tery may be completely exhausted. In that case, you may not
be able to charge it again.
Place the headset in a secure place to avoid inadvertent use
by children.
VS-3
Power adapter
(third party)
PC
To a USB port
Earphone plug
(3.5 (d) mm: 1⁄8 inch)
Using the earphones for a long time may
cause your ears to ache. We recommend
that you sometimes remove it while using.
WORD DEFINITION
RDANGER! Personal death, serious injury or an explosion may occur.
RWARNING! Personal injury, re hazard or electric shock may occur.
CAUTION Equipment damage may occur.
NOTE Recommended for optimum use. No risk of personal in-
jury, fire or electric shock.
Explicit definitions
The Bluetooth®communication range may vary, depending
on the environment in which the device operates.
Microwave ovens or wireless LAN may cause interference.
In that case, stop using those devices or move away from
them.
This Bluetooth®device has a range of use. If the communi-
cation is unstable, use the device within the range.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom
Incorporated (Japan) in Japan, the United States, the United King-
dom, Germany, France, Spain, Russia and/or other countries.
The Bluetooth®work mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Icom
inc. is under license.
All other products or brands are registered trademarks or trade-
marks of their respective holders.

1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan A-7139W-1EX Printed in Japan
© 2014 Icom Inc.
Specification
• Bluetooth
®
Version: Bluetooth
®
Version 3.0
• Transmission Output: Class 1
• Supported proles: HFP, HSP, A2DP, AVRCP
• The maximum number of paired Bluetooth
®
devices:
7 devices*
* You can pair with up to 7 headsets and
data devices. The 7 paired devices can-
not be all headsets or all data devices.
• Dimensions: 28.2(W)×65.1(H)×17.8(D) mm
(1.11(W)×2.56(H)×0.7(D) inch)
(Projections are not included)
• Operating temperature range:
–20ç to + 60ç (–4°F to +140°F)
• Charging temperature range:
0ç to 45ç (+32°F to +113°F)
• Weight: 30 g (1.1 oz) (approximately)
The specifications are subject to change without notice or obligations.
FCC and IC information
Radio operator warnings
• Do not use the headset near medical equipment or a per-
son who has a pacemaker. Radio waves from the headset
may cause interference, or endanger their life.
• Do not use the headset near microwave ovens. Interference
may occur.
• Do not make any changes or modications to the headset.
About the internal battery
• The lithium polymer battery inside VS-3 is a consumable
battery. The gradual deterioration of the charging ability is
not a failure, but a property of a polymer battery. The bat-
tery may recover by fully discharging, and then recharging,
several times before using the unit again.
• The operating time could be shorter at low temperatures.
• The lithium polymer battery is recyclable.
When you use a Bluetooth
®
device, pay attention to follow-
ing:
Bluetooth
®
devices operate on the 2.4 GHz band.
The 2.4 GHz band is also used by other devices, such as
Wireless LAN products, microwave ovens, RFID systems,
amateur radio stations, and so on.
When using the headset and turned ON near such devices,
interference may occur, causing a decrease in communica-
tion speed, and an unstable connection. In such cases, use
the headset away from the other devices, or stop using those
devices.
Electromagnetic Interference
How to use the VOX function
You can use the VOX function with the VS-3, when the trans-
ceiver’s VOX function is enabled.
See the transceiver’s instruction manual for details.
Programmable Key
You can assign other function to
the [PLAY], [FWD] or [RWD] keys
using the Bluetooth®unit installed
transceiver.
See the transceiver’s instruction
manual for details.
[FWD]
[PLAY]
[RWD]
Troubleshooting
The following chart is designed to help you correct problems which are not equipment malfunctions.
If you are unable to locate the cause of a problem or solve it through the use of this chart, contact your nearest Icom Dealer or
Service Center.
PROBLEM POSSIBLE CAUSE SOLUTION
Power does not turn ON. • The battery is exhausted. • Charge the battery.
• After pushing [RESET], push [PWR] to turn ON.
Pairing cannot be made. • The headset is not in the pairing
mode.
• The Bluetooth
®
device setting is
incorrect.
• Other Bluetooth
®
devices are
working around you.
• Other wireless LAN or electric de-
vices may interfere.
• Enter the pairing mode.
• Correct the pairing setting.
• Stop other Bluetooth
®
devices, or move away from
them.
• Stop other wireless LAN or electric devices, or leave
more space from them.
No sound from the earphone • The volume is low
• The earphone jack is almost de-
tached.
• The transceiver’s volume is low.
• Push [VOL] (+) to set the volume level.
• Properly connect the earphone jack.
• Increase the transceiver’s volume level.
• Communication is suddenly
cut off.
• Noise is mixed
• The Bluetooth
®
device is out of
range.
• Other wireless LAN or electric de-
vices may interfere
• Use the headset within the communication range.
The communication range of the headset is 10 meters
(32.8 feet), but it may be shorter, depending on the in-
terference.
• Stop other wireless LAN or electric devices, or leave
more space from them.
The power is on but the device
is disabled.
• The headset has malfunctioned. Push [RESET] to force power OFF the headset.
The transceiver does not
transmit.
• The transceiver is out of range.
• The transceiver’s Busy Lockout
function is activated, and the trans-
ceiver is receiving a signal.
• The MIC gain or VOX gain is incor-
rectly set.
• Change the frequency.
• Wait until the other station stops transmitting, or change
the frequency.
• Adjust the transceiver’s MIC gain or VOX gain, or the
headset’s MIC gain.
• FOR CLASS B UNINTENTIONAL RADIATORS:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in ac-
cordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and re-
ceiver.
• Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV techni-
cian for help.
CAUTION: Changes or modifications to this device, not ex-
pressly approved by Icom Inc., could void your authority to
operate this device under FCC regulations.
This device complies with Part 15 of FCC and Industry Can-
ada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause in-
terference, and (2) this device must accept any interference,
including interference that may cause undesired operation
of the device.
This transmitter must not be co-located or operated in con-
junction with any other antenna or transmitter.
This equipment complies with FCC/IC radiation exposure
limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines and
RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment has very low levels of RF energy that are deemed
to comply without testing of specic absorption ratio (SAR).
CAN ICES-3 (B)
Le présent appareil est conforme aux la partie 15 des règles
de la FCC et CNR d'Industrie Canada applicables aux appar-
eils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes: (1) l'appareil ne doit pas produire
de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Cet émetteur ne doit pas être co-localisé ou fonctionner en
conjonction avec une autre antenne ou émetteur.
Cet équipement est conforme aux limites d’exposition aux
rayonnements énoncées pour un environnement non contrôlé
et respecte les règles les radioélectriques (RF) de la FCC
lignes directrices d'exposition et d’exposition aux fréquences
radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet
une énergie RF très faible qui est considérée conforme sans
évaluation du débit d’absorption spécique (DAS).
NMB-3 (B)
Versions of the VS-3 which display the “CE”
symbol on the serial number label, comply with
the essential requirements of the Radio and
Telecommunications Terminal Equipment Di-
rective, 1999/5/EC, and the restriction of the
use of certain hazardous substances in electri-
cal and electronic equipment Directive, 2011/65/
EU.
You can get the DOC (Declaration Of Conformity) from your
nearest Icom dealer. See the Icom website for details of your
nearest dealer.
http://www.icom.co.jp/world/
Note for disconnecting
When you disconnect the VS-3 from the connected Blu-
etooth®device by resting or turning OFF the VS-3, the audio
output switches from the VS-3 to the device’s speaker.
Be sure to not set the audio volume of the device too high.
About CE
