Icom IC-9700 Installation and operating instructions

SERVICE MANUAL
ADDENDUM
June 2019
NOTE: Use these amended pages as one addendum set.
Do not mix them up with the previous master pages.
Definitions
Replacement page The page to replace the original one.
Addendum page The page to be added to the original set.
Amended page The page to be added as change history, including corrections.
|9700
CONTENTS
SECTION 5 PARTS LIST ……………………………………………5-1a~5-28a
SECTION 6 MECHANICAL PARTS ……………………………… 6-1a~6-6a
SECTION 7 BOARD LAYOUTS …………………………………… 7-1a~7-12a
SECTION 9 BLOCK DIAGRAM …………………………………… 9-1a~9-5a
SECTION 10 VOLTAGE DIAGRAM ……………………………… 10 -1a~10 -18 a

Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PART
NO. DESCRIPTION M. H/V
LOCATION
REF
NO.
PART
NO. DESCRIPTION M. H/V
LOCATION
5-1a
(Amended page)
June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT] [MAIN UNIT]
SECTION 5 PARTS LIST
Q221 1590004690 S.TRA LDTC143ZET1G T 165.4/17.4
Q222 1590005220 S.TRA LDTA114YET1G T 162.9/17.4
Q1051 1550000500 S.FET RZF020P01TL T 180.0/22.3
Q1052 1590004690 S.TRA LDTC143ZET1G T 177.0/25.6
Q1111 1560002190 S.FET RUM002N02T2L T 67.6/112.6
Q1112 1590005220 S.TRA LDTA114YET1G T 66.2/115.1
Q1501 1530004140 S.TRA L2SC4081RT1G T 184.3/141.0
Q1502 1510001200 S.TRA L2SA1576ART1G T 184.3/143.5
Q1511 1530004140 S.TRA L2SC4081RT1G T 184.3/147.0
Q1512 1510001200 S.TRA L2SA1576ART1G T 184.3/149.5
Q1531 1590004690 S.TRA LDTC143ZET1G T 157.3/131.0
Q1551 1590005220 S.TRA LDTA114YET1G T 150.2/139.9
Q1552 1590005220 S.TRA LDTA114YET1G T 143.2/139.9
Q1553 1590004690 S.TRA LDTC143ZET1G T 145.3/147.9
Q1554 1590004690 S.TRA LDTC143ZET1G T 149.6/149.4
Q1571 1590005220 S.TRA LDTA114YET1G T 152.9/133.5
Q1572 1590005220 S.TRA LDTA114YET1G T 152.9/125.6
Q1573 1590004690 S.TRA LDTC143ZET1G T 144.4/129.5
Q1574 1590004690 S.TRA LDTC143ZET1G T 142.1/132.0
Q1575 1590004690 S.TRA LDTC143ZET1G T 142.1/129.9
Q1621 1590004690 S.TRA LDTC143ZET1G T 155.2/151.3
Q2081 1530004140 S.TRA L2SC4081RT1G T 195.7/61.2
Q2091 1530004140 S.TRA L2SC4081RT1G T 186.6/60.2
Q2131 1590004690 S.TRA LDTC143ZET1G T 168.0/112.5
Q2501 1560002190 S.FET RUM002N02T2L T 131.4/20.4
Q2511 1530003960 S.TRA KTC2875-B-RTK/P T 129.6/31.6
Q2512 1590005220 S.TRA LDTA114YET1G T 132.4/32.2
Q2521 1560002190 S.FET RUM002N02T2L T 114.4/20.4
Q2531 1530003960 S.TRA KTC2875-B-RTK/P T 116.5/31.6
Q2532 1590005220 S.TRA LDTA114YET1G T 113.8/31.0
Q2541 1560002190 S.FET RUM002N02T2L T 108.5/20.8
Q2551 1530003960 S.TRA KTC2875-B-RTK/P T 108.0/30.8
Q2552 1590005220 S.TRA LDTA114YET1G T 110.8/31.2
Q2561 1590004690 S.TRA LDTC143ZET1G T 75.1/25.3
Q2562 1590005220 S.TRA LDTA114YET1G T 75.3/27.7
Q2567 1590004690 S.TRA LDTC143ZET1G T 88.5/24.0
Q2591 1510001200 S.TRA L2SA1576ART1G T 111.4/21.1
Q2601 1530004140 S.TRA L2SC4081RT1G T 89.8/27.4
Q2871 1530004140 S.TRA L2SC4081RT1G T 133.6/25.2
Q2881 1530004210 S.TRA DSC7004S0L T 130.0/125.5
Q2921 1530004140 S.TRA L2SC4081RT1G T 124.6/142.7
Q2931 1530004140 S.TRA L2SC4081RT1G T 131.8/140.6
Q2932 1530004210 S.TRA DSC7004S0L T 138.3/142.9
Q2933 1590005220 S.TRA LDTA114YET1G T 135.2/138.5
Q2951 1590004690 S.TRA LDTC143ZET1G T 120.5/144.8
Q3031 1550000430 S.FET RU1C002ZPTCL T 65.6/19.8
Q3032 1590004690 S.TRA LDTC143ZET1G T 61.0/19.8
Q3101 1590004690 S.TRA LDTC143ZET1G T 35.3/14.4
Q3111 1590004690 S.TRA LDTC143ZET1G T 45.3/14.4
Q3121 1590004690 S.TRA LDTC143ZET1G T 59.8/15.4
Q3131 1560002190 S.FET RUM002N02T2L T 52.4/7.9
Q3151 1550000500 S.FET RZF020P01TL T 53.0/24.6
Q3152 1590004690 S.TRA LDTC143ZET1G T 57.8/24.6
Q3181 1590004690 S.TRA LDTC143ZET1G T 14.1/44.6
Q3351 1550000500 S.FET RZF020P01TL T 50.7/28.0
Q3352 1590004690 S.TRA LDTC143ZET1G T 55.5/28.0
Q3381 1590004690 S.TRA LDTC143ZET1G T 29.3/42.0
Q8601 1530004590 S.TRA BFR193F H6327 T 106.3/40.8
Q8602 1510001270 S.TRA 2SAR502UBTL T 105.5/38.7
Q8621 1530004590 S.TRA BFR193F H6327 T 100.6/38.1
Q8641 1530004590 S.TRA BFR193F H6327 T 81.7/40.4
Q8661 1530004590 S.TRA BFR193F H6327 T 87.7/64.9
Q8801 1530002852 S.TRA 2SC4116-BLLF T 13.9/109.6
Q8811 1590004690 S.TRA LDTC143ZET1G T 20.8/114.7
Q8821 1590004690 S.TRA LDTC143ZET1G T 13.8/114.2
Q8822 1590004690 S.TRA LDTC143ZET1G T 17.7/114.8
Q8823 1590005220 S.TRA LDTA114YET1G T 90.1/130.8
D171 1750001810 S.DIO L1SS400T1G T 187.1/37.0
D251 1750001810 S.DIO L1SS400T1G T 164.0/80.7
D311 1750001810 S.DIO L1SS400T1G T 211.0/34.3
D312 1750001810 S.DIO L1SS400T1G T 209.5/34.3
D313 1750001810 S.DIO L1SS400T1G [#12] T 208.0/34.3
1750001810 S.DIO L1SS400T1G [#18]
D314 1750001810 S.DIO L1SS400T1G Only [#19] T 211.0/37.4
D315 1750001810 S.DIO L1SS400T1G T 209.5/37.4
D316 1750001810 S.DIO L1SS400T1G Only [#18] T 208.0/37.4
D317 1750001810 S.DIO L1SS400T1G [#15] T 211.0/40.5
1750001810 S.DIO L1SS400T1G [#17]
1750001810 S.DIO L1SS400T1G [#18]
D318 1750001810 S.DIO L1SS400T1G T 209.5/40.5
D320 1750001810 S.DIO L1SS400T1G [#13] T 211.0/43.6
1750001810 S.DIO L1SS400T1G [#17]
1750001810 S.DIO L1SS400T1G [#18]
D321 1750001810 S.DIO L1SS400T1G [#13] T 209.5/43.6
1750001810 S.DIO L1SS400T1G [#15]
D323 1750001810 S.DIO L1SS400T1G [#12] T 211.0/46.7
1750001810 S.DIO L1SS400T1G [#18]
D324 1750001810 S.DIO L1SS400T1G T 209.5/46.7
D326 1750001810 S.DIO L1SS400T1G T 211.0/49.8
D329 1750001810 S.DIO L1SS400T1G T 211.0/52.9
D330 1750001810 S.DIO L1SS400T1G [#13] T 209.5/52.9
1750001810 S.DIO L1SS400T1G [#15]
D332 1750001810 S.DIO L1SS400T1G T 211.0/56.0
D411 1750001820 S.DIO LRB706F-40T1G T 204.5/52.9
IC101 1140017780 S.IC R7S721001VCBG T 162.5/55.0
IC102 1130017040 S.IC MT48LC4M16A2P-6A IT:J T 133.5/86.5
IC171 1110007780 S.IC NJU7704F3-28A-TE1-#ZZZH T 180.1/32.1
IC181 1130018770 S.IC S25FL127SABMFI100 T 159.0/71.8
IC191 1140017190 S.IC GT24C1024-2CLI-TR T 167.5/72.8
IC192 1140017190 S.IC GT24C1024-2CLI-TR T 170.0/72.8
IC201 1130016730 S.IC S-1009N30I-M5T1U T 179.8/59.6
IC251 1130018410 S.IC RX-8803LC UB T 167.5/78.0
IC301 1140018750 S.IC LCMXO256C-4TN100C T 98.3/102.5
IC311 1140018771 S.IC STM32F030C6T6 T 195.0/47.0
IC331 1130018770 S.IC S25FL127SABMFI100 T 112.7/107.8
IC501 1180004480 S.REG XC6221A142MR-G T 130.1/117.9
IC502 1140016370 S.IC TMS320C5517AZCHA20 T 134.5/105.0
IC1001 6910025460 S.DC MAX17503ATP+T T 74.4/137.5
IC1011 1180004960 S.REG XC6230H001QR-G T 102.9/139.7
IC1021 1180004830 S.REG XC6222A331MR-G T 140.6/125.0
IC1031 1180004830 S.REG XC6222A331MR-G T 98.0/130.4
IC1041 6910027620 S.DC TPS54418RTER T 85.5/136.5
IC1042 1130007021 S.IC TC7S66FU (TE85LF) T 90.8/138.4
IC1071 1180004970 S.REG XC6222D251MR-G T 98.8/119.6
IC1091 1180004230 S.REG XC6222A321MR-G T 36.0/119.3
IC1101 6910026640 S.DC MP2224GJ-P T 60.4/138.6
IC1102 1130011930 S.IC SN74LVC1G04DCKR T 59.5/135.0
IC1111 6910027620 S.DC TPS54418RTER T 70.5/127.0
IC1112 1130007021 S.IC TC7S66FU (TE85LF) T 65.9/123.2
IC1121 1180004740 S.REG S-1313D33-M5T1U3 T 42.6/122.6
IC1131 1180004740 S.REG S-1313D33-M5T1U3 T 10.7/94.4
IC1201 6910026640 S.DC MP2224GJ-P T 87.2/123.3
IC1211 6910022360 S.DC TPS62110RSAR T 58.5/124.8
IC1221 1180004630 S.REG NJM7805DL1A-TE1-#FZZB T 9.5/122.9
IC1231 1180004430 S.REG XC6209F502MR-G T 158.0/115.0
IC1241 1180004240 S.REG XC6222D131PR-G T 10.0/90.0
IC1246 1180003940 S.REG XC6222D121PR-G T 11.2/99.9
IC1251 1180004800 S.REG XC6222D181MR-G T 15.0/104.2
IC1261 1110007950 S.IC INA199A2DCKR T 7.2/20.8
IC1321 1180005530 S.REG LP5912-3.3DRVR T 55.8/63.0
IC1331 1180004270 S.REG NJM2881F05-TE1-#ZZZB T 74.6/64.5
IC1501 1130018160 S.IC 74VHC04FT (BE) T 177.5/146.4
IC1521 1130009581 S.IC TC7W66FU (TE12LF) T 178.3/140.9
IC1531 1190002240 S.IC PCM2901E/2K T 166.8/131.0
IC1532 1130012260 S.IC SN74AHC1G32DCKR T 160.6/131.8
IC1551 1130019420 S.IC CP2102N-A01-GQFN28R T 146.0/144.1
IC1571 1130019420 S.IC CP2102N-A01-GQFN28R T 148.4/130.0
IC1601 1190002912 S.IC TUSB2046IBVFR T 160.0/143.4
IC1901 1130019590 S.IC LAN8710AI-EZK-ABC T 144.8/41.6
IC2001 1110007930 S.IC PCM1681PWPR T 181.9/72.0
IC2011 1110008890 S.IC NJU7056F3-TE2-#ZZZH T 174.2/77.9
IC2021 1110006570 S.IC TS462CPT T 191.2/71.8
IC2041 1110006570 S.IC TS462CPT T 151.8/118.5
IC2061 1110006570 S.IC TS462CPT T 166.3/118.5
IC2081 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 192.4/58.4
IC2101 1190004280 S.IC PCM1802DBR T 163.5/94.0
IC2102 1110006570 S.IC TS462CPT T 165.5/106.5
IC2131 1130009981 S.IC TC7W53FK (TE85LF) T 165.5/111.0
IC2201 1190003450 S.IC MP7741DQ-LF-P T 187.7/89.5
IC2221 1190003450 S.IC MP7741DQ-LF-P T 201.8/89.5
IC2241 1110008540 S.IC 62783G-S18-R T 183.7/132.5
IC2501 1110005320 S.IC NJM13403V-TE1-#ZZZB T 123.0/25.2
IC2541 1110005320 S.IC NJM13403V-TE1-#ZZZB T 100.0/25.6
IC2601 1110005320 S.IC NJM13403V-TE1-#ZZZB T 81.9/30.4
IC2621 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 106.8/13.2
IC2651 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 145.6/30.0
IC2801 1130017400 S.IC MC74HC4094ADTR2G T 112.0/48.2
IC2811 1130017400 S.IC MC74HC4094ADTR2G T 118.6/47.0
IC2821 1130017400 S.IC MC74HC4094ADTR2G T 125.2/47.0
IC2851 1130016460 S.IC R2A20169SA T 131.5/47.0
IC2852 1180004430 S.REG XC6209F502MR-G T 138.0/47.0
IC2861 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 137.0/28.2
IC2901 1120003020 S.IC MAX3221IPWR T 147.0/154.3
IC2961 1110007660 S.IC NJM2746V-TE1-#ZZZB T 122.3/36.6
IC3031 1110007400 S.IC BGA616 T 68.0/22.3
IC3061 1110009150 S.IC NJG1650HB6-TE1 T 85.0/17.8
IC3101 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 38.5/14.7
IC3111 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 48.5/14.7
IC3121 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 55.3/13.5
IC3151 1110008590 S.IC PGA-103+ T 14.8/30.3
IC3171 1180004760 S.REG S-1200B33-M5T1U T 25.0/30.4
IC3181 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 16.3/46.7
IC3182 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 16.3/59.7
IC3351 1110008590 S.IC PGA-103+ T 35.8/24.3
IC3371 1180004760 S.REG S-1200B33-M5T1U T 43.6/41.4
IC3381 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 35.3/42.3
IC3382 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 35.3/53.6
IC3501 1180004430 S.REG XC6209F502MR-G T 25.0/23.3
IC3511 1180004430 S.REG XC6209F502MR-G T 43.6/35.0
IC7201 1190004940 S.IC DAC3482IRKD T 43.1/69.9
IC7501 1190004960 S.IC LTC2156IUP-14#TRPBF T 32.2/99.7
IC7601 1140018370 S.IC 5CEFA9F23I7N T 67.7/95.6
IC7931 6910024650 S.IC 74LVC2G17GW125 T 47.9/108.2
IC7932 6910024650 S.IC 74LVC2G17GW125 T 47.9/111.7
IC8691 1130012610 S.IC SN74AHC1GU04DCKR T 86.5/42.6
IC8692 1130010540 S.IC SN74AHC74PWR T 87.7/47.9
IC8693 1130017950 S.IC SN65LVDS1DBVR T 86.5/72.5
IC8701 1110009880 S.IC AD9518-1ABCPZ-RL7 T 67.3/56.3
IC8811 1130012610 S.IC SN74AHC1GU04DCKR T 23.5/111.0
IC8812 1130018290 S.IC TC7SZ17FELJ T 26.4/111.0

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-2a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
D412 1750001820 S.DIO LRB706F-40T1G T 200.9/52.9
D1091 1750002110 S.DIO LRB551V-30T1G T 36.2/123.2
D1501 1750001810 S.DIO L1SS400T1G T 187.3/141.2
D1511 1750001810 S.DIO L1SS400T1G T 187.3/147.2
D1601 1750001820 S.DIO LRB706F-40T1G T 161.9/151.2
D1602 1750001820 S.DIO LRB706F-40T1G T 166.5/151.2
D2127 1750001810 S.DIO L1SS400T1G T 170.0/106.1
D2128 1750001810 S.DIO L1SS400T1G T 171.3/106.1
D2201 1750001810 S.DIO L1SS400T1G T 191.5/94.0
D2202 1750002130 S.ZEN DZ2J062M0L T 189.4/94.2
D2221 1750001810 S.DIO L1SS400T1G T 205.6/94.0
D2222 1750002130 S.ZEN DZ2J062M0L T 203.5/94.2
D2501 1750001810 S.DIO L1SS400T1G T 125.6/21.2
D2511 1750001810 S.DIO L1SS400T1G T 128.5/29.3
D2521 1750001810 S.DIO L1SS400T1G T 120.3/21.2
D2531 1750001810 S.DIO L1SS400T1G T 117.5/29.3
D2541 1750001810 S.DIO L1SS400T1G T 102.6/21.6
D2551 1750001810 S.DIO L1SS400T1G T 101.3/29.0
D2567 1750001810 S.DIO L1SS400T1G T 85.2/25.6
D2571 1750001810 S.DIO L1SS400T1G T 96.9/29.4
D2581 1750001810 S.DIO L1SS400T1G T 97.1/21.8
D2582 1750001810 S.DIO L1SS400T1G T 92.6/21.8
D2583 1750001810 S.DIO L1SS400T1G T 93.8/21.8
D2584 1750001810 S.DIO L1SS400T1G T 95.0/21.8
D2585 1750001810 S.DIO L1SS400T1G T 91.7/28.8
D2591 1730002890 S.ZEN DZ2J033M0L T 111.2/25.4
D2592 1750002230 S.DIO LRB751S-40T1G T 110.7/28.2
D2593 1750002230 S.DIO LRB751S-40T1G T 110.7/27.0
D2621 1750001810 S.DIO L1SS400T1G T 113.0/15.4
D2622 1750001810 S.DIO L1SS400T1G T 114.3/15.4
D2623 1750001810 S.DIO L1SS400T1G T 111.8/15.4
D2625 1750001810 S.DIO L1SS400T1G T 112.6/11.7
D2631 1750001810 S.DIO L1SS400T1G T 102.1/14.5
D2632 1750001810 S.DIO L1SS400T1G T 100.9/14.5
D2633 1750001810 S.DIO L1SS400T1G T 99.7/14.5
D2921 1750001810 S.DIO L1SS400T1G T 122.8/144.7
D2931 1750001810 S.DIO L1SS400T1G T 135.1/142.3
D3011 1750003070 S.DIO BAP70Q T 64.1/39.3
D3021 1750003070 S.DIO BAP70Q T 64.1/33.2
D3031 1750001810 S.DIO L1SS400T1G T 66.5/9.0
D3032 1750001810 S.DIO L1SS400T1G T 65.3/9.0
D3033 1750001810 S.DIO L1SS400T1G T 67.7/9.0
D3041 1750003070 S.DIO BAP70Q T 64.1/26.7
D3131 1790001622 S.DIO 1SV308L3F T 51.3/10.0
D3141 1750003070 S.DIO BAP70Q T 14.6/23.8
D3161 1750001790 S.DIO 1SS390 TE61 T 19.4/40.3
D3162 1750001790 S.DIO 1SS390 TE61 T 19.4/41.5
D3163 1750001810 S.DIO L1SS400T1G T 19.4/45.0
D3164 1750001810 S.DIO L1SS400T1G T 17.4/44.3
D3165 1750001810 S.DIO L1SS400T1G T 19.4/43.8
D3341 1750003070 S.DIO BAP70Q T 42.4/24.1
D3361 1750001790 S.DIO 1SS390 TE61 T 35.0/35.3
D3362 1750001790 S.DIO 1SS390 TE61 T 35.0/36.5
D3363 1750001810 S.DIO L1SS400T1G T 35.0/40.0
D3364 1750001810 S.DIO L1SS400T1G T 33.1/39.0
D3365 1750001810 S.DIO L1SS400T1G T 35.0/38.8
D8621 1750002320 S.DIO DB3J315E0L T 81.8/37.2
D8641 1750002320 S.DIO DB3J315E0L T 87.1/60.6
D8801 1750001790 S.DIO 1SS390 TE61 T 10.0/113.8
D8802 1750001790 S.DIO 1SS390 TE61 T 11.2/113.8
D8811 1750001820 S.DIO LRB706F-40T1G T 20.8/111.0
D8812 1750001810 S.DIO L1SS400T1G T 23.4/114.0
D9601 1750001820 S.DIO LRB706F-40T1G T 189.5/32.8
D9602 1750001820 S.DIO LRB706F-40T1G T 199.5/32.8
D9603 1750001820 S.DIO LRB706F-40T1G T 197.0/32.8
D9604 1750001820 S.DIO LRB706F-40T1G T 194.5/32.8
D9605 1750001820 S.DIO LRB706F-40T1G T 192.0/32.8
D9606 1750001820 S.DIO LRB706F-40T1G T 202.0/32.8
D9607 1750001820 S.DIO LRB706F-40T1G T 204.5/32.8
D9608 1750001820 S.DIO LRB706F-40T1G T 167.7/23.4
D9609 1750001820 S.DIO LRB706F-40T1G T 170.7/22.1
D9610 1750001820 S.DIO LRB706F-40T1G T 170.7/19.5
D9611 1750001820 S.DIO LRB706F-40T1G T 167.7/20.8
X101 6050014170 S.XTA CR-1017 (48.000 MHz) T 164.3/42.3
X1531 6050014190 S.XTA CR-1020 (12.000 MHz) T 174.8/129.4
X1611 6050014180 S.XTA CR-1019 (6.000 MHz) T 169.0/143.3
X1901 6050014270 S.XTA CR-1030 (25.000 MHz) T 144.5/35.3
X8601 6050014890 S.XTA CR-1080 (49.152 MHz) T 109.2/38.0
L1001 6200016430 S.COI VLS5045EX-3R3N T 68.2/138.9
L1041 6200016280 S.COI NRS5020T1R0NMGJ T 84.9/142.5
L1101 6200016430 S.COI VLS5045EX-3R3N T 54.7/136.9
L1111 6200016430 S.COI VLS5045EX-3R3N T 71.0/121.0
L1201 6200016400 S.COI VLS5045EX-6R8M T 81.5/121.6
L1202 6200015100 S.COI MLP2520S100MT T 75.2/127.7
L1211 6200016400 S.COI VLS5045EX-6R8M T 53.3/126.2
L2201 6190002080 S.COI CER1065-330M-R-0231 T 191.0/100.3
L2202 6190002080 S.COI CER1065-330M-R-0231 T 190.9/111.0
L2203 6200014460 S.COI SLF12555T-680M1R3-PF T 203.7/73.6
L2221 6190002080 S.COI CER1065-330M-R-0231 T 205.1/100.3
L2222 6190002080 S.COI CER1065-330M-R-0231 T 205.0/111.0
L3011 6200011860 S.COI LQW18ANR47G00D T 68.0/42.0
L3012 6200011860 S.COI LQW18ANR47G00D T 67.1/39.9
L3013 6200011860 S.COI LQW18ANR47G00D T 68.9/37.8
L3021 6200011860 S.COI LQW18ANR47G00D T 68.9/35.6
L3022 6200011860 S.COI LQW18ANR47G00D T 67.1/33.8
L3023 6200011860 S.COI LQW18ANR47G00D T 68.0/30.8
L3031 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) T 70.0/22.4
L3041 6200011860 S.COI LQW18ANR47G00D T 68.0/29.4
L3042 6200011860 S.COI LQW18ANR47G00D T 67.1/26.4
L3043 6200011860 S.COI LQW18ANR47G00D T 68.0/24.3
L3052 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) T 71.2/18.9
L3071 6200010910 S.COI LQW18AN56NG00D T 72.8/16.1
L3072 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 75.0/13.6
L3073 6200010910 S.COI LQW18AN56NG00D T 74.7/15.6
L3081 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) T 80.7/15.3
L3082 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) T 85.0/13.6
L3091 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 92.4/15.2
L3092 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 95.0/13.6
L3094 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) T 96.7/15.2
L3141 6200011860 S.COI LQW18ANR47G00D T 19.0/21.7
L3142 6200011860 S.COI LQW18ANR47G00D T 17.6/23.8
L3143 6200011860 S.COI LQW18ANR47G00D T 19.0/27.3
L3151 6200015510 S.COI LQW2BASR56J00L T 19.4/30.3
L3152 6200015470 S.COI LQW2BASR39J00L T 17.0/33.9
L3153 6200013860 S.COI MLK1005S12NJT T 13.2/33.8
L3191 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 18.0/48.9
L3192 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 18.0/57.4
L3201 6200010660 S.COI C2520C-R15G-A (0.15U) T 13.6/49.5
L3202 6200010660 S.COI C2520C-R15G-A (0.15U) T 13.6/56.9
L3341 6200011860 S.COI LQW18ANR47G00D T 44.5/28.5
L3342 6200011860 S.COI LQW18ANR47G00D T 42.4/27.1
L3343 6200011860 S.COI LQW18ANR47G00D T 38.8/28.5
L3351 6200015510 S.COI LQW2BASR56J00L T 35.9/28.9
L3352 6200015470 S.COI LQW2BASR39J00L T 32.3/26.5
L3353 6200013860 S.COI MLK1005S12NJT T 32.4/22.7
L3391 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 37.1/44.3
L3392 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 37.1/51.6
L3401 6200011770 S.COI LQW18ANR10G00D T 33.4/44.3
L3402 6200011770 S.COI LQW18ANR10G00D T 33.4/51.6
L3503 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 75.0/20.7
L3504 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 78.1/21.4
L7101 6200013830 S.COI MLK1005S22NJT T 65.2/45.2
L7102 6200013830 S.COI MLK1005S22NJT T 63.1/46.5
L7103 6200013840 S.COI MLK1005S18NJT T 61.7/46.1
L7104 6200013850 S.COI MLK1005S15NJT T 59.4/45.6
L7151 6200013770 S.COI MLK1005S68NJT T 57.4/44.4
L7152 6200013770 S.COI MLK1005S68NJT T 56.0/44.8
L7202 6140002551 S.COI #617DB-1919=P3 T 50.8/47.1
L7301 6200011670 S.COI LQW18AN82NG00D T 20.7/57.7
L7302 6200011650 S.COI LQW18AN68NG00D T 21.5/54.9
L7306 6200011860 S.COI LQW18ANR47G00D T 22.2/52.1
L7307 6200011860 S.COI LQW18ANR47G00D T 21.9/48.5
L7321 6200011800 S.COI C2520C-47NG-A T 14.1/63.2
L7322 6200010780 S.COI C2520C-1R0G-A T 20.1/62.5
L7351 6140005440 S.COI #617DB-1655 T 13.0/74.4
L7401 6140005440 S.COI #617DB-1655 T 23.5/74.4
L7421 6200011800 S.COI C2520C-47NG-A T 33.5/57.5
L7422 6200010780 S.COI C2520C-1R0G-A T 29.2/58.1
L7451 6200011670 S.COI LQW18AN82NG00D T 30.5/52.7
L7452 6200011650 S.COI LQW18AN68NG00D T 29.2/49.9
L7456 6200011860 S.COI LQW18ANR47G00D T 28.5/48.1
L7457 6200011860 S.COI LQW18ANR47G00D T 29.7/44.6
L7510 6140005440 S.COI #617DB-1655 T 61.5/74.0
L8621 6200011860 S.COI LQW18ANR47G00D T 103.1/36.3
L8622 6200010810 S.COI C2520C-2R2G-A T 100.3/35.6
L8623 6200010810 S.COI C2520C-2R2G-A T 95.2/39.7
L8624 6130003000 S.COI #617DB-1714=P3 T 86.7/37.2
L8625 6200011860 S.COI LQW18ANR47G00D T 79.8/36.5
L8641 6200011860 S.COI LQW18ANR47G00D T 79.6/41.5
L8642 6200010780 S.COI C2520C-1R0G-A T 80.9/44.6
L8643 6200010780 S.COI C2520C-1R0G-A T 79.0/52.1
L8644 6130003000 S.COI #617DB-1714=P3 T 82.2/60.6
L8645 6200011860 S.COI LQW18ANR47G00D T 89.1/59.8
L8661 6200011860 S.COI LQW18ANR47G00D T 85.5/65.2
L8662 6200011450 S.COI C2520C-R39G-A T 87.5/67.7
L8663 6200011450 S.COI C2520C-R39G-A T 80.1/65.8
L8664 6200010910 S.COI LQW18AN56NG00D T 63.2/68.8
L8665 6200010910 S.COI LQW18AN56NG00D T 65.2/69.6
L8731 6200017280 S.COI MLK1005SR12JT T 58.5/55.2
L8733 6200017280 S.COI MLK1005SR12JT T 58.4/57.5
L8801 6200005011 S.COI NLV25T-100J-PF T 10.2/107.9
L8802 6200005011 S.COI NLV25T-100J-PF T 16.4/109.7
R1 7030016110 S.RES RMC1/16S-473JTH (47 k) T 150.3/48.1
R2 7030016110 S.RES RMC1/16S-473JTH (47 k) T 150.3/49.0
R4 7030016110 S.RES RMC1/16S-473JTH (47 k) T 159.4/68.0
R5 7030016110 S.RES RMC1/16S-473JTH (47 k) T 163.9/68.0
R12 7030016110 S.RES RMC1/16S-473JTH (47 k) T 169.3/43.5
R15 7030016090 S.RES RMC1/16S-223JTH (22 k) T 146.5/49.2
R16 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 157.8/43.4
R17 7030016110 S.RES RMC1/16S-473JTH (47 k) T 149.8/47.2
R18 7030016110 S.RES RMC1/16S-473JTH (47 k) T 149.8/46.3
R19 7030016110 S.RES RMC1/16S-473JTH (47 k) T 156.6/43.4
R20 7030016110 S.RES RMC1/16S-473JTH (47 k) T 162.1/68.0
R21 7030016110 S.RES RMC1/16S-473JTH (47 k) T 161.2/68.0

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-3a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
R22 7030016110 S.RES RMC1/16S-473JTH (47 k) T 163.0/68.0
R23 7030016110 S.RES RMC1/16S-473JTH (47 k) T 160.3/68.0
R24 7030015970 S.RES RMC1/16S-103JTH (10 k) T 158.5/68.0
R25 7030016090 S.RES RMC1/16S-223JTH (22 k) T 155.7/43.4
R26 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 168.4/43.5
R27 7030016020 S.RES RMC1/16S-104JTH (100 k) T 174.6/62.8
R30 7030016020 S.RES RMC1/16S-104JTH (100 k) T 174.6/64.6
R31 7030016020 S.RES RMC1/16S-104JTH (100 k) T 176.8/60.1
R32 7030016020 S.RES RMC1/16S-104JTH (100 k) T 174.6/57.4
R33 7030016020 S.RES RMC1/16S-104JTH (100 k) T 176.8/58.3
R34 7030016020 S.RES RMC1/16S-104JTH (100 k) T 150.1/45.4
R35 7030016020 S.RES RMC1/16S-104JTH (100 k) T 174.6/63.7
R36 7030016090 S.RES RMC1/16S-223JTH (22 k) T 150.3/58.7
R37 7030016090 S.RES RMC1/16S-223JTH (22 k) T 150.3/57.8
R38 7030016090 S.RES RMC1/16S-223JTH (22 k) T 150.3/59.6
R39 7030016020 S.RES RMC1/16S-104JTH (100 k) T 156.0/68.0
R40 7030016020 S.RES RMC1/16S-104JTH (100 k) T 157.0/68.0
R41 7030016020 S.RES RMC1/16S-104JTH (100 k) T 155.0/68.0
R101 7030015970 S.RES RMC1/16S-103JTH (10 k) T 160.5/43.4
R102 7030015970 S.RES RMC1/16S-103JTH (10 k) T 167.5/43.5
R103 7030015970 S.RES RMC1/16S-103JTH (10 k) T 167.0/68.0
R104 7030015970 S.RES RMC1/16S-103JTH (10 k) T 154.0/68.0
R105 7030016110 S.RES RMC1/16S-473JTH (47 k) T 168.0/68.0
R106 7030016110 S.RES RMC1/16S-473JTH (47 k) T 170.2/43.5
R107 7030015970 S.RES RMC1/16S-103JTH (10 k) T 158.7/43.4
R108 7030016250 S.RES RMC1/16S-220JTH (22) T 150.6/49.9
R109 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/74.8
R110 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/74.3
R111 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/73.7
R112 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/73.2
R113 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/72.6
R114 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/72.1
R115 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/71.5
R116 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/71.0
R117 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/70.4
R118 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/69.9
R119 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/69.3
R120 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/68.8
R121 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/68.2
R122 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/67.7
R123 7030016150 S.RES RMC1/16S-100JTH (10) T 147.3/67.1
R124 7030016150 S.RES RMC1/16S-100JTH (10) T 145.3/66.6
R125 7030015970 S.RES RMC1/16S-103JTH (10 k) T 150.3/60.5
R126 7030016250 S.RES RMC1/16S-220JTH (22) T 147.3/62.4
R127 7030016250 S.RES RMC1/16S-220JTH (22) T 145.3/61.9
R128 7030016250 S.RES RMC1/16S-220JTH (22) T 147.3/61.3
R129 7030016250 S.RES RMC1/16S-220JTH (22) T 145.3/60.7
R130 7030016250 S.RES RMC1/16S-220JTH (22) T 147.3/60.2
R131 7030016250 S.RES RMC1/16S-220JTH (22) T 145.3/59.6
R132 7030016250 S.RES RMC1/16S-220JTH (22) T 147.3/59.1
R133 7030016250 S.RES RMC1/16S-220JTH (22) T 145.3/58.5
R134 7030016250 S.RES RMC1/16S-220JTH (22) T 147.3/58.0
R135 7030016250 S.RES RMC1/16S-220JTH (22) T 145.3/57.4
R136 7030016250 S.RES RMC1/16S-220JTH (22) T 147.4/56.9
R137 7030016250 S.RES RMC1/16S-220JTH (22) T 145.3/56.3
R138 7030016250 S.RES RMC1/16S-220JTH (22) T 147.3/55.8
R139 7030016250 S.RES RMC1/16S-220JTH (22) T 145.3/55.2
R140 7030015970 S.RES RMC1/16S-103JTH (10 k) T 173.7/46.6
R141 7030016500 S.RES RMC1/16S-562JTH (5.6 k) T 159.6/43.4
R150 7030016060 S.RES RMC1/16S-105JTH (1 M) T 165.0/44.5
R151 7030015930 S.RES RMC1/16S-471JTH (470) T 163.2/44.5
R152 7030016090 S.RES RMC1/16S-223JTH (22 k) T 136.3/78.3
R153 7030016090 S.RES RMC1/16S-223JTH (22 k) T 137.2/78.3
R154 7030016090 S.RES RMC1/16S-223JTH (22 k) T 138.1/78.3
R155 7030016090 S.RES RMC1/16S-223JTH (22 k) T 139.0/78.3
R156 7030016560 S.RES RMC1/16SJPTH T 135.8/93.9
R157 7030016090 S.RES RMC1/16S-223JTH (22 k) T 136.7/93.9
R158 7030015970 S.RES RMC1/16S-103JTH (10 k) T 179.8/37.3
R159 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.6/39.3
R160 7030015970 S.RES RMC1/16S-103JTH (10 k) T 179.4/39.8
R161 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.6/38.3
R162 7030015970 S.RES RMC1/16S-103JTH (10 k) T 179.4/38.8
R163 7030016020 S.RES RMC1/16S-104JTH (100 k) T 186.6/40.3
R164 7030016470 S.RES RMC1/16S-390JTH (39) T 174.6/59.2
R165 7030016250 S.RES RMC1/16S-220JTH (22) T 174.6/61.0
R166 7030016250 S.RES RMC1/16S-220JTH (22) T 174.6/61.9
R167 7030016250 S.RES RMC1/16S-220JTH (22) T 174.6/60.1
R168 7030016560 S.RES RMC1/16SJPTH T 169.6/68.0
R169 7030016250 S.RES RMC1/16S-220JTH (22) T 174.6/58.3
R171 7030016500 S.RES RMC1/16S-562JTH (5.6 k) T 182.8/34.6
R172 7030015990 S.RES RMC1/16S-683JTH (68 k) T 182.8/33.0
R173 7030015970 S.RES RMC1/16S-103JTH (10 k) T 183.9/34.6
R181 7030016110 S.RES RMC1/16S-473JTH (47 k) T 153.6/74.4
R182 7030016110 S.RES RMC1/16S-473JTH (47 k) T 153.6/73.5
R183 7030016110 S.RES RMC1/16S-473JTH (47 k) T 153.6/72.6
R184 7030016110 S.RES RMC1/16S-473JTH (47 k) T 164.5/73.0
R185 7030016110 S.RES RMC1/16S-473JTH (47 k) T 164.5/71.7
R186 7030016110 S.RES RMC1/16S-473JTH (47 k) T 164.5/70.5
R191 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 165.8/73.3
R192 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 167.5/69.6
R201 7030016220 S.RES RMC1/16S-563JTH (56 k) T 183.2/58.7
R202 7030016090 S.RES RMC1/16S-223JTH (22 k) T 183.2/59.6
R203 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 183.2/60.5
R204 7030016110 S.RES RMC1/16S-473JTH (47 k) T 181.9/58.2
R210 7030016150 S.RES RMC1/16S-100JTH (10) T 123.5/79.2
R211 7030016150 S.RES RMC1/16S-100JTH (10) T 125.5/79.0
R212 7030016150 S.RES RMC1/16S-100JTH (10) T 126.4/79.0
R213 7030016150 S.RES RMC1/16S-100JTH (10) T 127.7/79.0
R214 7030016150 S.RES RMC1/16S-100JTH (10) T 128.6/79.0
R215 7030016150 S.RES RMC1/16S-100JTH (10) T 130.4/79.0
R216 7030016150 S.RES RMC1/16S-100JTH (10) T 131.3/79.0
R217 7030016150 S.RES RMC1/16S-100JTH (10) T 132.5/79.0
R218 7030016150 S.RES RMC1/16S-100JTH (10) T 132.8/93.9
R219 7030016150 S.RES RMC1/16S-100JTH (10) T 131.0/93.9
R220 7030016150 S.RES RMC1/16S-100JTH (10) T 130.1/93.9
R221 7030016150 S.RES RMC1/16S-100JTH (10) T 128.9/93.9
R222 7030016150 S.RES RMC1/16S-100JTH (10) T 128.0/93.9
R223 7030016150 S.RES RMC1/16S-100JTH (10) T 126.2/93.9
R224 7030016150 S.RES RMC1/16S-100JTH (10) T 125.3/93.9
R225 7030016150 S.RES RMC1/16S-100JTH (10) T 123.9/93.9
R251 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 164.0/78.4
R252 7030016110 S.RES RMC1/16S-473JTH (47 k) T 168.9/75.4
R253 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 166.4/75.4
R254 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 166.5/81.0
R301 7030016560 S.RES RMC1/16SJPTH T 97.7/92.4
R302 7030016560 S.RES RMC1/16SJPTH T 108.4/104.5
R303 7030016560 S.RES RMC1/16SJPTH T 106.1/112.7
R304 7030015970 S.RES RMC1/16S-103JTH (10 k) T 91.6/92.4
R305 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 92.5/92.4
R306 7030016250 S.RES RMC1/16S-220JTH (22) T 105.0/73.6
R307 7030016250 S.RES RMC1/16S-220JTH (22) T 105.9/73.6
R308 7030016250 S.RES RMC1/16S-220JTH (22) T 106.8/73.6
R309 7030016250 S.RES RMC1/16S-220JTH (22) T 107.7/73.6
R311 7030016110 S.RES RMC1/16S-473JTH (47 k) T 193.6/40.2
R312 7030016110 S.RES RMC1/16S-473JTH (47 k) T 202.9/45.0
R313 7030016110 S.RES RMC1/16S-473JTH (47 k) T 202.9/45.9
R314 7030016110 S.RES RMC1/16S-473JTH (47 k) T 192.6/53.5
R315 7030016110 S.RES RMC1/16S-473JTH (47 k) T 193.5/54.4
R316 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 202.9/48.6
R317 7030016110 S.RES RMC1/16S-473JTH (47 k) T 211.0/31.8
R318 7030016110 S.RES RMC1/16S-473JTH (47 k) T 209.5/31.8
R319 7030016110 S.RES RMC1/16S-473JTH (47 k) T 208.0/31.8
R320 7030016020 S.RES RMC1/16S-104JTH (100 k) T 206.3/37.0
R321 7030016110 S.RES RMC1/16S-473JTH (47 k) T 187.5/45.8
R322 7030016020 S.RES RMC1/16S-104JTH (100 k) T 187.5/49.8
R323 7030016150 S.RES RMC1/16S-100JTH (10) T 187.5/52.3
R331 7030016110 S.RES RMC1/16S-473JTH (47 k) T 110.8/102.3
R332 7030016110 S.RES RMC1/16S-473JTH (47 k) T 112.1/102.3
R333 7030016110 S.RES RMC1/16S-473JTH (47 k) T 113.4/102.3
R334 7030016110 S.RES RMC1/16S-473JTH (47 k) T 111.6/112.9
R335 7030016110 S.RES RMC1/16S-473JTH (47 k) T 112.9/113.2
R336 7030016110 S.RES RMC1/16S-473JTH (47 k) T 113.8/113.2
R337 7030016110 S.RES RMC1/16S-473JTH (47 k) T 108.4/102.7
R371 7030016110 S.RES RMC1/16S-473JTH (47 k) T 196.8/54.2
R372 7030016110 S.RES RMC1/16S-473JTH (47 k) T 195.8/54.2
R373 7030016110 S.RES RMC1/16S-473JTH (47 k) T 88.1/98.8
R374 7030016020 S.RES RMC1/16S-104JTH (100 k) T 88.1/99.7
R375 7030016110 S.RES RMC1/16S-473JTH (47 k) T 93.4/92.4
R376 7030016110 S.RES RMC1/16S-473JTH (47 k) T 94.3/92.4
R377 7030016020 S.RES RMC1/16S-104JTH (100 k) T 92.6/112.7
R378 7030016110 S.RES RMC1/16S-473JTH (47 k) T 194.8/54.2
R379 7030016110 S.RES RMC1/16S-473JTH (47 k) T 88.1/97.9
R380 7030016110 S.RES RMC1/16S-473JTH (47 k) T 95.9/92.4
R381 7030016110 S.RES RMC1/16S-473JTH (47 k) T 107.0/112.7
R382 7030016110 S.RES RMC1/16S-473JTH (47 k) T 104.3/112.7
R383 7030016110 S.RES RMC1/16S-473JTH (47 k) T 105.2/112.7
R384 7030016110 S.RES RMC1/16S-473JTH (47 k) T 103.4/112.7
R385 7030015970 S.RES RMC1/16S-103JTH (10 k) T 91.7/112.7
R386 7030015970 S.RES RMC1/16S-103JTH (10 k) T 90.8/112.7
R394 7030016110 S.RES RMC1/16S-473JTH (47 k) T 108.4/103.6
R395 7030016110 S.RES RMC1/16S-473JTH (47 k) T 108.4/105.4
R396 7030016110 S.RES RMC1/16S-473JTH (47 k) T 108.4/106.3
R397 7030016110 S.RES RMC1/16S-473JTH (47 k) T 108.4/107.2
R411 7030016110 S.RES RMC1/16S-473JTH (47 k) T 202.9/50.9
R412 7030016110 S.RES RMC1/16S-473JTH (47 k) T 201.8/50.9
R413 7030016050 S.RES RMC1/16S-102JTH (1 k) T 202.7/54.1
R414 7030016050 S.RES RMC1/16S-102JTH (1 k) T 201.4/54.8
R421 7030016050 S.RES RMC1/16S-102JTH (1 k) T 88.1/100.6
R422 7030016020 S.RES RMC1/16S-104JTH (100 k) T 94.4/112.7
R423 7030016020 S.RES RMC1/16S-104JTH (100 k) T 93.5/112.7
R431 7030016020 S.RES RMC1/16S-104JTH (100 k) T 102.5/112.7
R432 7030016020 S.RES RMC1/16S-104JTH (100 k) T 101.6/112.7
R433 7030016020 S.RES RMC1/16S-104JTH (100 k) T 100.5/112.7
R434 7030016020 S.RES RMC1/16S-104JTH (100 k) T 99.6/112.7
R435 7030016110 S.RES RMC1/16S-473JTH (47 k) T 91.7/129.9
R440 7030016150 S.RES RMC1/16S-100JTH (10) T 104.7/92.4
R441 7030016150 S.RES RMC1/16S-100JTH (10) T 105.6/92.4
R442 7030016150 S.RES RMC1/16S-100JTH (10) T 106.5/92.4
R443 7030016150 S.RES RMC1/16S-100JTH (10) T 107.1/94.1
R444 7030016150 S.RES RMC1/16S-100JTH (10) T 107.6/92.4
R445 7030016150 S.RES RMC1/16S-100JTH (10) T 108.2/94.1
R446 7030016150 S.RES RMC1/16S-100JTH (10) T 108.7/92.4
R447 7030016150 S.RES RMC1/16S-100JTH (10) T 109.3/94.1
R506 7030016020 S.RES RMC1/16S-104JTH (100 k) T 147.0/102.2
R507 7030016020 S.RES RMC1/16S-104JTH (100 k) T 147.0/104.2
R508 7030016020 S.RES RMC1/16S-104JTH (100 k) T 147.0/106.2
R509 7030016020 S.RES RMC1/16S-104JTH (100 k) T 147.0/108.2
R514 7030016020 S.RES RMC1/16S-104JTH (100 k) T 142.0/107.9
R515 7030016020 S.RES RMC1/16S-104JTH (100 k) T 142.0/110.6
R516 7030016020 S.RES RMC1/16S-104JTH (100 k) T 122.0/106.5
R518 7030016110 S.RES RMC1/16S-473JTH (47 k) T 139.9/114.7
R520 7030016020 S.RES RMC1/16S-104JTH (100 k) T 120.1/102.5
R522 7030016020 S.RES RMC1/16S-104JTH (100 k) T 119.2/102.5
R527 7030016020 S.RES RMC1/16S-104JTH (100 k) T 121.1/107.5
R529 7030016020 S.RES RMC1/16S-104JTH (100 k) T 139.0/112.5
R531 7030016250 S.RES RMC1/16S-220JTH (22) T 125.0/104.5
R532 7030016250 S.RES RMC1/16S-220JTH (22) T 125.0/105.5
R533 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/107.5
R534 7030015970 S.RES RMC1/16S-103JTH (10 k) T 138.1/112.5
R535 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/109.5
R536 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/103.5
R537 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/102.4
R538 7030016020 S.RES RMC1/16S-104JTH (100 k) T 118.9/109.3
R539 7410001140 S.ARR EXB28V104JX T 122.1/97.0

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-4a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
R540 7030016020 S.RES RMC1/16S-104JTH (100 k) T 118.8/110.2
R541 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 134.3/121.5
R543 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 132.8/114.5
R545 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 136.3/121.5
R547 7030016020 S.RES RMC1/16S-104JTH (100 k) T 122.0/105.5
R548 7030016020 S.RES RMC1/16S-104JTH (100 k) T 122.0/104.5
R551 7030016250 S.RES RMC1/16S-220JTH (22) T 125.0/106.5
R552 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/108.5
R553 7030016150 S.RES RMC1/16S-100JTH (10) T 125.0/110.5
R554 7410001240 S.ARR EXB28V220JX T 125.0/98.0
R555 7410001240 S.ARR EXB28V220JX T 125.0/100.5
R556 7030016250 S.RES RMC1/16S-220JTH (22) T 139.9/112.5
R558 7030015910 S.RES RMC1/16S-101JTH (100) T 121.1/109.5
R559 7030015910 S.RES RMC1/16S-101JTH (100) T 121.1/110.4
R571 7030016800 S.RES RMC1/16SK104FTH (100 k) T 133.6/112.5
R572 7030016020 S.RES RMC1/16S-104JTH (100 k) T 130.9/112.5
R573 7030016020 S.RES RMC1/16S-104JTH (100 k) T 131.8/112.5
R574 7030016020 S.RES RMC1/16S-104JTH (100 k) T 135.4/112.5
R575 7030016020 S.RES RMC1/16S-104JTH (100 k) T 136.3/112.5
R576 7030016020 S.RES RMC1/16S-104JTH (100 k) T 129.1/112.5
R577 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/100.6
R578 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/101.5
R579 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/99.7
R580 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/98.8
R583 7030016040 S.RES RMC1/16S-224JTH (220 k) T 121.4/102.4
R584 7030016040 S.RES RMC1/16S-224JTH (220 k) T 122.0/103.5
R1002 7030015910 S.RES RMC1/16S-101JTH (100) T 77.9/134.5
R1004 7030017120 S.RES RGC1/16SC103DTH (10.0 k) T 77.9/137.4
R1005 7030016840 S.RES RGC1/16SC682DTH (6.80 k) T 79.2/136.9
R1006 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 77.9/139.2
R1007 7030016380 S.RES RMC1/16S-183JTH (18 k) T 77.9/140.1
R1008 7030016560 S.RES RMC1/16SJPTH T 76.6/140.5
R1011 7030016560 S.RES RMC1/16SJPTH T 108.2/140.8
R1012 7030016910 S.RES RGC1/16SC393DTH (39 k) T 107.2/140.3
R1013 7030016880 S.RES RGC1/16SC223DTH (22.0 k) T 107.2/142.0
R1021 7030016110 S.RES RMC1/16S-473JTH (47 k) T 143.8/125.0
R1041 7030016560 S.RES RMC1/16SJPTH T 90.9/136.5
R1044 7030016890 S.RES RGC1/16SC363DTH (36 k) T 88.5/134.3
R1045 7030016910 S.RES RGC1/16SC393DTH (39 k) T 88.5/133.4
R1046 7030016890 S.RES RGC1/16SC363DTH (36 k) T 88.5/136.1
R1047 7030016030 S.RES RMC1/16S-154JTH (150 k) T 88.1/138.1
R1048 7030016050 S.RES RMC1/16S-102JTH (1 k) T 89.7/135.5
R1051 7030016110 S.RES RMC1/16S-473JTH (47 k) T 177.9/22.2
R1052 7030016050 S.RES RMC1/16S-102JTH (1 k) T 177.4/24.0
R1053 7030016110 S.RES RMC1/16S-473JTH (47 k) T 180.3/24.7
R1071 7030006200 S.RES ERJ12YJ2R7U (2.7) T 98.8/124.6
R1091 7030010410 S.RES ERJ1TYJ 220U (22) T 29.3/122.0
R1093 7030016110 S.RES RMC1/16S-473JTH (47 k) T 33.8/120.0
R1094 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 27.5/125.3
R1101 7030015910 S.RES RMC1/16S-101JTH (100) T 63.0/134.1
R1103 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 61.5/135.0
R1104 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 63.0/135.0
R1105 7030016810 S.RES RGC1/16SC392DTH (3.90 k) T 63.0/136.8
R1106 7030016810 S.RES RGC1/16SC392DTH (3.90 k) T 63.0/137.7
R1111 7030016560 S.RES RMC1/16SJPTH T 65.9/126.0
R1114 7030016890 S.RES RGC1/16SC363DTH (36 k) T 66.8/128.1
R1115 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 65.9/128.1
R1116 7030016910 S.RES RGC1/16SC393DTH (39 k) T 65.0/128.1
R1117 7030016030 S.RES RMC1/16S-154JTH (150 k) T 67.7/124.8
R1118 7030016050 S.RES RMC1/16S-102JTH (1 k) T 67.3/126.9
R1119 7030015970 S.RES RMC1/16S-103JTH (10 k) T 66.2/112.7
R1202 7030015910 S.RES RMC1/16S-101JTH (100) T 87.2/120.1
R1204 7030016610 S.RES RGC1/16SC683DTH (68.0 k) T 89.0/120.1
R1205 7030016810 S.RES RGC1/16SC392DTH (3.90 k) T 90.3/121.0
R1206 7030017060 S.RES RGC1/16SC162DTH (1.6 k) T 89.4/121.9
R1212 7030015910 S.RES RMC1/16S-101JTH (100) T 62.2/122.9
R1214 7030016610 S.RES RGC1/16SC683DTH (68.0 k) T 58.8/128.5
R1215 7030018480 S.RES RGC1/16SC563DTH (56.0 k) T 60.6/128.5
R1216 7030016840 S.RES RGC1/16SC682DTH (6.80 k) T 61.5/128.5
R1221 7030010470 S.RES ERJ1TYJ 5R6U (5.6) T 18.2/123.0
R1222 7030010470 S.RES ERJ1TYJ 5R6U (5.6) T 22.6/123.0
R1261 7030013780 S.RES RCC16R020FTP T 5.0/21.2
R1262 7030015910 S.RES RMC1/16S-101JTH (100) T 7.2/22.6
R1263 7030008071 S.RES ERA3YED 273V (27 k) T 5.0/17.3
R1264 7030008071 S.RES ERA3YED 273V (27 k) T 6.3/18.1
R1265 7030006581 S.RES ERA3YED 122V (1.2 k) T 7.6/18.1
R1321 7030010580 S.RES ERJ1TYJ 1R5U (1.5) B 57.6/60.0
R1331 7030016470 S.RES RMC1/16S-390JTH (39) T 70.6/65.8
R1332 7030016470 S.RES RMC1/16S-390JTH (39) T 70.6/64.9
R1333 7030016470 S.RES RMC1/16S-390JTH (39) T 70.6/64.0
R1501 7030016380 S.RES RMC1/16S-183JTH (18 k) T 186.8/142.9
R1502 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.8/144.2
R1503 7030016360 S.RES RMC1/16S-123JTH (12 k) T 182.4/141.2
R1504 7030016110 S.RES RMC1/16S-473JTH (47 k) T 182.4/143.1
R1505 7030016020 S.RES RMC1/16S-104JTH (100 k) T 172.9/145.7
R1511 7030016380 S.RES RMC1/16S-183JTH (18 k) T 186.8/148.9
R1512 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.8/150.2
R1513 7030016360 S.RES RMC1/16S-123JTH (12 k) T 182.4/147.2
R1514 7030016110 S.RES RMC1/16S-473JTH (47 k) T 182.4/149.1
R1515 7030016020 S.RES RMC1/16S-104JTH (100 k) T 172.9/147.4
R1516 7030016020 S.RES RMC1/16S-104JTH (100 k) T 182.2/144.4
R1517 7030016250 S.RES RMC1/16S-220JTH (22) T 181.2/143.5
R1518 7030016250 S.RES RMC1/16S-220JTH (22) T 172.5/148.3
R1521 7030016110 S.RES RMC1/16S-473JTH (47 k) T 175.3/140.1
R1531 7030016050 S.RES RMC1/16S-102JTH (1 k) T 172.8/129.5
R1532 7030016060 S.RES RMC1/16S-105JTH (1 M) T 171.9/130.4
R1533 7030016060 S.RES RMC1/16S-105JTH (1 M) T 158.8/130.6
R1534 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 161.4/134.0
R1535 7030015970 S.RES RMC1/16S-103JTH (10 k) T 155.7/130.8
R1551 7030016110 S.RES RMC1/16S-473JTH (47 k) T 145.3/138.0
R1552 7030016110 S.RES RMC1/16S-473JTH (47 k) T 148.3/137.9
R1553 7030016250 S.RES RMC1/16S-220JTH (22) T 145.9/139.9
R1554 7030016250 S.RES RMC1/16S-220JTH (22) T 146.8/139.9
R1555 7030016020 S.RES RMC1/16S-104JTH (100 k) T 145.0/139.9
R1556 7030016250 S.RES RMC1/16S-220JTH (22) T 149.9/137.9
R1557 7030016250 S.RES RMC1/16S-220JTH (22) T 144.1/138.4
R1558 7030016020 S.RES RMC1/16S-104JTH (100 k) T 147.7/139.9
R1559 7030015970 S.RES RMC1/16S-103JTH (10 k) T 148.6/139.9
R1560 7030015970 S.RES RMC1/16S-103JTH (10 k) T 142.5/141.6
R1561 7030016110 S.RES RMC1/16S-473JTH (47 k) T 143.8/148.3
R1562 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 147.9/148.2
R1563 7030015970 S.RES RMC1/16S-103JTH (10 k) T 147.9/147.3
R1571 7030016110 S.RES RMC1/16S-473JTH (47 k) T 154.6/127.5
R1572 7030016110 S.RES RMC1/16S-473JTH (47 k) T 154.4/131.2
R1573 7030016250 S.RES RMC1/16S-220JTH (22) T 152.9/128.7
R1574 7030016250 S.RES RMC1/16S-220JTH (22) T 152.9/129.7
R1575 7030016020 S.RES RMC1/16S-104JTH (100 k) T 152.9/127.7
R1576 7030016250 S.RES RMC1/16S-220JTH (22) T 154.4/133.5
R1577 7030016250 S.RES RMC1/16S-220JTH (22) T 154.6/126.3
R1578 7030016020 S.RES RMC1/16S-104JTH (100 k) T 152.9/130.7
R1579 7030015970 S.RES RMC1/16S-103JTH (10 k) T 152.9/131.7
R1580 7030015970 S.RES RMC1/16S-103JTH (10 k) T 150.4/133.3
R1581 7030016110 S.RES RMC1/16S-473JTH (47 k) T 144.4/127.6
R1582 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 143.9/132.0
R1583 7030015970 S.RES RMC1/16S-103JTH (10 k) T 144.9/132.0
R1601 7030016330 S.RES RMC1/16S-153JTH (15 k) T 152.8/139.7
R1602 7030016520 S.RES RMC1/16S-270JTH (27) T 152.8/140.6
R1603 7030016330 S.RES RMC1/16S-153JTH (15 k) T 152.8/142.4
R1604 7030016520 S.RES RMC1/16S-270JTH (27) T 152.8/141.5
R1605 7030016330 S.RES RMC1/16S-153JTH (15 k) T 158.5/134.4
R1606 7030016520 S.RES RMC1/16S-270JTH (27) T 158.1/135.6
R1607 7030016330 S.RES RMC1/16S-153JTH (15 k) T 156.2/135.6
R1608 7030016520 S.RES RMC1/16S-270JTH (27) T 157.2/135.6
R1609 7030016330 S.RES RMC1/16S-153JTH (15 k) T 162.7/136.0
R1610 7030016520 S.RES RMC1/16S-270JTH (27) T 161.4/135.6
R1611 7030016330 S.RES RMC1/16S-153JTH (15 k) T 160.1/134.4
R1612 7030016520 S.RES RMC1/16S-270JTH (27) T 160.5/135.6
R1613 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 165.8/149.5
R1614 7030016020 S.RES RMC1/16S-104JTH (100 k) T 160.7/149.5
R1615 7030016520 S.RES RMC1/16S-270JTH (27) T 163.7/149.9
R1616 7030016520 S.RES RMC1/16S-270JTH (27) T 164.6/149.9
R1617 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 165.8/143.0
R1618 7030016060 S.RES RMC1/16S-105JTH (1 M) T 165.8/144.6
R1621 7030016050 S.RES RMC1/16S-102JTH (1 k) T 154.1/154.0
R1622 7030016110 S.RES RMC1/16S-473JTH (47 k) T 155.2/148.9
R1901 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/37.8
R1902 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/38.7
R1903 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/39.6
R1904 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/40.5
R1905 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/41.4
R1906 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/42.3
R1907 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/43.2
R1908 7030015910 S.RES RMC1/16S-101JTH (100) T 149.5/44.1
R1909 7030016110 S.RES RMC1/16S-473JTH (47 k) T 145.6/45.9
R1916 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 148.1/44.5
R1917 7030016560 S.RES RMC1/16SJPTH T 148.1/46.2
R1918 7030016270 S.RES RMC1/16S-151JTH (150) T 144.1/37.3
R1919 7030016060 S.RES RMC1/16S-105JTH (1 M) T 144.8/38.2
R1921 7030015910 S.RES RMC1/16S-101JTH (100) T 144.7/45.9
R1922 7030015910 S.RES RMC1/16S-101JTH (100) T 141.7/45.2
R1924 7030015970 S.RES RMC1/16S-103JTH (10 k) T 142.1/36.9
R1925 7030017180 S.RES RMC1/16K1212FTP (12.1 k) T 139.3/38.4
R1926 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 20.5/136.5
R1927 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 18.9/136.5
R1928 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 12.5/136.5
R1929 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 14.1/136.5
R1930 7030016560 S.RES RMC1/16SJPTH T 9.2/138.6
R1931 7030018740 S.RES RMC1/16S-750JTH (75) T 18.4/148.6
R1932 7030018740 S.RES RMC1/16S-750JTH (75) T 13.4/149.0
R1933 7030018740 S.RES RMC1/16S-750JTH (75) T 12.9/151.3
R1934 7030018740 S.RES RMC1/16S-750JTH (75) T 13.8/151.3
R1935 7030016560 S.RES RMC1/16SJPTH T 7.3/149.2
R1936 7030016370 S.RES RMC1/16S-271JTH (270) T 4.9/151.5
R1937 7030016370 S.RES RMC1/16S-271JTH (270) T 16.6/152.0
R2001 7030016560 S.RES RMC1/16SJPTH T 178.4/66.5
R2002 7410001240 S.ARR EXB28V220JX T 180.8/66.5
R2003 7410001240 S.ARR EXB28V220JX T 185.9/66.5
R2004 7030016040 S.RES RMC1/16S-224JTH (220 k) T 187.7/66.5
R2005 7030016560 S.RES RMC1/16SJPTH T 177.4/66.5
R2011 7030016560 S.RES RMC1/16SJPTH T 174.5/80.0
R2012 7030015910 S.RES RMC1/16S-101JTH (100) T 174.5/81.0
R2021 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 192.7/77.9
R2022 7030016050 S.RES RMC1/16S-102JTH (1 k) T 190.3/77.0
R2023 7030016360 S.RES RMC1/16S-123JTH (12 k) T 191.9/77.0
R2024 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 193.1/76.5
R2025 7030015910 S.RES RMC1/16S-101JTH (100) T 193.5/74.3
R2029 7030015910 S.RES RMC1/16S-101JTH (100) T 188.4/69.4
R2031 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 191.3/64.6
R2032 7030016050 S.RES RMC1/16S-102JTH (1 k) T 189.7/66.7
R2033 7030016360 S.RES RMC1/16S-123JTH (12 k) T 191.3/66.7
R2034 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 192.5/67.1
R2035 7030015910 S.RES RMC1/16S-101JTH (100) T 193.4/68.8
R2041 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 145.3/118.5
R2042 7030016050 S.RES RMC1/16S-102JTH (1 k) T 148.8/120.8
R2043 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 146.3/119.9
R2044 7030016500 S.RES RMC1/16S-562JTH (5.6 k) T 146.3/118.5
R2045 7030015910 S.RES RMC1/16S-101JTH (100) T 150.2/122.7
R2049 7030015910 S.RES RMC1/16S-101JTH (100) T 147.7/116.4
R2051 7030016480 S.RES RMC1/16S-821JTH (820) T 158.5/118.5
R2052 7030016050 S.RES RMC1/16S-102JTH (1 k) T 154.8/120.8
R2053 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 157.2/119.9
R2054 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 157.5/118.5
R2055 7030015910 S.RES RMC1/16S-101JTH (100) T 152.2/122.7
R2061 7030016480 S.RES RMC1/16S-821JTH (820) T 159.8/118.5

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-5a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
R2062 7030016050 S.RES RMC1/16S-102JTH (1 k) T 163.2/120.7
R2063 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 160.8/119.9
R2064 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 160.8/118.5
R2065 7030015910 S.RES RMC1/16S-101JTH (100) T 162.6/121.9
R2069 7030015910 S.RES RMC1/16S-101JTH (100) T 161.5/117.0
R2071 7030016480 S.RES RMC1/16S-821JTH (820) T 173.0/118.5
R2072 7030016050 S.RES RMC1/16S-102JTH (1 k) T 169.4/120.7
R2073 7030016430 S.RES RMC1/16S-392JTH (3.9 k) T 171.8/119.9
R2074 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 172.0/118.5
R2075 7030015910 S.RES RMC1/16S-101JTH (100) T 164.4/121.9
R2081 7030016020 S.RES RMC1/16S-104JTH (100 k) T 193.2/55.9
R2082 7030016020 S.RES RMC1/16S-104JTH (100 k) T 195.9/56.9
R2083 7030015910 S.RES RMC1/16S-101JTH (100) T 195.9/58.7
R2084 7030016020 S.RES RMC1/16S-104JTH (100 k) T 195.9/57.8
R2085 7030015970 S.RES RMC1/16S-103JTH (10 k) T 198.8/56.4
R2086 7030016560 S.RES RMC1/16SJPTH T 197.4/55.9
R2089 7030015910 S.RES RMC1/16S-101JTH (100) T 192.4/61.5
R2091 7030016020 S.RES RMC1/16S-104JTH (100 k) T 187.7/58.2
R2092 7030016020 S.RES RMC1/16S-104JTH (100 k) T 188.9/58.0
R2093 7030015910 S.RES RMC1/16S-101JTH (100) T 188.9/59.6
R2094 7030016020 S.RES RMC1/16S-104JTH (100 k) T 186.3/58.5
R2095 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.3/56.7
R2096 7030016560 S.RES RMC1/16SJPTH T 188.5/56.8
R2101 7410001240 S.ARR EXB28V220JX T 158.5/93.2
R2102 7030016250 S.RES RMC1/16S-220JTH (22) T 158.5/94.9
R2103 7030015910 S.RES RMC1/16S-101JTH (100) T 162.9/104.1
R2111 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 160.0/105.2
R2112 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 161.0/105.2
R2113 7030016110 S.RES RMC1/16S-473JTH (47 k) T 161.0/107.0
R2114 7030015970 S.RES RMC1/16S-103JTH (10 k) T 160.0/108.8
R2121 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 166.6/102.1
R2122 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 168.4/102.1
R2123 7030015990 S.RES RMC1/16S-683JTH (68 k) T 168.4/104.1
R2124 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 172.5/103.5
R2125 7030016050 S.RES RMC1/16S-102JTH (1 k) T 175.5/101.5
R2126 7030015920 S.RES RMC1/16S-221JTH (220) T 175.0/100.0
R2127 7030015970 S.RES RMC1/16S-103JTH (10 k) T 170.1/110.0
R2128 7030016380 S.RES RMC1/16S-183JTH (18 k) T 170.1/108.0
R2129 7030016380 S.RES RMC1/16S-183JTH (18 k) T 170.1/109.0
R2131 7030016110 S.RES RMC1/16S-473JTH (47 k) T 168.0/111.0
R2132 7030016110 S.RES RMC1/16S-473JTH (47 k) T 164.1/114.2
R2133 7030016110 S.RES RMC1/16S-473JTH (47 k) T 164.1/115.2
R2134 7030016560 S.RES RMC1/16SJPTH T 165.9/114.2
R2135 7030016330 S.RES RMC1/16S-153JTH (15 k) T 165.9/115.2
R2136 7030015970 S.RES RMC1/16S-103JTH (10 k) T 163.7/112.8
R2137 7030016380 S.RES RMC1/16S-183JTH (18 k) T 162.3/115.2
R2138 7030016380 S.RES RMC1/16S-183JTH (18 k) T 162.3/114.2
R2201 7030007160 S.RES ERJ12YJ3R3U (3.3) B 198.9/69.3
R2202 7030007160 S.RES ERJ12YJ3R3U (3.3) B 194.7/69.3
R2203 7030015970 S.RES RMC1/16S-103JTH (10 k) T 186.7/85.0
R2204 7030016380 S.RES RMC1/16S-183JTH (18 k) T 192.6/93.7
R2205 7030016330 S.RES RMC1/16S-153JTH (15 k) T 194.2/93.2
R2206 7030015970 S.RES RMC1/16S-103JTH (10 k) T 194.2/94.1
R2207 7030016110 S.RES RMC1/16S-473JTH (47 k) T 185.5/92.1
R2208 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 197.1/123.7
R2209 7030016150 S.RES RMC1/16S-100JTH (10) T 196.2/121.9
R2212 7030016050 S.RES RMC1/16S-102JTH (1 k) T 189.2/85.5
R2223 7030015970 S.RES RMC1/16S-103JTH (10 k) T 200.8/85.0
R2224 7030016380 S.RES RMC1/16S-183JTH (18 k) T 206.7/93.7
R2225 7030016330 S.RES RMC1/16S-153JTH (15 k) T 208.3/93.2
R2226 7030015970 S.RES RMC1/16S-103JTH (10 k) T 208.3/94.1
R2227 7030016110 S.RES RMC1/16S-473JTH (47 k) T 199.6/92.1
R2228 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 198.9/123.7
R2229 7030016150 S.RES RMC1/16S-100JTH (10) T 199.8/121.9
R2241 7030016270 S.RES RMC1/16S-151JTH (150) T 191.4/131.0
R2242 7030016270 S.RES RMC1/16S-151JTH (150) T 207.0/142.0
R2243 7030015930 S.RES RMC1/16S-471JTH (470) T 207.0/144.0
R2251 7030016270 S.RES RMC1/16S-151JTH (150) T 207.3/127.3
R2252 7030016270 S.RES RMC1/16S-151JTH (150) T 191.5/142.0
R2253 7030015930 S.RES RMC1/16S-471JTH (470) T 191.5/144.0
R2501 7030015930 S.RES RMC1/16S-471JTH (470) T 126.7/20.9
R2502 7030016320 S.RES RMC1/16S-225JTH (2.2 M) T 128.5/20.9
R2503 7030016070 S.RES RMC1/16S-474JTH (470 k) T 129.7/21.3
R2504 7030016110 S.RES RMC1/16S-473JTH (47 k) T 132.2/22.5
R2505 7030016380 S.RES RMC1/16S-183JTH (18 k) T 128.0/24.0
R2506 7030016000 S.RES RMC1/16S-823JTH (82 k) T 128.0/23.1
R2507 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 129.7/20.4
R2510 7030015910 S.RES RMC1/16S-101JTH (100) T 124.1/19.3
R2511 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 126.8/28.7
R2512 7030016080 S.RES RMC1/16S-822JTH (8.2 k) T 125.6/28.4
R2513 7030016320 S.RES RMC1/16S-225JTH (2.2 M) T 128.5/27.0
R2514 7030016560 S.RES RMC1/16SJPTH T 128.0/28.2
R2515 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 129.8/28.2
R2516 7030016020 S.RES RMC1/16S-104JTH (100 k) T 129.4/27.0
R2517 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 128.5/25.4
R2518 7030016000 S.RES RMC1/16S-823JTH (82 k) T 129.7/24.9
R2519 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 132.0/30.7
R2521 7030015930 S.RES RMC1/16S-471JTH (470) T 119.3/20.9
R2522 7030016320 S.RES RMC1/16S-225JTH (2.2 M) T 117.5/20.9
R2523 7030016070 S.RES RMC1/16S-474JTH (470 k) T 116.1/21.3
R2524 7030016110 S.RES RMC1/16S-473JTH (47 k) T 114.3/23.1
R2525 7030016380 S.RES RMC1/16S-183JTH (18 k) T 117.9/24.0
R2526 7030016000 S.RES RMC1/16S-823JTH (82 k) T 117.9/23.1
R2527 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 116.1/20.4
R2531 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 119.1/28.7
R2532 7030015970 S.RES RMC1/16S-103JTH (10 k) T 120.3/28.4
R2533 7030016320 S.RES RMC1/16S-225JTH (2.2 M) T 117.5/27.0
R2534 7030016560 S.RES RMC1/16SJPTH T 117.9/28.2
R2535 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 116.1/28.2
R2536 7030016020 S.RES RMC1/16S-104JTH (100 k) T 116.6/27.0
R2537 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 117.5/25.4
R2538 7030016000 S.RES RMC1/16S-823JTH (82 k) T 116.1/24.9
R2539 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 114.2/32.6
R2541 7030015940 S.RES RMC1/16S-681JTH (680) T 103.7/21.3
R2542 7030016320 S.RES RMC1/16S-225JTH (2.2 M) T 105.5/21.3
R2543 7030016070 S.RES RMC1/16S-474JTH (470 k) T 106.8/21.7
R2544 7030016110 S.RES RMC1/16S-473JTH (47 k) T 108.4/23.5
R2545 7030016380 S.RES RMC1/16S-183JTH (18 k) T 105.0/24.4
R2546 7030016000 S.RES RMC1/16S-823JTH (82 k) T 105.0/23.5
R2547 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 106.8/20.8
R2550 7030015910 S.RES RMC1/16S-101JTH (100) T 101.1/19.9
R2551 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 103.4/28.6
R2552 7030015970 S.RES RMC1/16S-103JTH (10 k) T 100.5/30.5
R2553 7030016320 S.RES RMC1/16S-225JTH (2.2 M) T 105.5/27.4
R2554 7030016560 S.RES RMC1/16SJPTH T 105.0/28.6
R2555 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 106.8/28.6
R2556 7030016020 S.RES RMC1/16S-104JTH (100 k) T 106.4/27.4
R2557 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 105.5/25.8
R2558 7030016000 S.RES RMC1/16S-823JTH (82 k) T 106.8/25.3
R2559 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 110.4/29.6
R2561 7030016710 S.RES RMC1/16S-106JTH (10 M) T 77.2/26.7
R2562 7030016790 S.RES RMC1/16S-335JTH (3.3 M) T 76.7/27.9
R2567 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 86.9/25.1
R2568 7030016350 S.RES RMC1/16S-122JTH (1.2 k) T 86.0/24.2
R2569 7030016090 S.RES RMC1/16S-223JTH (22 k) T 88.1/25.6
R2571 7030015930 S.RES RMC1/16S-471JTH (470) T 95.1/28.9
R2572 7030016200 S.RES RMC1/16S-274JTH (270 k) T 94.6/27.6
R2573 7030015970 S.RES RMC1/16S-103JTH (10 k) T 94.2/28.9
R2575 7030016100 S.RES RMC1/16S-334JTH (330 k) T 95.1/25.9
R2581 7030015910 S.RES RMC1/16S-101JTH (100) T 96.1/22.2
R2582 7030016400 S.RES RMC1/16S-564JTH (560 k) T 95.1/23.9
R2583 7030016020 S.RES RMC1/16S-104JTH (100 k) T 94.2/23.9
R2584 7030016110 S.RES RMC1/16S-473JTH (47 k) T 92.8/23.5
R2585 7030016110 S.RES RMC1/16S-473JTH (47 k) T 92.7/24.8
R2586 7030015970 S.RES RMC1/16S-103JTH (10 k) T 94.2/25.9
R2587 7510001671 S.THR NTCG16 4BH 103JT T 92.5/26.5
R2591 7030015930 S.RES RMC1/16S-471JTH (470) T 112.3/23.1
R2592 7030016040 S.RES RMC1/16S-224JTH (220 k) T 110.5/23.1
R2593 7030015970 S.RES RMC1/16S-103JTH (10 k) T 111.4/23.8
R2594 7030016020 S.RES RMC1/16S-104JTH (100 k) T 109.0/27.6
R2601 7030015970 S.RES RMC1/16S-103JTH (10 k) T 91.3/25.1
R2602 7030016140 S.RES RMC1/16S-124JTH (120 k) T 87.2/27.5
R2603 7030015910 S.RES RMC1/16S-101JTH (100) T 87.2/26.6
R2605 7030015990 S.RES RMC1/16S-683JTH (68 k) T 87.2/32.6
R2606 7030016200 S.RES RMC1/16S-274JTH (270 k) T 86.8/28.7
R2607 7030016090 S.RES RMC1/16S-223JTH (22 k) T 87.2/31.7
R2608 7030016150 S.RES RMC1/16S-100JTH (10) T 90.4/25.1
R2610 7030015910 S.RES RMC1/16S-101JTH (100) T 83.7/26.8
R2611 7030015910 S.RES RMC1/16S-101JTH (100) T 74.9/33.4
R2612 7030016790 S.RES RMC1/16S-335JTH (3.3 M) T 76.7/32.1
R2613 7030016310 S.RES RMC1/16S-155JTH (1.5 M) T 75.3/32.5
R2614 7030016720 S.RES RMC1/16S-185JTH (1.8 M) T 77.1/30.7
R2615 7030015990 S.RES RMC1/16S-683JTH (68 k) T 75.3/30.7
R2617 7030016380 S.RES RMC1/16S-183JTH (18 k) T 75.3/29.8
R2621 7030015970 S.RES RMC1/16S-103JTH (10 k) T 111.4/13.7
R2622 7030015970 S.RES RMC1/16S-103JTH (10 k) T 111.4/12.8
R2623 7030016020 S.RES RMC1/16S-104JTH (100 k) T 109.9/12.1
R2624 7030015980 S.RES RMC1/16S-333JTH (33 k) T 109.9/13.7
R2625 7030015970 S.RES RMC1/16S-103JTH (10 k) T 110.4/17.6
R2626 7030015910 S.RES RMC1/16S-101JTH (100) T 109.5/16.9
R2628 7030016560 S.RES RMC1/16SJPTH T 109.5/15.3
R2630 7030015910 S.RES RMC1/16S-101JTH (100) T 108.1/17.5
R2631 7030015970 S.RES RMC1/16S-103JTH (10 k) T 101.2/12.8
R2632 7030015980 S.RES RMC1/16S-333JTH (33 k) T 102.4/12.4
R2633 7030016110 S.RES RMC1/16S-473JTH (47 k) T 103.3/12.4
R2634 7030016020 S.RES RMC1/16S-104JTH (100 k) T 103.3/14.0
R2635 7030015970 S.RES RMC1/16S-103JTH (10 k) T 104.5/17.8
R2636 7030015910 S.RES RMC1/16S-101JTH (100) T 103.6/17.8
R2637 7030016560 S.RES RMC1/16SJPTH T 102.8/11.2
R2638 7030016560 S.RES RMC1/16SJPTH T 103.7/15.2
R2646 7030018130 S.RES RMC1/16SK472FTH (4.7 k) T 163.5/20.6
R2647 7030016900 S.RES RMC1/16SK102FTH (1 k) T 161.7/20.6
R2651 7030015910 S.RES RMC1/16S-101JTH (100) T 147.8/32.2
R2652 7030008270 S.RES RR0510P-104-D (100 k) T 140.5/31.5
R2653 7030008270 S.RES RR0510P-104-D (100 k) T 141.4/31.5
R2654 7030016020 S.RES RMC1/16S-104JTH (100 k) T 140.5/29.8
R2655 7030016110 S.RES RMC1/16S-473JTH (47 k) T 141.4/29.8
R2656 7030008270 S.RES RR0510P-104-D (100 k) T 142.3/31.5
R2657 7030008270 S.RES RR0510P-104-D (100 k) T 149.7/30.8
R2658 7030016020 S.RES RMC1/16S-104JTH (100 k) T 150.6/29.2
R2659 7030016020 S.RES RMC1/16S-104JTH (100 k) T 149.7/29.2
R2660 7030008270 S.RES RR0510P-104-D (100 k) T 148.8/30.8
R2801 7410001230 S.ARR EXB28V101JX T 112.0/53.2
R2802 7410001230 S.ARR EXB28V101JX T 114.3/42.1
R2811 7410001230 S.ARR EXB28V101JX T 118.6/52.0
R2812 7410001230 S.ARR EXB28V101JX T 119.3/42.1
R2821 7410001230 S.ARR EXB28V101JX T 125.2/52.0
R2822 7410001230 S.ARR EXB28V101JX T 125.9/42.1
R2851 7410001230 S.ARR EXB28V101JX T 134.0/41.6
R2852 7410001230 S.ARR EXB28V101JX T 131.5/41.6
R2853 7410001230 S.ARR EXB28V101JX T 129.0/41.6
R2861 7030016020 S.RES RMC1/16S-104JTH (100 k) T 138.0/31.3
R2863 7030016230 S.RES RMC1/16S-394JTH (390 k) T 136.4/31.3
R2864 7030015910 S.RES RMC1/16S-101JTH (100) T 135.5/32.2
R2870 7030015910 S.RES RMC1/16S-101JTH (100) T 134.8/30.5
R2871 7030016110 S.RES RMC1/16S-473JTH (47 k) T 137.8/23.4
R2872 7030016070 S.RES RMC1/16S-474JTH (470 k) T 137.4/25.2
R2873 7030016000 S.RES RMC1/16S-823JTH (82 k) T 136.2/24.3
R2874 7030015910 S.RES RMC1/16S-101JTH (100) T 135.6/25.2
R2875 7030015970 S.RES RMC1/16S-103JTH (10 k) T 135.2/22.8
R2876 7030016150 S.RES RMC1/16S-100JTH (10) T 134.2/22.8
R2881 7030015930 S.RES RMC1/16S-471JTH (470) T 133.9/125.0
R2891 7030016560 S.RES RMC1/16SJPTH T 185.5/159.9
R2901 7030015910 S.RES RMC1/16S-101JTH (100) T 152.3/159.2

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-6a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
R2902 7030015910 S.RES RMC1/16S-101JTH (100) T 143.0/157.3
R2903 7030015910 S.RES RMC1/16S-101JTH (100) T 142.0/151.9
R2921 7030015980 S.RES RMC1/16S-333JTH (33 k) T 122.0/142.3
R2922 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 120.9/142.3
R2923 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 126.4/143.2
R2924 7030016330 S.RES RMC1/16S-153JTH (15 k) T 122.9/142.3
R2931 7030015980 S.RES RMC1/16S-333JTH (33 k) T 133.8/141.5
R2932 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 133.8/142.4
R2933 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 132.2/138.5
R2934 7030016330 S.RES RMC1/16S-153JTH (15 k) T 133.8/140.6
R2935 7030016270 S.RES RMC1/16S-151JTH (150) T 136.8/139.4
R2936 7030015970 S.RES RMC1/16S-103JTH (10 k) T 138.1/138.9
R2941 7030015910 S.RES RMC1/16S-101JTH (100) T 134.0/144.2
R2942 7030016020 S.RES RMC1/16S-104JTH (100 k) T 133.1/144.2
R2951 7030015970 S.RES RMC1/16S-103JTH (10 k) T 120.0/142.3
R2961 7030019670 S.RES RMC1/16K392FTP (3.9 k) T 129.8/34.7
R2962 7030019790 S.RES RMC1/16K334FTP (330 k) T 129.8/36.2
R2963 7030019720 S.RES RMC1/16K222FTP (2.2 k) T 127.8/35.5
R2964 7030018540 S.RES RMC1/16K563FTP (56 k) T 115.6/35.3
R2965 7030018540 S.RES RMC1/16K563FTP (56 k) T 117.5/35.6
R2966 7030018540 S.RES RMC1/16K563FTP (56 k) T 129.8/37.5
R2967 7030018540 S.RES RMC1/16K563FTP (56 k) T 127.8/38.2
R2968 7030018540 S.RES RMC1/16K563FTP (56 k) T 115.1/37.2
R2969 7030019680 S.RES RMC1/16K393FTP (39 k) T 116.3/37.2
R2971 7030015910 S.RES RMC1/16S-101JTH (100) T 113.5/35.9
R3002 7030016560 S.RES RMC1/16SJPTH T 65.2/43.4
R3011 7030016050 S.RES RMC1/16S-102JTH (1 k) T 59.6/39.3
R3012 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 58.4/38.9
R3013 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 60.8/39.8
R3014 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 60.8/38.9
R3015 7030016410 S.RES RMC1/16S-561JTH (560) T 66.8/41.0
R3016 7030016050 S.RES RMC1/16S-102JTH (1 k) T 66.8/38.9
R3017 7030016160 S.RES RMC1/16S-820JTH (82) T 70.1/39.9
R3018 7030016410 S.RES RMC1/16S-561JTH (560) T 66.8/38.0
R3021 7030016050 S.RES RMC1/16S-102JTH (1 k) T 59.6/33.2
R3022 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 58.4/32.8
R3023 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 60.8/33.7
R3024 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 60.8/32.8
R3025 7030016410 S.RES RMC1/16S-561JTH (560) T 66.8/34.9
R3026 7030016050 S.RES RMC1/16S-102JTH (1 k) T 66.8/32.8
R3027 7030016160 S.RES RMC1/16S-820JTH (82) T 70.1/33.8
R3028 7030016410 S.RES RMC1/16S-561JTH (560) T 66.8/31.9
R3031 7030016050 S.RES RMC1/16S-102JTH (1 k) T 63.2/20.2
R3032 7030016110 S.RES RMC1/16S-473JTH (47 k) T 63.2/19.3
R3033 7030016130 S.RES RMC1/16S-150JTH (15) T 71.3/23.1
R3041 7030016050 S.RES RMC1/16S-102JTH (1 k) T 59.6/26.7
R3042 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 58.4/27.1
R3043 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 60.8/27.1
R3044 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 60.8/26.2
R3045 7030016410 S.RES RMC1/16S-561JTH (560) T 66.8/28.3
R3046 7030016050 S.RES RMC1/16S-102JTH (1 k) T 66.8/27.4
R3047 7030016160 S.RES RMC1/16S-820JTH (82) T 70.1/26.4
R3048 7030016410 S.RES RMC1/16S-561JTH (560) T 66.8/25.3
R3052 7030016560 S.RES RMC1/16SJPTH T 64.2/22.5
R3061 7030016050 S.RES RMC1/16S-102JTH (1 k) T 87.1/19.8
R3062 7030016050 S.RES RMC1/16S-102JTH (1 k) T 87.2/15.7
R3063 7030016050 S.RES RMC1/16S-102JTH (1 k) T 82.1/19.8
R3064 7030016400 S.RES RMC1/16S-564JTH (560 k) T 85.5/20.0
R3071 7030016370 S.RES RMC1/16S-271JTH (270) T 72.8/12.4
R3072 7030016570 S.RES RMC1/16S-180JTH (18) T 74.0/12.3
R3073 7030016370 S.RES RMC1/16S-271JTH (270) T 76.5/12.3
R3101 7030016110 S.RES RMC1/16S-473JTH (47 k) T 36.4/15.7
R3102 7030016110 S.RES RMC1/16S-473JTH (47 k) T 40.7/15.7
R3111 7030016110 S.RES RMC1/16S-473JTH (47 k) T 46.4/15.7
R3112 7030016110 S.RES RMC1/16S-473JTH (47 k) T 50.7/15.7
R3121 7030016110 S.RES RMC1/16S-473JTH (47 k) T 57.1/14.8
R3122 7030016110 S.RES RMC1/16S-473JTH (47 k) T 57.7/15.8
R3131 7030016050 S.RES RMC1/16S-102JTH (1 k) T 52.9/11.0
R3132 7030016050 S.RES RMC1/16S-102JTH (1 k) T 53.3/9.6
R3133 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 54.5/10.1
R3134 7030016110 S.RES RMC1/16S-473JTH (47 k) T 52.4/9.6
R3135 7030016050 S.RES RMC1/16S-102JTH (1 k) T 51.6/6.5
R3141 7030016410 S.RES RMC1/16S-561JTH (560) T 13.0/26.2
R3142 7030016560 S.RES RMC1/16SJPTH T 15.5/21.2
R3143 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 12.4/23.0
R3144 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 12.4/24.6
R3145 7030016410 S.RES RMC1/16S-561JTH (560) T 16.9/21.7
R3146 7030016050 S.RES RMC1/16S-102JTH (1 k) T 17.3/22.7
R3147 7030016270 S.RES RMC1/16S-151JTH (150) T 18.4/25.2
R3148 7030016410 S.RES RMC1/16S-561JTH (560) T 17.6/26.4
R3149 7030016560 S.RES RMC1/16SJPTH T 16.2/26.1
R3151 7030016270 S.RES RMC1/16S-151JTH (150) T 17.9/27.8
R3152 7030016020 S.RES RMC1/16S-104JTH (100 k) T 55.1/24.6
R3153 7030015970 S.RES RMC1/16S-103JTH (10 k) T 56.1/24.6
R3161 7030015920 S.RES RMC1/16S-221JTH (220) T 21.1/44.2
R3162 7030016020 S.RES RMC1/16S-104JTH (100 k) T 19.1/39.1
R3163 7030016020 S.RES RMC1/16S-104JTH (100 k) T 19.4/42.6
R3181 7030016560 S.RES RMC1/16SJPTH T 16.3/45.0
R3182 7030016110 S.RES RMC1/16S-473JTH (47 k) T 18.7/46.1
R3183 7030016110 S.RES RMC1/16S-473JTH (47 k) T 13.8/46.1
R3184 7030016110 S.RES RMC1/16S-473JTH (47 k) T 13.8/60.2
R3185 7030016110 S.RES RMC1/16S-473JTH (47 k) T 18.4/59.8
R3186 7030016110 S.RES RMC1/16S-473JTH (47 k) T 12.7/44.9
R3341 7030016410 S.RES RMC1/16S-561JTH (560) T 40.0/22.5
R3342 7030016560 S.RES RMC1/16SJPTH T 44.9/25.2
R3343 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 43.2/21.9
R3344 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 41.6/21.9
R3345 7030016410 S.RES RMC1/16S-561JTH (560) T 44.5/26.4
R3346 7030016050 S.RES RMC1/16S-102JTH (1 k) T 43.4/26.8
R3347 7030016270 S.RES RMC1/16S-151JTH (150) T 41.0/27.9
R3348 7030016410 S.RES RMC1/16S-561JTH (560) T 39.7/27.1
R3349 7030016560 S.RES RMC1/16SJPTH T 40.0/25.7
R3351 7030016270 S.RES RMC1/16S-151JTH (150) T 38.4/27.4
R3352 7030016020 S.RES RMC1/16S-104JTH (100 k) T 52.8/28.0
R3353 7030015970 S.RES RMC1/16S-103JTH (10 k) T 53.8/28.0
R3361 7030015920 S.RES RMC1/16S-221JTH (220) T 36.6/39.3
R3362 7030016020 S.RES RMC1/16S-104JTH (100 k) T 34.6/34.2
R3363 7030016020 S.RES RMC1/16S-104JTH (100 k) T 35.0/37.7
R3381 7030016560 S.RES RMC1/16SJPTH T 32.9/40.9
R3382 7030016110 S.RES RMC1/16S-473JTH (47 k) T 37.7/41.7
R3383 7030016110 S.RES RMC1/16S-473JTH (47 k) T 32.8/42.0
R3384 7030016110 S.RES RMC1/16S-473JTH (47 k) T 32.8/54.1
R3385 7030016110 S.RES RMC1/16S-473JTH (47 k) T 37.7/54.1
R3386 7030016110 S.RES RMC1/16S-473JTH (47 k) T 30.9/42.5
R3501 7030010570 S.RES ERJ1TYJ 4R7U (4.7) B 22.2/25.2
R3511 7030010570 S.RES ERJ1TYJ 4R7U (4.7) B 39.6/32.0
R7204 7030009691 S.RES ERA3YED 101V (100) T 45.9/45.2
R7206 7030009691 S.RES ERA3YED 101V (100) T 45.9/49.0
R7209 7030009820 S.RES RR0510P-681-D (680) T 32.9/70.9
R7210 7030005990 S.RES RR0510P-122-D (1.2 k) T 34.1/72.1
R7211 7030005990 S.RES RR0510P-122-D (1.2 k) T 33.5/71.5
R7212 7030015910 S.RES RMC1/16S-101JTH (100) B 46.6/62.6
R7301 7030016470 S.RES RMC1/16S-390JTH (39) T 22.2/61.2
R7302 7030016520 S.RES RMC1/16S-270JTH (27) T 21.3/59.4
R7303 7030016520 S.RES RMC1/16S-270JTH (27) T 21.3/60.3
R7352 7030015900 S.RES RMC1/16S-470JTH (47) T 12.1/79.3
R7353 7030015900 S.RES RMC1/16S-470JTH (47) T 13.9/79.3
R7354 7030016150 S.RES RMC1/16S-100JTH (10) T 13.5/80.5
R7355 7030016510 S.RES RMC1/16S-4R7JTH (4.7) T 23.3/102.2
R7356 7030016510 S.RES RMC1/16S-4R7JTH (4.7) T 23.3/101.3
R7357 7030015910 S.RES RMC1/16S-101JTH (100) T 24.5/101.7
R7402 7030015900 S.RES RMC1/16S-470JTH (47) T 22.6/79.3
R7403 7030015900 S.RES RMC1/16S-470JTH (47) T 24.4/79.3
R7404 7030016150 S.RES RMC1/16S-100JTH (10) T 23.1/80.5
R7405 7030016510 S.RES RMC1/16S-4R7JTH (4.7) T 23.3/98.2
R7406 7030016510 S.RES RMC1/16S-4R7JTH (4.7) T 23.3/97.3
R7407 7030015910 S.RES RMC1/16S-101JTH (100) T 24.5/97.7
R7451 7030016470 S.RES RMC1/16S-390JTH (39) T 29.0/54.5
R7452 7030016520 S.RES RMC1/16S-270JTH (27) T 30.6/54.5
R7453 7030016520 S.RES RMC1/16S-270JTH (27) T 29.0/55.4
R7501 7030016050 S.RES RMC1/16S-102JTH (1 k) T 22.5/103.7
R7510 7030015910 S.RES RMC1/16S-101JTH (100) T 29.7/93.1
R7511 7030015900 S.RES RMC1/16S-470JTH (47) T 57.5/73.0
R7512 7030015900 S.RES RMC1/16S-470JTH (47) T 57.5/75.1
R7513 7030016510 S.RES RMC1/16S-4R7JTH (4.7) T 29.3/91.9
R7514 7030016510 S.RES RMC1/16S-4R7JTH (4.7) T 30.2/91.9
R7903 7030015970 S.RES RMC1/16S-103JTH (10 k) T 65.6/108.8
R7904 7030015970 S.RES RMC1/16S-103JTH (10 k) T 74.2/108.0
R7931 7410001240 S.ARR EXB28V220JX T 49.5/105.7
R7932 7030016050 S.RES RMC1/16S-102JTH (1 k) T 46.0/105.8
R8101 7030016250 S.RES RMC1/16S-220JTH (22) T 73.2/81.5
R8102 7030016250 S.RES RMC1/16S-220JTH (22) T 84.5/108.8
R8103 7030016250 S.RES RMC1/16S-220JTH (22) T 84.5/106.6
R8104 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/107.2
R8105 7030016250 S.RES RMC1/16S-220JTH (22) T 84.5/107.7
R8106 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/98.4
R8107 7030016560 S.RES RMC1/16SJPTH T 72.5/108.4
R8108 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/106.1
R8109 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/108.3
R8110 7030016560 S.RES RMC1/16SJPTH T 83.0/96.2
R8111 7030016250 S.RES RMC1/16S-220JTH (22) T 84.5/103.3
R8112 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/102.2
R8113 7030016560 S.RES RMC1/16SJPTH T 84.5/96.7
R8114 7030016250 S.RES RMC1/16S-220JTH (22) T 84.5/100.0
R8115 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/87.8
R8116 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/89.5
R8117 7030015910 S.RES RMC1/16S-101JTH (100) T 78.6/111.2
R8118 7030016560 S.RES RMC1/16SJPTH T 84.5/93.4
R8119 7030015910 S.RES RMC1/16S-101JTH (100) T 79.6/111.2
R8120 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/105.0
R8121 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/99.5
R8122 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/86.7
R8123 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/86.2
R8124 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/88.9
R8125 7030016250 S.RES RMC1/16S-220JTH (22) T 83.0/100.6
R8126 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/91.1
R8127 7030016250 S.RES RMC1/16S-220JTH (22) T 84.5/98.9
R8128 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/91.7
R8129 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/87.3
R8130 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/92.2
R8131 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/90.0
R8132 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/84.0
R8133 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/90.6
R8134 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/88.4
R8135 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/85.6
R8136 7030016150 S.RES RMC1/16S-100JTH (10) T 84.5/84.5
R8137 7030016150 S.RES RMC1/16S-100JTH (10) T 83.0/85.1
R8138 7030016250 S.RES RMC1/16S-220JTH (22) T 84.5/105.5
R8139 7030016560 S.RES RMC1/16SJPTH T 83.0/92.8
R8140 7030016250 S.RES RMC1/16S-220JTH (22) T 88.9/74.2
R8141 7030016250 S.RES RMC1/16S-220JTH (22) T 91.6/74.2
R8142 7030016250 S.RES RMC1/16S-220JTH (22) T 92.5/74.2
R8143 7030016250 S.RES RMC1/16S-220JTH (22) T 90.7/74.2
R8144 7030016250 S.RES RMC1/16S-220JTH (22) T 89.8/74.2
R8301 7030017800 S.RES RMC1/16S-202JTH (2 k) T 78.2/108.7
R8601 7030016050 S.RES RMC1/16S-102JTH (1 k) T 110.9/35.6
R8604 7030016360 S.RES RMC1/16S-123JTH (12 k) T 107.6/40.5
R8606 7030015920 S.RES RMC1/16S-221JTH (220) T 104.0/40.6
R8607 7030016170 S.RES RMC1/16S-560JTH (56) T 104.7/36.7
R8608 7030015900 S.RES RMC1/16S-470JTH (47) T 101.9/40.7
R8609 7030015930 S.RES RMC1/16S-471JTH (470) T 100.6/41.6
R8621 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 100.6/40.4
R8622 7030016280 S.RES RMC1/16S-331JTH (330) T 102.0/38.1
R8623 7030016050 S.RES RMC1/16S-102JTH (1 k) T 98.9/39.5

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-7a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
R8624 7030016580 S.RES RMC1/16S-6R8JTH (6.8) T 98.9/37.7
R8641 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 80.2/38.2
R8642 7030016370 S.RES RMC1/16S-271JTH (270) T 81.8/39.1
R8643 7030016050 S.RES RMC1/16S-102JTH (1 k) T 78.6/39.1
R8644 7030016600 S.RES RMC1/16S-8R2JTH (8.2) T 79.7/40.0
R8661 7030016440 S.RES RMC1/16S-272JTH (2.7 k) T 87.7/62.4
R8662 7030016490 S.RES RMC1/16S-391JTH (390) T 86.5/63.7
R8663 7030016050 S.RES RMC1/16S-102JTH (1 k) T 89.1/63.5
R8664 7030016650 S.RES RMC1/16S-5R6JTH (5.6) T 89.1/65.1
R8665 7030015910 S.RES RMC1/16S-101JTH (100) T 63.8/70.3
R8692 7030015970 S.RES RMC1/16S-103JTH (10 k) T 88.2/43.0
R8693 7030015900 S.RES RMC1/16S-470JTH (47) T 89.6/52.6
R8694 7030015900 S.RES RMC1/16S-470JTH (47) T 87.7/52.6
R8695 7030015900 S.RES RMC1/16S-470JTH (47) T 85.3/52.2
R8700 7030012340 S.RES RR0510P-821-D T 68.2/49.6
R8701 7030006461 S.RES ERA3YED 152V (1.5 k) T 73.9/55.3
R8702 7030008061 S.RES ERA3YED 222V (2.2 k) T 72.1/56.1
R8703 7030008250 S.RES RR0510P-562-D (5.6 k) T 68.7/50.8
R8704 7030009190 S.RES RR0510P-332-D (3.3 k) T 67.8/50.8
R8705 7410001240 S.ARR EXB28V220JX T 69.6/61.5
R8706 7030017610 S.RES RMC1/16SK221FTH (220) T 62.0/49.2
R8707 7030017610 S.RES RMC1/16SK221FTH (220) T 62.0/51.2
R8708 7030017610 S.RES RMC1/16SK221FTH (220) T 61.5/54.0
R8709 7030017610 S.RES RMC1/16SK221FTH (220) T 60.6/54.0
R8712 7030017610 S.RES RMC1/16SK221FTH (220) T 60.5/58.7
R8713 7030017610 S.RES RMC1/16SK221FTH (220) T 61.5/58.7
R8716 7030016560 S.RES RMC1/16SJPTH T 56.9/55.2
R8719 7030016560 S.RES RMC1/16SJPTH T 56.8/57.5
R8801 7030016470 S.RES RMC1/16S-390JTH (39) T 10.0/111.7
R8802 7030016270 S.RES RMC1/16S-151JTH (150) T 9.1/111.7
R8803 7030016270 S.RES RMC1/16S-151JTH (150) T 8.7/113.0
R8804 7030015900 S.RES RMC1/16S-470JTH (47) T 11.7/110.5
R8805 7030016370 S.RES RMC1/16S-271JTH (270) T 11.7/109.6
R8806 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 12.9/112.2
R8807 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 15.0/111.8
R8808 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 19.0/110.3
R8811 7030015970 S.RES RMC1/16S-103JTH (10 k) T 23.5/109.0
R8812 7030015900 S.RES RMC1/16S-470JTH (47) T 28.6/110.5
R8813 7030016050 S.RES RMC1/16S-102JTH (1 k) T 20.8/109.0
R8814 7030015970 S.RES RMC1/16S-103JTH (10 k) T 23.4/115.2
R8821 7030015970 S.RES RMC1/16S-103JTH (10 k) T 16.2/114.4
R9006 7030015910 S.RES RMC1/16S-101JTH (100) T 19.3/9.8
R9007 7030015910 S.RES RMC1/16S-101JTH (100) T 18.3/9.8
R9008 7030015910 S.RES RMC1/16S-101JTH (100) T 17.3/9.8
R9009 7030015910 S.RES RMC1/16S-101JTH (100) T 16.3/9.8
R9010 7030015910 S.RES RMC1/16S-101JTH (100) T 15.3/9.8
R9106 7030015910 S.RES RMC1/16S-101JTH (100) T 124.5/9.8
R9107 7030015910 S.RES RMC1/16S-101JTH (100) T 123.5/9.8
R9108 7030015910 S.RES RMC1/16S-101JTH (100) T 122.5/9.8
R9109 7030015910 S.RES RMC1/16S-101JTH (100) T 121.5/9.8
R9110 7030015910 S.RES RMC1/16S-101JTH (100) T 120.5/9.8
R9116 7030015910 S.RES RMC1/16S-101JTH (100) T 119.0/16.1
R9203 7030016250 S.RES RMC1/16S-220JTH (22) T 177.9/9.8
R9204 7030016250 S.RES RMC1/16S-220JTH (22) T 177.4/16.1
R9205 7030016250 S.RES RMC1/16S-220JTH (22) T 176.9/9.8
R9206 7030016250 S.RES RMC1/16S-220JTH (22) T 176.4/16.1
R9207 7030016250 S.RES RMC1/16S-220JTH (22) T 175.9/9.8
R9210 7030015910 S.RES RMC1/16S-101JTH (100) T 174.4/16.1
R9211 7030015910 S.RES RMC1/16S-101JTH (100) T 173.9/9.8
R9212 7030015910 S.RES RMC1/16S-101JTH (100) T 173.4/16.1
R9213 7030015910 S.RES RMC1/16S-101JTH (100) T 172.9/9.8
R9214 7030015910 S.RES RMC1/16S-101JTH (100) T 171.9/9.8
R9215 7030015910 S.RES RMC1/16S-101JTH (100) T 170.9/9.8
R9301 7030016520 S.RES RMC1/16S-270JTH (27) T 177.3/35.0
R9302 7030016520 S.RES RMC1/16S-270JTH (27) T 175.5/35.0
R9303 7030016520 S.RES RMC1/16S-270JTH (27) T 173.7/35.0
R9304 7030016520 S.RES RMC1/16S-270JTH (27) T 171.9/35.0
R9305 7030016520 S.RES RMC1/16S-270JTH (27) T 170.1/35.0
R9306 7030016520 S.RES RMC1/16S-270JTH (27) T 168.3/35.0
R9307 7030016520 S.RES RMC1/16S-270JTH (27) T 166.5/35.0
R9308 7030016520 S.RES RMC1/16S-270JTH (27) T 164.7/35.0
R9309 7030015910 S.RES RMC1/16S-101JTH (100) T 142.1/9.2
R9310 7030016560 S.RES RMC1/16SJPTH T 141.1/9.2
R9311 7030015910 S.RES RMC1/16S-101JTH (100) T 139.7/9.2
R9312 7030016250 S.RES RMC1/16S-220JTH (22) T 138.8/9.2
R9325 7030016520 S.RES RMC1/16S-270JTH (27) T 178.2/35.0
R9326 7030016520 S.RES RMC1/16S-270JTH (27) T 176.4/35.0
R9327 7030016520 S.RES RMC1/16S-270JTH (27) T 174.6/35.0
R9328 7030016520 S.RES RMC1/16S-270JTH (27) T 172.8/35.0
R9329 7030016520 S.RES RMC1/16S-270JTH (27) T 171.0/35.0
R9330 7030016520 S.RES RMC1/16S-270JTH (27) T 169.2/35.0
R9331 7030016520 S.RES RMC1/16S-270JTH (27) T 167.4/35.0
R9332 7030016520 S.RES RMC1/16S-270JTH (27) T 165.6/35.0
R9333 7030016560 S.RES RMC1/16SJPTH T 163.8/35.0
R9334 7030016560 S.RES RMC1/16SJPTH T 162.9/35.0
R9335 7030016520 S.RES RMC1/16S-270JTH (27) T 162.0/35.0
R9336 7030016250 S.RES RMC1/16S-220JTH (22) T 138.4/15.6
R9337 7030015910 S.RES RMC1/16S-101JTH (100) T 137.5/15.6
R9401 7030015910 S.RES RMC1/16S-101JTH (100) T 183.6/21.9
R9402 7030015910 S.RES RMC1/16S-101JTH (100) T 184.1/28.2
R9403 7030016520 S.RES RMC1/16S-270JTH (27) T 184.6/21.9
R9404 7030016520 S.RES RMC1/16S-270JTH (27) T 185.1/28.2
R9405 7030016520 S.RES RMC1/16S-270JTH (27) T 186.1/28.2
R9406 7030016520 S.RES RMC1/16S-270JTH (27) T 187.6/21.9
R9407 7030016520 S.RES RMC1/16S-270JTH (27) T 188.1/28.2
R9408 7030016520 S.RES RMC1/16S-270JTH (27) T 188.6/21.9
R9409 7030016110 S.RES RMC1/16S-473JTH (47 k) T 183.6/19.7
R9410 7030016110 S.RES RMC1/16S-473JTH (47 k) T 184.1/30.4
R9411 7030016110 S.RES RMC1/16S-473JTH (47 k) T 184.6/19.7
R9412 7030016110 S.RES RMC1/16S-473JTH (47 k) T 185.1/30.4
R9413 7030016110 S.RES RMC1/16S-473JTH (47 k) T 187.6/19.7
R9414 7030016110 S.RES RMC1/16S-473JTH (47 k) T 188.1/30.4
R9415 7030016110 S.RES RMC1/16S-473JTH (47 k) T 188.6/19.7
R9501 7030016050 S.RES RMC1/16S-102JTH (1 k) T 196.8/121.0
R9502 7030016050 S.RES RMC1/16S-102JTH (1 k) T 199.2/121.0
R9601 7410001140 S.ARR EXB28V104JX T 196.9/24.5
R9602 7410001130 S.ARR EXB28V102JX T 196.9/27.5
R9603 7410001140 S.ARR EXB28V104JX T 199.7/24.5
R9604 7410001130 S.ARR EXB28V102JX T 199.7/27.5
R9605 7410001140 S.ARR EXB28V104JX T 161.7/22.4
R9606 7410001130 S.ARR EXB28V102JX T 164.7/22.4
C1 4030023010 S.CER 0402B104K160CT B 166.3/47.9
C2 4030023010 S.CER 0402B104K160CT B 166.3/47.0
C3 4030023010 S.CER 0402B104K160CT B 168.1/45.0
C101 4030023010 S.CER 0402B104K160CT T 172.1/43.5
C102 4030022680 S.CER 0402N150J500CT T 163.6/40.3
C103 4030022680 S.CER 0402N150J500CT T 166.7/41.9
C104 4030023010 S.CER 0402B104K160CT T 171.1/43.5
C105 4030023010 S.CER 0402B104K160CT B 168.0/49.3
C106 4030023010 S.CER 0402B104K160CT B 164.2/63.4
C107 4030023010 S.CER 0402B104K160CT B 163.3/63.4
C108 4030023010 S.CER 0402B104K160CT B 169.2/62.3
C109 4030023010 S.CER 0402B104K160CT B 168.7/63.2
C110 4030023010 S.CER 0402B104K160CT B 158.9/59.3
C111 4030023010 S.CER 0402B104K160CT B 159.8/59.3
C112 4030023010 S.CER 0402B104K160CT B 163.1/58.8
C113 4030023010 S.CER 0402B104K160CT B 166.5/61.5
C114 4030023010 S.CER 0402B104K160CT B 165.6/59.2
C115 4030023010 S.CER 0402B104K160CT B 166.5/59.2
C116 4030023010 S.CER 0402B104K160CT B 166.8/55.0
C117 4030023010 S.CER 0402B104K160CT B 169.9/55.8
C118 4030023010 S.CER 0402B104K160CT B 158.5/53.8
C119 4030023010 S.CER 0402B104K160CT B 158.5/52.9
C120 4030023010 S.CER 0402B104K160CT B 158.5/50.7
C121 4030023010 S.CER 0402B104K160CT B 158.5/49.7
C122 4030023010 S.CER 0402B104K160CT B 158.5/48.5
C123 4030023010 S.CER 0402B104K160CT B 165.2/46.1
C124 4030023010 S.CER 0402B104K160CT B 162.7/50.9
C125 4030023010 S.CER 0402B104K160CT B 163.7/51.3
C126 4030023010 S.CER 0402B104K160CT B 153.3/47.1
C127 4030023010 S.CER 0402B104K160CT B 154.7/46.3
C128 4030023010 S.CER 0402B104K160CT B 154.7/45.4
C129 4030023010 S.CER 0402B104K160CT B 162.9/46.2
C130 4030023010 S.CER 0402B104K160CT B 170.1/44.7
C131 4030023010 S.CER 0402B104K160CT B 170.5/46.5
C132 4030019560 S.CER GRM21BB31C106KE15L B 157.9/62.2
C133 4030019560 S.CER GRM21BB31C106KE15L T 173.7/43.7
C134 4030023010 S.CER 0402B104K160CT B 151.0/65.0
C135 4030023010 S.CER 0402B104K160CT B 153.6/65.9
C136 4030023010 S.CER 0402B104K160CT B 156.1/59.2
C137 4030023010 S.CER 0402B104K160CT B 157.6/58.6
C138 4030023010 S.CER 0402B104K160CT B 159.4/61.9
C139 4030023010 S.CER 0402B104K160CT B 164.6/61.2
C140 4030023010 S.CER 0402B104K160CT B 166.8/57.1
C141 4030023010 S.CER 0402B104K160CT B 166.8/56.2
C142 4030023010 S.CER 0402B104K160CT B 157.2/55.9
C143 4030023010 S.CER 0402B104K160CT B 158.5/51.8
C144 4030023010 S.CER 0402B104K160CT B 156.0/51.8
C145 4030023010 S.CER 0402B104K160CT B 167.8/52.1
C146 4030023010 S.CER 0402B104K160CT B 166.2/51.6
C147 4030023010 S.CER 0402B104K160CT B 166.2/50.6
C148 4030023010 S.CER 0402B104K160CT B 161.8/50.8
C149 4030023010 S.CER 0402B104K160CT B 163.4/48.2
C150 4030019560 S.CER GRM21BB31C106KE15L B 160.5/47.5
C151 4030019560 S.CER GRM21BB31C106KE15L B 152.3/62.7
C152 4030023010 S.CER 0402B104K160CT T 121.6/82.6
C153 4030023010 S.CER 0402B104K160CT T 124.6/79.0
C154 4030023010 S.CER 0402B104K160CT T 129.5/79.0
C155 4030023010 S.CER 0402B104K160CT T 133.4/79.0
C156 4030023010 S.CER 0402B104K160CT T 143.9/79.0
C157 4030023010 S.CER 0402B104K160CT T 131.9/93.9
C158 4030023010 S.CER 0402B104K160CT T 127.1/93.9
C159 4030023090 S.CER 0402B102K500CT T 161.7/43.9
C160 4030022560 S.CER 0402N5R0B500CT T 151.3/50.8
C171 4030022950 S.CER 0402B273K100CT T 179.8/30.2
C172 4030023010 S.CER 0402B104K160CT T 181.9/33.0
C181 4030023010 S.CER 0402B104K160CT T 159.9/75.2
C186 4030022560 S.CER 0402N5R0B500CT B 141.9/51.7
C191 4030023010 S.CER 0402B104K160CT T 167.4/70.5
C192 4030023010 S.CER 0402B104K160CT T 169.9/70.5
C201 4030023010 S.CER 0402B104K160CT T 181.9/60.1
C202 4030023030 S.CER 0402B103K250CT T 179.1/57.4
C251 4030019120 S.CER GRM188B31E105KA75D T 168.5/80.7
C301 4030023010 S.CER 0402B104K160CT T 88.5/103.6
C302 4030023010 S.CER 0402B104K160CT T 88.5/96.6
C303 4030023010 S.CER 0402B104K160CT T 96.8/92.4
C304 4030023010 S.CER 0402B104K160CT T 100.2/93.2
C305 4030023010 S.CER 0402B104K160CT T 108.0/101.5
C306 4030023010 S.CER 0402B104K160CT T 108.0/108.5
C307 4030023010 S.CER 0402B104K160CT T 97.8/112.7
C308 4030023010 S.CER 0402B104K160CT T 96.9/112.7
C309 4030023010 S.CER 0402B104K160CT T 95.7/112.2
C310 4030019560 S.CER GRM21BB31C106KE15L T 88.3/110.6
C311 4030019560 S.CER GRM21BB31C106KE15L T 188.1/43.3
C312 4030023010 S.CER 0402B104K160CT T 191.4/41.5
C313 4030023010 S.CER 0402B104K160CT T 196.2/40.6
C314 4030023010 S.CER 0402B104K160CT T 189.5/44.3
C315 4030023010 S.CER 0402B104K160CT T 200.6/49.8
C316 4030023010 S.CER 0402B104K160CT T 188.7/52.8
C331 4030023010 S.CER 0402B104K160CT T 109.6/111.4
C411 4030022640 S.CER 0402N101J500CT T 202.9/46.8
C412 4030022640 S.CER 0402N101J500CT T 202.9/47.7

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-8a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
C502 4030019120 S.CER GRM188B31E105KA75D T 129.8/120.2
C505 4030021580 S.CER GRM188B31E225KA12D T 130.8/115.5
C508 4030023010 S.CER 0402B104K160CT T 142.0/101.3
C510 4030019120 S.CER GRM188B31E105KA75D T 143.5/105.7
C512 4030023010 S.CER 0402B104K160CT T 142.0/100.4
C513 4030023010 S.CER 0402B104K160CT T 142.0/103.8
C514 4030019120 S.CER GRM188B31E105KA75D T 143.5/101.1
C515 4030023010 S.CER 0402B104K160CT T 144.6/101.1
C516 4030023010 S.CER 0402B104K160CT T 140.8/112.5
C517 4030023010 S.CER 0402B104K160CT T 132.7/112.5
C518 4030019120 S.CER GRM188B31E105KA75D T 136.7/96.9
C531 4030019560 S.CER GRM21BB31C106KE15L B 135.5/100.8
C532 4030019560 S.CER GRM21BB31C106KE15L B 142.5/101.3
C533 4030019560 S.CER GRM21BB31C106KE15L B 129.0/101.6
C534 4030019560 S.CER GRM21BB31C106KE15L T 125.0/113.7
C535 4030023010 S.CER 0402B104K160CT T 127.0/103.5
C536 4030023010 S.CER 0402B104K160CT T 127.3/112.5
C537 4030023010 S.CER 0402B104K160CT T 128.2/112.5
C538 4030023010 S.CER 0402B104K160CT T 142.0/109.7
C539 4030023010 S.CER 0402B104K160CT T 142.0/108.8
C540 4030023010 S.CER 0402B104K160CT T 142.0/102.2
C541 4030023010 S.CER 0402B104K160CT T 142.0/107.0
C542 4030023010 S.CER 0402B104K160CT T 137.2/112.5
C543 4030023010 S.CER 0402B104K160CT T 134.5/112.5
C544 4030023820 S.CER 0603B104K250CT B 136.4/105.2
C545 4030023010 S.CER 0402B104K160CT T 130.0/112.5
C546 4030023010 S.CER 0402B104K160CT T 134.5/97.5
C547 4030023010 S.CER 0402B104K160CT T 135.5/97.5
C548 4030019560 S.CER GRM21BB31C106KE15L B 136.3/113.5
C549 4030019560 S.CER GRM21BB31C106KE15L B 138.8/105.4
C550 4030019560 S.CER GRM21BB31C106KE15L B 144.0/103.3
C551 4030019560 S.CER GRM21BB31C106KE15L B 128.8/109.8
C552 4030023010 S.CER 0402B104K160CT T 127.0/107.5
C553 4030023010 S.CER 0402B104K160CT T 133.2/97.5
C554 4030023010 S.CER 0402B104K160CT T 132.1/97.5
C555 4030023010 S.CER 0402B104K160CT T 127.0/104.5
C556 4030023010 S.CER 0402B104K160CT T 127.0/105.5
C557 4030023010 S.CER 0402B104K160CT T 127.0/109.5
C558 4030023010 S.CER 0402B104K160CT T 127.0/106.5
C559 4030023010 S.CER 0402B104K160CT T 127.0/110.5
C560 4030023010 S.CER 0402B104K160CT T 127.0/108.5
C561 4030023010 S.CER 0402B104K160CT T 131.1/97.5
C1001 4030020190 S.CER GRM32EB31C476KE15L T 69.9/134.0
C1002 4030023010 S.CER 0402B104K160CT T 74.2/132.1
C1003 4030023010 S.CER 0402B104K160CT T 71.4/136.5
C1004 4030020190 S.CER GRM32EB31C476KE15L T 73.8/143.1
C1005 4030020190 S.CER GRM32EB31C476KE15L T 69.7/144.0
C1007 4030023010 S.CER 0402B104K160CT T 77.9/136.3
C1008 4030021580 S.CER GRM188B31E225KA12D T 74.9/141.0
C1012 4030019560 S.CER GRM21BB31C106KE15L T 98.5/139.0
C1013 4030019560 S.CER GRM21BB31C106KE15L T 104.2/136.1
C1021 4030023030 S.CER 0402B103K250CT T 142.8/125.0
C1022 4030019120 S.CER GRM188B31E105KA75D T 140.6/122.4
C1023 4030019560 S.CER GRM21BB31C106KE15L T 140.5/127.5
C1031 4030023030 S.CER 0402B103K250CT T 95.8/129.7
C1032 4030019120 S.CER GRM188B31E105KA75D T 98.3/133.1
C1033 4030019560 S.CER GRM21BB31C106KE15L T 98.1/127.8
C1041 4030022050 S.CER GRM21BR61C226ME44L T 85.5/132.3
C1042 4030023010 S.CER 0402B104K160CT T 85.5/133.7
C1043 4030023010 S.CER 0402B104K160CT T 83.0/139.3
C1044 4030023030 S.CER 0402B103K250CT T 86.7/139.3
C1045 4030023210 S.CER 0402B472K500CT T 89.7/133.9
C1046 4030022050 S.CER GRM21BR61C226ME44L T 89.5/140.7
C1047 4030022050 S.CER GRM21BR61C226ME44L T 89.5/142.5
C1049 4030023010 S.CER 0402B104K160CT T 89.0/138.4
C1050 4510010570 S.ELE 16 CE 470 LX T 111.6/120.1
C1071 4030019120 S.CER GRM188B31E105KA75D T 99.1/122.1
C1072 4030019560 S.CER GRM21BB31C106KE15L T 98.9/117.1
C1091 4510010460 ELE DXN-5R5H334U
C1092 4030019120 S.CER GRM188B31E105KA75D T 36.5/121.6
C1093 4030019560 S.CER GRM21BB31C106KE15L T 35.6/116.5
C1101 4030020190 S.CER GRM32EB31C476KE15L T 59.7/143.3
C1102 4030023010 S.CER 0402B104K160CT T 60.2/141.3
C1103 4030023010 S.CER 0402B104K160CT T 58.2/136.9
C1104 4030023010 S.CER 0402B104K160CT T 62.6/139.2
C1106 4030020190 S.CER GRM32EB31C476KE15L T 52.6/142.2
C1107 4030020190 S.CER GRM32EB31C476KE15L T 55.6/142.2
C1108 4030022810 S.CER 0402N330J500CT T 63.0/135.9
C1109 4030023010 S.CER 0402B104K160CT T 59.5/133.2
C1111 4030020190 S.CER GRM32EB31C476KE15L T 66.3/130.7
C1112 4030023010 S.CER 0402B104K160CT T 69.7/129.9
C1113 4030023010 S.CER 0402B104K160CT T 71.8/124.3
C1114 4030023030 S.CER 0402B103K250CT T 69.2/124.3
C1115 4030023030 S.CER 0402B103K250CT T 65.6/126.9
C1116 4030022050 S.CER GRM21BR61C226ME44L T 66.2/119.2
C1117 4030022050 S.CER GRM21BR61C226ME44L T 66.2/121.0
C1119 4030019120 S.CER GRM188B31E105KA75D T 68.2/115.1
C1120 4030023010 S.CER 0402B104K160CT T 67.7/123.2
C1121 4030019120 S.CER GRM188B31E105KA75D T 42.8/125.1
C1122 4030019120 S.CER GRM188B31E105KA75D T 42.8/120.1
C1131 4030019120 S.CER GRM188B31E105KA75D T 8.4/94.7
C1132 4030019120 S.CER GRM188B31E105KA75D T 13.0/94.7
C1141 4030019120 S.CER GRM188B31E105KA75D T 53.3/63.1
C1142 4030019560 S.CER GRM21BB31C106KE15L T 58.1/63.3
C1201 4030020190 S.CER GRM32EB31C476KE15L T 87.0/128.1
C1202 4030023010 S.CER 0402B104K160CT T 87.1/125.9
C1203 4030023010 S.CER 0402B104K160CT T 85.0/121.6
C1204 4030023010 S.CER 0402B104K160CT T 89.4/123.8
C1206 4030020190 S.CER GRM32EB31C476KE15L T 82.8/127.1
C1207 4030020190 S.CER GRM32EB31C476KE15L T 79.8/127.1
C1208 4030022810 S.CER 0402N330J500CT T 88.1/120.1
C1209 4030020190 S.CER GRM32EB31C476KE15L T 78.8/130.9
C1211 4030020190 S.CER GRM32EB31C476KE15L T 57.1/120.8
C1212 4030023010 S.CER 0402B104K160CT T 57.7/118.8
C1214 4030019120 S.CER GRM188B31E105KA75D T 61.9/125.5
C1216 4030022050 S.CER GRM21BR61C226ME44L T 50.5/121.9
C1217 4030022050 S.CER GRM21BR61C226ME44L T 52.3/121.9
C1218 4030022810 S.CER 0402N330J500CT T 59.7/128.5
C1221 4030019560 S.CER GRM21BB31C106KE15L T 11.9/118.5
C1223 4550007520 S.TAN F931A106MAABMA T 9.4/127.5
C1231 4030021580 S.CER GRM188B31E225KA12D T 155.5/115.0
C1232 4030021580 S.CER GRM188B31E225KA12D T 160.5/114.5
C1241 4030019120 S.CER GRM188B31E105KA75D T 6.8/89.3
C1242 4030019560 S.CER GRM21BB31C106KE15L T 13.4/89.5
C1246 4030019120 S.CER GRM188B31E105KA75D T 8.0/99.2
C1247 4030019560 S.CER GRM21BB31C106KE15L T 14.9/99.2
C1251 4030019120 S.CER GRM188B31E105KA75D T 12.3/104.6
C1252 4030019560 S.CER GRM21BB31C106KE15L T 15.3/106.8
C1261 4030023010 S.CER 0402B104K160CT T 9.2/21.1
C1262 4030023090 S.CER 0402B102K500CT T 8.7/18.1
C1331 4030023030 S.CER 0402B103K250CT T 72.8/62.6
C1332 4030019120 S.CER GRM188B31E105KA75D T 72.3/64.8
C1333 4030019560 S.CER GRM21BB31C106KE15L T 75.6/61.3
C1501 4030023010 S.CER 0402B104K160CT T 178.9/149.6
C1502 4030022630 S.CER 0402N100C500CT T 188.4/146.0
C1521 4030023010 S.CER 0402B104K160CT T 178.2/143.1
C1531 4030019560 S.CER GRM21BB31C106KE15L T 172.5/125.9
C1532 4030019560 S.CER GRM21BB31C106KE15L T 162.6/124.0
C1533 4030019560 S.CER GRM21BB31C106KE15L T 164.4/124.0
C1534 4030019560 S.CER GRM21BB31C106KE15L T 160.4/128.2
C1535 4030019560 S.CER GRM21BB31C106KE15L B 170.8/132.0
C1536 4030023010 S.CER 0402B104K160CT T 161.8/129.1
C1537 4030019560 S.CER GRM21BB31C106KE15L B 170.8/128.7
C1538 4030019560 S.CER GRM21BB31C106KE15L T 166.1/124.0
C1539 4030023010 S.CER 0402B104K160CT T 171.9/128.7
C1540 4030022770 S.CER 0402N270J500CT T 176.8/129.1
C1541 4030022770 S.CER 0402N270J500CT T 174.6/131.7
C1542 4030019560 S.CER GRM21BB31C106KE15L T 174.2/133.5
C1543 4030023010 S.CER 0402B104K160CT T 171.9/134.1
C1544 4030019560 S.CER GRM21BB31C106KE15L T 173.0/135.8
C1545 4030023010 S.CER 0402B104K160CT T 158.8/132.2
C1546 4030019120 S.CER GRM188B31E105KA75D T 158.1/129.2
C1551 4030023010 S.CER 0402B104K160CT T 149.2/145.5
C1552 4030019120 S.CER GRM188B31E105KA75D T 150.3/145.8
C1553 4030019120 S.CER GRM188B31E105KA75D T 147.2/149.4
C1571 4030023010 S.CER 0402B104K160CT T 147.0/133.3
C1572 4030019120 S.CER GRM188B31E105KA75D T 146.7/134.3
C1573 4030019120 S.CER GRM188B31E105KA75D T 142.1/133.7
C1601 4030022740 S.CER 0402N220J500CT T 154.0/140.1
C1602 4030022740 S.CER 0402N220J500CT T 154.0/141.9
C1603 4030022740 S.CER 0402N220J500CT T 160.0/137.7
C1604 4030022740 S.CER 0402N220J500CT T 158.4/137.7
C1605 4030022740 S.CER 0402N220J500CT T 163.3/137.7
C1606 4030022740 S.CER 0402N220J500CT T 161.6/137.7
C1611 4030023010 S.CER 0402B104K160CT T 165.8/141.1
C1612 4030022770 S.CER 0402N270J500CT T 172.3/141.4
C1613 4030022770 S.CER 0402N270J500CT T 168.7/147.9
C1614 4030023010 S.CER 0402B104K160CT T 159.6/150.4
C1615 4030023010 S.CER 0402B104K160CT T 159.1/149.5
C1618 4030019560 S.CER GRM21BB31C106KE15L T 158.0/151.8
C1623 4030023090 S.CER 0402B102K500CT T 155.2/152.8
C1901 4030023820 S.CER 0603B104K250CT B 147.3/42.1
C1903 4030022770 S.CER 0402N270J500CT T 144.3/33.3
C1904 4030022770 S.CER 0402N270J500CT T 146.9/35.5
C1905 4030019120 S.CER GRM188B31E105KA75D T 148.3/36.8
C1906 4030023010 S.CER 0402B104K160CT T 146.8/37.9
C1907 4030019560 S.CER GRM21BB31C106KE15L T 139.2/36.8
C1908 4030023010 S.CER 0402B104K160CT T 141.2/36.9
C1909 4030023010 S.CER 0402B104K160CT T 140.5/44.5
C1914 4030023010 S.CER 0402B104K160CT T 8.7/139.8
C1915 4030022170 S.CER GR442QR73D102KW01L T 9.2/150.9
C2001 4030019120 S.CER GRM188B31E105KA75D T 183.4/67.0
C2002 4030019560 S.CER GRM21BB31C106KE15L T 183.4/63.7
C2003 4030019560 S.CER GRM21BB31C106KE15L T 184.0/78.9
C2004 4030019120 S.CER GRM188B31E105KA75D T 180.7/77.3
C2005 4030019120 S.CER GRM188B31E105KA75D T 183.7/77.3
C2006 4030019560 S.CER GRM21BB31C106KE15L T 177.6/77.3
C2011 4030019560 S.CER GRM21BB31C106KE15L T 172.0/77.9
C2012 4030023010 S.CER 0402B104K160CT T 173.7/75.9
C2021 4030019570 S.CER C1608 CH 1H 332J-T T 194.4/76.2
C2022 4030023010 S.CER 0402B104K160CT T 190.3/76.1
C2023 4030022930 S.CER 0402N821J500CT T 191.9/76.1
C2029 4030019560 S.CER GRM21BB31C106KE15L T 188.4/71.8
C2031 4030019570 S.CER C1608 CH 1H 332J-T T 191.0/65.6
C2032 4030023010 S.CER 0402B104K160CT T 189.7/67.6
C2033 4030022930 S.CER 0402N821J500CT T 191.3/67.6
C2041 4030018600 S.CER C1608 CH 1H 152J-T T 145.9/121.1
C2042 4030023010 S.CER 0402B104K160CT T 147.8/120.8
C2043 4030022710 S.CER 0402N181J500CT T 147.3/118.5
C2044 4030019560 S.CER GRM21BB31C106KE15L T 148.8/124.2
C2049 4030019560 S.CER GRM21BB31C106KE15L T 151.8/115.2
C2051 4030019570 S.CER C1608 CH 1H 332J-T T 157.6/121.0
C2052 4030023010 S.CER 0402B104K160CT T 155.8/120.8
C2053 4030022670 S.CER 0402N121J500CT T 156.5/118.5
C2054 4030019560 S.CER GRM21BB31C106KE15L T 154.5/122.7
C2061 4030019570 S.CER C1608 CH 1H 332J-T T 160.3/121.0
C2062 4030023010 S.CER 0402B104K160CT T 162.2/120.7
C2063 4030022670 S.CER 0402N121J500CT T 161.8/118.5
C2069 4030019560 S.CER GRM21BB31C106KE15L T 168.6/115.2
C2071 4030019570 S.CER C1608 CH 1H 332J-T T 172.3/121.0
C2072 4030023010 S.CER 0402B104K160CT T 170.4/120.7
C2073 4030022670 S.CER 0402N121J500CT T 171.0/118.5
C2081 4030022690 S.CER 0402N151J500CT T 194.3/55.9
C2082 4030023010 S.CER 0402B104K160CT T 199.7/56.4

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-9a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
C2088 4030023010 S.CER 0402B104K160CT T 191.2/61.1
C2089 4030023010 S.CER 0402B104K160CT T 192.4/60.6
C2091 4030022690 S.CER 0402N151J500CT T 189.4/56.8
C2092 4030023010 S.CER 0402B104K160CT T 188.8/60.5
C2103 4030023010 S.CER 0402B104K160CT T 162.0/89.1
C2104 4030019560 S.CER GRM21BB31C106KE15L T 161.5/87.7
C2105 4030023010 S.CER 0402B104K160CT T 166.2/100.2
C2106 4030023010 S.CER 0402B104K160CT T 162.8/99.5
C2107 4030019560 S.CER GRM21BB31C106KE15L T 164.8/100.5
C2108 4030019560 S.CER GRM21BB31C106KE15L T 162.3/100.9
C2109 4030019560 S.CER GRM21BB31C106KE15L T 165.5/103.7
C2111 4030021580 S.CER GRM188B31E225KA12D T 160.0/102.9
C2112 4030022750 S.CER 0402N221J500CT T 160.0/107.0
C2113 4030019560 S.CER GRM21BB31C106KE15L T 162.2/109.3
C2121 4030021580 S.CER GRM188B31E225KA12D T 168.2/100.2
C2122 4030022670 S.CER 0402N121J500CT T 168.4/103.1
C2123 4030021580 S.CER GRM188B31E225KA12D T 173.5/101.9
C2125 4510010570 S.ELE 16 CE 470 LX T 175.5/93.2
C2126 4030019560 S.CER GRM21BB31C106KE15L T 172.3/100.4
C2127 4030023010 S.CER 0402B104K160CT T 173.5/99.0
C2128 4030019560 S.CER GRM21BB31C106KE15L T 170.2/112.2
C2131 4030023010 S.CER 0402B104K160CT T 163.7/111.0
C2136 4030019560 S.CER GRM21BB31C106KE15L T 161.3/111.6
C2201 4510010570 S.ELE 16 CE 470 LX T 201.7/62.7
C2202 4030021580 S.CER GRM188B31E225KA12D T 186.3/83.2
C2203 4030022740 S.CER 0402N220J500CT T 185.3/94.3
C2204 4030019560 S.CER GRM21BB31C106KE15L B 187.2/88.2
C2205 4030019570 S.CER C1608 CH 1H 332J-T T 186.4/86.2
C2206 4030021580 S.CER GRM188B31E225KA12D B 189.6/86.3
C2207 4030023010 S.CER 0402B104K160CT T 188.9/87.0
C2208 4030021580 S.CER GRM188B31E225KA12D T 190.2/91.0
C2209 4030019120 S.CER GRM188B31E105KA75D T 187.2/92.8
C2210 4030012610 S.CER C2012 JB 1C 474K-T T 197.1/106.0
C2211 4030019330 S.CER C1608 X7R 1C 224K-T T 197.3/107.6
C2212 4030019330 S.CER C1608 X7R 1C 224K-T T 196.8/116.4
C2213 4030023010 S.CER 0402B104K160CT T 197.1/122.8
C2214 4510010570 S.ELE 16 CE 470 LX T 190.1/120.8
C2215 4510010570 S.ELE 16 CE 470 LX T 194.2/86.6
C2222 4030021580 S.CER GRM188B31E225KA12D T 200.4/83.2
C2223 4030022740 S.CER 0402N220J500CT T 199.4/94.3
C2224 4030019560 S.CER GRM21BB31C106KE15L B 201.3/88.2
C2225 4030019570 S.CER C1608 CH 1H 332J-T T 200.5/86.2
C2226 4030021580 S.CER GRM188B31E225KA12D B 203.8/86.3
C2228 4030021580 S.CER GRM188B31E225KA12D T 204.3/91.0
C2229 4030019120 S.CER GRM188B31E105KA75D T 201.3/92.8
C2230 4030012610 S.CER C2012 JB 1C 474K-T T 211.2/106.0
C2231 4030019330 S.CER C1608 X7R 1C 224K-T T 211.4/107.6
C2232 4030019330 S.CER C1608 X7R 1C 224K-T T 210.9/116.4
C2233 4030023010 S.CER 0402B104K160CT T 198.9/122.8
C2234 4510010570 S.ELE 16 CE 470 LX T 205.8/120.8
C2235 4510010570 S.ELE 16 CE 470 LX T 208.2/86.5
C2240 4030023090 S.CER 0402B102K500CT T 181.9/125.4
C2241 4030023090 S.CER 0402B102K500CT T 191.4/129.2
C2242 4030023090 S.CER 0402B102K500CT T 207.0/140.2
C2243 4030023090 S.CER 0402B102K500CT T 207.1/146.6
C2251 4030023090 S.CER 0402B102K500CT T 206.0/126.9
C2252 4030023090 S.CER 0402B102K500CT T 191.5/140.2
C2253 4030023090 S.CER 0402B102K500CT T 191.4/146.5
C2503 4030022630 S.CER 0402N100C500CT T 129.7/22.2
C2504 4030024500 S.CER C1005 JB 1C 224K-T T 131.0/22.0
C2505 4030023010 S.CER 0402B104K160CT T 128.0/22.2
C2509 4030019120 S.CER GRM188B31E105KA75D T 122.9/20.3
C2510 4030023010 S.CER 0402B104K160CT T 123.2/21.9
C2512 4030023030 S.CER 0402B103K250CT T 129.7/24.0
C2513 4030024500 S.CER C1005 JB 1C 224K-T T 129.7/25.8
C2515 4030017480 S.CER C1608 JB 1A 474K-T T 127.3/31.8
C2518 4030022950 S.CER 0402B273K100CT T 125.6/29.3
C2523 4030022590 S.CER 0402N8R0C500CT T 116.1/22.2
C2524 4030024500 S.CER C1005 JB 1C 224K-T T 114.3/22.2
C2525 4030023010 S.CER 0402B104K160CT T 117.9/22.2
C2532 4030023030 S.CER 0402B103K250CT T 116.1/24.0
C2533 4030024500 S.CER C1005 JB 1C 224K-T T 116.1/25.8
C2535 4030017480 S.CER C1608 JB 1A 474K-T T 118.7/31.8
C2543 4030022570 S.CER 0402N6R0C500CT T 106.8/22.6
C2544 4030024500 S.CER C1005 JB 1C 224K-T T 108.4/22.6
C2545 4030023010 S.CER 0402B104K160CT T 105.0/22.6
C2549 4030019120 S.CER GRM188B31E105KA75D T 99.9/20.9
C2550 4030023010 S.CER 0402B104K160CT T 100.2/22.4
C2552 4030023030 S.CER 0402B103K250CT T 106.8/24.4
C2553 4030024500 S.CER C1005 JB 1C 224K-T T 106.8/26.2
C2555 4030017480 S.CER C1608 JB 1A 474K-T T 102.4/31.1
C2558 4030023020 S.CER 0402B473K160CT T 101.4/30.5
C2566 4030017480 S.CER C1608 JB 1A 474K-T T 82.1/24.7
C2601 4030023010 S.CER 0402B104K160CT T 87.7/28.7
C2602 4030023010 S.CER 0402B104K160CT T 87.2/30.8
C2609 4030019120 S.CER GRM188B31E105KA75D T 81.1/26.6
C2610 4030023010 S.CER 0402B104K160CT T 82.8/26.8
C2611 4030023090 S.CER 0402B102K500CT T 77.6/32.1
C2629 4030019120 S.CER GRM188B31E105KA75D T 107.8/16.4
C2630 4030023010 S.CER 0402B104K160CT T 107.7/15.4
C2651 4030023010 S.CER 0402B104K160CT T 146.2/32.2
C2652 4030019120 S.CER GRM188B31E105KA75D T 145.7/27.7
C2653 4030023010 S.CER 0402B104K160CT T 142.3/29.8
C2654 4030023010 S.CER 0402B104K160CT T 148.8/29.2
C2801 4030023010 S.CER 0402B104K160CT T 108.7/49.8
C2811 4030023010 S.CER 0402B104K160CT T 115.3/48.6
C2821 4030023010 S.CER 0402B104K160CT T 121.9/48.6
C2851 4030023010 S.CER 0402B104K160CT T 135.8/43.1
C2852 4030023010 S.CER 0402B104K160CT T 135.5/48.6
C2853 4030021580 S.CER GRM188B31E225KA12D T 138.4/49.3
C2854 4030021580 S.CER GRM188B31E225KA12D T 135.7/45.5
C2870 4030023010 S.CER 0402B104K160CT T 134.8/28.9
C2871 4030023030 S.CER 0402B103K250CT T 137.8/24.3
C2872 4030023010 S.CER 0402B104K160CT T 134.8/26.8
C2881 4030023030 S.CER 0402B103K250CT T 133.9/124.0
C2882 4030023010 S.CER 0402B104K160CT T 133.9/127.0
C2883 4510010570 S.ELE 16 CE 470 LX T 122.4/120.6
C2884 4030023010 S.CER 0402B104K160CT T 133.9/126.0
C2891 4030023030 S.CER 0402B103K250CT T 174.9/149.6
C2892 4030023030 S.CER 0402B103K250CT T 177.2/149.6
C2901 4030022740 S.CER 0402N220J500CT T 140.9/157.8
C2902 4030022740 S.CER 0402N220J500CT T 153.2/160.8
C2903 4030023010 S.CER 0402B104K160CT T 151.5/153.3
C2904 4030023010 S.CER 0402B104K160CT T 152.4/153.3
C2905 4030023010 S.CER 0402B104K160CT T 151.5/155.1
C2906 4030023010 S.CER 0402B104K160CT T 152.4/155.1
C2907 4030023010 S.CER 0402B104K160CT T 142.0/152.8
C2911 4030023030 S.CER 0402B103K250CT T 124.1/145.5
C2913 4030023030 S.CER 0402B103K250CT T 139.3/147.6
C2914 4030023030 S.CER 0402B103K250CT T 124.0/146.8
C2915 4030023090 S.CER 0402B102K500CT T 132.4/147.0
C2916 4030023030 S.CER 0402B103K250CT T 121.5/146.8
C2917 4030023030 S.CER 0402B103K250CT T 135.1/147.0
C2918 4030023030 S.CER 0402B103K250CT T 129.9/148.4
C2931 4030023030 S.CER 0402B103K250CT T 138.1/139.8
C2941 4030021580 S.CER GRM188B31E225KA12D T 134.0/146.3
C2942 4030021580 S.CER GRM188B31E225KA12D T 125.5/147.2
C2961 4030023010 S.CER 0402B104K160CT T 126.8/37.7
C2962 4030023010 S.CER 0402B104K160CT T 117.4/37.7
C2963 4030023010 S.CER 0402B104K160CT T 120.8/34.1
C3011 4030023030 S.CER 0402B103K250CT T 58.4/39.8
C3012 4030023030 S.CER 0402B103K250CT T 61.9/40.8
C3013 4030023030 S.CER 0402B103K250CT T 61.9/37.9
C3014 4030023030 S.CER 0402B103K250CT T 65.2/41.8
C3015 4030022520 S.CER 0402N1R0B500CT T 68.4/38.9
C3016 4030023030 S.CER 0402B103K250CT T 68.9/40.4
C3017 4030023030 S.CER 0402B103K250CT T 71.0/40.8
C3021 4030023030 S.CER 0402B103K250CT T 58.4/33.7
C3022 4030023030 S.CER 0402B103K250CT T 61.9/34.7
C3023 4030023030 S.CER 0402B103K250CT T 61.9/31.8
C3024 4030023030 S.CER 0402B103K250CT T 65.2/36.3
C3025 4030022520 S.CER 0402N1R0B500CT T 68.4/32.8
C3026 4030023030 S.CER 0402B103K250CT T 68.9/34.3
C3027 4030023030 S.CER 0402B103K250CT T 71.7/33.8
C3031 4030023010 S.CER 0402B104K160CT T 68.0/19.8
C3032 4030023030 S.CER 0402B103K250CT T 70.0/24.5
C3033 4030023030 S.CER 0402B103K250CT T 65.2/30.1
C3041 4030023030 S.CER 0402B103K250CT T 58.4/26.2
C3042 4030023030 S.CER 0402B103K250CT T 61.9/28.1
C3043 4030023030 S.CER 0402B103K250CT T 61.9/25.2
C3044 4030023030 S.CER 0402B103K250CT T 65.6/22.9
C3045 4030022520 S.CER 0402N1R0B500CT T 68.4/27.4
C3046 4030023030 S.CER 0402B103K250CT T 68.9/25.9
C3047 4030023030 S.CER 0402B103K250CT T 71.7/26.4
C3051 4030023030 S.CER 0402B103K250CT T 65.2/24.2
C3052 4030017630 S.CER C1005 CH 1H 120J-T T 71.0/21.1
C3053 4030022790 S.CER 0402N2R5B500CT T 71.5/19.9
C3054 4030017390 S.CER C1005 CH 1H 180J-T T 72.9/20.4
C3055 4030022720 S.CER 0402N1R5B500CT T 73.9/20.4
C3056 4030017390 S.CER C1005 CH 1H 180J-T T 76.3/21.9
C3057 4030022520 S.CER 0402N1R0B500CT T 78.2/20.4
C3058 4030017630 S.CER C1005 CH 1H 120J-T T 79.9/22.0
C3061 4030023090 S.CER 0402B102K500CT T 87.1/18.9
C3062 4030023090 S.CER 0402B102K500CT T 87.2/16.6
C3063 4030023090 S.CER 0402B102K500CT T 83.0/18.9
C3064 4030023090 S.CER 0402B102K500CT T 81.6/21.5
C3071 4030022770 S.CER 0402N270J500CT T 76.2/17.8
C3072 4030022670 S.CER 0402N121J500CT T 74.1/17.3
C3073 4030022770 S.CER 0402N270J500CT T 75.0/17.3
C3074 4030022740 S.CER 0402N220J500CT T 72.8/14.2
C3075 4030022630 S.CER 0402N100C500CT T 74.0/14.0
C3076 4030022680 S.CER 0402N150J500CT T 72.8/13.3
C3081 4030022590 S.CER 0402N8R0C500CT T 85.0/15.8
C3082 4030022840 S.CER 0402N390J500CT T 82.8/15.3
C3083 4030022590 S.CER 0402N8R0C500CT T 84.0/14.9
C3084 4030022570 S.CER 0402N6R0C500CT T 82.8/13.7
C3085 4030022530 S.CER 0402N2R0B500CT T 84.0/13.3
C3086 4030022570 S.CER 0402N6R0C500CT T 82.8/12.8
C3091 4030022660 S.CER 0402N120J500CT T 95.0/17.3
C3092 4030022900 S.CER 0402N680J500CT T 94.1/15.7
C3093 4030022590 S.CER 0402N8R0C500CT T 95.0/15.7
C3094 4030022590 S.CER 0402N8R0C500CT T 92.8/14.2
C3095 4030022530 S.CER 0402N2R0B500CT T 94.0/13.7
C3096 4030022590 S.CER 0402N8R0C500CT T 92.8/13.3
C3101 4030023030 S.CER 0402B103K250CT T 37.5/13.1
C3102 4030023030 S.CER 0402B103K250CT T 40.3/13.2
C3103 4030022640 S.CER 0402N101J500CT T 37.3/14.8
C3104 4030022640 S.CER 0402N101J500CT T 39.8/14.8
C3105 4030023030 S.CER 0402B103K250CT T 17.8/18.0
C3111 4030023030 S.CER 0402B103K250CT T 47.5/13.1
C3112 4030023030 S.CER 0402B103K250CT T 50.3/13.2
C3113 4030022640 S.CER 0402N101J500CT T 47.3/14.8
C3114 4030022640 S.CER 0402N101J500CT T 49.8/14.8
C3115 4030023030 S.CER 0402B103K250CT T 48.5/22.8
C3121 4030023030 S.CER 0402B103K250CT T 57.1/13.5
C3122 4030022640 S.CER 0402N101J500CT T 55.4/14.8
C3123 4030022640 S.CER 0402N101J500CT T 55.4/12.3
C3131 4030023030 S.CER 0402B103K250CT T 51.9/12.1
C3132 4030023030 S.CER 0402B103K250CT T 50.8/8.4
C3133 4030023030 S.CER 0402B103K250CT T 54.5/11.0
C3134 4030023030 S.CER 0402B103K250CT T 54.5/9.2
C3141 4030023030 S.CER 0402B103K250CT T 12.1/26.2
C3142 4030023030 S.CER 0402B103K250CT T 13.9/21.6
C3143 4030023030 S.CER 0402B103K250CT T 14.2/26.0

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-10a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
C3145 4030022520 S.CER 0402N1R0B500CT T 18.9/22.7
C3146 4030023030 S.CER 0402B103K250CT T 19.3/24.2
C3147 4030023030 S.CER 0402B103K250CT T 19.6/25.6
C3151 4030023030 S.CER 0402B103K250CT T 16.7/27.3
C3152 4030022850 S.CER 0402N391J500CT T 17.9/29.4
C3153 4030023030 S.CER 0402B103K250CT T 18.0/32.1
C3154 4030023030 S.CER 0402B103K250CT T 14.4/33.3
C3155 4030023010 S.CER 0402B104K160CT T 51.0/24.7
C3156 4030022540 S.CER 0402N3R0B500CT T 12.3/32.9
C3161 4030023030 S.CER 0402B103K250CT T 17.4/41.5
C3162 4030023010 S.CER 0402B104K160CT T 22.0/45.1
C3163 4030023030 S.CER 0402B103K250CT T 21.1/41.0
C3164 4030023010 S.CER 0402B104K160CT T 22.0/43.3
C3171 4030019120 S.CER GRM188B31E105KA75D T 24.8/28.1
C3172 4030019120 S.CER GRM188B31E105KA75D T 23.6/32.7
C3181 4030022640 S.CER 0402N101J500CT T 17.5/46.6
C3182 4030022640 S.CER 0402N101J500CT T 15.0/46.6
C3183 4030022640 S.CER 0402N101J500CT T 15.0/59.8
C3184 4030022640 S.CER 0402N101J500CT T 17.5/59.8
C3185 4030022640 S.CER 0402N101J500CT T 12.2/46.1
C3186 4030022640 S.CER 0402N101J500CT T 14.1/43.0
C3187 4030023030 S.CER 0402B103K250CT T 16.3/61.4
C3191 4030022540 S.CER 0402N3R0B500CT T 17.6/51.5
C3192 4030022540 S.CER 0402N3R0B500CT T 18.5/51.5
C3193 4030022580 S.CER 0402N7R0C500CT T 19.0/52.7
C3195 4030022540 S.CER 0402N3R0B500CT T 17.6/54.8
C3196 4030022540 S.CER 0402N3R0B500CT T 18.5/54.8
C3201 4030022560 S.CER 0402N5R0B500CT T 14.9/51.5
C3202 4030022560 S.CER 0402N5R0B500CT T 15.8/51.5
C3203 4030022600 S.CER 0402N9R0C500CT T 14.5/52.7
C3204 4030022660 S.CER 0402N120J500CT T 14.5/53.6
C3205 4030022560 S.CER 0402N5R0B500CT T 14.9/54.8
C3206 4030022560 S.CER 0402N5R0B500CT T 15.8/54.8
C3341 4030023030 S.CER 0402B103K250CT T 40.0/21.6
C3342 4030023030 S.CER 0402B103K250CT T 44.6/22.4
C3343 4030023030 S.CER 0402B103K250CT T 40.2/23.7
C3345 4030022520 S.CER 0402N1R0B500CT T 43.4/28.4
C3346 4030023030 S.CER 0402B103K250CT T 41.9/28.8
C3347 4030023030 S.CER 0402B103K250CT T 40.6/29.1
C3351 4030023030 S.CER 0402B103K250CT T 38.8/26.2
C3352 4030022850 S.CER 0402N391J500CT T 36.8/27.4
C3353 4030023030 S.CER 0402B103K250CT T 34.1/27.5
C3354 4030023030 S.CER 0402B103K250CT T 32.8/23.9
C3355 4030023010 S.CER 0402B104K160CT T 48.7/28.0
C3356 4030022540 S.CER 0402N3R0B500CT T 33.3/21.8
C3361 4030023030 S.CER 0402B103K250CT T 32.8/36.5
C3362 4030023010 S.CER 0402B104K160CT T 37.5/40.2
C3363 4030023030 S.CER 0402B103K250CT T 36.6/36.1
C3364 4030023010 S.CER 0402B104K160CT T 37.5/38.4
C3371 4030019120 S.CER GRM188B31E105KA75D T 43.3/39.1
C3372 4030019120 S.CER GRM188B31E105KA75D T 43.3/43.7
C3381 4030022640 S.CER 0402N101J500CT T 36.5/42.2
C3382 4030022640 S.CER 0402N101J500CT T 34.0/42.2
C3383 4030022640 S.CER 0402N101J500CT T 34.0/53.7
C3384 4030022640 S.CER 0402N101J500CT T 36.5/53.7
C3385 4030022640 S.CER 0402N101J500CT T 31.8/43.2
C3386 4030022640 S.CER 0402N101J500CT T 27.8/42.1
C3387 4030023030 S.CER 0402B103K250CT T 35.3/55.3
C3391 4030022540 S.CER 0402N3R0B500CT T 36.8/46.3
C3392 4030022540 S.CER 0402N3R0B500CT T 37.7/46.3
C3393 4030022580 S.CER 0402N7R0C500CT T 38.1/47.5
C3395 4030022540 S.CER 0402N3R0B500CT T 36.8/49.6
C3396 4030022540 S.CER 0402N3R0B500CT T 37.7/49.6
C3401 4030024550 S.CER 0402N3R5B500CT T 32.0/46.2
C3402 4030024550 S.CER 0402N3R5B500CT T 32.9/46.3
C3403 4030022540 S.CER 0402N3R0B500CT T 32.5/47.5
C3405 4030024550 S.CER 0402N3R5B500CT T 32.0/49.7
C3406 4030024550 S.CER 0402N3R5B500CT T 32.9/49.6
C3407 4030024550 S.CER 0402N3R5B500CT T 33.9/47.1
C3408 4030024550 S.CER 0402N3R5B500CT T 33.9/48.8
C3501 4030019560 S.CER GRM21BB31C106KE15L T 25.0/20.7
C3502 4030019560 S.CER GRM21BB31C106KE15L T 25.0/25.8
C3511 4030019560 S.CER GRM21BB31C106KE15L T 43.6/32.5
C3512 4030019560 S.CER GRM21BB31C106KE15L T 43.6/37.6
C7101 4030022580 S.CER 0402N7R0C500CT T 64.0/44.7
C7102 4030017630 S.CER C1005 CH 1H 120J-T T 64.0/45.6
C7103 4030022580 S.CER 0402N7R0C500CT T 60.8/44.4
C7104 4030022580 S.CER 0402N7R0C500CT T 62.6/45.2
C7105 4030022520 S.CER 0402N1R0B500CT T 60.8/46.1
C7106 4030017630 S.CER C1005 CH 1H 120J-T T 59.9/44.4
C7107 4030022540 S.CER 0402N3R0B500CT T 59.4/46.5
C7108 4030022560 S.CER 0402N5R0B500CT T 59.0/44.4
C7151 4030022810 S.CER 0402N330J500CT T 58.5/47.4
C7152 4030022690 S.CER 0402N151J500CT T 57.4/46.1
C7153 4030022700 S.CER 0402N180J500CT T 56.9/47.4
C7154 4030022870 S.CER 0402N471J500CT T 56.5/46.1
C7155 4030022810 S.CER 0402N330J500CT T 55.6/46.1
C7201 4030024500 S.CER C1005 JB 1C 224K-T B 36.2/69.5
C7202 4030024500 S.CER C1005 JB 1C 224K-T B 36.9/68.9
C7203 4030024500 S.CER C1005 JB 1C 224K-T B 37.5/68.2
C7204 4030024500 S.CER C1005 JB 1C 224K-T B 38.2/67.6
C7205 4030024500 S.CER C1005 JB 1C 224K-T B 38.8/66.9
C7206 4030024500 S.CER C1005 JB 1C 224K-T B 39.5/66.3
C7207 4030024500 S.CER C1005 JB 1C 224K-T B 40.1/65.6
C7208 4030024500 S.CER C1005 JB 1C 224K-T B 40.8/65.0
C7209 4030024500 S.CER C1005 JB 1C 224K-T B 41.4/64.3
C7210 4030024500 S.CER C1005 JB 1C 224K-T B 42.1/63.7
C7211 4030024500 S.CER C1005 JB 1C 224K-T T 42.3/59.3
C7212 4030023010 S.CER 0402B104K160CT T 43.5/59.3
C7213 4030024500 S.CER C1005 JB 1C 224K-T B 45.2/64.8
C7214 4030023010 S.CER 0402B104K160CT B 45.9/65.4
C7215 4030024500 S.CER C1005 JB 1C 224K-T B 39.3/73.3
C7216 4030024500 S.CER C1005 JB 1C 224K-T B 46.5/66.1
C7217 4030024500 S.CER C1005 JB 1C 224K-T B 39.9/74.0
C7218 4030024500 S.CER C1005 JB 1C 224K-T B 47.2/66.7
C7219 4030024500 S.CER C1005 JB 1C 224K-T B 41.6/75.5
C7220 4030024500 S.CER C1005 JB 1C 224K-T B 48.7/68.2
C7221 4030019560 S.CER GRM21BB31C106KE15L T 32.6/77.4
C7222 4030019560 S.CER GRM21BB31C106KE15L T 50.8/65.7
C7223 4030024500 S.CER C1005 JB 1C 224K-T B 46.7/73.6
C7224 4030023010 S.CER 0402B104K160CT T 35.1/69.1
C7225 4030019560 S.CER GRM21BB31C106KE15L T 45.3/61.6
C7226 4030019560 S.CER GRM21BB31C106KE15L T 30.0/73.3
C7227 4030019560 S.CER GRM21BB31C106KE15L T 29.3/71.0
C7231 4030023030 S.CER 0402B103K250CT T 56.0/48.6
C7301 4030022860 S.CER 0402N470J500CT T 22.2/58.5
C7302 4030022580 S.CER 0402N7R0C500CT T 21.8/57.3
C7303 4030022900 S.CER 0402N680J500CT T 22.7/57.3
C7304 4030022680 S.CER 0402N150J500CT T 21.2/56.0
C7305 4030022840 S.CER 0402N390J500CT T 22.7/53.8
C7306 4030022590 S.CER 0402N8R0C500CT T 21.2/50.9
C7307 4030022590 S.CER 0402N8R0C500CT T 21.6/49.5
C7308 4030022770 S.CER 0402N270J500CT T 22.5/50.4
C7321 4030022670 S.CER 0402N121J500CT T 16.9/62.9
C7322 4030022690 S.CER 0402N151J500CT T 16.3/64.4
C7323 4030022570 S.CER 0402N6R0C500CT T 19.1/64.9
C7324 4030022560 S.CER 0402N5R0B500CT T 17.5/64.9
C7353 4030023030 S.CER 0402B103K250CT T 11.5/68.9
C7354 4030023010 S.CER 0402B104K160CT T 12.6/80.5
C7402 4030023030 S.CER 0402B103K250CT T 22.0/68.9
C7404 4030023010 S.CER 0402B104K160CT T 24.0/80.5
C7421 4030022670 S.CER 0402N121J500CT T 35.7/58.6
C7422 4030022690 S.CER 0402N151J500CT T 34.6/59.8
C7423 4030022570 S.CER 0402N6R0C500CT T 30.8/56.8
C7424 4030022560 S.CER 0402N5R0B500CT T 31.5/56.2
C7451 4030022860 S.CER 0402N470J500CT T 29.0/53.6
C7452 4030022580 S.CER 0402N7R0C500CT T 29.5/52.4
C7453 4030022900 S.CER 0402N680J500CT T 28.6/52.4
C7454 4030022680 S.CER 0402N150J500CT T 29.6/51.0
C7455 4030022840 S.CER 0402N390J500CT T 28.0/51.0
C7456 4030022590 S.CER 0402N8R0C500CT T 29.5/46.9
C7457 4030022590 S.CER 0402N8R0C500CT T 30.0/45.6
C7458 4030022770 S.CER 0402N270J500CT T 28.2/46.4
C7501 4030023010 S.CER 0402B104K160CT T 26.5/99.0
C7502 4030023010 S.CER 0402B104K160CT T 25.2/104.3
C7503 4030020120 S.CER C1005 JB 0J 225M-T T 25.4/100.4
C7504 4030023010 S.CER 0402B104K160CT T 25.2/95.2
C7505 4030023010 S.CER 0402B104K160CT T 38.2/95.3
C7506 4030023010 S.CER 0402B104K160CT T 38.2/104.1
C7507 4030019560 S.CER GRM21BB31C106KE15L T 22.7/106.9
C7508 4030020120 S.CER C1005 JB 0J 225M-T T 25.0/99.5
C7509 4030019560 S.CER GRM21BB31C106KE15L T 22.7/105.1
C7510 4030023030 S.CER 0402B103K250CT T 65.2/71.7
C7511 4030023030 S.CER 0402B103K250CT T 65.7/75.5
C7512 4030023030 S.CER 0402B103K250CT T 59.9/71.1
C7651 4030023030 S.CER 0402B103K250CT B 57.5/99.6
C7653 4030023010 S.CER 0402B104K160CT B 57.5/100.5
C7701 4030019560 S.CER GRM21BB31C106KE15L B 58.1/107.5
C7702 4030023010 S.CER 0402B104K160CT B 64.3/97.6
C7703 4030023010 S.CER 0402B104K160CT B 67.7/99.6
C7706 4030023030 S.CER 0402B103K250CT B 64.7/94.6
C7707 4030023030 S.CER 0402B103K250CT B 69.2/99.3
C7752 4030023010 S.CER 0402B104K160CT B 57.5/90.6
C7753 4030023010 S.CER 0402B104K160CT B 61.2/87.1
C7758 4030023030 S.CER 0402B103K250CT B 58.7/89.6
C7759 4030023030 S.CER 0402B103K250CT B 60.7/89.8
C7760 4030023030 S.CER 0402B103K250CT B 62.7/93.6
C7801 4030023030 S.CER 0402B103K250CT B 65.2/89.6
C7803 4030023010 S.CER 0402B104K160CT B 66.2/89.6
C7805 4030019560 S.CER GRM21BB31C106KE15L B 56.3/107.5
C7852 4030023010 S.CER 0402B104K160CT B 69.7/87.4
C7854 4030023030 S.CER 0402B103K250CT B 70.2/88.6
C7931 4030023010 S.CER 0402B104K160CT T 47.4/113.5
C7932 4030023010 S.CER 0402B104K160CT T 47.4/110.0
C7933 4030023010 S.CER 0402B104K160CT T 45.6/110.1
C7934 4030023090 S.CER 0402B102K500CT T 45.6/107.9
C8051 4030023010 S.CER 0402B104K160CT B 77.0/85.7
C8052 4030023010 S.CER 0402B104K160CT B 73.7/89.0
C8053 4030023010 S.CER 0402B104K160CT B 76.9/91.6
C8054 4030023010 S.CER 0402B104K160CT B 73.2/96.4
C8061 4030023030 S.CER 0402B103K250CT B 77.0/86.6
C8062 4030023030 S.CER 0402B103K250CT B 73.7/87.4
C8063 4030023030 S.CER 0402B103K250CT B 74.5/91.6
C8064 4030023030 S.CER 0402B103K250CT B 72.7/94.4
C8071 4030019560 S.CER GRM21BB31C106KE15L B 75.8/106.7
C8101 4030023010 S.CER 0402B104K160CT B 77.5/98.3
C8102 4030023010 S.CER 0402B104K160CT B 73.7/101.0
C8105 4030023030 S.CER 0402B103K250CT B 76.5/98.3
C8106 4030023030 S.CER 0402B103K250CT B 71.5/100.6
C8109 4030019560 S.CER GRM21BB31C106KE15L B 77.7/100.1
C8151 4030023090 S.CER 0402B102K500CT B 69.2/90.1
C8152 4030023090 S.CER 0402B102K500CT B 70.6/102.3
C8153 4030023090 S.CER 0402B102K500CT B 67.3/102.6
C8154 4030023090 S.CER 0402B102K500CT B 70.5/94.4
C8155 4030023090 S.CER 0402B102K500CT B 70.5/96.1
C8161 4030023010 S.CER 0402B104K160CT B 70.1/90.1
C8162 4030023010 S.CER 0402B104K160CT B 66.7/97.6
C8163 4030023010 S.CER 0402B104K160CT B 65.7/93.6
C8164 4030023010 S.CER 0402B104K160CT B 70.5/92.8
C8165 4030023010 S.CER 0402B104K160CT B 71.0/97.3
C8166 4030023010 S.CER 0402B104K160CT B 67.3/101.6
C8167 4030023010 S.CER 0402B104K160CT B 70.6/104.0
C8171 4030019560 S.CER GRM21BB31C106KE15L B 71.6/107.3
C8172 4030019560 S.CER GRM21BB31C106KE15L B 72.0/84.5

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5 -11a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
C8175 4030022050 S.CER GRM21BR61C226ME44L B 69.8/107.3
C8176 4030022050 S.CER GRM21BR61C226ME44L B 69.7/84.5
C8201 4030023030 S.CER 0402B103K250CT B 76.1/90.6
C8202 4030023030 S.CER 0402B103K250CT B 74.8/94.4
C8203 4030023030 S.CER 0402B103K250CT B 76.1/101.5
C8204 4030023030 S.CER 0402B103K250CT B 59.5/87.2
C8207 4030023010 S.CER 0402B104K160CT B 73.5/90.6
C8208 4030023010 S.CER 0402B104K160CT B 75.7/94.4
C8209 4030023010 S.CER 0402B104K160CT B 76.1/102.4
C8210 4030023010 S.CER 0402B104K160CT B 59.5/86.3
C8213 4030019560 S.CER GRM21BB31C106KE15L B 77.0/88.3
C8251 4030023030 S.CER 0402B103K250CT B 71.7/89.8
C8252 4030023030 S.CER 0402B103K250CT B 73.2/102.8
C8253 4030023030 S.CER 0402B103K250CT B 67.2/105.3
C8257 4030023010 S.CER 0402B104K160CT B 71.7/87.4
C8258 4030023010 S.CER 0402B104K160CT B 73.9/104.4
C8259 4030023010 S.CER 0402B104K160CT B 65.7/105.0
C8263 4030019560 S.CER GRM21BB31C106KE15L B 65.6/107.5
C8301 4030023090 S.CER 0402B102K500CT B 77.2/103.6
C8302 4030023010 S.CER 0402B104K160CT B 76.3/103.6
C8303 4030019560 S.CER GRM21BB31C106KE15L B 78.7/107.6
C8351 4030023090 S.CER 0402B102K500CT B 73.7/98.4
C8352 4030023090 S.CER 0402B102K500CT B 63.0/89.6
C8354 4030023010 S.CER 0402B104K160CT B 74.1/99.6
C8355 4030023010 S.CER 0402B104K160CT B 62.6/88.3
C8357 4030019560 S.CER GRM21BB31C106KE15L B 62.0/107.5
C8501 4030023030 S.CER 0402B103K250CT B 59.7/90.8
C8506 4030023010 S.CER 0402B104K160CT B 58.7/88.1
C8510 4030019560 S.CER GRM21BB31C106KE15L B 54.5/107.5
C8511 4030019560 S.CER GRM21BB31C106KE15L B 75.8/108.4
C8512 4030023010 S.CER 0402B104K160CT B 56.2/102.9
C8513 4030023030 S.CER 0402B103K250CT B 57.1/102.9
C8521 4030023030 S.CER 0402B103K250CT B 75.6/97.3
C8522 4030023030 S.CER 0402B103K250CT B 73.5/92.6
C8526 4030023010 S.CER 0402B104K160CT B 74.7/97.3
C8527 4030023010 S.CER 0402B104K160CT B 75.9/92.6
C8552 4030023030 S.CER 0402B103K250CT B 66.7/91.6
C8554 4030023010 S.CER 0402B104K160CT B 67.7/90.1
C8555 4030019560 S.CER GRM21BB31C106KE15L B 63.7/107.5
C8571 4030023030 S.CER 0402B103K250CT B 67.1/87.4
C8572 4030023010 S.CER 0402B104K160CT B 67.1/88.3
C8601 4030023030 S.CER 0402B103K250CT T 110.9/37.2
C8602 4030023010 S.CER 0402B104K160CT T 107.1/36.0
C8603 4030023090 S.CER 0402B102K500CT T 107.1/36.9
C8604 4030023010 S.CER 0402B104K160CT T 107.1/35.1
C8605 4030023090 S.CER 0402B102K500CT T 108.5/40.5
C8606 4030022630 S.CER 0402N100C500CT T 109.7/40.9
C8607 4030023010 S.CER 0402B104K160CT T 105.9/36.5
C8609 4030023010 S.CER 0402B104K160CT T 107.3/38.9
C8610 4030023030 S.CER 0402B103K250CT T 102.3/39.5
C8611 4030023030 S.CER 0402B103K250CT T 102.8/40.7
C8622 4030023030 S.CER 0402B103K250CT T 100.6/39.5
C8623 4030023010 S.CER 0402B104K160CT T 103.6/34.5
C8624 4030022600 S.CER 0402N9R0C500CT T 97.4/34.7
C8625 4030022590 S.CER 0402N8R0C500CT T 97.0/35.9
C8626 4030022590 S.CER 0402N8R0C500CT T 95.5/36.4
C8627 4030022600 S.CER 0402N9R0C500CT T 94.3/36.8
C8628 4030022700 S.CER 0402N180J500CT T 95.5/34.6
C8629 4030022700 S.CER 0402N180J500CT T 95.5/35.5
C8641 4030023030 S.CER 0402B103K250CT T 78.8/37.7
C8642 4030023030 S.CER 0402B103K250CT T 80.2/39.1
C8643 4030023010 S.CER 0402B104K160CT T 78.5/42.5
C8644 4030022570 S.CER 0402N6R0C500CT T 80.5/46.7
C8645 4030022540 S.CER 0402N3R0B500CT T 80.5/47.6
C8646 4030022540 S.CER 0402N3R0B500CT T 80.1/49.0
C8647 4030022570 S.CER 0402N6R0C500CT T 81.0/49.9
C8648 4030022560 S.CER 0402N5R0B500CT T 78.9/47.6
C8649 4030022590 S.CER 0402N8R0C500CT T 78.9/48.5
C8661 4030023030 S.CER 0402B103K250CT T 89.1/61.9
C8662 4030023030 S.CER 0402B103K250CT T 87.7/63.3
C8663 4030023010 S.CER 0402B104K160CT T 84.4/64.1
C8664 4030022530 S.CER 0402N2R0B500CT T 84.8/67.4
C8665 4030022530 S.CER 0402N2R0B500CT T 83.6/67.0
C8666 4030022530 S.CER 0402N2R0B500CT T 83.1/65.8
C8667 4030022530 S.CER 0402N2R0B500CT T 82.2/64.9
C8668 4030024550 S.CER 0402N3R5B500CT T 83.6/68.2
C8670 4030022660 S.CER 0402N120J500CT T 62.5/70.8
C8671 4030022660 S.CER 0402N120J500CT T 66.3/70.8
C8672 4030022740 S.CER 0402N220J500CT T 66.6/68.8
C8692 4030023010 S.CER 0402B104K160CT T 84.7/42.8
C8693 4030023010 S.CER 0402B104K160CT T 84.4/49.1
C8694 4030023030 S.CER 0402B103K250CT T 87.1/74.7
C8701 4030024500 S.CER C1005 JB 1C 224K-T T 74.7/58.1
C8702 4030022630 S.CER 0402N100C500CT T 73.4/56.4
C8703 4030023230 S.CER 0402B562K500CT T 74.6/56.8
C8704 4030022600 S.CER 0402N9R0C500CT T 73.4/57.3
C8705 4030023090 S.CER 0402B102K500CT T 72.3/54.4
C8706 4030023090 S.CER 0402B102K500CT T 71.8/59.7
C8707 4030023090 S.CER 0402B102K500CT T 72.3/52.4
C8708 4030023090 S.CER 0402B102K500CT T 69.6/50.8
C8709 4030023090 S.CER 0402B102K500CT T 65.6/61.8
C8710 4030023090 S.CER 0402B102K500CT T 66.9/50.8
C8711 4030023090 S.CER 0402B102K500CT T 66.0/50.8
C8712 4030023090 S.CER 0402B102K500CT T 62.9/54.1
C8713 4030023090 S.CER 0402B102K500CT T 61.9/56.3
C8714 4030019560 S.CER GRM21BB31C106KE15L T 72.0/50.4
C8715 4030023090 S.CER 0402B102K500CT T 62.9/58.5
C8716 4030019560 S.CER GRM21BB31C106KE15L T 73.2/59.7
C8717 4030023090 S.CER 0402B102K500CT T 60.7/49.7
C8718 4030023090 S.CER 0402B102K500CT T 60.7/50.6
C8720 4030023030 S.CER 0402B103K250CT T 60.1/55.2
C8721 4030023030 S.CER 0402B103K250CT T 60.0/57.5
C8732 4030022770 S.CER 0402N270J500CT T 59.3/54.0
C8734 4030022770 S.CER 0402N270J500CT T 59.2/58.7
C8735 4030022770 S.CER 0402N270J500CT T 57.7/54.0
C8736 4030022770 S.CER 0402N270J500CT T 57.6/58.7
C8801 4030023010 S.CER 0402B104K160CT T 10.0/110.1
C8802 4030023010 S.CER 0402B104K160CT T 11.2/111.7
C8803 4030023010 S.CER 0402B104K160CT T 13.8/112.2
C8804 4030023010 S.CER 0402B104K160CT T 17.1/112.2
C8805 4030022700 S.CER 0402N180J500CT T 18.1/110.3
C8806 4030023010 S.CER 0402B104K160CT T 19.1/109.0
C8811 4030023010 S.CER 0402B104K160CT T 23.5/112.8
C8812 4030023010 S.CER 0402B104K160CT T 20.8/113.0
C8813 4030023010 S.CER 0402B104K160CT T 26.4/112.6
C8821 4030023010 S.CER 0402B104K160CT T 13.8/115.7
C8822 4030023010 S.CER 0402B104K160CT T 19.3/114.8
C9001 4030023030 S.CER 0402B103K250CT T 26.6/5.6
C9002 4030023030 S.CER 0402B103K250CT T 24.3/3.8
C9003 4030023030 S.CER 0402B103K250CT T 23.0/5.6
C9004 4030023090 S.CER 0402B102K500CT T 21.3/7.7
C9005 4030023090 S.CER 0402B102K500CT T 20.3/7.7
C9006 4030023030 S.CER 0402B103K250CT T 19.3/7.7
C9007 4030023030 S.CER 0402B103K250CT T 18.3/7.7
C9008 4030023030 S.CER 0402B103K250CT T 17.3/7.7
C9009 4030023030 S.CER 0402B103K250CT T 16.3/7.7
C9010 4030023030 S.CER 0402B103K250CT T 15.3/7.7
C9011 4030023030 S.CER 0402B103K250CT T 14.3/7.7
C9012 4030023030 S.CER 0402B103K250CT T 13.3/7.7
C9013 4030023090 S.CER 0402B102K500CT T 12.3/7.7
C9014 4030023090 S.CER 0402B102K500CT T 11.3/7.7
C9101 4030023030 S.CER 0402B103K250CT T 131.8/5.6
C9102 4030023030 S.CER 0402B103K250CT T 130.0/5.6
C9103 4030023030 S.CER 0402B103K250CT T 128.2/5.6
C9104 4030023090 S.CER 0402B102K500CT T 126.5/7.7
C9105 4030023090 S.CER 0402B102K500CT T 125.5/7.7
C9106 4030023030 S.CER 0402B103K250CT T 124.5/7.7
C9107 4030023030 S.CER 0402B103K250CT T 123.5/7.7
C9108 4030023030 S.CER 0402B103K250CT T 122.5/7.7
C9109 4030023030 S.CER 0402B103K250CT T 121.5/7.7
C9110 4030023030 S.CER 0402B103K250CT T 120.5/7.7
C9111 4030023030 S.CER 0402B103K250CT T 119.5/7.7
C9112 4030023030 S.CER 0402B103K250CT T 118.5/7.7
C9113 4030023090 S.CER 0402B102K500CT T 117.5/7.7
C9114 4030023090 S.CER 0402B102K500CT T 117.0/18.2
C9115 4030023090 S.CER 0402B102K500CT T 118.0/18.2
C9116 4030023090 S.CER 0402B102K500CT T 119.0/18.2
C9151 4030023030 S.CER 0402B103K250CT T 113.0/128.5
C9152 4030023030 S.CER 0402B103K250CT T 116.7/123.7
C9201 4030023030 S.CER 0402B103K250CT T 181.4/5.6
C9202 4030023030 S.CER 0402B103K250CT T 179.4/5.6
C9203 4030022630 S.CER 0402N100C500CT T 177.9/7.7
C9204 4030022630 S.CER 0402N100C500CT T 177.4/18.2
C9205 4030022630 S.CER 0402N100C500CT T 176.9/7.7
C9206 4030022630 S.CER 0402N100C500CT T 176.4/18.2
C9207 4030022630 S.CER 0402N100C500CT T 175.9/7.7
C9208 4030023090 S.CER 0402B102K500CT T 175.4/18.2
C9209 4030023090 S.CER 0402B102K500CT T 174.9/7.7
C9210 4030023030 S.CER 0402B103K250CT T 174.4/18.2
C9211 4030023030 S.CER 0402B103K250CT T 173.9/7.7
C9212 4030023030 S.CER 0402B103K250CT T 173.4/18.2
C9213 4030023030 S.CER 0402B103K250CT T 172.9/7.7
C9214 4030023030 S.CER 0402B103K250CT T 171.9/7.7
C9215 4030023030 S.CER 0402B103K250CT T 170.9/7.7
C9216 4030023030 S.CER 0402B103K250CT T 169.9/7.7
C9217 4030023030 S.CER 0402B103K250CT T 168.9/7.7
C9218 4030023090 S.CER 0402B102K500CT T 167.9/7.7
C9219 4030023090 S.CER 0402B102K500CT T 166.9/7.7
C9301 4030022750 S.CER 0402N221J500CT T 177.3/37.0
C9302 4030022750 S.CER 0402N221J500CT T 175.5/37.0
C9303 4030022750 S.CER 0402N221J500CT T 173.7/37.0
C9304 4030022750 S.CER 0402N221J500CT T 171.9/37.0
C9305 4030022750 S.CER 0402N221J500CT T 170.1/37.0
C9306 4030022750 S.CER 0402N221J500CT T 168.3/37.0
C9307 4030022750 S.CER 0402N221J500CT T 166.5/37.0
C9308 4030022750 S.CER 0402N221J500CT T 164.7/37.0
C9310 4030022750 S.CER 0402N221J500CT T 141.1/7.1
C9311 4030023030 S.CER 0402B103K250CT T 139.7/7.1
C9312 4030022740 S.CER 0402N220J500CT T 138.8/7.1
C9321 4030023010 S.CER 0402B104K160CT T 156.3/5.9
C9322 4030023010 S.CER 0402B104K160CT T 154.8/5.9
C9323 4030023010 S.CER 0402B104K160CT T 153.3/5.9
C9325 4030022750 S.CER 0402N221J500CT T 178.2/37.0
C9326 4030022750 S.CER 0402N221J500CT T 176.4/37.0
C9327 4030022750 S.CER 0402N221J500CT T 174.6/37.0
C9328 4030022750 S.CER 0402N221J500CT T 172.8/37.0
C9329 4030022750 S.CER 0402N221J500CT T 171.0/37.0
C9330 4030022750 S.CER 0402N221J500CT T 169.2/37.0
C9331 4030022750 S.CER 0402N221J500CT T 167.4/37.0
C9332 4030022750 S.CER 0402N221J500CT T 165.6/37.0
C9333 4030022750 S.CER 0402N221J500CT T 163.8/37.0
C9334 4030022750 S.CER 0402N221J500CT T 162.9/37.0
C9335 4030022750 S.CER 0402N221J500CT T 162.0/37.0
C9336 4030022740 S.CER 0402N220J500CT T 138.4/18.1
C9337 4030023030 S.CER 0402B103K250CT T 137.5/18.1
C9401 4030023010 S.CER 0402B104K160CT T 186.6/21.1
C9501 4030023090 S.CER 0402B102K500CT T 173.3/115.9
C9502 4030023090 S.CER 0402B102K500CT T 173.3/113.7
C9503 4030023090 S.CER 0402B102K500CT T 173.3/111.5
C9504 4030023090 S.CER 0402B102K500CT T 172.8/109.3
C9506 4030023090 S.CER 0402B102K500CT T 173.8/106.6
RL2241 6310000150 S.REL AGN200S09ZK1 T 195.5/133.0

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-12a
(Amended page)
June 2019
[MAIN UNIT] [MAIN UNIT]
RL2242 6310000150 S.REL AGN200S09ZK1 T 203.0/144.1
RL2251 6310000150 S.REL AGN200S09ZK1 T 203.0/133.0
RL2252 6310000150 S.REL AGN200S09ZK1 T 195.5/144.1
CP8661 6910009670 S.CHE HK3-S-T T 73.4/36.1
CP8662 6910009670 S.CHE HK3-S-T T 71.9/29.6
J101 6510025142 S.CON 10FLT-SM2-TB (LF) (SN) (M) T 183.0/39.0
J301 6510027290 S.CON 52808-0671 T 101.0/89.5
J1621 6510026540 CON UBB-4R-D14T-4D (LF) (SN)
J1901 6510024040 CON TM11R-5M2-88-LP
J2262 6510014961 S.CON B2B-ZR-SM4-TF (LF) (SN) T 211.8/140.0
J2881 6510018961 S.CON B2B-PH-SM4-TB (LF) (SN) T 135.0/133.0
J2891 6510032670 CON ABA-JAK-038-K54
J2901 6510027740 CON HSJ2462-010010
J2911 6510023671 CON TCS4480-0141577
J3071 6510032350 S.CON 20279-001E-01 T 75.0/10.0
J3081 6510032350 S.CON 20279-001E-01 T 85.0/10.0
J3091 6510032350 S.CON 20279-001E-01 T 95.0/10.0
J3101 6510032350 S.CON 20279-001E-01 T 37.5/10.0
J3111 6510032350 S.CON 20279-001E-01 T 47.5/10.0
J3121 6510032350 S.CON 20279-001E-01 T 57.5/10.0
J7402 6510032670 CON ABA-JAK-038-K54
J8661 6510032350 S.CON 20279-001E-01 T 71.2/44.7
J8801 6510032350 S.CON 20279-001E-01 T 5.4/109.7
J9001 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 19.0/12.9
J9101 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 124.3/12.9
J9151 6510022311 S.CON B5B-PH-SM4-TB (LF) (SN) T 119.0/133.0
J9201 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 174.7/12.9
J9301 6510022472 S.CON 40FLT-SM2-TB (LF) (SN) (M) T 147.0/12.4
J9401 6510024522 S.CON 12FLT-SM2-TB (LF) (SN) (M) T 185.8/25.0
J9501 6510023261 S.CON B6B-PH-SM4-TB (LF) (SN) T 180.0/111.5
DS1901 5040003590 S.LED SML-D12P8WT86 T 16.1/153.7
DS1902 5040003590 S.LED SML-D12P8WT86 T 4.9/153.7
S171 2230001480 S.SWI LS37J2-T T 186.3/33.6
T1901 5920000990 S.TRA H1102FNLT T 16.5/142.5
BT251 3020000390 S.LIT ML414HIV01E T 157.5/79.5
EP101 6910023350 S.BEA MMZ1005B601CT B 156.5/62.2
EP102 6910019900 S.BEA MPZ1608S601AT B 152.3/68.0
EP103 6910023350 S.BEA MMZ1005B601CT B 164.1/49.6
EP104 6910023350 S.BEA MMZ1005B601CT T 134.3/79.0
EP111 6910021140 S.BEA MMZ1005S800CT T 145.3/54.1
EP112 6910021140 S.BEA MMZ1005S800CT T 147.0/54.7
EP113 6910021140 S.BEA MMZ1005S800CT T 147.0/53.6
EP114 6910021140 S.BEA MMZ1005S800CT T 145.0/53.0
EP115 6910021140 S.BEA MMZ1005S800CT T 145.0/51.9
EP116 6910021140 S.BEA MMZ1005S800CT T 147.0/52.5
EP117 6910021140 S.BEA MMZ1005S800CT T 147.0/51.4
EP118 6910021140 S.BEA MMZ1005S800CT T 145.0/50.8
EP181 6910023350 S.BEA MMZ1005B601CT T 155.7/75.8
EP191 6910023350 S.BEA MMZ1005B601CT T 165.8/69.6
EP301 6910023350 S.BEA MMZ1005B601CT T 90.0/111.5
EP311 6910023350 S.BEA MMZ1005B601CT T 189.5/41.8
EP331 6910023350 S.BEA MMZ1005B601CT T 109.1/113.0
EP501 6910019900 S.BEA MPZ1608S601AT T 122.8/113.5
EP502 6910016540 S.BEA BLM15AG121SN1D T 143.5/103.4
EP1001 6910018930 S.BEA MPZ2012S601A T 74.4/133.5
EP1002 6910018930 S.BEA MPZ2012S601A T 67.2/143.7
EP1041 6910018930 S.BEA MPZ2012S601A T 85.5/130.5
EP1042 6910024810 S.BEA MPZ2012S300AT T 89.5/144.3
EP1101 6910018930 S.BEA MPZ2012S601A T 63.2/142.3
EP1102 6910018930 S.BEA MPZ2012S601A T 51.6/133.2
EP1103 6910018930 S.BEA MPZ2012S601A T 70.5/131.3
EP1112 6910024810 S.BEA MPZ2012S300AT T 75.4/119.2
EP1201 6910018930 S.BEA MPZ2012S601A T 91.1/127.4
EP1202 6910018930 S.BEA MPZ2012S601A T 76.2/125.0
EP1203 6910018930 S.BEA MPZ2012S601A T 61.3/120.2
EP1204 6910018930 S.BEA MPZ2012S601A T 63.8/121.4
EP1212 6910018930 S.BEA MPZ2012S601A T 51.5/130.5
EP1531 6910023350 S.BEA MMZ1005B601CT T 158.3/127.8
EP1532 6910023350 S.BEA MMZ1005B601CT T 170.5/136.7
EP1551 6910023350 S.BEA MMZ1005B601CT T 151.3/144.6
EP1571 6910023350 S.BEA MMZ1005B601CT T 147.0/135.4
EP1601 6910023350 S.BEA MMZ1005B601CT T 165.8/138.8
EP1621 6910023350 S.BEA MMZ1005B601CT T 154.1/156.9
EP1901 6910019900 S.BEA MPZ1608S601AT T 142.0/47.0
EP2001 6910019900 S.BEA MPZ1608S601AT T 183.4/65.7
EP2002 6910019900 S.BEA MPZ1608S601AT T 181.5/79.5
EP2101 6910019900 S.BEA MPZ1608S601AT T 161.7/86.1
EP2102 6910019900 S.BEA MPZ1608S601AT T 161.9/102.5
EP2241 6910019900 S.BEA MPZ1608S601AT T 179.8/125.4
EP2261 6910018930 S.BEA MPZ2012S601A T 207.4/149.1
EP2262 6910018930 S.BEA MPZ2012S601A T 194.3/150.6
EP2263 6910018930 S.BEA MPZ2012S601A T 212.2/157.1
EP2264 6910018930 S.BEA MPZ2012S601A T 208.2/136.8
EP2801 6910023350 S.BEA MMZ1005B601CT T 108.7/51.4
EP2811 6910023350 S.BEA MMZ1005B601CT T 115.3/50.2
EP2821 6910023350 S.BEA MMZ1005B601CT T 121.9/50.2
EP2881 6910019900 S.BEA MPZ1608S601AT T 126.0/125.5
EP2882 6910019900 S.BEA MPZ1608S601AT T 136.5/127.0
EP2891 6910023350 S.BEA MMZ1005B601CT T 185.5/156.1
EP2892 6910023350 S.BEA MMZ1005B601CT T 177.2/150.5
EP2893 6910023350 S.BEA MMZ1005B601CT T 174.9/150.5
EP2901 6910023350 S.BEA MMZ1005B601CT T 141.8/157.8
EP2902 6910023350 S.BEA MMZ1005B601CT T 152.3/160.8
EP2911 6910023350 S.BEA MMZ1005B601CT T 122.8/148.4
EP2912 6910018930 S.BEA MPZ2012S601A T 127.0/147.5
EP2913 6910019900 S.BEA MPZ1608S601AT T 138.3/147.9
EP2914 6910023350 S.BEA MMZ1005B601CT T 124.0/148.4
EP2915 6910023350 S.BEA MMZ1005B601CT T 134.0/148.4
EP2916 6910023350 S.BEA MMZ1005B601CT T 121.5/148.4
EP2917 6910018930 S.BEA MPZ2012S601A T 136.5/147.5
EP2918 6910023350 S.BEA MMZ1005B601CT T 129.0/148.4
EP3011 6910018460 S.BEA MMZ1005Y102C-T T 59.2/38.0
EP3012 6910018460 S.BEA MMZ1005Y102C-T T 71.1/38.8
EP3021 6910018460 S.BEA MMZ1005Y102C-T T 59.2/31.9
EP3022 6910018460 S.BEA MMZ1005Y102C-T T 71.2/32.6
EP3041 6910018460 S.BEA MMZ1005Y102C-T T 59.2/28.0
EP3042 6910018460 S.BEA MMZ1005Y102C-T T 71.2/27.6
EP3142 6910018460 S.BEA MMZ1005Y102C-T T 17.5/25.2
EP3151 6910019900 S.BEA MPZ1608S601AT T 19.2/33.2
EP3161 6910018460 S.BEA MMZ1005Y102C-T T 21.1/42.6
EP3342 6910018460 S.BEA MMZ1005Y102C-T T 41.3/26.7
EP3351 6910019900 S.BEA MPZ1608S601AT T 32.9/28.7
EP3361 6910018460 S.BEA MMZ1005Y102C-T T 36.6/37.7
EP7201 6910021240 S.BEA MMZ1005A152ET T 41.4/59.3
EP7202 6910019900 S.BEA MPZ1608S601AT T 34.3/66.3
EP7203 6910019900 S.BEA MPZ1608S601AT T 31.3/67.7
EP7204 6910018460 S.BEA MMZ1005Y102C-T T 31.9/74.8
EP7205 6910018460 S.BEA MMZ1005Y102C-T T 33.1/75.7
EP7206 6910018930 S.BEA MPZ2012S601A T 34.0/79.8
EP7501 6910018930 S.BEA MPZ2012S601A T 18.6/104.6
EP7502 6910019900 S.BEA MPZ1608S601AT T 18.5/106.8
EP7651 6910019900 S.BEA MPZ1608S601AT T 58.1/112.9
EP7931 6910019900 S.BEA MPZ1608S601AT T 47.9/115.2
EP8051 6910019900 S.BEA MPZ1608S601AT T 73.1/112.9
EP8151 6910024810 S.BEA MPZ2012S300AT T 69.9/112.9
EP8201 6910019900 S.BEA MPZ1608S601AT T 75.6/112.9
EP8251 6910019900 S.BEA MPZ1608S601AT T 64.6/112.9
EP8301 6910019900 S.BEA MPZ1608S601AT T 76.9/112.9
EP8351 6910019900 S.BEA MPZ1608S601AT T 62.0/112.9
EP8501 6910019900 S.BEA MPZ1608S601AT T 56.8/112.9
EP8502 6910019900 S.BEA MPZ1608S601AT T 59.4/112.9
EP8551 6910019900 S.BEA MPZ1608S601AT T 63.3/112.9
EP8601 6910023420 S.BEA MMZ1005A222ET T 108.3/35.6
EP8602 6910018460 S.BEA MMZ1005Y102C-T T 105.7/34.9
EP8621 6910018460 S.BEA MMZ1005Y102C-T T 104.5/35.4
EP8641 6910018460 S.BEA MMZ1005Y102C-T T 80.1/42.5
EP8661 6910018460 S.BEA MMZ1005Y102C-T T 85.6/63.7
EP8691 6910018460 S.BEA MMZ1005Y102C-T T 84.0/50.3
EP8692 6910018460 S.BEA MMZ1005Y102C-T T 87.1/75.6
EP8701 6910018460 S.BEA MMZ1005Y102C-T T 72.3/53.5
EP8702 6910019900 S.BEA MPZ1608S601AT T 63.0/60.6
EP8703 6910018460 S.BEA MMZ1005Y102C-T T 73.5/50.8
EP8801 6910023350 S.BEA MMZ1005B601CT T 16.2/112.2
EP8811 6910018460 S.BEA MMZ1005Y102C-T T 25.2/114.5
EP9001 6910024660 S.BEA MPZ2012S102AT T 26.6/8.9
EP9002 6910024660 S.BEA MPZ2012S102AT T 24.8/8.9
EP9003 6910024660 S.BEA MPZ2012S102AT T 23.0/8.9
EP9004 6910018460 S.BEA MMZ1005Y102C-T T 21.3/9.8
EP9005 6910018460 S.BEA MMZ1005Y102C-T T 20.3/9.8
EP9011 6910018460 S.BEA MMZ1005Y102C-T T 14.3/9.8
EP9012 6910018460 S.BEA MMZ1005Y102C-T T 13.3/9.8
EP9013 6910018460 S.BEA MMZ1005Y102C-T T 12.3/9.8
EP9014 6910018460 S.BEA MMZ1005Y102C-T T 11.3/10.1
EP9101 6910024660 S.BEA MPZ2012S102AT T 131.8/8.9
EP9102 6910024660 S.BEA MPZ2012S102AT T 130.0/8.9
EP9103 6910024660 S.BEA MPZ2012S102AT T 128.2/8.9
EP9104 6910018460 S.BEA MMZ1005Y102C-T T 126.5/9.8
EP9105 6910018460 S.BEA MMZ1005Y102C-T T 125.5/9.8
EP9111 6910018460 S.BEA MMZ1005Y102C-T T 119.5/9.8
EP9112 6910018460 S.BEA MMZ1005Y102C-T T 118.5/9.8
EP9113 6910018460 S.BEA MMZ1005Y102C-T T 117.5/9.8
EP9114 6910018460 S.BEA MMZ1005Y102C-T T 117.0/16.1
EP9115 6910018460 S.BEA MMZ1005Y102C-T T 118.0/16.1
EP9151 6910024660 S.BEA MPZ2012S102AT T 114.0/126.5
EP9152 6910024660 S.BEA MPZ2012S102AT T 119.0/126.1
EP9201 6910024660 S.BEA MPZ2012S102AT T 181.4/8.9
EP9202 6910024660 S.BEA MPZ2012S102AT T 179.4/8.9
EP9208 6910018460 S.BEA MMZ1005Y102C-T T 175.4/16.1
EP9209 6910018460 S.BEA MMZ1005Y102C-T T 174.9/9.8
EP9216 6910018460 S.BEA MMZ1005Y102C-T T 169.9/9.8
EP9217 6910018460 S.BEA MMZ1005Y102C-T T 168.9/9.8
EP9218 6910018460 S.BEA MMZ1005Y102C-T T 167.9/9.8
EP9219 6910018460 S.BEA MMZ1005Y102C-T T 166.9/9.8
EP9301 6910015970 S.BEA MMZ1608B 301CT-AS T 151.5/8.7
EP9302 6910015970 S.BEA MMZ1608B 301CT-AS T 150.3/8.7
EP9303 6910015970 S.BEA MMZ1608B 301CT-AS T 149.1/8.7
EP9304 6910015970 S.BEA MMZ1608B 301CT-AS T 147.9/8.7
EP9305 6910015970 S.BEA MMZ1608B 301CT-AS T 146.7/8.7
EP9306 6910015970 S.BEA MMZ1608B 301CT-AS T 145.5/8.7
EP9307 6910015970 S.BEA MMZ1608B 301CT-AS T 144.3/8.7
EP9308 6910015970 S.BEA MMZ1608B 301CT-AS T 143.1/8.7
EP9321 6910019900 S.BEA MPZ1608S601AT T 156.3/8.9
EP9322 6910019900 S.BEA MPZ1608S601AT T 154.8/8.9
EP9323 6910019900 S.BEA MPZ1608S601AT T 153.3/8.9
EP9324 6910019900 S.BEA MPZ1608S601AT T 139.4/16.1
EP9325 6910015970 S.BEA MMZ1608B 301CT-AS T 152.3/16.1
EP9326 6910015970 S.BEA MMZ1608B 301CT-AS T 151.1/16.1
EP9327 6910015970 S.BEA MMZ1608B 301CT-AS T 149.9/16.1
EP9328 6910015970 S.BEA MMZ1608B 301CT-AS T 148.7/16.1
EP9329 6910015970 S.BEA MMZ1608B 301CT-AS T 147.5/16.1

Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-13a
(Amended page)
June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT]
EP9330 6910015970 S.BEA MMZ1608B 301CT-AS T 146.3/16.1
EP9331 6910015970 S.BEA MMZ1608B 301CT-AS T 145.1/16.1
EP9332 6910015970 S.BEA MMZ1608B 301CT-AS T 143.9/16.1
EP9333 6910015970 S.BEA MMZ1608B 301CT-AS T 142.7/16.1
EP9335 6910015970 S.BEA MMZ1608B 301CT-AS T 140.6/16.1
EP9501 6910019900 S.BEA MPZ1608S601AT T 173.3/117.0
EP9502 6910019900 S.BEA MPZ1608S601AT T 173.3/114.8
EP9503 6910019900 S.BEA MPZ1608S601AT T 173.3/112.6
EP9504 6910019900 S.BEA MPZ1608S601AT T 173.3/110.4
EP9505 6910019900 S.BEA MPZ1608S601AT T 173.3/108.2
EP9506 6910019900 S.BEA MPZ1608S601AT T 173.5/105.4

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-14a
(Amended page)
June 2019
[PA-A UNIT] [PA-A UNIT]
IC101 1110009820 S.IC MMG3H21NT1 B 60.8/52.0
IC211 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 35.9/33.1
IC691 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 142.2/46.2
IC1161 1110009890 S.IC NJG1152KA1-TE1 T 80.6/13.1
IC1162 1180004760 S.REG S-1200B33-M5T1U T 74.9/16.2
Q111 1550000500 S.FET RZF020P01TL T 27.0/32.9
Q112 1590004060 S.TRA LDTC114EET1G T 21.7/34.3
Q201 1560002490 S.FET PD85004-HF T 38.9/27.3
Q301 1560002470 S.FET AFT05MP075NR1 T 66.0/30.0
Q401 1560002230 S.FET FK3503010L T 116.6/4.5
Q701 1520000651 S.TRA 2SB1201S-TL-E T 126.9/56.6
Q702 1510001200 S.TRA L2SA1576ART1G T 133.0/58.5
Q703 1590004060 S.TRA LDTC114EET1G T 132.8/56.1
Q1221 1590004060 S.TRA LDTC114EET1G T 20.2/10.3
Q1222 1590004310 S.TRA LDTA114EET1G T 22.5/10.3
Q1231 1590004060 S.TRA LDTC114EET1G T 20.2/12.6
Q1232 1590004310 S.TRA LDTA114EET1G T 22.5/12.6
Q1241 1590004060 S.TRA LDTC114EET1G T 27.8/10.3
Q1242 1590004310 S.TRA LDTA114EET1G T 30.1/10.3
Q1243 1560002230 S.FET FK3503010L T 27.5/12.6
Q1244 1590004310 S.TRA LDTA114EET1G T 30.1/12.6
D311 1750001810 S.DIO L1SS400T1G T 55.2/39.6
D401 1750001810 S.DIO L1SS400T1G T 117.7/9.5
D601 1750002230 S.DIO LRB751S-40T1G T 145.1/8.0
D602 1750002230 S.DIO LRB751S-40T1G T 146.3/8.0
D611 1750001810 S.DIO L1SS400T1G T 141.4/41.7
D651 1750002230 S.DIO LRB751S-40T1G T 156.9/14.1
D652 1750002230 S.DIO LRB751S-40T1G T 155.7/14.1
D661 1750001810 S.DIO L1SS400T1G T 141.4/50.9
D1121 1790001622 S.DIO 1SV308L3F T 89.8/7.2
D1122 1790001622 S.DIO 1SV308L3F T 89.6/12.0
D1123 1790001622 S.DIO 1SV308L3F T 89.6/10.8
D1124 1790001622 S.DIO 1SV308L3F T 87.6/11.2
D1161 1790002170 S.VAR LXES15AAA1-133 T 81.1/10.3
L101 6200009861 S.COI NLV25T-1R5J-PF T 29.1/26.6
L201 6200012990 S.COI 0.25-1.9-9TL 84.0N T 32.0/25.5
L202 6200010060 S.COI AS080647-56N T 46.1/28.1
L301 6110001360 COI LA-179
L302 6170000340 COI LW-33
L401 6200010780 S.COI C2520C-1R0G-A T 120.0/12.7
L402 6200010780 S.COI C2520C-1R0G-A T 115.0/7.8
L403 6200010780 S.COI C2520C-1R0G-A T 121.5/6.9
L501 6110001330 COI LA-176
L502 6110001360 COI LA-179
L503 6110001330 COI LA-176
L601 6200009861 S.COI NLV25T-1R5J-PF T 144.7/5.0
L651 6200009861 S.COI NLV25T-1R5J-PF T 154.1/17.2
L701 6200010780 S.COI C2520C-1R0G-A T 142.8/19.3
L1101 6200013680 S.COI 0.40-2.00-9TL 69N T 98.9/7.9
L1102 6200013680 S.COI 0.40-2.00-9TL 69N T 93.2/7.9
L1103 6200010680 S.COI C2520C-R22G-A (0.22U) T 106.5/12.4
L1121 6200003281 S.COI NLV25T-2R2J-PF T 89.6/14.7
L1122 6200003281 S.COI NLV25T-2R2J-PF T 86.6/15.3
L1151 6200012910 S.COI 0.35-1.6-8TL 45.5N T 86.1/8.3
L1152 6200012580 S.COI 0.35-1.6-5TL 23.8N T 82.1/7.9
L1161 6200013840 S.COI MLK1005S18NJT T 78.6/14.2
L1162 6200011860 S.COI LQW18ANR47G00D T 78.1/16.8
L1171 6200012700 S.COI 0.50-2.0-6TL 35.0N T 74.0/9.1
L1172 6200012700 S.COI 0.50-2.0-6TL 35.0N T 67.2/6.6
L1191 6200010910 S.COI LQW18AN56NG00D T 60.1/7.5
R6 7030015910 S.RES RMC1/16S-101JTH (100) T 11.5/20.3
R7 7030015910 S.RES RMC1/16S-101JTH (100) T 11.5/19.3
R8 7030015910 S.RES RMC1/16S-101JTH (100) T 11.5/18.3
R9 7030015910 S.RES RMC1/16S-101JTH (100) T 11.5/17.3
R10 7030015910 S.RES RMC1/16S-101JTH (100) T 11.5/16.3
R101 7030016370 S.RES RMC1/16S-271JTH (270) T 19.3/27.0
R102 7030016570 S.RES RMC1/16S-180JTH (18) T 19.3/25.5
R103 7030016370 S.RES RMC1/16S-271JTH (270) T 20.6/26.0
R105 7030016560 S.RES RMC1/16SJPTH T 28.6/23.6
R111 7030016050 S.RES RMC1/16S-102JTH (1 k) T 23.2/33.8
R112 7030016110 S.RES RMC1/16S-473JTH (47 k) T 24.1/32.9
R113 7030016110 S.RES RMC1/16S-473JTH (47 k) T 29.1/34.3
R201 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 34.1/23.5
R202 7030019460 S.RES RMC1/8-561JTP (560) T 38.9/23.5
R211 7030016560 S.RES RMC1/16SJPTH T 32.0/34.6
R212 7030016020 S.RES RMC1/16S-104JTH (100 k) T 32.9/34.6
R213 7030016020 S.RES RMC1/16S-104JTH (100 k) T 32.0/32.9
R214 7030016110 S.RES RMC1/16S-473JTH (47 k) T 32.9/32.9
R215 7030015910 S.RES RMC1/16S-101JTH (100) T 32.9/31.3
R216 7030016050 S.RES RMC1/16S-102JTH (1 k) T 35.5/25.8
R219 7030015910 S.RES RMC1/16S-101JTH (100) T 35.1/35.8
R301 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 57.3/23.7
R311 7030016330 S.RES RMC1/16S-153JTH (15 k) T 39.9/33.9
R312 7030016020 S.RES RMC1/16S-104JTH (100 k) T 39.0/33.9
R314 7030016560 S.RES RMC1/16SJPTH T 39.4/32.3
R315 7030015910 S.RES RMC1/16S-101JTH (100) T 40.7/31.8
R316 7030019390 S.RES RMC1/8-470JTP (47) T 55.7/35.8
R317 7030019460 S.RES RMC1/8-561JTP (560) T 56.9/40.7
R401 7030009891 S.RES ERA3YED 151V (150) T 120.1/9.7
R402 7030009891 S.RES ERA3YED 151V (150) T 121.3/9.7
R403 7030009661 S.RES ERA3YED 121V (120) T 118.0/7.6
R404 7030009661 S.RES ERA3YED 121V (120) T 118.0/6.4
R405 7030019090 S.RES RMC1/8-104JTP (100 k) T 115.6/20.7
R451 7510001551 S.THE NTCG16 4LH 333JT T 60.0/19.6
R452 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 58.7/20.4
R601 7030009781 S.RES ERA3YHD 680V (68) T 155.6/7.8
R602 7030007230 S.RES ERA3YED 102V (1 k) T 156.8/7.8
R611 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 143.2/41.3
R612 7030016020 S.RES RMC1/16S-104JTH (100 k) T 143.2/42.2
R613 7030016020 S.RES RMC1/16S-104JTH (100 k) T 143.0/40.4
R615 7030015970 S.RES RMC1/16S-103JTH (10 k) T 140.4/42.2
R616 7030016280 S.RES RMC1/16S-331JTH (330) T 140.4/43.8
R617 7030015970 S.RES RMC1/16S-103JTH (10 k) T 139.5/43.8
R651 7030009781 S.RES ERA3YHD 680V (68) T 146.4/14.1
R652 7030007230 S.RES ERA3YED 102V (1 k) T 145.2/14.1
R661 7030015980 S.RES RMC1/16S-333JTH (33 k) T 143.7/51.1
R662 7030016020 S.RES RMC1/16S-104JTH (100 k) T 143.7/50.2
R663 7030016020 S.RES RMC1/16S-104JTH (100 k) T 142.5/50.1
R665 7030015970 S.RES RMC1/16S-103JTH (10 k) T 140.3/50.5
R666 7030016280 S.RES RMC1/16S-331JTH (330) T 140.4/49.3
R667 7030015970 S.RES RMC1/16S-103JTH (10 k) T 139.2/49.7
R691 7030015910 S.RES RMC1/16S-101JTH (100) T 139.6/48.3
R701 7030010580 S.RES ERJ1TYJ 1R5U (1.5) T 127.4/62.1
R702 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 133.2/62.1
R703 7030016070 S.RES RMC1/16S-474JTH (470 k) T 134.1/61.2
R704 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 131.2/56.6
R705 7030016380 S.RES RMC1/16S-183JTH (18 k) T 136.1/56.8
R706 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 137.0/58.4
R1121 7030016460 S.RES RMC1/16S-181JTH (180) T 91.3/13.2
R1122 7030016520 S.RES RMC1/16S-270JTH (27) T 92.5/11.1
R1123 7030016470 S.RES RMC1/16S-390JTH (39) T 91.1/9.3
R1124 7030016520 S.RES RMC1/16S-270JTH (27) T 91.6/10.2
R1125 7030016160 S.RES RMC1/16S-820JTH (82) T 88.6/5.6
R1126 7030016460 S.RES RMC1/16S-181JTH (180) T 89.5/9.7
R1127 7030016460 S.RES RMC1/16S-181JTH (180) T 87.6/13.3
R1161 7030015970 S.RES RMC1/16S-103JTH (10 k) T 84.0/14.5
R1162 7030016330 S.RES RMC1/16S-153JTH (15 k) T 83.1/14.5
R1163 7030016390 S.RES RMC1/16S-184JTH (180 k) T 82.2/10.8
R1164 7030015940 S.RES RMC1/16S-681JTH (680) T 78.6/15.1
R1165 7030016560 S.RES RMC1/16SJPTH T 77.4/11.5
R1166 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 73.9/19.0
R1231 7030016110 S.RES RMC1/16S-473JTH (47 k) T 24.1/12.1
R1241 7030016110 S.RES RMC1/16S-473JTH (47 k) T 31.6/9.8
R1242 7030016110 S.RES RMC1/16S-473JTH (47 k) T 31.6/13.0
C1 4030023030 S.CER 0402B103K250CT T 9.3/26.7
C2 4030023030 S.CER 0402B103K250CT T 9.3/25.3
C3 4030023030 S.CER 0402B103K250CT T 9.3/23.8
C4 4030023090 S.CER 0402B102K500CT T 8.8/22.3
C5 4030023090 S.CER 0402B102K500CT T 8.8/21.3
C6 4030023030 S.CER 0402B103K250CT T 8.8/20.3
C7 4030023030 S.CER 0402B103K250CT T 8.8/19.3
C8 4030023030 S.CER 0402B103K250CT T 8.8/18.3
C9 4030023030 S.CER 0402B103K250CT T 8.8/17.3
C10 4030023030 S.CER 0402B103K250CT T 8.8/16.3
C11 4030023030 S.CER 0402B103K250CT T 8.8/15.3
C12 4030023030 S.CER 0402B103K250CT T 8.8/14.3
C13 4030023090 S.CER 0402B102K500CT T 8.8/13.3
C14 4030023090 S.CER 0402B102K500CT T 8.8/12.3
C101 4030023090 S.CER 0402B102K500CT T 21.9/25.5
C102 4030023090 S.CER 0402B102K500CT T 28.6/24.5
C112 4030022640 S.CER 0402N101J500CT T 28.6/28.7
C113 4030023090 S.CER 0402B102K500CT T 28.6/29.6
C114 4030023010 S.CER 0402B104K160CT T 28.6/30.5
C202 4030023090 S.CER 0402B102K500CT T 30.4/23.6
C204 4030023030 S.CER 0402B103K250CT T 35.9/24.6
C205 4030020750 S.CER GRM31A5C2J220JW01D T 42.5/27.1
C206 4030020820 S.CER GRM31A5C2J121JW01D T 44.0/22.3
C211 4030023030 S.CER 0402B103K250CT T 36.3/35.3
C212 4030022640 S.CER 0402N101J500CT T 35.5/26.7
C213 4030023090 S.CER 0402B102K500CT T 35.5/27.6
C214 4030023010 S.CER 0402B104K160CT T 35.5/28.5
C215 4030023030 S.CER 0402B103K250CT T 49.8/33.8
C216 4030023010 S.CER 0402B104K160CT T 43.9/33.2
C217 4030023090 S.CER 0402B102K500CT T 44.8/33.2
C218 4030022640 S.CER 0402N101J500CT T 45.7/33.2
C219 4030019560 S.CER GRM21BB31C106KE15L T 47.1/33.5
C301 4030021020 S.CER GRM31A5C2J101JW01D T 54.1/30.0
C302 4030020770 S.CER GRM31A5C2J330JW01D T 55.7/24.3
C303 4030021300 S.CER GQM22M5C2H330JB01L T 72.7/37.5
C305 4030021280 S.CER GQM22M5C2H180JB01L T 82.3/24.3
C306 4030022400 S.CER GQM22M5C2H8R0CB01L T 92.7/41.8
C307 4030021280 S.CER GQM22M5C2H180JB01L T 92.6/18.3
C308 4030025210 S.CER GQM22M5C2H101JB01L T 96.4/16.1
C309 4030021280 S.CER GQM22M5C2H180JB01L T 99.3/22.7
C310 4030025210 S.CER GQM22M5C2H101JB01L T 100.3/18.3
C311 4030020750 S.CER GRM31A5C2J220JW01D T 54.1/27.9
C312 4030022640 S.CER 0402N101J500CT T 53.7/39.5
C313 4030023090 S.CER 0402B102K500CT T 53.7/40.4
C314 4030023010 S.CER 0402B104K160CT T 55.2/41.6
C315 4510011410 S.ELE 25 CE 470 LX T 63.6/54.2
C316 4030023010 S.CER 0402B104K160CT T 71.9/55.7
C317 4030023090 S.CER 0402B102K500CT T 71.9/54.8
C318 4030022640 S.CER 0402N101J500CT T 71.9/53.9
C319 4510011410 S.ELE 25 CE 470 LX T 105.1/57.3
C320 4510011410 S.ELE 25 CE 470 LX T 90.9/50.0
C321 4030022640 S.CER 0402N101J500CT T 100.7/51.1
C322 4030023090 S.CER 0402B102K500CT T 101.6/51.1
C323 4030023010 S.CER 0402B104K160CT T 102.5/51.1
C401 4030023030 S.CER 0402B103K250CT T 120.9/14.8
C402 4030023030 S.CER 0402B103K250CT T 112.9/6.9
C403 4030023030 S.CER 0402B103K250CT T 118.8/9.0
C404 4030023010 S.CER 0402B104K160CT T 122.7/10.8
C405 4030023090 S.CER 0402B102K500CT T 122.7/9.9
C406 4030022640 S.CER 0402N101J500CT T 122.7/9.0

Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-15a
(Amended page)
June 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[PA-A UNIT]
C407 4030023030 S.CER 0402B103K250CT T 118.8/5.0
C408 4030021230 S.CER GRM31B5C2J102JW01L T 114.4/24.4
C451 4030023030 S.CER 0402B103K250CT T 59.2/17.6
C452 4030023030 S.CER 0402B103K250CT T 58.7/19.5
C501 4030025480 S.CER GQM22M5C2H9R0CB01L T 118.4/27.4
C502 4030024640 S.CER GRM31A5C2J2R0CW01D T 125.2/27.5
C504 4030021000 S.CER GRM31A5C2J100JW01D T 104.8/29.7
C505 4030021200 S.CER GRM31A5C2J120JW01D T 123.4/39.1
C506 4030021210 S.CER GRM31A5C2J150JW01D T 121.8/37.5
C507 4030024640 S.CER GRM31A5C2J2R0CW01D T 125.6/13.4
C508 4030020740 S.CER GRM31A5C2J180JW01D T 129.5/19.4
C509 4030024670 S.CER GRM31A5C2J9R0DW01D T 142.1/14.3
C601 4030023090 S.CER 0402B102K500CT T 146.5/5.9
C602 4030023090 S.CER 0402B102K500CT T 142.9/4.9
C612 4030023090 S.CER 0402B102K500CT T 138.6/43.8
C651 4030023090 S.CER 0402B102K500CT T 154.7/15.2
C652 4030023090 S.CER 0402B102K500CT T 153.9/19.4
C661 4030023090 S.CER 0402B102K500CT T 143.7/49.3
C662 4030023090 S.CER 0402B102K500CT T 138.3/50.3
C691 4030023030 S.CER 0402B103K250CT T 140.0/47.1
C701 4030023090 S.CER 0402B102K500CT T 121.9/60.5
C702 4030023090 S.CER 0402B102K500CT T 133.3/54.7
C703 4030023090 S.CER 0402B102K500CT T 130.3/56.6
C704 4030023090 S.CER 0402B102K500CT T 136.1/58.4
C705 4030023090 S.CER 0402B102K500CT T 142.8/23.7
C706 4030023010 S.CER 0402B104K160CT T 143.7/23.7
C1101 4030022880 S.CER 0402N560J500CT T 99.5/12.0
C1102 4030022670 S.CER 0402N121J500CT T 98.3/11.6
C1103 4030022700 S.CER 0402N180J500CT T 96.0/12.0
C1104 4030023140 S.CER 0402B271K500CT T 93.7/11.6
C1105 4030022810 S.CER 0402N330J500CT T 92.5/12.0
C1121 4030023030 S.CER 0402B103K250CT T 91.9/14.8
C1122 4030023030 S.CER 0402B103K250CT T 91.3/11.6
C1123 4030023030 S.CER 0402B103K250CT T 90.2/5.6
C1124 4030023030 S.CER 0402B103K250CT T 87.9/9.5
C1151 4030022860 S.CER 0402N470J500CT T 86.1/12.0
C1152 4030022580 S.CER 0402N7R0C500CT T 84.9/11.6
C1153 4030022580 S.CER 0402N7R0C500CT T 84.0/11.6
C1154 4030022750 S.CER 0402N221J500CT T 83.1/10.8
C1155 4030022900 S.CER 0402N680J500CT T 82.6/12.0
C1161 4030023030 S.CER 0402B103K250CT T 82.2/14.5
C1162 4030023030 S.CER 0402B103K250CT T 78.6/12.0
C1163 4030023030 S.CER 0402B103K250CT T 78.6/18.5
C1164 4030022490 S.CER GRM155B31C105MA12D T 74.3/14.0
C1165 4030022490 S.CER GRM155B31C105MA12D T 74.8/19.0
C1171 4030022570 S.CER 0402N6R0C500CT T 76.3/6.8
C1172 4030022840 S.CER 0402N390J500CT T 75.7/6.1
C1173 4030022860 S.CER 0402N470J500CT T 76.0/11.1
C1174 4030022770 S.CER 0402N270J500CT T 76.9/10.2
C1175 4030022770 S.CER 0402N270J500CT T 74.0/5.8
C1176 4030022770 S.CER 0402N270J500CT T 71.7/6.7
C1177 4030022860 S.CER 0402N470J500CT T 71.1/7.3
C1178 4030022840 S.CER 0402N390J500CT T 69.5/8.9
C1179 4030022570 S.CER 0402N6R0C500CT T 70.1/8.3
C1191 4030022700 S.CER 0402N180J500CT T 61.8/7.1
C1192 4030022700 S.CER 0402N180J500CT T 58.4/7.1
RL401 6310000170 S.REL EE2-3NUH-L T 110.2/17.5
J1 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 5.0/20.0
J101 6510032350 S.CON 20279-001E-01 T 18.8/31.1
J1201 6510032350 S.CON 20279-001E-01 T 55.8/7.5
EP1 6910024660 S.BEA MPZ2012S102AT T 12.9/27.2
EP2 6910024660 S.BEA MPZ2012S102AT T 12.9/25.4
EP3 6910024660 S.BEA MPZ2012S102AT T 12.9/23.7
EP4 6910018460 S.BEA MMZ1005Y102C-T T 11.5/22.3
EP5 6910018460 S.BEA MMZ1005Y102C-T T 11.5/21.3
EP11 6910018460 S.BEA MMZ1005Y102C-T T 11.5/15.3
EP12 6910018460 S.BEA MMZ1005Y102C-T T 11.5/14.3
EP13 6910018460 S.BEA MMZ1005Y102C-T T 11.5/13.3
EP14 6910018460 S.BEA MMZ1005Y102C-T T 11.5/12.3
EP101 6910019900 S.BEA MPZ1608S601AT T 29.1/32.2
EP211 6910018460 S.BEA MMZ1005Y102C-T T 35.0/29.7
EP215 6910024660 S.BEA MPZ2012S102AT T 49.5/32.4
EP301 6910020710 E.O OT-047 M3
EP302 6910020710 E.O OT-047 M3
EP311 6910018460 S.BEA MMZ1005Y102C-T T 53.7/38.6
EP701 6910024660 S.BEA MPZ2012S102AT T 121.3/62.1
EP702 6910024660 S.BEA MPZ2012S102AT T 136.1/52.0
EP1161 6910019900 S.BEA MPZ1608S601AT T 76.5/18.5

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-16a
(Amended page)
June 2019
[PA-B UNIT] [PA-B UNIT]
IC51 1110007950 S.IC INA199A2DCKR T 77.7/7.3
IC101 1110009820 S.IC MMG3H21NT1 T 32.5/48.0
IC211 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 76.0/49.2
IC691 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 125.3/59.5
IC1161 1110009890 S.IC NJG1152KA1-TE1 T 102.3/59.1
IC1162 1180004760 S.REG S-1200B33-M5T1U T 103.7/55.5
Q31 1590005140 S.FET TJ50S06M3L T 20.0/31.8
Q32 1590004060 S.TRA LDTC114EET1G T 27.3/30.5
Q111 1550000500 S.FET RZF020P01TL T 35.6/52.0
Q112 1590004060 S.TRA LDTC114EET1G T 37.2/55.9
Q201 1560002490 S.FET PD85004-HF T 49.3/48.0
Q301 1560002470 S.FET AFT05MP075NR1 T 98.2/31.6
Q401 1590004060 S.TRA LDTC114EET1G T 18.3/54.9
Q402 1590000440 S.TRA DTA143ZUA T106 T 20.6/54.6
Q403 1560002230 S.FET FK3503010L T 107.8/49.2
Q701 1520000651 S.TRA 2SB1201S-TL-E T 48.5/56.7
Q702 1510001200 S.TRA L2SA1576ART1G T 43.5/61.3
Q703 1590004060 S.TRA LDTC114EET1G T 48.9/61.3
Q1181 1530004100 S.TRA MT3S20P (TE12LF) T 88.6/57.8
Q1221 1590004060 S.TRA LDTC114EET1G T 18.3/57.9
Q1222 1590004310 S.TRA LDTA114EET1G T 20.4/57.9
Q1231 1590004060 S.TRA LDTC114EET1G T 22.7/57.9
Q1232 1590000440 S.TRA DTA143ZUA T106 T 25.0/57.6
Q1241 1590004060 S.TRA LDTC114EET1G T 27.3/57.9
Q1242 1590004310 S.TRA LDTA114EET1G T 29.4/57.9
Q1243 1560002230 S.FET FK3503010L T 31.7/57.6
Q1244 1590004310 S.TRA LDTA114EET1G T 34.0/57.9
D21 1750002000 S.ZEN DZ2J180M0L T 79.3/18.2
D22 1710000831 S.DIO DF30SC4M-7072 T 61.4/28.5
D23 1750003510 S.ZEN TPSMD15A T 31.5/35.8
D311 1750001810 S.DIO L1SS400T1G T 76.9/43.7
D401 1710001061 DIO L407CDB
D402 1710001061 DIO L407CDB
D403 1710001061 DIO L407CDB
D404 1710001061 DIO L407CDB
D405 1750002310 S.DIO L8104R T 128.3/49.9
D406 1750002310 S.DIO L8104R T 125.6/49.9
D407 1750003890 S.DIO L9204FR T 114.3/48.5
D601 1750002230 S.DIO LRB751S-40T1G T 148.8/52.2
D611 1750001810 S.DIO L1SS400T1G T 125.0/55.6
D651 1750002230 S.DIO LRB751S-40T1G T 153.2/58.9
D661 1750001810 S.DIO L1SS400T1G T 125.0/63.8
D1121 1790001622 S.DIO 1SV308L3F T 111.4/60.7
D1122 1790001622 S.DIO 1SV308L3F T 112.9/56.2
D1123 1790001622 S.DIO 1SV308L3F T 111.2/58.2
D1124 1790001622 S.DIO 1SV308L3F T 110.4/56.2
D1161 1790002170 S.VAR LXES15AAA1-133 T 103.9/58.7
FI1191 2040002390 S.SAW TA1808A (440 MHz) T 81.6/57.5
L101 6200011670 S.COI LQW18AN82NG00D T 36.5/48.8
L102 6200015120 S.COI LQW15AN18NJ00D T 35.6/44.2
L103 6200015120 S.COI LQW15AN18NJ00D T 36.6/44.2
L202 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) T 40.0/45.7
L221 6200012980 S.COI 0.40-1.4-5TR 18.3N T 57.1/41.8
L321 6110003980 COI LA-604
L401 6110001780 COI LA-267
L402 6110000410 COI LA-69
L403 6200010150 S.COI AS080340-15N T 121.2/50.4
L404 6200013000 S.COI 0.25-1.9-13TL 135N T 125.6/45.1
L405 6200013000 S.COI 0.25-1.9-13TL 135N T 111.2/48.7
L501 6110000410 COI LA-69
L502 6110000410 COI LA-69
L601 6200002651 S.COI NLV25T-R18J-PF T 149.8/49.2
L651 6200002651 S.COI NLV25T-R18J-PF T 152.3/62.0
L701 6200010780 S.COI C2520C-1R0G-A T 134.9/55.2
L1101 6200012800 S.COI 0.40-1.5-5TL 20N T 119.1/56.9
L1102 6200013070 S.COI 0.40-1.1-6TR 15.6N T 114.8/59.9
L1121 6200015410 S.COI MLK1005SR33JT T 114.2/55.2
L1122 6200015410 S.COI MLK1005SR33JT T 109.4/57.4
L1151 6200014450 S.COI 0.40-1.4-2TL 5.3J T 105.2/60.5
L1161 6200013840 S.COI MLK1005S18NJT T 100.2/61.0
L1162 6200011860 S.COI LQW18ANR47G00D T 98.3/56.7
L1171 6200011770 S.COI LQW18ANR10G00D T 98.1/60.5
L1172 6200011770 S.COI LQW18ANR10G00D T 93.5/60.0
L1181 6200014760 S.COI MLK1005SR22JT T 85.3/59.5
L1191 6200011800 S.COI C2520C-47NG-A T 70.7/53.4
R6 7030015910 S.RES RMC1/16S-101JTH (100) T 12.1/46.5
R7 7030015910 S.RES RMC1/16S-101JTH (100) T 12.1/45.5
R8 7030015910 S.RES RMC1/16S-101JTH (100) T 12.1/44.5
R9 7030015910 S.RES RMC1/16S-101JTH (100) T 12.1/43.5
R10 7030015910 S.RES RMC1/16S-101JTH (100) T 12.1/42.5
R16 7030015910 S.RES RMC1/16S-101JTH (100) T 12.1/36.5
R31 7030016020 S.RES RMC1/16S-104JTH (100 k) T 24.7/31.8
R32 7030015970 S.RES RMC1/16S-103JTH (10 k) T 25.7/31.8
R51 7030015910 S.RES RMC1/16S-101JTH (100) T 75.7/8.2
R52 7030013710 S.RES PMR50HZPFV2L00 T 77.8/4.3
R53 7030007230 S.RES ERA3YED 102V (1 k) T 80.2/6.4
R54 7030009591 S.RES ERA3YED 472V (4.7 k) T 80.2/7.6
R55 7030016090 S.RES RMC1/16S-223JTH (22 k) T 80.5/11.6
R56 7030015910 S.RES RMC1/16S-101JTH (100) T 79.4/9.9
R101 7030016480 S.RES RMC1/16S-821JTH (820) T 28.9/51.0
R102 7030016650 S.RES RMC1/16S-5R6JTH (5.6) T 28.5/49.6
R103 7030016480 S.RES RMC1/16S-821JTH (820) T 29.5/49.6
R111 7030016050 S.RES RMC1/16S-102JTH (1 k) T 37.1/54.1
R112 7030016110 S.RES RMC1/16S-473JTH (47 k) T 35.3/54.1
R113 7030016110 S.RES RMC1/16S-473JTH (47 k) T 39.4/51.5
R202 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 42.1/49.3
R203 7030016560 S.RES RMC1/16SJPTH T 42.1/51.1
R204 7030015520 S.RES RMC1/16JPTP T 37.9/46.4
R211 7030015970 S.RES RMC1/16S-103JTH (10 k) T 73.5/51.3
R212 7030016020 S.RES RMC1/16S-104JTH (100 k) T 72.3/50.8
R213 7030016020 S.RES RMC1/16S-104JTH (100 k) T 71.7/49.3
R214 7030016220 S.RES RMC1/16S-563JTH (56 k) T 72.7/49.3
R215 7030015910 S.RES RMC1/16S-101JTH (100) T 42.8/54.4
R216 7030016050 S.RES RMC1/16S-102JTH (1 k) T 43.1/49.3
R219 7030015910 S.RES RMC1/16S-101JTH (100) T 72.7/47.5
R301 7030016120 S.RES RMC1/16S-682JTH (6.8 k) T 89.3/37.9
R302 7030016120 S.RES RMC1/16S-682JTH (6.8 k) T 89.3/25.3
R303 7030010250 S.RES ERJ1TY 0R00U (JPW) T 86.9/31.6
R311 7030016330 S.RES RMC1/16S-153JTH (15 k) T 80.2/50.2
R312 7030016020 S.RES RMC1/16S-104JTH (100 k) T 79.2/50.2
R314 7030016560 S.RES RMC1/16SJPTH T 79.2/48.4
R315 7030015910 S.RES RMC1/16S-101JTH (100) T 79.0/47.0
R316 7030019390 S.RES RMC1/8-470JTP (47) T 73.2/40.4
R317 7030019410 S.RES RMC1/8-471JTP (470) T 76.8/42.0
R401 7030015970 S.RES RMC1/16S-103JTH (10 k) T 138.8/7.9
R402 7030010480 S.RES ERJ1TYJ 181U (180) T 142.4/11.2
R403 7030016020 S.RES RMC1/16S-104JTH (100 k) T 123.9/52.7
R404 7030016110 S.RES RMC1/16S-473JTH (47 k) T 111.9/51.8
R451 7510001551 S.THE NTCG16 4LH 333JT T 92.0/42.2
R452 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 90.5/44.3
R601 7030009691 S.RES ERA3YED 101V (100) T 153.1/52.1
R602 7030009691 S.RES ERA3YED 101V (100) T 154.3/52.1
R611 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 128.0/57.5
R612 7030016020 S.RES RMC1/16S-104JTH (100 k) T 127.0/55.7
R613 7030016020 S.RES RMC1/16S-104JTH (100 k) T 126.0/55.7
R615 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 123.9/55.8
R616 7030016280 S.RES RMC1/16S-331JTH (330) T 122.7/57.3
R617 7030015970 S.RES RMC1/16S-103JTH (10 k) T 122.7/55.3
R651 7030009691 S.RES ERA3YED 101V (100) T 148.9/58.9
R652 7030009691 S.RES ERA3YED 101V (100) T 147.7/58.9
R661 7030015970 S.RES RMC1/16S-103JTH (10 k) T 127.6/61.7
R662 7030016020 S.RES RMC1/16S-104JTH (100 k) T 127.6/63.5
R663 7030016020 S.RES RMC1/16S-104JTH (100 k) T 126.0/63.1
R665 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 123.9/63.1
R666 7030016280 S.RES RMC1/16S-331JTH (330) T 122.7/60.9
R667 7030015970 S.RES RMC1/16S-103JTH (10 k) T 122.7/62.9
R691 7030015910 S.RES RMC1/16S-101JTH (100) T 122.1/59.5
R701 7030010580 S.RES ERJ1TYJ 1R5U (1.5) T 40.1/58.4
R702 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 42.5/56.7
R703 7030016070 S.RES RMC1/16S-474JTH (470 k) T 45.5/62.6
R704 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 46.0/61.3
R705 7030016380 S.RES RMC1/16S-183JTH (18 k) T 130.0/59.7
R706 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 131.6/60.8
R1101 7030016560 S.RES RMC1/16SJPTH T 117.7/55.0
R1121 7030016460 S.RES RMC1/16S-181JTH (180) T 113.2/54.3
R1122 7030016520 S.RES RMC1/16S-270JTH (27) T 113.1/58.6
R1123 7030016470 S.RES RMC1/16S-390JTH (39) T 113.1/60.2
R1124 7030016520 S.RES RMC1/16S-270JTH (27) T 112.2/59.3
R1125 7030016160 S.RES RMC1/16S-820JTH (82) T 109.8/62.0
R1126 7030016460 S.RES RMC1/16S-181JTH (180) T 107.4/56.2
R1127 7030016460 S.RES RMC1/16S-181JTH (180) T 107.7/58.3
R1161 7030015970 S.RES RMC1/16S-103JTH (10 k) T 102.4/62.6
R1162 7030016330 S.RES RMC1/16S-153JTH (15 k) T 102.4/61.7
R1163 7030016390 S.RES RMC1/16S-184JTH (180 k) T 104.8/58.7
R1164 7030015940 S.RES RMC1/16S-681JTH (680) T 100.2/60.0
R1165 7030016560 S.RES RMC1/16SJPTH T 99.0/59.2
R1166 7030016300 S.RES RMC1/16S-332JTH (3.3 k) T 100.3/56.2
R1181 7030016560 S.RES RMC1/16SJPTH T 93.5/57.9
R1182 7030015950 S.RES RMC1/16S-152JTH (1.5 k) T 92.5/57.3
R1183 7030016460 S.RES RMC1/16S-181JTH (180) T 91.6/55.7
R1184 7030015930 S.RES RMC1/16S-471JTH (470) T 91.6/58.9
R1185 7030016250 S.RES RMC1/16S-220JTH (22) T 85.6/60.4
R1186 7030016590 S.RES RMC1/16S-120JTH (12) T 86.1/61.8
R1187 7030016520 S.RES RMC1/16S-270JTH (27) T 82.8/60.8
R1188 7030016560 S.RES RMC1/16SJPTH T 84.5/57.7
R1221 7030016110 S.RES RMC1/16S-473JTH (47 k) T 20.4/59.8
R1241 7030016110 S.RES RMC1/16S-473JTH (47 k) T 29.4/59.8
R1242 7030016110 S.RES RMC1/16S-473JTH (47 k) T 34.0/59.8
C2 4030023030 S.CER 0402B103K250CT T 9.3/51.5
C3 4030023030 S.CER 0402B103K250CT T 9.3/50.5
C4 4030023090 S.CER 0402B102K500CT T 9.3/48.5
C5 4030023090 S.CER 0402B102K500CT T 9.3/47.5
C6 4030023030 S.CER 0402B103K250CT T 9.3/46.5
C7 4030023030 S.CER 0402B103K250CT T 9.3/45.5
C8 4030023030 S.CER 0402B103K250CT T 9.3/44.5
C9 4030023030 S.CER 0402B103K250CT T 9.3/43.5
C10 4030023030 S.CER 0402B103K250CT T 9.3/42.5
C11 4030023030 S.CER 0402B103K250CT T 9.3/41.5
C12 4030023030 S.CER 0402B103K250CT T 9.3/40.5
C13 4030023090 S.CER 0402B102K500CT T 9.3/39.5
C14 4030023090 S.CER 0402B102K500CT T 9.3/38.5
C15 4030023090 S.CER 0402B102K500CT T 9.3/37.5
C16 4030023090 S.CER 0402B102K500CT T 9.3/36.5
C21 4030023090 S.CER 0402B102K500CT T 77.8/12.0
C22 4030023030 S.CER 0402B103K250CT T 70.9/3.1
C23 4510011410 S.ELE 25 CE 470 LX T 65.9/7.6
C24 4030023010 S.CER 0402B104K160CT T 71.9/3.1
C25 4030023030 S.CER 0402B103K250CT T 72.9/3.1
C26 4030023090 S.CER 0402B102K500CT T 77.8/11.1
C27 4030022860 S.CER 0402N470J500CT T 72.0/12.4
C28 4030022750 S.CER 0402N221J500CT T 72.0/11.5

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-17a
(Amended page)
June 2019
[PA-B UNIT] [PA-B UNIT]
C1153 4030022560 S.CER 0402N5R0B500CT T 107.0/60.6
C1154 4030022590 S.CER 0402N8R0C500CT T 106.0/58.7
C1155 4030022560 S.CER 0402N5R0B500CT T 107.9/60.6
C1161 4030023030 S.CER 0402B103K250CT T 102.4/60.7
C1162 4030023030 S.CER 0402B103K250CT T 100.2/58.3
C1163 4030023030 S.CER 0402B103K250CT T 99.4/56.2
C1164 4030019120 S.CER GRM188B31E105KA75D T 102.9/53.0
C1165 4030019120 S.CER GRM188B31E105KA75D T 101.3/55.9
C1171 4030024550 S.CER 0402N3R5B500CT T 97.3/58.6
C1172 4030024550 S.CER 0402N3R5B500CT T 96.9/57.4
C1173 4030024550 S.CER 0402N3R5B500CT T 96.4/60.2
C1175 4030024550 S.CER 0402N3R5B500CT T 94.6/58.6
C1176 4030024550 S.CER 0402N3R5B500CT T 95.0/57.4
C1177 4030024550 S.CER 0402N3R5B500CT T 96.4/58.6
C1178 4030024550 S.CER 0402N3R5B500CT T 95.5/58.6
C1181 4030023090 S.CER 0402B102K500CT T 91.6/57.3
C1182 4030022630 S.CER 0402N100C500CT T 85.2/61.8
C1183 4030022660 S.CER 0402N120J500CT T 85.3/58.6
C1184 4030023090 S.CER 0402B102K500CT T 83.7/60.8
C1185 4030023010 S.CER 0402B104K160CT T 83.2/62.0
C1188 4030022550 S.CER 0402N4R0B500CT T 92.5/58.9
C1191 4030022630 S.CER 0402N100C500CT T 71.6/57.5
C1192 4030022630 S.CER 0402N100C500CT T 69.8/57.5
C1193 4030024490 S.CER 0402NR75B500CT T 70.3/56.3
C1194 4030022540 S.CER 0402N3R0B500CT T 71.2/56.3
J1 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 5.0/46.3
J41 6510022311 S.CON B5B-PH-SM4-TB (LF) (SN) T 22.0/43.3
J61 6510018921 S.CON B8B-PH-SM4-TB (LF) (SN) T 87.5/10.8
J101 6510032350 S.CON 20279-001E-01 T 28.5/53.7
J1201 6510032350 S.CON 20279-001E-01 T 66.4/57.5
F21 5220000400 HOL FHA010-01F
F22 5210000940 FUS 1205
EP2 6910024660 S.BEA MPZ2012S102AT T 13.0/51.9
EP3 6910024660 S.BEA MPZ2012S102AT T 13.0/50.1
EP4 6910018460 S.BEA MMZ1005Y102C-T T 12.1/48.5
EP5 6910018460 S.BEA MMZ1005Y102C-T T 12.1/47.5
EP11 6910018460 S.BEA MMZ1005Y102C-T T 12.1/41.5
EP12 6910018460 S.BEA MMZ1005Y102C-T T 12.1/40.5
EP13 6910018460 S.BEA MMZ1005Y102C-T T 12.1/39.5
EP14 6910018460 S.BEA MMZ1005Y102C-T T 12.1/38.5
EP15 6910018460 S.BEA MMZ1005Y102C-T T 12.1/37.5
EP21 6910020710 E.O OT-047 M3
EP22 6910020710 E.O OT-047 M3
EP41 6910024660 S.BEA MPZ2012S102AT T 21.6/36.7
EP42 6910024660 S.BEA MPZ2012S102AT T 18.1/36.7
EP62 6910020710 E.O OT-047 M3
EP63 6910020710 E.O OT-047 M3
EP101 6910018460 S.BEA MMZ1005Y102C-T T 37.4/50.3
EP211 6910018460 S.BEA MMZ1005Y102C-T T 42.8/53.4
EP221 6910024660 S.BEA MPZ2012S102AT T 60.3/40.5
EP311 6910018460 S.BEA MMZ1005Y102C-T T 80.8/47.0
EP651 6910012350 S.BEA MMZ1608Y 102BT T 127.7/59.9
EP701 6910024660 S.BEA MPZ2012S102AT T 37.4/60.8
EP702 6910014730 S.BEA MPZ2012S331A-T T 130.6/57.6
EP703 6910014730 S.BEA MPZ2012S331A-T T 131.2/54.6
EP1161 6910019900 S.BEA MPZ1608S601AT T 99.5/54.8
C31 4030023090 S.CER 0402B102K500CT T 27.4/28.8
C41 4030023030 S.CER 0402B103K250CT T 23.8/36.7
C42 4030023030 S.CER 0402B103K250CT T 15.8/36.7
C51 4030023010 S.CER 0402B104K160CT T 77.3/9.3
C52 4030023010 S.CER 0402B104K160CT T 80.6/8.7
C53 4030022640 S.CER 0402N101J500CT T 80.6/9.6
C54 4030023010 S.CER 0402B104K160CT T 78.5/9.9
C61 4030023010 S.CER 0402B104K160CT T 91.7/14.1
C62 4030023090 S.CER 0402B102K500CT T 92.6/14.1
C63 4030023010 S.CER 0402B104K160CT T 120.5/12.8
C64 4030023090 S.CER 0402B102K500CT T 120.5/13.8
C65 4030023010 S.CER 0402B104K160CT T 80.2/12.8
C66 4030023090 S.CER 0402B102K500CT T 81.1/12.9
C67 4030022860 S.CER 0402N470J500CT T 82.0/13.1
C68 4030022860 S.CER 0402N470J500CT T 90.8/14.1
C101 4030022870 S.CER 0402N471J500CT T 29.5/47.3
C102 4030022580 S.CER 0402N7R0C500CT T 35.8/47.3
C103 4030024550 S.CER 0402N3R5B500CT T 36.4/45.8
C112 4030023090 S.CER 0402B102K500CT T 37.2/57.6
C113 4030023090 S.CER 0402B102K500CT T 38.4/51.5
C114 4030023010 S.CER 0402B104K160CT T 40.2/49.0
C115 4030022870 S.CER 0402N471J500CT T 39.3/49.0
C116 4030023090 S.CER 0402B102K500CT T 38.4/49.0
C201 4030022530 S.CER 0402N2R0B500CT T 36.8/47.3
C203 4030022600 S.CER 0402N9R0C500CT T 38.6/44.2
C211 4030023090 S.CER 0402B102K500CT T 71.7/47.5
C212 4030022870 S.CER 0402N471J500CT T 43.5/50.5
C213 4030023090 S.CER 0402B102K500CT T 43.5/51.4
C214 4030023010 S.CER 0402B104K160CT T 43.5/52.3
C221 4030024650 S.CER GRM31A5C2J7R0DW01D T 51.6/41.7
C222 4030020770 S.CER GRM31A5C2J330JW01D T 63.8/46.9
C227 4030022870 S.CER 0402N471J500CT T 56.2/39.1
C228 4030023010 S.CER 0402B104K160CT T 57.2/39.1
C229 4030023090 S.CER 0402B102K500CT T 58.2/39.1
C230 4030019560 S.CER GRM21BB31C106KE15L T 54.2/39.5
C301 4030020790 S.CER GRM31A5C2J560JW01D T 69.5/38.9
C302 4030020770 S.CER GRM31A5C2J330JW01D T 72.6/35.2
C303 4030020740 S.CER GRM31A5C2J180JW01D T 75.4/30.0
C305 4030020780 S.CER GRM31A5C2J470JW01D T 84.9/38.3
C307 4030020780 S.CER GRM31A5C2J470JW01D T 84.9/24.9
C313 4030022870 S.CER 0402N471J500CT T 78.8/40.4
C314 4030023090 S.CER 0402B102K500CT T 80.1/41.4
C315 4030023010 S.CER 0402B104K160CT T 80.1/42.6
C321 4030025200 S.CER GQM22M5C2H150JB01L T 107.0/43.5
C322 4030025200 S.CER GQM22M5C2H150JB01L T 113.1/43.5
C324 4030025200 S.CER GQM22M5C2H150JB01L T 107.0/19.8
C325 4030025200 S.CER GQM22M5C2H150JB01L T 113.1/19.8
C328 4030025480 S.CER GQM22M5C2H9R0CB01L T 133.5/33.9
C330 4030025210 S.CER GQM22M5C2H101JB01L T 138.3/25.8
C331 4030022750 S.CER 0402N221J500CT T 122.8/14.1
C332 4030023030 S.CER 0402B103K250CT T 123.7/14.1
C333 4030023010 S.CER 0402B104K160CT T 124.6/14.1
C334 4510011410 S.ELE 25 CE 470 LX T 130.7/20.3
C401 4030023030 S.CER 0402B103K250CT T 138.9/8.9
C402 4030023030 S.CER 0402B103K250CT T 146.2/8.9
C403 4030021200 S.CER GRM31A5C2J120JW01D T 131.2/49.8
C404 4030022560 S.CER 0402N5R0B500CT T 117.3/48.5
C405 4030025210 S.CER GQM22M5C2H101JB01L T 128.7/45.0
C406 4030022870 S.CER 0402N471J500CT T 116.4/46.8
C407 4030023090 S.CER 0402B102K500CT T 109.2/50.9
C408 4030023090 S.CER 0402B102K500CT T 106.0/49.4
C409 4030023090 S.CER 0402B102K500CT T 127.2/42.2
C411 4030022380 S.CER GQM22M5C2H3R0BB01L T 145.3/35.6
C412 4030025210 S.CER GQM22M5C2H101JB01L T 137.8/38.5
C451 4030023090 S.CER 0402B102K500CT T 90.5/41.3
C452 4030022870 S.CER 0402N471J500CT T 90.5/42.3
C453 4030023030 S.CER 0402B103K250CT T 90.5/43.3
C501 4030024460 S.CER GQM22M5C2H1R5BB01L T 137.8/43.6
C502 4030024580 S.CER GRM31A5C2J1R0CW01D T 142.3/48.5
C503 4030021430 S.CER GQM22M5C2H4R0CB01L T 144.6/39.1
C504 4030024580 S.CER GRM31A5C2J1R0CW01D T 142.6/54.7
C505 4030025450 S.CER GQM22M5C2H7R0CB01L T 145.9/47.5
C506 4030024580 S.CER GRM31A5C2J1R0CW01D T 145.5/51.8
C507 4030024580 S.CER GRM31A5C2J1R0CW01D T 156.1/54.1
C508 4030024580 S.CER GRM31A5C2J1R0CW01D T 154.5/49.9
C603 4030023090 S.CER 0402B102K500CT T 150.4/51.4
C604 4030022750 S.CER 0402N221J500CT T 151.8/48.5
C612 4030023090 S.CER 0402B102K500CT T 122.7/56.3
C653 4030023090 S.CER 0402B102K500CT T 154.5/59.7
C654 4030022750 S.CER 0402N221J500CT T 151.7/60.1
C661 4030023090 S.CER 0402B102K500CT T 127.6/62.6
C662 4030023090 S.CER 0402B102K500CT T 122.7/61.9
C691 4030023090 S.CER 0402B102K500CT T 123.1/59.5
C701 4030023090 S.CER 0402B102K500CT T 35.6/62.1
C702 4030023090 S.CER 0402B102K500CT T 47.4/61.7
C703 4030023090 S.CER 0402B102K500CT T 43.5/56.7
C704 4030023090 S.CER 0402B102K500CT T 131.6/59.8
C705 4030023030 S.CER 0402B103K250CT T 132.4/57.9
C706 4030022750 S.CER 0402N221J500CT T 132.4/57.0
C707 4030023030 S.CER 0402B103K250CT T 132.4/56.1
C1101 4030022870 S.CER 0402N471J500CT T 116.5/54.9
C1103 4030022570 S.CER 0402N6R0C500CT T 116.5/56.5
C1104 4030022810 S.CER 0402N330J500CT T 116.5/58.1
C1105 4030022600 S.CER 0402N9R0C500CT T 115.3/57.4
C1121 4030022870 S.CER 0402N471J500CT T 114.8/54.3
C1122 4030023030 S.CER 0402B103K250CT T 112.0/53.8
C1123 4030022870 S.CER 0402N471J500CT T 113.7/57.4
C1124 4030022870 S.CER 0402N471J500CT T 110.7/62.0
C1125 4030022870 S.CER 0402N471J500CT T 108.7/55.8
C1126 4030022870 S.CER 0402N471J500CT T 107.7/57.4
C1151 4030022560 S.CER 0402N5R0B500CT T 109.1/58.7
C1152 4030022560 S.CER 0402N5R0B500CT T 108.8/60.6

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-18a
(Amended page)
June 2019
[PA-C UNIT] [PA-C UNIT]
IC20 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 153.5/37.8
IC51 1180003210 S.REG NJM2831F10-TE1-#ZZZB T 113.1/41.2
IC131 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 84.6/14.7
IC141 1110009820 S.IC MMG3H21NT1 T 72.0/12.3
IC191 1110007400 S.IC BGA616 T 59.0/17.5
IC231 1190003920 S.IC ADL5350ACPZ-R7 T 37.8/11.0
IC271 1130019350 S.IC LMX2581SQ/NOPB T 41.1/29.8
IC301 1180004660 S.REG NJM2881F33-TE1-#ZZZB T 23.2/26.0
IC321 1110010150 S.IC TQP3M9037 T 100.8/51.0
IC331 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 89.1/50.8
IC332 1110009550 S.IC NJG1801K75-TE1-#ZZZM T 82.2/50.8
IC361 1110009740 S.IC AK1228-L T 48.7/47.1
IC421 1110007400 S.IC BGA616 T 25.6/43.8
Q1 1510001200 S.TRA L2SA1576ART1G T 151.8/16.1
Q2 1520000651 S.TRA 2SB1201S-TL-E T 154.0/22.5
Q3 1590004690 S.TRA LDTC143ZET1G T 150.1/10.6
Q51 1590004690 S.TRA LDTC143ZET1G T 114.1/46.1
Q52 1590004040 S.TRA LDTA123YET1G T 114.8/44.0
Q81 1560002480 S.FET AFT09MS031NR1 T 100.8/24.6
Q101 1560002490 S.FET PD85004-HF T 71.1/24.3
Q195 1550000500 S.FET RZF020P01TL T 61.6/6.5
Q196 1590004690 S.TRA LDTC143ZET1G T 64.9/5.1
Q321 1550000500 S.FET RZF020P01TL T 96.9/56.1
Q322 1590004690 S.TRA LDTC143ZET1G T 96.3/58.5
Q326 1590004310 S.TRA LDTA114EET1G T 106.1/57.4
Q327 1590004690 S.TRA LDTC143ZET1G T 104.8/59.4
Q361 1590004690 S.TRA LDTC143ZET1G T 46.5/43.4
Q422 1590004690 S.TRA LDTC143ZET1G T 15.0/45.7
Q423 1550000500 S.FET RZF020P01TL T 18.6/44.7
D21 1750002230 S.DIO LRB751S-40T1G T 147.3/46.6
D22 1750002230 S.DIO LRB751S-40T1G T 163.1/46.6
D31 1750001810 S.DIO L1SS400T1G T 148.7/37.8
D41 1750001810 S.DIO L1SS400T1G T 157.5/37.2
D51 1750001810 S.DIO L1SS400T1G T 117.1/45.6
D81 1750001810 S.DIO L1SS400T1G T 90.8/18.8
D321 1790002170 S.VAR LXES15AAA1-133 T 104.3/51.7
D326 1750002570 S.DIO BAP50-04215 T 107.9/51.7
FI321 2040002410 S.SAW TA1985A (1260 MHz) T 94.8/50.8
FI431 2040002400 S.SAW TB0648A (351 MHz) T 20.6/39.0
L1 6200010780 S.COI C2520C-1R0G-A T 143.7/48.1
L21 6200002591 S.COI NLV25T-039J-PF T 149.1/43.1
L22 6200002591 S.COI NLV25T-039J-PF T 161.3/43.1
L81 6200012700 S.COI 0.50-2.0-6TL 35.0N T 110.9/18.5
L91 6200017080 S.COI AS100240-6R8NJ 6.8N T 145.2/29.1
L92 6200017080 S.COI AS100240-6R8NJ 6.8N T 136.2/37.7
L101 6200013140 S.COI 0.26-0.9-8TR 21.5N T 75.2/27.5
L121 6200012530 S.COI 0.40-1.3-2TL 3.7N T 82.8/33.6
L141 6200011670 S.COI LQW18AN82NG00D T 75.8/10.2
L142 6200013920 S.COI MLK1005S3N9ST T 76.2/12.7
L161 6200010140 S.COI LQW18AN3N9C00D T 64.4/12.1
L162 6200010140 S.COI LQW18AN3N9C00D T 63.2/13.9
L163 6200010120 S.COI LQW18AN5N6C00D T 62.4/15.8
L191 6200011670 S.COI LQW18AN82NG00D T 60.9/13.9
L201 6200013860 S.COI MLK1005S12NJT T 56.1/16.3
L202 6200013900 S.COI MLK1005S5N6ST T 53.8/16.3
L221 6200010140 S.COI LQW18AN3N9C00D T 46.4/13.4
L222 6200010120 S.COI LQW18AN5N6C00D T 44.8/11.6
L223 6200010130 S.COI LQW18AN6N8C00D T 42.0/10.8
L231 6200010140 S.COI LQW18AN3N9C00D T 36.5/8.2
L232 6200011770 S.COI LQW18ANR10G00D T 39.7/8.3
L233 6200013920 S.COI MLK1005S3N9ST T 37.0/13.5
L234 6200010140 S.COI LQW18AN3N9C00D T 39.5/14.5
L235 6200011770 S.COI LQW18ANR10G00D T 42.3/13.7
L241 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) T 30.0/8.6
L242 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) T 28.2/10.4
L251 6200011580 S.COI LQW18AN33NG00D T 26.6/7.9
L252 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) T 23.8/6.9
L261 6200013890 S.COI MLK1005S6N8JT T 51.3/24.2
L262 6200013880 S.COI MLK1005S8N2JT T 51.8/26.5
L266 6200013890 S.COI MLK1005S6N8JT T 50.7/30.9
L267 6200013870 S.COI MLK1005S10NJT T 48.6/31.3
L271 6200013750 S.COI MLK1005SR10JT T 46.5/31.6
L272 6200013750 S.COI MLK1005SR10JT T 46.1/32.8
L273 6200013750 S.COI MLK1005SR10JT T 47.4/27.1
L274 6200013750 S.COI MLK1005SR10JT T 47.0/28.4
L311 6200010120 S.COI LQW18AN5N6C00D T 116.3/54.1
L312 6200012310 S.COI LQW18AN4N7D00D T 113.6/52.6
L313 6200010120 S.COI LQW18AN5N6C00D T 111.7/51.5
L323 6200013840 S.COI MLK1005S18NJT T 98.9/51.5
L361 6200010630 S.COI LQW18AN8N2D00D T 58.6/42.2
L362 6200010120 S.COI LQW18AN5N6C00D T 51.8/46.6
L363 6200013880 S.COI MLK1005S8N2JT T 52.6/51.5
L364 6200013880 S.COI MLK1005S8N2JT T 50.5/52.3
L365 6200011660 S.COI LQW18ANR15G00D T 43.8/48.4
L366 6200011660 S.COI LQW18ANR15G00D T 43.8/44.7
L367 6140002551 S.COI #617DB-1919=P3 T 38.7/46.6
L368 6200011730 S.COI LQW18AN10NG00D (650MA) T 60.3/48.5
L381 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00) T 31.4/50.7
L382 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) T 28.9/48.9
L391 6200011580 S.COI LQW18AN33NG00D T 25.4/50.5
L392 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) T 23.0/46.5
L422 6200009250 S.COI LQW18ANR22G00D
(LQW1608AR22G00) T 23.0/42.9
L431 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 25.1/39.5
L432 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 15.9/40.2
R1 7030010580 S.RES ERJ1TYJ 1R5U (1.5) T 157.0/13.7
R2 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 154.4/17.9
R3 7030016070 S.RES RMC1/16S-474JTH (470 k) T 151.2/13.7
R4 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 150.0/16.5
R6 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 157.3/29.2
R7 7030016380 S.RES RMC1/16S-183JTH (18 k) T 156.0/29.7
R20 7030015910 S.RES RMC1/16S-101JTH (100) T 153.6/33.8
R21 7030010980 S.RES ERA3YHD 470V (47) T 154.6/46.5
R22 7030010980 S.RES ERA3YHD 470V (47) T 155.8/46.5
R23 7030007230 S.RES ERA3YED 102V (1 k) T 153.4/46.5
R24 7030007230 S.RES ERA3YED 102V (1 k) T 157.0/46.5
R25 7030016180 S.RES RMC1/16S-680JTH (68) T 148.5/45.3
R31 7030016280 S.RES RMC1/16S-331JTH (330) T 149.2/35.9
R32 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 149.2/36.8
R33 7030015970 S.RES RMC1/16S-103JTH (10 k) T 149.6/34.7
R34 7030016020 S.RES RMC1/16S-104JTH (100 k) T 150.5/37.5
R35 7030015990 S.RES RMC1/16S-683JTH (68 k) T 148.7/39.3
R36 7030016020 S.RES RMC1/16S-104JTH (100 k) T 150.5/39.3
R41 7030016280 S.RES RMC1/16S-331JTH (330) T 157.8/35.2
R42 7030015960 S.RES RMC1/16S-472JTH (4.7 k) T 157.8/36.1
R43 7030015970 S.RES RMC1/16S-103JTH (10 k) T 156.2/34.0
R44 7030016020 S.RES RMC1/16S-104JTH (100 k) T 156.5/35.8
R45 7030016020 S.RES RMC1/16S-104JTH (100 k) T 158.4/38.6
R46 7030016020 S.RES RMC1/16S-104JTH (100 k) T 157.5/38.6
R51 7030015900 S.RES RMC1/16S-470JTH (47) T 116.7/44.0
R52 7030016020 S.RES RMC1/16S-104JTH (100 k) T 110.9/41.2
R61 7030019090 S.RES RMC1/8-104JTP (100 k) T 135.9/52.2
R71 7510001551 S.THE NTCG16 4LH 333JT T 94.8/14.2
R72 7030016420 S.RES RMC1/16S-182JTH (1.8 k) T 93.4/12.6
R81 7030019410 S.RES RMC1/8-471JTP (470) T 91.6/20.5
R82 7030015200 S.RES RMC1/16-392JTP (3.9 k) T 93.1/18.3
R102 7030015910 S.RES RMC1/16S-101JTH (100) T 74.6/21.3
R103 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 72.0/21.3
R104 7030016560 S.RES RMC1/16SJPTH T 70.4/21.3
R131 7030015910 S.RES RMC1/16S-101JTH (100) T 84.5/17.8
R132 7030015910 S.RES RMC1/16S-101JTH (100) T 87.6/15.5
R133 7030016020 S.RES RMC1/16S-104JTH (100 k) T 88.5/13.2
R134 7030015970 S.RES RMC1/16S-103JTH (10 k) T 87.6/13.2
R135 7030015910 S.RES RMC1/16S-101JTH (100) T 80.6/16.2
R137 7030015970 S.RES RMC1/16S-103JTH (10 k) T 81.5/13.8
R138 7030016110 S.RES RMC1/16S-473JTH (47 k) T 81.5/15.4
R139 7030016020 S.RES RMC1/16S-104JTH (100 k) T 80.3/15.0
R151 7030015930 S.RES RMC1/16S-471JTH (470) T 67.2/8.8
R152 7030015930 S.RES RMC1/16S-471JTH (470) T 68.2/8.9
R153 7030016150 S.RES RMC1/16S-100JTH (10) T 67.7/7.6
R191 7030016130 S.RES RMC1/16S-150JTH (15) T 59.6/13.2
R192 7030016020 S.RES RMC1/16S-104JTH (100 k) T 63.4/5.3
R193 7030015970 S.RES RMC1/16S-103JTH (10 k) T 63.8/6.5
R213 7030016560 S.RES RMC1/16SJPTH T 50.3/15.8
R261 7030016370 S.RES RMC1/16S-271JTH (270) T 35.8/17.9
R262 7030016370 S.RES RMC1/16S-271JTH (270) T 38.2/17.9
R263 7030016570 S.RES RMC1/16S-180JTH (18) T 37.0/17.4
R266 7030016460 S.RES RMC1/16S-181JTH (180) T 50.2/33.0
R267 7030016260 S.RES RMC1/16S-330JTH (33) T 51.4/33.4
R268 7030016460 S.RES RMC1/16S-181JTH (180) T 50.2/33.9
R271 7030016250 S.RES RMC1/16S-220JTH (22) T 36.6/27.3
R272 7030016250 S.RES RMC1/16S-220JTH (22) T 36.5/25.8
R273 7030016250 S.RES RMC1/16S-220JTH (22) T 37.7/25.2
R274 7030016250 S.RES RMC1/16S-220JTH (22) T 38.6/25.2
R276 7030009851 S.RES ERA3YED 271V (270) T 44.4/24.0
R277 7030009691 S.RES ERA3YED 101V (100) T 44.4/25.5
R278 7030016250 S.RES RMC1/16S-220JTH (22) T 37.4/32.6
R279 7030016560 S.RES RMC1/16SJPTH T 47.4/34.1
R280 7030016560 S.RES RMC1/16SJPTH T 48.6/27.5
R293 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 48.6/29.3
R298 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 46.5/34.9
R301 7030016370 S.RES RMC1/16S-271JTH (270) T 30.3/30.2
R302 7030016370 S.RES RMC1/16S-271JTH (270) T 31.2/30.2
R303 7030016570 S.RES RMC1/16S-180JTH (18) T 30.7/31.4
R304 7030006210 S.RES ERJ12YJ4R7U (4.7) T 20.6/29.6
R321 7030016110 S.RES RMC1/16S-473JTH (47 k) T 99.3/56.1
R322 7030016020 S.RES RMC1/16S-104JTH (100 k) T 94.9/56.0
R323 7030015970 S.RES RMC1/16S-103JTH (10 k) T 94.9/57.7
R326 7030016050 S.RES RMC1/16S-102JTH (1 k) T 108.1/54.0
R327 7030016110 S.RES RMC1/16S-473JTH (47 k) T 109.3/54.5
R331 7030016020 S.RES RMC1/16S-104JTH (100 k) T 90.8/53.8
R332 7030016050 S.RES RMC1/16S-102JTH (1 k) T 89.6/54.3
R333 7030016020 S.RES RMC1/16S-104JTH (100 k) T 90.8/47.7
R334 7030016050 S.RES RMC1/16S-102JTH (1 k) T 89.6/47.2
R335 7030016020 S.RES RMC1/16S-104JTH (100 k) T 80.6/53.8
R336 7030016050 S.RES RMC1/16S-102JTH (1 k) T 81.8/54.2
R337 7030016020 S.RES RMC1/16S-104JTH (100 k) T 80.6/47.8
R338 7030016050 S.RES RMC1/16S-102JTH (1 k) T 81.8/47.3
R341 7030016180 S.RES RMC1/16S-680JTH (68) T 87.1/48.7
R343 7030015910 S.RES RMC1/16S-101JTH (100) T 87.1/49.6
R344 7030015910 S.RES RMC1/16S-101JTH (100) T 85.9/49.1
R346 7030016560 S.RES RMC1/16SJPTH T 87.1/52.9
R361 7030016340 S.RES RMC1/16S-393JTH (39 k) T 49.0/50.7
R363 7030016660 S.RES RMC1/16SK49R9FTH (49.9) T 50.9/49.5
R365 7030016110 S.RES RMC1/16S-473JTH (47 k) T 48.0/43.6
R367 7030016290 S.RES RMC1/16S-222JTH (2.2 k) T 45.6/46.6

The underlined parts have been updated from the addendum of the previous version, or from the original page.
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
REF
NO.
PARTS
NO. DESCRIPTION M.H/V LOCATION
5-19a
(Amended page)
June 2019
[PA-C UNIT] [PA-C UNIT]
R421 7030016110 S.RES RMC1/16S-473JTH (47 k) T 20.6/45.9
R422 7030016130 S.RES RMC1/16S-150JTH (15) T 22.2/44.3
R423 7030016020 S.RES RMC1/16S-104JTH (100 k) T 16.6/44.5
R424 7030015970 S.RES RMC1/16S-103JTH (10 k) T 16.6/46.1
R432 7030016560 S.RES RMC1/16SJPTH T 14.7/38.3
R505 7030015910 S.RES RMC1/16S-101JTH (100) T 16.2/11.8
R506 7030015910 S.RES RMC1/16S-101JTH (100) T 16.7/16.1
R507 7030015910 S.RES RMC1/16S-101JTH (100) T 16.7/17.0
R508 7030015910 S.RES RMC1/16S-101JTH (100) T 16.7/17.9
R509 7030015910 S.RES RMC1/16S-101JTH (100) T 16.7/18.8
R510 7030015910 S.RES RMC1/16S-101JTH (100) T 16.7/19.7
R513 7030016250 S.RES RMC1/16S-220JTH (22) T 16.7/20.6
R514 7030016250 S.RES RMC1/16S-220JTH (22) T 16.7/21.5
R515 7030016250 S.RES RMC1/16S-220JTH (22) T 16.7/22.4
R516 7030016250 S.RES RMC1/16S-220JTH (22) T 16.7/23.3
R517 7030016250 S.RES RMC1/16S-220JTH (22) T 16.7/24.2
C1 4030023090 S.CER 0402B102K500CT T 152.5/13.7
C2 4030023090 S.CER 0402B102K500CT T 158.0/19.1
C3 4030023090 S.CER 0402B102K500CT T 154.0/19.1
C4 4030023090 S.CER 0402B102K500CT T 149.6/15.3
C5 4030023090 S.CER 0402B102K500CT T 155.8/30.9
C8 4030022860 S.CER 0402N470J500CT T 145.4/41.8
C9 4030023090 S.CER 0402B102K500CT T 145.4/42.7
C10 4030023010 S.CER 0402B104K160CT T 145.4/43.6
C11 4030023090 S.CER 0402B102K500CT T 157.3/31.6
C14 4030022860 S.CER 0402N470J500CT T 154.0/9.3
C16 4030022860 S.CER 0402N470J500CT T 150.7/9.1
C17 4030023720 S.CER 0603N470J500CT T 120.4/12.4
C20 4030023090 S.CER 0402B102K500CT T 153.6/35.6
C21 4030023090 S.CER 0402B102K500CT T 147.3/44.9
C22 4030022870 S.CER 0402N471J500CT T 149.7/44.9
C23 4030022630 S.CER 0402N100C500CT T 149.7/45.8
C24 4030022630 S.CER 0402N100C500CT T 161.6/45.8
C25 4030022870 S.CER 0402N471J500CT T 161.6/44.9
C26 4030023090 S.CER 0402B102K500CT T 163.2/44.9
C29 4030022860 S.CER 0402N470J500CT T 151.2/42.7
C30 4030022860 S.CER 0402N470J500CT T 159.2/42.7
C31 4030023090 S.CER 0402B102K500CT T 150.5/34.7
C33 4030022860 S.CER 0402N470J500CT T 141.8/5.3
C34 4030022860 S.CER 0402N470J500CT T 142.4/4.4
C35 4030022860 S.CER 0402N470J500CT T 142.9/3.5
C41 4030023090 S.CER 0402B102K500CT T 157.1/34.0
C42 4030023090 S.CER 0402B102K500CT T 156.6/38.6
C51 4030022870 S.CER 0402N471J500CT T 118.2/45.3
C52 4030023090 S.CER 0402B102K500CT T 119.1/45.3
C53 4030023010 S.CER 0402B104K160CT T 119.1/43.7
C54 4030022860 S.CER 0402N470J500CT T 108.8/41.2
C55 4030019560 S.CER GRM21BB31C106KE15L T 115.7/41.2
C56 4030019120 S.CER GRM188B31E105KA75D T 109.9/40.9
C57 4030023090 S.CER 0402B102K500CT T 114.2/47.6
C58 4030022860 S.CER 0402N470J500CT T 115.9/47.6
C59 4030022860 S.CER 0402N470J500CT T 65.9/38.6
C60 4030022860 S.CER 0402N470J500CT T 65.9/37.7
C61 4030020740 S.CER GRM31A5C2J180JW01D T 139.3/49.9
C62 4030024580 S.CER GRM31A5C2J1R0CW01D T 139.3/46.1
C71 4030022870 S.CER 0402N471J500CT T 93.4/13.5
C72 4030023090 S.CER 0402B102K500CT T 93.4/14.4
C75 4030023010 S.CER 0402B104K160CT T 104.2/4.3
C76 4030023090 S.CER 0402B102K500CT T 105.1/4.3
C77 4030022860 S.CER 0402N470J500CT T 119.2/2.7
C81 4030023850 S.CER 0603B102K500CT T 122.4/12.4
C82 4030023730 S.CER 0603N471J500CT T 118.4/11.6
C83 4510011410 S.ELE 25 CE 470 LX T 133.8/10.9
C84 4030023820 S.CER 0603B104K250CT T 124.4/12.4
C87 4030025270 S.CER 1111C6R8CW501X T 106.5/18.8
C88 4030023090 S.CER 0402B102K500CT T 90.7/17.3
C89 4030024460 S.CER GQM22M5C2H1R5BB01L T 90.9/30.1
C91 4030025220 S.CER GQM22M5C2H6R0CB01L T 94.3/30.1
C92 4030022870 S.CER 0402N471J500CT T 91.6/17.3
C93 4030023010 S.CER 0402B104K160CT T 89.8/17.3
C94 4030021000 S.CER GRM31A5C2J100JW01D T 109.1/15.1
C95 4030021430 S.CER GQM22M5C2H4R0CB01L T 135.5/24.6
C96 4030025520 S.CER GQM22M5C2H1R0BB01L T 139.4/22.3
C97 4030024460 S.CER GQM22M5C2H1R5BB01L T 141.8/35.9
C98 4030022380 S.CER GQM22M5C2H3R0BB01L T 138.5/41.5
C101 4030023090 S.CER 0402B102K500CT T 78.3/27.0
C102 4030022870 S.CER 0402N471J500CT T 77.4/27.0
C103 4030023010 S.CER 0402B104K160CT T 79.2/27.0
C104 4030019560 S.CER GRM21BB31C106KE15L T 79.4/25.1
C106 4030023090 S.CER 0402B102K500CT T 76.7/20.8
C107 4030022870 S.CER 0402N471J500CT T 75.8/20.9
C108 4030023010 S.CER 0402B104K160CT T 77.6/20.9
C109 4030022580 S.CER 0402N7R0C500CT T 75.8/15.3
C110 4030024550 S.CER 0402N3R5B500CT T 74.6/15.9
C113 4030022660 S.CER 0402N120J500CT T 71.9/20.4
C114 4030023290 S.CER 0603N2R0B500CT T 71.8/29.8
C115 4030023310 S.CER 0603N3R0B500CT T 71.8/27.5
C117 4030023330 S.CER 0603N4R0B500CT T 71.8/32.4
C119 4030021000 S.CER GRM31A5C2J100JW01D T 77.1/33.6
C121 4030024580 S.CER GRM31A5C2J1R0CW01D T 80.6/35.9
C123 4030022370 S.CER GQM22M5C2H2R0BB01L T 87.5/33.2
C131 4030023090 S.CER 0402B102K500CT T 84.5/16.9
C132 4030022640 S.CER 0402N101J500CT T 88.1/12.0
C133 4030022640 S.CER 0402N101J500CT T 81.1/12.6
C141 4030023090 S.CER 0402B102K500CT T 77.0/9.1
C142 4030022870 S.CER 0402N471J500CT T 75.3/9.1
C143 4030023010 S.CER 0402B104K160CT T 77.0/8.2
C144 4030022550 S.CER 0402N4R0B500CT T 75.0/11.6
C145 4030022870 S.CER 0402N471J500CT T 69.2/8.9
C146 4030022540 S.CER 0402N3R0B500CT T 75.0/13.2
C161 4030022540 S.CER 0402N3R0B500CT T 66.3/13.6
C162 4030022520 S.CER 0402N1R0B500CT T 64.7/13.2
C163 4030022570 S.CER 0402N6R0C500CT T 65.1/14.4
C164 4030022620 S.CER 0402N0R5B500CT T 64.2/14.4
C165 4030022570 S.CER 0402N6R0C500CT T 64.2/16.2
C166 4030022620 S.CER 0402N0R5B500CT T 62.8/16.8
C167 4030024550 S.CER 0402N3R5B500CT T 61.6/17.3
C191 4030023090 S.CER 0402B102K500CT T 58.7/15.0
C192 4030022870 S.CER 0402N471J500CT T 58.7/14.1
C193 4030022870 S.CER 0402N471J500CT T 60.3/15.8
C195 4030023090 S.CER 0402B102K500CT T 63.9/8.4
C196 4030023090 S.CER 0402B102K500CT T 66.5/5.0
C201 4030022790 S.CER 0402N2R5B500CT T 57.1/18.6
C202 4030022530 S.CER 0402N2R0B500CT T 56.1/17.9
C203 4030022720 S.CER 0402N1R5B500CT T 55.7/19.1
C204 4030022590 S.CER 0402N8R0C500CT T 54.7/17.3
C205 4030022790 S.CER 0402N2R5B500CT T 54.7/18.2
C221 4030022530 S.CER 0402N2R0B500CT T 47.3/11.9
C222 4030022530 S.CER 0402N2R0B500CT T 46.1/12.3
C223 4030022550 S.CER 0402N4R0B500CT T 46.1/11.4
C224 4030022720 S.CER 0402N1R5B500CT T 43.7/11.9
C225 4030024550 S.CER 0402N3R5B500CT T 43.7/10.3
C226 4030022620 S.CER 0402N0R5B500CT T 42.5/11.9
C227 4030024550 S.CER 0402N3R5B500CT T 40.8/9.7
C231 4030023090 S.CER 0402B102K500CT T 35.0/9.2
C232 4030022870 S.CER 0402N471J500CT T 34.2/10.2
C233 4030019560 S.CER GRM21BB31C106KE15L T 34.2/12.3
C234 4030022870 S.CER 0402N471J500CT T 41.3/12.3
C235 4030022530 S.CER 0402N2R0B500CT T 40.0/7.2
C236 4030022530 S.CER 0402N2R0B500CT T 35.8/13.9
C237 4030022530 S.CER 0402N2R0B500CT T 39.6/13.4
C238 4030022530 S.CER 0402N2R0B500CT T 41.3/14.0
C241 4030022550 S.CER 0402N4R0B500CT T 37.0/7.0
C242 4030022630 S.CER 0402N100C500CT T 30.0/10.8
C243 4030022560 S.CER 0402N5R0B500CT T 31.0/8.9
C244 4030022560 S.CER 0402N5R0B500CT T 28.0/8.2
C245 4030022790 S.CER 0402N2R5B500CT T 28.5/9.4
C251 4030022680 S.CER 0402N150J500CT T 26.5/10.0
C252 4030022700 S.CER 0402N180J500CT T 25.6/9.1
C253 4030022580 S.CER 0402N7R0C500CT T 25.1/10.4
C254 4030022680 S.CER 0402N150J500CT T 24.2/9.5
C255 4030022900 S.CER 0402N680J500CT T 24.7/8.3
C261 4030022520 S.CER 0402N1R0B500CT T 51.8/25.6
C263 4030022520 S.CER 0402N1R0B500CT T 53.1/24.2
C264 4030022530 S.CER 0402N2R0B500CT T 50.2/26.5
C266 4030022570 S.CER 0402N6R0C500CT T 49.8/30.9
C268 4030022570 S.CER 0402N6R0C500CT T 50.2/32.1
C269 4030022630 S.CER 0402N100C500CT T 51.4/34.8
C271 4030022870 S.CER 0402N471J500CT T 40.4/25.0
C272 4030022870 S.CER 0402N471J500CT T 42.8/26.4
C273 4030019120 S.CER GRM188B31E105KA75D T 42.5/24.7
C274 4030022870 S.CER 0402N471J500CT T 44.6/27.4
C275 4030022870 S.CER 0402N471J500CT T 47.8/32.8
C276 4030022870 S.CER 0402N471J500CT T 48.6/28.4
C277 4030022870 S.CER 0402N471J500CT T 45.0/34.7
C278 4030023010 S.CER 0402B104K160CT T 45.0/35.6
C279 4030022870 S.CER 0402N471J500CT T 43.8/35.1
C280 4030021580 S.CER GRM188B31E225KA12D T 42.5/34.7
C281 4030023170 S.CER 0402B332K500CT T 41.3/34.5
C282 4030021580 S.CER GRM188B31E225KA12D T 39.9/34.7
C283 4030022060 S.CER GRM188B30J106ME47D T 38.7/34.7
C284 4030021400 S.CER GRM188B30J226MEA0D T 37.5/34.7
C285 4030022060 S.CER GRM188B30J106ME47D T 35.7/33.6
C286 4030021400 S.CER GRM188B30J226MEA0D T 35.7/34.9
C287 4030022870 S.CER 0402N471J500CT T 36.6/30.6
C288 4030023010 S.CER 0402B104K160CT T 36.6/29.7
C289 4030022870 S.CER 0402N471J500CT T 36.1/28.5
C291 4030022530 S.CER 0402N2R0B500CT T 48.6/26.5
C292 4030022530 S.CER 0402N2R0B500CT T 50.2/25.6
C293 4030022870 S.CER 0402N471J500CT T 47.0/29.3
C296 4030022530 S.CER 0402N2R0B500CT T 47.0/30.4
C297 4030022530 S.CER 0402N2R0B500CT T 48.6/30.4
C298 4030022870 S.CER 0402N471J500CT T 46.1/33.7
C301 4030023010 S.CER 0402B104K160CT T 21.0/26.6
C302 4030021580 S.CER GRM188B31E225KA12D T 23.6/23.5
C303 4030023010 S.CER 0402B104K160CT T 21.0/25.0
C304 4030022060 S.CER GRM188B30J106ME47D T 31.2/26.8
C305 4030023010 S.CER 0402B104K160CT T 30.0/26.7
C306 4030022640 S.CER 0402N101J500CT T 29.1/26.7
C307 4030022060 S.CER GRM188B30J106ME47D T 46.5/24.7
C308 4030023010 S.CER 0402B104K160CT T 48.5/24.2
C309 4030022640 S.CER 0402N101J500CT T 47.6/24.2
C311 4030022540 S.CER 0402N3R0B500CT T 118.4/54.0
C312 4030022720 S.CER 0402N1R5B500CT T 115.7/51.7
C313 4030022720 S.CER 0402N1R5B500CT T 113.9/51.2
C314 4030022540 S.CER 0402N3R0B500CT T 110.4/50.8
C320 4030022630 S.CER 0402N100C500CT T 76.7/56.5
C321 4030022640 S.CER 0402N101J500CT T 97.7/50.8
C322 4030022870 S.CER 0402N471J500CT T 92.0/50.8
C323 4030022870 S.CER 0402N471J500CT T 99.5/52.8
C324 4030023030 S.CER 0402B103K250CT T 99.5/53.7
C325 4030022640 S.CER 0402N101J500CT T 103.1/50.8
C326 4030022870 S.CER 0402N471J500CT T 105.5/50.8
C327 4030022870 S.CER 0402N471J500CT T 109.3/53.6
C328 4030023090 S.CER 0402B102K500CT T 104.5/57.3
C329 4030022630 S.CER 0402N100C500CT T 96.4/60.0
C330 4030022630 S.CER 0402N100C500CT T 103.2/59.5
C331 4030022870 S.CER 0402N471J500CT T 84.7/52.9
C332 4030022630 S.CER 0402N100C500CT T 90.1/52.9
C333 4030022630 S.CER 0402N100C500CT T 90.1/48.6
C334 4030022630 S.CER 0402N100C500CT T 81.4/52.9
C335 4030022630 S.CER 0402N100C500CT T 81.4/48.7
