ICPDAS TPD Mx Series User manual

Technical support: servic[email protected] P1
TPD-280/283/283U-Mx Series
Quick Start
v1.1, Jan. 2019
What’s in the box?
Related Information
Thanks for buying ICPDAS TPD 2.8 inch Mx Series device. This
shipping package contains the following items:
TPD-280/283/283U-Mx
Series x 1
Quick Start x 1
(This Document)
If you are new to TPD-280/283/283U-Mx Series, please read the
“Chapter 3. Getting Started”
of the TouchPAD Hardware User
Manual for detailed information about install the free development
tool –HMIWorks and how to create your first project.
Documents, such as the User Manuals, the API References,
etc.: http://ftp.icpdas.com/pub/cd/touchpad/document/
Free Development Software, HMIWorks v2.10.10 or above:
http://ftp.icpdas.com/pub/cd/touchpad/setup/
If you have any questions, please feel free to contact us via email.

Technical support: servic[email protected] P2
1 Appearance
Front View TPD-280-Mx Rear View
TPD-283-Mx Rear View TPD-283U-Mx Rear View
2 Pin Assignments
On the back of the TPD-280/283U-Mx
No
Pin
Description
0
F.G.
Frame Ground. F.G. is connected to the inside EMI or
ESD suppression circuits. Make sure that F.G. is
connected to the Earth
1
VDC
DC input Voltage (range: +12 V ~ +48 V)
2
GND
Connected to the power supply’s ground pin
3
Data+
The positive data line of the RS-485 network
4
Data-
The negative data line of the RS-485 network
Rotary Switch
Ethernet
2.8”TFT LCD
with Touch
Panel
RS-485
Rotary
Switch
RS-485
Rotary Switch
Ethernet
USB

Technical support: servic[email protected] P3
3 Rotary Switch & Default Settings
The definition of the rotary switch (TPD-280-Mx):
No
Mode
Description
0
Run Only
Run the program. (Default)
1
Update Only
This mode is used for updating programs.
The definition of the rotary switch (TPD-283-Mx):
No
Mode
Description
0
Run &
Update
Run or update the program. This mode is
used in the development phase. (Default)
1
Force
Update
While the application run on the TouchPAD
device seriously crashes, use this mode to
update a new application to the TouchPAD
device through Ethernet.
2
Run Only
Run the program.
The definition of the rotary switch (TPD-283U-Mx):
No
Mode
Description
0
Run &
Update
(Ethernet)
This is a special run mode which is used in
the development stage. The TouchPAD
device can be updated by a PC from the
remote side through Ethernet. (Default)
1
Ethernet
Force
Update
While the application run on the TouchPAD
device seriously crashes, use this mode to
update a new application to the TouchPAD
device through Ethernet.
2
Run Only
Run the program.
9
USB Force
Update
Update a new application to the TouchPAD
device through USB.
Network Default Settings (TPD-283/283U-Mx):
IP Address
192.168.255.1
Subnet Mask
255.255.0.0
Gateway
192.168.0.1

Technical support: servic[email protected] P4
4 First Use of the TPD 2.8” Mx Series
1. Connect wires as the below figure or
prepare an Ethernet cable which will be used
to supply power through PoE if there’s a
RJ-45 Ethernet port on it. And set the rotary
switch to 0 (At this point, the power is not yet
supplied).
2. Supply power to the TPD-280/283/283U-Mx,
wait for several seconds and then you can see
the default program run on it.
3. Try to touch on the icons on the bottom-right
corner of the screen of the TPD-280/283/283U-Mx and you can find that
TPD-280/283/283U-Mx switches to the setting pages.
5 Hardware Installation
PoE Switch
Outlet Box, OB120 (optional)
External Power
Use a flat-head screwdriver to
set rotary switch
(TPD-283/283U-Mx only)
GND
VDC
(+12-+48 V)
(TPD-280/283U-Mx only)

Technical support: servic[email protected] P5
TPD-280/283/283U-Mx 系列
快速入門指南
v1.1, 2019年1月
檢查配件
參考資訊
感謝您購買泓格的
TPD 2.8
吋
Mx
系列產品。產品包裝內應包含下列
配件:
TPD-280/283/283U-Mx 系列 x 1
產品須知 x 1(本文件)
如果您是第一次使用
TPD-280/283/283U-Mx系列，請參閱
TouchPAD
硬體使用手冊的
“第3 章啟動 TouchPAD” 來了解如何安裝免費的
開發軟體
HMIWorks 並建立第一個專案以及更多詳細的相關資訊。
相關文件，如使用手冊、應用程式介面指南(API Reference) 等:
http://ftp.icpdas.com/pub/cd/touchpad/document/
免費開發軟體，HMIWorks 版本 2.10.10 或以上版本:
http://ftp.icpdas.com/pub/cd/touchpad/setup/
如有任何問題歡迎使用
E-mail
聯繫我們，我們將會為您提供完善的咨
詢服務
。

Technical support: servic[email protected] P6
1 外觀
前配置圖 TPD-280-Mx 後配置圖
TPD-283-Mx 後配置圖 TPD-283U-Mx 後配置圖
2 腳位定義
在TPD-280/283U-Mx 的背面可見到如右圖
No
Pin
說明
0
F.G.
機架接地，F.G. (連接到內部的 EMI 或ESD 保護電路)，
請接到大地
1
VDC
直流電壓輸入 (範圍：+12 V ~ +48 V)
2
GND
連到電源的接地端
3
Data+
RS-485 網路的正訊號線
4
Data-
RS-485 網路的負訊號線
2.8吋觸控
液晶螢幕
旋轉開關
旋轉開關
Ethernet
RS-485
RS-485
Ethernet
USB
旋轉開關

Technical support: servic[email protected] P7
3 旋轉開關及出廠預設值
TPD-280-Mx 旋轉開關的配置模式定義:
No
模式
說明
0
Run Only
執行程式。(出廠預設)
1
Update Only
更新程式。
TPD-283-Mx 旋轉開關的配置模式定義:
No
模式
說明
0
Run & Update
執行/更新程式，用於程式開發階段 (能
執行程式，也能進行更新)。(出廠預設)
1
Force Update
強制更新，當程式異常而無法進入上述
更新時可用此模式更新。
2
Run Only
執行程式。
TPD-283U-Mx 旋轉開關的配置模式定義:
No
模式
說明
0
Run & Update
(Ethernet)
執行/更新程式，用於程式開發階段 (能
執行程式，也能進行更新)。(出廠預設)
1
Ethernet Force
Update
強制更新，當 TouchPAD 上的程式嚴
重毀損時可用此模式透過 Ethernet 更
新。
2
Run Only
執行程式。
9
USB Force
Update
透過 USB 更新程式。
網路設定出廠預設如下表 (TPD-283/283U-Mx):
IP Address
192.168.255.1
Subnet Mask
255.255.0.0
Gateway
192.168.0.1

Technical support: servic[email protected] P8
4 第一次使用 TPD 2.8” Mx 系列
1. 如左圖所示，將電源和接地線連接完成。
或是若有 RJ-45 的乙太網路接孔，可以準備
一條網路線，透過乙太網路供電 (PoE)。然
後將旋轉開關(Rotary Switch) 轉到 0 (此時
尚未供電)。
2. 開始供電給 TPD-280/283/283U-Mx，等待約數秒
的開機時間，接著可以看到 TPD-280/283/283U-Mx
執行出貨預附的程式如右圖所示。
3. 試著按一下 TPD-280/283/283U-Mx 螢幕上面的圖示，TPD-280/283/283U-Mx
會切到其他的頁面。
5 硬體安裝
乙太網路供電
使用一字起子來配置旋轉開關
安裝於專用暗盒 OB120 (選購)
外部供電器
(TPD-283/283U-Mx 適用)
(TPD-280/283U-Mx 適用)
GND
VDC
(+12-+48 V)
