Sony Ipela PCS-XG80 Quick setup guide

HD VISUAL COMMUNICATION SYSTEM
PCS-XG80
PCS-XG80S
SYSTEM INTEGRATION MANUAL
1st Edition
Version 2.0

PCS-XG80
!警告
このマニュアルは，サービス専用です。
お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災，
人身事故につながることがあります。
危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.

1
PCS-XG80
Table of Contents
3. Maintenance
3-1. Updating of Software ...................................................... 3-1
3-1-1. Web Version-upgrade............................................. 3-1
3-1-2. Updating Using Memory Stick..............................3-5
3-1-3. Upgrading Using FTP (No Support)...................... 3-6
3-2. Optional Software Installation ........................................ 3-6
3-3. Confirmation Procedure of
Local Terminal Operation Using Self-Loop.................... 3-7
3-4. Description on Status Menu ............................................ 3-9
3-4-1. Network Routing Check ........................................ 3-9
3-4-2. Communication Mode Status...............................3-10
3-4-3. LAN Line Status .................................................. 3-11
3-4-4. Machine Information ........................................... 3-12
3-4-5. Peripheral Status .................................................. 3-14
3-5. Description on Service Menu........................................ 3-15
3-5-1. Displaying the Service Menu............................... 3-15
3-5-2. Description on Service Menu .............................. 3-16
3-6. How to Take Logs ......................................................... 3-18
3-6-1. Supported Logs .................................................... 3-18
3-6-2. System Log .......................................................... 3-18
3-6-3. Operation Log ...................................................... 3-20
3-6-4. Call Log ............................................................... 3-21
3-7. Network Trouble Check ................................................ 3-22
3-7-1. Test Procedure...................................................... 3-22
3-7-2. Description of Each Test...................................... 3-23
3-8. Replacing the Batteries.................................................. 3-27
1. Installation
1-1. Layout Information for PCS-XG80/XG80S ................... 1-3
1-1-1. Simple Connection................................................. 1-3
1-1-2. Camera Connection................................................ 1-4
1-1-3. Microphone Connection ...................................... 1-10
1-1-4. Audio Specifications and Settings ....................... 1-13
1-1-5. Echo Canceller..................................................... 1-19
1-1-6. Monitor Connection............................................. 1-20
1-1-7. Pen Tablet............................................................. 1-21
1-1-8. Remote Commander and Pairing......................... 1-22
1-1-9. Two Serial Ports on PCS-XG80S ........................ 1-24
1-2. System Connections ...................................................... 1-26
1-2-1. System Connection via a LAN and a SIP............1-26
1-2-2. PCS-XG80 Connection Using SIP.......................1-27
1-2-3. System Connection via an ISDN ......................... 1-28
1-2-4. System Configuration Using
Two IP Connections ............................................. 1-29
1-2-5. IPv6...................................................................... 1-30
1-2-6. Multipoint Connection
(Example of Connection).....................................1-30
1-2-7. Multipoint Connection (Screen Display)............. 1-33
1-2-8. To Connect a Video Equipment for Input ............ 1-41
2. Setup/Alignment and Video Mode
2-1. Turning the System On/Off............................................. 2-1
2-1-1. Turning On the System .......................................... 2-1
2-1-2. Turning Off the System ......................................... 2-1
2-2. Initial Setup and Other Setup .......................................... 2-2
2-2-1. Setup of Your First Time Power-On ...................... 2-2
2-2-2. Other Setup ............................................................ 2-6
2-3. Video Mode and Bandwidth............................................2-9
2-3-1. 1080i Mode ............................................................ 2-9
2-3-2. 720P and Other Mode .......................................... 2-10

1-1
PCS-XG80
Section 1
Installation
This section describes the typical system connections. Refer to the Operating Instructions supplied with
the unit together.
n
The PCS-XG80S, PCS-RF1 and PCSA-CXG80 all incorporate an RF (radio frequency) transmitting and
receiving module.
For notes on RF waves, refer to the operating instructions supplied with the unit.
Position the camera and microphone appropriately in the video conferencing room.
c
You must turn off the power to the HD visual Communication System before attempting to connect the
camera to the system using the supplied camera cable. Otherwise, the camera and/or system may be
damaged, or the picture may not be displayed.

1-2 PCS-XG80
Installation Flowchart
Preparation at
location of installation
Unpacking
Check of supplied accessories
Software installation
Yes
No
<Refer to “1-1. Layout information for PCS-XG80/XG80S”>
<Refer to “1-1-1. Simple Connection”>
<Refer to “3-8. Replacing the Batteries”>
<Refer to “2-1-1. Turning On the System”>
<Refer to “2-2-1. Setup of Your First Time Power-On”>
System connections <Refer to “1-2. System Connections”>
Other setup, if needed <Refer to “2-2-2. Other Setup”>
Operation test and confirmation
Turn off the system <Refer to “2-1-2. Turning Off the System”>
End
Turn on the power to the system
and perform initialization
<Refer to “3-1. Updating of Software”>
<Refer to “3-2. Optional Software Installation”>
.Updating of software
.Optional software installation

1-3
PCS-XG80
*Supplied cable
*Supplied
*Supplied
*Supplied
Not supplied To LAN
Not supplied
PCS-XG80S rear panel

*Supplied cable
Connector caps for REC OUT and LAN2, indicated by the shading, are fitted at the factory.
1-1. Layout Information for PCS-XG80/XG80S
1-1-1. Simple Connection
Making a “simple connection”
To start video conferencing by making a “simple connection”, connect the cables to the green connectors,
as shown below.
Connect the HDMI cable. (HD video and stereo audio)
Connect the camera cable.
Connect the microphones.
Connect the network cable.
Connect the AC power adaptor.

1-4 PCS-XG80
4 m
(13.12 ft)
1.5 m (4.92 ft)
5.6 m (18.37 ft)
100d
100d
70d
1-1-2. Camera Connection
Shooting range of camera unit
Be sure to position the camera and microphone appropriately in your video conferencing room.
represents the shooting area of the camera when the zoom has been extended fully. indicates the
shooting area of the camera when the angling function is fully utilized. Use the measurements shown
below as a guide for the layout of your video conferencing room.
Top view (horizontal range at maximum zoom-out)
Installing the camera on a desk
Place the camera on a flat surface whenever possible. In extreme circumstances, you may place the cam-
era on an inclined surface provided the inclination does not exceed ?15 degrees, to ensure that the pan/tilt
operates correctly.

1-5
PCS-XG80
TERMINALVISCA OUT
POWER/STANDBY




Front Rear

Location and function of camera parts
Lens
This is a 10-magnification optical zoom lens.
POWER/STANDBY indicator
TERMINAL connector
Connect to the CAMERA connector on the HD Visual Communication System.
Receiver of the RF Remote Commander
The Remote Commander and the Communication System are paired at the factory.
If the Communication System is located apart from the Remote Commander, it may not be controlled
due to the condition of reception. In this case, perform the procedure to pair the Camera Unit with the
Remote Commander. Refer to the Operating Instructions or 1-1-8 “Remote Commander and Pairing”.
Operable distance of RF-Remote Commander is 10 m (30 ft.). Depending on the circumstances, a
longer operable distance may be possible.
VISCA OUT connector
This is used for VISCA connection to 2nd camera. When a second camera is connected with the HD
Visual Communication System, connect the VISCA cable from the first camera with the VISCA IN of
the second camera. Please refer to “Connecting HD camera as 2nd Camera”. (page 1-9)

1-6 PCS-XG80
18
9
D-sub 15-pin Male
(Plug)
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Signal Coaxial cable 75 Z
1.5C-2 V
Coaxial cable 75 Z
1.5C-2 V
Coaxial cable 75 Z
1.5C-2 V
Twisted pair
AWG #28
Twisted pair
AWG #28
AWG #24
AWG #24
Y_CAM
Y_CAM(RET)
Pb_CAM
Pb_CAM(RET)
Pr_CAM
Pr_CAM(RET)
TXD(for external camera)
RXD(for external camera)
+19.5 V
LVDS_RXD+
LVDS_RXD_
LVDS_TXD+
LVDS_TXD_
GND
Shell Shield Shield
15
18
9
D-sub 15-pin Male
(Plug)
Terminal side Camera side
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Signal
Y_CAM
Y_CAM(RET)
Pb_CAM
Pb_CAM(RET)
Pr_CAM
Pr_CAM(RET)
+19.5 V
LVDS_TXD+
LVDS_TXD_
LVDS_RXD+
LVDS_RXD_
GND
Shell
15
Camera cable length
.The PCSA-CXG80 is provided with a 3-m (10-ft.) camera cable as standard.
.If you need to extend the camera cable, refer to “Camera connector pin assignments/cable wiring,”
shown below.
The camera cable line, corresponding to pin numbers 1 to 6, must be made up using coaxial cable (75 Z).
For pin numbers 1 to 6 and 9, the characteristics, structure, and line gauge must be as shown below. You
can extend the camera cable up to a maximum length of 20 m (60 ft.). Test the cable before attempting
to use it.
Camera connector pin assignments/cable wiring
The camera connector pin assignments/cable wiring are as shown below.

1-7
PCS-XG80
Supported cameras
The PCS-XG80S can be connected to the following cameras.
As the first camera, PCSA-CXG80, PCSA-CG70, EVI-HD1, BRC-H700/Z700.
As a second camera, EVI-HD1, BRC-H700/Z700. (BRC-Z700 is supported by Ver. 2 and later.)
Camera image flip
Allows you to rotate the camera image through 180 degrees when the first or the second camera is in-
stalled in a ceiling. This is done from the setting menu. For an explanation of the settings, refer to the
operating instructions supplied with the unit.
This function is supported only by the BRC-H700/Z700. It is not supported by any other camera models.
Connecting an EVI-HD1 as 1st camera
Connecting an EVI-HD1 as 1st camera is as below.
n
When using a camera other than PCSA-CXG80, you should not set the “RF Remote Control Reception”
as “Camera”.
1
8
9
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
AWG#28
AWG#28
AWG#28
AWG#26
To PCS-XG80S To EVI-HD1
EVI-HD1
To EVI-HD1
AWG#26
AWG#26
Shell
Shell
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Shell
1
2
3
4
5
6
7
8
11(R)
(PLUG IN POWER)
2(L)
RLRLRL
2
S VIDEO IN RGB IN RGB OUT HDMI OUT
1
- EXT - 2REC OUTAUDIO OUTAUDIO 1 IN
AUX CONTROL
2
CAMERA
EC-MIC(A7) MIC(A1/A3)
1
DC 19.5V
ISDN UNIT
15
11
5
1
7
6
8
3
5
1
2
10
6
Breakout cable is separately required.
(For detail, contact your local Sony Sales Office/Service Center.)
PCS-XG80S rear panel
Breakout
cable

1-8 PCS-XG80
Connecting a BRC-H700/Z700 as the 1st camera
A BRC-H700/Z700 is connected as the 1st camera as described below.
You can use the breakout cable as explained in “Connecting an EVI-HD1 as the 1st camera”.
n
Configure the cameras so that a COMPONENT signal is output from their RGB/COMPONENT outputs.
When using a camera other than the PCSA-CXG80, do not set “RF Remote Control Reception” to “Cam-
era”.
11(R)
(PLUG IN POWER)
2(L)
RLRLRL
2
S VIDEO IN RGB IN RGB OUT HDMI OUT
1
- EXT - 2REC OUTAUDIO OUTAUDIO 1 IN
AUX CONTROL
2
CAMERA
EC-MIC(A7) MIC(A1/A3)
1
DC 19.5V
ISDN UNIT
11(R)
(PLUG IN POWER)
2(L)
RLRLRL
2
S VIDEO IN RGB IN RGB OUT HDMI OUT
1
- EXT - 2REC OUTAUDIO OUTAUDIO 1 IN
AUX CONTROL
2
CAMERA
EC-MIC(A7) MIC(A1/A3)
1
DC 19.5V
ISDN UNIT
RGB/COMPONENT
VISCA RS-422
1 2 3 4 5 6 7 8 9
EXT SYNC IN VIDEO
IR SELECT
75
1 2 3
OFF ON
DATA M IX
OFF ON
IN VISCA RS-232C OUT S VIDEO
DC IN 12V
R
BRC-H700 BRC-Z700
RGB/COMPONENT
VISCA RS-422
1 2 3 4 5 6 7 8 9
EXT SYNC IN
IR SELECT
75 1 2 3
DATA MIX
OFF ON
OFF ON
IN VISCA RS-232C OUT
DC IN 12V
R
Breakout cable is separately required.
(For detail, contact your local Sony Sales
Office/Service Center.)
PCS-XG80S rear panel PCS-XG80S rear panel
Breakout
cable
Breakout
cable

1-9
PCS-XG80
Connecting PCSA-CG70 as 1st camera
When using the PCSA-CG70 as the first camera, use the camera cable provided with the camera and
connect this cable to the PCSA-XG80S.
n
When using a camera other than PCSA-CXG80, you should not set the “RF Remote Control Reception”
as “Camera”.
Connecting HD camera as 2nd camera
Connecting HD camera as 2nd Camera is as below.
100 preset camera settings
Up to 100 camera angle/zoom settings can be registered in the system’s preset memory.
For an explanation of how to register a preset, refer to the Operating Instructions supplied with the unit.
For both the 1st and 2nd camera, up to 100 settings can be stored in the Communication System.
Ver. 2.0 and later support the saving of thumbnails together with the camera preset settings.
When the preset settings are recalled from the Communication System, the system automatically switches
from the 1st to the 2nd camera (or from the 2nd to the 1st camera).
TERMINAL
VISCA OUT
/
OPEN
VIDEO IN AUDIO 2 IN
MAINTENANCE
YPbPrL R
1st HD camera
Component cable
VIDEO
(Y, Pb, Pr)
IN *Commercially available
Camera cable
*Supplied with camera
VISCA cable
*Commercially available
2nd HD camera
D-sub 15 pin
EVI-HD1,
BRC-H700/Z700
(BRC-Z700 is supported
since Ver. 2 release)

1-10 PCS-XG80
1-1-3. Microphone Connection
The PCS-A1, PCSA-A3 and PCSA-A7 microphones can be connected to the input of the PCS-XG80S.
Up to two PCS-A1 microphones, up to two PCSA-A3 microphones, and up to 80 PCSA-A7 (cascaded
connection 40 +cascaded connection 40) can be connected. When you connect the microphone(s) to the
PCS-XG80S, pay careful attention to the positioning guidelines described below.
PCS-A1, PCSA-A3 microphone layout
The positioning of the PCS-A1, PCSA-A3 microphones with the PCS-XG80/XG80S is the same as with
other models in the PCS series. For details, refer to the Operating Instructions.
Two recommended audio setups (Case1 and Case2) are shown below.
Case1
Microphone PCS-A1 x2
Suggested number 4 to 6 persons
Input audio mode (microphone) Stereo *1
Output audio mode (loud speaker) Stereo *1
Setup menu configuration Communication: Audio mode MPEG4
Audio 1: Audio Input MIC
Audio 1: Input select (MIC) MIC (A1/A3)
Audio 1: Input Mode Stereo *1
Audio 1: Output Mode Stereo *1
Audio 1: Echo canceller On
n
*1 “Stereo or Monaural” depends on the setting of Input Mode/Output Mode of far end point.
*Place each loud speaker at least 1.5 m from the PCS-A1.
3 m or less
0.5 m to 1.5 m
PCS-A1 x2
Loud
speaker
R
L
Loud
speaker
1 m to 1.5 m

1-11
PCS-XG80
Case2
Microphone PCS-A1 x2
Suggested number 10 to 14 persons
Input audio mode (microphone) Monaural
Output audio mode (loud speaker) Stereo *1
Setup menu configuration Communication: Audio mode MPEG4
Audio 1: Audio Input MIC
Audio 1: Input select (MIC) MIC (A1/A3)
Audio 1: Input Mode Monaural
Audio 1: Output Mode Stereo *1
Audio 1: Echo canceller On
n
*1 “Stereo or Monaural” depends on the setting of Input Mode/Output Mode of far end point.
*Place each loud speaker at least 1.5 m from the PCS-A1.
0.5 m to 1.5 m
3 m or less
PCS-A1 x2
Loud
speaker
Loud
speaker
R
L

1-12 PCS-XG80
PCSA-A7
PCS-XG80/XG80S
1.5 m
Loud speaker
PCSA-A7 microphone layout
Be particularly careful when setting up the PCSA-A7 microphones, referring to the layout shown below.
Position the PCSA-A7 microphone at least 1.5 m (5 ft.) from the loud speaker. Otherwise echo is likely
to be a problem.
n
Notes on placing the PCSA-A7 microphones
.Position the microphones about 50 cm (1.6 ft) from the participants.
.For details on the cascade layout and the power supply of the PCSA-A7, refer to the Operating Instruc-
tions.

1-13
PCS-XG80
11(R)
(PLUG IN POWER)
2(L)
RLRLRL
2
S VIDEO IN RGB IN RGB OUT HDMI OUT
1
- EXT - 2REC OUTAUDIO OUTAUDIO 1 IN
AUX CONTROL
2
CAMERA
EC-MIC(A7) MIC(A1/A3)
1
DC 19.5V
ISDN UNIT

OPEN
LAN 1 ALERT LAN 2 ALERT
/
OPEN
VIDEO IN AUDIO 2 IN
MAINTENANCE
YPbPr L R

1-1-4. Audio Specifications and Settings
Audio and microphone input/output signal specification
No. Connector name Type I/O I/O level
specification
(MAX)
I/O level
specification
(STANDARD)
Band-
width
(max)
Specification
(input/output
impedance, etc)
1 EC-MIC (A7)
1/2
Special 10
pin
I/O A7 Special A7 Special 16 kHz Digital I/F
12 V power supply
2 MIC (A1/A3)
L/R
mini jack I A1/A3 Special A1/A3 microphone
sensitivity
_33 dBs@34 dBspl
16 kHz 4.8 kZ
(Plug in
power 2.5 V)
3 AUDIO 1 IN L/R RCA Male I +9 dBs max
(max: clip level)
_11 dBs 22 kHz 47 kZor more,
unbalanced
4 AUDIO OUT L/R RCA Male O +6 dBs _14 dBs 22 kHz 1 kZor less
5 REC OUT L/R RCA Male O +6 dBs _14 dBs 22 kHz 1 kZor less
6 AUDIO 2 IN L/R RCA Male I +9 dBs max
(max: clip level)
_11 dBs 22 kHz 47 kZor more,
unbalanced

1-14 PCS-XG80
Notice of external microphone usage
If you connect external microphones with “AUDIO 1 IN” or “AUDIO 2 IN”, you need to use Mic Mixer
and adjust its output level to line level, and this output should be inputted to “AUDIO 1 IN” or “AUDIO 2
IN”.
Adjust the audio level by watching the level meter displayed on the monitor to prevent level clipping. The
level meter can be displayed by setting “On” of “Setup →Home Menu 3 →Audio Level Meter”.
When “AUDIO 1 IN” and “AUDIO 2 IN” are used as AUX which can be selected in Setup menu (Setup
→Audio 1 →Audio Input), up to 22 kHz input signal can be passed through, but echo canceling function
cannot be used.
When “AUDIO 1 IN” and “AUDIO 2 IN” are used as MIC which can be selected in Setup menu
(Setup →Audio 1 →Audio Input), echo canceling function can be used (but input frequency is
limited.).
For details of Menu settings, refer to “To set up audio input and echo canceller” in 2-2-2.
Adjusting the volume from the remote party’s audio by viewing the volume level of the
Communication System and adjusting the volume on the TV monitor
Before adjusting the volume on the TV monitor, set the volume on the Communication System to the
appropriate position.
1. To display the volume meter, confirm its setting. (Setup →Home Menu 3 →Volume)
2. Press the VOLUME [+]/[_] buttons on the remote commander to set the volume level, such that the
bar displayed on the screen is adjusted to the middle position.
3. Adjust the volume on the TV monitor so that you can clearly hear a remote party speaking.
n
Do not activate the TV’s surround sound feature as it may prevent the echo canceller of the Commu-
nication System from functioning properly and thus produce an unexpected sound. During communi-
cation, set the volume on the Communication System to the appropriate level. Do not adjust the
volume on the TV monitor.

1-15
PCS-XG80
Setting the audio mode and determining the current mode
The following table shows the relationship between the “Audio mode” setting under the Communication
Mode menu, configured for each terminal at the transmission and reception sides, as well as the negotiated
mode.
When the communication bit rate exceeds 128 kbps:
“Audio mode” setting at Receiver Side (Communication Setup Menu)
MPEG MPEG MPEG MPEG
G.722 G.722 G.722 G.722
G.728 G.728 G.728 G.728
G.711 G.711 G.711 G.711 G.711 G.711 G.711 G.711
“Audio mode”
setting at Sender
Side
(Communication
Setup Menu)
MPEG G.722 G.728 G.711 *1*1*1G.722 *1G.722 G.728 G.711
MPEG G.722 G.711 *1*1*1G.722 *1G.722 G.711 G.711
MPEG G.728 G.711 *1*1*1G.728 *1G.711 G.728 G.711
G.722 G.728 G.711 G.722 G.722 G.728 G.722 G.711 G.722 G.728 G.711
MPEG G.711 *1*1*1G.711 *1G.711 G.711 G.711
G.722 G.711 G.722 G.722 G.711 G.722 G.711 G.722 G.711 G.711
G.728 G.711 G.728 G.711 G.728 G.728 G.711 G.711 G.728 G.711
G.711 G.711 G.711 G.711 G.711 G.711 G.711 G.711 G.711
*1: When the communication bit rate exceeds 768 kbps, the audio mode is AAC Stereo, and when it is between 128kbps-768kbps, AAC Monaural.
When the communication bit rate is 128 kbps or less:
“Audio mode” setting at Receiver Side (Communication Setup Menu)
MPEG MPEG MPEG MPEG
G.722 G.722 G.722 G.722
G.728 G.728 G.728 G.728
G.711 G.711 G.711 G.711 G.711 G.711 G.711 G.711
“Audio mode”
setting at Sender
Side
(Communication
Setup Menu)
MPEG G.722 G.728 G.711 G.728 AAC
Mono G.728 G.728 AAC Mono G.722 G.728 G.711
MPEG G.722 G.711 AAC
Mono
AAC
Mono
AAC
Mono G.722 AAC Mono G.722 G.711 G.711
MPEG G.728 G.711 G.728 AAC
Mono G.728 G.728 AAC Mono G.711 G.728 G.711
G.722 G.728 G.711 G.728 G.722 G.728 G.728 G.711 G.722 G.728 G.711
MPEG G.711 AAC
Mono
AAC
Mono
AAC
Mono G.711 AAC Mono G.711 G.711 G.711
G.722 G.711 G.722 G.722 G.711 G.722 G.711 G.722 G.711 G.711
G.728 G.711 G.728 G.711 G.728 G.728 G.711 G.711 G.728 G.711
G.711 G.711 G.711 G.711 G.711 G.711 G.711 G.711 G.711

1-16 PCS-XG80
Audio output delay setting
Using the Lip Sync function closely synchronizes the audio and video signals. Even with the Lip Sync
function, however, there still may be a slight time lag, but this can be eliminated by setting a value in
“Audio Output Delay Setting”.
Note that, when the audio signal is fed to an audio system other than that built into the video display, even
using Lip Sync function will not be eliminate the time lag between the audio and video. The time lag can
also be eliminated by setting a delay in “Audio Output Delay Setting”. “Default” is that value with which
the audio is almost synchronized with the video. You can select “Default”, “Default ?50 ms”, and “De-
fault ?100 ms”. When you select “Custom”, an audio output delay between 0 ms and 500 ms can be set as
an absolute delay (Ver.2.01 and later), which has no relation to the Default value.
Audio input delay setting
When there is a time lag between the input audio and input video, a delay can be set in “Audio Input
Delay” to adjust the audio to the video.
An identical delay is set for all the microphones and all the external lines of the Communication System.
After setting up the audio and video system to operate with the Communication System, setting “Audio
Input Delay”, but then disconnecting the audio and video system from the Communication System,
restore the original values or set the “Default” value.
“Audio Delay from Video Picture at Remote Party” contains “Audio Input Delay” set for the local party
and the “Audio Output Delay” set for the remote party. The optimum “Audio Output Delay” setting is
adjusted for each remote party according to the individual usage circumstances, so it is recommended to
use the “Default” value for “Audio Input Delay Setting”.
