Idis DC-S6 81HRX Series User manual

Powered by
DC-S
Series
Installation Manual
DC-S6881HRX
DC-S6681HRX
DC-S6881HRX-A
DC-S6681HRX-A

2
This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the rst time,
as well as users with experience using comparable products, must read this operation manual carefully before use and
heed to the warnings and precautions contained herein while using the product. Safety warnings and precautions
contained in this operation manual are intended to promote proper use of the product and thereby prevent accidents
and property damage and must be followed at all times. Once you have read this operation manual, keep it at an easily
accessible location for future reference.
• The manufacturer will not be held responsible for any product damage resulting from the use of unauthorized parts and
accessories or from the user's failure to comply with the instructions contained in this manual.
• The information in this document is believed to be accurate as of the date of publication even though explanation
about some functions may not be incorporated. The manufacturer is not responsible for any problems resulting from
the use thereof. The information contained herein is subject to change without notice. Revisions or new editions to this
publication may be issued to incorporate such changes.
• It is recommended that rst-time users of this network camera and individuals who are not familiar with its use seek
technical assistance from their retailer regarding product installation and use.
• If you need to disassemble the product for functionality expansion or repair purposes, you must contact your retailer and
seek professional assistance.
• Both retailers and users should be aware that this product has been certied as being electromagnetically compatible for
commercial use. If you have sold or purchased this product unintentionally, please replace with a consumer version.
Safety Symbols
Symbol Publication Description
IEC60417, No.5032 Alternating Current
In-Text
Symbol Type Description
Caution Important information concerning a specic function.
Note Useful information concerning a specic function.
Before reading this manual

Before reading this manual
3
Safety Precautions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safeguards
1. Read Instructions
All the safety and operating instructions should be read before the
appliance is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future
reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not
use liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the approval
of the manufacturer as such additions may result in the risk of re,
electric shock or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Placing and Accessories
Do not place this equipment on an wall or ceiling that is not
strong enough to sustain the camera. The equipment may fall,
causing serious injury to a child or adult, and serious damage
to the equipment. Wall or shelf mounting should follow the
manufacturer's instructions, and should use a mounting kit approved
by the manufacturer.
This equipment and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
equipment and cart combination to overturn.
Do not place this equipment in an enclosed space. Sucient
ventilation is required to prevent an increase in ambient temperature
which can cause malfunction or the risk of re.
7. Power Sources
This equipment should be operated only from the type of power
source indicated on the marking label. If you are not sure of the
type of power, please consult your equipment dealer or local power
company.
You may want to install a UPS (Uninterruptible Power Supply)
system for safe operation in order to prevent damage caused by an
unexpected power stoppage. Any questions concerning UPS, consult
your UPS retailer.
This equipment should be remain readily operable.
8. Power Cord
Operator or installer must remove power and TNT connections before
handling the equipment.
9. Lightning
For added protection for this equipment during a lightning storm,
or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the equipment due to lightning
and power-line surges. If thunder or lightning is common where the
equipment is installed, use a surge protection device.
10. Overloading
Do not overload wall outlets and extension cords as this can result in
the risk of re or electric shock.
11. Objects and Liquids
Never push objects of any kind through openings of this equipment
as they may touch dangerous voltage points or short out parts that
could result in a re or electric shock. Never spill liquid of any kind on
the equipment.
12. Servicing
Do not attempt to service this equipment yourself. Refer all servicing
to qualied service personnel.
13. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to
qualied service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have hit the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following the
operating instructions, adjust only those controls that are covered
by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work
by a qualied technician to restore the equipment to its normal
operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance —
this indicates a need for service.
14. Replacement Parts
When replacement parts are required, be sure the service technician
has used replacement parts specied by the manufacturer or that
have the same characteristics as the original part. Unauthorized
substitutions may result in re, electric shock or other hazards.
15. Safety Check
Upon completion of any service or repairs to this equipment, ask the
service technician to perform safety checks to determine that the
equipment is in proper operating condition.
16. Field Installation
This installation should be made by a qualied service person and
should conform to all local codes.
17. Correct Batteries
Warning: Risk of explosion if battery is replaced by an incorrect type.
Replace only with the same or equivalent type. Dispose of used
batteries according to the instructions. The battery shall not be
exposed to excessive heat such as sunshine, re or the like.
Avertissement: risque d'explosion en cas d'utilisation d'une batterie
de type incorrect. Le remplacer uniquement par un type identique
ou équivalent. Mettre les batteries usées au rebut conformément
aux instructions. La batterie ne doit pas être exposée à une source de
chaleur excessive, telle que le soleil, le feu, ou analogue.
18. Tmra
A manufacturer’s maximum recommended ambient temperature
(Tmra) for the equipment must be specied so that the customer and
installer may determine a suitable maximum operating environment
for the equipment.

Before reading this manual
4
Warning: This product emits infrared light. Do not look into the IR LED.
FCC Compliance Statement
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART
15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE
WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE
RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO
CAUSE HARMFUL INTERFERENCE, IN WHICH CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID
THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE
CANADIAN INTERFERENCE CAUSING EQUIPMENT REGULATIONS.
WEEE (Waste Electrical & Electronic Equipment)
Correct Disposal of This Product
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote
the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
oce, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
Copyright
© 2022 IDIS Co., Ltd.
IDIS Co., Ltd. reserves all rights concerning this operation manual.
Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly
prohibited.
Contents of this operation manual are subject to change without prior notice for reasons such as functionality
enhancements.
Registered Trademarks
IDIS is a registered trademark of IDIS Co., Ltd.
Other company and product names are registered trademarks of their respective owners.
This product contains software built partially on open-source content. You may obtain the complete
corresponding source code depending on whether or not the source is publicly available under a license policy.
For more information, refer to System > General page. This product includes software developed by the University
of California, Berkeley and its contributors, and software developed by the OpenSSL Project for use in the OpenSSL
Toolkit (http://www.openssl.org/). Also, this product includes cryptographic software written by Eric Young (eay@
cryptsoft.com).

5
Table of Contents
1
2
3
Part 1 – Introduction.........................................6
Product Features ................................................................6
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Overview .......................................................................9
Body......................................................................................9
Pendant (Inner View) .....................................................................10
Factory Reset ............................................................................11
Installation .....................................................................12
Inserting a SD Memory Card ..............................................................12
Installation...............................................................................12
Dimensions ..............................................................................14
Part 2 - Camera Connection .................................15
With DirectIP® NVR-based Layout ...............................................15
With non DirectIP® NVR-based Layout...........................................16
Part 3 - Appendix ...........................................17
Troubleshooting ...............................................................17
Specications ..................................................................18

6
Product Features
DC-S6881HRX / DC-S6681HRX /DC-S6881HRX-A/
DC-S6681HRX-A is an IP-based network camera that
compresses and transmits video over ethernet.
You can use the IDIS Discovery program to change
network camera settings or the IDIS Solution Suite
Compact program to manage multiple network
cameras. In addition, the embedded web server (IDIS
Web) lets you remotely view live video or scan recorded
video using a web browser. In addition, you can use
the IDIS Solution Suite Compact to manage network
cameras and view/record video.
In this operation manual, the term Remote System
refers to the computer on which the remote program
(IDIS Solution Suite Compact or IDIS Web) is running.
• Supports DirectIP mode working with a DirectIP®
NVR that allows users to simply set up all required
congurations without a PC
• Supports ONVIF protocol (Core specication version
2.4.0, Prole S)
• Multi-streaming for high-resolution and high-quality
video monitoring and simultaneous recording in real-
time as well as exible congurations for those
• Supports H. 265, H.264 video compression and
M-JPEG still image compression algorithms
• Supports 4-stage video compression rate and
multiple compression resolutions
• Two-way audio communication support for remote
audio dialog
DC-S6881HRX / DC-S6681HRX model
only
• Video stream buering to counter pre-/post-event
buering and network delays for improved network
recording reliability
• Remote monitoring via web browser or remote
software
• Automatic web casting code (HTML) generation
Part 1 – Introduction

Part 1 – Introduction
7
• Up to 10 simultaneous remote monitoring
connections
• IP ltering, HTTPS, SSL, and congurable user
authority levels for greater security
• Network bandwidth limitation and MAT features for
more ecient use of network bandwidth
• Easy network access via UPnP (Universal Plug and
Play) function and embedded mDNS (Multicast DNS)
protocol
• Wide dynamic range compensation (True WDR) for
improved video quality in high-contrast situations
• Slow shutter support for improved low-lighting video
capture performance
• Day & Night feature (built-in IR cut lter changer)
• Quick and easy rmware upgrade over the network
• Redundant rmware and auto recovery features for
improved system stability
• Network-based integrated management of multiple
network cameras
• Multiple event detection modes
• Backup storage on a microSD memory card as
a safeguard against data loss during network
interruptions
• Supports 24 VAC
• Video out feature (selectable NTSC/PAL)
• Supports zoom function using an AF zoom lens
• Pan/Tilt control with a micro stepping motor
• Features a built-in heater for continued use in sub-
zero temperature conditions
• IP66-level for waterproof and dustproof features
Remote monitoring and recording via multistreaming
are available using the IDIS Solution Suite Compact
program. For more information on using IDIS Solution
Suite Compact, refer to its operation manual.
There is a limit to the number of users allowed to
connect remotely via the Internet at the same time.

Part 1 – Introduction
8
Accessories
Upon purchasing the product, check inside the box to make sure all the following accessories are included. External
appearances and colors of the accessories may vary depending on the model.
Network Camera Mount Adapter, Screws
Allen Wrench Ferrite Core
Waterproong accessory (Bushing, Glue) Quick Guide

Part 1 – Introduction
9
Overview
Product color and design may vary depending on the
model.
Body
1
4
3
2
5
6
78
1Mount
2Pendant
3Body Assembly Standards
4Lens
5IR LED
6Wiper
7Factory Reset Button
8SD Memory Card Slot
• Body Assembly Standards
For tightening the body.
• Lens
AF Zoom Lens is mounted.
• IR LED
A sensor in the middle monitors lighting levels and
activates the IR LED during low-lighting conditions.
• Factory Reset Button
Restores the camera's default factory settings. For
more information, refer to the Factory Reset.
• SD Memory Card Slot
Used to insert a microSD memory card into
the camera. (An SLC (Single Level Cell) or MLC
(Multi Level Cell) card by SanDisk or Transcend is
recommended) Make sure that the cover is joined
properly when screwing it; otherwise, the IP66 level
is not guaranteed.
• To remove/insert the SD memory card or
perform the factory reset, make sure that the
cover is joined properly when screwing it.
Otherwise, the IP66 level is not guaranteed. For
more information, contact your product retailer.
• Do not remove the SD memory card while the
system is in operation. Removing the card while
the system is in operation can cause the system
to malfunction and/or corrupt data stored on
the SD memory card.
• An SD memory card is a consumable product
with a nite service life. Prolonged use will
damage the card's memory sectors and result
in data loss or memory card failure. Test the SD
memory card regularly and replace it whenever
necessary.

Part 1 – Introduction
10
Pendant (Inner View)
1
2
3
4
1Power
2Network Port
3Alarm In/Out
4Video Out, Audio In/Out
• Network Port
Connect a network cable with an RJ-45 connector to
this port. You can congure, manage, and upgrade
this camera and monitor its images from a remote
computer over the network. For more information
on network connection setup, refer to the IDIS
Discovery operation manual.
The table below shows the network cable
specications.
<The network cable specications>
Item Content Note
Connector RJ-45
Ethernet 10/100Base 10/100Mbps
Cable UTP Category
5e or higher
Maximum
length 100m
PoE High-PoE
• Alarm In/Out
– ALI:Connect an alarm-in device to this port.
(Mechanism: Choose between an NC (Normally
Closed) type or an NO (Normally Open) type) →
Connect a mechanical or electrical switch to the
alarm in port and the GND (ground) connector.
Alarm in range is 0V to 5V. In order to detect alarm
input from an electrical switch, the signal must be
higher than 4.3V from an NC switch or less than
0.3V from an NO switch and must last for longer
than 0.5 seconds.
– ALO: It is the BJT (Bipolar Junction Transistor) -
open collector output. If the voltage and current
exceed the specication limit (Max load: 50mA,
Max Voltage: 30VDC), the product could be
damaged. When connecting the device which
exceeds the specication limit, refer to the picture
(circuit) below.
If used with an external inductive load(e.g. relay),
a diode must be connected in parallerl with
the load for protection. Otherwise, the product
could be damaged.
• Audio In/Out DC-S6881HRX / DC-S6681HRX model
only
, Video Out
– A_I: Connect an audio source to this port. (line in)
– A_O: Connect an amplier to this port (line out).
This device does not feature a built-in audio
amplier unit and therefore requires the user to
purchase a separate speaker system with a built-in
amplier.
– V_O, GND: Connect the cable's signal line and
ground line to these ports and the connector on
its opposite end to a monitor. Use these ports
for previewing video and not monitoring video.
Go to Remote Setup (Video – Camera menu >
Miscellaneous tab) and choose a video out signal.
(NTSC or PAL)

Part 1 – Introduction
11
When inserting an alarm in/out, audio in/out,
or video out, connector, hold down the button
and push the connector in through the exposed
hole. Release the button and then gently pull
on the wire to ensure a secure connection. To
disconnect, press down on the button again and
pull the wire out.
• Check your local laws and regulations on
making video or audio recordings. The user will
be held liable for any violation of the law.
• Organize the power cable so that it will not
cause people to trip over or become damaged
from chairs, cabinets, desks, and other objects
in the vicinity. Do not run the power cable
underneath carpet or a rug or plug the cable
into a power outlet shared by a number of other
devices.
• Wrap the camera-end of the earth cable twice
around the provided ferrite core for EMC
(Electromagnetic Compatibility). If not, you may
experience video stuttering.
Ferrite Core
Network Cable
• The network connector is not designed to be
connected directly with cable or wire intended
for outdoor use.
Factory Reset
Only use the factory reset button to restore the camera
to its factory default settings.
A factory reset will clear all camera settings congured
by the user.
1 Shut o the power supply.
2 Press and hold the reset button down.
3 Hold the button down and reconnect the power.
4 Once the device turns back on, wait 5 seconds, and
then release the reset button.
5 The device will go through the resetting process and
reboot. All camera settings will be restored to their
factory defaults after the reboot.
It's also possible to do a factory reset by pressing and releasing
the reset switch while the camera is turned on or using the IDIS
Discovery program from a remote location. A factory reset will
reboot the system. For more information on factory reset, refer
to the IDIS Discovery operation manual.
Make sure that the cover is joined properly when
screwing it; otherwise, the IP66 level is not guaranteed.

Part 1 – Introduction
12
Installation
Installation of this product does not require the use of
special tools.
For more information on other devices comprising the
overall system, refer to their respective installation
manuals.
Product color and design may vary depending on the
model.
Inserting a SD Memory Card
Insert a SD memory card into the SD memory card slot
with the 'micro SD' print facing upward.
micro
SD
Push the SD memory card until it disengages from the
slot, and then pull it out.
Make sure that the cover is joined properly when
screwing it; otherwise, the IP66 level is not guaranteed.
Installation
• Check the wall or ceiling to see if it needs to be
reinforced. The camera may fall o if the wall or
ceiling is not strong enough to support its weight.
• Install the camera in a shaded area. If the camera
is installed in direct sunlight, it may be aected
adversely.
1 Make a cable hole in the wall or ceiling.
Apply glue
to the gaps Pendant
Bushing
Bushing
Use a bushing provided with the camera to prevent
moisture or water from entering through the bracket
or pipe. First, pass the cable through the waterproof
bushing, assemble it in the pendant, and then use the
waterproof glue provided with the camera to ll the
cable gap and the holes.
1-1/2" Bracket
Mount Adapter
Pendant
<Installing to the bracket> <Installing to the Pipe>
2 When installing in 1-1/2" PF bracket, assemble
mount adapter to the bracket and then assemble
the pendant. Hook the safety wire of the camera on
the safety wire ring of the bracket.
The bracket must be purchased separately.

Part 1 – Introduction
13
3 Assemble the mount adapter to the camera body
and secure it by using the mount adapter screws (3
points).
Lever
4 Gently push the lever located at the bottom of the
pendant to lower it and connect the cable.
5 Assemble the pendant and the body by matching
the installation direction guides. Rotate the camera
body clockwise to position the reference mark in the
upper section and the lower section as shown in the
gure.
6 Use the allen wrench provided with the camera to
secure the 3 screws on the pendant.
7 Supply the power.

Part 1 – Introduction
14
Dimensions
401.8mm (15.81”)
20mm
Ø242mm (9.52”)
Ø43.5mm (1.71”)
7mm4mm
Ø242mm (9.52”)

15
Use the camera by connecting to DirectIP® NVR or non DirectIP® NVR, VMS such as IDIS Solution Suite Compact.
With DirectIP® NVR-based Layout
Audio Out
< Network Camera >
Power
Remote Monitoring
Monitor Out
Alarm Out
Sensor In
Audio In
Network
24 VAC
24 VAC
Network
< NVR >
DirectIP® NVR makes it easy to use cameras without extra network congurations.
Each camera can be controlled via the DirectIP® NVR setup menu, without any PC.
For detailed camera settings, please see the camera setting pages of DirectIP® NVR manual.
For users using the camera with DirectIP® NVR connection, do not need to consider contents in the camera operation
manual.
Part 2 - Camera Connection

Part 2 - Camera Connection
16
With non DirectIP® NVR-based Layout
Network Camera
Network
Remote Monitoring
(IDIS Solution Suite Compact
or IDIS Web)
Remote Recording
(IDIS Solution Suite Compact)
microSD Memory Card
Alarm Out
Sensor In
Audio Out
Audio In
24 VAC
Control the camera over the network from software installed on a computer.
Ideal for using the camera over the network from a remote location.
The contents in the camera operation manual are only for users using the camera with non DirectIP® NVR connection
or VMS connection such as IDIS Solution Suite Compact.

Part 3 - Appendix
17
Problem Check
The main unit won't turn
on.
• Check the power cable connection.
• Check the power outlet.
I can't see Live videos. • Check the camera's power status.
• Check the network connection status of the computer and the network camera.
Images are blurry. • Make sure the lens is clean. If not, clean it using a soft piece of cloth or a brush.
• Make sure the lens is in focus. Adjust the focus during daytime.
• If there is too much light coming into the camera or the camera is picking up an
overly bright light source, adjust the camera's position/angle accordingly.
Video color appears
incorrect.
Check the white balance settings. If using the Auto option, it may take some time for
the white balance to be adjusted.
Images are blinking. If the camera is pointed at the sun or a uorescent lamp, adjust the camera's angle away.
Lost the admin ID and
password and unable
to connect to a network
camera.
You must perform a factory reset. A factory reset will revert all settings, including
network settings, to their factory defaults. After performing a factory reset, make a
memo of the admin ID and password as a safety precaution.
Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet
Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below.
Part 3 - Appendix
Troubleshooting

Part 3 - Appendix
18
Specications
These product specications may change without prior notice.
Video
Image Sensor 1/1.8" CMOS
Max. Resolution DC-S6881HRX(-A) 3840x2160
DC-S6681HRX(-A) 3328x1872
Scanning Mode Progressive Scan
Lens type AF Zoom Lens
Focal Length f=6.5mm ~ 202mm (31x)
Aperture F1.55 ~ 4.8
Iris Control DC Auto Iris
Angular Field of View Wide : 63°(H), 37.6°(V), 70.3°(D)
Tele : 2.37°(H), 1.33°(V), 2.7°(D)
Min. Illumination Color : 0.1 lux @ F1.55
B/W : 0 lux (IR LED ON)
Dynamic Range 120 dB, True WDR
Electronic Shutter Speed Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter(1/7.5, 1/15)
Day & Night IR cut lter with auto switch
IR Distance (LEDs) 200m (2ea)
Video Out * Terminal Block 1ea
* Use this port for previewing video and not monitoring video.
Pan/Tilt/Rotate
Pan Range 360° (Endless)
Pan Speed 240°/sec (preset 240°/sec)
Tilt Range -10° ~ 190° (-100° ~ 100°)
Tilt Speed 240°/sec (preset 240°/sec)
Preset 256ea

Part 3 - Appendix
19
Network
Video Compression H.265, H.264(MP), M-JPEG
Bitrate Control VBR, CBR
Max. Frame Rate DC-S6881HRX(-A) 30fps : 3840 x 2160
DC-S6681HRX(-A) 30fps : 3328 x 1872
Audio Compression DC-S6881HRX /
DC-S6681HRX model only
ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law
Supported
Resolution
DC-S6881HRX(-A) 3840 x 2160, 1 920 x 1080, 1280 x 720, 640 x 360
DC-S6681HRX(-A) 3328 x 1872, 1920 x 1080, 1280 x 720, 640 x 360
Multi-Video Streaming Quadruple
Ethernet RJ45(10/100Based Ethernet)
Edge Storage** (Optional)
(micro SD/SDHC/SDXC memory card, Smart Failover (class 6
or higher, max. 512GB))
** An SLC (Single Level Cell) or MLC (Multi Level Cell) card by SanDisk or Transcend is recommended to ensure stable recording
performance.
** An SD memory card is a consumable product with a nite service life. Prolonged use will damage the card's memory sectors and
result in data loss or memory card failure. Test the SD memory card regularly and replace it whenever necessary.
** microSD Logo is a trademark of SD-3C, LLC.
I/O
Audio In/Out Line-in 1ea / Line-out 1ea DC-S6881HRX / DC-S6681HRX model only
Alarm In 8 TTL, NC/NO Programmable, 4.3V(NC) or 0.3V(NO) threshold, 5V DC
Alarm Out 2 TTL open collectors, Max. load: 30mA, Max. voltage: 5VDC

Part 3 - Appendix
20
General
Vandal Resistance Yes
Out-door Ready IP66, Heater
Operating Temperature*** IR LED OFF: -40°C ~ +55°C (-40°F ~ +131°F)
IR LED ON: -40°C ~ +40°C (-40°F ~ +104°F)
Boot Up Temperature*** IR LED OFF: -20°C ~ +55°C (-4°F ~ +131°F)
IR LED ON: -20°C ~ +40°C (-4°F ~ +104°F)
Operating Humidity 0% ~ 90%
Power Source 24VAC, High PoE
Power Consumption HEATER OFF, IR LED OFF: 24V~, 1.2A, 21.1W, 50/60Hz/ High-PoE, 50-57V, 20.3W
HEATER ON, IR LED ON: 24V~, 3.4A, 65.8W, 50/60Hz/ High-PoE, 50-57V, 60.0W
Approval FCC, CE
External Dimensions (Ø x H) 9.52” x 15.79” (242mm x 401mm)
Weight (Main Unit) 16.31 lbs. (7.4kg)
*** It may not operate normally in an environment where the ambient temperature is below -40°C( -40°F ).
*** If the product is left unattended in an environment where the ambient temperature is below -20°C(
-4°F ) and the power is turned
on, it will boot after internal heating for 5 minutes for normal operation.
*** In a -40°C(
-40°F ) environment, the product may not defrost depending on the installation location.
V1.1
