Quick Start User Guide
CAN-8123/ CAN-8223/CAN-8423
CANopen Slave Device
Introduction
This user guide introduces the user how to implement the
CAN-8123/CAN-8223/CAN-8423 into their applications in a quick and easy
way. Therefore, it only provides the basic instructions. For more detail
information about the CAN-8123/CAN-8223/CAN-8423, please refer to the
CAN-8123/CAN-8223/CAN-8423 user manual in the product CD or download
it from following web site:
http://www.icpdas.com/products/Remote_IO/can_bus/can-8123.htm
or
http://www.icpdas.com/products/Remote_IO/can_bus/can-8423.htm
CAN-8123/CAN-8223 Hardware Structure
CAN-8423 Hardware Structure
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 1

CAN-8123/ CAN-8223 CAN bus connectors ping assignment
Pin Signal Description
1 CAN_GND Ground (0V)
2 CAN_L CAN_L bus line
(dominant low)
3 CAN_SHLD Optional CAN Shield
4 CAN_H CAN_H bus line
(dominant high)
5 CAN_V+ CAN external positive supply
CAN-8423 CAN bus connectors ping assignment
Pin Signal Description
2 CAN_H CAN_H bus line
(dominant high)
3 CAN_SHLD Optional CAN Shield
4 CAN_L CAN_L bus line
(dominant low)
Power and CAN Connection
The CAN-8123/CAN-8223/CAN-8423 CAN connector is standard 5-pin screw terminal
connector. Uses can connect it directly with any other standard male 5-pin screw terminal.
Take a note that the CAN-8423 power pin of CAN connector is useless. Therefore, users need
to give CAN-8423 power by using power connector. Please refer to the CAN-8423 Hardware
Structure described before.
Terminal Resistance
In order to minimize the reflection effects on the CAN bus line, the CAN bus line has to be
terminated at both ends by two terminal resistances. The CAN-8123/CAN-8223/CAN-8423
has the 120Ωterminal resistance inside. The JP2 of the CAN-8123/CAN-8223 and the JP1 of
the CAN-8423 is for terminal resistance. Their position and jumper status are shown in the
following figure.
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 2

Install CAN Slave Utility
Step1:Download the CAN Slave Utility setup file from the web site
http://www.icpdas.com/download/index.htm
or CD-ROM disk following the path:
“/CANopen/Slave/CAN-8x23/Utility/Setup.exe”
Step 2: Execute the CAN_SL_Setup.exe file to install the CAN Slave Utility.
CAN-8123/ CAN-8223 Configuration (Off-line mode)
Step 1: Select “Application Layer” to “CANopen”. Then, select the “Setting status” to offline.
Here, assume that users’ CAN slave device is CAN-8223 with node id 123 and baud rate
1000Kbps. Fill the correct value of users’ CAN-8223 node id and baud in the “NODE ID” and
“CAN Baud rate” filed. Then, select the “Slot Number” to “2 Slot”.
Step 2: Assume that users plug the I-8024 and I-8042 slot modules in the slot 0 and 1
respectively. Click the slot 0 icons shown in the “CAN Slave Device Situation” frame. Select
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 3

8024 in the list box, and click button “Apply Module” to save the configuration. After finish the
configuration, users can slip the mouse point to the slot module in the “CAN Slave Device
Situation” frame. Afterwards, add another module I-8042 in the slot 1 by following the method
described before. When all slot are configured, click “Save Setting” to go on the next.
Step 3: Users can check the default settings for each slot module by clicking this module. Or
move the mouse pointer on the slot module to see the module name and module information in
the “Module Information” frame.
Step 4: The two fields, “description” and “create by”, can help users to do some notes in the
EDS file. If they are empty, the “ICPDAS CANopen I/O Slave Device” and “ICPDAS” will be
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 4

used for the default value. Users can also click on the “PDO Information”, “Device Information “,
and the “Slot Module Information” button to view the PDO objects, device profile and slot
module information. If everything is ok, click the “Finish” button to create the EDS file.
Note: If users use off-line method to get the EDS file, the objects which are used to record the
input/output range of the analog modules will be described to default value in the EDS file.
However, the I-87K slot modules hold the input/output range parameter settings in their own
EEPROM. It may cause the mismatch between real input/output range setting and EDS file. By
the way, II-8KCPSx needs to configure the input/output range settings by using CANopen
SDO protocol. For more detail, please refer to the section 5.5 in CAN-8123/CAN-8223/
CAN-8423 user manual.
CAN-8423 Configuration (On-line mode)
Before using the CAN Slave utility, please make sure that you have connected COM1 of
the CAN-8423 with the available COM port on your PC. The architecture is displayed in the
following figure. In this example, the CAN-8423 will be used, and slot modules, I-87057,
I-87057, I-87024 and I-87017H are plugged in the slot 0, 1, 2, 3 respectively (If users don’t
have any slot module, they can also follow this demo to configure their CAN-8423. But some
situation or information relative with slot modules will be difference).
Step 1: Turn off the CAN-8423. Set the “Baud” rotary switch of CAN-8423 to 9 for
configuration mode. Then Turn on the CAN-8423.
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 5

Step 2: Use the “ID” rotary switch and “Baud” rotary switch to set the baud rate of CAN-8423.
The node ID is useless when the value exceeds the 7F (127 for decimal format) because of
the CANopen spec definition. The relationship between the rotary switch value and practical
baud rate is displayed in the following table. Here, use ID 123 and baud rate 1000Kbps for the
demo. Therefore, set the “ID” rotary switch to “7B” (7B=7*16+B=112+11=123) and “Baud”
rotary switch to 7.
Rotary Switch Value Baud rate (K BPS)
0 10
1 20
2 50
3 125
4 250
5 500
6 800
7 1000
Step 3: Execute the CAN_SL.exe file, and the figure will be displayed. Select a PC COM port
to connect the CAN-8423. Here, use PC COM 2 for this demo. Therefore, users need to click
the “PC COM Port” list box, set it to COM2, and click button “Connect” to connect the
CAN-8423. Afterwards, the utility tool will get the information stored in the CAN-8423.
Step 4: Users can move the mouse pointer to the slot of CAN-8423 shown in the “CAN Slave
Device Situation” to get the module information of this slot module.
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 6

Step 5: Click the slot module 3. Here, select the output range to -10.00V~+10.00V in the list
box of “Module Configuration” frame for example. Because the feature of I-8024 slot module,
each channel output range will be changed together after users select the output range of one
channel. Click “Set” button to store the parameter setting. If all of slot module configurations
are finished, click “Build EDS File” button to go on the next step.
Step 6: Afterwards, users can see the “EDS File Information” window, and fill the
“Description” and “Create by” filed for the EDS file. Also, users can see the CANopen objects
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 7

information and modules information by click the buttons. Please refer to the step 6 in the
off-line setting described before.
Note: The CAN-8423 can also create the EDS file by using off-line mode, and set the analog
input range or analog output range by using the CANopen SDO protocol. For more detail,
please refer to the section 5.5 in CAN-8123/CAN-8223/CAN-8423 user manual.
Application Procedure
Set the CAN-8423 terminal
resistance
Configure the CAN-8123/CAN-8223/
CAN-8423 by using off-line mode
Configure the CAN-8423 by
using on-line mode
Set the CAN-8123/CAN-8223/
CAN-8423 terminal resistance
Power off the CAN-8423 Set ID and Baud rate by using rotary
switch
Connect the CAN-8423
CAN connector
Connect the CAN-8123/CAN-8223/
CAN-8423 CAN connector.
Power on the CAN-8423 Power on the CAN-8123/CAN-8223/
CAN-8423
Apply the CAN-8423 into
CANopen network.
Apply the CAN-8123/CAN-8223/
CAN-8423 into CANopen network.
CAN-8423 Procedure CAN-8123/CAN-8223/ CAN-8423
Procedure
