PCI-AD64 Series Quick Start
v1.0, Dec. 2022
Packing List
In addition to this guide, the package includes the following items:
PCI-AD64 Series
Technical Support
[e-mail]
www.icpdas.com
Resources
How to search for drivers, manuals and
spec information on ICP DAS website.
For Mobile Web
For Desktop Web
Related Information
For more detailed information related to the software manual, hardware
manual, PCI-AD64 series Driver & SDK and sample program:
http://www.icpdas.com/en/download/index.php?model=PCI-AD64SU
PCI
-AD64
PCI
-AD64

P2
1 Installing Windows Driver
1) Download or locate the Windows driver.
The UniDAQ driver supports 32-/64-bit Windows 10/11, which can be
found in the
https://www.icpdas.com/en/download/index.php?kw=UniDAQ
2) Click the “Next>” button to start the installation.
3) Check your DAQ Card is or not on supported list, then click the
“Next>” button.
4) Select the installed folder, the default path is C:\ICPDAS\UniDAQ,
confirm and click the “Next>” button.
5) Check your DAQ Card on list, then click the “Next>” button.
6) Click the “Next>” button on the Select Additional Tasks window.
7) Click the “Next>” button on the Download Information window.
8) Select “No, I will restart my computer later” and then click the
“Finish” button.
NOTE:
For more detailed information related to driver installation, refer to
Chapter 4 “Starting” in the PCI-AD64 series user manual.

P3
2 Installing Hardware on PC
1) Power off the Computer.
2) Remove all covers from the Computer.
3) Select an unused PCI /PCI Express slot.
4) Carefully insert the Card into PCI/PCI
Express slot.
5) Replace the Computer Covers.
6) Power on the Computer.
7) The operating system will automatically detect the new hardware and
install the necessary drivers after reboot the PC.
8) Open the “Device Manager” to verify that the PCI-AD64 Card has
been correctly installed and is in the Device Manager, as illustrated on
below.
[UniDAQ]PCI-AD64SU Analog Input Board

P4
3 Pin Assignments

P5
4 Advanced Configuration
Before beginning the “Self-test”, use the advanced configuration tool in
the Windows Device Manager to settings the Analog Input type, the
detail configuration is illustrated in the figure below.
1) Open the Windows Device Manager, Right-click PCI-AD64 and
select the Properties on popup menu.
2) Click the Advanced tab to open the advanced configuration tool. In
the Analog Input Type section, select the Single Ended options for
execute a self- test.
3) Click the Save Setting(S) button and OK button to complete the
configuration.

P6
5 Testing Board
Prepare for device
CA-SCSI15-H3 (optional) cable
DN-68A (optional) daughter board
1) Connect the CON1 to DN-68A board using the CA-SCSI15-H3 cable.
2) AI functional test and wiring
Connect the signal AO channel 0 to AI channel 0, and connect the signals as
follows.
Connect the AI_GND pin (Pin60)to battery(-) on the terminal board
Connect the AI0 pin (Pin68) to battery(+) on the terminal board.

P7
3) Launch the UniDAQ Utility
program, it was installed in the
default folder, it will be located at
“C:\ICPDAS\UniDAQ\Driver”.
4) Click the “TEST”button to start the test.
Click the ”Analog Input” item than click “SINGLE” button to get values.
Check the voltage is or not equal battery.

