INSTALLATION INSTRUCTIONS LC41PI / LC48MPI POWER INJECTORS

J10

J6 J2 J3

J10

J6 J2 J3

J10

J6 J2 J3

PUTS

NONC NOC

ETHERN ET/

IED MID SPAN

Model# LANcom LC372SR

AUX

INPUT

CALLSWITCHES

REMOTEMIC

AUXAUDIO INPUT

+-S+-S +-S+-V

SPKR

OUT LINE

OUT MUTEP OWER FORM C RELA Y OUTPUTS

NC NOCNCNOCNCNOCNCNOC

ETHERNET/

IED MIDSPAN

2SR

HANDSET

INTER FACE

AUX

INPUT

CALL SWIT CHES

REMOTEMIC

IR RECEIVE R INPUTS

AUX AUDIO INPUT SPKR

OUT LINE

OUT MUTEPOWER FORMC RELAYOUTPUTS

ETHERN ET/

IED MID SPAN

HANDSET

INTERFACE

IR RECEIVE R INPUTS

2SR

HANDSET

INTERFACE

AUX

INPUT

CALLSWITCHES

REMOTEMIC

IR RECEIVE R INPUTS

ETHERN ET/

HANDSET

IR RECEIVE R INPUTS

LC372SR

LC331IC-C LC331IC-W LC331IC-W

LC48MPI

Category 5e

Cable

CONNECTION DIAGRAM

ETHERNET SWITCH

REV: 04-11 DOC: 1303B PAGE 1

INSTALLATION INSTRUCTIONS LC41PI / LC48MPI POWER INJECTORS

LC41PI / LC48MPI

POWER INJECTORS

Installation Instructions

INTRODUCTION

The LC41PI and LC48MPI Power Injectors are an integral part of the LANcom SCS system. They provide operating

voltage and current for the LC372SR Classroom Sound Reinforcement Module, LC331IC Integrated Communications

Module and other LANcom components.

The LC41PI 1-port power injector is a small power block that provides up to 1.35 amps of power for one LANcom SCS

endpoint device.

The LC48MPI 8-port power injector is a 1RU rack mount unit that provides power for up to eight LANcom SCS endpoints.

Each port can supply power to devices such as the LC372SR classroom sound reinforcement module with its 30 watt

amplifier. Every port is fuse protected and all ports can provide up to 1.35 amps simultaneously. Includes eight 3’ CAT6

patch cables

Figure 1 - LC41PI Front View

Figure 2 - LC48MPI Front View

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Install in accordance with the manufacturer’s in-

structions.

8. Do not install near any heat sources such as ra-

diators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9. Only use attachments/accessories specified by the

manufacturer.

10. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord

or plug is damaged, liquid has been spilled or ob-

jects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not

operate normally, or has been dropped.

SAFETY SYMBOLS

Labeling on products and the Installation Instructions &

User Manual may use safety related graphical symbols

as shown below to note safety requirements.

Lightning Bolt: The lightning flash with

arrowhead symbol, within an equilateral triangle,

WARNING symbol, is intended to alert the user to

the presence of un-insulated dangerous voltage

within the product’s enclosure that may be

sufficient in magnitude to constitute a risk of

electric shock to persons or domestic animals.

Exclamation Point: The exclamation point

within an equilateral triangle, CAUTION symbol,

is in-tended to alert the user to the presence of

important operating and maintenance (servicing)

instructions, or a hazard that can damage equip-

ment.

Do not proceed beyond a WARNING or CAUTION notice

until you have understood the hazardous condition and

have taken appropriate steps.

PAGE 2DOC: 1303B REV: 04-11

LC41PI / LC48MPI POWER INJECTORS INSTALLATION INSTRUCTIONS

CONNECTIONS

34 1

Figure 3 - LC41PI Front and Rear Views

34 2

345

Figure 4 - LC48MPI Front and Rear Views

1. Power Connector

This connector to attach a power cord to provide AC power to the device.

2. Input RJ45 (Data) Connector

This input RJ45 connector is used to connect to a network switch. This port connects to a non-powered network

switch and uses a connector wired as shown in Table 1.

3. Output RJ45 (Data / PWR) Connector

This output RJ45 connector is used to connect to a LANcom endpoint device that requires PoE for operation. This

port provides both data and +48V DC power to the device. The connector should be wired as shown in Table 2.

4. Indicator LED

This blue indicator LED indicates that power is present at the Data / PWR port.

5. Fuse

This is a replaceable fuse that protects the output of each port from drawing too much current.

DATA/

PWR DATA

REV: 04-11 DOC: 1303B PAGE 3

INSTALLATION INSTRUCTIONS LC41PI / LC48MPI POWER INJECTORS

RJ45 Connector Wiring

Each pair of ports connects to either a network switch or a LANcom endpoint device using CAT5e or better structured

cable. Each connector should be wired as shown below.

Pin Function CAT5 Color Code

1 Data Rx + Orange /W

2 Data RX – Orange

3 Data TX + Green /W

4 Not Used Blue

5 Not Used Blue/W

6 Data TX – Green

7 Not Used Brown /W

8 Not Used Brown

Table 1 - RJ45 Input (Data) Connector Wiring

Pin Function CAT5 Color Code

1 Data Rx + Orange /W

2 Data RX – Orange

3 Data TX + Green /W

4 +48V DC Blue

5 +48V DC Blue/W

6 Data TX – Green

7 –48V DC (Ground) Brown /W

8 –48V DC (Ground) Brown

Table 2 - RJ45 Output (Data / PWR) Connector Wiring

Fuse Replacement (LC48MPI Only)

If a fuse is blown, it can be replaced as shown in Figure 5. Use caution to ensure that the pins are properly aligned when

inserting a new fuse.

Figure 5 - Fuse Replacement (LC48MPI)

Specifications

Electrical

Input Voltage......................................................................................................... 85VAC – 264VAC, 50Hz – 60Hz

Output Voltage............................................................................................................................................. 48VDC

Output Current (per port)............................................................................................................................... 1.35A

Fuse (LC48MPI per port) ................................................................................................................ 1.5A slow-blow

Mechanical

LC41PI
