Icop Vortex86-6071 User manual
Vortex86-6071
PC/104 Embedded Vortex86CPU Module
128MB/4S/2USB/CRT/LCD/Audio/LAN
User’s Manual
(Revision 1.0)
StockCheck.com
ii
Copyright
The information in this manual is subject to change without notice for continuous
improvement in the product. All rights are reserved. The manufacturer assumes no
responsibility for any inaccuracies that may be contained in this document. And
makes no commitment to update or to keep current the information contained in this
manual.
No part of this manual may be reproduced, copied, translated or transmitted, in
whole or in part, in any form or by any means without the prior written permission of
the ICOP Technology Inc..
Copyright 2002 ICOP Technology Inc.
Manual No. IUM6071000-01 Ver. 1.0 All rights reserved.
1st issue date: July 31, 2003
Trademarks Acknowledgment
Vortex86
is the registered trademark of ICOP Technology Inc.
Other brand names or product names appearing in this document are the
properties and registered trademarks of their respective owners. All
names mentioned herewith are served for identification purpose only.
StockCheck.com
iii
T a b l e o f C o n t e n t s
T a b l e o f C o n t e n t s iii
C h a p t e r 0 Startup 1
0.1 Packing List........................................................ 1
0.2 Option Accessory ............................................... 1
0.3 Specification ...................................................... 2
C h a p t e r 1 Introduction 5
1.1 Features ............................................................. 5
1.2 Specifications..................................................... 6
1.3 VGA Interface ..................................................... 7
1.4 Audio Interface ................................................... 7
1.5 Network Interface ............................................... 7
Chapter 2 Installation 8
2.1 Board Outline ..................................................... 8
2.1.1 By Function ........................................................ 8
2.1.2 By Location ......................................................... 9
2.2 Connectors & Jumpers Summary ..................... 10
2.3 Pin Assignments & Jumper Settings .............. 111
J1 : VGA Connector .................................................. 11
J2 : RESET ................................................................. 11
J3 : USB Connector ................................................... 11
J4 : PS/2 Keyboard Connection................................... 11
J6 : Speaker ............................................................. 12
J7 : PS/2 Mouse Connection ....................................... 12
J8 : LCD Connector .................................................. 13
J5 : LCD Volts Selection ............................................ 13
J9 : LAN Connection ................................................. 14
J10 : IDE Connector ................................................. 14
J11 : Power Connector ............................................. 15
J12 : CPU FAN .......................................................... 15
StockCheck.com
iv
J13 : RS232/RS485 Select .......................................... 15
J14 : FDD Connector ................................................ 16
J15 : COM1 Connection ........................................... 16
J16 : COM2 Connection ........................................... 17
J17 : Printer Connector ............................................. 17
J18 : RS485 Connection ............................................ 17
J19 : PC/104 Connector .......................................... 178
J20 : PC/104 Connector ............................................ 18
J21 : Line-in Connector ............................................. 19
J22 : Line-out Connector .......................................... 20
J23 : Mic-in Connector ............................................. 20
J24 : COM3 Connection ........................................... 20
J25 : COM4 Connection ........................................... 20
2.4 Watchdog Timer ............................................... 21
Chapter 3 SVGASetup 25
3.1 Introduction...................................................... 25
3.1.1 SoC Chipset ...................................................... 25
3.1.2 Display memory................................................. 25
3.2 Flat Panel BIOS Wiring ..................................... 26
C h a p t e r 4 Network Interface 30
4.1 Introduction...................................................... 30
4.2 Software Support.............................................. 30
Warranty 31
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 1
C h a p t e r 0
Startup
0.1 Packing List
Product Name Function Package
Vortex86-6071
PC/104 Embedded
Vortex86CPU
Module
Vortex86-6071 PC/104 Embedded
Vortex86CPU Module
Manual & Drivers CD x 1
FDD cable x 1
HDD cable x 1
VGA cable x 1
LAN cable x 1
USB cable x 1
Audio cable x 3
RS232 cable x 4
Printer cable x 1
PS2 cable for Keyboard and Mouse x 2
0.2 Option Accessory
Product Name Function Package
ICOP-0094 IDE Exchange Kit IDE 44 pin (2.0mm Pitch) to IDE 40 pin (2.54mm
Pitch), Board size: 70 x 50 mm)
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC 2
0.3 Specification
Features Vortex86-6071
Processor Chipset DM&P(SiS)Vortex86
System-on-Chip CPU–200MHz
Real Time Clock with Lithium Battery Backup
Bus Interface PC/104 Standard Compliant
Memory Onboard 128MB SDRAM
BIOS AMI BIOS
Multi I/O Enhanced IDE interface
RS232 port x3
RS232/485 port x1
Parallel port x1
FDD interface x1
USB port x1
Line-in port x1
Line-out port x1
Mic-in port x1
Video Display AGP Rev.2.0 Compliant
Shared system memory area up to 16MB.
Resolution up to 1,920Cx 1,440 true colors
CRT/LCD display
LAN Realtek 8100B single chip
Full-duplex transfer mode, doubles effective
bandwidth 16KB RAM buffer
Throughput 10/100Mbps
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 3
Connectors 2.0mm 44-pin box header for IDE
2.0mm 10-pin box header for RS-232 x3
2 pin header for RS-485
2.0mm 26-pin box header for Printer
2.0mm 34-pin box header for FDD
2.0mm 10-pin box header for USB
2.0mm 10-pin box header for VGA
2.0mm 8-pin header for Ethernet
2.0mm 44-pin box header for LCD connector
2.0mm 4-pin header for Line-in
2.0mm 4-pin header for Line-out
2.0mm 4-pin header for Mic-in
5-pin box header for AT-Keyboard connector
5-pin header for PS/2 Mouse
Watchdog Timer Software Watchdog Timer
Three 8254 Compatible Programmable 16-bit
Counters.
Power Requirement Single Voltage +5V @1.2 A
Board Weight 100g
Board Size 90mm X 96mm
Operating Temperature -20°C ~ +70°C
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC 4
This page is intentionally left blank.
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 5
C h a p t e r 1
Introduction
1.1 Features
PC/104 Embedded Vortex86
CPU Module (90 x 96 mm)
DM&P Vortex86
System-On-Chip
CRT and Flat Panel Display interface
Onboard 128MB SDRAM
Enhanced IDE devices and FDD interface
One Bi-directional Parallel Port
RS-232/485 interface
Watchdog timer
Onboard Keyboard & Mouse connector
Onboard Audio connector
Onboard Ethernet
Single voltage +5V power connector
Operating temperature from –20°C〜+70°C
Board Support Package for Windows CE.NET
Accept custom modification
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC 6
1.2 Specifications
Embedded CPU: DM&P Vortex86
System-on-Chip CPU – 200MHz,
Realtime clock, and watchdog timer.
BIOS: Y2K compliant AMI system BIOS
System Memory: Onboard 128MB SDRAM
Bus Interface: PC/104 ISA Bus Interface
Data Bus: 64-bit
Bus Speeds: PCI Bus – 33MHz
DMA Channels: 7
Interrupt Levels: 15
Enhanced IDE: supports one port and up to two hard drives or Enhanced
IDE devices of PIO mode 4. BIOS enabled/disabled
Watchdog Timer: generates either a RESET, NMI or an IRQ when your
application loses control over the system. Optionally the watchdog can
trigger a user specified interrupt.
Real-time Clock: included in Vortex86
SOC with onboard lithium battery
backup. CMOS data backup of BIOS setup and BIOS default.
Keyboard and Mouse Connectors: supports PS/2 Keyboard and mouse
Serial ports: Supports high speed RS-232 port, high speed RS-232/485
port (jumper selectable).
Floppy Disk Drive Interface: supports up to two floppy drives, 5¼“ (360 KB
or 1.2 MB) and 3½ “ (720 KB, 1.44 MB). BIOS enabled / disabled
Bi-directional Parallel Port: supports SPP, EPP and ECP mode. BIOS
enabled/disabled
Audio port:AC97 CODEC, includes line-in, line out, mic-in functions.
Power Requirements: single voltage +5 V @ 1.2A
Board Dimensions: 90 (L) x 96 (W) mm.
Board Weight: 100 g
Extended Operating Temperature: -20°C ~+70 °C
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 7
1.3 VGA Interface
Chipset: DM&P Vortex86
SOC
Memory: Shared system memory up to 128MB
System Bus: 33-bit PCI bus
Panel Data Bus: 24-bit
Display: CRT and LCD Flat Panel
Compliance:
- AGP 2.0 / 4X Compliant / Fully DirectX 8 Compliant
- Cooperates with “Video Bridge” to support Digital LCD/CRT Monitor
Digital Output:
- Supports VESA Standard Super High Resolution Graphic Modes
Supported Flat Panels:
- PVI 6.4” TFT LCD panel P/N: V16C6448AC
- SHARP 6.4” TFT LCD panel P/N: LQ64D341
(HIROSE DF9BA-31P-1V)
- NEC 6.5” TFT Color LCD panel P/N: NL6448BC20-08
(HIROSE DF9B-31P-1V)
- AU 8.4” LVDS Color LCD panel P/N: B084SN01
- AU 10.4” LVDS Color LCD panel P/N: B104SN01
- AU 13.3” LVDS Color LCD panel P/N: UB133X01
1.4 Audio Interface
Chipset: Realtek ALC202
Compliance: AC97 CODEC
Support: Line-in/Line-out/Mic out
1.5 Network Interface
Chipset: Realtek 8100B single chip
Type: 10/100BASE-T
Transfer Mode: Full duplex, doubles effective bandwidth
Buffer: Built-in 16KB RAM Buffer.
Connectors: 8-pin male header, pitch 2.0mm
Monitoring LEDs: network ready indicator, network activity
indicator
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC 8
C h a p t e r 2
Installation
2.1 Board Outline
2.1.1 By Function
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 9
2.1.1 By Location
The red dot indicates the first pin of each connector
J2
J21
J22
J23
J14
J8
J5
J4
J7
J18 J10 J9
J6
J17
J24
J25
J3
J16
J12
J1
J15
J13
J11 J19
J20
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC
10
2.2 Connectors & Jumpers Summary
SUMMARY
J1: VGA Connection 2.0 ∅Box Header
J2: RESET Pin Header
J3: USB Connection 2.0 ∅Box Header
J4: PS/2 Keyboard Connection 2.0 ∅Box Header
J5: LCD Volts Selection Pin Header
J6: Speaker Pin Header
J7: PS/2 Mouse connector Pin Header
J8: LCD Connection 2.0 ∅Box Header
J9: LAN Connector Pin Header
J10: IDE Connection 2.0 ∅Box Header
J11: Power Connector Pin Header
J12: CPU Fan connector Molex Box Header
J13: RS232/485 Selection for COM2 Pin Header
J14: FDD Connection 2.0 ∅Box Header
J15: COM1 Connection 2.0 ∅Box Header
J16: COM2 Connection 2.0 ∅Molex Header
J17: Printer Connection 2.0 ∅Box Header
J18: RS485 Connector Pin Header
J19,J20: PC104 Connector Box Header
J21: Line-in Connection 2.0 ∅Box Header
J22: Line-out Connection 2.0 ∅Box Header
J23: Mic-in Connection 2.0 ∅Box Header
J24: COM3 Connection 2.0 ∅Box Header
J25: COM4 Connection 2.0 ∅Box Header
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 11
2.3 Pin Assignments & Jumper Settings
J1 : VGA Connector - 2.0 ∅10-pin Box Header
Pin # Signal
Name Pin # Signal
Name
1 ROUT 2 GND
3 GOUT 4 GND
5 BOUT 6 GND
7 HSYNC 8 GND
9 VSYNC 10 GND
J2 : RESET - 2-pin Header
Pin # Signal
Name
1 PWROK
2 GND
J3 : USB Connector - 2.0 ∅pitch 10-pin Box Header
Pin # Signal
Name Pin # Signal
Name
1 VCC 2 VCC
3 -DATA1 4 -DATA0
5 +DATA1 6 +DATA0
7 GND 8 GND
9 GND 10 GND
J4 : PS/2 Keyboard Connection - 5-pin Molex Header
Pin # Signal Name
1 KBCLK
2 KBDAT
3 NC
4 GND
5 SB 5V (VCC)
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC
12
J6 : Speaker - 2-pin Header
Pin # Signal
Name
1 SPKR
2 VCC
J7 : PS/2 Mouse Connection- 5-pin Header
Pin # Signal Name
1 PMCLK
2 PMDAT
3 NC
4 GND
5 SB 5V (VCC)
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 13
J8 : LCD Connector - 2.0 ∅pitch 44-pin Box Header
Pin # Signal
Name Pin # Signal
Name SISSED
CONN. DSTN DIGITAL
18-BIT
RGB
24-BIT
1 LCDVCC 2 LCDVCC VAD0 LD0 G2 G4
3 VAD0 4 VAD1 VAD1 LD1 G3 G5
5 VAD2 6 VAD3 VAD2 LD2 G4 G6
7 VAD4 8 VAD5 VAD3 LD3 G5 G7
9 VAD6 10 VAD7 VAD4 LD4 R0
11 VAD8 12 VAD9 VAD5 LD5 R1
13 VAD10 14 VAD11 VAD6 LD6 R0 R2
15 GND 16 UD4 VAD7 LD7 R1 R3
17 UD5 18 UD6 VAD8 UD0 R2 R4
19 UD7 20 GND VAD9 UD1 R3 R5
21 VBD0 22 VBD1 VAD10 UD2 R4 R6
23 VBD2 24 VBD3 VAD11 UD3 R5 R7
25 VBD4 26 VBD5
27 VBD6 28 VBD7 VBD0 B0
29 VBD8 30 VBD9 VBD1 B1
31 VBD10 32 VBD11 VBD2 B0 B2
33 GND 34 GND VBD3 B1 B3
35 PLDXCLK 36 VBGCLK VBD4 B2 B4
37 VADE 38 VBDE VBD5 B3 B5
39 AHSYNC 40 VBHSYNC VBD6 B4 B6
41 AVSYNC 42 VBVSYNC VBD7 B5 B7
43 DISPOFF 44 VDDEN VBD8 G0
VBD9 G1
J5: LCD Volts Selection - 3-pin Header VBD10
G0 G2
Pin # Signal Name
VBD11 G1 G3
1-2 +5V UD4 UD4
2-3 +3.3V
UD5 UD5
UD6 UD6
UD7 UD7
PLDXCLK SHFCLK
VADE
MOD/LDE
VAHSYNC
LP/HYSNC
VHVSYNC
FLM/VYSNC
DISOFF ENBT
VBGCLK XCLK XCLK
VBDE
DEN DEN
VBHSYNC
HSYNC
HSYNC
VBVSYNC
VSYNC
VSYNC
VDDEN
VDDEN
VDDEN
VDDEN
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC
14
J9 : LAN Connection - 8-pin Header
Pin # Signal
Name Pin # Signal
Name
1 TX+ 2 TX-
3 RX+ 4 LED0
5 LED0+ 6 RX-
7 LED1+ 8 LED1
J10 : IDE Connector - 2.0 ∅pitch 44-pin Box Header
Pin # Signal
Name Pin # Signal
Name
1 IDERST- 2 GND
3 IDED7 4 IDED8
5 IDED6 6 IDED9
7 IDED5 8 IDED10
9 IDED4 10 IDED11
11 IDED3 12 IDED12
13 IDED2 14 IDED13
15 IDED1 16 IDED14
17 IDED0 18 IDED15
19 GND 20 NC
21 IDEREQ 22 GND
23 IDEIOW- 24 GND
25 IDEIOR- 26 GND
27 ICHRDY 28 GND
29 IDACK- 30 GND
31 IDEIRQ 32 NC
33 IDESA1 34 CBLID
35 IDESA0 36 IDESA2
37 IDECS-0 38 IDECS-1
39 DASP 40 GND
41 VCC 42 VCC
43 GND 44 NC
StockCheck.com
Vortex86-6071 : PC/104 Embedded Vortex86CPU Module 15
J11 : Power Connector - 2-pin Header
Pin # Signal
Name
1 SB5V
2 GND
J12 : CPU FAN - 2-pin Molex Header
Pin # Signal
Name
1 VCC
2 GND
J13 : RS232/RS485 Select - 3-pin Header
Pin # Signal Name
1-2 COM2 RS232
2-3 RS485
StockCheck.com
Vortex86-6071 : Embedded Half-SizeVortex86AIO SBC
16
J14 : FDD Connector - 2.0 ∅34-pin Box Header (17x2)
Pin # Signal
Name Pin # Signal
Name
1 GND 2 DENSEL
3 GND 4 NC
5 GND 6 NC
7 GND 8 INDEX\
9 GND 10 MTRO\
11 GND 12 DS1\
13 GND 14 DS0\
15 GND 16 MTR1\
17 GND 18 DIR\
19 GND 20 STEP\
21 GND 22 WD\
23 GND 24 WG\
25 GND 26 TR0\
27 GND 28 WP\
29 GND 30 RD\
31 GND 32 HDSEL\
33 GND 34 DSKCHG\
J15 : COM1 Connection (RS-232 Connector) - 2.0 ∅10-pin Box
Header
Pin # Signal
Name Pin # Signal
Name
1 DCD1 2 RXD1
3 TXD1 4 DTR1
5 GND 6 DSR1
7 RTS1 8 CTS1
9 RI1 10 NC
StockCheck.com
Table of contents
Other Icop Control Unit manuals
