iHome iH11 User manual

Model iH11
Alarm Clock for
your iPod ®
Questions? Visit www.ihomeaudio.com
Model:iH11
InstructionManual
Date:March5,08
Printcolor:Blacktextonwhitepaper
Size:178Wx140Hmm

1
2
3
3
4
5
5
6
6
7
8
8
9
10
11
12
Quick Start
Controls and Indicators
iH11 Display
Install Clock Backup Battery
Using The Optional Remote Control
Install/Replace the Remote Control Battery
To check for iPod compatibility
Setting Up the iH11
Charging your iPod
Listening to your iPod
Listening to non-docking iPod or other portable audio devices
Alarm Operation
Sleep Operation
Snooze/Dimmer Operation
A Consumer Guide to Product Safety
Trouble Shooting
Solución De Problemas
Warranty Information
Table of Contents
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material
should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine, thinner
or similar materials can damage the surface of the unit.
Maintenance

FCC Information
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and , if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
SDI Technologies Inc.
1299 Main Street,
Rahway
NJ 07065
Tel. No.: [phone]

1
Quick Start
2:inserts
Select the dock insert for your
iPod model from the table below
and place insert in dock.
Never dock an iPod without
an insert in place.
3:iPod
Insert iPod into dock with proper
insert (iPod must not be in a skin or
case). iPod will charge while docked.
Press iPod Button on iH11 to play
iPod.
4:time • Move the DST switch on the back of the unit to +1 or -1 (adds or
subtracts an hour to account for daylight saving time).
• Press & Hold the Clock adj. button on the back of the unit until
the display flashes.
• Press the Hour Set / Minute buttons to set current time.
• Press the Clock Adj. button again to confirm time setting.
NOTE: If the insert for your iPod isn’t listed, please visit an Apple store or www.ihomeaudio.com
to purchase the proper insert.
iPod Touch
thin iPod with video (30 GB)
Insert 9
3rd Gen nano
insert 13
3rd Gen nano
iPod with video (60,80 GB)
Insert 10
thin (30 GB) iPod with video
thin (80GB) iPod classic
thick (60, 80 GB) iPod with video
thick (160 GB) iPod classic
iPod Touch
insert 14
For this iPod
Use this insert
1:power
Attach AC adaptor cable to jack on
back of the iH11 and plug the other
end into a wall socket.
DC 10Vline in clock adj.
dst
-1 +1 on o

Controls and Indicators
Front Panel
Power Off /
Alarm Reset Button 
 Volume + Button
iPod Dock
 iPod Play/Pause Button
 Volume - Button
DST Switch 
Snooze/Dimmer Button 
Remote Sensor
Back Panel
2
 DC Jack
Alarm Set /
Alarm On/Off Button 
Clock Adj. Button 
 Hour Set Button
 Sleep/Minute Set Button
 EXB Expanded Bass Switch
Line-in Jack 
DC 10Vline in clock adj.
dst
-1 +1 on o

Installing Backup Battery
3
iH11 Display
Install Clock Backup Battery
PM Indicator
Battery Low Indicator
Daylight Saving Time
Indicator
iPod Indicator
Sleep Indicator
Alarm Indicator
Time Display
The iH11 uses a CR2032 button cell backup battery system to provide
continuous alarm operation and clock settings in the event of a power
failure. If the Backup Battery has been installed and a power failure
occurs or the AC adaptor is accidentally disconnected, the display backlight
will not remain lit, but current time and alarm time settings will be temporarily
maintained. Otherwise, you must reset the time and alarm settings.
1. Please make sure the AC adaptor is connected. Otherwise all settings may
be lost during battery replacement.
2. Open backup battery compartment door located on the backside of the unit.
3. Insert one CR2032 button cell battery, checking that the polarity (+ and
– sides of the battery) matches the drawing in the battery compartment.
Close the compartment door.
Note: Make sure you dispose of batteries properly (see your local regulations).


Install/Replace the Remote Control Battery
The remote control battery is already installed at the factory. When the
remote control stops operating or its range seems reduced, it is time
to replace the battery with a new one.
1. The battery door is located on the back end of the remote control.
2. Pull the battery door to release the battery door latch and take out
the battery.
3. Insert a CR2032 battery, checking that the + and – sides of the
battery match the drawing inside the battery compartment.
4. Replace the battery door.
Note: Make sure you dispose of batteries properly (see your local regulations).
The Remote Control controls basic functions on the iH11 and certain iPod functions when the iPod is docked in the iH11.
For best results, aim remote control towards the remote sensor on the left side of the unit.
To check for iPod compatibility
iH11 is an advanced system and supports most updated iPod features. To ensure your iPod works properly with the iH11,
please update your iPod firmware with the latest version, available through iTunes.
Installing Remote Battery



 Power Off /Alarm Reset Button
 Snooze/Dimmer Button
Volume - Button  Reverse Button
 Forward Button
 Volume + Button
 Mute Button
 iPod Play/Pause Button
Sleep Button 
4
Using The Optional Remote Control Unit

Setting the Clock Time
Note: Press the Clock Adj. Button once during normal operation to view the current time display format (12 hour or 24
hour format). 12 hour is the default format.
1. Press and hold the Clock Adj. Button for 2 seconds until the display flashes. Press the Hour Set Button until the
current hour is displayed. Next, press the Sleep/Minute Set Button to set the current minute.
2. Press the Clock Adj. Button again to confirm the clock setting. You should hear 2 beeps indicating the clock time is
set.
3. For 12 hour or 24 hour time format setting: Press the Alarm Set Button during time setting to set 12-hour or 24-hour
display format. Remember to set the correct AM or PM time (an icon to the right of the time display is the PM indicator;
there is no AM indicator).
4. During daylight saving time, set the DST Switch located on the backside of the unit to +1 to advance the time one
hour. The DST Icon will appear next to the time display to indicate DST is on. Set the switch to -1 to quickly set the time
back one hour at the end of daylight saving time.
5
Setting Up the iH11
Note: Please make sure you are using the correct insert for your iPod (see page 1) and that it is properly docked into the
iH11. Failure to do so may damage your iPod.
1. While your iPod is docked in the unit and the unit is connected to AC power, it recharges (until fully charged). The iH11
will not overcharge your iPod. Note that other non-docking iPods will NOT charge.
Charging your iPod

1. Dock the already playing iPod. The iH11 will automatically turn on and you will hear the music playing from your iPod.
The iPod Icon will appear at the right lower corner the display, indicating iPod playing mode.
For enhanced bass, slide the EXB Expanded Bass Switch located on the back of the unit to the ON position.
Note: If the playing song/music loudness is too low on the iPod itself, the iH11 may not detect that the iPod is in play mode.
Press the iPod Play/Pause Button on the iH11 or remote control twice to play it.
2.
When the iPod is docked and in standby mode, press the  iPod Play/Pause Button on the iH11 or remote control to play
it. The iPod Icon will appear at the right lower corner the display, indicating iPod playing mode.
3. Press the iPod Play/Pause Button again to pause play; press again to resume it.
4. Press the Volume + and Volume – Button on the iH11 or remote control to adjust the system volume. Press the
Mute Button on the remote control to mute the output; press Mute again to release it.
5. Press the >> or << (forward or reverse) Button on the remote control to go to the next or previous track. Press
and hold while a track is playing for high speed forward or reverse music search of the current track.
6. To turn the iH11 OFF, press the Alarm Reset/Power Off Button on the iH11 or remote control. Your iPod will
continue charging while in the dock.
6
Listening to your iPod
If you are using an iPod without a docking port or other MP3 player or portable audio device, you can still play it through
the iH11 via the Line-in Jack.
1. Plug one end of an audio patch cord (available at www.ihomeaudio.com) into the headphone or line-out jack on
your device and the other end of the patch cord into the iH11 Line-in Jack, located on the back of the unit.
2. Press the iPod Play/Pause Button on the iH11 or remote control to turn the iH11 on. The iPod Icon will appear at
the lower right corner the display, indicating Line-in playing mode.
3. Turn on and play your device.
4. Press the Volume + and Volume – Button on the iH11 or remote control to adjust the system volume. You may
need to adjust your device volume, too.
5. To turn othe iH11 OFF, press the Alarm Reset/Power Off Button on the iH11 or remote control. Please remember
to turn off your device, too.
Listening to a non-docking iPod or other portable audio devices

The iH11 Home System for iPod features “Sure Alarm”. If a power failure occurs or the AC adaptor is accidentally
disconnected, the unit will change to buzzer alarm to wake you up (provided you have installed backup battery).
This unit also features Gentle Waking, which gradually increases the volume of whatever alarm you set.
NOTE: TO WAKE TO iPod, YOUR iPod MUST BE PROPERLY DOCKED AND OFF (NOT IN PLAY MODE) OR NO
ALARM WILL SOUND. You CANNOT wake to Line in audio devices.
Setting the Alarm Time
1. Press and hold the Alarm Set Button for 2 seconds until the display flashes. Press the Hour Set Button until the
desired alarm hour is displayed. Next, press the Sleep/Minute Set Button to set the desired alarm minute.
Remember to set the correct AM or PM if you are using 12 hour clock format.
2. Press the Alarm Set Button again to exit the setting mode. You should hear 2 beeps indicating the alarm is set.
Note: Once you set the alarm time, the alarm will be automatically armed, indicated by the Alarm Icon. To disarm the alarm,
press the Alarm Set Button. The Alarm Icon will disappear and the alarm will not sound at the set time.
Note: Make sure to adjust volume level for comfortable wake up volume
4. When the alarm is sounding, the Alarm Icon will flash.
• To snooze during the alarm, press the Snooze/Dimmer Button. The alarm will be silenced for 9 minutes, then come
on again.
• To turn the alarm off, press the Alarm Reset/Power Off Button. The alarm will come on again the next day at the
same time.
5. If the alarm is not turned off after it sounds, it will play for approximately one hour then turn off automatically. This cycle
will repeat every 24 hours unless the controls are changed.
Note: Please make sure your iPod has enough songs to play for one hour, otherwise please set the iPod repeat mode to ON.
Note: If there is no iPod present or there is no music detected on the iPod at alarm time, the iH11 will automatically switch to
buzzer alarm.
7
Alarm Operation
