ICP DAS USA SmartView TPM-4100 User manual

TPM-4100/TP-4100/TP-2070/
TP-3080/TP-5120/TP-6150/
TP-7170 Touch Panel
Monitor User Manual
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 1
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

Warranty
All products manufactured by ICP DAS are under warranty regarding defective
materials for a period of one year, beginning from the date of delivery to the original
purchaser.
Warning
ICP DAS assumes no liability for any damage resulting from the use of this product.
ICP DAS reserves the right to change this manual at any time without notice. The
information furnished by ICP DAS is believed to be accurate and reliable. However,
no responsibility is assumed by ICP DAS for its use, nor for any infringements of
patents or other rights of third parties resulting from its use.
Copyright
Copyright © 2012 by ICP DAS Co., Ltd. All rights are reserved.
Trademarks
Names are used for identification purposes only and may be registered trademarks of
their respective companies.
Contact us
If you encounter any problems, please feel free to contact us.
You can rely on ICPDAS for a prompt quick response.
Email: [e-mail]
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 2
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

Table of Contents
Table of Contents.............................................3
1. Introduction ..................................................5
1.1. Features.....................................................................7
1.2. Specifications.............................................................8
1.3. Dimension................................................................14
1.4. I/O interfaces............................................................28
1.5. Companion CD ........................................................30
1.6. System Setup...........................................................31
1.6.1. System Configuration................................. 31
1.6.2. Panel Mounting...........................................36
2. Touch Driver Setup....................................38
2.1. Windows CE 5.0 ......................................................39
2.1.1. USB Touch Driver....................................... 40
2.1.1.1. Installation for WinPAC-8000 and WinPAC-5000 41
2.1.1.2. Configuration for WinPAC-8000 and WinPAC-5000 42
2.1.1.3. Uninstalling the WinPAC-8000 and WinPAC-5000 44
2.1.1.4. Other Windows CE5.0 Devices...45
2.1.2. Serial Touch Driver.....................................46
2.1.2.1. Installation for WinPAC-8000 and WinPAC-5000 47
2.1.2.2. Configuration for WinPAC-8000 and WinPAC-5000 49
2.1.2.3. Uninstalling the WinPAC-8000 and WinPAC-5000 51
2.1.2.4. Other Windows CE5.0 Devices...52
2.2. Windows CE 6.0 ......................................................53
2.2.1. USB Touch Driver....................................... 54
2.2.1.1. Installation for XP-8000-CE6.......55
2.2.1.2. Configuration for XP-8000-CE6...57
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 3
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

2.2.1.3. Uninstalling the XP-8000-CE6.....58
2.2.1.4. Other Windows CE6.0 Devices...60
2.2.2. Serial Touch Driver.....................................61
2.2.2.1. Installation for XP-8000-CE6.......62
2.2.2.2. Configuration for XP-8000-CE6...65
2.2.2.3. Uninstalling the XP-8000-CE6.....67
2.2.2.4. Other Windows CE 6.0 Device....69
2.3. Windows XP Embedded..........................................70
2.3.1. Universal Driver..........................................70
2.3.1.1. Installation for XP-8000...............71
2.3.1.2. Configuration for XP-8000...........77
2.3.1.3. Uninstall for XP-8000 ..................81
2.3.1.4. Other Windows XP Embedded Devices 83
2.4. Windows XP/7..........................................................84
2.4.1. Universal Driver..........................................84
2.4.1.1. Installation...................................85
2.4.1.2. Configuring..................................89
2.4.1.3. Uninstall ......................................91
Appendix A. Revision History.......................93
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 4
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

1. Introduction
This chapter provides an overview of the
TPM-4100/TP-4100/TP-2070/TP-3080/T
P-5120/TP-6150/TP-7170 and its
components.
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 5
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

The TPM-4100/TP-4100/TP-2070/TP-3080/TP-5120/TP-6150/TP-7170
Panel Mount Monitor includes a standard TFT LCD screen with a rugged
aluminum front bezel resolution and a wide operating temperature range. The
TPM-4100/TP-4100/TP-2070/TP-3080/TP-5120/TP-6150/TP-7170 is also
guaranteed to integrate with ICP DAS PAC control systems, such as
WP-8000 series, LinPAC-8000 series and the XP-8000 series.
Package List
The shipping package includes the following items:
1 TFT LCD Monitor
1 VGA cable
1 RS-232 cable
1 USB cable
4 Mounting clamps
4 Mounting Screws
1 Power supply
1 Companion CD containing software drivers and digital versions of the
user manuals
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 6
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

1.1. Features
Support resolution
Mode name
Size
Resolution
TP-2070
7”
800 x 480
TP-3080
8.4”
800 x 600
TPM-4100/TP-4100
10.4”
TP-5120
12.1”
TP-6150
15”
1024 x 768
TP-7170
17”
1280 x1024
Full-function OSD control keys for optimizing the display
Driver Support for Windows 2K/XP/Vista/7/XP-Embedded/WinCE 5.0/6.0/Linux
Wide operating temperature range
Mode name
Operating temperature
TP-2070
-20~+70 °C
TP-3080
TPM-4100/TP-4100
TP-5120
TP-6150
TP-7170
Aluminum front bezel design that is ideal for rugged applications
LED backlight technology
Supports the IP65 standard for protection against dust and water
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 7
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

1.2. Specifications
The table below is a summary of the specifications of the touch panel, and lists the
accessories that are supported by the touch panel.
Specifications
Model
TP-2070
Display
Size 7”
Resolution 800 x 480
Luminance 400 cd/m2
Touch screen 4-wire, analog resistive; Light Transmission: 80%
Contrast ratio 500:1
Viewing angle (H/V) 140/120
Backlight life (hrs) 20,000
Touchscreen function
Combo RS-232 & USB interface
Input signal VGA (analog RGB)
MMI (Man Machine Interface)
OSD control Functions: Brightness, Contrast, Clock, Phase, Horizontal Position, Vertical Position
and Sharpness
Power switch Yes
LED indicators Power, Display signal is detected
Power
Input range +12 ~ +48 VDC
Power consumption 5 W
Mechanical
Casing Plastic
Dimensions (W x L x H) 213 mm x 148 mm x 44 mm
Installation Panel Mounting, VESA (75 x 75) Mounting
Ingress protection Front panel: IP65
Environmental
Operating temperature -20 ~ +70℃
Storage temperature -30 ~ +80℃
Ambient relative humidity 10 ~ 90% RH (non-condensing)
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 8
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

Model
TP-3080
Display
Size 8.4”
Resolution 800 x 600
Max. Color 16.7 M
Luminance 400 cd/m2
Touch screen 5-wire, analog resistive; Light Transmission: 80%
Contrast ratio 500:1
Viewing angle (H/V) 140/130
Backlight life (hrs) 50,000
Touchscreen function
Combo RS-232 & USB interface
Input signal VGA (analog RGB)
MMI (Man Machine Interface)
OSD control Functions: Brightness, Contrast, Clock, Phase, Horizontal Position, Vertical Position
and Sharpness
LED indicators Power, Display signal is detected
Power
Input range +12 ~ +48 VDC
Power consumption 7 W
Mechanical
Casing Plastic
Dimensions (W x L x H) 249 mm x 207 mm x 65 mm
Installation Panel Mounting, VESA (75 mm x 75 mm; 100 mm x 100 mm) Mounting
Ingress protection Front panel: IP65
Environmental
Operating temperature -20 ~ +70℃
Storage temperature -30 ~ +80℃
Ambient relative humidity 10 ~ 90% RH (non-condensing)
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 9
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

Model
TPM-4100
TP-4100
Display
Size 10.4”
Resolution 800 x 600
Max. colors 16.7 M
Luminance 400 cd/m2
Touch screen 5-wire, analog resistive
Light Transmission: 80%
5-wire, analog resistive
Light Transmission: 80%
Contrast ratio 500:1
Viewing angle (H/V) 140/130
Backlight life (hrs) 50,000
Touchscreen function
Combo RS-232 & USB interface
Input signal
VGA (analog RGB)
MMI (Man Machine Interface)
OSD control Functions: Brightness, Contrast, Clock, Phase, Horizontal Position, Vertical Position
and Sharpness
Power switch Yes
LED indicators
Power, Display signal is detected
Power
Input range
+12 ~ +48 V
DC
Power consumption 8.5 W
Mechanical
Material Aluminum Plastic
Dimensions (W x L x H)
293 mm x 231 mm x 53 mm
291 mm x 229 mm x 54 mm
Installation Panel Mounting Panel Mounting, VESA (75 x 75) Mounting
Ingress protection
Front panel: IP65
Environmental
Operating temperature
-20 ~ +70℃
Storage temperature -30 ~ +80℃
Ambient relative humidity
10 ~ 90% RH (non-condensing)
Touch Panel Monitor User Manual, version 1.0.7, Last Revised: June 2014 Page: 10
