Idex HURST eDRAULIC SC 258 E2 User manual

Instruction manual for rescue equipment
273023085 EN
(Original instruction manual)
replaces 07.2019
Edition 09.2019
eDRAULIC combi tools
SC 258 E2
SC 358 E2
SC 757 E2
SC 758 E2

2
Content Page
1. Dangerclassications 4
2. Productsafety 5
3. Intendeduse 9
4. Functionaldescription 11
4.1 Description 11
4.2 Structure of rescue devices 12
4.3 Hydraulic circuit diagram 13
4.4 Operating movement controls 13
5. Operation 13
5.1 Battery or power supply for eDRAULIC device 13
5.2 Operating the star grip 14
6. Cutting,spreading,pulling,squeezing 15
6.1 Safety notes 15
6.2 Cutting 16
6.3 Spreading 18
6.4 Pulling 20
6.5 Squeezing 24
7. Dismantlingtheequipment/deactivationfollowingoperation 25
8. Maintenanceandservice 25
8.1 Oil change 26
8.2 eDRAULIC combination tools 26
8.3 Protective equipment 27
 8.4 Checkingthelterinthebatteryshaft 27
9. Repairs 28
9.1 General information 28
9.2 Preventive service 29
9.3 Repairs 29

3
10.Troubleshooting 33
11.Technicaldata 35
11.1 eDRAULIC combination device 36
11.2 Noise emission (based on standard EN ISO 3744) 38
11.3 Operating and storage temperature ranges 38
11.4 Oscillation / vibration 38
11.5 Torques for central bolts 38
11.6 Cutting performance 39
12.Accessories 40
12.1 Batteries 40
12.2 Battery charger 41
12.3 Power supply 41
12.4 Chain sets 42
13.Instructionsregardingdisposal 42
14.Notes 43
Content Page

4
 Wearahelmetwithafaceguard.
 Wearprotectivegloves.
 Wearsafetyshoes
 Properrecycling
 Protecttheenvironment
 Readandfollowtheoperatinginstructions.
Wedi󰀨erentiatebetweenvariousdi󰀨erentcategoriesofsafetyinstructions.Thetableshown
belowprovidesanoverviewoftheassignmentofsymbols(pictograms)andsignalwordsto
thespecicdangerandthepossibleconsequences.
1. Danger classications
Pictogram Damage /
injury to Keyword Denition Consequences
Persons
DANGER! Immediatedanger Deathorsevere
injury
WARNING!
Potentially
dangerous
situation
Potentialdeathor
seriousinjury
CAUTION! Lessdangerous
situation
Minororslight
injury
Property
ATTENTION!
Riskofdamage
toproperty/
environment
Damagetothe
equipment,
damagetothe
environment,
damageto
surroundings
-NOTE
Handlingtipsand
otherimportant/
usefulinformation
andadvice
Noinjury/damage
topersons/
environment/
device

5
2. Product safety
HURST products are developed and manufactured to ensure the best performance and
qualitywhenusedasintended.
Thesafetyoftheoperatoristhemostimportantconsiderationinproductdesign.Furthermore,
theoperatinginstructionsareintendedtohelpyouuseHURSTproductssafely.
Thegenerallyapplicablelegalandotherbindingregulationspertainingtothepreventionof
accidentsandprotectionoftheenvironmentapplyandaretobecompliedwithinadditionto
theoperatinginstructions.
Theequipment,includingaccessories,mayonlybeoperatedbypersonsfamiliarwiththis
InstructionManualandwithappropriatetraining inthesafetyaspectsofsuchequipment,
otherwise,thereisariskofsevereinjuryordeath.
AlloperatorsshouldcarefullyreadandfollowthisInstructionManualandtheAkkuPower
GmbH Safety Instructions for eDRAULIC batteries, including all warnings, cautions and
informationcontained thereinbeforetheyattempttouseormaintaintheequipmentorits
accessories.Donotattempttoutilizeormaintaintheequipment,includinganyaccessories,
unlessyouhaveaqualifiedtrainershowyouhowtosafelyandproperlyusethisequipment.
The use and operation of the HURSTRescue equipment which is powered by lithium-
ionbatteries must comply with the Akku Power GmbH Safety Instructions for
eDRAULICbatterieswhichareincludedwiththebatteries.
Tosafelyoperateormaintaintheequipment,includingaccessories,youmustreadandfollow
thisInstructionManualandallaccessorymanuals,inadditiontoreceivingtheappropriate
safetytraining.
Pleaseensurethatnobody
partsorclothingarecaught
betweenthevisiblymoving
parts(e.g.bladearms).
Workingundersuspended
loadsisnotpermittedwhere
suchloadsarebeinglifted
onlybymeansofhydraulic
orelectro-hydraulicdevices.
Ifthisworkisunavoidable,
suitablemechanicalsupports
arealsorequired.
Wearprotectiveclothing,
asafetyhelmetwithvisor,
protectivefootwearand
gloves.
Inspectthedevicebeforeand
afteruseforvisibledefectsor
damage.
WARNING / CAUTION!
Pleaseensurethattheaccessoriesyouuseareappropriateforthemaximum
operatingpressureandtheperformanceoftheequipment!
WARNING / CAUTION!
Theoperatinginstructionsforaccessoriesmustbe followed!

6
Immediatelyreportany
changesthatoccur(including
changesinoperating
behavior)totheappropriate
persons/departments!If
necessary,theequipmentis
tobeshutdownimmediately
andsecured!
Allboltedconnectionsmust
becheckedforleaksand
externallyvisibledamage,
whichmustberepaired
immediately!Escaping
hydraulicuidcancause
injuriesandres.
Intheeventofmalfunction,
immediatelydeactivatethe
deviceandsecureit.Repair
thefaultimmediately.
Donotcarryoutanychanges
(additionsorconversions)
totheequipmentwithout
obtainingthepriorapprovalof
HURST.
Observeallsafetyanddanger
informationonthedeviceand
intheoperatinginstructions.
Allsafetyanddanger
instructionsonthedevice
mustalwaysbecompleteand
inalegiblecondition.
Anymodeofoperationwhich
compromisesthesafetyand/
orstabilityofthedeviceis
forbidden!
Repairstotheequipment
mayonlybecarriedoutby
atrainedservicetechnician
withspecicknowledgeofthe
device.
Safetydevicesmayneverbe
disabled!
OnlygenuineHURST
accessoriesandspareparts
aretobeusedforrepairs.
Beforeswitchingon/starting
upthedeviceandduringits
operation,makesurethat
nobodywillbeendangered
bythis.
Observeallintervals
forrecurringtestsand/
orinspectionsthatare
prescribedorstatedinthe
operatinginstructions.
Whenworkingclosetolive
componentsandcables,
suitablemeasuresmust
betakentoavoidcurrent
transfersorhigh-voltage
transferstotheequipment.
Pleasenotethatmaterial
couldfalldownorsuddenly
breakfreeduringspreading,
cutting,squeezingoperations
asaresultofshearing,
tearingorbreaking;
appropriatestepsmustbe
takentoavoidthis.

7
Theequipmentislledwith
hydraulicuid.Thishydraulic
uidcanbedetrimentalto
healthifitisswallowedor
itsvaporisinhaled.Direct
contactwiththeskinmust
beavoidedforthesame
reason.Also,whenhandling
hydraulicuid,notethatitcan
negativelya󰀨ectbiological
systems.
Whenworkingwithorstoring
theequipment,ensurethat
thefunctionandthesafety
oftheequipmentarenot
impairedbythee󰀨ectsof
severeexternaltemperatures
andthattheequipmentisnot
damagedinanyway.Please
notethattheequipmentcan
alsoheatupoveralong
periodofuse.
Makesurethatthereis
adequatelightingwhile
working.
Beforetransportingthe
equipment,alwaysensure
thattheaccessoriesare
positionedinsuchaway
thattheycannotcausean
accident.
Alwayskeeptheseoperating
instructionseasilyaccessible
attheplaceofoperation.
Ensuretheproperdisposalof
allremovedparts,left-overoil
andhydraulicuidaswellas
packagingmaterials!
TheeDRAULICdeviceshave
anIP54protectionclass.
Theyaresuitableforusein
wetweatherconditionsand
aresplashproof.
TheeDRAULICdevicesare
notsuitableforunderwater
use.
Pleaseensurethatyoudonot
becomeentangledincables
andtripwhenworkingwithor
transportingthedevice.
Pleaseensurethatthe
batterycontactsarenotshort-
circuited.
Thebuild-upofstaticcharges
andthereforepossible
sparkingmustbeavoided
whenhandlingthedevice.
Onlytouchbroken-o󰀨or
cut-o󰀨partswhilewearing
protectivegloves,asthetorn/
cutedgescanbeverysharp.

8
The generally applicable, legal and other binding national and international regulations
pertainingtothepreventionofaccidentsandprotectionoftheenvironmentapplyandareto
beimplementedinadditiontotheoperatinginstructions.
WARNING / CAUTION / ATTENTION!
Thedeviceisintendedexclusively forthepurposestatedintheoperatinginstructions(see
chapter"ProperUse").Any other use is not in accordance with its designated purpose.
Themanufacturer/supplierisnotliableforanydamageresultingfromimproperuse.Theuser
bearssoleresponsibilityforsuchuse.
Proper use includes observance of the operating instructions and compliance with the
inspectionandmaintenanceconditions.
Never work in a fatigued or intoxicated state!
DonotexposetheAkku
PowerGmbHlithium-ion
batterytowater,oil,or
moistureorliquidofanykind,
asthiscouldleadtoabattery
malfunctionresultinginre
causingpersonalinjuryor
death!
Donotattempttousethe
HURSTRescueEquipment
withtheAkkuPowerGmbH
lithium-ionbatterythat
hasbeenexposeddirectly
orindirectlytowater,oil,
moistureorliquidofanykind,
asthiscouldleadtoabattery
malfunctionresultinginre
causingpersonalinjuryor
death!
DonotexposetheAkku
PowerGmbHlithium-ion
batterychargertowater,oil
ormoistureorliquidofany
kindasthiscouldleadtoa
batterymalfunctionresulting
inrecausingpersonalinjury
ordeath!
DonotplacetheAkkuPower
GmbHlithium-ionbatterythat
hasbeenexposeddirectly
orindirectlytowater,oil,
moistureorliquidofanykind
ontoachargerasthiscould
leadtoabatterymalfunction
resultinginrecausing
personalinjuryordeath!

9
3. Intended use
HURSTeDRAULICdeviceshavebeenspeciallydesignedtorescueorretrievethebodiesof
victimsofroad,railoraircraftaccidentsortobeusedduringrescueoperationsfrombuildings.
HURSTeDRAULICcombinationdevicesareusedtofreeinjuredpersonsataccidentscenes
bycuttingthroughdoors,roofbeamsandhinges.HURSTeDRAULICcombinationdevices
can also be used to free persons who have become trapped by pushing open doors or
removingobstacleswiththeaidofachainset.
CAUTION / PLEASE NOTE!
Caremustalwaysbetakenthattheenvironmentoftheobjecttobeprocessed
remainsstableandsecuredagainstunintentionalshiftingbyusingstrongsupports
orunderpinning.
WARNING / CAUTION / PLEASE NOTE!
TheHURSTeDRAULICdevicesandtheAkkuPowerGmbHlithium-ionbatteries:
- ARE NOTsuitableforunderwateruse
- ARE NOTwaterproof
- ARE NOTwater-resistant
- ARE NOTliquid-prooforresistant
Donotexpose theAkkuPowerGmbHlithium-ion battery orbatterychargerto
water,oilormoistureasthiscouldleadtoabatterymalfunctionresultinginre
causingpersonalinjuryordeath!
There have been reports of spontaneous burns and res igniting from the
charging,storageanduseoflithium-ionbatteries.Youmustalwayscheckthat
theAkkuPowerGmbHlithium-ionbatteryischargingandoperatingconsistently
withthebatterymanufacturer’smanualandhasnotbeendamagedorexposedto
moistureorliquidofanykind.

10
WARNING / CAUTION / PLEASE NOTE!
Thefollowingmaynotbecut/squeezed:
- live cables
- prestressed and hardened parts such as springs, spring steels,
steeringcolumnsandrollers
 - pipesundergasorliquidpressure,
 - compoundmaterials(steel/concrete)
 - explosivebodiessuchasairbagcartridges
Theoperatingpressureplacedontherescuedevicemayonlybedirectlychanged
after consultation with HURST.A change in settings may result in damage to
propertyand/orinjuries.
HURSTeDRAULICdevicesarenotexplosion-protected!
When using the devices in potentially explosive environment, the following
mustbeexcluded:
 - thatthedevicecouldtriggeranexplosion.
 - thatworkingwiththedevicecouldtriggeranexplosion;e.g.sparksmayresult
fromcuttinganobject.
TheresponsibilityforexplosionpreventionorforrulingoutworkwithaneDRAULIC
devicewiththeoperatorofthedeviceorwiththepersonresponsibleattheplace
ofuse.
When working in areas at risk of explosion, all applicable legal,
national and international regulations, standards and safety rules
for avoiding explosions must be observed without restriction!
Therescueequipmentshouldnotcomeintocontactwithacidsoralkalies.Ifthis
is unavoidable, clean the equipment immediately afterwards with a suitable
cleaningagent.
You can obtain accessories and replacement parts for the rescue devices from your
authorizedHURSTdealer!

11
4. Functional description
4.1 Description
Thecombinationdeviceshavebeendesignedinsuchawaythatahydraulicallyoperated
pistonactivatesmechanicaljointssymmetricallytoopenorcloseasetoftwooppositeblade
arms,thusenablingobjectstobecut.
Foralldevices,themovementisactivatedbymeansofavalveintheformofastargrip.
Alldevicesguaranteethedeadman'sswitchandthefullload-supportingfunctionwhenthe
stargripisreleased.
HURSTeDRAULICdevicesdonotneedtobeconnectedtoanexternalhydraulicsource
(e.g.amotorpump).Generationoftherequiredhydraulicpressuretakesplacewithinthe
bodyofthedevice.
Eitherabatteryoranexternalpowersupplymustbeconnectedasanenergysource.
Youcanchoosewhichenergysourceyouwishtouse.Boththeaccumulatorbatteryand
themainspowerunitcanbeinsertedintotheopeningprovidedinthebodyofthetool.
Theyarethenautomaticallylockedintoposition.
YoucanextendtheoperatingtimeofyoureDRAULICdevicebyusingseveralbatteries.
Thebatteriescanberechargedafteruse,usingasuitableexternalcharger.
Ifyouaremakinguseofanexternalpowersupply,thedevicecanbeusedforanalmost
unlimitedtime.Thistimeisonlylimitedbytheexternalenergysourceandtheoverheating
switchofthepowersupply.
ToallowyoutoselectthebestpossibleenergysupplyforyoureDRAULICdevice,neither
thebatterynorthepowersupplyformpartofthedeliveryscope.Youwillndsuitablebat-
teriesandpowersuppliesintheHURSTaccessorieslist.
eDRAULICdevicescomewithstandardlightttingstofacilitateworkunderpoorlight
conditions.
Thelight-emittingdiodesattachedontheoperatingsidelightuptheworkarea.The
mainswitchhasalsobeenequippedwitharinglight,sothatyoucanimmediatelydetect
whetherthedeviceisswitchedonornot.Whenexchangingthebatteryorpowersupply,
theconnectionslotwilllightupforapproximately30seconds.

12
9
12
11
1
23
4
5
6
7
8
10
SC 258 E2
13
4.2.1 Combination tool
 1 Stargrip
 2 Mainswitch
 3 Quickexchangebattery
orpowersupply
 4 Releasebuttonforbat-
teryandpowersupply
 5 Handle
 6 Ventilationslots
 7 Bladearms
 8 Pivotboltwithsecured
nut
 9 Plastichousing
10 Toolbody
11 Protectivecover
12 Light
13 Exchangeabletipat-
tachments
4.2 Structure of rescue devices
11 SC 358 E2
SC 757 E2
SC 758 E2

13
4.4 Operating movement controls
Thepistonmovementiscontrolledbythestargripontheattachedvalve(seeillustrationbelow).
Stargrip
5.1 Battery or power supply for eDRAULIC device
5. Operation
Commissioning
Beforeinitialoperation,thebattery(whereused)oftherescuedevicemustbefullyloaded,
usingtheexternalcharger.
4.3 Hydraulic circuit diagram
AB
cutting/gripping/
pulling/squeezing
spreading/
opening
Belowasimpliedhydraulicramrepresentingthetoolisdepicted.
A=toolB=stargripvalve

14
Procedure:
 1. Unplugthepowersupply(whereused)fromthemains.
 2. Fullypressdownthetwounlockingbuttonsandcarefullypullthebatteryorpower
supplyoutofthedevice.
Do not use force!
 3. Thebatterycannowberechargedinthecharger(pleasetakenoteoftheseparate
operatinginstructionsforthechargerandthebatteriestobeused);alternatively,the
powersupplycanbereplaced.
 4. InserttherechargedornewbatteryintotheeDRAULICdeviceuntilitreachesthe
stop.Thebatteryorpowersupplywillbeautomaticallylockedwhencorrectlyoper-
ated.
Connectionslot
Open the device ( ):
Turnthestargripinthedirectionofthecorrespondingsymbol
(open)andholditinthisposition.
Close the device ( ):
Turnthestargripinthedirectionofthecorrespondingsymbol
(close)andholditinthisposition.
"Dead-man’s" function:
Followingrelease,thestargripautomaticallyreturnstothe
centralposition,fullyguaranteeingloadretention.
5.2 Operating the star grip
(alsoseechapteron"Operatingmovementcontrol")

15
6. Cutting, spreading, pulling, squeezing
6.1 Safety notes
Before rescue work can commence, the object must be stabilized in its current position.
Ensurethattheobjectstobeworkedonareadequatelyunderpinnedand/orsupportedto
ensurethatthereisnoriskofslidingorshifting.
Worldwide safety guidelines pertaining to the specic country must be observed and
compliedwith.
WARNING / CAUTION / PLEASE NOTE!
HURSTeDRAULICdevicesarenotexplosion-protected!
Whenusingthedevicesinpotentiallyexplosiveenvironments,the following
mustbeexcluded:
 - thatthedevicecouldtriggeranexplosion.
 - thatworkingwiththedevicecouldtriggeranexplosion;e.g.sparksmayresult
fromcuttinganobject.
TheresponsibilityforexplosionpreventionorforrulingoutworkwithaneDRAULIC
devicelieswiththeoperatorofthedeviceorwiththepersonresponsibleatthe
placeofuse.
When working in areas at risk of explosion, all applicable legal,
national and international regulations, standards and safety rules
for avoiding explosions must be observed without restriction!
Thefollowingaretobewornwhenworkingwiththerescueequipment:
- protectiveclothing,
- safetyhelmetwithvisororprotectivegoggles,
- protectivegloves,
- and,ifnecessary,earprotection.
Beforeoperatingtherescuedevice,youshouldensurethatnoparticipantsorbystandersare
atriskfromthemovementsoftherescuedeviceorfromyingfragments!Avoidunnecessary
damagetopropertybelongingtoothersortoobjectsnotinvolvedintherescueordamage
causedbyyingfragments.
Note on the operation of the eDRAULIC with a rechargeable battery:
IftherechargeablebatteryremainsintheeDRAULICdevicewiththemainswitchon,but
withoutactivatingthestargrip,therechargeablebatterywillswitchitselfo󰀨aftersometime
(approximately10-60minutes,dependingonthetypeofbattery).Ifthestargripisthen
activated,theeDRAULICdevicewillnotswitchitselfon.
Inordertoresumeworkwiththedevice,theeDRAULICdevicemustrstbeswitchedo󰀨at
themainsandthenswitchedonagain.
Alternatively,thecapacitydisplayontherechargeablebatterycanbeactivatedorthebattery
maybebrieyunpluggedandrepluggedagain.

16
It is strictly prohibited to reach into the path of the
rescue device (e.g. between the blades and the material/
object to which the force is to be applied)!
CAUTION / PLEASE NOTE!
The strong e󰀨ect of the force of the rescue equipment during operation could
causepiecesof thevehicleto break o󰀨ory o󰀨,posingadanger topersons.
Those not involved in the rescue operation should therefore keep at a safe
distance appropriate to thesituation.Any trapped or enclosed persons must
beprotected.
6.2 Cutting
Thebladesshouldbepositionedata90°angletotheobjecttobecut,ifpossible.
RIGHT
WRONG
12
93
15°
15°
90°
Highercuttingcapacitiescanbeachievedbycuttingascloseaspossibletotheblade’spivotpoint.
RIGHT
WRONG

17
During cutting, the gap between the blade tips (in the transverse direction) must not be
exceeded,otherwisethebladeisindangerofbreaking:
ATTENTION!
Wherepossible,avoidcuttingthroughhigh-strengthpartsofthevehiclebody
(e.g. side impact protection). This may result in damage to the blades or to
increasedwearandtear!
eDRAULIC cutting device max. gap at the blade tips
[mm] / [in.]
SC 258 E2 3 / 0.12
SC 358 E2 3 / 0.12
SC 757 E2 3 / 0.12
SC 758 E2 3 / 0.12
Cutting with SC 358 E2, SC 757 E2 and SC 758 E2
ThespreadertipofSC358E2,SC757E2andSC758E2canberemoved.Thisprevents
thematerialfrombecomingstuckbetweenthespreadertips,hinderingthecuttingprocess.
Removing the spreader tip
Step 1:
Toremovethespreadertips,rstpushoutbolt“A”alittle,usingangeroranobject.Afair
amountofforceneedstobeappliedinitially,asthebolthasaballcatchtopreventitfrom
fallingoutunintentionally.
3.
2.
1.
A

18
6.3 Spreading
Usethefrontofthetipsonlytoincreaseanexistinggap.Toincreasegripandtoavoidhaving
thetipssliporbreakoutoftheparttobeprocessed,thegripshouldbereappliedatanearly
stage.Thehighestforcedevelopsintherearareaoftheplug-ontiporintherearspreading
areaofthecombinationblades.
WARNING / CAUTION / PLEASE NOTE!
The light metal alloy arms may not be damaged.
Spreading Enlargingagap
approx25mm
approx. 1 in
Step 2:
Theboltcanthenbegrippedbytheangeandpulledoutuptothelimitstop.Thelimitstop
willpreventtheboltfrombeingpulledoutentirely.Thismeansthatitcannotbelost.
Step 3:
Pullthespreadertipforwardstoremoveit.
Attaching the spreader tip:
Attachmentofthespreadertiptakesplaceinthereversesequence.
Ensurethattheboltisalwayscompletelypushedinandengages.Ifthebolthas
notengaged,thismayresultinthetipinadvertentlycomingloosewhileinuse.
Thisinturncouldresultindamagetotherescueequipment.Therescuedevice
couldalsosliporpartscouldbeungo󰀨,resultingininjuriestoboththeoperator
andthecrashvictim.
Caremustalsobetakenthattheboltdoesnotinadvertentlycomeloosewhile
thedeviceisinuse.

19
Workingsurfaceistoosmall,
tipsslipo󰀨.
Onlyforincreasingthesize
ofagap(notsuitablefor
spreading)
Tipsgetasafegrip. Workwiththetipsonly.
Donotdamagethe
spreaderarms!
Everye󰀨ortshouldbemadetofullyengagethewidthofthetipduringaspreading/lifting
maneuver(seepicturebelow).
Failuretodoso,couldresultindebrisying.

20
6.4 Pulling
WARNING / CAUTION / PLEASE NOTE!
The light metal alloy arms may not be damaged.
- HURSTchainsetsmustbeusedforpulling.
- Whenusingachainforpulling,makesurethatthepinsandhooksarepositionedcorrectly
sothatthechaincannotslip.
- Onlychainsetsinperfectconditionmaybeused.
- Thepullingchainsmustbecheckedbyanexpertatleastonceayear.
- Alsoconsulttheseparateoperatinginstructionsforthecorrespondingchainset!
Attachmenthole
forchainsets
ATheconnectingpiecesforHURSTchain
setsarefastenedtothebladesusing
loadboltsinholes"A".(seeillustration
ontheright)
Chain sets:
forSC258E2: KSV8/258
forSC358E2: KSV11
forSC757E2: KSV13
forSC758E2: KSV13
NOTE:
Alsotakenoteofalltheinstructionsandregulationsintheseparatelyprovided
operatinginstructionsforthechainsets.
