ICS 680ES User manual

© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
680ES
OPERATOR MANUAL
WARNING: READ AND UNDERSTAND ALL SAFETY WARNINGS
AND ALL INSTRUCTIONS BEFORE YOU USE THIS EQUIPMENT.
Failure to follow the warnings and instructions may result in re, serious injury, or death.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
Original Document

680ES OPERATOR MANUAL
2
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
This instruction manual contains translations of a manual drafted in English and
are provided to assist those who do not speak English as their rst language.
Being a technical writing, some terms may not have a like or equivalent meaning
as translated. Therefore, you should not rely on this translation, and should
cross-reference the English version, where relying on the translated instructions
could result in harm to your person or property.

680ES OPERATOR MANUAL
3
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
TABLE OF CONTENTS
SYMBOLS AND LABELS
ICS 680ES NAMES AND TERMS
PRODUCT IDENTIFICATION
INTRODUCTION
SAFETY RULES
UNPACKING AND ASSEMBLY
FUELING
OPERATION
TRANSPORTING & STORING
MAINTENANCE
TROUBLESHOOTING
REFERENCE
EMISSIONS
TECHNICAL SPECIFICATIONS
SERVICE CENTERS
DECLARATION OF CONFORMITY
4
7
9
10
11
15
22
25
36
37
45
46
47
49
50
51
Table of Contents

680ES OPERATOR MANUAL
4
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
SYMBOLS AND LABELS
THE FOLLOWING SYMBOLS ARE FOUND THROUGHOUT THIS MANUAL
AND/OR ON THE SAW AND ARE DESIGNED TO MAKE YOU AWARE OF POTENTIAL
HAZARDS OR UNSAFE PRACTICES.
Symbols & Labels
SAFETY ALERT
Indicates that the text that
follows explains a danger,
warning or caution.
READ INSTRUCTIONS
The original instruction manual
contains important safety and
operating information. Read and
follow the instructions carefully.
WEAR LONG PANTS
Wear long pants when operating
the saw.
WEAR FOOT PROTECTION
Wear appropriate closed-toe
boots when operating the saw.
WEAR HAND PROTECTION
Wear hand protection when
operating the saw.
KERF WIDTH
Do not insert tool into slot
narrower than chain.
VENTILLATION REQUIRED
Use tool in a well ventillated area
WEAR EYE, HEARING AND
RESPIRATORY PROTECTION
WEAR HEAD PROTECTION
Wear eye , hearing
and respiratory protection and a
protective helmet when
operating the saw.

680ES OPERATOR MANUAL
5
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
SYMBOLS AND LABELS
THE FOLLOWING SYMBOLS ARE FOUND THROUGHOUT THIS MANUAL
AND/OR ON THE SAW AND ARE DESIGNED TO MAKE YOU AWARE OF POTENTIAL
HAZARDS OR UNSAFE PRACTICES.
SOUND POWER
Sound power level is 117 dB(A).
Symbols & Labels
DO NOT USE A LADDER
Never stand on a ladder when
using the saw.
FIRE DANGER
Risk of re if warnings not
followed.
SLIPPERY SURFACE
Unsure footing can lead to
accidents.
ONE-HANDED HOLD
Do not operate the saw
with one hand.
BEWARE OF KICKBACK
Kickback can cause severe
injuries.
TWO-HANDED HOLD
Operate the saw with two hands,
securely gripping both handles

680ES OPERATOR MANUAL
6
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
LABELS ON YOUR SAW
EMISSIONS LABELS
NAMEPLATE LABEL
Symbols & Labels
SAFETY LABEL
XXXX = Indicates the saw number
within production series
WW = Week number
within the year
Y = Last Digit of the
year the saw was built
LABELS SHOWN FOR REFERENCE ONLY
ICS, Blount, Inc.
4909 SE Int.Way Portland
OR 97222 USA
IMPORTANT ENGINE INFORMATION
THIS ENGINE MEETS U.S. EPA EXH REGS
FOR 2015 MY.
EMISSIONS COMPLIANCE PERIOD: 50
HOURS REFER TO OWNER’S MANUAL FOR
MAINTENANCE SPECIFICATIONS AND
ADJUSTMENTS. MADE IN ITALY
MANUFACTURED:
FAMILY: FE8XS.0775CS
ENGINE DISP.: 76.5CC TWC

680ES OPERATOR MANUAL
7
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Names & Terms
ICS 680ES NAMES AND TERMS
Air box intake
The only entry point of air into the engine
Bar pad
The mounting pad on the powerhead that helps assure proper alignment of the
guidebar.
Bar slot
The slot feature on the guidebar that ts over the bar studs.
Bystander safety zone
A 6 m (20 ft) circle around the operator that must remain free from bystanders,
children and pets.
Chain catcher
A device for retaining the chain if it breaks or derails.
Chain pitch
The distance between any three consecutive rivets on the chain divided by
two.
Chain tensioning screw
An adjustment screw used to set proper tension on the chain and compensate
for chain stretch from normal use.
Front handle
The support handle located at or toward the front of the saw intended to be
gripped by the left hand.
Guidebar
A railed structure that supports and guides the chain. Sometimes simply called
the “bar”.
Kickback
The rapid backward and/or upward motion of the guidebar, occurring when the
chain near the top area of the nose of the guidebar contacts a foreign object or
snags in the workpiece.
Multi-function lever
A device for setting the choke and temporarily advancing the throttle in a
partially open position to aid starting, allows the engine to run or causes the
engine to stop.
Mud ap
A barrier to protect the operator from cutting debris and other projectiles.

680ES OPERATOR MANUAL
8
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Names & Terms
ICS680ES NAMES AND TERMS
Powerhead
A saw without the chain or guidebar.
Pushback
The rapid backward motion of the guidebar, occurring when the chain on
the top straight portion of the guidebar contacts a foreign object or
snags in the workpiece.
Rear handle
The support handle located at or toward the rear of the saw intended to be
gripped by the right hand.
Rear hand guard:
A structural barrier at the bottom right side of the rear handle to protect the
operator in case the chain breaks or derails.
Side cover:
The component on the powerhead that covers the drive sprocket and directs
debris away from the operator during use.
Side cover nuts:
The components on the side cover that secure the side cover and guidebar.
Throttle trigger lock-out
A device that prevents the unintentional operation of the throttle trigger until
manually released.
Throttle trigger
A mechanism that controls engine RPM.
WallWalker®
A device used as a fulcrum to provide mechanical advantage during cutting.
Water shut-o valve
A mechanism that controls water delivery and ow to the guidebar and chain.

680ES OPERATOR MANUAL
9
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Product Identication
PRODUCT IDENTIFICATION
Chain tensioning screw
Front handle
Fuel filler cap
Multi-function lever
Rear handle
Starter handle
Water shut
off valve
Air box intake
Bar slot
Bar stud
Chain catcher
WallWalker®
Guidebar
Mud flap
Powerhead
Rear hand guard
Nameplate label
Side cover
Side cover nuts
Throttle trigger
lock-out
Throttle trigger

680ES OPERATOR MANUAL
10
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
INTRODUCTION
The 680ES saw is designed to cut concrete, stone, and masonry when used with
the appropriate genuine ICS Diamond Chain. This is a professional tool and is
solely intended for use by trained and experienced operators. A rst time
operator should obtain practical instruction before using the saw, as well as reading
and understanding this Operator’s Manual.
Local legislation and/or workplace standards may regulate the use of this saw.
Determine what regulations are applicable in the place you work before using the
saw.
Prop 65 statement:
California Proposition 65 (the Safe Drinking Water and Toxic Enforcement Act of
1986) refers to the California legislation that was intended by its authors to protect
California citizens and the State’s drinking water sources from chemicals known
to cause cancer, birth defects or other reproductive harm, and to inform citizens
about exposures to such chemicals. Proposition 65 requires businesses to notify
Californians about signicant amounts of chemicals in the products they purchase,
in their homes or workplaces, or that are released into the environment. By
providing this information, Proposition 65 enables Californians to make informed
decisions about protecting themselves from exposure to these chemicals.
Proposition 65 also prohibits California businesses from knowingly discharging
signicant amounts of listed chemicals into sources of drinking water.
The engine exhaust from this machine and some types of dust/debris created from
its normal operation may contain chemicals known to the State of California to
cause cancer, birth defects, or other reproductive harm.
Introduction

680ES OPERATOR MANUAL
11
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
SAFETY RULES
To get the maximum benet from your saw, and assure maximum safety, be sure to
read this manual thoroughly and follow the safety instructions provided.
EXPLANATION OF WARNING LEVELS
IMPORTANT
Indicates a hazard with a medium level of risk which, if not avoided, could result in
death or serious injury.
Indicates a hazard with a low level of risk which, if not avoided, could result in minor
or moderate injury.
Indicates a potential situation exists which, if not avoided, may result in damage to
your saw or property.
Indicates a hazard with a high level of risk which, if not avoided, will result in death or
serious injury.
WARNING
CAUTION
DANGER
Safety Rules

680ES OPERATOR MANUAL
12
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Safety Rules
HANDLING FUEL SAFELY
Check saw for fuel leaks before starting.
Check regularly for leaks from the fuel cap and fuel lines and do not start saw if any
leaks are found.
Avoid spilling fuel on yourself or on the saw.
Use only approved containers to transport and store fuel. If fuel is spilled on the
saw, wipe up the spillage and allow the rest to evaporate. If fuel is spilled on
yourself or your clothes, immediately remove contaminated clothing and wash any
part of your body that has contacted fuel with soap and warm water.
Fuel vapors are highly ammable.
Turn o the saw, assure that the multi-function lever is set in the “STOP” position,
and allow the engine to cool a few minutes before fueling. Do not smoke or refuel
the saw in close proximity to any ignition sources. Move the saw at least 3 m (10 ft)
from the fueling area before restarting it.
WARNING
CAUTION
WORK AREA SAFETY
Keep children and bystanders away from work area.
Set up a well-marked safety zone with a roped boundary and clear signs to keep
bystanders at least 6 m (20 ft) away.
Remove or control slurry to prevent slippery conditions while cutting.
This saw uses water and can cause slippery surfaces due to the slurry
produced and/or freezing temperatures.
Drugs or alcohol can impair vision, dexterity, and judgment.
Do not operate the saw when tired or under the inuence of any substance.
Breathing exhaust gases can cause asphyxiation and carbon monoxide
poisoning in high concentrations.
Use the saw only in a well-ventilated area.
DANGER
WARNING
CAUTION
Following are the basic instructions to assure work area safety.

680ES OPERATOR MANUAL
13
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Safety Rules
PERSONAL SAFETY
Always wear protective clothing.
At a minimum always wear eye protection and/or face shield, hearing protection,
long sleeve shirt, long pants, closed toe shoes with non-slip soles, and gloves. In
many work situations, a hard hat and steel toed shoes may also be required. Avoid
loose tting clothing.
This saw can generate hazardous dust and vapors.
Determine the nature of the material you are going to cut before proceeding with
the job. Be especially aware of cutting materials containing silica and asbestos
as inhaling dust can result in respiratory disease. Be sure to use appropriate
respiratory protection designed to lter out microscopic particles. Be sure to use
adequate water pressure.
Over-exposure to vibration can lead to circulatory and/or nerve damage to the
extremities, especially in cold temperatures (Reynaud’s Disease).
If you experience tingling, numbness, pain or changes in skin color, particularly in
your ngers, hands or wrists, stop using the saw immediately. If the problem
persists, seek medical attention.
Following are the basic instructions to assure personal safety.
WARNING
Long-term exposure to noise can result in permanent hearing impairment.
Always wear approved hearing protection.
This machine produces an electromagnetic eld during operation.
This eld may under some circumstances interfere with active or passive medical
implants. To reduce the risk of serious or fatal injury, we recommend persons with
medical implants consult their physician and the medical implant manufacturer
before operating this machine.

680ES OPERATOR MANUAL
14
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Safety Rules
USING THE ICS SAW SAFELY
Following are the basic instructions to assure safe use of the saw. Also read and
understand additional safety precautions specic to the operation and
maintenance of the saw throughout this manual.
DO NOT operate the ICS saw with a saw chain or saw bar designed to cut
wood. Using wood cutting saw chain on the ICS saw could result in severe injuries
to the operator or a bystander! Use ONLY the cutting attachments specied in this
manual on this saw.
DO NOT operate the saw with damaged, modied, broken, or missing
components.
Below safety features are designed to protect against contact with moving parts,
ejected debris, broken chain, thrown water, and concrete slurry.
• Side cover
• Mud ap
• Mud ap bracket (Chain Catcher)
• Rear hand guard
• Throttle trigger interlock
Use only Genuine ICS replacement parts. Use of unauthorized aftermarket parts
may result in injury or damage to the saw.
DO NOT insert the guidebar into a slot narrower than the width of the chain.
Rapid pushback, kickback and/or chain breakage could result.
DO NOT operate the saw without an adequate water supply.
The integral water supply channels in the guidebar act to cool and lubricate the
cutting system as well as to suppress dust and debris generated during cutting.
Assure that the water supply is capable of delivering 1.5 bar (20 psi) pressure to the
saw at a minimum ow rate of 4 lpm (1 gpm).
WARNING
DANGER
Never attempt to cut ductile iron pipe or similar pipe materials with the saw
unless using PowerGrit® Utility Saw Chain.
Using concrete saw chain in these applications can cause the chain to snag
abruptly in the cut which may result in chain breakage, pushback and/or kickback.

680ES OPERATOR MANUAL
15
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
BOX CONTENTS
Minimum contents for all packages shown. Some packages also contain
guidebar and diamond chain.
See page 44 for listing of compatible guidebars and diamond chain.
Unpacking & Assembly
GUIDEBAR AND DIAMOND CHAIN
INSTALLATION & TENSIONING
Following are the basic instructions for guidebar and diamond chain installation
and tensioning.
Never perform any maintenance or adjustments on the saw while the engine is
running.
Be sure the multi-function lever is set to the “STOP” position before proceeding.
Improper chain tension can lead to failure of the chain or derailing of the chain
o of the guidebar.
Check tension frequently and adjust if drive links of chain hang 18 mm (3/4 in) or
more below the guidebar groove
Always wear gloves when handling the bar and chain.
These components can develop sharp edges and cause cuts.
WARNING
CAUTION

680ES OPERATOR MANUAL
16
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
GUIDEBAR AND DIAMOND CHAIN INSTALLATION & TENSIONING
Unpacking & Assembly
STEP 1
Loosen side cover nuts and remove side cover.
STEP 2
Remove shipping spacer.

680ES OPERATOR MANUAL
17
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Unpacking & Assembly
GUIDEBAR AND DIAMOND CHAIN INSTALLATION & TENSIONING
STEP 4
Mount the diamond chain on the guidebar starting
at the drive sprocket and continue over the
guidebar nose.
STEP 3
Place guidebar onto studs and tensioning
adjustment pin.

680ES OPERATOR MANUAL
18
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
GUIDEBAR AND DIAMOND CHAIN INSTALLATION & TENSIONING
Unpacking & Assembly
STEP 5
Install the side cover and nuts. Do not fully tighten
side cover nuts until chain is properly tensioned.
STEP 6
Make sure all the drive links are inside the guidebar
groove then lift the bar nose and tension the chain
by turning the tensioning screw clockwise.

680ES OPERATOR MANUAL
19
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
Unpacking & Assembly
GUIDEBAR AND DIAMOND CHAIN INSTALLATION & TENSIONING
CHAIN TOO TIGHT CHAIN TOO LOOSE
STEP 7
Check for proper tension by pulling the chain around the bar by hand.
If you cannot easily pull by hand, the chain is too tight and needs to be
loosened slightly.
CAUTION: Be aware that the guidebar rails may develop sharp edges
over time so always pull the diamond chain by the diamond segments.
STEP 8
Continue to lift up on the nose of the guidebar and firmly tighten the
side cover nuts.
NOTE: To prevent chain tensioner breakage, be sure the side cover
nuts are tightened to approximately 27 Nm (20 ft-lbs).

680ES OPERATOR MANUAL
20
© 2015 ICS®, Blount International Inc. Specications are subject to
change without notice. REV071315 F/N 577451
CHECKING & ADJUSTING CHAIN TENSION
Unpacking & Assembly
All chains have a tendency to stretch when used. Diamond chains stretch more
than wood cutting chains because of the abrasive materials they are cutting.
Assure that proper chain tension is maintained.
If tension is set too tight, it will lead to excessive chain stretch, and most of the
saw’s power will be used just to overcome friction. In severe cases the chain may
not turn at all, and can lead to chain breakage. If the tension is set too loose, the
chain could be thrown o of the bar, or allow the sprocket to turn without turning
the chain, which will damage the drive links.
When a chain stretches to a point where the drive links are hanging approximately
12 mm (1/2 in) to 18 mm (3/4 in) below the guidebar groove, it is time to tension
the chain.
IMPORTANT
WARNING
CAUTION
Improper chain tension can lead to failure of the chain or derailing of the chain
o of the guidebar.
Check chain tension frequently and adjust if drive links of chain hang 18 mm (3/4 in)
or more below the guidebar.
