ICP DAS USA LinPAC-5000 User manual

ICPDAS - 1 -
Q
Qu ui ic ck k
S
St ta ar rt t
f
fo or r
L
Li in nP PA AC C- -5 50 00 00 0
Version 1.2, 2011/01/20
ÂWhat’s In the Box?
LP-5K module microSD card Software Utility CD Screw Driver RS-232 Cable
ÂPreparing for start-up your LinPAC-5000
Power Supply: +10V ~ +30VDC (Ex: DP-665)
http://www.icpdas.com/products/Accessories/power_supply/power_list.htm
ÂView of the LinPAC-5000
1 USB Port 6 COM 1 (RS-232)(console) 11 LED Indicator
2 Ethernet Port 7 COM 2 (RS-485) 12 microSD socket
3 Ethernet Port 8 COM 3 (RS-232) 13 VGA Port
4 Microphone-In 9 Power 14 Xboard (optional)
5 Earphone-Out 10 Frame Ground 15 Operating Modes Selector

ÂConfiguring the operating mode
Make sure the rotary
switch place in the
“0” position.
Rotary switch position Modes of operation
0 Normal mode(Default)
1 Quick mode
2 OS update mode
3 Debug mode
Others Reserved
Normal mode(Default)
The normal mode is the default mode of operation. Use this mode for more tasks and
configurations. Programs also are executed in this mode.
Quick mode
The safe mode is used to skip the LinPAC-5000 boot screen form microSD/microSDHC
card, so as to speed up the booting process.
OS update mode
The mode is a way used to update OS, and the Linux OS image was just suitable for the
LP-5000 by ICP DAS. If the LP-5000 cannot be boot or run the normal mode, please
update OS image again. Please pay attention to backup important files first before
updating OS image. For more information, please refer to “LP-5000 OS update manual”.
Debug mode
The purpose of this mode is to development by ICP DAS.
Reserved
Rotary switch position 4~9 are reserved by ICP DAS.
ICPDAS - 2 -

ÂConnect the LinPAC-5000 and Windows PC
The port is located on the right-upper corner on the LinPAC-5000. It is a
standard RS-232 serial port, and it provides TxD, RxD, GND,
non-isolated.
Start HyperTerminal by clicking on ‘Start ÆPrograms ÆAccessories
ÆCommunications ÆHyper Terminal’
In the ‘COM properties’ dialog box, please set for 115200 bits per
second, 8 data bits, no parity, 1 stop bit and no flow control to set up
the communication parameters for the COM1 port, and press ‘OK’ when
done.
ICPDAS - 3 -

ICPDAS - 4 -
Turn on the power, and user should see a message appear on the
screen, and the total process is completed.
To login LinPAC-5000 by ‘getty’ command.
ID: root
Password: root

ÂConnect the LinPAC-5000 and Linux PC
Install HyperTerminal tool in Linux PC such as minicom, gtkterm, etc.
Take minicom as an example, please refer to the following steps:
Type ’minicom -s’ to configure COM1 port, and press down and select
‘Serial port setup’.( please set for 115200 bits per second, 8 data bits,
no parity, 1 stop bit and no flow control to set up the communication
parameters for the COM1 port). Finally, press ‘Exit’.
ICPDAS - 5 -

ICPDAS - 6 -
minicom in action
To login LinPAC-5000 by ’getty’ command.
ID: root
Password: root

ÂTelent to LinPAC-5000
In HyperTerminal :
>> In Linux PC :>> In Windows PC :
ICPDAS - 7 -

ÂGet & Configure IP of LinPAC-5000
The LinPAC-5000 network setting includes two ways. One is DHCP and the
other is “Assigned IP”. DHCP is the default setting after the LinPAC-5000 is
produced and this way is easy for users. However, if your network system is
without DHCP server, then users need to configure the network setting by using
“Assigned IP”.
Boot up LinPAC-5000 and telnet to LinPAC-5000 first.
Type in “vi /etc/network/interfaces” to open the network setting file.
ÂTechnical Support
ICP DAS Website: www.icpdas.com.tw
ICP DAS Service :
[email protected]
[email protected]
