IEI Technology HYPER-KBN User manual

HYPER-KBN
Page I
User Manual
HYPER-KBN
MODEL:
PICO-ITX SBC with AMD® G-Series SoC Processor,
DDR3, DVI-I/LVDS, GbE, USB 3.0,
SATA6Gb/s,Audio and RoHS
Rev. 1.02 - 27 December, 2013
HYPER-KBN CPU Card

HYPER-KBN
Page II
Revision
Date Version Changes
27 December, 2013 1.02 Update Appendix D: Example program for WDT
27 November, 2013 1.01 Update Section 2.3: Packing List
21 October, 2013 1.00 Initial release

HYPER-KBN
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

HYPER-KBN
Page IV
Table ofContents
1 INTRODUCTION........................................................................................................... 1
1.1 INTRODUCTION ........................................................................................................... 2
1.2 MODEL VARIATIONS..................................................................................................... 2
1.3 FEATURES ................................................................................................................... 3
1.4 CONNECTORS.............................................................................................................. 4
1.5 DIMENSIONS................................................................................................................ 5
1.6 DATA FLOW................................................................................................................. 6
1.7 TECHNICAL SPECIFICATIONS........................................................................................ 7
2 UNPACKING .................................................................................................................. 9
2.1 ANTI-STATIC PRECAUTIONS........................................................................................ 10
2.2 UNPACKING PRECAUTIONS ........................................................................................ 10
2.3 PACKING LIST.............................................................................................................11
2.4 OPTIONAL ITEMS ....................................................................................................... 12
3 CONNECTORS............................................................................................................. 13
3.1 PERIPHERAL INTERFACE CONNECTORS....................................................................... 14
3.1.1 HYPER-KBN Layout........................................................................................ 14
3.1.2 Peripheral Interface Connectors ..................................................................... 15
3.1.3 External Interface Panel Connectors............................................................... 16
3.2 INTERNAL PERIPHERAL CONNECTORS......................................................................... 16
3.2.1 AT/ATX Mode Select Switch............................................................................. 16
3.2.2 Audio Connector.............................................................................................. 17
3.2.3 Battery Connector............................................................................................ 18
3.2.4 Buzzer Connector............................................................................................. 19
3.2.5 Clear CMOS Button......................................................................................... 20
3.2.6 DDR3 SO-DIMM Slot...................................................................................... 21
3.2.7 Front Panel Connector .................................................................................... 21
3.2.8 LAN LED Connector........................................................................................ 22
3.2.9 LVDS LCD Connector ..................................................................................... 23
3.2.10 LVDS Backlight Inverter Connector.............................................................. 24

HYPER-KBN
Page V
3.2.11 Power Button Connector................................................................................ 25
3.2.12 Reset Button Connector ................................................................................. 26
3.2.13 RS-232 Serial Port Connector....................................................................... 26
3.2.14 SATA 6Gb/s Drive Connector ........................................................................ 27
3.2.15 SATA Power Connector.................................................................................. 28
3.2.16 SPI Flash Connector...................................................................................... 29
3.2.17 System Fan Connector................................................................................... 29
3.2.18 USB Connector .............................................................................................. 30
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ............................................. 31
3.3.1 DVI Connector................................................................................................. 32
3.3.2 LAN Connectors............................................................................................... 32
3.3.3 Power Connectors............................................................................................ 33
3.3.4 USB Connectors............................................................................................... 34
4 INSTALLATION........................................................................................................... 35
4.1 ANTI-STATIC PRECAUTIONS........................................................................................ 36
4.2 INSTALLATION CONSIDERATIONS ................................................................................ 36
4.3 SO-DIMM INSTALLATION.......................................................................................... 38
4.4 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................... 39
4.4.1 Audio Kit Installation....................................................................................... 39
4.4.2 SATA Drive Connection ................................................................................... 40
4.4.3 Single RS-232 Cable........................................................................................ 41
4.5 EXTERNAL PERIPHERAL INTERFACE CONNECTION....................................................... 42
4.5.1 DVI Display Device Connection...................................................................... 42
4.5.2 LAN Connection............................................................................................... 43
4.5.3 USB Connection............................................................................................... 44
4.6 HEAT SINK ENCLOSURE ............................................................................................. 45
5 BIOS.............................................................................................................................. 47
5.1 INTRODUCTION ......................................................................................................... 48
5.1.1 Starting Setup................................................................................................... 48
5.1.2 Using Setup...................................................................................................... 48
5.1.3 Getting Help..................................................................................................... 49
5.1.4 Unable to Reboot after Configuration Changes.............................................. 49
5.1.5 BIOS Menu Bar................................................................................................ 49

HYPER-KBN
Page VI
5.2 MAIN ........................................................................................................................ 50
5.3 ADVANCED ................................................................................................................ 51
5.3.1 ACPI Settings................................................................................................... 52
5.3.2 RTC Wake Settings........................................................................................... 52
5.3.3 CPU Configuration.......................................................................................... 54
5.3.4 IDE Configuration ........................................................................................... 55
5.3.5 USB Configuration........................................................................................... 56
5.3.6 F81216 Super IO Configuration...................................................................... 57
5.3.6.1 Serial Port 1 Configuration...................................................................... 58
5.3.7 Serial Port Console Redirection ...................................................................... 59
5.3.7.1 Console Redirection Settings .................................................................... 60
5.4 CHIPSET.................................................................................................................... 62
5.4.1 GFX Configuration.......................................................................................... 63
5.4.2 South Bridge Configuration............................................................................. 63
5.4.3 North Bridge Configuration............................................................................. 65
5.4.4 VUMA INT15 Config Select............................................................................. 66
5.5 BOOT........................................................................................................................ 68
5.6 SECURITY.................................................................................................................. 70
5.7 EXIT.......................................................................................................................... 70
A BIOS MENU OPTIONS .............................................................................................. 72
B ONE KEY RECOVERY................................................................................................ 75
B.1 ONE KEY RECOVERY INTRODUCTION ......................................................................... 76
B.1.1 System Requirement......................................................................................... 77
B.1.2 Supported Operating System........................................................................... 78
B.2 SETUP PROCEDURE FOR WINDOWS............................................................................ 79
B.2.1 Hardware and BIOS Setup .............................................................................. 80
B.2.2 Create Partitions............................................................................................. 80
B.2.3 Install Operating System, Drivers and Applications....................................... 84
B.2.4 Building the Recovery Partition...................................................................... 85
B.2.5 Create Factory Default Image......................................................................... 87
B.3 AUTO RECOVERY SETUP PROCEDURE ........................................................................ 92
B.4 SETUP PROCEDURE FOR LINUX ................................................................................. 96
B.5 RECOVERY TOOL FUNCTIONS .................................................................................. 100
B.5.1 Factory Restore ............................................................................................. 101

HYPER-KBN
Page VII
B.5.2 Backup System............................................................................................... 102
B.5.3 Restore Your Last Backup.............................................................................. 103
B.5.4 Manual........................................................................................................... 104
B.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN ....................................... 105
B.6.1 Configure DHCP Server Settings.................................................................. 106
B.6.2 Configure TFTP Settings............................................................................... 107
B.6.3 Configure One Key Recovery Server Settings............................................... 108
B.6.4 Start the DHCP, TFTP and HTTP................................................................. 109
B.6.5 Create Shared Directory................................................................................ 109
B.6.6 Setup a Client System for Auto Recovery .......................................................110
B.7 OTHER INFORMATION ..............................................................................................113
B.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller........................113
B.7.2 System Memory Requirement .........................................................................115
C TERMINOLOGY.........................................................................................................116
D WATCHDOG TIMER ................................................................................................ 121
E HAZARDOUS MATERIALS DISCLOSURE........................................................... 124
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS ROHS
COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY................................................... 125

HYPER-KBN
Page VIII
List of Figures
Figure 1-1: HYPER-KBN.................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: Dimensions (mm)........................................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations (Front)..............................................................14
Figure 3-2: Connector and Jumper Locations (Rear)...............................................................15
Figure 3-3: AT/ATX Mode Select Switch Location ....................................................................17
Figure 3-4: Audio Connector Location.......................................................................................18
Figure 3-5: Battery Connector Location.....................................................................................19
Figure 3-6: Battery Connector Location.....................................................................................19
Figure 3-7: Clear CMOS Button Location...................................................................................20
Figure 3-8: DDR3 SO-DIMM Slot Location..................................................................................21
Figure 3-9: Front Panel Connector Location .............................................................................22
Figure 3-10: LAN LED Connector Location ...............................................................................23
Figure 3-11: LVDS Connector Location......................................................................................23
Figure 3-12: Backlight Inverter Connector Location.................................................................24
Figure 3-13: Power Button Connector Location........................................................................25
Figure 3-14: Reset Button Connector Location.........................................................................26
Figure 3-15: RS-232 Serial Port Connector Location................................................................27
Figure 3-16: SATA 6Gb/s Drive Connector Location ................................................................28
Figure 3-17: SATA Power Connector Location .........................................................................28
Figure 3-18: SPI Flash Connector Location...............................................................................29
Figure 3-19: System Fan Connector Locations.........................................................................30
Figure 3-20: USB Connector Locations......................................................................................31
Figure 3-21: External Peripheral Interface Connector..............................................................31
Figure 3-22: LAN Connector........................................................................................................33
Figure 4-1: SO-DIMM Installation ................................................................................................38
Figure 4-2: Audio Kit Cable Connection.....................................................................................39
Figure 4-3: SATA Drive Cable Connection.................................................................................40
Figure 4-4: Single RS-232 Cable Installation .............................................................................41
Figure 4-5: DVI Connector ...........................................................................................................43

HYPER-KBN
Page IX
Figure 4-6: LAN Connection........................................................................................................44
Figure 4-7: USB Connector..........................................................................................................45
Figure 4-8: Heat Sink Retention Screws.....................................................................................46
Figure B-1: IEI One Key Recovery Tool Menu ...........................................................................76
Figure B-2: Launching the Recovery Tool.................................................................................81
Figure B-3: Recovery Tool Setup Menu .....................................................................................81
Figure B-4: Command Prompt ....................................................................................................82
Figure B-5: Partition Creation Commands.................................................................................83
Figure B-6: Launching the Recovery Tool.................................................................................85
Figure B-7: Manual Recovery Environment for Windows........................................................85
Figure B-8: Building the Recovery Partition..............................................................................86
Figure B-9: Press Any Key to Continue .....................................................................................86
Figure B-10: Press F3 to Boot into Recovery Mode..................................................................87
Figure B-11: Recovery Tool Menu ..............................................................................................87
Figure B-12: About Symantec Ghost Window...........................................................................88
Figure B-13: Symantec Ghost Path ............................................................................................88
Figure B-14: Select a Local Source Drive ..................................................................................89
Figure B-15: Select a Source Partition from Basic Drive .........................................................89
Figure B-16: File Name to Copy Image to ..................................................................................90
Figure B-17: Compress Image.....................................................................................................90
Figure B-18: Image Creation Confirmation................................................................................91
Figure B-19: Image Creation Complete......................................................................................91
Figure B-20: Image Creation Complete......................................................................................91
Figure B-21: Press Any Key to Continue ...................................................................................92
Figure B-22: Auto Recovery Utility.............................................................................................93
Figure B-23: Launching the Recovery Tool...............................................................................93
Figure B-24: Auto Recovery Environment for Windows ..........................................................93
Figure B-25: Building the Auto Recovery Partition...................................................................94
Figure B-26: Factory Default Image Confirmation ....................................................................94
Figure B-27: Image Creation Complete......................................................................................95
Figure B-28: Press any key to continue.....................................................................................95
Figure B-29: Partitions for Linux.................................................................................................97
Figure B-30: Manual Recovery Environment for Linux ............................................................98
Figure B-31: Access menu.lst in Linux (Text Mode).................................................................99
Figure B-32: Recovery Tool Menu ..............................................................................................99

HYPER-KBN
Page X
Figure B-33: Recovery Tool Main Menu...................................................................................100
Figure B-34: Restore Factory Default.......................................................................................101
Figure B-35: Recovery Complete Window...............................................................................102
Figure B-36: Backup System.....................................................................................................102
Figure B-37: System Backup Complete Window ....................................................................103
Figure B-38: Restore Backup ....................................................................................................103
Figure B-39: Restore System Backup Complete Window......................................................104
Figure B-40: Symantec Ghost Window ....................................................................................104

HYPER-KBN
Page XI
List of Tables
Table 1-1: HYPER-KBN Model Variations.....................................................................................2
Table 1-2: Technical Specifications..............................................................................................8
Table 3-1: Peripheral Interface Connectors...............................................................................16
Table 3-2: Rear Panel Connectors ..............................................................................................16
Table 3-3: AT/ATX Mode Select Switch Settings.......................................................................17
Table 3-4: Audio Connector Pinouts ..........................................................................................18
Table 3-5: Battery Connector Pinouts........................................................................................19
Table 3-6: Battery Connector Pinouts........................................................................................20
Table 3-7: Clear CMOS Button Settings.....................................................................................20
Table 3-8: Front Panel Connector Pinouts.................................................................................22
Table 3-9: LAN LED Connector Pinouts.....................................................................................23
Table 3-10: LVDS Connector Pinouts.........................................................................................24
Table 3-11: Backlight Inverter Connector Pinouts....................................................................25
Table 3-12: Power Button Connector Pinouts...........................................................................25
Table 3-13: Reset Button Connector Pinouts............................................................................26
Table 3-14: RS-232 Serial Port Connector Pinouts ...................................................................27
Table 3-15: SATA Power Connector Pinouts.............................................................................28
Table 3-16: SPI Flash Connector Pinouts ..................................................................................29
Table 3-17: System Fan Connector Pinouts ..............................................................................30
Table 3-18: USB Connector Pinouts...........................................................................................31
Table 3-19: DVI Connector Pinouts.............................................................................................32
Table 3-20: LAN Pinouts ..............................................................................................................33
Table 3-21: Connector LEDs........................................................................................................33
Table 3-22: Power Connector Pinouts........................................................................................34
Table 3-23: USB 3.0 Port Pinouts................................................................................................34
Table 5-1: BIOS Navigation Keys................................................................................................49

HYPER-KBN
Page XII
List ofBIOS Menus
BIOS Menu 1: Main.......................................................................................................................50
BIOS Menu 2: Advanced..............................................................................................................51
BIOS Menu 3: ACPI Configuration..............................................................................................52
BIOS Menu 4: RTC Wake Settings ..............................................................................................53
BIOS Menu 5: CPU Configuration...............................................................................................54
BIOS Menu 6: IDE Configuration.................................................................................................55
BIOS Menu 7: USB Configuration...............................................................................................56
BIOS Menu 8: Super IO Configuration........................................................................................57
BIOS Menu 9: Serial Port 1 Configuration Menu.......................................................................58
BIOS Menu 10: Serial Port Console Redirection.......................................................................59
BIOS Menu 11: Console Redirection Settings...........................................................................60
BIOS Menu 12: Chipset ................................................................................................................62
BIOS Menu 13: GFX Configuration.............................................................................................63
BIOS Menu 14: South Bridge Configuration..............................................................................64
BIOS Menu 15: North Bridge Configuration ..............................................................................65
BIOS Menu 16: VUMA INT15 Configuration...............................................................................66
BIOS Menu 17: Boot.....................................................................................................................68
BIOS Menu 18: Security...............................................................................................................70
BIOS Menu 19:Exit........................................................................................................................71
BIOS Menu 20: IEI Feature...........................................................................................................96

HYPER-KBN
Page 1
1Introduction
Chapter
1

HYPER-KBN
Page 2
1.1 Introduction
Figure 1-1: HYPER-KBN
The HYPER-KBN PICO-ITX motherboard is an AMD® G-Series SoC processor platform.
It supports one 1600/1333 MHz DDR3 SO-DIMM up to 8.0 GB.
The HYPER-KBN includes a LVDS connector and a DVI-I connector. Expansion and I/O
include two USB 3.0 connectors on the rear panel, two USB 2.0 connectors by pin header
and one SATA 6Gb/s connector. Serial device connectivity is provided by one internal
RS-232 connector. One RJ-45 Ethernet connector provides the system with smooth
connections to an external LAN.
1.2 Model Variations
The model variations of the HYPER-KBN Series are listed below.
ModelNo. SoC
HYPER-KBN-4151-R10 AMD® G-Series GX-415GA, 15W, 1.5GHz
HYPER-KBN-2101-R10 AMD® G-Series GX-210HA, 9W, 1.0GHz
Table 1-1: HYPER-KBN Model Variations

HYPER-KBN
Page 3
1.3 Features
Some of the HYPER-KBN motherboard features are listed below:
PICO-ITX form factor with AMD® G-Series SoC processor supports DDR3
1600/1333 MHz memory
12V only single voltage design for AT/ATX power by DC power jack
DVI-I and 18-bit single channel LVDS support for dual displays
IEI One Key Recovery solution allows you to create rapid OS backup and
recovery

HYPER-KBN
Page 4
1.4 Connectors
The connectors on the HYPER-KBN are shown in the figure below.
Figure 1-2: Connectors

HYPER-KBN
Page 5
1.5 Dimensions
The dimensions of the board are listed below:
Figure 1-3: Dimensions (mm)

HYPER-KBN
Page 6
1.6 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram

HYPER-KBN
Page 7
1.7 TechnicalSpecifications
HYPER-KBN technical specifications are listed below.
Specification HYPER-KBN
SoC AMD® G-Series SoC processor
Memory One 204-pin 1600/1333 MHz single-channel DDR3 SO-DIMM
supported (system max. 8GB)
BIOS UEFI BIOS
Ethernet 1 x PCIe GbE by Realtek RTL8111E with ASF 2.0 support
Graphics GPU frequency 300MHz (Radeon™ HD 8310E), DirectX ®
11.1, UVD4.2, HDMI™ 1.4a, DisplayPort 1.2
Display Output Dual display support
1 x DVI-I (1920x1200@60Hz)
1 x 18-bit single channel LVDS (1600x900@60Hz)
UART IC Fintek F81216AD
Audio Realtek ALC662 HD Audio codec
Watchdog Timer Software programmable supports 1~255 sec. system reset
I/O Interface Connectors
Audio Connector 1 x Analog audio by 10-pin (2x5) header
Ethernet One RJ-45 port
Fan 1 x 4-pin system fan connector
Serial Ports 1 x RS-232 by 10-pin (2x5) header
USB Ports 2 x USB3.0 (on rear I/O)
2 x USB2.0 by 8-pin (2x4) header
Front Panel 1 x 6-pin (1x6) wafer for power LED & HDD LED
1 x 2-pin (1x2) wafer for power button
1 x 2-pin (1x2) wafer for reset button
LAN LED 1 x 2-pin (1x2) header
Storage

HYPER-KBN
Page 8
Specification HYPER-KBN
Serial ATA 1 x SATA6Gb/s with 5V SATA power connector (NO RAID)
Environmentaland Power Specifications
Power Supply 12V DC power input only, AT/ATX supported
1 x External DC power jack
Power Consumption TBD
Operating Temperature -10°C ~ 60°C
Storage Temperature -20°C ~ 85°C
Humidity 5% ~ 95% (non-condensing)
PhysicalSpecifications
Dimensions 100 mm x 72 mm
Weight GW/NW 600 g / 250 g
Table 1-2: Technical Specifications
