TPM-4100/TP-4100
Touch Panel Monitor
User Manual

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 2
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
Warranty
All products manufactured by ICP DAS are under warranty regarding defective
materials for a period of one year, beginning from the date of delivery to the original
purchaser.
Warning
ICP DAS assumes no liability for any damage resulting from the use of this product.
ICP DAS reserves the right to change this manual at any time without notice. The
information furnished by ICP DAS is believed to be accurate and reliable. However,
no responsibility is assumed by ICP DAS for its use, not for any infringements of
patents or other rights of third parties resulting from its use.
Copyright
Copyright @ 2012 by ICP DAS Co., Ltd. All rights are reserved.
Trademark
The names used for identification only may be registered trademarks of their
respective companies.
Contact US
If you have any problem, please feel free to contact us.
You can count on us for quick response.
Email: [e-mail]

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 3
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
Table of Contents
Table of Contents.............................................3
1. Introduction ..................................................5
1.1. Features.....................................................................7
1.2. Specifications.............................................................8
1.3. Dimension..................................................................9
1.4. I/O interfaces............................................................13
1.5. Companion CD ........................................................14
1.6. System Setup...........................................................15
1.6.1. System Configuration................................. 15
1.6.2. Panel Mounting...........................................18
2. Touch Driver Installation...........................20
2.1. Windows CE 5.0 ......................................................21
2.1.1. USB Touch Driver....................................... 22
2.1.1.1. Installation for WinPAC-8000 and WinPAC-5000 23
2.1.1.2. Configuring for WinPAC-8000 and WinPAC-500024
2.1.1.3. Uninstall for WinPAC-8000 and WinPAC-5000 26
2.1.1.4. Other Windows CE5.0 Device.....27
2.1.2. Serial Touch Driver.....................................28
2.1.2.1. Installation for WinPAC-8000 and WinPAC-5000 29
2.1.2.2. Configuring for WinPAC-8000 and WinPAC-500031
2.1.2.3. Uninstall for WinPAC-8000 and WinPAC-5000 33
2.1.2.4. Other Windows CE5.0 Device.....34
2.2. Windows CE 6.0 ......................................................35
2.2.1. USB Touch Driver.......................................36
2.2.1.1. Installation for XP-8000-CE6.......37
2.2.1.2. Configuring for XP-8000-CE6......38

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 4
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
2.2.1.3. Uninstall for XP-8000-CE6..........40
2.2.1.4. Other Windows CE 6.0 Device....42
2.2.2. Serial Touch Driver.....................................43
2.2.2.1. Installation for XP-8000-CE6.......44
2.2.2.2. Configuring for XP-8000-CE6......46
2.2.2.3. Uninstall for XP-8000-CE6..........48
2.2.2.4. Other Windows CE 6.0 Device....50
2.3. Windows XP Embedded..........................................51
2.3.1. Universal Driver..........................................51
2.3.1.1. Installation for XP-8000...............52
2.3.1.2. Configuring for XP-8000..............57
2.3.1.3. Uninstall for XP-8000 ..................61
2.3.1.4. Other Windows XP Embedded Device 63
2.4. Windows XP/7..........................................................64
2.4.1. Universal Driver..........................................64
2.4.1.1. Installation...................................65
2.4.1.2. Configuring..................................69
2.4.1.3. Uninstall ......................................71

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 5
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1. Introduction
This chapter provides an overview
of TPM-4100/TP-4100 and its
components.

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 6
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
The TPM-4100/TP-4100 Panel Mount Monitor adopt a standard 10.4" TFT
LCD screen with rugged aluminum front bezel and support 800 x 600
resolution, and -25 ~ 75°C operating temperature. The TPM-4100/TP-4100 is
also guaranteed to work with ICP DAS PAC control system, such as
WP-8000 series, XP-8000 series.
Package List
The shipping package includes the following items:
Monitor x 1 pcs
VGA cable x 1 pcs
RS-232 cable x 1 pcs
USB cable x 1 pcs
Mounting clamp x 4 pcs
Screw x 4 pcs
Power supply x 1 pcs
Companion CD containing software drivers and digital version of the
user manuals x 1 pcs

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 7
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1.1. Features
10.4" LCD supports 800 x 600 resolution
Full-function OSD control keys to optimize the display
Driver Supports Windows 2k/XP/Vista/7/XP-Embedded/WinCE 5.0/6.0
Wide operating temperature -25 ~ +75° C
Aluminum front bezel design ideal for rugged applications
LED backlight technology
Supports IP65 standard for protection against to dust and water

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 8
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1.2. Specifications
The table below summarizes the specifications of TPM-4100/TP-4100, and lists the
accessories that TPM-4100/TP-4100 supports.
Specification
Model
TPM-4100
TP-4100
Display
Size 10.4”
Resolution 800 x 600
Max. color 16.7 M
Brightness (cd/m2) 320
Contrast ration 500:1
Viewing angle (H/V) 140/130
Backlight life (hrs) 50,000
Touch panel 4-wire 5-wire
Analog resistive, RS-232 or USB1.1 (Type B) interface
Input signal VGA(analog RGB)
MMI (Man Machine Interface)
OSD control Functions: Brightness, Contrast, Phase ,Horizontal Position, Vertical Position and
Sharpness
Power switch
Yes
LED indicators Power, Display signal is detected
Power
Input range +12 ~48 VDC
Power consumption
8.5 W
Mechanical
Material
Aluminum
Plastic
Dimensions (W x L x H) 293 mm x 231 mm x 53 mm 290 mm x 228 mm x 53 mm
Installation Panel Mouting Panel Mounting, VESA (75 x 75)
Mounting
Ingress protection Front panel : IP65
Environmental
Operating temperature -25 ~ +75 ℃
Storage temperature
-30 ~ +80 ℃
Ambient relative humidity 10 ~ 90 % RH (non-condensing)

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 9
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1.3. Dimension
TPM-4100

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 10
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 11
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
TP-4100

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 12
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 13
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1.4. I/O interfaces
TPM-4100
TP-4100

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 14
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1.5. Companion CD
This package comes with a CD that provides a collection of the documentation and
drivers. All of them are listed below.
Driver
Win_XP_7
Windows 2k/XP/2003/2008/Vista/7 touch driver
Touch driver for XP-8000 series
Touch driver for WP-8000 and WP-5000 series
Document
Touch_Panel_User_Manual_v100.pdf
Other XP Embedded device
V5.0
Other CE5.0 device
WP-8000 and WP-5000 device
Touch driver
Other CE6.0 device
XP-8000-CE6 device
Touch driver for XP-8000-CE6 series
Touch driver
Touch driver
CD:\TPM-4100_TP-4100
Win_XP_Embedded
XP-8000 device
WinCE
V6.0

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 15
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1.6. System Setup
This section details the systems adjustment and how to mount.
1.6.1. System Configuration
Front Panel Controls
Control Function
1 Adjust V-Position,H-Position,
Clock and Clock and Clock-Phase
2
Turn on/off OSD main menu
3
Select adjustment item
4
Select adjustment item counter-clockwise
1
2
3
4
5
6
TPM-4100
TP-4100

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 16
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
5
Decrease value of the adjustment item
6 1. Increase value of the adjustment item
2. Enter the adjustment item
OSD Menu Functions
Control
Description
Contrast
Adjust monitor’s contrast
Brightness
Adjust monitor’s brightness
Image setting
Auto config
Press to adjust automatically.
Phase
Increase or decrease the snow noise of the
image after auto adjustment is made.
Clock
The dot clock is fine-adjusted after auto
adjusts.
H-position
Move the screen left or right
V-position
Moves the screen up or down
Color setting NATIVE Color temperature
9300K Color temperature
6500K Color temperature
USER Making adjustments to the R/G/B content.
OSD setting Language
Support 8 languages.
OSD.H Move the OSD position horizontally on the
screen. When the ▲button is pressed, the
OSD control menu will move to the right side of
the screen. Likewise, when the ▼button is
pressed, the OSD control menu will move to the
left side.
OSD.V Move the OSD position vertically on the
screen. When the ▲button is pressed, the
OSD control menu will move to the top side of the
screen. Likewise, when the ▼button is pressed,
the OSD control menu will move to the lower side.

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 17
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
Data and Power LED
Data and Power LED are in top right corner.
Data LED: When the light is green, it represents no display signal.
Power LED: When the light is red, the power is on. When the light is dark, the power
is off.
Display mode__
Resolution
Hori. Sync
Vert. Sync
640 x 480
31.4 KHz
50 Hz
31.4 KHz
59.9 Hz
37.5 KHz
75 Hz
720 x 400
31.4 KHz
70 Hz
800 x 600
35.1 KHz
56.2 Hz
37.8 KHz
60.3 Hz
46.9 KHz
75 Hz
1024 x 768
48.3 KHz
60 Hz
56.4 KHz
70 Hz
60.0 KHz
75 Hz

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 18
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
1.6.2. Panel Mounting
Insert the mounting brackets.
Screw the mounting bracket
to the unit.
Eight places can be chosen at will to put
four mounting clamps to tighten the unit.

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 19
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
Refer the Sec.1.3 for the
dimension.
Panel thickness up to 6 mm.

TPM-4100/TP-4100 Touch Panel Monitor User Manual, version 1.0.0,Last Revised: June 2012 Page: 20
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [e-mail]
2. Touch Driver Installation
This chapter provides a guided tour
that describes the steps needed to
install, uninstall, configure for touch
driver.
