IDROBASE PerfectCool Cielo User manual

MADE IN ITALYMADE IN ITALY
Quality assured firm
Rev. 00 - 04/2014Rev. 00 - 04/2014
CIELO
IMPORTANT!
Before installing and
using the machine impe-
rative that the installer
and the user read and un-
derstand all parts of this
manual.
The manual is an integral
part of the machine and
must necessarily be kept
for future reference until
the demolition of the ma-
chine.
Naturally cooler
GB Use and maintenance manual

16 Rev. 00 - 04/2014
Thanking you for the preference you gave us, IDROBASE GROUP Srl is glad to include your rm in the list of its
preferred customers and relies that the use of this machine will be fully satisfactory.
This manual is intended to provide all instructions and precautions to be followed to properly use the machine in
safety and productivity; It is therefore appropriate that the operator consult this manual before using the machine.
The manual must always be available to the operator and kept in good condition; is the user's responsibility to wor-
ry about the training of personnel assigned to the use and maintenance for safety purposes . The replacement of
parts not manufactured or approved by the ngers IDROBASE GROUP Srl may a ect the performance or durabi-
lity of the machine and create the potential risk to the machine itself or the sta , as well as make void the warranty.
The descriptions and illustrations contained in this publication are not binding; IDROBASE GROUP Srl therefore
reserves the right to make changes at any time, without obligation , to update the publication , to change bodies ,
details, accessories supplies for further improvement, or for any other manufacturing and / or commercial function
greater safety.
The instructions, drawings , tables, and all that is contained in the following le are technical in nature and reser-
ved, for this reason, any information can not be communicated to third parties without written authorization from
IDROBASE GROUP Srl that is its sole owner.
In case of dispute the valid jurisdiction is that of Padua (Italy).
GOOD JOB !
Rev. 00 - 04/2014

17 Rev. 00 - 04/2014
INDEX
GB
Prog. Description Page
1 Applications
1.1 General warnings 18
1.2 Machine identi cation 18
1.3 Warranty 18
1.4 Conditions for returns 19
1.5 Cases in which the manufacturer is not liable 19
1.6 Safety 19
1.7 Symbols 20
1.8 Glossary 21
1.9 Notes on the labels 21
2 Product presentation
2.1 Purpose 22
3 Layout of the manual
3.1 Information 23
4 Electric and hydraulic connection 24
5 Operation and use
5.1 Range of applications 25
5.2 Working limits 25
5.3 Water connection to the machine 25
5.4 Stickers and Labels 25
5.5 Training 26
6 Cleaning and disinfecting
6.1 Cleaning and disinfection 27
6.2 Demolition and disposal 27
7 Maintenance
7.1 Maintenance 28
7.2 Cleaning nozzles 28
7.3 Electric system 28
7.4 Weekly maintenance 28
8 Destruction and disposal 29
Rev. 00 - 04/2014

18 Rev. 00 - 04/2014
1  APPLICATIONS
1.1 GENERAL WARNINGS
BEFORE INSTALLING AND USING THE MACHINE IT IS COMPULSORY THAT THE INSTALLER AND THE
USERS READ AND UNDERSTAND ALL OF THE INFORMATION IN THIS MANUAL.
THIS MANUAL IS AN INTEGRAL PART OF THE MACHINE; IT MUST ALWAYS BE AVAILABLE DURING
THE NORMAL OPERATION OF THE MACHINE AND IT IS IMPERATIVE THAT IT IS RETAINED FOR FUTU
RE REFERENCE UNTIL THE DISPOSAL OF THE MACHINE.
THE COPYRIGHT OF THIS MANUAL “INSTRUCTION FOR INSTALLATION AND USE” IS THE PROPERTY
OF IDROBASE GROUP SRL. ALL OF THE INFORMATION TEXT, DRAWINGS, DIAGRAMS, ETC. CON
TAINED IN THIS MANUAL IS CONFIDENTIAL. NO PART OF THIS MANUAL CAN BE REPRODUCED AND
DISTRIBUTED EITHER IN PART OR COMPLETE BY ANY MEANS OF REPRODUCTION, PHOTOCOPIES,
MICROFILM, OR OTHER WITHOUT WRITTEN AUTHORIZATION FROM IDROBASE GROUP SRL.
1.2 MACHINE IDENTIFICATION
The machine is distinguished by a manufacturer’s plate
1.3 WARRANTY
All of our equipments are subjected to accurate and rigorous tests and are covered under warranty in
accordance with statutory law from manufacturing defects.
THE WARRANTY IS INVALIDATED IF THE USE OF THE MACHINE DOES NOT CONFORM TO THE IN
STRUCTIONS FOR USE CONTAINED IN THIS MANUAL, AND IF THE ORIGINAL COMPONENTS, ACCES
SORIES, SPARE PARTS AND CONTROL SYSTEMS ARE NOT USED.
The warranty starts from the date of purchase within the meaning of the act concerning warranty in the
country of sale. IDROBASE GROUP SRL undertakes to repair or replace free of charge any parts that have
manufacturing faults within the warranty period. Faults not clearly due to materials or manufacturing shall
be examined at one of our Technical Assistance Centres or at our headquarters and charged according to
the results.
PERFECT COOL S.r.l.
35010 Borgoricco (PD) ITALY - Via dell’Industria, 25
Tel. [phone] r.a. - Fax [phone]
Modello
Model
Matricola
Production nr.
Anno
Year
Kg V Hz A Kw Temperatura
Temperature
Pressione max
Max pressure
lt/min Pressione nominale
Nominal pressure
MODEL
WEIGHT
MAX PRESSURE
MANUFACTURER
NAME
PRODUCTION
NUMBER
YEAR OF PRODUCTION
FREQUENCY
CURRENT ABSORBED
VOLTAGE
POWER ABSORBED
FLOW RATE
PROTECTION DEGREE
TEMPERATURE
NOMINAL PRESSURE
Rev. 00 - 04/2014

19 Rev. 00 - 04/2014
1  APPLICATIONS
The following are excluded from the warranty: accidental damage due to transport, negligence or inap-
propriate treatment, incorrect or improper use or installation, i.e. not complying to the instruction ma-
nual, and any situations that do not depend on machine standards and operation, or on electrical and
equipment use. The warranty is invalidated if the equipment is repaired or tampered with by unauthorized
third parties. The equipment shall not be replaced nor the warranty extended after it has been repaired for
faults. The warranty does not cover cleaning the working parts or replacing consumable components such
as pump oil, nozzle, etc. IDROBASE GROUP SRL is not liable for any damage to persons or objects due
to incorrect installation or improper use of the equipment.
1.4 CONDITIONS FOR RETURNS
It will be the responsibility of the end user to return the product to the retailer; or telephone for further
information to the number
[phone]
1.5 CASES IN WHICH THE MANUFACTURER IS NOT LIABLE
The manufacturer is not liable for damage caused by the following:
•Improper use of the machine or use by untrained people.
•Use of non genuine spare parts.
•Non-compliance with maintenance.
•Unauthorized modi cations or operation.
•Non-observance, in total or part, of the instruction manual.
•Non-observance, in total or part, of the safety regulation in force in the country where the machine is
used.
1.6 SAFETY
The CIELO is well-advanced from a technical point of view and for a proper installation, good operation,
proper use and maintenance, it needs trained, responsible sta who has to comply with the following rules
of safety and conduct.
•Do NOT expose the machine to freeze and the outside weather in general. Freezing can cause severe
damages to the pump and circuit. The prolonged downtime at temperatures below 0°C (zero Celsius
degrees) can cause damages or break pump and pipes, it is better to do a complete emptying;
•The electrical system connected to the machine MUST be made in compliance with the laws in force in
the country of installation;
•It is RECOMMENDED the presence of a di erential circuit breaker, with a sensitivity of 30 mA above the
socket or power plant;
•Do NOT use extension cords or loose plugs;
•The integrity and insulation of the electric cable and equipment MUST be checked, because the work
environment is necessarily exposed to water and humidity conditions that preclude the natural system
insulation;
•Do NOT use the machine if the cable is damaged or worn; disconnect the device from the network and
contact an authorized service center;
•You MUST follow the rules imposed by the Fire Department or by local entrusted bodies.
•Do NOT touch the plug with wet hands or feet!
•Avoid accidental operation. You MUST place the switch OFF before inserting or removing the plug from
the socket;
•Do NOT pull the cord to remove the plug;
Rev. 00 - 04/2014

20 Rev. 00 - 04/2014
1  APPLICATIONS
•Do NOT install the machine near  ammable materials (expecially on environments with airborne particles: pla-
stics, resins, acids, inks, etc.);
•Do NOT use paints, acids, solvents, oily or very dense liquids, and so on;
•The machine MUST be used by a properly trained single operator;
•Do NOT leave the machine unattended, especially with children around.
•Do NOT use the machine in the presence of unauthorized person or persons who are not wearing suitable pro-
tective garments;
•It is RECOMMENDED not to place the machine on ramps or sloped  oor, possibly remember to lock the wheels
with the appropriate mechanisms;
•If the machine will be put outside good precautions must be taken in order to PREVENT the dangerous e ect of
weather conditions.
1.7 SYMBOLS
In this manual the symbols depicted describe important functions of the machine for the in-
stallation, and for the use and disposal. For correct and safe use of the machine the operator
must read carefully all parts of this manual paying special attention to the warning symbols
and manufacturer’s plate.
PAY ATTENTION TO SAFETY IN THE WORKPLACE!
FOLLOW THE INSTRUCTIONS DISPLAYED ON THE WARNING SIGNS. FAILURE TO DO SO MAY
CAUSE SEVERE INJURY OR ENDANGER PERSONAL SAFETY. ENSURE THAT THE SIGNS ARE
PRESENT AND LEGIBLE. IF THEY ARE NOT, THEY SHOULD BE FITTED OR REPLACED.
THIS MANUAL MUST BE READ BEFORE USING OR CARRYING OUT MAINTENANCE OR OTHER
OPERATIONS ON THE MACHINE. DO NOT ALLOW UNAUTHORIZED PERSONNEL TO USE THE
MACHINE.
Rev. 00 - 04/2014

21 Rev. 00 - 04/2014
1.8 GLOSSARY
The following symbols advise the operator of dangerous situations or the important opera-
tions for the correct running of the machine.
WARNING SIGNS!
THIS MANUAL MUST BE READ BEFORE USING OR CARRYING OUT MAINTENANCE OR OTHER
OPERATIONS ON THE MACHINE.
INFORMATION!
THE INFORMATION CONTAINED IN THIS MANUAL SHOW THE RIGHT PROCEDURES FOR THE
CORRECT MAINTENANCE AND USE OF THE MACHINE
INFORMATION!
THE CAUTION INDICATES SPECIAL PROCEDURES THAT IF NOT OBSERVED CAN CAUSE DAMA
GE TO PERSONS OR PROPERTY.
WARNING!
MAINTENANCE OR REPAIRS MUST NEVER BE CARRIED OUT WHITE THE MACHINE IS LIVE/
SWITCHED ON. ALWAYS DISCONNECT FROM THE ELECTRICAL SUPPLY BEFORE CARRYING
OUT REPAIRS OR REMOVING THE COVER.
WARNING!
AVOID STORING OR USING THE MACHINE IN EXTREME TEMPERATURES. FROST MAY CAUSE
SERIOUS DAMAGE TO THE HIGH PRESSURE PUMP.
WARNING!
PROTECTIVE GARMENTS SHOULD BE WORN.
1.9 NOTES ON THE LABELS
Never remove the labels from the machine. If they have deteriorated, ask your retailer or the
manufacturer directly for a replacement.
THE MANUFACTURER IS NOT LIABLE IN ANY WAY IN THE EVENT OF ACCIDENTS OR BREAKA
GE DUE TO NONOBSERVANCE OF THE WARNINGS.
IN CASE OF LOSING THIS MANUAL OR ANY MISUNDERSTANDING CONTACT THE RETAILER
IMMEDIATELY.
THE STICKER SHOWING THE WAY OF USE AND RESTRICTIONS HAS NEVER TO BE REMOVED
FROM THE PLACE THEY ARE.
1  APPLICATIONS
Rev. 00 - 04/2014

22 Rev. 00 - 04/2014
2.1 PURPOSE
CIELO generate a  ow of air and atomized water.
The civil applications are:
•Bar;
•Hotel;
•Restaurantes;
•night club;
Through the use of suitable optional kits or models for each of these types achieves maximum performance.
It uses the principle of adiabatic cooling, the ambient temperature is lowered by evaporation of the water spray.
2  PRODUCT PRESENTATION
Rev. 00 - 04/2014

23 Rev. 00 - 04/2014
3.1 INFORMATION
This manual is an essential document for the safe use of the equipment. It should be kept
in a safe place and must be accessible to the user / repairer to ensure the correct use of the
machine and thereby avoid any risks through incorrect Installation, misuse or negligence.
We recommend to follow carefully the instructions below, as the manufacturer is not liable
for any damage caused to persons or property, or su ered from the machine when used
di erently than what described, or if you do not comply with maintenance and safety requi-
rements.
This manual should always be available to the user and/or maintenance, which must be infor-
med about the correct use of the machine and any residual risks.
The instructions in this manual do not supersede the safety and technical data, installation
and also use for operating, which are applied directly on the machine.
The user must follow the safety regulations to the country of installation, in addition to the
rules dictated by common sense.
You should not use the machine if you note any defects or damages that could compromise
the original security; the responsible for the installation, the user or maitenance technician
has to report any anomalies to the manufacturer.
The machine is built for speci c applications. It should not be changed and/or used for appli-
cations di erent than those speci ed in the eld of use.
Instructions, drawings, tables and all that is contained in the following documents are of
technical nature, and therefore any con dential information can not be provided to third
parties without the written permission of IDROBASE GROUP SRL which is the sole owner.
Descriptions and illustrations contained in this publication do not mean demanding; IDRO-
BASE GROUP SRL therefore reserves the right to make changes at any time to bodies, details,
accessories supplies, appropriate for any manufacturing or commercial improvement.
Rev. 00 - 04/2014
3  LAYOUT OF THE MANUAL

24 Rev. 00 - 04/2014
4  ELECTRIC AND HYDRAULIC CONNECTION
1
2
WATER PIPE
ELECTRIC CABLE
FROM INSIDE THE BASE, CONNECTING:
11
Rev. 00 - 04/2014
2

25 Rev. 00 - 04/2014
5  OPERATION AND USE
5.1 RANGE OF APPLICATIONS
•Cooling of internal and external areas (only coverage) such as: bars, restaurants, swiming
pools, discos, theme parks, meeting places, poultry farms, livestock farming, machine shop
and industries.
•Humidi cation of internal and external areas .
WARNING!
DON'T USE IN ENVIRONMENTS WHERE EXPLOSIVE POWDERS ARE PRESENT. DON'T USE TO
DISTRIBUTE TOXIC CHEMICALS OR PRODUCTS THAT CAUSE HARM TO PEOPLE OR THE EN
VIRONMENT. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY DAMAGE CAUSED BY IM
PROPER OR INCORRECT USE OR FAILURE TO OBSERVE THE RULES SET OUT IN THIS MANUAL.
5.2 WORKING LIMITS
Prolonged inactivity (machine stopped) with temperatures lower than 5°C (5 degrees cen-
tigrade) can cause damage or breakage to the pump, hoses, and to the parts in general. It
is therefore advisable to empty the machine completely. For more information contact the
retailer or manufacturer.
5.3 WATER CONNECTION TO THE MACHINE
The machine is connected to the system using water hoses still closed dimensioned accor-
ding to the  ow and pressure to which the system should work.
The pipes laid shall not have any bending.
Serial connection to the water supply is carried out by a female tting 3/8 "
5.4 STICKERS AND LABELS
On the machine and manual signs and pictograms are shown in order to highlight or draw
any hazardous situations or behaviors to be followed for safe operation.
WARNING!
NEVER PUT ANY PART OF THE BODY AND / OR OBJECTS THROUGH THE OPENINGS OF
THE FAN, WHERE THERE IS A NEED, YOU MUST FIRST DISCONNECT THE POWER SUPPLY.
WARNING!
NEVER REMOVE THE SAFETY DEVICES WITHOUT FIRST DISCONNECTING THE VOLTAGE
AND ABSOLUTELY DO NOT TURN ON THE MACHINE WITHOUT THESE DEVICES.
Rev. 00 - 04/2014

26
5 - OPERATION AND USE
5.5 TRAINING
It is the responsibility of the owner and/or supervisor to assign an operator and train him in
the use of the machine according to the instructions in this manual.
WARNING!
THE SYSTEM MUST BE USED ONLY BY A TRAINED OPERATOR, WHO USES THE MACHINE IN
ACCORDANCE WITH THE INSTRUCTIONS CONTAINED IN THIS MANUAL AND/OR THE MA
NUAL FOR ANY EXTERNAL EQUIPMENT. NO LIABILITY SHALL BE ACCEPTED FOR ANY IMPRO
PER USE OF THE MACHINE NOT ENVISAGED IN THIS MANUAL.
Rev. 00 - 04/2014Rev. 00 - 04/2014

27 Rev. 00 - 04/2014
6  CLEANING AND DISINFECTING
6.1 CLEANING AND DISINFECTION
After a period of inactivity of the system, before to reuse it, it is better to clean and disinfect
whole the pipe line. For this operation contact a quali ed technician or the retailer.
Check that the water lters that are used with the machine are of the correct size and that
they are periodically removed, checked, and cleaned.
6.2 DESTRUCTION AND DISPOSAL
WARNING!
THE DESTRUCTION OF THE MACHINE MUST BE CARRIED OUT ONLY BY A TRAINED PERSON
OR BY A QUALIFIED TECHNICIAN.
When it has been decided to destroy the machine and render it unusable it is recommended
that all parts which could be dangerous are rendered safe, removing all of the electrical com-
ponents, while conforming to current legislation regarding the scrapping of these materials.
The various components should be brought to the appropriate recycling centres.
WARNING!
THE DISPOSAL OF THE MACHINE MUST BE CARRIED OUT ACCORDING TO THE LAWS OF THE
COUNTRY IN WHICH IT IS TO BE DISPOSED.
FUR FURTHER INFORMATION CALL
[phone]
Rev. 00 - 04/2014

28 Rev. 00 - 04/2014
7  MAINTENANCE
WARNING!
EVERY TIME THE MACHINE IS CLEANED OR MAINTAINED IT MUST FIRST BE STOPPED BY FOL
LOWING THE STEPS DESCRIBED IN PARAGRAPH 8.4.
TO GUARANTEE MACHINE SAFETY, YOU ARE ADVISED TO USE ONLY SPARE PARTS AUTHO
RIZED BY THE MANUFACTURER. DO NOT CARRY OUT TEMPORARY OR DANGEROUS REPAIRS.
CAUTION!
DURING OPERATION, THE SYSTEM MUST MAINTAIN A NOISE LEVEL THAT COMPLIES WITH
LEGISLATION. FURTHERMORE, THERE MUST BE NO WATER LEAKAGE FROM THE PUMPING
MODULE OR THE LINE.
7.1 MAINTENANCE
MACHINE contain a high pressure water supply, an electric motion system and a control sy-
stem that need a big maintenance. Everything works, most of the time, in awful climatic con-
ditions: bad weather, humidity, ice, hot, hard and non-stop usage and, not always adequate
water, not always strained fuel.
The solution is preventing breakages. How to do it?
Simply replacing the components before they cause breakages.
7.2 CLEANING NOZZLES
Check every 50 hours the proper functioning of the nozzles of the crown group that could get
clogged due to the formation of limestone or using unclean water.
A nozzle is clogged note because drips or has a spray angle is not uniform.
For the procedure for cleaning the nozzle follow the relevant procedure that will be delivered
along with the booklet.
When replacing the nozzles do not tighten with excessive force. Each contact tip stamped its
own characteristics,  ow and spray angle.
7.3 ELECTRIC SYSTEM
Check annually the functioning of the electrical system and check the fastening of the links. The
change of temperature and possible vibrations cause loosening of the electrical connections with
its overheating.
WARNING!
IT IS GOOD TO REMEMBER THAT THE MAINTENANCE CARRIED OUT PROPERLY, CAN MINIMI
ZE THE DOWNTIME DUE TO FAILURE.
A REPAIR DONE IN A TIMELY MANNER TO AVOID FURTHER DETERIORATION.
USE AS MUCH AS POSSIBLE, ORIGINAL SPARE PARTS.
7.4 WEEKLY MAINTENANCE
•Power cable in good condition
•Water pipes and ttings in optimum condition and undamaged.
•Replacing the nozzles that spray visually unevenly even after they are cleaned.
Rev. 00 - 04/2014

29
8  DESTRUCTION DISPOSAL
WARNING!
THE DESTRUCTION OF THE MACHINE MUST BE CARRIED OUT ONLY BY A TRAINED PERSON
OR BY A QUALIFIED TECHNICIAN.
When it has been decided to destroy the machine and to render it unusable, It is recommen-
ded that all parts which could be dangerous are rendered safe, removing all of the electrical
components, while conforming to current legislation regarding the scrapping of these mate-
rials. The various components should be brought to the appropriate recycling centres.
WARNING!
THE DISPOSAL OF THE MACHINE MUST BE CARRIED OUT ACCORDING TO THE LAWS OF THE
COUNTRY IN WHICH IT IS TO BE DISPOSED.
Rev. 00 - 04/2014Rev. 00 - 04/2014

Rev. 00 - 04/2014
www.idrobase.com
www.perfectcool.it
www.idrotech.com
www.sparesclub.com
Idrobase Group S.r.l.
Via dell’Industria, 25 • 35010 BORGORICCO (PD) • ITALY
Tel. [phone] • Fax [phone]
[e-mail]
www.idrobasegroup.com
Rev. 00 - 04/2014
