IDEAL Bikes TARGET User manual

BMIBEN22V01
InstructIons for use
EN 4210

IDEAL BIKES is a brand of NIKOS MANIATOPOULOS S.A.
NIKOS MANIATOPOULOS S.A.
INDUSTRIAL & TRADING CYCLE COMPANY
Kosti Palama & Solonos Str., Agios Vasileios,
26504 Patras, Greece
Tel.: [phone] | Fax: [phone] | Email: [e-mail]
© 2022 NIKOS MANIATOPOULOS S.A. | Subject to changes.
NIKOS MANIATOPOULOS S.A. is not liable for technical or editorial errors.
Contents
PlusDocu GmbH
Stralauer Platz 34, 10243 Berlin, Germany
inf[email protected] | www.plusdocu.com
© Copyright
Text, pictures and information are protected by copyright and are subject to the
copyright terms of PlusDocu GmbH.
Duplication, reproduction, translation and any other kind of commercial use of this
documentation, in whole or in part, in printed or electronic form, is only permitted
with prior written approval.

FRAME
ATop tube ESeat stay
BHead tube FSeat tube
CDown tube GSuspension fork/fork
DChainstay
A
B
C
D
G
EF

OVERVIEW
4
TARGET
1Handlebar with operating elements 7Pedal drive
2Handlebar stem 8Derailleur system
3Cables/hydraulic cables 9Rear wheel
4Front wheel 10 Rear disc brake
5Front disc brake 11 Seat post quick-release clamp
6Front wheel hub 12 Saddle with seat post
2
3
1
5
4
6
7
8
11
12
10
9

5
OVERVIEW
TRAVELON
1Handlebar with operating elements 10 Derailleur system
2Handlebar stem 11 Stand
3Cables/hydraulic cables 12 Rear wheel
4Headlight 13 Rear disc brake
5Front mudguard 14 Rear mudguard
6Front wheel 15 Rear light with reflector
7Front disc brake 16 Carrier
8Front wheel hub/hub dynamo 17 Seat post quick-release clamp
9Pedal drive 18 Saddle with seat post
1
2
3
4
7
5
6
8
9
10
11
16
17
18
13
14
15
12

TABLE OF CONTENTS
6
OVERVIEW 3
Frame...................................................................................................................................... 3
TARGET.................................................................................................................................... 4
MULTIGO................................................................................................................................. 5
ABOUT THESE INSTRUCTIONS 10
1 Reading and storing these instructions ........................................................................ 10
2 Applicable documents................................................................................................... 11
3 Labelling and meanings of safety notices and warnings .............................................. 11
3.1 Presentation and layout.....................................................................................................12
3.2 Hazard classification ..........................................................................................................12
4 Explanation of symbols and signs ................................................................................. 13
5 Product marking ............................................................................................................ 14
SAFETY 15
6 Proper use...................................................................................................................... 15
7 Classification (classification for bicycles usage)............................................................ 16
8 Misuse............................................................................................................................ 18
9 Residual risks ................................................................................................................. 18
10 Safety notices ................................................................................................................ 19
10.1 General safety information................................................................................................19
10.2 Safety instructions for cycling in road traffic.....................................................................21
11 Maximum permitted total weight................................................................................. 22
12 Torques .......................................................................................................................... 23
12.1 Overview of tightening torques.........................................................................................25
13 Maintenance and wear ................................................................................................. 28
13.1 Wear...................................................................................................................................28
13.2 Replacing components ......................................................................................................29
14 Notes on components made of carbon........................................................................ 29
BEFORE FIRST USE 30
15 Familiarising yourself with the bicycle .......................................................................... 30
16 Checking the bicycle before you start riding................................................................. 30
17 Setting the optimum sitting position ............................................................................ 32

7
TABLE OF CONTENTS
PEDAL DRIVE 33
18 General information...................................................................................................... 33
19 Chain drive..................................................................................................................... 33
19.1 Method of operation and handling...................................................................................33
19.2 Wear and maintenance .....................................................................................................34
19.3 Cleaning and care ..............................................................................................................34
BRAKES 35
20 General information...................................................................................................... 35
21 Brake lever configuration .............................................................................................. 35
22 Warnings for using the brakes....................................................................................... 36
23 Disc brake....................................................................................................................... 38
23.1 Method of operation .........................................................................................................38
23.2 Warnings relating to the use of disc brakes ......................................................................39
23.3 Bedding in disc brakes .......................................................................................................41
24 Rim brake....................................................................................................................... 42
24.1 Method of operation .........................................................................................................42
24.2 Warnings relating to the use of rim brakes .......................................................................42
25 Operating the brake ...................................................................................................... 42
26 Checking the brake........................................................................................................ 43
27 Adjustments .................................................................................................................. 44
27.1 Adjusting the brake lever...................................................................................................44
28 Wear and maintenance................................................................................................. 45
29 Cleaning and care .......................................................................................................... 45
GEAR SHIFT SYSTEM 46
30 General information...................................................................................................... 46
31 Operating elements....................................................................................................... 47
32 Derailleur system........................................................................................................... 47
32.1 Method of operation .........................................................................................................47
32.2 Operating the derailleur system........................................................................................48
32.3 Checking the derailleur system .........................................................................................48
32.4 Wear and maintenance .....................................................................................................49
32.5 Cleaning and care ..............................................................................................................49
33 Hub shifting system ....................................................................................................... 50
33.1 Method of operation .........................................................................................................50
33.2 Operating the hub shifting system ....................................................................................50
33.3 Checking the hub shifting system......................................................................................50
33.4 Wear and maintenance .....................................................................................................51
33.5 Cleaning and care ..............................................................................................................51
34 Electronic gear shift system .......................................................................................... 51

TABLE OF CONTENTS
8
WHEELS 52
35 General information...................................................................................................... 52
35.1 Rims and spokes.................................................................................................................53
35.2 Tyre types...........................................................................................................................54
35.3 Valve types .........................................................................................................................54
35.4 Tyre pressure......................................................................................................................55
36 Pumping up tyres........................................................................................................... 55
37 Regular checks............................................................................................................... 56
SADDLE 57
38 Adjusting the saddle...................................................................................................... 57
38.1 Adjusting the saddle height...............................................................................................58
38.2 Adjusting the saddle position............................................................................................59
HANDLEBAR 60
39 Adjusting the handlebar................................................................................................ 60
SUSPENSION FORK 61
40 General information...................................................................................................... 61
40.1 Method of operation and terms .......................................................................................62
40.2 Spring tension and lock-out function ................................................................................63
40.3 Wear and maintenance .....................................................................................................64
40.4 Cleaning and care ..............................................................................................................64
OTHER COMPONENTS 65
41 Lights.............................................................................................................................. 65
41.1 General information ..........................................................................................................65
41.2 Mounting points ................................................................................................................65
41.3 Switching the lights on and off ..........................................................................................66
42 Quick-release clamp ...................................................................................................... 67
43 Bell .................................................................................................................................68
44 Carrier............................................................................................................................ 69
45 Stand.............................................................................................................................. 70
STORAGE AND TRANSPORTATION 71
46 Storage of the bicycle .................................................................................................... 71
47 Transport of the bicycle................................................................................................. 71

9
TABLE OF CONTENTS
DISPOSAL 72
HOW TO HANDLE THE BICYCLE 73
48 Overview of the operating steps................................................................................... 73
48.1 Preparation ........................................................................................................................73
48.2 Using the bicycle................................................................................................................74
48.3 Cleaning and maintaining the bicycle ...............................................................................74
48.4 Regularly checking the bicycle components.....................................................................75
49 After a fall....................................................................................................................... 75
50 Riding with children....................................................................................................... 76
51 Transporting baggage.................................................................................................... 76
51.1 Using carriers .....................................................................................................................77
WARRANTY CONDITIONS 78
MAINTENANCE PLAN 80
BICYCLE PASSPORT 82
HANDOVER CERTIFICATE 84
NOTES 85

ABOUT THESE INSTRUCTIONS
10
ABOUT THESE INSTRUCTIONS
1 Reading and storing these instructions
These Instructions for use – referred to in the following as the “instructions”
– are part of the scope of supply of this bicycle.
Whenever these instructions refer to the "bicycle" in general, they mean any
of the bicycle models described here.
All illustrations in these instructions are examples; as a result, individual details on your
bicycle may differ from those shown in these instructions.
These instructions contain all of the important information on safety and use of your bicycle.
They are based on the standards that apply in the European Union.
Before using your bicycle for the first time, please read these instructions and all applicable
manufacturer's component instructions, especially safety notices, carefully and completely.
If you do not follow these instructions and all other applicable manufacturer's component
instructions, you or other persons could be injured and/or cause damage to property.
Always keep these instructions and all applicable manufacturer's component instructions
on hand for further use.
If you pass on the bicycle to a third party, it is essential that you include these instructions
and all applicable manufacturer's component instructions.
You can download a copy of these instructions in PDF format from the manufacturer’s
website.

11
ABOUT THESE INSTRUCTIONS
2 Applicable documents
In addition to these instructions, always observe the additionally applicable manufacturer's
instructions for the components installed on your bicycle.
Any manufacturer's instructions for other components enclosed with these instructions
must also be observed. For example:
-Brakes
-Suspension fork and rear suspension
-Gear shift system
-Hubs/quick-release clamps
-etc.
As a supplement to these instructions, these manufacturer's component instructions form
an essential part of the scope of the technical documentation for this bicycle.
If you have not received separate manufacturer's component instructions, please contact
the manufacturer of your bicycle to ask for a copy.
3 Labelling and meanings of safety notices and warnings
Safety notices and warnings describe hazards that could occur when handling or using the
bicycle, and provide instructions on how to avoid such hazards.
The safety notices are summarised in the "SAFETY" section.
Warnings are placed next to the step or process from where the potential hazard arises.
In order to use the bicycle safely, it is imperative to heed the safety notices and warnings.
Therefore, you must read through all the safety notices and warnings very carefully and take
the contents on board in order to avoid risks when handling and using the bicycle. Safety
notices and warnings are indicated as follows in these instructions, based on the possible
consequences of failure to observe them.

ABOUT THESE INSTRUCTIONS
12
3.1 Presentation and layout
SIGNAL WORD
Type and source of hazard

»Measures to prevent the hazard.
3.2 Hazard classification
DANGER
»The signal word “Danger” indicates a hazard with a high degree of risk: failure
to comply with the safety notices and warnings in this category will result in a
fatal or serious injury.
WARNING
»The signal word “Warning” indicates a hazard with a medium degree of risk:
failure to comply with the safety notices and warnings in this category can result
in a fatal or serious injury.
CAUTION
»The signal word “Caution” indicates a hazard with a moderate degree of risk:
failure to comply with the safety notices and warning notices in this category
may result in moderate or minor injuries.
NOTE
»The signal word “Note” indicates a hazard that can lead to damage to property:
Failure to comply with the safety notices and warnings in this category may
damage the bicycle or cause other damage to property.

13
ABOUT THESE INSTRUCTIONS
4 Explanation of symbols and signs
You must read and observe the instructions.
This symbol indicates useful additional information on handling and using
the bicycle.
Marking for recyclable materials. Dispose of the packaging according to
the type of material. Dispose of card and cardboard in your waste paper
container and films in your plastic recyclables container.

ABOUT THESE INSTRUCTIONS
14
5 Product marking
Description of the product marking.
2
3
1
Fig. 1: 
1Name and address of manufacturer
2Maximum permitted total weight*
22
3ISO 4210-2 Cycles – Safety requirements for bicycles
*The maximum permitted total weight of the bicycle (sum of bicycle + cyclist + load) must never be exceeded.

15
SAFETY
SAFETY
6 Proper use
Neither the manufacturer nor the specialist dealer will accept liability for damage which
occurs due to improper use. Only use the bicycle in the manner described in these instruc-
tions. Any other use is considered improper and may lead to accidents, serious injury or
damage to the bicycle and its components.
The warranty will be rendered void in the event of improper use of the bicycle.
Fundamentally, the following applies:
-The bicycle is designed for one cyclist.
-The sitting position on the bicycle must be correctly adjusted according to the cyclist's
height.
-The maximum permitted total weight of the bicycle must not be exceeded 
22.
-Country-specific and regional regulations must be observed to comply with the
proper use of the bicycle in road traffic 
21.
-The bicycle is not approved for use with a child seat and/or trailer (child trailer, load
trailer, dog trailer, etc.). Observe the instructions in the bicycle passport. 
82.
Furthermore, the specific guidelines on proper use for the relevant classification for usage
of the bicycle also apply
16.
Possible examples of improper use are as follows:
-Using an unsuitable bicycle with a child seat and/or a trailer.

SAFETY
16
The classification corresponds to
".
Category Description applies to cycles and EPACs Typical range
∅speed
used on standard paved surfaces where the tyres
are intended to maintain contact with the ground at
average speed, with occasional drops.
15 km/h
to
25 km/h
includes condition 1 and also unpaved roads and
gravel trails with moderate gradients. In these
conditions, contact with irregular terrain and
repeated loss of tyre contact with the ground may
occur. Drops are intended to be limited to 15 cm or
less.
15 km/h
to
25 km/h
includes condition 1 and 2 as well as rough trails,
rough, unpaved roads and rough terrain and
unimproved roads that require technical skills. Jumps
and drops are intended to be less than 60 cm.
Not relevant
includes conditions 1, 2 and 3, or downhill gradients
on rough trails at speeds of less than 40 km/h. Jumps
are intended to be less than 120 cm.
Not relevant
7 

17
SAFETY
If you have specific questions about your model, please contact the manufacturer's Customer
Service department.
Max. drop/
jump height Intended use Cycle type (examples)
Recommended riding
skills
< 15 cm Commuting and leisure with
moderate effort
City bikes and
urban bikes
No specific riding
skills required
< 15 cm Leisure and trekking with
moderate effort
Trekking bike, travel
bike
No specific riding
skills required
< 60 cm
Sports and competitive
events with moderately
challenging technical trail
skills
Cross-country
and marathon
Requires technical
skills and practice
< 120 cm
Sports and competitive
events with highly
challenging technical trail
features
Mountain bikes, trail
bikes
Requires technical
skills, practice and
good riding control

SAFETY
18
8 Misuse
In order to use your bicycle safely, avoid the following instances of misuse:
• Use of the bicycle for competitions, jumps, stunts or tricks if the bicycle category (clas-
sification for usage) excludes such use;
• Incorrect repairs and maintenance.
• Structural changes to the delivery condition of the bicycle.
INFORMATION
Misuse of the bicycle can lead to the warranty becoming void.
9 Residual risks
Unavoidably, certain residual risks will remain when using the bicycle – despite a well-cal-
culated design by the manufacturer and compliance with the specifications for proper use
on the part of the user.
You yourself can reduce, but not completely eliminate, these residual risks by observing all
safety notices and warnings. It is therefore important that you are aware that residual risks
exist when using the bicycle.
The unpredictable residual risks when using the bicycle described here include:
• Unpredictable cycling manoeuvres and/or misconduct on the part of other road users;
• Distraction from the road traffic;
• Misjudging the road-holding capability and speed of the bicycle as well as your own
riding skills, for example;
• Surprising or sudden changes in road characteristics such as freezing rain or black ice;
• Unexpected material defects or signs of wear that can lead to components of the
bicycle breaking or being impaired in their function.

19
SAFETY
10 Safety notices
10.1 General safety information
WARNING
Risk of accident and injury!
             
reduce the general risk of accidents and injuries, you will expose yourself, and
possibly others, to an increased risk of serious injury.
»Only use your bicycle if you are familiar with handling it and its functions, and
always follow the instructions on the proper use of your bicycle.
»When using any approved special equipment or structures, please note that
doing so may alter how you handle your bicycle and adjust your cycling style
accordingly. When using recumbent or aero handlebars, access to the operating
elements may be restricted, for instance, and the stopping distance may be
longer than usual.
»Ride with foresight in order to recognise events early and to be able to react to
them.
»Always adapt your cycling style and speed to the current weather conditions
and road characteristics.
»Please note in particular that the braking distance can be longer and the tyres
have less grip on icy, wet, slippery or dirty roads.
»Pay attention to other road users and adopt a defensive cycling style.
»Always visually inspect your bicycle before using it. Make sure that your bicycle
or its components do not have any cracks, scoring, damage or colour changes.
»Make sure that safety-related devices on the bicycle (e.g. the brakes) are
correctly adjusted and functional.
»Never use your bicycle if safety-related components (e.g. the brakes) are
damaged or do not function properly.
»Under no circumstances should you arbitrarily exchange components on the
bicycle or make any changes or repairs to the bicycle or individual components.
Have any damage to the bicycle repaired by your specialist dealer and any
damaged components replaced only with suitable original spare parts.
»Contact your specialist dealer if you are unable to carry out work on the bicycle
described in the instructions yourself (e.g. making certain adjustments or similar
tasks), if you are unsure or if you do not have the correct tools.
»After an accident or fall or if your bicycle has been subjected to excessive loads,
contact your specialist dealer for a professional inspection of your bicycle.

SAFETY
20
CAUTION
Risk of injury when wearing unsuitable clothing!
Since moving parts of the bicycle are catching points for clothing, you can injure
yourself if you wear unsuitable clothing when using your bicycle.
»When cycling, wear tight-fitting legwear if possible instead of wide trousers,
dresses or skirts.
»Make sure that loose clothing cannot get caught in the moving parts of the
bicycle, for example, by using trouser clips.
»Make sure that no loose straps, laces or similar are hanging down.
»Wear shoes with non-slip soles to prevent your foot from slipping during
pedalling.
NOTE
Risk of damage due to improper use!
             
there is a risk that components may show signs of wear or break more quickly.
»Always observe the permitted total weight of the bicycle (including the cyclist
and any baggage). The permitted total weight must not be exceeded.
»Ensure that the tyre inflation pressure is set correctly and adjust it if necessary.
»Do not cycle through deep water unless such use is explicitly permitted according
to the proper use for your bicycle.
