IEI Technology KINO-DH310 User manual

1
Mini-ITX SBC supports 14nm LGA1151 Intel® 8th Generation Core™
i7/i5/i3, Celeron® and Pentium® processor, DDR4, dual independent
displays, dual GbE LAN, M.2, SATA 6Gb/s, HD Audio and RoHS
KINO-DH310
Quick Installation Guide
Version 1.0
March 26, 2020
Package List
KINO-DH310 package includes the following items:
1 x KINO-DH130 single board computer
1 x I/O Shielding
1 x SATA cable
1 x QIG
©2020 Copyright by IEI Integration Corp.
All rights reserved.
All manuals and user guides at all-guides.com

2
Specifications
CPU:
LGA1151 socket supports 8th generation Intel® Core™ i7/i5/i3,
Pentium® or Celeron® processor (35W/65W)
System Chipset:Intel® H310
Memory:
Two 260-pin 2666/2400 MHz dual-channel DDR4 SDRAM
un-buffered SO-DIMMs supporting up to 64GB
BIOS: AMI UEFI BIOS
Graphics Engine:
Intel® HD Graphics Gen 9 Engines with low power 16
execution units, support DX11.3/12, OpenGL 4.3/4.4/4.5and
OpenCL1.2/2.0/2.1
Display Output:
Dual independent display
2 x HDMI ( up to 1920 x 1080@60Hz/ 4960x2160@24Hz)
1 x internal DP (up to 4096 x 2304@60Hz) (optional)
Ethernet:
LAN1: Realtek RTL8111H PCIe GbE controller
LAN2: Realtek RTL8111H PCIe GbE controller
External I/O Interface:
4 x USB 3.2 Gen 1
2 x RS-232
Internal I/O Interface:
2 x SATA 6Gb/s with 5/12V SATA power connector (No RAID)
4 x USB 2.0 (2x4 pin, P=2.0)
1 x RS-232 (2x5 pin, P=2.0)
1 x RS-422/485 (1x4 pin, P=2.0)
1 x KB/MS (1x6 pin)
SMBus:1 x SMBus (1x4 pin)
I²C:1 x I²C (1x4 pin)
Audio:
All manuals and user guides at all-guides.com

3
Realtek ALC662 HD codec
2 x Audio jack (Lin-out, Mic-in)
1 x Front audio (2x5 pin)
Front Panel:
1 x Front Panel (1x10 pin, power LED, HDD LED, power
button, reset button)
LEN LED: 2 x LAN LED (1x2 pin)
Expansion:
1 x PCIe x16
1 x M.2 M key (2280, Gen 2, PCIe x2 only)
1 x M.2 A key (2230, PCIe x1 & USB 2.0)
Watchdog Timer:
Software Programmable support 1~255 sec. System reset
Digital I/O:1 x 8-bit digital I/O (2x5 pin)
TPM:1 x TPM (2x10 pin)
Fan Connector:
2 x Smart fan connector (1x4 pin)
Chassis Open:1 x Chassis intrusion (1x2 pin)
Power supply:
DC 12V input
1 x External DC jack (4-pin DIN)
1 x Internal power connector (2x2 pin)
Support AT/ATX mode
ErP/EuP Compliant
Power Consumption:
12V@11.32A (Intel® Core™ i7-8700 up to 4.60 GHz CPU with
two 8GB 2666MHz DDR4 memory)
Operation Temperature: -0°C ~ 60°C
Storage Temperature: -10°C ~ 70°C
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 170mm x 170mm
Weight (GW/NW): 900g / 400g
All manuals and user guides at all-guides.com

4
CE/FCC compliant
Ordering Information
KINO-DH310-R10:
Mini-ITX SBC supports 14nm LGA1151 Intel® 8th Generation Core™
i7/i5/i3, Celeron® and Pentium® processor, DDR4, dual independent
displays, dual GbE LAN, M.2, SATA 6Gb/s, HD Audio and RoHS
KINO-DH310-DP-R10**:
Mini-ITX SBC supports 14nm LGA1151 Intel® 8th Generation
Core™ i7/i5/i3, Celeron® and Pentium® processor, DDR4,
dual independent displays, dual GbE LAN, M.2, SATA 6Gb/s,
HD Audio, DP and RoHS
32006-001100-201-RS: PS/2 KB/MS cable, 135mm, P=2.0
32001-008600-200-RS:Dual port USB cable, 210mm, P=2.0
32205-002700-200-RS:RS-232 cable, 200mm, P=2.0
CF115XA-R10: High-performance LGA1155/1156 cooler kit, 1U
chassis compatible 73W
CF-115XC-R10:
LGA1155/LGA1156 cooler kit, 1U chassis compatible, 45W
CF-115XD-R10:
LGA1155/LGA1156 cooler kit, 1U chassis compatible, 65W
TPM-IN02-R20: 20-pin Infineon TPM 2.0 module, software
management tool, firmware v5.5
All the drivers and utilities for the
KINO-DH310 are available on IEI
Resource Download Center. Type
KINO-DH310 and press Enter to find all
the relevant software, utilities, and
documentation. To install software from
the downloaded ISO file, mount the file
as a virtual drive to view its content.
IEI Resource Download Center
https://download.ieiworld.com
All manuals and user guides at all-guides.com

5
Jumpers setting and connectors
LABEL
FUNCTION
J_ATX_AT1
AT/ATX Power Mode Setting
J_CMOS1
Clear CMOS Button
USB SW1, USB SW2
USB Power Setting
J_FLASH1
Flash Descriptor Security Override
F_PANEL1
PWR & RST Buttons and Indicators
HDMI1
HDMI Port B (Up) & HDMI Port C (Down)
Connector
DP1
Internal Display Port Connector
LAN1_USB1
RJ-45 LAN and USB 3.2 Gen 1 Connector
LAN2_USB2
RJ-45 LAN and USB 3.2 Gen 1 Connector
KB_MS1
6-pinheader Keyboard & Mouse Connector
USB1, USB2
Internal USB 2.0 Connectors
COM3
Internal RS-232 Serial Port Connector
COM1
External RS-232 Serial Port Connector
AUDIO_CV1
HD Audio Connector
FRONT_PANEL1
Front Panel Audio Connector
SATA1, SATA2
SATA 6Gb/s Connectors
M2_M1
M.2 M-key Connector
CPU_FAN1
CPU Fan Connector
SYS_FAN1
System Fan Connector
DIO1
Digital Input / Output Connector
PWR1
External Power Connector
CN2
Internal Power Connector
SMB1
SMBus Connector
I2C1
I2C Connector (to EC)
LED_LAN1
LAN1 LED Connector
LED_LAN2
LAN2 LED Connector
CHASSIS1
Chassis Status Connector
M2_A1
M.2 A-key Connector
CN1
EC Debug Port Connector
SATA_PWR1,
SATA_PWR2
SATA Power Connectors
All manuals and user guides at all-guides.com

6
COM4
Internal RS-422/485 Serial Port Connector
TPM1
Trusted Platform Module Connector
J_ATX_AT1: AT/ATX Power Mode Setting
PIN NO.
DESCRIPTION
Short 1 - 2
ATX Power Mode (default)
Short 2 - 3
AT Power Mode
J_CMOS1: Clear CMOS Button
PIN NO.
DESCRIPTION
NC (default)
Keep CMOS Setup
(Normal Operation)
Press button
Clear CMOS Setup
USB SW1, USB SW2: USB Power Setting
USB SW1
DESCRIPTION
+5V DUAL
5V DUAL (default)
+5V
+5V
J_FLASH1: Flash Descriptor Security Override
PIN NO.
DESCRIPTION
Short 1 - 2
Disabled (default)
Short 2 - 3
Enabled
All manuals and user guides at all-guides.com

7
F_PANEL1: PWR & RST Buttons and Indicators
PIN
DESCRIPTION
PIN
DESCRIPTION
1
NC
6
PWRLED
PWR
LED
PWR
BTN
2
PWRBTSW#
7
PWRLED
3
GND
8
GND
HDD
LED
4
+V5S
9
RESET+
RESET
5
HDD_LED-
10
GND
HDMI1: HDMI Port B (Up) & HDMI Port C (Down) Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
A1
TMDS_C_DATA2P
B1
TMDS_B_DATA2P
A2
GND
B2
GND
A3
TMDS_C_DATA2N
B3
TMDS_B_DATA2N
A4 TMDS_C_DATA1P B4 TMDS_B_DATA1P
A5
GND
B5
GND
A6
TMDS_C_DATA1N
B6
TMDS_B_DATA1N
A7 TMDS_C_DATA0P B7 TMDS_B_DATA0P
A8
GND
B8
GND
A9
TMDS_C_DATA0N
B9
TMDS_B_DATA0N
A10
TMDS_C_CLKP
B10
TMDS_B_CLKP
A11
GND
B11
GND
A12
TMDS_C_CLKN
B12
TMDS_B_CLKN
A13
NC
B13
NC
A14 NC B14 NC
A15
DDC_C_CLK
B15
DDC_B_CLK
A16
DDC_C_SDA
B16
DDC_B_SDA
A17 GND B17 GND
A18
+5V
B18
+5V
A19
HDMI_C_HPD
B19
HDMI_B_HPD
All manuals and user guides at all-guides.com

8
DP1: Internal Display Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+5V
11
AUXP
2
LANE1N
12
AUXN
3
LANE1P
13
GND
4
GND
14
LANE2P
5
LANE3N
15
LANE2N
6
LANE3P
16
GND
7
GND
17
LANE0P
8 AUX_CTRL_DET_D 18 LANE0N
9
GND
19
+3.3V
10
HPD
LAN1_USB1: Ethernet and USB 3.2 Gen 1 Connectors
USB1: External USB 3.2 Gen 1 Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 VCC 10 VCC
2
USB_DATA-
11
USB_DATA-
3
USB_DATA+
12
USB_ DATA+
4
GND
13
GND
5
USB3_RX-
14
USB3_RX-
6
USB3_RX+
15
USB3_ RX+
7
GND
16
GND
8 USB3_TX- 17 USB3_TX-
9
USB3_TX+
18
USB3_TX+
LAN1: RJ-45 LAN connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
20
LAN1_MDI0P
24
LAN1_MDI2P
21
LAN1_MDI0N
25
LAN1_MDI2N
22
LAN1_MDI1P
26
LAN1_MDI3P
23
LAN1_MDI1N
27
LAN1_MDI3N
All manuals and user guides at all-guides.com

9
LAN2_USB2: Ethernet and USB 3.2 Gen 1 Connectors
USB2: External USB 3.2 Gen 1 Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
10
VCC
2
USB_DATA-
11
USB_DATA-
3
USB_DATA+
12
USB_ DATA+
4
GND
13
GND
5
USB3_RX-
14
USB3_RX-
6
USB3_RX+
15
USB3_ RX+
7 GND 16 GND
8
USB3_TX-
17
USB3_TX-
9
USB3_TX+
18
USB3_TX+
LAN2: RJ-45 LAN connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
20
LAN1_MDI0P
24
LAN1_MDI2P
21
LAN1_MDI0N
25
LAN1_MDI2N
22
LAN1_MDI1P
26
LAN1_MDI3P
23
LAN1_MDI1N
27
LAN1_MDI3N
KB_MS1: 6-pinheader Keyboard/Mouse Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
Mouse Data
3
Mouse Clock
4
Keyboard Data
5
Keyboard Clock
6
GND
USB1, USB2: Internal USB 2.0 Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
GND
3
USB_DATA-
4
USB_DATA+
5
USB_DATA+
6
USB_DATA-
7
GND
8
VCC
All manuals and user guides at all-guides.com

10
COM3: Internal RS-232 Serial Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
DSR
3
RXD
4
RST
5
TXD
6
CTS
7
DTR
8
RI
9
GND
10
GND
COM1: External RS-232 Serial Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI1
AUDIO_CV1 : Audio Line-In/Out MIC Connector
PIN NO.
DESCRIPTION
Line_Out
(Green)
Connect this port to headphone or speaker
Microphone
(Pink)
Connect this port to microphone
FRONT_PANEL1: Front Panel Audio Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LMIC2-L
2
AUD_GND
3
LMIC2-R
4
PRESENCE#
5
LLINE2-R
6
MIC2-JD
7
FRONT-IO
8
NC
9
LLINE2-L
10
LINE2-JD
All manuals and user guides at all-guides.com

11
M2_M1: M.2 M-key Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
3.3V
3
GND
4
3.3V
5
N/A
6
NC
7
N/A
8
NC
9
GND
10
NC
11
N/A
12
3.3V
13
N/A
14
3.3V
15
GND
16
3.3V
17
N/A
18
3.3V
19
N/A
20
NC
21
GND
22
NC
23
N/A
24
NC
25
N/A
26
NC
27
GND
28
NC
29
PERn1
30
NC
31
PERp1
32
NC
33
GND
34
NC
35
PETn1
36
NC
37
PETp1
38
NC
39
GND
40
NC
41
PERn0
42
NC
43
PERp0
44
NC
45
GND
46
NC
47
PETn0
48
NC
49
PETp0
50
NC
SATA1, SATA2: SATA 6Gb/s Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
5
SATA_RX-
2
SATA_TX+
6
SATA RX+
3
SATA_TX-
7
GND
4
GND
8
N/C
All manuals and user guides at all-guides.com

12
51
GND
52
NC
53
CLKN
54
NC
55
CLKP
56
NC
57
GND
58
NC
59
NC
60
NC
61
NC
62
NC
63
NC
64
NC
65
NC
66
NC
67
NC
68
NC
69
PEDET
70
3.3V
71
GND
72
3.3V
73
GND
74
3.3V
75
GND
CPU_FAN1: CPU Fan Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+12V
3
FANIO
4
PWM
SYS_FAN1: System Fan Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+12V
3
FANIO
4
PWM
DIO1: Digital Input / Output Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
VCC
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0
All manuals and user guides at all-guides.com

13
PWR1: Power Connector (12V, Power Adapter)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
GND
3
VCC
4
GND
5
GND
CN2: Internal Power Connector (12V)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
GND
3
VCC
4
VCC
SMB1: SMBus Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
SMB_DATA
3
SMB_CLK
4
+5V
I2C1: I2C Connector (to EC)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
PCH_GP38
3
PCH_GP39
4
+5V
LED_LAN1: LAN Link LED Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
+3.3V
2
LAN1_LED_LNK#_ACT
LED_LAN2: LAN Link LED Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
+3.3V
2
LAN2_LED_LNK#_ACT
CHASSIS1: Chassis Status Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
1
+3.3VSB
2
CHASSIS OPEN
All manuals and user guides at all-guides.com

14
M2_A1: M.2 A-key Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+3.3V
3
USB2_DP
4
+3.3V
5
USB2_DN
6
NC
7
GND
8
9
10
11
12
13
14
15
16
NC
17
NC
18
GND
19
NC
20
NC
21
NC
22
NC
23
GND
24
GND
25
NC
26
NC
27
NC
28
NC
29
GND
30
GND
31
NC
32
NC
33
GND
34
NC
35
PETP0
36
GND
37
PETN0
38
NC
39
GND
40
NC
41
PERP0
42
NC
43
PERN0
44
NC
45
GND
46
NC
47
PCIE_CLK+
48
NC
49
PCIE_CLK-
50
NC
51
GND
52
PLT_RST
53
NC
54
NC
55
PCIE_WAKE
56
W_DIS
57
GND
58
NC
59
NC
60
NC
61
NC
62
NC
63
GND
64
NC
All manuals and user guides at all-guides.com

15
65
NC
66
NC
67
NC
68
CLK_REQ
69
GND
70
+3.3V
71
NC
72
+3.3V
73
NC
74
+3.3V
75
GND
CN1: EC Debug Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
EC_EPP_STB#
11
EC_EPP_BUSY
2
EC_EPP_PD0
12
EC_EPP_KSI5
3
EC_EPP_PD1
13
EC_EPP_KSI4
4
EC_EPP_PD2
14
EC_EPP_AFD#
5
EC_EPP_PD3
15
NC
6
EC_EPP_PD4
16
EC_EPP_INIT#
7
EC_EPP_PD5
17
EC_EPP_SLIN#
8
EC_EPP_PD6
18
GND
9
EC_EPP_PD7
19
GND
10
NC
20
GND
SATA_PWR1,SATA_PWR2: SATA Power Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+V12S
2
GND
3
GND
4
+V5S
COM4: Internal RS-422/485 Serial Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RXD485#
2
RXD485+
3
TXD485+
4
TXD485#
All manuals and user guides at all-guides.com

16
TPM1: Trusted Platform Module Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LCLK
2
GND
3
LFRAME#
4
KEY
5
LRERST#
6
+5V
7
LAD3
8
LAD2
9
+3.3V
10
LAD1
11
LAD0
12
GND
13
SCL
14
SDA
15
SB3V
16
SERIRQ
17
GND
18
GLKRUN#
19
LPCPD#
20
LDRQ#
All manuals and user guides at all-guides.com

17
Board Layout: Jumper and Connector Locations
(Unit: mm)
All manuals and user guides at all-guides.com
